I.B.U. Electronics IBU2 Manual

Full Option Electronic Board for R/C Trucks
Operating & Installation Manual

Contents
1 Introduction
2 Features
3 The IBU2 Truck
4 Connecting radio and radio configuration
5 Controls
6 Changing sounds
7 Configuration settings
8 Trou le shooting
9 Authorised dealers
10 Follow us

1 INTRODUCTION
The IBU2 Truck is a Multi-Function Controller for Radio Controlled Trucks, featuring realistic sound
effects and lighting all from a hobby grade channel radio set (AM, FM, 2. Ghz) sold separately.
2 FEATURES
•Sound effects are fully user definable via supplied microSD card, so any type of
truck can be selected or something totally unique.
•Fully synchronized sounds with truck actions, including engine start-up and
shutdown, rev up, brake, reverse beep, horn, indicators, change of speed, gear
selection, air discharge, trailer hook up, and many more.
•User settings changeable via the supplied microSD card, no special software
required.
•User can define top speed 0-100%
•User can define restricted reverse speed for added realism. 0-100% based on set
forward speed
•Compactable with Tamiya lighting tractor unit and trailer units.
•Lighting effects controlled via the remote using channel radio set. Including
hazards, head lights and tail lights, high beam, fog lights.
•Automatic synchronized features like reverse beep and reverse light during
reversing, brake sounds and brake light when braking, indicators during slow speed
turns.
•Cab vibration unit
(Sold separately)
control for realism. User changeable settings via
supplied microSD card.
•Modern ESC allowing ultra realistic speed control even at slow speeds. And higher
efficiency allowing longer battery run time.
•User changeable protection. IBU2 Truck protected by 2A fuse and 10A fuse for ESC.
No more sending back to manufacturer for repair after accidental electrical short.
•Built in battery monitoring to protect your batteries.
•Supports 2S LiPo, 6 cell Ni-Cd, 6 cell Mi-MH batteries.
•Optional audio upgrade unit, allowing twin speakers and twin volume control. 1
dedicated to engine, 1 dedicated to sound effects each rated at 6w.
•Small dimensions at 103 x 65 x 25mm, leaving more space in cab for interior detail.

3. THE IBU2 TRUCK
Layout of the IBU2 Truck.
Connector Utilization
Vi ration Motor Output for cabin vibration motor
Speaker 2W audio output @ 8 ohms ( W @ Ohms)
High Beam High beam lights output
Right Winker Right turn indicator output
Left Winker Left turn indicator output
Fog Lights Front fog lights output
Reverse Lights Reverse light output
Rear /Brake Lights Rear/brake lights output
Headlights Headlight/Side lights output
Coupler Switch Trailer micro switch input
Battery Power input
Motor Output Motor output
Audio Volume Audio volume regulation
Service Fuse Protection fuse for services (2A)
Motor Fuse Protection fuse for traction motor (10A)
Gear Shift Servo Gear shift servo output
Steer Servo
Trailer Latch
Steering servo output
Trailer latch servo output

BOARD SETTINGS
After installing the board on the truck set the type of battery used through the dip switch on the
board below.
Battery Type Switch 1
Li-Po battery (*) ON
Ni-Mh or Ni-Cd (*) OFF
Radio Programming Switch 2
Programming mode ON
Normal mode OFF
(*) Monitors the voltage of the battery pack. When this becomes low the alarm sound is played.
Further use on a low battery will lead to the truck turning off.

CONNECTING RADIO AND CONFIGURATION
•Connect the receiver with cables (included) referring to the figure and the table below.
•Make sure to have no reverse or dual /rate active on radio channels.
•Turn on the truck and the radio transmitter.
•Wait until the receiver is aligned to the transmitter. (when aligned the low beam lights will
stop blinking and stay lit)
•Move the dip switch 2 to ON.
•Move both stick to the radio in all directions until it stops.
•Move the dip switch 2 to OFF.
•The board is now configured for use with the radio / receiver connected to it.
Receiver connected (cable inserted corresponds to channel 1)
Inputs IBU2
Connect to the channel relative to the stick / command you want to use
CH1 Acceleration / reverse
CH2 Steer
CH3 Lights, horn
CH4 Gear shift

5CONTROLS
•Switch on the truck, the head light will flash.
•Turn on the radio, the head lights remain on and you hear the horn sound.
•At this point you can activate certain functions such as:
High beam lights, fog lights, indicators, emergency lights, horn 1 & 2, coupling / uncoupling
trailers.
•Start the engine of the truck (right stick diagonally lower left for 5 seconds) and wait for the
engine to finish starting up and starts idling.
•Engage a gear and bring the left stick forward or backward to move, make sure the truck is
moving in the right direction.
•Try to steer right and left and check that the wheels are moving in the right direction, check
also the activation of turning indicator lights.
NOTE
If some of the movements are reversed compared to the command you need to reverse its own
channel on the radio, or change the parameter for the channel in the file "IBU2_TR.ini" in the root
of the microSD board inserted in IBU2 (see chapter 7 below).

Additional controls availa le from the radio controller
•Head light control (default = ON)
Right stick in the top left corner for 1-2 seconds to turn on / off the lights
•High eam lights control stick right up to 1-2 seconds to turn on / off high beam lights
•Fog lights control right stick down for 1-2 seconds to turn on / off lights
•Emergency lights control right stick in the upper right corner for 1-2 seconds to turn on / off
the emergency lights
•Latch/unlatch trailer right stick in the bottom right corner for 1-2 seconds to hook/unhook the
trailer
•Horn 1 right stick up (about 25% of the movement) to play the sound effect of the horn 1
•Horn 2 right stick down (about 25% of the movement) to play the sound effect of the horn 2
•Revving the engine with out moving truck, right stick up (about a 25% of the movement
useful) to play the sound effect of the engine revving.
•Air exhaust from the air rake reservoir right stick down (about 25% of the movement useful)
to play the sound effect of the exhaust air

6CHANGING THE SOUNDS
On the supplied microSD are provided customized sound effects for a several number of trucks.
Note: To fully enjoy the sound quality it is recommended to use the original Tamiya
tm
speaker's or
a speaker of good quality available from your local dealer.
To select the set of sounds appropriate for the truck on which is installed the IBU2, do the
following:
1. With power OFF, press lightly on the microSD inserted under the IBU2 to release the microSD
memory card (NOTE: DO NOT PULL THE MICROSD TO UNLOCK !!!), pull it out and insert into a
memory card reader (not supplied) on your PC, MAC.
2. Access the media and browse its contents.
3. In the root of the media are the files used by the sound module of IBU2.
Each wave file is associated with a different sound effect according to the correspondence
set in the file "IBU2_TR.INI":
Varia le in the file IBU2_TR.ini Es. Audio file Corresponding effect
Engine Cold ON estartc.wav Starting a cold engine
Engine Warm ON estartw.wav Starting the engine hot
Engine Stop estop.wav Engine stop
Engine Idle eidle.wav Engine idling
Engine Step 1 es01.wav Motor Ramp 1
Engine Step 2 es02.wav Motor Ramp 2
...
Engine Step XX esXX.wav Motor Ramp XX
Revup revup.wav acceleration
Revdw revdw.wav deceleration
Air last1 air st1.wav 1 air vent
Air last2 air st2.wav Air vent 2
Air last3 air st3.wav Air vent 3
Air last4 air st4.wav Air vent 4
AlarmRev alarmrev.wav Reverse Alarm
AlarmBatt alarm .wav Battery Alarm
Brake rake.wav raking
Dryer dryer.wav air vent dryer
Horn1 horn1.wav Clacson1
Horn2 horn2.wav Clacson2
Latch latch.wav trailer coupling
Unlatch unlatch.wav release trailer
Shift1 horn1.wav Clacson1
Shift2 horn2.wav Clacson2
Turn1 turn1.wav indicator 1
Turn2 turn2.wav indicator 2

. To choose a different truck set for your truck simply enter into its subfolder (e.g. "Mack") and
copy all the files in the root of the microSD, overwriting the existing ones. Check the name
matching the audio samples with the associated tags in the file IBU2_TR.INI.
5. Remove the microSD from the PC/MAC adapter and put it back into the IBU2 socket until it
clicks, turn on your truck and try new sounds included.
6. New sound sets when produced will be available to download from http://www.ibu-
electronics.com/downloads_9.html
You can also create your own sounds by replacing the sounds provided by converting a sound
effect or music from any format (WAV, MP3) in WAV format, mono, 22050 Hz, 8 bits. Each sample
must not have a size greater than 1 Mb or its reproduction will be truncated.
The names of the * .wav files are not important, as long as the file is reported IBU2.ini proper
correspondence between each file and its sound effect, and provided they are not longer than 8
characters (plus the extension ".wav") and do not contain spaces or periods.
Example
"Abcd_defg.wav" Not good (9 characters);
"Abcdefghi.wav" Okay (8 characters);
"Ab cd.wav" Not good (5 characters, but there is a space);
"Ab.cd.wav" Not good (there is a point in the middle of the name).
Note: some audio editing software is not able to successfully convert the audio in this format, or
add data that can not be read by IBU2: if you have problems in the reproduction of its
samples, please contact the manufacturer.
Also avoid reformat the microSD provided ecause some operating systems do not
properly format the media.

7CONFIGURATION SETTINGS "IBU2_TR.INI"
In addition to the associations of the sound effects with the corresponding wave file, into the text
file IBU2_TR.INI there are other variables that allow you to customize certain features of your IBU2
Truck.
Configuring the reverse channel radio
Each line refers to a specific channel receiver, this function is used, if you are using an older radio
(without memory), to avoid having to set (if necessary) the reverse channels depending on the
truck that are using
RadioCH1InverseCmd = FALSE; TRUE / FALSE
RadioCH2InverseCmd = FALSE; TRUE / FALSE
RadioCH3InverseCmd = FALSE; TRUE / FALSE
RadioCH InverseCmd = FALSE; TRUE / FALSE
In this example, all channels have value FALSE this means that no channel is applied on the
inversion, or the commands that arrive from the transmitter are reported to the decoding circuit
so as sent.
Configuring the reverse servo
If needed, you can reverse the direction of rotation of the servos, each line is related to a specific
channel, and this function is used as different manufactured servos turn in opperstie direct. This
will be truck specific.
The line:
SteerInverseCmd = FALSE; TRUE / FALSE allows you to reverse the steering control
The line:
TrailInverseCmd = FALSE;TRUE / FALSE allows to invert the command of latch/unlatch the trailer
The line:
ShiftInverseCmd = FALSE; TRUE / FALSE allows you to reverse the command of the gear shift
In this example, all channels have value FALSE this means that no channel is applied on the
inversion.
Configuring the front and rear lights
The parameter is used to configure the state of the headlights at truck power on
HeadlightInitialStatus = 1; [0 OFF - 1 ON]
In this case, the lights will be turned on at power on, by entering the value 0 (zero) the truck will
start with the lights off.
(The lights can be turned on or off even from the transmitter, see chapter 5 Controls)

Configuration of the rear lights and brake lights
The rear lights and the stop, (typically two LEDs) are powered by the same output, the output is
modulated to obtain a low intensity for the tail lights, the parameter:
TailLightIntensity = 50; [1..50]%
Allows you to adjust the brightness of the rear lights, a lower value will decrease and vice versa a
highest increase.
Since braking output is modulated at 50% if you use a value very close to this for the sidelights the
braking effect will be barely visible.
The following parameter allows you to adjust the length of time of the brake lights stay lit when
you make a brake:
BrakeDuration = 500; [100..5000] mSec
The range of values allowed is from 100 to 5000 milliseconds.
Configuring the maximum current supplied to the motor
Parameter: CurrentMotorTreshold = 10; [1..15]
Adjusts the threshold of over current monitoring protection.
The default value is 10 Amperes, it is possible in case of use of particular reducers or very heavy
truck to increase up to a maximum of 15 Ampere the current supplied to the motor.
Configuration of the power supplied to the motor
The parameter: PowerMotorScale = 100; [1..100]%
Allows to adjust the overall power delivered to the engine during running, this function calibrates
accurately the movement speed to approach to the dynamics of the real truck, a lower value will
decrease and vice versa a higher increase.
Configuration of the vibration of the cab of the truck
The parameters: MinPwmMot = 25; [0..100] and MaxPwmMot = 30; [0 ... 100]
Allow to set the minimum and the maximum speed of the vibration unit, from 1% to 100%
To turn off simply enter the value 0 in both parameters.
Configuring the maximum reverse speed
The parameter: ReverseSpeed = 50; [1 ... 100]%
Used to limit the speed during reverse.
To have same speed backwards as forwards set parameter to 100

8 TROUBLE SHOOTING
Nr. ANOMALY POSSIBLE SOLUTION
1 I turn on the truck but
nothing happens.
- The battery is exhausted: recharge
- The power connections are broken or incorrect: check
the connections from the battery
2 The engine does not start
when I hold stick down left.
- Check that the turning indicators flash, high beam and
fog lights operate in the right direction with respect to
the control stick, if not servo channels and/or reverse
settings need changing.
If correct check battery voltage, engine won’t start on a
low battery.
3 I turn on the truck but the
headlights continues to flash
-No valid RX signals received : check the connections
between the IBU2 truck and receiver
4 The turning indicators are in
opposite direction
- Reverse the channel (Ch ) in the transmitter or in the
settings file IBU2.ini
5 I have no sound - Ensure that the volume is turned up
- Ensure that the speaker is connected
- Ensure the microSD card is plugging in correctly
- Ensure that the samples are all present in the microSD
card, the correct size and properly associated to its
function in the file IBU2.ini
6 The truck moves or steers
the opposite direction
compared to controls
- Reverse the acceleration channel (Ch1) and / or steering
(Ch2) on the transmitter or in the settings file
IBU2_TR.ini
7 The servo(s) does not move - Check that the servo connector is inserted with the
correct orientation
- Check that the servo can move freely in the direction
8 The card overheats or a
burning smell
- Disconnect the battery immediately / off the wagon:
there must be some short circuit in your links!

9 Authorised Dealers
Europe / U.K. U.S.: RC Tank Electronics http://rc-truck.weebly.com/
http://rctankelectronics.weebly.com/
Europe / Italy Modeltecnica http://www.modeltecnica.it/catalog/index.php
10 Follow Us
https://www.youtube.com/channel/UC1SWKKffZzUtXBU9B4QBRAg
https://www.facebook.com/pages/IBU2-Truck/1535099413442564
Design, manufacturing and product support:
I.B.U. by Bretti Ivano
http://www.ibu-electronics.com
Via Vittorio Emanuele, 70
120 8 Sommariva del Bosco
Cuneo - Italy
C. F. BRTVNI60R03E379T
P. IVA 035076900 2
