i-PRO WV-S22500-F3LSeries User manual

1
New functions and addendum
・This document contains descriptions of how to set the new functions and their restrictions.
Refer also to the Operating Instructions of this product.
・Depending on the model used, the screens shown in the explanations may differ to the
actual camera screens.
・This document is for the following models.
Notation Model
SC384BSSeriesS
WV-S1136, WV-S1536L, WV-S1536LN, WV-S1536LN-B, WV-S1536L-B, WV-S1536LNS,
WV-S1536LTN, WV-S2136, WV-S2136-B, WV-S2136G, WV-S2136G-B, WV-S2136L,
WV-S2136L-B, WV-S2136LG, WV-S2136LG-B, WV-S2236L, WV-S2236L-B,
WV-S2236LG, WV-S2236LG-B, WV-S2536L, WV-S2536LG, WV-S2536LGN,
WV-S2536LN, WV-S2536LTN, WV-S1536LT, WV-S2536LT,
WV-S1136A, WV-S1536LA, WV-S1536LNA, WV-S1536LNA-B, WV-S1536LA-B,
WV-S1536LNSA, WV-S1536LTNA, WV-S2136A, WV-S2136A-B, WV-S2136GA,
WV-S2136GA-B, WV-S2136LA, WV-S2136LA-B, WV-S2136LGA, WV-S2136LGA-B,
WV-S2236LA, WV-S2236LA-B, WV-S2236LGA, WV-S2236LGA-B, WV-S2536LA,
WV-S2536LGA, WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA, WV-S1536LTA,
WV-S2536LTA
SC384BSSeriesH
WV-S15700-V2L Series, WV-S15500-V3L Series, WV-S22600-V2L Series,
WV-S25700-V2L Series, WV-S25500-V3L Series, WV-S25500-V3L Series,
WV-S15500-F3L Series, WV-S22500-F3LSeries, WV-S25500-F3L Series,
WV-S15600-V2L Series, WV-S22700-V2L Series, WV-S22500-V3L Series,
WV-S25600-V2L Series, WV-S15500-F6L Series, WV-S22500-F6L Series,
WV-S25500-F6L Series
fisheye
WV-S4156, WV-S4176, WV-S4556L, WV-S4556LM, WV-S4576L, WV-S4576LM,
WV-S4156A, WV-S4176A, WV-S4556LA, WV-S4556LMA, WV-S4576LA, WV-S4576LMA
Multi
WV-S8543, WV-S8543G, WV-S8543L, WV-S8543LG, WV-S8543LN, WV-S8543N
WV-S8544, WV-S8544G, WV-S8544L, WV-S8544LG, WV-S8544LN, WV-S8544N,
WV-S8563L, WV-S8563LG,WV-S8563LN,WV-S8564L,WV-S8564LG,WV-S8564LN,
WV-S8573L, WV-S8573LG, WV-S8573LN, WV-S8574L, WV-S8574LG, WV-S8574LN
miniAI
WV-S71300-F3, WV-S71300A-F3
PTZ S
WV-S65340-Z4K, WV-S65340-Z4N, WV-S61302-Z4, WV-S65340-Z2K, WV-S65340-Z2N,
WV-S61301-Z2, WV-S65340-Z 4 G, W V-S65340-Z 2 G, W V-S61301-Z1, WV-S61300-Z Y,
WV-S61300-Z Y G, W V-S61501-Z1, WV-S65302-Z2, WV-S65302-Z 2 G, W V-S65302-Z2-1,
WV-S65301-Z1, WV-S65301-Z 1 G, W V-S65301-Z1-1, WV-S65301-Z1S, WV-S65300-Z Y,
WV-S65300-Z Y G, W V-S65501-Z1, WV-S65501-Z1G
PTZ U
WV-U65302-Z2, WV-U65302-Z2 G, W V-U61301-Z2, WV-U65301-Z1, WV-U65301-Z 1 G,
WV-U61301-Z1, WV-U65300-Z Y, W V-U65300-Z Y G, W V-U61300-Z Y, W V-U61300-ZYG

2
Due to software upgrade, the following functions have been added and changed to
this product.
・Firmware Ver.1.20
SC384BSSeriesS
(Except for WV-S1536LTN, WV-S2536LTN, WV-S2136G, WV-S2136LG, WV-S2236LG,
WV-S2536LG, WV-S2536LGN)
・Firmware Ver.1.31
SC384BSSeriesS
・Firmware Ver.1.40
SC384B
SSeriesS
No.
Functions
Item (Page)
Page
1
Add to the system log when recording stream fails to write
Status (Maintenance)
7
2 Add a function to notify the user of writing failures in the
recording stream with a unique alarm
Status (Maintenance) 8
3 Add a note when the bit rate of the recording stream is
set to a value exceeding recommended value
Image (Image/Audio)
9
4 SDK version display Software mng.
( Ext. software )
10
5
Extend authentication password for the destination of notification
Advanced (Network)
12
No.
Functions
Item (Page)
Page
6
Change AI-VMD and AI People Detection to be
pre-installed
Software mng. 13
7
Add RAM capacity expansion mode Software mng.
( Ext. software )
14
8
Add LLDP function
Advanced (Network)
15
No.
Functions
Item (Page)
Page
9
Add SFTP periodic image transmission to “Event
operation” of Easy Setup
Event action (Easy Setup) 17
10 Add “SFTP periodic image transmission error” to “Save
trigger” of SD memory card
SD memory card (Basic) 25
11
Add link to SFTP settings in Camera action on alarm
Alarm
26
12
Add SFTP image transmission function
Advanced (Network)
29
13 Add SFTP periodic image transmission to “Schedule
mode” of Schedule
Schedule 34
14
Using the recording function is changed when the Ext.
software mode is On
Advanced (Network) 36
15
Change the initial value of “Overwrite” of SD memory
card to On
SD memory card (Basic) 37
16
Add NTP test function
Advanced (Network)
38
17
Add TLS settings to HTTPS
Advanced (Network)
39
18
Add MQTT function
Advanced (Network)
40
19
Add a system log when MQTT function fails
Status (Maintenance)
43

3
・Firmware Ver.1.41
SC384B
SSeriesS
*1 Except for WV-S1136A, WV-S1536LA, WV-S1536LNA, WV-S1536LNA-B,
WV-S1536LA-B, WV-S1536LNSA, WV-S1536LTNA, WV-S2136A, WV-S2136A-B,
WV-S2136GA, WV-S2136GA-B, WV-S2136LA, WV-S2136LA-B, WV-S2136LGA,
WV-S2136LGA-B, WV-S2236LA, WV-S2236LA-B, WV-S2236LGA, WV-S2236LGA-B,
WV-S2536LA, WV-S2536LGA, WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA,
WV-S1536LTA, WV-S2536LTA.
・Firmware Ver.2.10
・Firmware Ver.2.10
fisheye
No.
Functions
Item (Page)
Page
20
Add Genetec Stratocast Service
*1
Network (Stratocast)
44
No.
Functions
Item (Page)
Page
21 Changed new GUI (Graphical User Interface)
( Except
Multi
)
- 47
22
Add AI-VMD alarm area information on TCP alarm
notification
Notification (Alarm) 48
23
Add Image transmission log on Status page
Status (Maintenance)
49
No.
Functions
Item (Page)
Page
24
About removal of functions due to end of Internet
Explorer support
- 51
9
Add SFTP periodic image transmission to “Event
operation” of Easy Setup
Event action (Easy Setup) 17
10
Add “SFTP periodic image transmission error” to “Save
trigger” of SD memory card
SD memory card (Basic) 25
11
Add link to SFTP settings in Camera action on alarm
Alarm
26
12
Add SFTP image transmission function
Advanced (Network)
29
13 Add SFTP periodic image transmission to “Schedule
mode” of Schedule
Schedule 34
14
Using the recording function is changed when the Ext.
software mode is On
SD memory card (Basic) 36
15
Change the initial value of “Overwrite” of SD memory
card to On
SD memory card (Basic) 37
25 Changed the initial value of “Audio input encoding
format”
Audio (Image/Audio) 52
26
Add "Close (Continue)" and "Open (Continue)" to the
operation setting values of [Terminal 1], [Terminal 2],
and [Terminal 3] on the [Alarm] tab
Alarm
53
27
Add alarm test function to the alarm
Alarm
55
8
Add LLDP function
Advanced (Network)
15

4
・Firmware Ver.2.20
16
Add NTP test function
Advanced (Network)
38
17
Add TLS settings to HTTPS
Advanced (Network)
39
18
Add MQTT function
Advanced (Network)
40
19
Add a system log when MQTT function fails
Status (Maintenance)
43
28 Add log indications/error indications relating to
Firmware Upgrade
System log (Maintenance)
56
No.
Functions
Item (Page)
Page
29
Add FTP to the communication protocol of the file
transfer function
SC384BSSeriesS
miniAI
PTZ S
PTZ U
Advanced (Network) 57
30
Add SFTP periodic image transmission to “Event
operation” of Easy Setup
SC384BSSeriesS
miniAI
PTZ S
PTZ U
Event action (Easy Setup) 64
31
Change “SFTP periodic image transmission error” to
“FTP/SFTP periodic image transmission error” in “Save
trigger” of SD memory card.
<SD memory card supported models only>
SC384B
SSeriesS
miniAI
PTZ S
PTZ U
SD memory card (Basic) 75
32
Change the link of “SFTP setup” to “FTP/SFTP setup” in
Camera action on alarm
SC384B
SSeriesS
miniAI
PTZ S
PTZ U
Alarm 76
33
Add “FTP access to camera” to “Common” in Network
setup
SC384B
SSeriesS
miniAI
PTZ S
PTZ U
Network (Network) 78
34
Change “SFTP periodic image transmission” to
“FTP/SFTP periodic image transmission” in “Schedule”
mode
SC384B
SSeriesS
miniAI
PTZ S
PTZ U
Schedule 79
35
Add the log related to FTP/SFTP to system log
SC384BSSeriesS
miniAI
PTZ S
PTZ U
System log (Others) 81
36 Add Ext. software function
PTZ U
Extension software
(Software mng.)
82
37 Add Ext. software mode <SD memory card supported
models only>
PTZ U
SD memory card (Basic) 90
38 Add HTML initialization function
SC384B
SSeriesS
miniAI
PTZ S
PTZ U
Default reset
(Maintenance) 91
SC384BSSeriesH
SC384BSSeriesH
SC384BSSeriesH
SC384BSSeriesH
SC384BSSeriesH
SC384BSSeriesH
SC384B
SSeriesH
SC384BSSeriesH

5
Firmware Ver.2.20
miniAI
Firmware Ver.2.30
No.
Functions
Item (Page)
Page
22
Add AI-VMD alarm area information on TCP alarm
notification
Notification (Alarm) 48
23
Add Image transmission log on Status page
Status (Maintenance)
49
No.
Functions
Item (Page)
Page
39
Add 2fps and 3fps to FTP/SFTP refresh interval, add
1920x1080 to pre-alarm resolution, expand image
destination server to 2 locations
fisheye
miniAI
SC384BSSeriesS
SC384BSSeriesH
PTZ S
PTZ U
Advanced (Network) 92
40
Add 0.5s, 1s, 2s, 3s, and 4s to the alarm deactivation
time
fisheye
miniAI
SC384B
SSeriesS
SC384B
SSeriesH
PTZ S
PTZ U
Alarm
101
41
Add schedule setting to switch image quality at sunrise
and sunset
fisheye
miniAI
SC384BSSeriesS
SC384BSSeriesH
Multi
PTZ S
PTZ U
Schedule
102
42
Add enable/disable setting to SNMP agent setting
fisheye
miniAI
SC384BSSeriesS
SC384BSSeriesH
Multi
PTZ S
PTZ U
SNMP (Network)
107
43
Add corridor view mode to image capture mode
fisheye
Live image types –Image
capture mode
108
44
Add 1280x720 image capture size for Stream (1) and
Stream (2) (4 mega pixel model only)
Multi
Stream
Image/Audio – Image
111
45
Add title edit icon next to camera title
fisheye
miniAI
SC384BSSeriesS
SC384BSSeriesH
Multi
PTZ S
PTZ U
“Live” page
113

6
Firmware Ver.2.32
Firmware Ver.2.33
Firmware Ver.2.40
No.
Functions
Item (Page)
Page
-
Add new model number:
WV-S1136A, WV-S1536LA, WV-S1536LNA,
WV-S1536LNA-B, WV-S1536LA-B, WV-S1536LNSA,
WV-S1536LTNA, WV-S2136A, WV-S2136A-B,
WV-S2136GA, WV-S2136GA-B, WV-S2136LA, ,
WV-S2136LA-B, WV-S2136LGA, WV-S2136LGA-B,
WV-S2236LA, WV-S2236LA-B, WV-S2236LGA,
WV-S2236LGA-B, WV-S2536LA, WV-S2536LGA,
WV-S2536LGNA, WV-S2536LNA, WV-S2536LTNA,
WV-S1536LTA, WV-S2536LTA, WV-S4156A,
WV-S4176A, WV-S4556LA, WV-S4556LMA,
WV-S4576LA, WV-S4576LMA
For the above models, the previous firmware is not
available earlier than Ver.2.32.
- -
No.
Functions
Item (Page)
Page
46
Add SD memory card file system format to the “SD
memory card” settings
fisheye
miniAI
SC384BSSeriesS
SC384BSSeriesH
Multi
PTZ S
PTZ U
Basic - SD memory card 114
No.
Functions
Item (Page)
Page
47
Fix frame rate not to be halved when setting GOP
control “Advanced(Fixed GOP 60s w/1s
key-frame)”
Multi
Image/Audio – Image
116
48
Change the default of the preset sequence
PTZ S
PTZ – Position 118
49
Change the default of auto track data in video
stream
PTZ S
PTZ – Auto track data in
video stream
119
50
Change the default setting for guest user to “Use”
PTZ S
User authentication –
Guest User
119
51
Change the setting so that SNMP is not used in the
default state (Off)
miniAI
SC384BSSeriesS
SC384BSSeriesH
Multi
PTZ S
Network
120
52
About the effect of the maximum shutter setting on
the auto track function
miniAI
SC384BSSeriesS
SC384BSSeriesH
Multi
PTZ S
PTZ – Auto track setting
screen
PTZ – Auto track alarm
setting screen
120
53
About settings that are not applied when restoring
setup data
PTZ S
Maintenance – Data
121
Multi
Multi
Multi

7
1. Add to the system log when recording stream fails to write
(Operating Instructions “Others” – “Maintenance” - Check the status [Status])
A system log has been added for errors in the write process of the recording stream to the log related
to SD memory cards.
Category
Indication
Description
SD memory
card
<SD>Format
Successfully formatted the SD memory card.
<SD>Format error
Error occurred when formatting the SD
memory card.
<SD> Write-protect ON
(Locked card)
A write-protected SD memory card is
inserted.
<SD> Detection error
The SD memory card could not be correctly
recognized.
<SD> Write error An error occurred when writing to the SD
memory card.
<SD> Read error An error occurred when reading from the SD
memory card.
<SD> Delete error An error occurred when deleting data from
the SD memory card.
<SD> File system error
An error occurred in File system of the SD
memory card.
<SD> Undefined error An error other that the ones above has
occurred for the SD memory card.
<SD> An abnormality occurs in
continuity of the SD memory
recording. Check the recording bit
rate setting of the SD memory
recording.
An error occurred when writing to the SD
memory card.
<SD> An error occurs in the SD
memory card. Check the status of
the SD memory card.
The SD memory card write process still
generates data loss. Make sure that the SD
memory card is properly recognized.
If the card is not recognized, reboot the unit,
or remove and reinsert the SD memory card
to check.

8
2. Add a function to notify the user of writing failures in the recording
stream with a unique alarm
(Operating Instructions “Others” – “Maintenance” - Configure the alarm settings
[Alarm]) －Configuration of the settings relating to alarm notification［Notification］
－Configure the settings relating to Panasonic alarm protocol)
Add the write processing error of the recording stream to the occurrence condition of the Panasonic
alarm protocol notification of “Diag.”
Panasonic alarm protocol
• ［Panasonic alarm protocol］
Select “On” or “Off” to determine whether or not to provide notification by Panasonic alarm protocol
according to the settings for the “Alarm” and “Diag.” checkboxes of “Destination of notification” below.
- When an alarm is detected (“Alarm”)
- When a notification of the remaining capacity of the SD memory card has been provided
(“Diag.”)
- When the SD memory card has become full (“Diag.”)
- When the SD memory card cannot be recognized (“Diag.”)
- When there is a write error on the SD memory card (“Diag.”)
Default: Off
Destination of notification
•[Address 1] - [Address 8]
Enter the destination IP address or host name of the Panasonic alarm protocol from the following.
Up to 8 destination server addresses can be registered.
[Alarm] checkbox: When the checkbox is checked, the Panasonic alarm notification will be provided
upon an alarm occurrence.
[Diag.] checkbox: When the checkbox is checked, notification using Panasonic alarm protocol will be
provided in the following cases.
– When notification of the remaining capacity of the SD memory card has been provided
– When the SD memory card has become full
– When the SD memory card cannot be recognized
– When the SD memory card cannot be written
[Destination server address]: Enter the destination server address or host name.
Available characters: Alphanumeric characters, the colon (:), the period (.), the underscore (_), and
the hyphen (-).
To delete the registered destination server address, click the [Delete] button respective to the desired
destination server address.

9
3. Add a note when the bit rate of the recording stream is set to a value
exceeding recommended value
(Operating Instructions “Image/Audio” - Configure the settings relating to Stream
[Image]
Add the statement that it is possible that an error may occur in the continuity of SD memory card
recording, if you set a bit rate that exceeds the recommended value in “Note” of “Max bit rate (per
client) *”.
[Max bit rate (per client)*]:
Note
• The bit rate for “Stream” is restricted by “Bandwidth control (bit rate)” on the [Network] tab on the
“Network” page. When a value with “*” attached is set, images may not be streamed.
• It is recommend that the bit rate setting of the stream to be 8192 kbps or lower. Setting a value higher
than 8192 kbps may cause abnormalities in the continuity of the recorded video.
• When the refresh interval is too short, the actual bit rate may exceed the set bit rate depending on the
subject.
• Depending on the number users connecting at the same time or the combination of features used, the
bit rate may be lower than the configured value. Check the transmission of images after changing
settings.

10
4. SDK version display
(Operating Instructions – Perform management of the extension software and the schedule
setting [Ext. software] - Perform the installation, uninstallation and version upgrade of the
extension software [Software mng.])
The firmware version and SDK version of the camera and ext. software have been added to the
software management screen.
If the SDK version of the camera is older than the ext. software, a message will be displayed to that
effect.
Installing the extension software
Unique information
[SDK version]
Display the version information of the SDK installed in the camera. If the ext. software you install
requires a version number higher than the one shown here, the ext. software may not work properly.
[Software version]
The version information of the installed camera software will be displayed.

11
Extension software
[Version]
If you have installed ext. software, the version information of the installed ext. software is displayed
along with the version information of the SDK installed in the ext. software.
If the version information of the SDK embedded in the camera is less than the version number
required by the ext. software, the ext. software may not operate properly.
Note
• For ext. software that does not have SDK version information installed, the SDK version information
will not be displayed.

12
5. Extend authentication password for the destination of notification
(Operating Instructions – Configure the network settings [Network] – Configure advanced
network settings [Advanced] - Configure the settings related to sending E-mails)
The number of characters that can be entered for the authentication password of the destination of
notification has been expanded to 128 characters.
•[Authentication – Password]
Enter the password to access the server.
Available number of characters: 0 - 128 characters
Unavailable characters: " &

13
6. Change AI-VMD and AI People Detection to be pre-installed
(Operating Instructions – Perform management of the extension software and the schedule
setting [Ext. software])
Change the pre-installed Ext. software AI Video Motion Detection (“AI-VMD”) and AI Privacy Guard to
AI-VMD and AI People Detection. Along with that, it is stated in "Note" that AI-VMD and AI People
Detection are pre-installed.
Management of the extension software and the schedule setting can be performed on the “Ext. software”
page. The “Ext. software” page has the [Software mng.] tab and the [Operation sched.] tab.
Note
• AI-VMD and AI People Detection are already installed. For further information, refer to the respective
operating instructions.
• The camera software upgrade will not change the installed Ext. software.

14
7. Add RAM capacity expansion mode
(Operating Instructions – Perform management of the extension software and the schedule
setting [Ext. software] – Perform the installation, uninstallation and version upgrade of the
extension software [Software mng.])
RAM capacity expansion mode has been added to the software management screen.
This mode increases the amount of RAM available to the Ext. software.
Unique information
[RAM capacity expansion mode]
Set On/Off whether to expand the RAM capacity.
Default: Off
Note
• When “RAM capacity expansion mode” is set to “On”, the recording function to SD memory card by this
product cannot be used.
• If the minus is displayed in the “Remaining RAM” value, uninstall the ext. software or set the remaining
RAM to “On”.
• Click the [Set] button to restart the product. After restarting, the product cannot be operated for about 2
minutes, same way as when the power is turned on.
• For information about the Ext. software that requires the “RAM capacity expansion mode” to be set to
“On”, refer to our support website.
https://i-pro.com/global/en/surveillance/i-pro-application-platform/application-list

15
8. Add LLDP function
(Operating Instructions – Configuring the network settings [Network] – Configure advanced
network settings [Advanced])
LLDP (Link Layer Discovery Protocol) has been added to [Advanced] of [Network]. Interoperability can
be achieved by sending and receiving camera's device information to and from LLDP-compatible
devices.
[LLDP]
Enable/Disable whether to enable the LLDP function and Fabric Attach.
Default: Disable
When set to “Enable”, LLDP including TLVs with the checks in the table below will be sent.
End Of
LLDPDU
TLV
Chassis
ID T LV
Port ID
TLV
Ti m e To
Live TLV
Port
Descripti
on TLV
System
Name
TLV
System
Descripti
on TLV
System
Capability
TLV
Manage
ment
Address
TLV
IEEE802.3
Power
via MDI
TLV
Fabric
Attach
Element
TLV
✔✔✔✔✔✔✔✔✔✔✔
* Models that support PoE+ power supply will send LLDP including TLVs with the checks in the table
below for PoE+ power supply even if set to “Disable”.
End Of
LLDPDU
TLV
Chassis
ID T LV
Port ID
TLV
Ti m e To
Live TLV
Port
Descripti
on TLV
System
Name
TLV
System
Descripti
on TLV
System
Capability
TLV
Manage
ment
Address
TLV
IEEE802.3
Power
via MDI
TLV
Fabric
Attach
Element
TLV
✔✔✔✔✔

16
Fabric Attach
[Fabric Attach authentication key]
Enter the key to be used for Fabric Attach authentication. Note that this is valid only when “LLDP” is
“Enable”.
Available number of characters:0 - 32 characters (If Fabric attach authentication is not performed,
leave it blank.)
Available characters: Alphanumeric characters
Default: None (blank)
Note
• Click the [Set] button to restart the product. After restarting, the product cannot be operated for about 2
minutes, just like when the power is turned on.
• For information about devices that can be connected using Fabric Attach, refer to our support website.
https://i-pro.com/global/en/surveillance/training-support/support/technical-information

17
9. Add SFTP periodic image transmission to “Event operation” of Easy
Setup
(Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event
action])
With the addition of the SFTP function, SFTP periodic image transmission has been added to the
“Event action” of Easy Setup.
You can set event actions for SD schedule recording/SFTP periodic image transmission/alarm
detection. Once the settings are completed in each setup menu, click the [Next] button to proceed.
The setup flow is as follows.
Note
• If you click the [Next] button, the settings in the screen will be saved.

18
Flow of event action setup
Event function type:
Select the trigger
according to the
purpose of setting.
Event action setup:
Configure the action
conditions selected
in the event
function type setup.
Event detailed
setup:
Configure the
details of the
settings in event
action setup.
Alarm
(→Alarm: Configure the terminal
and VMD (alarm setup menu))
Schedule
(→Schedule: Configure SD
recording or SFTP periodic image
transmission (schedule function
type setup menu))
Terminal/VMD/SCD/Audio detection
SFTP
transmission
（→Alarm:
Configure the
details for
image transfer
or recording
conditions）
SD memory
recording
JPEG/H.265/
H.264
（→Alarm:
Configure the
details for
recording
conditions）
SD memory
recording
H.265/H.264
（→Schedule:
Set SD memory
recording (video
recording setup
menu)
SFTP periodic
transmission
（→Schedule:
Configure
SFTP periodic
transmission
(SFTP periodic
transmission
setup menu))
Settings of image
transfer
conditions
Settings of
recording
conditions
Settings of
recording
conditions
Settings of image
transfer method
SFTP settings
Alarm output (terminal)
E-mail settings
Schedule settings
Completed
Completed

19
Configure the schedule/alarm (event function type setup menu)
(Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event
action] – Configure the schedule/alarm (event function type setup menu))
Here, select the function type of the event.
[Trigger]
• Alarm: Select when setting the alarm detection settings.
• Schedule: Select during “SD memory recording” or “SFTP periodic image transmission”.
• Default: Alarm
[SD memory card format]
To format the SD memory card, click the [Execute] button.
Once you click the [Execute] button, the “Format” confirmation screen will be displayed.
If you click the [OK] button, the formatting will start.
Once the “Format” completion screen is displayed, press the button.
IMPORTANT
• All data saved on the SD memory card will be deleted when the SD memory card is formatted.
• Do not turn off the power of the camera during formatting.
[Next] button
If you select “Alarm”, and click the [Next] button, the alarm setup menu will be displayed.
(→ Alarm: Configure the terminal and VMD (alarm setup menu)”)
If you select “Schedule”, and click the [Next] button, the schedule function type setup menu will be
displayed. (→Schedule: Configure SD recording or “SFTP periodic image transmission (schedule
function type setup menu)”)

20
Alarm: Configure the alarm function type (Alarm function type setup
menu)
(Operating Instructions – Use Easy Setup [Easy Setup] – Configure an event action [Event
action] – Alarm: Configure the alarm function type (Alarm function type setup menu))
Select the alarm function type as “SFTP transfer” or “SD memory recording”.
Configure “Recording format” of SD memory recording triggered by an alarm occurrence.
[Trigger]
• SFTP transfer: When an alarm occurs, performs SFTP Transfer of the JPEG image.
• SD memory recording: When an alarm occurs, records the image to the SD memory card.
Note
• “SFTP Transfer” for when an alarm occurs and “SFTP periodic image transmission” can both be
performed simultaneously.
• If both “SFTP Transfer” for when an alarm occurs and “SFTP periodic image transmission” are set,
“SFTP Transfer” will be given priority when an alarm occurs.
[Recording format]
Select the recording format by selecting from “JPEG(1)”, “JPEG(2)”, “Stream(1)”, “Stream(2)”,
“Stream(3)” and “Stream(4)”.
[Next] button
If you select “SFTP Transfer” for “Trigger” and click the [Next] button, the SFTP transfer setup menu will
be displayed. (→“Set SFTP transfer (SFTP transfer setup menu)”)
If you select “SD memory recording” for “Trigger”, select “JPEG(1)” or “JPEG(2)” for “Recording format”,
and then click the [Next] button, the JPEG recording setup menu will be displayed. (→Configure SD
memory recording (JPEG) (JPEG recording setup menu))
If you select “SD memory recording” for “Trigger”, select “Stream(1)”, “Stream(2)”, “Stream(3)”, or
“Stream(4)” for “Recording format”, and then click the [Next] button, the video recording setup menu will
be displayed. (→“Configure SD memory recording (H.265 or H.264) (video recording setup menu)”)
Note
• If you click the [Next] button, the setting items in the screen are saved.
• Even when the audio detection alarm is set, alarm recording onto the SD memory card will not be
performed.
[Back] button
If you click the [Back] button the alarm setup menu will be displayed. (→Alarm: “Configure the terminal
and VMD (alarm setup menu)”)
