Digital Watchdog INFINITY Snapit DWC-D4367WD User manual

ABOUT MANUAL
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
Indoor Dome Camera
DWC-D4367WD
DWC-D4367WTIR
12132012

2
PRECAUTIONS
FCC COMPLIANCE
Do not open or modify.
Do not open the case except during maintenence and installation, for it may be dangerous and can
cause damages.
Do not put objects into the unit.
Keep metal objects and flammable substances from entering the camera.
It can cause fire, short-circuits, or other damages.
Be careful when handling the unit.
To prevent damages, do not drop the camera or subject it to shock or vibration.
Do not install near electric or magnetic fields.
Protect from humidity and dust.
Protect from high temperature.
Be careful when installing near the ceiling of kitchen or a boiler room, as the temperature may rise
to high levels.
Cleaning:
To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.
Mounting Surface:
The material of the mounting surface must be strong enough to support the camera.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference, when the equipment is operated in a residential environment. This equipment
generates, uses, and radiates radio frequency energy; and if it is not installed and used in accordance
with the instruction manual, it may cause harmful interference to radio communications.
WARNING: Changes or modifications are not expressly approved by the manufacturer.

TABLE OF CONTENTS
3
Introduction
Installation
Module OSD Menu
Troubleshooting
Warranty Information
Specifications
Features
Parts and Descriptions
Dimensions
Inside the Box
Mount Installation Instructions
Connecting to Monitors
Adjusting the Camera Lens
4
5
6
7
8-9
10
12
14-25
26
27-28
29-30
Adjusting the 3-Axis Gimbal 13

4
FEATURES*
1/3” Sony Super HAD CCD II
620 TV Lines (B&W), 600 TV Lines (Color)
3.3~12mm Varifocal Auto Iris Lens
70ft Range IR with Intelligent Camera Sync [DWC-D4367WTIR Only]
Electronic Day and Night [DWC-D4367WD Only]
TDN (True Day and Night / IR Cut Filter) [DWC-D4367WTIR Only]
Smart DNR (Digital Noise Reduction)
WDR (Wide Dynamic Range)
Star-Light (Super Low Light Technology)
HME (Highlight Masking Exposure)
Programmable Privacy Zones & Motion Detection
Easy Icon Driven OSD Menu with Built-In Joystick
UTP & RS485 Built-In
Auto Sensing 12VDC or 24VAC with Line Lock
Secondary Video-BNC Output

5
PART & DESCRIPTIONS*
1
Lens
3UTP
4RS-485
2
Power Input Connctor
12VDC/24VAC Dual Voltage
6
Primary Video BNC-Output Connector
5
10
Secondary Video-BNC
Output Connector
9
Camera Control Board
7
Bubble Dome Cover
8
Upper Case
Mounting Screws
2
3
4
8
1
NO IR IR
5
6
7
10
9

6
DIMENSIONS IN MILLIMETERS (IN)*
Surface Mount
89
(3.5”)
108(4.25”)
Top View
40.5(1.59”)
56.3(2.22”)
96.8(3.81”)
108(4.25”)

7
INSIDE THE BOX*
Included with Snapit Indoor Dome Camera
User Manual
Mounting Template
2 Machine Screws and 2 Dry Wall Anchors
Secondary Video-BNC Cable
1
2
3
4
4

8
SURFACE MOUNT INSTALLATION INSTRUCTIONS*
Squeeze the sides of the
camera and separate the
camera module from the
dome cover.
Use the camera’s mounting
template or your camera to
mark the holes as required.
Drill holes into the drywall and
insert the drywall mounts into
the holes.
Pull wires through and make
connections. Then, mount the
camera to the wall using the
included machine screws.
1 2 3
4
Adjust the camera lens
position by using the 3-Axis
Gimbal.
Snap the dome cover over
the camera module.
5 6

9
WALL MOUNT INSTALLATION INSTRUCTIONS*
Check to see all parts are in
the box.
Use the mount to mark the
pilot holes that are required.
Drill holes into the drywall
and insert the drywall mounts.
Secure the wall mount to the
wall using the mounting
screws.
Attach the base of the camera
to the wall mount with the
smaller machine screws.
Adjust the camera lens, and
snap the dome cover over
the camera module.
1 2 3
4 5

CONNECTING TO MONITORS*
Power Connection: 12VDC & 24VDC Dual Voltage (Auto Polarity Detection and Protection)
All cameras are equipped with a second video output for on-site configuration.
Use the diagram below to connect to a Monitor or CRT Monitor properly.
DC 12V / AC 24V
CCTV Monitor
Monitor
300.0mm(11.8”)
Second Video Output
NO IRIR
10

UTP SYSTEM*
Passive to Passive
Passive to Active
UTP Cable (Max.300ft)
Passive UTP
DVR(Digital Video Recorder)
Monitor
Including the Passive UTP
DVR(Digital Video Recorder)
Monitor
UTP Cable (Max 3,000ft)
Including the Passive UTP
Active UTP
11

12
ADJUSTING THE CAMERA LENS*
Follow the instructions provided below to make any lens adjustments.
1Loosen the Zoom & Focus Handles by rotating them counter-clockwise.
Adjust the field of view by moving the handles to the RIGHT (Tele) to zoom in, or to the LEFT (Wide) to zoom out.
Adjust the focus the same way as described above AFTER the desired zoom position is established.
Once the desired adjustments have been made, please tighten the handles back by turning them clockwise.
2
3
4
NO IR IR
ZOOM
FOCUS
Zoom:
Focus:
Tele - Wide
Far - Near

Rotation 360 Panning 360
NO IR IR NO IR IR
Tilting 90
NO IR
Tilting 75
IR
13
ADJUSTING THE 3-AXIS GIMBAL*
The Gimbal mechanism yields maximum rotation and placement as shown below.

14
MODULE OSD MENU*
LENS
BACKLIGHT
AGC
STARLIGHT
3D DNR
EXIT JUMP
EXPOSURE
PRIVACY SET-UP
COLOR FUNCTION
MOTION
WB MODE
RED GAIN
BLUE GAIN
D&N MODE
NIGHT C.
NIGHT A.
MASK 1AREA SET
MIRROR
SHARPNESS
GAMMA
SLC
NIGHT UP
EXIT JUMP
SAVE & EXIT
EXIT
TITLE EDIT
DPC SET
LANGUAGE
OSD COLOR
COMMUNICATION
FACTORY SET.
COLOR MODE
EXIT JUMP
EXIT JUMP
SENSITIV.
SHOW INDI.
EXTER-OUT.
EXIT JUMP
MASK 2
MASK 3
MASK 4
MASK 5
MASK 6
MASK 7
MASK 8
EXIT JUMP
MANUAL / DC
OFF / BLC / HME / WDR
OFF / LOW / MID / HIGH / HIGHEST
OFF / x2 ~ x1024
OFF / LOW / MID / HIGH / SMART
SAVE& EXIT / EXIT
AWC / ATW / MANUAL / PUSHLOCK
0 ~ 255
0 ~ 255
NORMAL / COOL / WARM
SAVE& EXIT / EXIT
AUTO / COLOR / B&W
0 ~ 100
0 ~ 100
SAVE & EXIT / EXIT
MIRROR / OFF
0 ~ 30
MANUAL / 0.45 / 0.60 / 1.0
OFF / ON
OFF / ON
SAVE& EXIT / EXIT
AREA 1~4 > OFF / ON
1 ~ 30
OFF / ICON / TRACE
OFF / ON
SAVE & EXIT / EXIT
OFF / ON
OFF / ON
OFF / ON
OFF / ON
OFF / ON
OFF / ON
OFF / ON
OFF / AUTO
ENGLISH /
繁體中文/ 简 体中文/日本語 /
DEUTSCH / FRENCH / ITALIAN /
RUSSIAN / SPANISH / DUTCH
BLUE / GREEN / CYAN / RED /
MAGENTA / YELLOW / PURPLE /
GRAY
OFF / ON
OFF / ON
OFF / ON
SAVE& EXIT / EXIT
DAY & NIGHT
EXIT
EXIT JUMP
NO / YES
SAVE & EXIT / EXIT
MONITOR
MODE 1 / MODE 2

15
EXPOSURE
LENS
Manual Manual mode supports the fixed board lens or the manual iris
lens.
DC DC mode supports the auto-iris varifocal lens.
NOTE: Both MANUAL and DC mode have FOCUS TARGET. You can adjust
the focus by finding the highest number on the FOCUS TARGET.
See page 16 for focus information.
ELC Levels and DC Levels are adjustable. The higher the number, the brighter
the image.
E. Shutter sets the shutter speed levels from 1/60 to 1/100000.
*For LENS-MANUAL Mode, the default E.SHUTTER is AUTO.
*For LENS-DC Mode, the default E.SHUTTER is 1/60. Select DC-AUTO for*outdoor use.
Select 1/100FLC to run camera in flickerless mode.
Note: The STARLIGHT option cannot be controlled if the E.SHUTTER setting is
above 1/60.

16
EXPOSURE
BACKLIGHT
OFF
BLC BACK LIGHT COMPENSATION
MANUAL User can manually adjust the BLC level in five areas of the scene (TOP, BOTTOM, CENTER, LEFT, RIGHT).
Increase the BLC levels to make the image brighter.
SMART This is recommended. Camera will automatically detect and adjust the BLC zone. BLC levels to choose
from include: LOWEST, LOW, MID, HIGH.
HME HIGHLIGHT MASKING EXPOSURE
HME masks highlights to allow objects to appear clearly on the screen. If ON is selected, HME levels are
adjustable. The lower the number, the darker the masking areas.
WDR (TRUE) WIDE DYNAMIC RANGE
True WDR in this camera is not supported by a double scan CCD. However, this special DSP can automatically
perform two scans depending on the lighting.

17
EXPOSURE
AGC (AUTO GAIN CONTROL) AGC enhances the picture brightness in low light conditions. A higher
OFF / LOW / MID / HIGH / HIGHEST level AGC setting makes the images brighter; however, it could increase
the amount of noise.
STARLIGHT Starlight mode automatically activates slow shutter function when the
OFF / x2 ~ x1024 image is too dark. x4 is the default. We do not recommend you to
increase the setting, for it causes the image to lag.
Note: Starlight menu cannot be controlled if the E.SHUTTER setting is
above 1/60.
3D DNR (DIGITAL NOISE REDUCTION) 3D-DNR reduces the noise on the screen in low light conditions and
OFF / LOW / MID / HIGH / SMART allows for clearer images, even at night. The SMART option will adjust
the camera to prevent lagging when there is motion.
EXIT JUMP
SAVE & EXIT Save the current settings and exit the OSD menu.
EXIT Exit the OSD menu without saving the changes.

18
COLOR
WB MODE
AWC Auto White Balance Control mode compensates for color
temperature changes between 2000K and 18000K.
ATW Auto Tracking White Balance Control mode compensates for color
temperature changes between 2500K and 9500K.
MANUAL Users can control the white balance manually by changing RED
GAIN and BLUE GAIN (see below).
PUSHLOCK Pushlock is to fix the white balance based on the current lighting.
RED GAIN
0 ~ 255 Adjusts the amount of red in the image.
BLUE GAIN
0 ~ 255 Adjust the amount of blue in the image.
COLOR MODE
NORMAL Color is similar to actual color.
COOL Color has more blue.
WARM Color has more red.
EXIT JUMP
SAVE & EXIT Save the current settings and exit the OSD menu.
EXIT Exit the OSD menu without saving the changes.

19
DAY & NIGHT
D&N MODE
AUTO Camera switches between day and night automatically depending
on light level. Camera will stay in color mode when there is enough
light. Camera will switch to B&W at night or other low light
environments.
If AUTO is selected, please define the following settings:
*BURST: If ON is selected, the camera provides a color burst signal
*in night mode. If OFF, no color burst signal is provided.
*COLOR->B&W: Adjusts the light level at which the camera switches from
*day (color) to night (B&W) mode. The higher the number, the lower the light level.
*B&W->COLOR: Adjusts the light level at which the camera switches from
*night (B&W) to day (color) mode. This number should be lower than the value
*of COLOR->B&W above.
*SMART IR: ON/OFF. If using IR LEDs, ON is recommended.
*READ TIME: Time interval delay before switching from day mode to night
*mode. It is adjustable from 3 seconds to 12 seconds.
*EX_IR INT.: AUTO/EXT. If using IR LEDs built into the camera, select AUTO.
*If using external IR LEDs separately, select EXT.
COLOR Camera always stays in day/color mode.
B&W Camera always stays in night/B&W mode.
NIGHT C.
0 ~ 100 Color will be reduced in low light conditions.
(This level cannot be adjusted when 3D-DNR is ON.)
NIGHT A.
0 ~ 100 Edge sharpness will be reduced in low light conditions.
(This level cannot be adjusted when 3D-DNR is ON.)
EXIT JUMP
SAVE & EXIT Save the current settings and exit the OSD menu.
EXIT Exit the OSD menu without saving the changes.

20
FUNCTION
MIRROR
OFF
MIRROR Flips the image horizontally.
SHARPNESS
0 ~ 30 Sets the image sharpness. The higher the number, the sharper
the image.
GAMMA
0.45 / 0.60 / Select the desired gamma level. 0.45 is default setting.
1.0 / MANUAL
SLC (SIDE LIGHT COMPENSATION)
OFF / ON Increase the brightness on sides of the image.
NIGHT-UP
OFF / ON Adjusts sensitivity in low light conditions by set-up level. If ON is selected, the set-up level becomes higher,
and the images become brighter.
EXIT JUMP
SAVE & EXIT Save the current settings and exit the OSD menu.
EXIT Exit the OSD menu without saving the changes.
