I-Rocks IRK71M User manual

Model No.：IRK71M
Quick Installation Guide
IRK71M
RGB Illuminated
Mechanical Keyboard

RGB Illuminated Mechanical Keyboard
CONTENTS
English Quick Installation Guide ....................... 1-1
繁體中文 快速安裝手冊 ............................................... 2-1

1-1EN
RGB Illuminated Mechanical Keyboard
USB-C
Model No.：IRK71M
Quick Installation Guide
IRK71M
RGB Illuminated
Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-2EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-3EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-4EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-5EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-6EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-7EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-8EN
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-9EN
RGB Illuminated Mechanical Keyboard
1
2
RGB Illuminated Mechanical Keyboard
Package Contents
•Keyboard x 1 •Quick Start Guide x 1 •USB-C Cable x 1
System Requirements
•Compatible with: Windows® 7 , Windows® 8.1 and
Windows® 10 or later.
•Available USB Port
Specifications
•Interface: USB ( Full Speed )
•Key number: 107 Keys
•Smart dial wheel: 1 Set
•Switch type: Mechanical Switch
•Key stroke: 4.0 mm
•N-Key rollover ( NKRO)
•Multimedia Hotkeys: 15 keys
•Backlight Effect Hotkeys: 8 keys
•Rated Voltage / Current: DC 5V / 500 mA Max.
•Weight: approx. 1.3 kg
•Cable length: approx. 180 cm
•Dimension: 444 (L) X 155 (W) X 42 (H) mm
Hardware Installation
1. Turn on computer
2. Plug USB cable into an available USB port on your computer and
keyboard ( USB-A for computer & USB-C for keyboard )
3. Your computer will automatically detect the keyboard
4. You may use the keyboard after detection
Product Information
1. LED indication
•Num lock LED Indicator
•Caps lock LED Indicator
•Scroll lock LED Indicator
•Win lock LED Indicator
PS1 : 4 indicators blinking: backlight customization mode
PS2 : Esc key backlight only: full key lock is in effect ( Fn+Esc )
2. Hotkeys
Press “ “ and desired function key simultaneously to use
hotkeys.
2.1 Setting key function
•“ “ + “ “ + “ “：N-Key Rollover anti-ghosting
function ( default )
•“ “ + “ “ + “ “：6-Key Rollover anti-ghosting &
standard USB settings
•“ “ + “ “ + “ “：Factory reset
( Press and hold for 5 seconds )
2.2 Backlight Function Keys
Side Backlight
•“ “ + “ “ + “ “ or “ “ : Select side backlight
colors
( depending on backlight effects )
•“ “ + “ “ + “ “ or “ “：Adjust side backlight
speed
( depending on backlight effects )
•“ “ + “ “：Turn side backlight on or off
•“ “ + “ “：Switch between side backlight effects
( 7 types )
Keyboard Backlight
•“ “ + “ “ or “ “：Adjust brightness ( 4 levels )
•“ “ + “ “ or “ “ : Select or switch key backlight
colors
( depending on backlight effects )
•“ “ + “ “ or “ “：Adjust backlight speed
( depending on backlight effects )
•“ “ + “ “：Turn keyboard backlight on or off
•“ “ + “ “：Light fadeout and tracing effects ( 5 types )
•“ “ + “ “：Monochrome and breathing backlight
effects
•“ “ + “ “：Backlight Customization Mode
Onboard memory can store up to five backlight customization
profile. Users may set backlight according to their preferences,
and profiles will be stored in 1 / 2 / 3 / 4 / 5 key respectively
after saving.
How to customize backlight:
A. Press“ “ + “ “ or (2/3/4/5) to select and switch to lighting
mode 1 ( 2/3/4/5)
B. Press“ “ + “ “ + “ “ simultaneously to activate
custom backlight setting
( 4 LED key indicators will start blinking )
C. Press desired key you want to configure, and the key will light
up; press“ “ + “ “ or “ “ to select colors for the key
D. Setting next key and color
E. Press the same illuminated key to cancel backlight setting for
the key
F. After configuration, press“ “ + “ “ + “ “ to save all
settings to current lighting mode and leave backlight
customization mode ( all 4 indicators will stop blinking )
G. Follow the same step A to F for setting 2/3/4/5 lighting mode
•“ “ + “ “：RGB Backlight Effects – Set A ( 3 options )
•“ “ + “ “：RGB Backlight Effects – Set B ( 7 options)
2.3 Multimedia & function key
•“ “ + “ “：Show Desktop
•“ “ + “ “：Lock PC
•“ “ + “ “：Search for files or folders
•“ “ + “ “：Launch Calculator
•“ “ + “ “：Open my Computer
•“ “ + “ “：Open E-Mail
•“ “ + “ “：Open the internet browser
•“ “ + “ “：Media player
•“ “ + “ “：Play / pause
•“ “ + “ “：Backward
•“ “ + “ “：Stop play
•“ “ + “ “：Forward
•“ “ + “ “：Full key lock
( keyboard only lights up Esc key when mode is in effect )
•“ “ + “ “：Turn Windows lock on or off
2.4 Smart wheel function
Smart wheel is powered by Windows 10 protocol without
additional software, if you’re using the latest version of
Windows 10.
Smart Wheel is customizable and will automatically switch to your
preferred tool depending on software you’re using. Switch
between scrolling, zoom, rotation, brush tuning, video editing,
multimedia control and more. Smart Wheel support ranges from
Windows 10 built-in apps to pro software.
Press the below button to switch wheel mode
•“ “：Wheel - volume control mode
Wheel clockwise: Increase volume
Wheel counterclockwise: Decrease Volume
Wheel button: Mute
•“ “：Wheel - Task Switcher Mode
Wheel clockwise: Next Window
Wheel counterclockwise: Previous Window
Wheel button: Select
•“ “：Wheel - Smart Wheel
Only works on PC with Windows 10
Go to Windows 10 Settings -> Devices -> Wheel for
customization

1-10EN
RGB Illuminated Mechanical Keyboard
3

1-11EN
RGB Illuminated Mechanical Keyboard
3. Software
Please download the latest keyboard app for setup from iRocks
website
1. Double click the installation software you download and follow
the instructions step by
2. Plug in the keyboard after installation, the software will start to
identify it
3. Launch the software. It will take some time to download the
memory parameter and setting of the keyboard
Note: You must plug in the keyboard in order to start the
software

2-1CH
RGB Illuminated Mechanical Keyboard
USB-C
Model No.：IRK71M
Quick Installation Guide
IRK71M
RGB Illuminated
Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)

2-2CH
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)

2-3CH
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
產品資訊
1.LED 指示燈
•數字鎖指示燈
•大小寫指示燈
•滾動鎖指示燈
•視窗鍵鎖指示燈
註一 : 單ESC背光鍵亮時, 表示全部按鍵在鎖鍵狀態( Fn+ESC )
註二 : 4個LED同時閃爍,表示進入按鍵背光自定義模式
2.功能快捷鍵
同時按壓 “ “ 鍵跟下列按鍵產生對應的快捷功能
2.1 設定鍵
•“ “ + “ “ + “ “：全區防衝突功能 (鍵盤內定值)
•“ “ + “ “ + “ “：USB標準規範六鍵輸出功能
•“ “ + “ “ + “ “：長按5秒,可將按鍵所有功能
恢復出廠設定
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)

2-4CH
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)

2-5CH
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)

2-6CH
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)

2-7CH
RGB Illuminated Mechanical Keyboard
RGB Illuminated Mechanical Keyboard
包裝內容
•鍵盤 X 1 •快速安裝手冊 x 1 •USB-C 連接線 x 1
系統需求
•微軟的視窗系統Windows® 7, Windows® 8.1 , Windows® 10
•可用的USB傳輸埠
產品規格
•產品名稱: RGB背光機械鍵盤
•產品型號: IRK71M
•介面: USB ( Full Speed )
•按鍵數: 107 鍵
•智慧型按壓滾輪: 1組
•開關形式: 機械開關
•按鍵行程: 4.0±0.5mm
•全區防鬼鍵設計 (NKRO)
•多媒體鍵: 15 鍵
•背光特效鍵: 8 鍵
•電壓/電流: DC 5V / 500 mA Max.
•產品重量: 約 1.3 公斤
•USB 線長: 約 180 公分
•產品尺寸: 444 (L) X 155 (W) X 42 (H)mm
硬體安裝
1. 開啟電腦電源。
2. 將所附的USB傳輸線USB-A 接於電腦端 & USB-C 接於鍵盤端。
3. 電腦會自動偵測到鍵盤裝置。
4. 安裝完成。
2.2 背光功能快捷鍵
側背光功能
•“ “ + “ “ + “ “ or “ “ : 選擇側背光顏色
( 依背光特效而定 )
•“ “ + “ “ + “ “ or “ “：調整側背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：側背光開啟跟關閉，ON / OFF
•“ “ + “ “：側背光特效模式切換 ( 7 種特效 )
按鍵背光
•“ “ + “ “ or “ “：調整按鍵背光明亮度 ( 四階 )
•“ “ + “ “ or “ “ : 選擇按鍵背光顏色
( 依背光特效而定 )
•“ “ + “ “ or “ “：調整按鍵背光特效變化速度
( 依背光特效而定 )
•“ “ + “ “：按鍵背光開啟跟關閉，ON / OFF
•“ “ + “ “：光跡追蹤 ( 5種效果切換 )
•“ “ + “ “：單色恆亮及呼吸背光特效切換
•“ “ + “ “：自訂背光模式
此功能提供5組使用者自訂背光功能，讓使用者依個人喜好，設定想
要的背光按鍵及顏色, 分別儲存於按鍵 1/2/3/4/5 中。
當按下FN+DEL一次後，會啟動第一組自訂背光，再按 FN+DEL一
次，切換下一組， 以此類推。
使用者也可直接按壓FN+1/2/3/4/5 直接叫出對應的自訂背光效果。
自訂背光設定方式：
A. 同時按壓“ “ + “ “ or (2/3/4/5) 選擇要修訂的自訂背光模式
1 (2/3/4/5)
B. 同時按壓“ “ + “ “ + “ “啟動自訂背光錄製
( 4個指示燈快閃爍 )
C. 選擇按壓想要的背光亮起的按鍵，背光亮起，
按“ “ + “ “ or “ “選擇該鍵顏色
D. 繼續按壓其他要設定的按鍵，及選顏色
E. 按壓已亮起的背光按鍵，可再次取消該鍵背光
F. 完成設定，同時按壓“ “ + “ “ + “ “儲存設定,離開自
訂背光設定模式( 4個指示燈停止閃爍 )
G. 2/3/4/5自訂背光模式設定方式同步驟A到F
•“ “ + “ “：背光特效A ( 共3組特效切換 )
•“ “ + “ “：RGB背光特效B ( 共7 組特效切換 )
2.3 多媒體及功能快捷鍵
•“ “ + “ “：顯示桌面
•“ “ + “ “：鎖定電腦
•“ “ + “ “：搜尋檔案或資料夾
•“ “ + “ “：計算機
•“ “ + “ “：我的電腦
•“ “ + “ “：開啟Ｅ-Mail 軟體
•“ “ + “ “：開啟網路瀏覽器
•“ “ + “ “：多媒體呼叫
•“ “ + “ “：播放/暫停
•“ “ + “ “：回上一首
•“ “ + “ “：停止
•“ “ + “ “：回下一首
•“ “ + “ “：開啟跟關閉全部鍵盤鎖鍵功能
( 所有背光功能熄滅，單單ESC鍵背光亮起 )
•“ “ + “ “：開啟跟關閉鎖Windows/Application鍵
2.4 智慧旋鈕功能
智慧滾輪模式相容於Windows 10內建協定，只要您的電腦使用
Windows 10最新版本，皆可支援，無須任何額外驅動程式，從最簡單
的Windows 10 隨附應用程式，專業軟體皆能套用此功能。
智慧轉輪可依不同軟體自訂功能，並能根據軟體自動切換至對應的設
定。隨心切換，滾動瀏覽、縮放或旋轉、調整畫筆、影片剪輯及多媒
體播放等功能。
按壓下列按鍵進行旋鈕功能切換
•“ “：滾輪音量調整模式
滾輪順時針: 調整音量大聲
滾輪逆時針: 調整音量小聲
按壓滾輪: 音量靜音
•“ “：滾輪工作頁面選項模式
滾輪順時針: 向右移動工作頁面選項
滾輪逆時針: 向左移動工作頁面選項
按壓滾輪: 選取頁面
•“ “：智慧轉輪功能 (如下圖)
1. 請至開始>控制台>裝置>轉輪選項進行相關滾輪功能設
定
2. 將游標移置或切換到對應的軟體，常壓旋鈕叫出智慧轉
輪，選轉旋鈕選定所要的功能後按壓旋鈕選定。
(智慧轉輪功能項目會依對應的軟體及自行設定的不同，
自行切換對應的功能選項)
