I-rocks K86r User manual

Model No.：IRK86R

Quick Installation Guide

K86R

Rechargeable Wireless

Mechanical Keyboard

Rechargeable Wireless Mechanical Keyboard

CONTENTS

English

Quick Installation Guide ....................... 1-1

繁體中文快速安裝手冊 ............................................... 2-1

Package Contents

• Keyboard x 1

• USB dongle

• USB-C Cable x 1

• Puller for switch & keycap

• Quick Installation Guide x 1

System Requirements

• Microsoft Windows system: Windows® 7, Windows® 8.1

, Windows® 10. Windows® 11

• Available USB Port

Features

• Mechanical keyswitches for fast response and smooth key feedback

• Preinstalled bottom pad and silicone switch dampener sheet

• All-zone Gateron hotswap sockets

• High performance 2.4GHz wireless / USB wired connection

• Detachable USB-C cable and 2-level adjustable feet

• PBT doubleshot keycaps

• RGB backlight supporting dynamic effects

• Built-in hotkey to access multimedia, mail, full key lock, PC lock and more

• Software for editing macros and backlighting

Specifications

• Keyboard

- Dual mode interface : Wired (USB Full Speed) / Wireless (2.4GHz)

- Key number : 100 Keys

- Switch type : Mechanical switch with hotswap sockets

- Key stroke : 4.0 mm

- N-Key rollover ( NKRO)

- Multimedia keys : 12keys

- Backlight effective keys : 4 keys

- Voltage : DC 5V

- Charging interface : USB C

- Rechargeable li-ion battery : 3750 mAh

- Cable length : approx. 180 cm

- Weight : approx. 1170 g

- Dimension : 384 (L) X 139(W) X 40 (H) mm

• Receiver

- Interface : USB

- Dimension : 18.6(L) X 14.5(W) X 6.1 (H) mm

Hardware Installation

This keyboard has two connection modes: wired and wireless. You may

find connection switch on the bottom of your keyboard.

- Switch “ ON ” : Wireless Mode

- Switch “ OFF “ : Wired Mode

• Wired Installation

1. Flip the connection switch to “ OFF “ for wired mode

2. Turn on your computer

3. Plug USB cable into an available USB port on your computer and keyboard.

( USB Type A for computer & Type C for keyboard )

4. Your computer will automatically detect the keyboard

5. You may use the keyboard after detection

- Press FN+Ctrl+S to enable or disable Energy Saving Mode. When the

mode is enabled, backlight of your keyboard will automatically be

turned off after 5 minutes of keyboard inactivity and turned back on

after pressing any key. Energy Saving Mode in wired mode is

disabled by default.

• Wireless Installation

1. Flip the connection switch to “ ON “ for wireless mode

2. Power on the computer and plug USB receiver into a USB port on

your computer.

3. Turn on the power of keyboard and make sure battery has enough power

4. Your computer will automatically detect the receiver and connect

with the keyboard.

Under wireless mode : The backlight of your keyboard will be

automatically turned off after 1.5 minute of

keyboard inactivity. To turn backlight back on,

press any key.

To set idle timeout for keyboard's Energy Saving Mode in RF mode

Hotswap Switch Replacement

Product Information

1. LED Indicator

- Backlight with only Esc key on : The keyboard is full key locked.

Press Fn+Esc to lock or unlock.

- All 4 indicators blinking : The keyboard is in Backlight

Customization Mode.

2. Function Keys

Press Fn and desired function key simultaneously to use hotkeys.

2.1 Function Keys

2.2 Multimedia & function key

2.3 Backlight Function Keys

3. Software

The keyboard software is working under wired mode only; however,

saved keyboard settings will be applied under both wired and

wireless mode. Please go to iRocks official website to download and

install latest software for backlight, macro, multimedia keys

configuration and more.

1. Double click the installation software you download and follow the

instructions step by

2. Plug in the keyboard after installation, the software will start to

identify it.

3. Launch the software. It will take some time to download the

memory parameter and setting of the keyboard.

Attention : Connection switch (on the bottom of your keyboard) must

be flipped to “OFF” to use the software.

Troubleshooting & Cautions

If your wireless keyboard does not work normally :

■ Check if connection switch on the bottom of your keyboard is

　 flipped to “ ON “ ( 2.4G wireless mode).

■ Check the USB receiver is connected to your computer’s USB port

　 correctly – unplug and plug it back.

■ Charge your keyboard immediately when the battery low indicator

　 lights up.

■ Metal objects close to or in between the keyboard may reduce

　 wireless performance. Try moving metal objects away from the

　 keyboard.

■ This keyboard has 2.4GHz wireless connection,Using USB 3.x and

　 2.4GHz wireless devices at the same time may cause radio

　 frequency interference and affect normal functionality of the

　 wireless device. Try to reduce radio interference of the USB 3.x

　 device to your wireless keyboard, Plug the receiver into the USB 2.0

　 port or other locations as far away as possible from the USB 3.x

　 port or use USB hub / USB extension cable to re-position your

　 wireless receiver to a location away from the USB 3.x port.

■ For saving power, the keyboard goes into sleep mode when it’s not

　 in use for a while. Press any key and wait for 1 to 3 seconds to bring

　 the keyboard out of sleep mode.

■ Charge the battery of your keyboard before storing it without use.

　 Storing your keyboard with low battery status and voltage for long

　 periods of time may cause battery malfunction.

■ When your keyboard is not in use, switching to USB wired mode

　 (connection switch W) is recommended.

■ Avoid putting your keyboard under high moisture condition or

　 direct sun.

■ Do not expose your keyboard to extreme temperatures, heat

　 , fire or liquid.

Wireless ID Pairing

The wireless keyboard is pre-paired with included receiver before

shipment. It saves the need to pair and is ready to use out of the box.

When you need to re-pair your keyboard and receiver manually to

prevent signal interference or other issues, please follow the steps

below :

1. Flip the connection switch to “ ON ” for 2.4G wireless mode and

make sure the keyboard is powered on.

2. Press and hold Fn + P for 3 seconds to enter pairing mode

( P key will flash ).

3. Unplug and plug the USB receiver back into your computer’s

USB port.

4. Move the keyboard to close the USB receiver within 15cm, the ID

setting process will start automatically.

(It will take about 4~8 seconds)

5. Your keyboard should be ready to use

6. The above steps need to be completed within 1 minute, If the

keyboard doesn’t work properly, please remove the USB receiver

from computer’s USB port, then proceed to step 2~4 again.

1-1EN

Rechargeable Wireless Mechanical Keyboard

OFF ON
