I-Tech AVP117e-220DC User manual

How to replace Main Cable
Model: AVP117e-220DC
1. Definition of Main Cable
Connect with
Mouse pad
Connect with AD board
Connect with OSD
board
Connect with
Keyboard
Connect with
button board
For button board
For KB/mouse
For video
signal
For power
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

2. To open the cover
a. Follow photos below, release the screws - rear cover 10 pcs, hinge cover 4 pcs,
LCD module 6 pcs
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

b. Follow photos below, release the screws on the side of LCD module –3pcs each
side.
3. To open the keyboard cover
a. Follow photos below, release the screws x 6
Release screw x 3
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

b. Remove screw x 3
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

4. There is total 4 covers should be removed
a. (Please pay attention when removing the keyboard cover, because there is
cable connecting)
Please pay attention when
removing the keyboard cover,
because there is cable connecting
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

b. Pay attention and try not to move two silver buttons both sides.
If the button falls off unfortunately, this is the
correct way to put it back
Please try not to touch this button
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

5. Change the Main Cable
Follow the original connecting, replace the cables.
a. Main board
b. AD board & OSD board
Power video signal button board KB/mouse
AD board OSD board
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

c. Keyboard & mouse
d. KVM button board
Release screw x 4, and then replace the new cable
i-Tech Company LLC
TOLL FREE: [phone] • EMAIL: [email protected] • WEB: www.iTechLCD.com

6. Stabilize the main cable with cable guide
Buckle for AD board cable & OSD cable
Stable the main cable on
cable guide
