I-Tech IT-E185 User manual

IT-E185 Power Meter Fixture
User Manual
Model: IT-E185
Version: V2.0

Notices
© ItechElectronics, Co., Ltd. 2016
No part of this manual may be
reproduced in any form or by any means
(including electronic storage and
retrieval or translation into a foreign
language) without prior permission and
written consent from Itech Electronics,
Co., Ltd. as governed by international
copyright laws.
Manual Part Number
IT-E185-402317
Revision
2st Edition: June 22, 2016
Itech Electronics, Co., Ltd.
Trademarks
Pentium is U.S. registered trademarks
of Intel Corporation.
Microsoft, Visual Studio, Windows and
MS Windows are registered trademarks
of Microsoft Corporation in the United
States and/or other countries and
regions.
Warranty
The materials contained in this
document are provided “as is”, and
is subject to change, without prior
notice, in future editions. Further, to
the maximum extent permitted by
applicable laws, ITECH disclaims
all warrants, either express or
implied, with regard to this manual
and any information contained
herein, including but not limited to
the implied warranties of
merchantability and fitness for a
particular purpose. ITECH shall not
be held liable for errors or for
incidental or indirect damages in
connection with the furnishing, use
or application of this document or of
any information contained herein.
Should ITECh and the user enter
into a separate written agreement
with warranty terms covering the
materials in this document that
conflict with these terms, the
warranty terms in the separate
agreement shall prevail.
Technology Licenses
The hardware and/or software
described herein are furnished under a
license and may be used or copied only
in accordance with the terms of such
license.
Restricted Rights Legend
U.S. Government Restricted Rights.
Software and technical data rights
granted to the federal government
include only those rights customarily
provided to end user customers. ITECH
provides this customary commercial
license in software and technical
data pursuant to FAR 12.211
(Technical Data) and 12.212
(Computer Software) and, for the
Department of Defense, DFARS
252.227-7015 (Technical Data –
Commercial Items) and DFARS
227.7202-3 (Rights in Commercial
Computer Software or Computer
Software Documentation).
Safety Notices
A CAUTION sign denotes a hazard.
It calls attention to an operating
procedure or practice that, if not
correctly performed or adhered to,
could result in damage to the
product or loss of important data.
Do not proceed beyond a
CAUTION sign until the indicated
conditions are fully understood and
met.
A WARNING sign denotes a hazard.
It calls attention to an operating
procedure or practice that, if not
correctly performed or adhered to,
could result in personal injury or
death. Do not proceed beyond a
WARNING sign until the indicated
conditions are fully understood and
met.
NOTE
A NOTE sign denotes important hint.
It calls attention to tips or
supplementary information that is
essential for users to refer to.

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. i
Certification and Quality Assurance
IT-E185 completely reaches nominal technical indicators in the manual.
Warranty service
ITECH Company will provide one-year warranty services for the product
materials and manufacturing (excluding the following limitations).
When warranty service or repair is needed, please send the product to the
service unit specified by ITECH Company.
When the product is sent to ITECH Company for warranty service, the
customer must pay the one-way freight to the maintenance department of
ITECH, and ITECH will be responsible for return freight.
If the product is sent to ITECH for warranty service from other countries,
the customer will be responsible for all the freight, duties and other taxes.
Limitation of Warranty
Warranty service does not apply to the damage caused in the following
circumstances:
Damage resulting from customer-wired circuits or customer-supplied parts
or accessories;
Product which has been modified or repaired by the customer;
Damage caused by the circuit installed by the customer or damage caused
by operation of the product in non-specified environment;
The product model or serial number is altered, deleted, removed or made
illegible by customer;
Damage caused by accidents, including but not limited to lightning, water,
fire, abuse or negligence.
Safety signs
Direct current
ON (power)
Alternating current
OFF (power)
Both direct and alternating
current
Power-on state
Protective earth (ground)
terminal
Power-off state

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 2
Earth (ground) terminal
Reference terminal
Caution
Positive terminal
Warning (refer to this manual
for specific Warning or
Caution information)
Negative terminal
A chassis terminal
-
-
Regulation tag
The CE tag shows that the product complies
with the provisions of all relevant European
laws (if the year is shown, it indicates that the
year when the design is approved).
This instrument complies with the WEEE
directive (2002/96/EC) tag requirements.
This attached product tag shows that the
electrical/electronic product cannot be
discarded in household waste.
This symbol indicates that no danger will
happen or toxic substances will not leak or
cause damage in normal use within the
specified period. The service life of the
product is 10 years. The product can be
used safely within the environmental
protection period; otherwise, the product
should be put into the recycling system.
Waste electrical and electronic equipment (WEEE)
directive
Waste electrical and electronic equipment (WEEE) directive,

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 3
2002/96/EC
The product complies with tag requirements of the WEEE
directive (2002/96/EC). This tag indicates that the electronic
equipment cannot be disposed of as ordinary household waste.
Product Category
According to the equipment classification inAnnex I of the WEEE
directive, this instrument belongs to the “Monitoring” product.
If you want to return the unnecessary instrument, please contact
the nearest sales office of ITECH.

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 4
Compliance Information
Complies with the essential requirements of the following applicable European
Directives, and carries the CE marking accordingly:
Electromagnetic Compatibility (EMC) Directive 2014/30/EU
Low-Voltage Directive (Safety) 2014/35/EU
Conforms with the following product standards:
EMC Standard
IEC 61326-1:2012/ EN 61326-1:2013 ¹²³
Reference Standards
CISPR 11:2009+A1:2010/ EN 55011:2009+A1:2010 (Group 1, Class A)
IEC 61000-4-2:2008/ EN 61000-4-2:2009
IEC 61000-4-3:2006+A1:2007+A2:2010/ EN 61000-4-3:2006+A1:2008+A2:2010
IEC 61000-4-4:2004+A1:2010/ EN 61000-4-4:2004+A1:2010
IEC 61000-4-5:2005/ EN 61000-4-5:2006
IEC 61000-4-6:2008/ EN 61000-4-6:2009
IEC 61000-4-11:2004/ EN 61000-4-11:2004
1. The product is intended for use in non-residential/non-domestic environments. Use of the
product in residential/domestic environments may cause electromagnetic interference.
2. Connection of the instrument to a test object may produce radiations beyond the specified
limit.
3. Use high-performance shielded interface cable to ensure conformity with the EMC standards
listed above.
Safety Standard
IEC 61010-1:2010/ EN 61010-1:2010

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. v
CONTENT
Certification and Quality Assurance ...................................................................................................................... 1
Warranty service................................................................................................................................................... 1
Limitation of Warranty .......................................................................................................................................... 1
Safety signs ........................................................................................................................................................... 1
Regulation tag....................................................................................................................................................... 2
Waste electrical and electronic equipment (WEEE) directive................................................................................. 2
Compliance Information ....................................................................................................................................... 4
About IT-E185 ....................................................................................................................................................... 1
Dimension............................................................................................................................................................. 1
Introduction of Front Panel and Rear Panel........................................................................................................... 2
Connecting Fixture ................................................................................................................................................ 2
Application Case ................................................................................................................................................... 5

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 1
About IT-E185
IT-E185 is an optional accessory for the User of ITECH, which is mainly for
convenient wiring during test with IT9121/IT9121E power meter. See the figure
below for IT-E185:
Dimension
IT-E185 dimension figure is as follows:
Unit:mm

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 2
Introduction of Front Panel and Rear Panel
IT-E185 Front Panel
①Three core socket
②Power Switch
IT-E185 Rear Panel
①Voltage input terminals
②AC power input socket
③Current input terminals
Connecting Fixture
During AC input power consumption test of AC-DC adapter, the IT-E185 is
required to connect IT9121/IT9121E to the adapter and grid lines in series.
When the measured current is relatively large, connect the voltage input
terminal to the side that is closest to the load. When the measured current is
relatively small, connect the current input terminal to the side that is closest to
the load. both circuit figures are as follows:
①
②
①
②
③

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 3
Measuring higher current:
Measuring lower current:
Voltage input terminal
The terminals are safety banana jacks (female). Only insert a safety
terminal whose conductive parts are not exposed into a voltage input
terminal.
Current input terminal
The terminals are binding posts, and the screws are M6. Either wind a
wire around a screw or pass a crimped terminal through the screw axis,
and then tighten firmly with the terminal knob.
Connecting Method
The connection method for measuring the low-current measurement circuit is
as follows:
1. Open the current terminal protection covers of the power meter and the
device.
Protective Cover
Protective Cover

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 4
2. Put the DUT input terminal to the three-core socket on the front panel.
3. Connect the voltage and current terminals of IT9121/IT9121E power meter
to the corresponding terminals on the rear panel, as shown below:
NOTE
Connect the voltage positive terminal of the power meter to the V+2 terminal on the rear
panel and put the V+1 suspended when high current is measured.
4. Connect theAC power input socket of the rear panel to the 220 VAC input,
as show above.
5. To guarantee personal safety, after the measurement circuit is connected,
Connect DUT input terminal
Connect AC input

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 5
please install the current terminal protection cover to avoid touching the
current terminal during measurement.
Application Case
When testing the AC input power consumption of AC-DC adapter,
IT9121/IT9121E is required to be connected to the adapter and grid lines in
series.
Without Fixture
When the device is not used, cut off the plug that connects to the grid lines and
lead out the internal L, N and GND wires. Connect the voltage and current
terminals of the power meter to the circuit following the principles of voltage
parallel circuit and current series circuit.
Use Fixture
When the fixture is used, the wiring is simple without damaging the original plug.
Wiring steps are as follows:
1. Put the DUT input terminal to the three-core socket on the front panel.
Power meter
Connect battery to
output terminal
220V AC power input
220V AC
power input
Test AC power input consumption
DUT
Cut point

IT-E185User Manual
Copyright © Itech Electronics Co., Ltd. 6
2. It is not necessary to cut off the plug. After the current passes through the
device, the device will automatically strip the voltage and current terminals
from the three-core plug. Connect the corresponding voltage and current
terminals to the terminals on IT9121/IT9121E power meter.
The front panel
of IT-E185
The rear panel
of IT-E185

Contact US
Thank you for purchasing ITECH products.If you have any doubt about this product, please
contact us as follow.
1. Please refer to the CD-ROM of related user’s manual in package.
2. Click www.itechate.com or scan the right two-dimension code
to visit the ITECH website.
3. Select the most convenient contact method for further consultancy.
4. Send E-mail to [e-mail] or dial the service hot-line in China: 4006025000
YOUR POWER TESTING SOLUTION
