I-Tech IT2800 Series User manual

Graphical Source Measure
Unit
IT2800 Series User Manual
Model: IT2800
Version: V1.0 / 08，2022

Notices
© Itech Electronic, Co.,
Ltd. 2022
No part of this manual
may be reproduced in any
form or by any means (in-
cluding electronic storage
and retrieval or translation
into a foreign language)
without prior permission
and written consent from
Itech Electronic, Co., Ltd.
as governed by interna-
tional copyright laws.
Manual Part Number
Trademarks
Pentium is U.S. registered
trademarks of Intel
Corporation.
Microsoft, Visual Studio,
Windows and MS Win-
dows are registered
trademarks of Microsoft
Corporation in the United
States and/or other coun-
tries and regions.
Warranty
The materials contained in this docu-
ment are provided “as is”, and is sub-
ject to change, without prior notice, in
future editions. Further, to the maxi-
mum extent permitted by applicable
laws, ITECH disclaims all warrants, ei-
ther express or implied, with regard to
this manual and any information con-
tained herein, including but not limited
to the implied warranties of merchant-
ability and fitness for a particular pur-
pose. ITECH shall not be held liable
for errors or for incidental or indirect
damages in connection with the fur-
nishing, use or application of this
document or of any information con-
tained herein. Should ITECH and the
user enter into a separate written
agreement with warranty terms cover-
ing the materials in this document that
conflict with these terms, the warranty
terms in the separate agreement shall
prevail.
Technology Licenses
The hardware and/or software de-
scribed herein are furnished under a li-
cense and may be used or copied only
in accordance with the terms of such
license.
Restricted Rights Legend
Restricted permissions of the U.S.
government. Permissions for software
and technical data which are author-
ized to the U.S. Government only in-
clude those for custom provision to
end users. ITECH follows FAR 12.211
(technical data), 12.212 (computer
software). DFARS 252.227-7015
(technical data–commercial products)
and DFARS 227.7202-3 (permissions
for commercial computer software or
computer software documents) while
providing the customized business li-
censes of software and technical data.
Safety Notices
A CAUTION sign denotes
a hazard. It calls attention
to an operating procedure
or practice that, if not cor-
rectly performed or ad-
hered to, could result in
damage to the product or
loss of important data. Do
not proceed beyond a
CAUTION sign until the in-
dicated conditions are
fully understood and met.
A WARNING sign denotes
a hazard. It calls attention
to an operating procedure
or practice that, if not cor-
rectly performed or ad-
hered to, could result in
personal injury or death.
Do not proceed beyond a
WARNING sign until the
indicated conditions are
fully understood and met.
A NOTE sign denotes im-
portant hint. It calls atten-
tion to tips or
supplementary informa-
tion that is essential for
users to refer to.

Copyright © Itech Electronic Co., Ltd. I
IT2800 Series User Manual
Quality Certification and Assurance
We certify that series instrument meets all the published specifications at time
of shipment from the factory.
Warranty
ITECH warrants that the product will be free from defects in material and work-
manship under normal use for a period of one (1) year from the date of delivery
(except those described in the Limitation of Warranty below).
For warranty service or repair, the product must be returned to a service center
designated by ITECH.
•The product returned to ITECH for warranty service must be shipped PRE-
PAID. And ITECH will pay for return of the product to customer.
•If the product is returned to ITECH for warranty service from overseas, all
the freights, duties and other taxes shall be on the account of customer.
Limitation of Warranty
This Warranty will be rendered invalid in case of the following:
•Damage caused by circuit installed by customer or using customer own
products or accessories;
•Modified or repaired by customer without authorization;
•Damage caused by circuit installed by customer or not operating our prod-
ucts under designated environment;
•The product model or serial number is altered, deleted, removed or made il-
legible by customer;
•Damaged as a result of accidents, including but not limited to lightning, mois-
ture, fire, improper use or negligence.

Copyright © Itech Electronic Co., Ltd. II
IT2800 Series User Manual
Safety Symbols
Direct current ON ( power)
Alternating
current
OFF ( power)
Both direct and
alternating
current
Power-on state
Chassis (earth
ground) symbol.
Power-off state
Earth ( ground)
terminal
Reference
terminal
Caution Positive terminal
Warning ( refer to
this manual for
specific Warning
or Caution
information)
Negative terminal
A chassis
terminal
- -
Safety Precautions
The following safety precautions must be observed during all phases of opera-
tion of this instrument. Failure to comply with these precautions or specific warn-
ings elsewhere in this manual will constitute a default under safety standards of
design, manufacture and intended use of the instrument. ITECH assumes no li-
ability for the customer’s failure to comply with these precautions.

Copyright © Itech Electronic Co., Ltd. III
IT2800 Series User Manual
•Do not use the instrument if it is damaged. Before operation, check
the casing to see whether it cracks. Do not operate the instrument
in the presence of inflammable gasses, vapors or dusts.
•The instrument is provided with a power cord during delivery and
should be connected to a socket with a protective earth terminal, a
junction box or a three-phase distribution box. Before operation, be
sure that the instrument is well grounded.
•Please always use the provided cable to connect the instrument.
•Check all marks on the instrument before connecting the instru-
ment to power supply.
•Ensure the voltage fluctuation of mains supply is less than 10% of
the working voltage range in order to reduce risks of fire and elec-
tric shock.
•Do not install alternative parts on the instrument or perform any un-
authorized modification.
•Do not use the instrument if the detachable cover is removed or
loosen.
•To prevent the possibility of accidental injuries, be sure to use the
power adapter supplied by the manufacturer only.
•We do not accept responsibility for any direct or indirect financial
damage or loss of profit that might occur when using the
instrument.
•This instrument is used for industrial purposes, do not apply this
product to IT power supply system.
•Never use the instrument with a life-support system or any other
equipment subject to safety requirements.

Copyright © Itech Electronic Co., Ltd. IV
IT2800 Series User Manual
•SHOCK HAZARD Ground the Instrument. This product is provided
with a protective earth terminal. To minimize shock hazard, the in-
strument must be connected to the AC mains through a grounded
power cable, with the ground wire firmly connected to an electrical
ground (safety ground) at the power outlet or distribution box. Any
interruption of the protective (grounding) conductor or disconnec-
tion of the protective earth terminal will cause a potential shock
hazard that could result in injury or death.
•Before applying power, verify that all safety precautions are taken.
All connections must be made with the instrument turned off, and
must be performed by qualified personnel who are aware of the
hazards involved. Improper actions can cause fatal injury as well as
equipment damage.
•SHOCK HAZARD, LETHAL VOLTAGES This product can output the
dangerous voltage that can cause personal injury, and the operator
must always be protected from electric shock. Ensure that the out-
put electrodes are either insulated or covered using the safety cov-
ers provided, so that no accidental contact with lethal voltages can
occur.
•Never touch cables or connections immediately after turning off the
instrument. Verify that there is no dangerous voltage on the electro-
des or sense terminals before touching them.
•After using the device, turn off the power switch of the device be-
fore unplugging the power cord or disassembling the terminals. Do
not touch the cable or the terminal immediately. Depending on the
model, the dangerous voltage at the plug or terminal is maintained
for 10 seconds after the device is switched off. Make sure that there
is no dangerous voltage before touching them.
•Failure to use the instrument as directed by the manufacturer may
render its protective features void.
•Always clean the casing with a dry cloth. Do not clean the internals.
•Make sure the vent hole is always unblocked.
Environmental Conditions
The instrument is designed for indoor use and an area with low condensation.
The table below shows the general environmental requirements for the
instrument.

Copyright © Itech Electronic Co., Ltd. V
IT2800 Series User Manual
Environmental Conditions Requirements
Operating temperature 0°C～40°C
Operating humidity 20%～80%( non-condensation)
Storage temperature -10°C～70 °C
Altitude Operating up to 2,000 meters
Installation category II
Pollution degree Pollution degree 2
In order to ensure the accuracy of measurement, it is recommended to oper-
ate the instrument half an hour after start-up.
Regulation Tag
The CE tag shows that the product complies with the
provisions of all relevant European laws (if the year is
shown, it indicates that the year when the design is
approved).
The UKCA tag shows that the product complies with
the provisions of all relevant United Kingdom laws (if
the year is shown, it indicates that the year when the
design is approved).
This instrument complies with the WEEE directive
(2002/96/EC) tag requirements. This attached product
tag shows that the electrical/electronic product cannot
be discarded in household waste.
This symbol indicates that no danger will happen or
toxic substances will not leak or cause damage in nor-
mal use within the specified period. The service life of
the product is 10 years. The product can be used
safely within the environmental protection period; oth-
erwise, the product should be put into the recycling
system.

Copyright © Itech Electronic Co., Ltd. VI
IT2800 Series User Manual
Waste Electrical and Electronic Equipment
(WEEE) Directive
Waste electrical and electronic equip-
ment (WEEE) directive, 2002/96/EC
The product complies with tag re-
quirements of the WEEE directive
(2002/96/EC). This tag indicates that
the electronic equipment cannot be
disposed of as ordinary household
waste. Product Category
According to the equipment classifi-
cation in Annex I of the WEEE direc-
tive, this instrument belongs to the
“Monitoring” product.
If you want to return the unnecessary
instrument, please contact the near-
est sales office of ITECH.

Copyright © Itech Electronic Co., Ltd. VII
IT2800 Series User Manual
Compliance Information
Complies with the essential requirements of the following applicable European
Directives, and carries the CE marking accordingly:
•Electromagnetic Compatibility (EMC) Directive 2014/30/EU
•Low-Voltage Directive (Safety) 2014/35/EU
Conforms with the following product standards:
EMC Standard
IEC 61326-1:2012/ EN 61326-1:2013 ¹²³
Reference Standards
CISPR 11:2015+A1:2016 Ed 6.1
IEC 61000-3-2: 2018 RLV
IEC 61000-3-3: 2013+A1:2017
IEC 61000-4-2:2008
IEC 61000-4-3 2006+A1:2007+A2:2010/ EN 61000-4-3 A1:2008+A2:2010
IEC 61000-4-4:2012
IEC 61000-4-5:2014+A1:2017
IEC 61000-4-6:2013+cor1:2015
IEC 61000-4-11:2004+A1:2017
1. The product is intended for use in non-residential/non-domestic environments. Use of the
product in residential/domestic environments may cause electromagnetic interference.
2. Connection of the instrument to a test object may produce radiations beyond the specified
limit.
3. Use high-performance shielded interface cable to ensure conformity with the EMC standards
listed above.
Safety Standard
IEC 61010-1:2010+A1:2016

Copyright © Itech Electronic Co., Ltd. VIII
IT2800 Series User Manual
Content
Quality Certification and Assurance .................................................................................. I
Warranty ............................................................................................................................ I
Limitation of Warranty ........................................................................................................ I
Safety Symbols................................................................................................................. II
Safety Precautions............................................................................................................ II
Environmental Conditions................................................................................................ IV
Regulation Tag.................................................................................................................. V
Waste Electrical and Electronic Equipment (WEEE) Directive ....................................... VI
Compliance Information.................................................................................................. VII
1 Quick Reference................................................................................................................. 1
1.1 Brief Introduction...................................................................................................... 1
1.2 Front-Panel Overview .............................................................................................. 2
1.3 Home-Screen Overview........................................................................................... 4
1.4 Icon Reference......................................................................................................... 5
1.5 Rear-Panel Overview............................................................................................... 7
1.6 Menu Overview ........................................................................................................ 9
1.6.1 Meter.............................................................................................................. 9
1.6.2 Scope........................................................................................................... 15
1.6.3 Recorder ...................................................................................................... 19
1.6.4 Sweep.......................................................................................................... 22
1.6.5 Meas ohms .................................................................................................. 25
1.6.6 Meas limit..................................................................................................... 26
1.6.7 Meas math ................................................................................................... 31
1.6.8 System......................................................................................................... 34
1.6.9 Config .......................................................................................................... 37
1.6.10 Battery ....................................................................................................... 41
1.6.11 Save / Recall.............................................................................................. 45
1.7 Models and Options ............................................................................................... 46
2 Inspection and Installation................................................................................................ 50
2.1 Verifying the Shipment ........................................................................................... 50
2.2 Instrument Size Introduction .................................................................................. 51
2.3 Rack Installation..................................................................................................... 51
2.4 Connecting the Power Cord................................................................................... 52
2.5 Connecting the Device Under Test (DUT) ............................................................. 54
3 Technical Specification..................................................................................................... 58
3.1 Main Specification.................................................................................................. 58
3.1.1 IT2801.......................................................................................................... 58
3.1.2 IT2805.......................................................................................................... 62
3.1.3 IT2806.......................................................................................................... 67
3.2 Supplemental Characteristics................................................................................ 72
4 Routine Maintenance ....................................................................................................... 73
4.1 Instrument Self-Test............................................................................................... 73
4.2 Cleaning and Maintenance .................................................................................... 73
4.3 Contact of ITECH Engineers ................................................................................. 74
4.4 Return for Repair.................................................................................................... 75

Quick Reference
1Quick Reference
This chapter briefly introduces the front panel, rear panel, keyboard button
functions and front panel display functions of this series instrument to ensure a
quick understanding of the appearance, structure and key usage features of the
instrument before operating the instrument. This chapter does not introduces
each operating characteristics in detail. It is just a quick reference guide to help
you quickly learn the operating characteristics of the instrument.
♦ Brief Introduction
♦ Front-Panel Overview
♦ Home-Screen Overview
♦ Icon Reference
♦ Rear-Panel Overview
♦ Menu Overview
♦ Models and Options
1.1 Brief Introduction
The IT2800 Series are compact and cost-effective bench-top Source Measure
Units (SMUs) with the capability to source and measure both voltage and
current. These capabilities make the IT2800 Series ideal for a wide variety of IV
(current versus voltage) measurement tasks that require both high resolution
and accuracy.
Performance and functions:
•5 inch touch display supports both graphical and numerical view modes.
•Combing the capabilities of six devices in one: Voltage Source, Current
Source, 6 ½ Digital Multimeter (DCV,DCI, ohms), Battery Simulator,
electronic load and Pulse Generator
•Integrating 4-quadrant sourcing & measuring capabilities, and supporting
Two-wire & Four-wire measurement
•Resolution up to 10fA/100nV, sampling rate up to 10us.
•Built-in battery simulator function, suitable for IOT low power precision
measurement
•Sweep Capability: Linear/Log/ Pulsed-line AR/Pulsed-Log and LIST
•Multi-channel and simultaneous operation design, with parallel testing
capability
•Built-in resistance, power, and Math measurement features
•With GUARD output function, suitable for low current measurement
Copyright © Itech Electronic Co., Ltd. 1

Quick Reference
•Front USB port used for data storage, screen capture, or test configuration
import
•Built-in Digital IO/USB/LAN communication interface
1.2 Front-Panel Overview
The detailed front panel of the IT2800 series instruments is described below.
•IT2801
•IT2806
Copyright © Itech Electronic Co., Ltd. 2

Quick Reference
Name Description
USB-A port Saves reading buffer data and screen snapshots to a USB
flash drive (Menu→System→Communication→USB Type
must be set to Host). The flash drive must be formatted as a
FAT32 drive. After disconnecting the USB memory, wait 10
seconds before connecting it again or new one. Turning the
instrument off while the USB memory is being accessed
may damage the device.
[View] Used to change the display mode. Press the [View] key to
enter the oscilloscope interface. Press the [View] key again
to enter the Meter measurement interface.
[Trig] Start a single measurement or start a trigger system.
[Menu] Menu function button.
Power Switch Turn on or off the power switch of the instrument.
Touchable
display
The 5-inch touch screen can display source meter settings,
measurement results, status information, etc. Operations
involving parameter setting or selection can be set by
clicking on the touch screen, or by using the function buttons
on the right side combined with the knob.
[On/Off] Turns the power output on or off. When this button is lit, the
output is on.
[Shift] key Composite function keys that combine with other keys to
achieve the function labeled above the key.
[V-set]
(Config)
•Voltage setting button.
•Key combination. Use the [Shift] then [V-set] keys to
access the Config menu.
[I-set]
(Sweep)
•Current setting button.
•Key combination. Use the [Shift] then [I-set] keys to
enter Sweep interface.
[Esc] (Local) •Exit / Undo key
•Key combination. In remote programmable operation,
use the [Shift] then [Esc] keys to switch the instrument
to local operation mode.
[Enter] (Print) •Confirm button
•Key combination. Use the [Shift] then [Enter] keys to
take a screenshot and save the image as a bmp file.
Copyright © Itech Electronic Co., Ltd. 3

Quick Reference
Name Description
Pressable
knob
•Turn the knob to adjust the voltage or current value, or
turn the page to display the menu item. Turn clockwise to
increase the set value and counterclockwise to decrease
the set value; after entering the menu interface, turn the
knob to turn the page to display the menu items.
•Press the knob. Equivalent to the [Enter] key.
Left and right
arrow keys
Use the left and right arrow keys to move the cursor below a
number, or to move to select a setting item.
Output /
Measurement
terminals
Terminals for SMU channel. High Force, Low Force, High
Sense, Low Sense, Guard, and chassis ground. For details,
see2.5 Connecting the Device Under Test (DUT).Attention:
Never connect the Guard terminal to any output,
including circuit common, chassis ground, or any other
guard terminal. Doing so will damage the instrument.
1.3 Home-Screen Overview
IT2800series SMUs run a self-test automatically when it is powered on. If the
self-test finishes with no errors, the screen below is displayed.
Copyright © Itech Electronic Co., Ltd. 4

Quick Reference
No. Name Description
1 Status display
area
Displays information such as the instrument's
measurement range or status.
2 Measured
value display
area
The measured values are displayed in real time. The
upper row is for the primary measurement data and
the lower row is for the secondary measurement
data.
3 Measurement
trigger mode
(Auto/Manual)
•Continue & Measure (Auto): Automatically and
continuously refreshes the Meter value.
•Manual Trigger Mode (Manual): Manual trigger is
required, and the trigger signal must be received
first (e.g. Trig button, pin trigger, etc.), and then
the Meter value is refreshed.
4 Setting value
editing area
Set the voltage value and current value. You can
change these values by pressing the [V-set] and
[I-set] keys on the front panel.
5 Range
selection area
Select the measurement range.
1.4 Icon Reference
This series of instruments provides detailed prompt information during
operation to facilitate users to understand the instrument functions during use.
•Icon Introduction
Icon Description Icon Description
Output off state
The output is on and in CV
constant voltage mode.
The output is on and in
CC constant current
mode. Config configuration menu
Battery simulation
function is enabled Sense function is turned on
Recorder function is
turned on
Resistance measurement
function is turned on
Copyright © Itech Electronic Co., Ltd. 5

Quick Reference
Icon Description Icon Description
Composite limit test
function is turned on
Math calculation function is
turned on
Pulse mode is turned
on
Waiting for the trigger to run
Sweep
Sweep is running
The interlock terminal is open.
At this time, the voltage setting
value is less than or equal to
±42V, and cannot be set greater
than ±42V.
Interlock terminal short-
circuit state. The
voltage setting can
exceed ±42V at this
time, up to the rated
voltage value.
The instrument is under remote
control.
The instrument
recognizes that the
USB flash drive is
inserted.
High capacitance mode is
turned on.
Multi-master fault
indication
Fiber optic communication
anomaly
Disable output. This
fault indication pops up
when the output is
greater than 42V and
the Interlock becomes
open. Overcurrent protection status
Over temperature
protection status Overvoltage protection status
Sense abnormal
protection status Communication command error
Voltage measurement
in the 1000V range (-
only IT2801 models are
available)
Voltage measurement in the
200V range
Voltage measurement
in the 20V range
Voltage measurement in the 2V
range
Copyright © Itech Electronic Co., Ltd. 6

Quick Reference
Icon Description Icon Description
Voltage measurement
in the 200mV range
Current measurement in 10A
range (only IT2806 available)
Current measurement
in 3A range
Current measurement in 1A
range
Current measurement
in 100mA range
Current measurement in 10mA
range
Current measurement
in 1mA range
Current measurement in 100uA
range
Current measurement
in 10uA range
Current measurement in 1uA
range
Current measurement
in 100nA range
Current measurement in 10nA
range
Resistance
measurement in the
200MΩ range
Resistance measurement in the
20MΩ range
Resistance
measurement in the
2MΩ range
Resistance measurement in the
200kΩ range
Resistance
measurement in the
20kΩ range
Resistance measurement in the
2kΩ range
Resistance
measurement in the
200Ω range
Resistance measurement in the
20Ω range
Resistance
measurement in the 2Ω
range -
1.5 Rear-Panel Overview
The IT2800 Series SMU detailed rear panel description is shown below.
Copyright © Itech Electronic Co., Ltd. 7

Quick Reference
No. Name Description
1 Optional
expansion slot
Optional interfaces: (The baffle is installed by default when the user
does not purchase the interface.)
•IT-E177: GPIB communication card
2 Smart fan outlet This is the cooling fan outlet, please do not cover or block it.
3 Digital I/O
terminals
Rear panel digital IO terminals. For detailed pin function
descriptions, see Digital I/O instruction.
4 Fiber optic
socket interface
(TX and RX)
For communication between multiple SMUs, suitable for multi-
channel and synchronous operation.
5 USB-B
communication
interface
USB-B type interface, supporting both USBTMC and USBVCP
options. And, the Menu→System→Communication→USB Type
must be set to Device.
6 LAN
communication
interface
Used for LAN communication.
7 AC power input
interface
The AC power cord is connected to this outlet and supports
100~240VAC input.
Digital I/O instruction
The pins of Digital I/O are described as follows.
Copyright © Itech Electronic Co., Ltd. 8

Quick Reference
Pin Description
1~16 Digital I/O pins, specific function reference 1.6.8 System.
17~20 GND
21 and
22
Inter Lock Control (output interlock terminal), shorting these 2 pins,
the device can set and output more than ±42V; otherwise, it only
supports setting and outputting ±42V and below.
23~25 +5V reference voltage pin. Can be used to provide 5V high level
control signal to Digital I/O pins 1~16.
1.6 Menu Overview
When the [Menu] button in the lower left corner of the instrument is pressed,
the button lights up and the screen displays as follows.
1.6.1 Meter
Function Introduction
For an introduction to the interface, see 1.3 Home-Screen Overview.
The IT2800 supports the following measurement parameters. The
measurement parameters displayed in the actual interface are associated with
the settings of Menu→Config→Measure→View Type.
Copyright © Itech Electronic Co., Ltd. 9

Quick Reference
•Current
•Voltage
•Resistance
•Power
Resistance data is given by Resistance = Vmeas/Imeas.
Power data is given by Power = Vmeas * Imeas.
In the above formula, Vmeas is the voltage measurement data, and Imeas is
the current measurement data.
Parameter Setting
The Meter interface also supports the setting of voltage and current values, as
well as the selection of voltage and current ranges.
Voltage value setting:
Based on the Menu→Config→Source Mode setting is Volts (Voltage source
mode) or Amps (Current source mode), the Meter interface will display the
voltage setting as V-set or V Limit.
The setup method is as follows.
•Method 1: Set by knob and button combination
1. Turn the knob or press the left/right key in the Meter screen until the
parameter area is selected.
2. Press the [Enter] key.
The cursor flashes at this point, indicating that the parameter is in the
state to be modified, as shown in the following figure.
Copyright © Itech Electronic Co., Ltd. 10
