I-Tech ASKW2400SX User manual

ASKW2400SX
LCD Console Drawer Quick
Installation Guide
i-Tech CompanyLLC
TOLLFREE:[phone]• EMAIL:[email protected]m• WEB:www.iTechLCD.com

Stepone
LoosenscrewA onbothsidestoslideoutandremovethetworearsliderails.
Steptwo
AttachthetworearsliderailstotherearverticalmountingrailsoftherackcabinetusingstandardM6cage
nutsandscrews.
Stepthree
PositiontheLCDconsoledrawersothetworearsliderailswillslideintothemainbodyoftheLCDconsole
drawer.AttachthemountingearsoftheLCDconsoledrawertothefrontverticalmountingrailsoftherack
cabinetusingstandardM6cage nutsandscrews.
I-TECH
i-Tech CompanyLLC
CDMPANYL TOLLFREE:[phone]• EMAIL:[email protected]m• WEB:www.iTechLCD.com

Step four
UnlockLatch(B)totheleft.Slideoutalongwiththe rail.
Stepfive
UnlockLatch(B)totheleftagaintoliftupLCD.
Step si
nlockLatch(C)toadjustscreenanglebyholdingthehandle(D)totheright.
I-TECH
i-Tech CompanyLLC
COMPANY) TOLLFREE:[phone]• EMAIL:[email protected]m• WEB:www.iTechLCD.com

Stepseven
.heoperatingposition.
2. Adjustthelocker(E)totheright,thenbackward,andLCDmodulewillbelocked.
Step eight
1. Afteroperating,releasethelocker(E)toforwardandtheleft.
2. Holdthehandle(D)totheleft.
I-TECH
i-Tech CompanyLLC
COMPANY) TOLLFREE:[phone] • EMAIL:[email protected]m• WEB:www.iTechLCD.com

ConnectingGuide
