i3-TECHNOLOGIES i3PROJECTOR Configuration guide

www.i3-technologies.com i3PROJECTOR cleaning instructions
CLEANING INSTRUCTIONS
FOR i3PROJECTOR — 2015/08/17

www.i3-technologies.com i3PROJECTOR cleaning instructions
Preface
This is just a simply cleaning instruction for the projector. If the dust is in
the engine module, please follow normal repair procedure to replace a new
engine module.
Suggest to wear dust masks and gloves when cleaning projector.

www.i3-technologies.com i3PROJECTOR cleaning instructions
Contents
I. Cleaning Tools
II. Cleaning instruction
1.Lamp Base Projector Cleaning
(1).External cleaning
(2).Internal cleaning
2.Laser Base Projector Cleaning
(1).External cleaning
(2).Internal cleaning

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Tools
4
Cleaning Tools
Electrostatic ion gun
Dust masks Anti-static gloves
Dust free cloth

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
5
Cleaning Instruction
1.Lamp base projector cleaning for 2402W and 2802W.
(1).External cleaning
a.Using dust free cloth to clean appearance of the whole projector.

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
6
b.Pull out the filter and using the electrostatic ion gun to clean the filter*2.
Blowing back and forth about 3~5s
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
7
C.Remove the lamp module and using the electrostatic ion gun to clean the
lamp module.
.
First,as picture, using electrostatic to
blow the explosion-proof mesh about
3~5s,then,turn over lamp module to
blow the other side of explosion-
proof mesh.
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
8
(2).Internal cleaning
First,using electrostatic ion gun to blow from inside to outside
about 3~5s to avoid dust into inside of machine and engine.
Blowing LVPS Blowing top cover Blowing lamp coverBlowing IO cover
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
9
Then,using dust free cloth to clean the surface of the projector
that visible.
The dust cleaning is completed.
Put a protective film on the mirror before blowing to prevent the dust entering
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
10
2.Laser Base Projector Cleaning for L3502W,L3302FH andL3002UW .
(1).External cleaning
a.Using dust free cloth to clean appearance of the whole projector.
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
11
b.Pull out the filter and using the electrostatic ion gun to blow the filter*2.
Blowing back and forth about 3~5s
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
12
(2).Internal cleaning
First,using electrostatic ion gun to blow from inside to outside
about 3~5s to avoid dust into inside of machine and engine.
Blowing LVPS Blowing left coverBlowing heat sink Blowing right cover
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
Cleaning Instructions
13
Then ,using dust free cloth to clean the surface of the projector
that visible.
The dust cleaning is completed.
Blowing top cover
Seal the aperture of
engine module before
blowing by 3M tape
to prevent the dust
entering
Cleaning Instruction

www.i3-technologies.com i3PROJECTOR cleaning instructions
