IA Networks Technology IPM3400 User manual

IPM3400 Compact Power Meter
User guide
IA Networks Technology Co., Ltd.
5F-1, No.44, Sec. 2, Roosevelt Rd., Taipei, Taiwan
TEL：[phone] FAX：[phone]
http:// www.iantech.com.tw E-mail：[email protected]

IA Networks Technology IPM3400 User Guide
3
Content
Chapter 1 Introduction
1.1 Introduction
1.2 Caution
1.2.1 Danger
1.2.2 Products Warranty and Customer Support
1.2.3 Limitation of Warranty
Chapter 2: Specification
Chapter 3 : Installation
3.1 Inspection
3.2 safety
3.3 Size and Latch
3.4 Mounting and Dismounting
3.4.1 Mounting
3.4.2 Dismounting
Chapter 4 : Wiring Diagrams
4.1 Connection Diagrams
Chapter 5 : Dip switch On/Off
Chapter 6: Communication Formats
6.1 Specification
6.2 Modbus Register
Appendix : Question and Answer

IA Networks Technology IPM3400 User Guide
4
Chapter 1 Introduction
1.1 Product Introduction
IPM3400 series are designed for general single phase or poly phase power measurement, with wide
range. it con be applied either on low voltage primary side or medium/high voltage secondary side for
its high accuracy (<1%, IEC62053-21) under 5A current. IPM3400 equipped with clip-on CT, standard
communication, small size and low cost.
Features：
1. True RMS energy and power parameters measurement in compact size。
2. clip-on CT, easy wiring for on-line installation。
3. RS485 communication support Modbus protocol。
4. Wh accuracy better than 0.5%(pf =1)。
5. Support Lon Talks (option)。
6. wild range of measurement with various size of CT , up to 200A(24Φmm) 。
7. LED pulse output。
1.2 Caution
1.2.1 Danger
The meter contains hazardous voltages. The meter should never be disassembled. Failure
to observe this practice can result in serious injury or death. Any work on or near energized
meters, meter sockets, or other metering equipment can present a danger of electrical
shock. It is strongly recommended that all work should be performed only by qualified
industrial electricians and metering specialist. IA Networks assumes no responsibility if your
electrical installer does not follow the appropriate national and local electrical codes.
1.2.2 PRODUCT WARRANTY & CUSTOMER SUPPORT
IA Networks warrants all products free from defects in material and workmanship for a
period of one year from the date of shipping. During the warranty period, we will, at our
position, either repair any product that proves to be defective. To report any defect, please
contact ：[phone] or [email protected]w.
Please have the model, serial number and a detailed problem description available when
you call. If the problem concerns a particular reading, please have all meter readings
available. When returning any merchandise to IA Networks, a return SN. is required.
1.2.3 LIMITATION OF WARRANTY
This warranty does not apply to defects resulting from unauthorized modification, misuse,
or use for reason other than electrical power monitoring. The supplied meter is not a
user-serviceable product.

IA Networks Technology IPM3400 User Guide
5
Chapter 2 Specification
Input V 10-300V
Input I CT Φ10mm （60A）， CT Φ16mm（100A）、CT Φ24mm（200A）
Aux Power DC 10-30V
Frequency 60/50Hz
Starting I <0.025A
Wiring diagram 1-phase 4-channel
Power
Parameters
Measures
V1, V1, V2, V2
I 1, I 2, I 3, I 4
kW1, kW2, kW3, kW4
kVA1, kVA2, kVA3, kVA4
kvar1, kvar2, kvar3, kvar4
PF1, PF2, PF3, PF4
kWh1, kWh2, kWh3, kWh4
kVAh1, kVAh2, kVAh3, kVAh4
kvarh1, kvarh2, kvarh3, kvarh4
Frequency
Communication RS485, half duplex isolated
Baud Rate：9600, 19200(default), 38400
Protocol：Modbus
LonTalks：(option)
kWh Accuracy 0.5%(PF=1)，better than IEC62053-21
Size 78(L) × 35(W) × 99(H) mm
Operation Temp -10℃~60 ℃
Installation Rail-mounted

IA Networks Technology IPM3400 User Guide
6
Chapter3: Installation
3.1 Inspection
On receipt of the instrument and prior to installation, makes sure it has not been damaged
during shipment.
The instrument is no longer safe when,
a) shows clear signs of damage
b) does not work
c) long storage under extreme conditions
d) damage during shipment
3.2 Safety
Please use the soft dry clothes to clean the instrument.
Please do not use any chemical or detergent or volatile solvents to clean the instrument, in order to
avoid any possibility of the cover damage。
3.3 Size and Latch
Top View (mm)
Side View (mm)
Position of latch

IA Networks Technology IPM3400 User Guide
7
Dimension of this product is 99mm（length）× 32mm（wide）× 78mm（high）
Products come with external split type clip on CT’s. Use only the attached CT’s, and do not
disconnect CT’s from meter. and never direct connect the other CT’s from the secondary side。
Please read this operation manual carefully before using。
Please re-confirm the measure position。
IPM3400 can be installed as rail mounting mode or embedded, no need to drill a hole or screw to
fix it（rail mounting width can up to the length of 35 mm ）。
Meter auxiliary power for IPM3400 is DC 10V -30V。
3.4 Mounting and Dismounting
3.4.1 Mounting
Pull down the “latch” of meter, and mount the meter on to the rail and lock it, as shown in below picture.
Pull down
3.4.2 Dismounting
Wire Disconnection
1. Open the clicked CT first and remove CTS from lines，Do not disconnect CT from
terminals.
2. Disconnect the voltage input wires from terminals and wrap the wire tips with plastic
tape.
3. Disconnect the communication wires from terminal.
4. Disconnect the Aux power from terminal and wrap the wire tip with plastic tape.
Dismount
From the back to pull down the latch, then can release the meter

IA Networks Technology IPM3400 User Guide
8
Chapter 4 : Wiring Diagrams
Voltage Input
This instrument can measure voltage up to a maximum 300V. Higher than 300V, please
add the PT in front to protect the instrument.
Confirm the voltage.
Current Input
The external CT’s are friable, please handle with care.
The current input for this instrument is in mA range. Only the attached CT’s can be
used. The normal CT’s from panel will damage the instrument due to its large current
(around 5A)
When more than one instrument will be installed, please do not disconnect the CT with
its instrument. Each instrument is calibrated with matching CT’s.
To install CT’s, confirm the lines with terminals and latch on the split CT with each cable.
(Detail will be found in next section)
CT bending area is quite frangible; please handle with extra care, especially when the
room between CT’s is limited.
The current direction must follow K-L marked on CT
Please select the right size CT for different size current cables.
The maximum current value can not exceed the CT rating.

IA Networks Technology IPM3400 User Guide
9
4.1 Connection diagram
IPM3400
Please first check the current input terminal, and follow the white black, white black, white black, white
black wired order（1S 1L 2S 2L 3S 3L 4S 4L）.After connection the CT’s, clip on CT’s. Make sure the
arrow sign on CT’s follow current flow direction（K→L）Note: it must in same direction。
Connect the voltage input terminal. For IPM3400, connect V2- V2+ and V1- V1+。
Then, Connect RS485 D+ D- ，LonTalks D+ D- (”－”, ”＋” sequence base on the top cover mark
showed)。And then, add the auxiliary power。DC10- 30V (+ - FG)
16Φ/100A 24Φ/200A

IA Networks Technology IPM3400 User Guide
10
1P4W(IPM3400)
Chapter 5 : Dip Switch ON /OFF
Dip Switch
Dip switch is used for Modbus address setting, default is 1 i.e. all OFF
For example : Modbus address is 10，find the table of dip switch 1-6 is on, off, off, on, off, off
SW1 -6 setting the Modbus address of communication, 1-64
Modbus Address 1 2 3 4 5 6
1 OFF OFF OFF OFF OFF OFF
2 ON OFF OFF OFF OFF OFF
3 OFF ON OFF OFF OFF OFF
4 ON ON OFF OFF OFF OFF
5 OFF OFF ON OFF OFF OFF
6 ON OFF ON OFF OFF OFF
7 OFF ON ON OFF OFF OFF
8 ON ON ON OFF OFF OFF
9 OFF OFF OFF ON OFF OFF
10 ON OFF OFF ON OFF OFF
11 OFF ON OFF ON OFF OFF
12 ON ON OFF ON OFF OFF
13 OFF OFF ON ON OFF OFF
14 ON OFF ON ON OFF OFF
15 OFF ON ON ON OFF OFF
16 ON ON ON ON OFF OFF
17 OFF OFF OFF OFF ON OFF
18 ON OFF OFF OFF ON OFF
19 OFF ON OFF OFF ON OFF
20 ON ON OFF OFF ON OFF
21 OFF OFF ON OFF ON OFF
1L 2S 2L 3S 4S 4L1S V2-
L1
L2
L1
L2
L1
L2
L1
L2
L1
L2
L1
L2
V1+V1-V2+
3L

IA Networks Technology IPM3400 User Guide
11
22 ON OFF ON OFF ON OFF
23 OFF ON ON OFF ON OFF
24 ON ON ON OFF ON OFF
25 OFF OFF OFF ON ON OFF
26 ON OFF OFF ON ON OFF
27 OFF ON OFF ON ON OFF
28 ON ON OFF ON ON OFF
29 OFF OFF ON ON ON OFF
30 ON OFF ON ON ON OFF
31 OFF ON ON ON ON OFF
32 ON ON ON ON ON OFF
33 OFF OFF OFF OFF OFF ON
34 ON OFF OFF OFF OFF ON
35 OFF ON OFF OFF OFF ON
36 ON ON OFF OFF OFF ON
37 OFF OFF ON OFF OFF ON
38 ON OFF ON OFF OFF ON
39 OFF ON ON OFF OFF ON
40 ON ON ON OFF OFF ON
41 OFF OFF OFF ON OFF ON
42 ON OFF OFF ON OFF ON
43 OFF ON OFF ON OFF ON
44 ON ON OFF ON OFF ON
45 OFF OFF ON ON OFF ON
46 ON OFF ON ON OFF ON
47 OFF ON ON ON OFF ON
48 ON ON ON ON OFF ON
49 OFF OFF OFF OFF ON ON
50 ON OFF OFF OFF ON ON
51 OFF ON OFF OFF ON ON
52 ON ON OFF OFF ON ON
53 OFF OFF ON OFF ON ON
54 ON OFF ON OFF ON ON
55 OFF ON ON OFF ON ON
56 ON ON ON OFF ON ON
57 OFF OFF OFF ON ON ON
58 ON OFF OFF ON ON ON
59 OFF ON OFF ON ON ON
60 ON ON OFF ON ON ON
61 OFFOFFONONONON
62 ONOFFONONONON
63 OFF ON ON ON ON ON
64 ON ON ON ON ON ON

IA Networks Technology IPM3400 User Guide
12
SW7-8 are used to select Wh pulse output (IPM3400) to the LED for each of four channels
IPM3400：Select Wh pulse output to LED
Wh pulse output 7 8
Wh1
(
ch1
)
OFF OFF
Wh2
(
ch2
)
ON OFF
Wh3
(
ch3
)
OFF ON
Wh4
(
ch4
)
ON ON

IA Networks Technology IPM3400 User Guide
13
Chapter 6 communication Formats
6.1 Specifications
Communication protocol :Modbus
Transport specification
Bits per Byte：1 start bit
8 data bits, least significant bit sent first
1 or 2 stop bits（default = 1, stop）
Error Check：Cyclical Redundancy Check（CRC）
Baud Rate：9600, 19200（default）, 38400
Modbus slave address：1-64(default：1)
Modbus Function Code：03h, 04h, 10h
Code MODBUS_ name Description
03h Read Holding Registers Read the contents of read/write location
04h Read Input Registers Read the contents of read only location
10h Pre-set Multiple Registers Set the contents of read/write location
Note: the max. data reading of Function 03 and Function04 is 125 registers
Format of data
Integer：16bitswithsign
Unsigned Integer：16 bits without sign
Float：IEEE 754 Format ，each with 2 registers, Low Word is first priority while transmit
IEEE 754 Format
Definition of the floating format of the Bits
Data Hi Word，
Hi Byte
Data Hi Word，
Lo Byte
Data Lo Word，
Hi Byte
Data Lo Word，
Lo Byte
SEEE EEEE EMMM MMMM MMMM MMMM MMMM MMMM
Value = (-1)S2E - 127(1.M) 0 < E < 255
Where:
Srepresents the sign bit where 1 is negative and 0 is positive
Eis the two’s complement exponent with an offset of 127. i.e. an exponent of zero is represented by
127, an exponent of 1 by 128 etc.
Mis the 23-bit normal mantissa. The highest bit is always 1 and, therefore, is not stored.
transport sequence
1 2 3 4
Data Lo Word，Hi Byte Data Lo Word，Lo Byte Data Hi Word，Hi Byte Data Hi Word，Lo Byte

IA Networks Technology IPM3400 User Guide
14
6.2 Modbus Register
Modbus Module #1 Holding Register : Setup Parameter
Parameter name Modbus Register Len Data
Type Range Default value Units Comment
Modicom
Format Hex
Comm_485_BaudRate 44097 0x1000 Word UInt 0: 9600 1: 19200
2: 38400 1 bps
Comm_485_StopBit 44098 0x1001 Word UInt
0:1 Stop bit,
1:2 Stop bit 0
Meter_Ratio 44099 0x1002 Word UInt 1-65535 500
PT_Ratio 44100 0x1003 Word UInt 1-65535
100 0.01 0.01-655.35
(V1.26)
10 0.1 0.1-6553.5
(V1.00~V1.25)
CT_Ratio 44101 0x1004 Word UInt 1-65535 1
Modbus Module #2 Input Register : Voltage, Current, Power, Energy(Float) for
IPM3400
Parameter name Modbus Register Len Data
Type Range Units Comment
Modicom
Format Hex
V_a 34353-
34354 0x1100- 0x1101 DWord
Float Volt Primary
I_a 34355-
34356 0x1102- 0x1103 DWord
Float Amp Primary
kW_a 34357-
34358 0x1104- 0x1105 DWord
Float kW Primary
kvar_a 34359-
34360 0x1106- 0x1107 DWord
Float kvar Primary
kVA_a 34361-
34362 0x1108- 0x1109 DWord
Float kVA Primary
PF_a 34363-
34364 0x110A- 0x110B DWord
Float Primary
kWh_a 34365-
34366 0x110C- 0x110D DWord
Float Primary
kvarh_a 34367-
34368 0x110E- 0x110F DWord
Float Primary
kVAh_a 34369-
34370 0x1110- 0x1111 DWord
Float Primary
V_b 34371-
34372 0x1112- 0x1113 DWord
Float Volt Primary
I_b 34373-
34374 0x1114- 0x1115 DWord
Float Amp Primary
kW_b 34375-
34376 0x1116- 0x1117 DWord
Float kW Primary
kvar_b 34377-
34378 0x1118- 0x1119 DWord
Float kvar
kVA_b 34379-
34380 0x111A- 0x111B DWord
Float kVA Primary
PF_b 34381-
34382 0x111C- 0x111D DWord
Float Primary
kWh_b 34383-
34384 0x111E- 0x111F DWord
Float Primary
kvarh_b 34385-
34386 0x1120- 0x1121 DWord
Float Primary
kVAh_b 34387-
34388 0x1122- 0x1123 DWord
Float Primary
V_c 34389-
34390 0x1124- 0x1125 Dword Float
Volt Primary
I_c 34391-
34392 0x1126- 0x1127 Dword Float
Amp Primary
kW_c 34393-
34394 0x1128- 0x1129 Dword Float
kW Primary
kvar_c 34395- 0x112A- Dword Float kvar Primary

IA Networks Technology IPM3400 User Guide
15
34396 0x112B
kVA_c 34397-
34398 0x112C- 0x112D Dword Float
kVA Primary
PF_c 34399-
34400 0x112E- 0x112F Dword Float
Primary
kWh_c 34401-
34402 0x1130- 0x1131 Dword Float
Primary
kvarh_c 34403-
34404 0x1132- 0x1133 Dword Float
kVAh_c 34405-
34406 0x1134- 0x1135
V_avg(V_d) 34407-
34408 0x1136- 0x1137 Dword Float
Volt Primary
I_avg(I_d) 34409-
34410 0x1138- 0x1139 Dword Float
Amp Primary
kW_tot(kW_d) 34411-
34412 0x113A- 0x113B Dword Float
kW Primary
kvar_tot(kvar_d) 34413-
34414 0x113C- 0x113D Dword Float
kvar Primary
kVA_tot(kVA_d) 34415-
34416 0x113E- 0x113F Dword Float
kVA Primary
PF_tot(PF_d) 34417-
34418 0x1140- 0x1141 Dword Float
Primary
kWh_tot(kWh_d) 34419-
34420 0x1142- 0x1143 Dword Float
Primary
kvarh_tot(kvarh_d) 34421-
34422 0x1144- 0x1145 Dword Float
kVAh_tot(kVAh_d) 34423-
34424 0x1146- 0x1147 Dword Float
Frequency 34425-
34426 0x1148- 0x1149 Dword Float Hz After V1.29-3
Modbus Module #4 Input Register : Voltage, Current, Power, Energy(Int) for
IPM3400
Parameter name Modbus Register Len Data
Type Range Units Comment
Modicom
Format Hex
V_a 34609-
34610 0x1200- 0x1201 DWord UInt32 0.1 Volt Primary
I_a 34611-
34612 0x1202- 0x1203 DWord UInt32 0.1A Primary
kW_a 34613-
34614 0x1204- 0x1205 DWord Int32 0.1kW Primary
kvar_a 34615-
34616 0x1206- 0x1207 DWord Int32 0.1kvar Primary
kVA_a 34617-
34618 0x1208- 0x1209 DWord Int32 0.1kVA Primary
PF_a 34619 0x120A Word Int -1000~+1000 0.001PF -1.000~1.000
kWh_a 34620-
34621 0x120B- 0x120C DWord Int32 0~99999999 0.1kWh 0~9999999.9
kvarh_a 34622-
34623 0x120D- 0x120E DWord Int32 0~99999999
0.1kvarh 0~9999999.9
kVAh_a 34624-
34625 0x120F- 0x1210 DWord Int32 0~99999999 0.1kVAh 0~9999999.9
V_b 34626-
34627 0x1211- 0x1212 DWord UInt32 0.1 Volt Primary
I_b 34628-
34629 0x1213- 0x1214 DWord UInt32 0.1A Primary
kW_b 34630-
34631 0x1215- 0x1216 DWord Int32 0.1kW Primary
kvar_b 34632-
34633 0x1217- 0x1218 DWord Int32 0.1kvar Primary
kVA_b 34634-
34635 0x1219- 0x121A DWord Int32 0.1kVA Primary
PF_b 34636 0x121B Word Int -1000~+1000 0.001PF -1.000~1.000
kWh_b 34637-
34638 0x121C- 0x121D DWord Int32 0~99999999 0.1kWh 0~9999999.9
kvarh_b 34639- 0x121E- DWord Int32 0~99999999
0.1kvarh 0~9999999.9

IA Networks Technology IPM3400 User Guide
16
34640 0x121F
kVAh_b 34641-
34642 0x1220- 0x1221 DWord Int32 0~99999999 0.1kVAh 0~9999999.9
V_c 34643-
34644 0x1222- 0x1223 DWord UInt32 0.1 Volt Primary
I_c 34645-
34646 0x1224- 0x1225 DWord UInt32 0.1A Primary
kW_c 34647-
34648 0x1226- 0x1227 DWord Int32 0.1kW Primary
kvar_c 34649-
34650 0x1228- 0x1229 DWord Int32 0.1kvar Primary
kVA_c 34651-
34652 0x122A- 0x122B DWord Int32 0.1kVA Primary
PF_c 34653 0x122C Word Int -1000~+1000 0.001PF -1.000~1.000
kWh_c 34654-
34655 0x122D- 0x122E DWord Int32 0~99999999 0.1kWh 0~9999999.9
kvarh_c 34656-
34657 0x122F- 0x1230 DWord Int32 0~99999999
0.1kvarh 0~9999999.9
kVAh_c 34658-
34659 0x1231- 0x1232 DWord Int32 0~99999999 0.1kVAh 0~9999999.9
V_avg(V_d) 34660-
34661 0x1233- 0x1234 DWord UInt32 0.1 Volt Primary
I_avg(I_d) 34662-
34663 0x1235- 0x1236 DWord UInt32 0.1A Primary
kW_tot(kW_d) 34664-
34665 0x1237- 0x1238 DWord Int32 0.1kW Primary
kvar_tot(kvar_d) 34666-
34667 0x1239- 0x123A DWord Int32 0.1kvar Primary
kVA_tot(kVA_d) 34668-
34669 0x123B- 0x123C DWord Int32 0.1kVA Primary
PF_tot(PF_d) 34670 0x123D Word Int -1000~+1000 0.001PF -1.000~1.000
kWh_tot(kWh_d) 34671-
34672 0x123E- 0x123F DWord Int32 0~99999999 0.1kWh 0~9999999.9
kvarh_tot(kvarh_d) 34673-
34674 0x1240- 0x1241 DWord Int32 0~99999999
0.1kvarh 0~9999999.9
kVAh_tot(kVAh_d) 34675-
34676 0x1242- 0x1243 DWord Int32 0~99999999 0.1kVAh 0~9999999.9
Frequency 34677 0x1244 Word UInt16 0~9999
0.01Hz 0.00~99.99
After V1.29-3
Appendix：Question and Answer
Q1. if the turn point of the split type clip on CT break, or inner iron -core break, how to settle
this condition?
（1）the measure data will be not accuracy as before, and can not use again。
（2）please do not use the tape to fix it and then re-use again。
Q2. if multiple set of meter are being installed，the split type clip on CT and set of meter are able
to take it apart and to mix use？
Please do not mix use，because the set of ct and meter from IA Networks, are all calibrate well and
Gain after QC。

IA Networks Technology IPM3400 User Guide
17
Q3. the real power rate（kw）, if the value of measure is negative?
（1）first check the current input end – line terminal, （check the connect is it 1S、1L、2S、2L、3S、
3L、4S、4L），base on white black, white black, white black follow the sequence order。
（2）check the field current is same direction of（K→L）must follow the same direction on the split type
clip on CT inner arrow。
Q4. PC and meter can not make the communication？
（1）confirm the Modbus Address，default is 1。
（2）confirm the Band Rate，default is 9600。
（3）confirm the stop bit，default is 2。
（4）confirm the RS485 之connect line terminal ＋、－is it connect correct。
Q5. Regarding to the combine shipment of the meter with split type CT, what is the maximum
dimension？
（1）power line if ＜Φ10 use 60A CT，Φ10～Φ16 use 100A CT，Φ16～Φ24 use 200A CT。
Q6. Regarding to the split type small CT , if the wire is not longer enough ?
（1）Φ10split type CT，fix wire is 1.8M，if need extension, please use the same size wire, and
dimension to apply it，the connection part is need to use tinning and insulate tape to cover it the copper。
（2）Φ16and Φ24split type CT，the std. wire of length is 2M, if over 2M you can choice the suitable
one to add。
