IAG ICS6SE3 User manual

MODEL
ICS6SE3
600mm
Electric Cooktop with
Solid Elements
Manual
Installation and Operation

ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 2 -
Congratulationsonchoosingoneourappliances,wehopeyouhavemanyreliableyearsofusefrom
thisnewappliance.

Werecommendthatyoureadthismanualforbestperformanceandtoextendthelifeofyour
appliance.Youshouldkeepthismanualinasafeplaceandaccessibleplaceshouldfuturereferencebe
required.

Thankyou.


NOTE:ThisUserInstructionManualcontainsimportantinformation,includingsafety&
installationpoints,whichwillenableyoutogetthemostoutofyourappliance.Pleasekeepitina
safeplacesothatitiseasilyavailableforfuturereference;foryouoranypersonnotfamiliarwith
theoperationoftheappliance.


WARNINGS

Theapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
givensupervisedorinstructionconcerninguseoftheappliancebyaresponsiblepersonforthey
safety.

Youngchildrenshouldbesupervisedatalltimestoensurethattheydonotplaywiththe
appliance.

Duringuse,theappliancebecomeshot.Careshouldbetakentoavoidtouchingtheheating
elementsofthecooktop.Pleasekeepchildrenawayfromthecooktop.

Donotuseharshabrasivecleanersorsharpmetalscraperstocleanthecooktopasthiscould
causescratching.

Donotuseasteamcleanertocleantheoven.

Pansshouldbeliftedonandoffthehobsurfaceandnotdragged.

Cookingzonesshouldnotbeswitchedonwithoutcookwareplacedonit.Alsothecookware
shouldnotbeempty.



ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 3 -
CONTENTS

Importantsafetyinformation4
Specifications           5
Productandcutoutdimensions 5
Productspecifications 5
Standardaccessories5
Electricaldetails        5
Hobsurfacelayout        6
Usingthehob  6
Beforefirstuse6
Controlknobs6
Turningonazoneandsettingapowerlevel7
Hobguidelines7
Cleaningandmaintenance7
Cleaningthehobtop7
Aftereachuse 8
Maintainingthesolidplates8
Installation8
Positioning8‐9
Unpackingtheappliance9
Installingtheappliance 9
Heatshieldrequirement9
Sealingtape10
Affixingcooktoptobenchtop10
Electricalconnection 11
Connectingthemainssupplycable 11
Replacingthemainssupplycable 11
Myapplianceisn’tworkingcorrectly12
















ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 4 -
IMPORTANTSAFETYINFORMATION

Yoursafetyisoftheutmostimportance.Pleasemakesurethatyoureadthisinstructionbooklet
beforeattemptingtoinstallorusetheappliance.Ifyouareunsureofanyoftheinformation
containedinthisbooklet,pleasecontacttheTechnicalserviceDepartment.

GeneralInformation
Thisapplianceisdesignedfordomestichouseholduseandforthecookingandfryingofdomesticfoodstuffs..
IMPORTANT:Theadjacentfurnitureandallmaterialsusedintheinstallationmustbeabletowithstanda
minimumtemperatureof85°Cabovetheambienttemperatureoftheroomitislocatedin,whilstinuse.
Certaintypesofvinylorlaminatekitchenfurnitureareparticularlypronetoheatdamageordiscolourationat
temperaturesbelowtheguidelinesgivenabove.
Duringnormalusesomediscolourationmayoccurfromexcessiveheatedgeneratedbythesolidhotplates,
Anydamagecausedbytheappliancebeinginstalledincontraventionofthistemperaturelimit,willbethe
liabilityoftheowner.
Yournewapplianceisguaranteedagainstelectricalormechanicaldefects.Theforegoingdoesnotaffectyour
statutoryrights.
Theuseofthisapplianceforanyotherpurposeorinanyotherenvironmentwithouttheexpressagreementwill
invalidateanywarrantyorliabilityclaim.
Youshouldnotusethisappliancetostoreitemsonorasaworksurface.
Nomodificationstotheappliancearepermitted.
Youshouldnotstoreorplaceflammableorhighlyflammableliquids/materialsontopoforneartheappliance.
Itemsmadefromaluminium,plasticorplasticfilmshouldalsobekeptawayfromtheappliance,astheymayfuse
tothesurface.
Repairsmayonlybecarriedoutbyauthorisedserviceagent.

Child/InfirmPersonsSafety
Babiesandyoungchildrenarepreventedfrombeingneartotheapplianceandnotallowedtotouchthe
applianceatanytime.Duringandafteruse,allsurfaceswillbecomehot.
Ifitisnecessaryforyoungerfamilymemberstobeinthekitchen,pleaseensurethattheyarekeptunderclose
supervisionatalltimes.
OlderchildrenandInfirmpersonsshouldonlybeallowedtoutilisetheappliancewhenfullysupervised.

GeneralSafety
Theapplianceshouldonlybeinstalledandconnectedbyasuitablequalifiedperson.
Careshouldbetakentoensurethattheunitsandworksurfacesthatyoubuildtheapplianceinto,meetwiththe
relevantstandards.

Duringuse
Anyfilmorstickersthatarepresentonthehobsurfacewhenitisdeliveredshouldberemovedbeforeuse.
Careshouldbeusedwhenutilizingtheappliance,otherwisethereisariskofburnsbeingcaused.
Youshouldnotallowtheelectricalconnectioncablestocomeintocontactwiththehobsurfacewhenitishotor
anyhotcookware.
Iffatandoiloverheats,thenitcanigniteextremelyquickly.Forthisreason,whencookingwithfatandoilthe
applianceshouldnotbeleftunattended.
Makesurethatallofthecookingzonesareswitchedoffafteruse.

Cleaning
Cleaningofthehobshouldbecarriedoutonaregularbasis.Thesolidplatesshouldalsobemaintainedona
regularbasis.
IMPORTANT:Beforeattemptingtocleantheapplianceormaintaintheplates,itshouldbedisconnectedfromthe
mainsandcool.
Greatcareshouldbetakenwhilstusingthisapplianceandwhenfollowingthecleaningprocedure.
Youshouldnotuseasteamjetoranyotherhighpressurecleaningequipmenttocleantheappliance.

ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 5 -
INSTALLATION

Thisappliancemustbecorrectlyinstalledbyasuitablyqualifiedperson,strictlyin
accordancewiththemanufacturer’sinstructions.Pleaseseethespecificsectionof
thisbookletthatreferstoinstallation.

SPECIFICATIONS


Productdimensions: Cutoutdimensions:
Width:580mm Width:555mm
Breadth:500mm Breadth:473mm
Depth:45mm

Productspecifications:
2x2.0kWthermostaticelements(diameter180mm)
2x1.5kWthermostaticelements(diameter145mm)
Sidecontroloperation

Electricaldetails
RatedVoltage:220‐240V–50/60Hz
SupplyConnection:30Amp(doublepoleswitchedfusedoutletwith3mmcontactgap)
MaxRatedInputs:7.00kW
MainsSupplyLead:3corex2.5mm²(notsupplied)

Forfuturereferencepleaserecordthefollowinginformationwhichcanbefoundontherating
plateandthedateofpurchasewhichcanbefoundonyoursalesinvoice.Theratingplateofyour
hobislocatedontheunderneathoftheappliance.Thereforeitisagoodideatorecordthis
informationbeforeyouinstallyourappliance.

ModelNumber……………………………….
SerialNumber……………………………….
DateofPurchase……………………………….






ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 6 -
Hobsurfacelayout













Usingthehob

Beforefirstuse

IMPORTANT:Youshouldcleanthehobsurfaceandsolidelementplates(see“Cleaning
andmaintenance”section).


Youshouldswitchononecookingelementatatime,for5minutesatthemaximumsetting.
Thiswillhelptoeliminateanynewsmellthatexistsandevaporateanyhumiditythathas
formedontheheatingelementsduringtransit.
Whendoingthisburnoffprocess,anappropriatelysizedsaucepancontainingcoldwater
shouldbeplacedonthezoneinquestion.
Donotburnoffmorethanoneelementatonce.

Controlknobs
Alloperationsareperformedbymeansofthe4controlknobsthatcanbefoundontheright
handsideofthehobtop.
Thecontrolknobscanbeturnedeitherclockwiseoranti‐clockwisetoselectaheatinglevel.
Thenumbersaroundtheoutsideofeachcontrolknobindicatesthepowerlevelthatyouhave
setthezoneto.
Amarkingtothebottomrightofeachcontrolknob,indicateswhichzonethatitcontrols.








1500 watt
thermostatic
element
2000 watt
thermostatic
element
2000 watt
thermostatic
element
Control knobs
1500 watt
thermostatic
element
On / Off
indicato
r

ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 7 -
Turningonanelementandsettingapowerlevel



Turnthecontrolknobofthezonethatyouwishtocookon,clockwiseoranticlockwiseuntilit
reachesthepowerlevelthatyoudesire.
Eachcookingzonecanbeadjustedbetween1and6,onebeingthecoolestzonesettingand
sixbeingthehottestzonesetting.
Whenyouhavefinishedcooking,makesurethatyouturnthecontrolknobanti‐clockwise,to
the0position.

Hobguidelines
Thefirstfewtimesthehobtopisused,itmaygiveoffanacrid,burningsmell.Thissmellwill
disappearcompletelywithrepeateduse.
Thehobsurfaceisfittedwithcookingareasofdifferentdiameterandpower.
Youshouldnotusesaucepanswithroughbottoms,asthiscanscratchthesolidplates.
Beforeuse,makesurethatthebottomsofthesaucepansarecleananddry.
Whencold,thebottomofthepansshouldbeslightlyconcave,astheyexpandwhenhotand
lieflatonthesurfaceofthehob.Thiswillallowtheheattotransfermoreeasily.
Thebestthicknessforthebottomofthepansis2–3mmofenameledsteeland4–6mmfor
stainlesssteelwithsandwichtypebottoms.
Iftheserulesarenotfollowed,thentherewillbeagreatlossofheatandenergy.Heatnot
absorbedbythesaucepan,willspreadtothehob,frameandsurroundingcabinets.
Preferablycoverpanswithalidtopermitcookingatalowerheatsetting.
Alwayscookvegetablesandpotatoes,etc.inaslittlewatertoreducecookingtimes.

CLEANING&MAINTENANCE
Cleaningandmaintenanceoperationsmustonlybecarriedoutwhenthecooktops
iscool.
Theapplianceshouldbedisconnectedfromyourmainssupplybeforecommencing
anycleaningprocess.


Cleaningthehobtop
Anyresiduesthatareleftonthehobtopsurfacefromcleaningagentsshouldberemoved
thoroughly.Youshouldremoveanyresidueswithwaterandalittlewashingupliquid.

Abrasivecleanersorsharpobjectscandamagethehobsurface;youshouldcleanit
usingwaterandalittlewashingupliquid.

Althoughitiseasiertocleansomedepositswhilstthehobsurfaceisstillwarm,youshould
takecarenottoburnyourselfifcleaningthehobsurfacewhenitisstillwarm.

ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 8 -
Aftereachuse
Wipetheapplianceoverwithadampclothandalittlewashingupliquid.
Drytheappliancebyrubbingthesurfacewithacleancloth.
Ifthehobtopisheavilysoiledthenifthehobsurfaceismadefromstainlesssteel,thenasuitable
stainlesssteelcleanershouldbeused.
IMPORTANT:Ifastainlesssteelcleanerisnotusedregularly,thenitispossibleforthesurfaceof
thehobtochangecolouroveraperiodoftime.
Forotherhobsurfaces,acleanersuchas“HobBrite”or“BarKeepersFriend”maybeappropriate.

Maintainingthesolidplates
Ifsomethingisspiltontotheplateitself,thenitcanberemovedusingasoftbrush,plasticor
nylonscourerandwarmwater.
Tokeepthesolidplatesingoodcondition,youshouldputalittleoliveoilontoakitchentoweland
rubitontothesurfaceoftheplate.Thenexttimetheplateisused,thenitmayproducealittle
smoke.
Alternativelyyoucanuseahotplateconditioner;theseproductscannormallybefoundatlarger
supermarketsandhardwarestores.Themanufacturer’sinstructionsshouldbefollowedwhen
usingtheseproducts.
IMPORTANT:Ifthesolidplatesarenotmaintainedregularlywitholiveoilorahotplate
conditioner,thentheymayrust.

INSTALLATION

Positioning
Theadjacentfurnituremustbeabletowithstandaminimumtemperatureriseof
85°Cabovetheambienttemperatureoftheroomitislocatedin,duringperiodsof
use.


600’mm
400mm
700mm
55mm
50mm
180mm
Without a cooker hood With acooker hood
600’mm
400mm
700mm
55mm
50mm
180mm
Cooker
hood



ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 9 -
Positioning(continued)
ThisapplianceisclassifiedasClass3andthereforeistobebuiltintoakitchenunit(dependingonsize)
or600mmworktop,providingthefollowingminimumdistancesareallowed:
700mmbetweenthehobsurfaceandtheundersideofanyhorizontalsurfaceaboveit.
650mmdistancebetweencooktopandbaseofRangehoodfiltersshouldbepresent..
50mmclearancearoundtheapplianceandbetweenthehobsurfaceandanycombustible
materials.

Unpackingtheappliance
Whenunpackingtheappliancepleasecheckthatthefollowingitemsarecontainedwithinthe
packaging:
1Electriccooktop
1Installationandinstructionmanual
4Fixingscrews
4Clamps
1Sealingstrip

Installingtheappliance
Cutaholeintheworktopthatcorrespondswiththedrawingshownbelow.



Heatshieldrequirement
IMPORTANT:Wheninstallingthecooktopaboveadrawerorcupboardwithaccessfromthe
undersideaheatshieldmustbefittedaminimum25mmbelowthebaseofthecooktopas
illustratedbelowtopreventinjuryfromheatgeneratedfromthecooktop.Wheninstalledabove
anoventhisheatshieldisnotrequired.




ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 10 -
Sealingtape
Carefullyturnthehobupsidedownandplaceitonacushionedmat.Applythesealingstrip
providedaroundtheedgeoftheappliance(seebelowpicture).Theprotectivecoveringmustbe
removedfrombothsides.Donotleaveagapinthesealingagentoroverlapthethickness.
IMPORTANT:Donotuseasiliconsealanttosealtheapplianceagainstthebenchtop.Thiswill
makeitdifficulttoremovethehobfromthebenchtopinfuture,particularlyifitneedstobe
serviced.



Affixingcooktoptobenchtop
Placetheclamp(B)overtheholesthatmatchthesizeofthescrews.Thereareonesetofscrew
holesineachcornerofthehob.Slightlytightenascrew(C)throughtheclamp(B)sothatthe
clampisattachedtothehob,butsothatyoucanstilladjustthepositionofit.
Carefullyturnthehobbackoverandthengentlyloweritintotheapertureholethatyouhavecut
out.
Ontheunderneathofthehob,adjusttheclampsintoapositionthatissuitableforyourworktop.
Thenfullytightenthescrews(C)tosecurethehobintoposition.



























ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 11 -
Electricalconnection

Thisappliancemustbeinstalledbyaqualifiedperson.

Beforeconnectingtheappliance,makesurethatthesupplyvoltagemarkedonthe
ratingplatecorrespondswithyourmainssupplyvoltage.

WARNING:THISAPPLIANCEMUSTBEEARTHED.
Thisappliancemustbewiredintoa30Adoublepoleswitchedfusedspuroutlet,having3mm
contactseparationandplacedinaneasilyaccessiblepositionadjacenttotheappliance.Itshould
notbelocatedabovetheapplianceandnomorethan1.25mawayfromit.
Thespuroutletmuststillbeaccessibleevenwhenyourovenislocatedinitsoperatingposition.
Cabletype:H05RRF3corex2.5mm²

Connectingthemainssupplycable
Themainsterminalblockislocatedontheundersideofthehobandtheterminalsareaccessible
byremovingtheterminalblockcoverbyremovingthecoverscrew.
Thecableconnectionsmustbeinaccordancewiththediagramlocatedonthebottomofthehob.



ThebrasslinksmustbepositionedasmarkedintheappropriatediagramandonceestablishedALL
terminalscrewsmustbetighteneddownfirmly.
Ifwhenthehobisfirstswitchedon,onlytwoofthezoneswork,youshouldrecheckthatthe
terminalscrewsareallfullytightenedbetweenthelinks.
IMPORTANT:TheappliancemustNOTbeconnectedtothemainssupplybymeansofa13Aplug
andsocket.
Thecablecanbeloopedifnecessary,butmakesurethatisnotkinkedortrappedwhenthehobis
inposition.Caremustbetakentoavoidthecablebeingincontactwithhotpartsoftheappliance.

Replacingthemainssupplycable
Ifthemainssupplycableisdamaged,thenitmustbereplacedbyanappropriatereplacementwhich
canbeobtainedfromtheSeller.Themainssupplycableshouldbereplacedinaccordancewiththe
followinginstructions:
Switchtheapplianceoffatthecontrolswitch.
Opentheterminalblockontheundersideofthehob.
Unscrewtheterminalscrewsfixingthecable.
Replacethecablewithoneofthesamelengthandinaccordancewiththespecificationgiven
above.
The“green‐yellow”earthwiremustbeconnectedtotheterminalmarked.Itmustbeabout10
mmlongerthantheliveandneutralwires.
The“blue”neutralwiremustbeconnectedtotheterminalmarkedwithletter(N)‐thelivewire
mustbeconnectedtotheterminalmarkedwithletter(L).

ACS6SE2 and ICS6SE3 60cm Cooktop Installation and Operation Manual
- 12 -
MYAPPLIANCEISNOTWORKINGPROPERLY
Thecookingzonesarenotfunctioningorwillnotswitchon.
★ Checkthatthemainselectricalsupplytotheapplianceiscorrectandworking.Checkthemains
fuse.
Ahummingsoundisheardwhenacookingzoneisselected.
★ Thisisnormal;thesoundwilldisappearwhenthezoneheatsup.
Thecookingzoneshavebecomediscoloured
★ Thismaybecausedbyburntonremnantsoffood.Thiswillnotaffecttheworkingoftheappliance.
Howeveryoushouldmakesurethatthecleaninginstructionsarebeingfollowedregularly.
Onlytwoofthezonesonmyhobareworking
★ Youshouldrecheckthattheterminalscrewsareallfullytightenedbetweenthelinks.



IMPORTANT:Ifyourapplianceappearsnottobeoperatingcorrectly,thenyou
shoulddisconnectitfromyourmainssupplyandthencontacttheService
Department.
DONOTATTEMPTTOREPAIRTHEAPPLIANCEYOURSELF.


Pleasenotethatifanengineerisaskedtoattendwhilsttheproductisunderguaranteeandfinds
thattheproblemisnottheresultofanappliancefault,thenyoumaybeliableforthecostofthe
calloutcharge.
Theappliancemustbeaccessiblefortheengineertoperformanynecessaryrepair.Ifyour
applianceisinstalledinsuchawaythatanengineerisconcernedthatdamagewillbecausedto
theapplianceoryourkitchen,thenhewillnotcompletearepair.
Thisincludessituationswhereapplianceshavebeentiledin,sealedinwithsealant,have
woodenobstructionsplacedinfrontoftheappliance,likeplinths.
















