iBabyGuard™

Infant Snooze Baby Sleep Monitor

User Manual

IMPORTANT INFORMATION –PLEASE READ FIRST BEFORE USE

The iBabyGuard™ Infant Snooze consists of a wireless Breath Movement monitoring mat (model IBG iSnooze 5M)

which works with an Android-powered Smartphone Apps for remote control.

The Android OS Version had to be minimum version 2.1 in order to be used with the iBabyGuard™ Infant Snooze

Apps.

All the music file formats supported by Android OS are supported by the music stream function of the

iBabyGuard™ Infant Snooze Apps. Some phone models may not support all the music files formats listed.

MP3

MIDI

PCM/WAVE

AAC LC/LTP

HE-AACv1 (AAC+)

AMR-NB

AMR-WB

FLAC

Vorbis

The remote receiver, model IBG iSnooze 5C (Parent Unit ) is included in the product. It can be used in place of the

smartphone Apps.

Only either the iBabyGuard™ Infant Snooze smartphone Apps or the Parent Unit can be used for communication

with the Infant Snooze at any one time, but NOT both can be used simultaneously.

Baby weight limit on the Infant Snooze for effective monitoring should fall within the range below:

Avoid placing any cloth material between the baby and the Infant Snooze. When cloth material is placed on the

mat, thickness of the material should be less than 3mm. Recommended materials are cotton bed sheet, cotton

bath towel or swaddling cloth. Other unknown materials may compromise the sensitivity.

2kg / 4.4lb –10kg / 22lb

Warning and disclaimer

The iBabyGuard™ Infant Snooze is NOT a medical device or a diagnostic device to prevent Sudden Infant

Death Syndrome (SIDS) or ‘cot death’. Babies with a known predisposition to any breathing abnormality

including apnea, obstructive sleep apnea should be monitored by a doctor. Please seek advice from

doctors or health care professional for medical diagnosis or when unsure of any symptoms.

iBabyGuard™ Infant Snooze is NOT a substitute for proper adult supervision. It is important that an adult

stays within range of the monitor at all times during use.

This Infant Snooze is constructed with highly sensitive fiber optics technology. To ensure accuracy and durability,

please observe the following care and maintenance instructions.

Care and maintenance of the mat

NO JUMPING/STAMPING

NO SHARP HITS

NO HEAVY WEIGHT BEYOND LIMIT

NO BENDING

NO HOLDING OF THE

EDGE IN ONE HAND

NO IMMERSING IN WATER

It is advisable to use the Infant Snooze for sleeping purpose and should not be used as a play mat.

Avoid major movement activity around the Infant Snooze as it is highly sensitive and may pick up the

movement signal as part of the movement signal of the baby. Patting action, high vibration or motor-

running activities will affect the accuracy of the breath movement count.

DO NOT add thick and heavy items such as mattress between your baby and the Infant Snooze.

Any form of spillage or stain should be wiped off immediately with water on a damp cloth to prevent

permanent stain on the Infant Snooze. Avoid using strong detergent. Gentle wipe is sufficient to clean up

stains. Excessive scrubbing action may damage the water-resistance property of the Infant Snooze.

Observe polarity of the battery placement for proper functioning of the Infant Snooze.

DO NOT disassemble, crush, short-circuit or incinerate the battery as it may cause fire, injury, burns or

other hazards.

DO NOT put the Parent Unit near wireless devices or a microwave oven. Such devices can disrupt the

transmission of the alarm signal.

The operating temperature range for the iBabyGuard™ Infant Snooze is from 100C - 400C. DO NOT

operate beyond this range as it may not function according to defined specifications.

Disposal instructions

Do not dispose of the iBabyGuard™ Infant Snooze or Parent Unit with unsorted waste. Improper disposal may be

harmful to the environment and human health. Please refer to your local waste authority for information on return

and collection systems in your area.

iBabyGuard™ Infant Snooze Smartphone Apps Status Indication Summary Sheet

Status indication

Event

Remarks

Calibration in progress

The display will indicate an hour glass

rotating in a circular motion

Sleeping

The display will be as shown when baby

is sleeping soundly.

Movement / Wake up alert

The display will be as shown whenever

the baby moves. After the baby falls

asleep, wake up alert is activated after

a baby’s sounds or cries with

continuous movement is detected from

the Infant Snooze

Absence from Infant Snooze

alert

The display will be as shown and alarm

will be activated whenever the baby is

out of the Infant Snooze

No breath movement

detected

The display will be as shown and alarm

will be activated when no breath

movement is detected

Error 1: Fiber sensor is broken

Please contact your service centre

Error 8: High pressure

exerted / Weight limit

exceeded

High pressure, such as heavy weight on

the mat or the baby sitting up. The

alarm will also be activated.

Error 9: Device

Malfunction

means any other number

than 1 and 8

Please contact your service centre

Parent Unit Status Indication Summary Sheet

Status indication

Event

Remarks

Calibration in progress

The display will indicate an hour glass

rotating in a circular motion

Sleeping

The display will be as shown when baby

is sleeping soundly.

Movement / Wake up alert

The display will be shown whenever the

baby moves. After the baby falls asleep,

wake up alert is activated after a baby’s

sounds or cries with continuous

movement is detected from the mat

Absence from Infant Snooze

alert

The display will be as shown and alarm

will be activated whenever the baby is

out of the Infant Snooze

No breath movement

detected

The display will be as shown and alarm

will be activated when no breath

movement is detected

Error 1: Fiber sensor is broken

Please contact your service centre

Error 8: High pressure exerted

/ Weight limit exceeded

High pressure, such as heavy weight on

the Infant Snooze or the baby sitting

up. The alarm will also be activated.

Error 9: Device

Malfunction

means any other number

than 1 and 8

Please contact your service centre

Table of Contents

1. GETTING STARTED................................................................................................................................. 1

1.1 Parts description for the Infant Snooze(Model IBG iSnooze 5M)................................................. 2

1.2 Parts description for the Parent Unit (Model IBG iSnooze 5C)..................................................... 3

1.3 Setting up the Infant Snooze with the Smartphone Apps ............................................................ 5

1.4 Settings on the Smartphone Apps ................................................................................................ 7

2. KEY FEATURES OF SMARTPHONE APPS .............................................................................................. 12

2.1 Baby activity monitor.................................................................................................................. 12

2.2 Ambient temperature display..................................................................................................... 12

2.3 Streaming of music / lullaby ....................................................................................................... 13

2.4 Baby sleep log ............................................................................................................................. 14

2.5 Breath Scope ...............................................................................................................................14

3. BABY ACTIVITY STATUS INDICATION ON SMARTPHONE .................................................................... 15

3.1 Sleeping....................................................................................................................................... 15

3.2 Baby movement..........................................................................................................................15

3.3 Baby absence ..............................................................................................................................16

4. ALARM CONDITIONS FOR THE SMARTPHONE APPS...........................................................................16

4.1 Clearing of alarms ....................................................................................................................... 16

4.2 No breath movement.................................................................................................................. 17

4.3 Wake up alert.............................................................................................................................. 17

4.4 Baby absence alert......................................................................................................................18

5. OTHER STATUS INDICATIONS ON THE SMARTPHONE APPS...............................................................19

5.1 Out of range / Link loss ...............................................................................................................19

5.2 Manual pairing of Infant Snooze and Smartphone..................................................................... 19

5.3 Low battery alert for Infant Snooze............................................................................................20

5.4 Error 1: Fiber sensor is broken.................................................................................................... 20

5.5 Error 8: Weight limit indication for the Infant Snooze ...............................................................21

5.6 Error 9: Device malfunction ........................................................................................................ 21

6. EXCEPTIONS MANAGEMENT FOR SMARTPHONE...............................................................................22

7. SETTING UP THE INFANT SNOOZE WITH PARENT UNIT...................................................................... 23

7.1 Powering up the Parent Unit ......................................................................................................23

7.2 Setting up the Parent Unit ..........................................................................................................24

8. KEY FEATURES OF PARENT UNIT.........................................................................................................26

8.1 Audio Monitor.............................................................................................................................26

8.2 Speaking to your baby.................................................................................................................26

9. BABY ACTIVITY STATUS INDICATION ON PARENT UNIT...................................................................... 27

9.1 Sleeping....................................................................................................................................... 27

9.2 Baby movement..........................................................................................................................27

9.3 Baby absence .............................................................................................................................. 27

10. ALARM CONDITIONS FOR THE PARENT UNIT ................................................................................. 27

10.1 Clearing of alarms ....................................................................................................................... 27

10.2 No breath movement.................................................................................................................. 28

10.3 Wake up alert.............................................................................................................................. 28

10.4 Baby absence alert......................................................................................................................29

11. OTHER STATUS INDICATIONS ON THE PARENT UNIT ..................................................................... 29

11.1 Out of range / Link loss ...............................................................................................................29

11.2 Manual pairing of Infant Snooze and Parent Unit ...................................................................... 30

11.3 Low battery indication for Parent Unit ....................................................................................... 30

11.4 Low battery indication for Infant Snooze ................................................................................... 30

11.5 Error 1: Fiber sensor is broken.................................................................................................... 31

11.6 Error 8: Weight limit indication for the Infant Snooze ...............................................................31

11.7 Error 9: Device malfunction ........................................................................................................ 31

12. TROUBLESHOOTING AND FAQ........................................................................................................ 32

13. MAINTENANCE................................................................................................................................ 33

14. TECHNICAL SUPPORT ...................................................................................................................... 33

15. LIMITED WARRANTY .......................................................................................................................34

1. GETTING STARTED

Package contents

Your iBabyGuard™ Infant Snooze package includes:

Infant Snooze

Quick Start Guide

Before you can use the mat, you need the following (not included in the product):

-4 X AA dry cell battery for the Infant Snooze

-2 X AAA dry cell battery for the Parent Unit

For best performance, Lithium dry cell battery is recommended.

1.1Parts description for the Infant Snooze(Model IBG iSnooze 5M)

POWER button

Turn the Infant Snooze ON or OFF

LED indicator

Infant Snooze operation status indication

Microphone

Pick up audio sound from the Infant Snooze

Speaker

Output lullaby music stream from smart phone (Output parents / caregivers voice only

when Parent Unit is used)

Battery

compartment of

mat

Uses 4 x AA dry cell batteries for the Infant Snooze (Batteries not included)

Infant Snooze

For monitoring baby

1.2Parts description for the Parent Unit (Model IBG iSnooze 5C)

Turn the parent unit ON or OFF

Reset alarm (Press and hold the button)

ALARM ENABLE

button

Turn alarm enable function ON or OFF

Reset alarm (Press and hold the button)

SENSITIVITY button

To set Infant Snooze sensitivity level

Reset alarm (Press and hold the button)

TALK button

Press to talk to your baby remotely

Speaker

Listen to sound from your baby

Microphone

To talk to your baby when press & hold on the TALK button

Volume

To adjust volume for the Parent Unit

Alarm select switch

To select the alarm type

Battery

Compartment

Uses 2 x AAA dry cell batteries (Batteries not included)

Lanyard hole

To insert a lanyard (Lanyard not included with the product)

1.3 Setting up the Infant Snooze with the Smartphone Apps

Insertion of battery to the Infant Snooze

Flip the Infant Snooze over to the bottom side.

Insert the 4 AA batteries inside the battery

compartment. Cover back the battery cover as shown

by the arrow.

Power on the Infant Snooze

Place the Infant Snooze on the cot, mattress or any flat

surface.

Put your baby on the Infant Snooze.

Press the power button at the tip of Infant Snooze

frame as shown. The LED indicator on the top of the

Infant Snooze will light up.

HINT:

Check the mat LED indicator. It will light up alternating between green and red colour during initial pairing mode,

will show green colour once connection is established with the smartphone Apps.

Power on the Smartphone Apps

For first time use,

Download the iBabyGuard™ Infant Snooze Apps

from the Google Play store.

Install the iBabyGuard™ Infant Snooze Apps.

Go to Settings -> Wireless & networks ->

Bluetooth settings ->

Tap on “Scan for devices”

Tap on the Bluetooth device name for the

iBabyGuard™ Infant Snooze to pair with the

Infant Snooze (while Infant Snooze is still in

pairing mode such that LED is blinking red &

green)

Bluetooth device name for the Infant Snooze:

iSnoozeXX

Tap on the iBabyGuard™ Infant Snooze Apps icon.

The Apps will establish communication with the Infant

Snooze automatically.

Once connected, the current baby status will be

displayed on the Home screen as shown.

WARNING:

The Infant Snooze will establish communication with only 1 device at one time.

Please ensure the Smartphone Apps is turned off when the Parent Unit is in use and vice versa.

HINT:

Check that iBabyGuard™ Infant Snooze Apps is always running in the background on your Android Devices, when using

another App in the foreground. The Android OS may close the iBabyGuard™ Infant Snooze Apps and other Apps

running in the background when there are many Apps running and takes up too much memory space of the Android

Device.

For Android OS version 4.0 and above: To prevent the Android Devices from closing iBabyGuard™ Infant Snooze Apps

when the Apps is shifted to the background on your Android Device, do the following steps.

(Note : The iBabyGuard™ Infant Snooze Apps may be closed by the Android OS as well when the above case of many

Apps running in the background occur.)

Go to Settings -> Developer options -> Apps

Ensure “Don’t keep activities” is unchecked

Under “Background process limit”, ensure “No background processes” is unchecked

1.4 Settings on the Smartphone Apps

There are numerous settings available on the “Setting” tab of the Smartphone App for setting alarms on

the Smartphone, volume and sensitivity control on the Infant Snooze, feeding reminders, as well as

enabling a factory reset. Below is a summary table for the settings and its setting operations are detailed

below.

Setting

Function

Alarm settings

Alarm type

Alarm volume

Alert enable

Select alarm type, volume and enable alarm mode for the

baby sound/wake up movement and baby absence states

Mat control

Infant Snooze volume

Infant Snooze sensitivity

Set Infant Snooze volume and sensitivity

Feeding schedule

Feeding reminder

Reminder tone

Reminder interval

Schedule reminders for feeding baby

General settings

Temperature unit

Factory reset

Version

Set the unit for ambient temperature display,

Reset settings to factory default and check apps version

Alarm type

There are 3 alarm types to select on the smartphone for

the baby states which require attention.

Vibrate

Sound

Vibrate and Sound (both activated)

Tap the preferred alarm type to activate it.

The corresponding vibrate and/or sound alarm icons

are indicated on the top of the LCD screen as shown

(highlighted in red).

HINT:

Consider switching to vibration mode when parent/caregiver needs a rest from looking after the baby.

WARNING:

Setting for alarm type does not apply to mandatory alarm for no breath movement condition. Refer to

section 4.2 for details.

Alarm volume

There is a 10-step interval scroll bar for adjusting the

alarm volume for the smartphone.

Tap on “Alarm volume”

Adjust the volume on the scroll bar

Tap “OK” to set the alarm volume.

WARNING:

Set to low volume and adjust up slowly to protect your ears.

Setting for alarm volume does not apply to mandatory alarm for no breath movement condition. Refer to section

4.2 for details.

Alert enable

The alert enable function is a single control function

which activates BOTH the baby wake up and absence

detection.

To enable the alert function,

Tap the checkbox for “Alert enable” as shown.

To disable the alert function,

Tap the checkbox once till the check mark

symbol disappears.

It is disabled by default.

When enabled, the alert enable icon is indicated on the

top of the LCD screen as shown (highlighted in red).

Note: Please refer to section 4.3 and 4.4 for more

details on the Wake up and Absence alert notification

functions respectively.

WARNING:

Alert will be disabled during music / lullaby stream to prevent false alert due to sound.

It is advisable NOT to disable alarm when your baby is unwell or need extra attention.

Infant Snooze volume

There are 3 volume levels to select for the music stream

and transmitting audio sound from the Infant Snooze

High

Mid

Low

Tap the preferred volume level to activate it.

WARNING:

Volume is fixed for the mandatory No breath novement alarm and cannot be adjusted. Refer to section 4.2 for

details.

Infant Snooze sensitivity

There are 3 sensitivity levels.

High (3, Default)

Mid (2)

Low (1)

Tap the preferred sensitivity level to adjust it.

The numerical representation for the sensitivity level is

indicated on the top of the LCD screen as shown

(highlighted in red).

HINT:

When baby is moving extensively and the display does NOT show strong movement, set higher sensitivity.

Set lower sensitivity when baby is sleeping soundly and the display shows strong movement.

Feeding schedule

To schedule feeding reminder,

Tap the checkbox for “Feeding reminder” as

shown.

Select reminder tone

Select time interval

The feeding reminder activation icon is indicated on the

top of the LCD screen as shown (highlighted in red).

Temperature unit

There are 2 units for selection to display for the

ambient temperature, namely Celsius (oC) or Fahrenheit

(oF).

Tap the commonly used unit for your location.

Other manuals for Infant Snooze Baby Sleep Monitor

Table of contents

Other iBabyGuard Baby Monitor manuals

iBabyGuard

iBabyGuard Infant Snooze Baby Sleep Monitor User manual

iBabyGuard

iBabyGuard Infant Snooze Baby Sleep Monitor User manual

iBabyGuard

iBabyGuard Infant Snooze User manual

iBabyGuard

iBabyGuard Infant Snooze User manual

Popular Baby Monitor manuals by other brands

Levana

Levana OmaSense quick start guide

Bubbli

Bubbli BBBBY24MONA quick start guide

ANMEATE

ANMEATE SM 24 user manual

Hisense

Hisense Babysense user manual

Summer

Summer 29640 instruction manual

TrueLife

TrueLife NannyCam R3 Smart manual

Lionelo

Lionelo Babyline 5.1 user manual

Graco

Graco 2725 owner's manual

MonBaby

MonBaby Smart Button user manual

Philips

Philips Baby Monitor SBCSC363 Instructions for use

Motorola

Motorola MBP164 Connect user guide

Motorola

Motorola MBP483 quick start guide

Beurer

Beurer Janosch JBY 93 Instructions for use

Uniden

Uniden BW6151R Series owner's manual

Oricom

Oricom babysense 2 user guide

Alcatel

Alcatel BABY LINK 510 user guide

Philips

Philips AVENT DECT SCD535/00 Specifications

Angelcare

Angelcare AC601-A owner's manual
