iBabyGuard Infant Snooze User manual


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  







iBabyGuard™
InfantSnoozeActiveBabyMonitor
UserManual







Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
2

IMPORTANTINFORMATION–PLEASEREADFIRSTBEFOREUSE
TheiBabyGuard™InfantSnoozeActiveBabyMonitorconsistsofawirelessBreathMovementmonitoringmat
(modelIBGiSnooze5M)whichworkswithanAndroid‐poweredSmartphoneAppsforremotecontrol.

TheAndroidOSVersionhadtobeminimumversion2.1inordertobeusedwiththeiBabyGuard™InfantSnooze
ActiveBabyMonitorApps.

AllthemusicfileformatssupportedbyAndroidOSaresupportedbythemusicstreamfunctionofthe
iBabyGuard™InfantSnoozeActiveBabyMonitorApps.Somephonemodelsmaynotsupportallthemusicfiles
formatslisted.

MP3
MIDI
PCM/WAVE
AACLC/LTP
HE‐AACv1(AAC+)
AMR‐NB
AMR‐WB
FLAC
Vorbis

Theremotereceiver,modelIBGiSnooze5C(ParentUnit)isincludedintheproduct.Itcanbeusedinplaceofthe
smartphoneApps.

OnlyeitherthesmartphoneiBabyGuard™InfantSnoozeActiveBabyMonitorAppsortheParentUnitcanbeused
forcommunicationwiththeInfantSnoozeatanyonetime,butNOTbothcanbeusedsimultaneously.

BabyweightlimitontheInfantSnoozeforeffectivemonitoringshouldfallwithintherangebelow:

AvoidplacinganyclothmaterialbetweenthebabyandtheInfantSnooze.Whenclothmaterialisplacedonthe
mat,thicknessofthematerialshouldbelessthan3mm.Recommendedmaterialsarecottonbedsheet,cotton
bathtowelorswaddlingcloth.Otherunknownmaterialsmaycompromisethesensitivity.

2kg/4.4lb–10kg/22lb


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
3

Warninganddisclaimer
TheiBabyGuard™InfantSnoozeActiveBabyMonitorisNOTamedicaldeviceoradiagnosticdeviceto
preventSuddenInfantDeathSyndrome(SIDS)or‘cotdeath’.Babieswithaknownpredispositiontoany
breathingabnormalityincludingapnea,obstructivesleepapneashouldbemonitoredbyadoctor.Please
seekadvicefromdoctorsorhealthcareprofessionalformedicaldiagnosisorwhenunsureofany
symptoms.
iBabyGuard™InfantSnoozeActiveBabyMonitorisNOTasubstituteforproperadultsupervision.Itis
importantthatanadultstayswithinrangeofthemonitoratalltimesduringuse.
ThisInfantSnoozeisconstructedwithhighlysensitivefiberopticstechnology.Toensureaccuracyanddurability,
pleaseobservethefollowingcareandmaintenanceinstructions.

Careandmaintenanceofthemat
 
NOJUMPING/STAMPING  NOSHARPHITS  NOHEAVYWEIGHTBEYONDLIMIT 

NOBENDING  NOHOLDINGOFTHE
EDGEINONEHAND

NOIMMERSINGINWATER 

ItisadvisabletousetheInfantSnoozeforsleepingpurposeandshouldnotbeusedasaplaymat.

AvoidmajormovementactivityaroundtheInfantSnoozeasitishighlysensitiveandmaypickupthe
movementsignalaspartofthemovementsignalofthebaby.Pattingaction,highvibrationormotor‐
runningactivitieswillaffecttheaccuracyofthebreathmovementcount.

DONOTaddthickandheavyitemssuchasmattressbetweenyourbabyandtheInfantSnooze.



Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
4

Anyformofspillageorstainshouldbewipedoffimmediatelywithwateronadampclothtoprevent
permanentstainontheInfantSnooze.Avoidusingstrongdetergent.Gentlewipeissufficienttocleanup
stains.Excessivescrubbingactionmaydamagethewater‐resistancepropertyoftheInfantSnooze.

ObservepolarityofthebatteryplacementforproperfunctioningoftheInfantSnooze.

DONOTdisassemble,crush,short‐circuitorincineratethebatteryasitmaycausefire,injury,burnsor
otherhazards.

DONOTputtheParentUnitnearwirelessdevicesoramicrowaveoven.Suchdevicescandisruptthe
transmissionofthealarmsignal.

TheoperatingtemperaturerangefortheiBabyGuard™InfantSnoozeActiveBabyMonitorisfrom10
0
C‐
40
0
C.DONOToperatebeyondthisrangeasitmaynotfunctionaccordingtodefinedspecifications.


Disposalinstructions
DonotdisposeoftheiBabyGuard™InfantSnoozeActiveBabyMonitororParentUnitwithunsortedwaste.
Improperdisposalmaybeharmfultotheenvironmentandhumanhealth.Pleaserefertoyourlocalwaste
authorityforinformationonreturnandcollectionsystemsinyourarea.












Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
5

iBabyGuard™InfantSnoozeActiveBabyMonitorSmartPhoneAppsStatusIndicationSummarySheet
StatusindicationEventRemarks

Calibrationinprogress
Thedisplaywillindicateanhourglass
rotatinginacircularmotion

Sleeping
Thedisplaywillbeasshownwhenbaby
issleepingsoundly.

Movement/Wakeupalert
Thedisplaywillbeasshownwhenever
thebabymoves.Afterthebabyfalls
asleep,wakeupalertisactivatedafter
ababy’ssoundsorcrieswith
continuousmovementisdetectedfrom
theInfantSnooze

AbsencefromInfantSnooze
alert
Thedisplaywillbeasshownandalarm
willbeactivatedwheneverthebabyis
outoftheInfantSnooze


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
6


Nobreathmovement
detected
Thedisplaywillbeasshownandalarm
willbeactivatedwhennobreath
movementisdetected

Error1:Fibersensorisbroken
Pleasecontactyourservicecentre

Error8:Highpressure
exerted/Weightlimit
exceeded
Highpressure,suchasheavyweighton
thematorthebabysittingup.The
alarmwillalsobeactivated.

Error9:Device
Malfunction
meansanyothernumber
than1and8

Pleasecontactyourservicecentre



Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
7

ParentUnitStatusIndicationSummarySheet
StatusindicationEventRemarks

Calibrationinprogress
Thedisplaywillindicateanhourglass
rotatinginacircularmotion

Sleeping
Thedisplaywillbeasshownwhenbaby
issleepingsoundly.

Movement/Wakeupalert
Thedisplaywillbeshownwheneverthe
babymoves.Afterthebabyfallsasleep,
wakeupalertisactivatedafterababy’s
soundsorcrieswithcontinuous
movementisdetectedfromthemat


AbsencefromInfantSnooze
alert
Thedisplaywillbeasshownandalarm
willbeactivatedwheneverthebabyis
outoftheInfantSnooze

Nobreathmovement
detected
Thedisplaywillbeasshownandalarm
willbeactivatedwhennobreath
movementisdetected

Error1:Fibersensorisbroken
Pleasecontactyourservicecentre

Error8:Highpressureexerted
/Weightlimitexceeded
Highpressure,suchasheavyweighton
theInfantSnoozeorthebabysitting
up.Thealarmwillalsobeactivated.

Error9:Device
Malfunction
meansanyothernumber
than1and8

Pleasecontactyourservicecentre



Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
8

 TableofContents
1.GETTINGSTARTED.................................................................................................................................1
1.1PartsdescriptionfortheInfantSnooze(ModelIBGiSnooze5M).................................................2
1.2PartsdescriptionfortheParentUnit(ModelIBGiSnooze5C).....................................................3
1.3SettinguptheInfantSnoozewiththeSmartphoneApps............................................................5
1.4SettingsontheSmartphoneApps................................................................................................7
2.KEYFEATURESOFSMARTPHONEAPPS..............................................................................................12
2.1Babyactivitymonitor..................................................................................................................12
2.2Ambienttemperaturedisplay.....................................................................................................12
2.3Streamingofmusic/lullaby.......................................................................................................13
2.4Babysleeplog.............................................................................................................................14
2.5BreathScope...............................................................................................................................14
3.BABYACTIVITYSTATUSINDICATIONONSMARTPHONE....................................................................
15
3.1Sleeping.......................................................................................................................................15
3.2Babymovement..........................................................................................................................15
3.3Babyabsence..............................................................................................................................16
4.ALARMCONDITIONSFORTHESMARTPHONEAPPS...........................................................................16
4.1Clearingofalarms.......................................................................................................................16
4.2Nobreathmovement..................................................................................................................17
4.3Wakeupalert..............................................................................................................................17


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
9

4.4Babyabsencealert......................................................................................................................18
5.OTHERSTATUSINDICATIONSONTHESMARTPHONEAPPS...............................................................19
5.1Outofrange/Linkloss...............................................................................................................19
5.2ManualpairingofInfantSnoozeandSmartphone.....................................................................19
5.3LowbatteryalertforInfantSnooze............................................................................................20
5.4Error1:Fibersensorisbroken....................................................................................................21
5.5Error8:WeightlimitindicationfortheInfantSnooze...............................................................21
5.6Error9:Devicemalfunction........................................................................................................22
6.EXCEPTIONSMANAGEMENTFORSMARTPHONE...............................................................................22
7.SETTINGUPTHEINFANTSNOOZEWITHPARENTUNIT......................................................................23
7.1PoweringuptheParentUnit......................................................................................................23
7.2SettinguptheParentUnit..........................................................................................................24
8.KEYFEATURESOFPARENTUNIT.........................................................................................................26
8.1AudioMonitor.............................................................................................................................26
8.2Speakingtoyourbaby.................................................................................................................26
9.BABYACTIVITYSTATUSINDICATIONONPARENTUNIT......................................................................27
9.1Sleeping.......................................................................................................................................27
9.2Babymovement..........................................................................................................................27
9.3Babyabsence..............................................................................................................................27
10.ALARMCONDITIONSFORTHEPARENTUNIT.................................................................................27


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
10

10.1Clearingofalarms.......................................................................................................................27
10.2Nobreathmovement..................................................................................................................28
10.3Wakeupalert..............................................................................................................................28
10.4Babyabsencealert......................................................................................................................29
11.OTHERSTATUSINDICATIONSONTHEPARENTUNIT.....................................................................29
11.1Outofrange/Linkloss...............................................................................................................29
11.2ManualpairingofInfantSnoozeandParentUnit......................................................................30
11.3LowbatteryindicationforParentUnit.......................................................................................30
11.4LowbatteryindicationforInfantSnooze...................................................................................31
11.5Error1:Fibersensorisbroken....................................................................................................31
11.6Error8:WeightlimitindicationfortheInfantSnooze...............................................................31
11.7Error9:Devicemalfunction........................................................................................................31
12.TROUBLESHOOTINGANDFAQ........................................................................................................32
13.MAINTENANCE................................................................................................................................33
14.TECHNICALSUPPORT......................................................................................................................33
15.LIMITEDWARRANTY.......................................................................................................................34





Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
1

1. GETTINGSTARTED
Packagecontents
YouriBabyGuard™ Infant Snooze Active Baby Monitor Matpackageincludes:
InfantSnooze
QuickStartGuide

Beforeyoucanusethemat,youneedthefollowing(notincludedintheproduct):
-4XAAdrycellbatteryfortheInfantSnooze
-2XAAAdrycellbatteryfortheParentUnit

Forbestperformance,Lithiumdrycellbatteryisrecommended.


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
2

1.1PartsdescriptionfortheInfantSnooze (ModelIBGiSnooze5M) 
 








1POWERbuttonTurntheInfantSnoozeONorOFF
2LEDindicatorInfantSnoozeoperationstatusindication
3MicrophonePickupaudiosoundfromtheInfantSnooze
4SpeakerOutputlullabymusicstreamfromsmartphone(Outputparents/caregiversvoiceonly
whenParentUnitisused)
5
Battery
compartmentof
mat
Uses4xAAdrycellbatteriesfortheInfantSnooze(Batteriesnotincluded)
6InfantSnoozeFormonitoringbaby
1
2
4
3
5
6


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
3

1.2PartsdescriptionfortheParentUnit (ModelIBGiSnooze5C) 

7TurntheparentunitONorOFF
Resetalarm(Pressandholdthebutton)
8ALARMENABLE
button
TurnalarmenablefunctionONorOFF
Resetalarm(Pressandholdthebutton)
9SENSITIVITYbutton
TosetInfantSnoozesensitivitylevel
Resetalarm(Pressandholdthebutton)
10TALKbuttonPresstotalktoyourbabyremotely
11SpeakerListentosoundfromyourbaby
12MicrophoneTotalktoyourbabywhenpress&holdontheTALKbutton
10 7 13
11 9 8
12 14

16 15


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
4


























13VolumeToadjustvolumefortheParentUnit
14AlarmselectswitchToselectthealarmtype
15Battery
CompartmentUses2xAAAdrycellbatteries(Batteriesnotincluded)
16LanyardholeToinsertalanyard(Lanyardnotincludedwiththeproduct)


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
5

1.3 SettinguptheInfantSnoozewiththeSmartphoneApps
InsertionofbatterytotheInfantSnooze

FliptheInfantSnoozeovertothebottomside.
Insertthe4AAbatteriesinsidethebattery
compartment.Coverbackthebatterycoverasshown
bythearrow.


PowerontheInfantSnooze
PlacetheInfantSnoozeonthecot,mattressoranyflat
surface.
PutyourbabyontheInfantSnooze.
PressthepowerbuttonatthetipofInfantSnooze
frameasshown.TheLEDindicatoronthetopofthe
InfantSnoozewilllightup. 

HINT:
CheckthematLEDindicator.Itwilllightupalternatingbetweengreenandredcolourduringinitialpairingmode,
willshowgreencolouronceconnectionisestablishedwiththesmartphoneApps.




Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
6

PowerontheSmartphoneApps
Forfirsttimeuse,
DownloadtheiBabyGuard™InfantSnooze
ActiveBabyMonitorAppsfromtheGooglePlay
store.
InstalltheiBabyGuard™InfantSnoozeActive
BabyMonitorApps.
GotoSettings‐>Wireless&networks‐>
Bluetoothsettings‐>
Tapon“Scanfordevices”
TapontheBluetoothdevicenameforthe
iBabyGuard™InfantSnoozeActiveBaby
MonitortopairwiththeInfantSnooze(while
InfantSnoozeisstillinpairingmodesuchthat
LEDisblinkingred&green)
BluetoothdevicenamefortheInfantSnooze:
iSnoozeXX

TapontheiBabyGuard™InfantSnoozeActiveBaby
MonitorAppsicon.

TheAppswillestablishcommunicationwiththeInfant
Snoozeautomatically.

Onceconnected,thecurrentbabystatuswillbe
displayedontheHomescreenasshown.






WARNING:
TheInfantSnoozewillestablishcommunicationwithonly1deviceatonetime.
PleaseensuretheSmartphoneAppsisturnedoffwhentheParentUnitisinuseandviceversa.


HINT:
CheckthatiBabyGuard™InfantSnoozeActiveBabyMonitorApps
 isalwaysrunninginthebackgroundonyour
AndroidDevices,whenusinganotherAppintheforeground.TheAndroidOSmayclosetheiBabyGuard™Infant
SnoozeActiveBabyMonitorApps
 andotherAppsrunninginthebackgroundwhentherearemanyAppsrunningand
takesuptoomuchmemoryspaceoftheAndroidDevice.

ForAndroidOSversion4.0andabove:TopreventtheAndroidDevicesfromclosingiBabyGuard™InfantSnoozeActive
BabyMonitorApps
 whentheAppsisshiftedtothebackgroundonyourAndroidDevice,dothefollowingsteps.
(Note:TheiBabyGuard™InfantSnoozeActiveBabyMonitorApps
 maybeclosedbytheAndroidOSaswellwhenthe
abovecaseofmanyAppsrunninginthebackgroundoccur.)
GotoSettings‐>Developeroptions‐>Apps
Ensure“Don’tkeepactivities”isunchecked
Under“Backgroundprocesslimit”,ensure“Nobackgroundprocesses”isunchecked


Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
7

1.4 SettingsontheSmartphoneApps
Therearenumeroussettingsavailableonthe“Setting”taboftheSmartphoneAppforsettingalarmson
theSmartphone,volumeandsensitivitycontrolontheInfantSnooze,feedingreminders,aswellas
enablingafactoryreset.Belowisasummarytableforthesettingsanditssettingoperationsaredetailed
below.

SettingFunction
Alarmsettings
Alarmtype
Alarmvolume
Alertenable
Selectalarmtype,volumeandenablealarmmodeforthe
babysound/wakeupmovementandbabyabsencestates
Matcontrol
InfantSnoozevolume
InfantSnoozesensitivity
SetInfantSnoozevolumeandsensitivity
Feedingschedule
Feedingreminder
Remindertone
Reminderinterval
Scheduleremindersforfeedingbaby
Generalsettings
Temperatureunit
Factoryreset
Version
Settheunitforambienttemperaturedisplay,
Resetsettingstofactorydefaultandcheckappsversion

Alarmtype
Thereare3alarmtypestoselectonthesmartphonefor
thebabystateswhichrequireattention.
Vibrate
Sound
VibrateandSound(bothactivated)

Tapthepreferredalarmtypetoactivateit.

Thecorrespondingvibrateand/orsoundalarmicons
areindicatedonthetopoftheLCDscreenasshown
(highlightedinred).


HINT:
Considerswitchingtovibrationmodewhenparent/caregiverneedsarestfromlookingafterthebaby.

WARNING:
Settingforalarmtypedoesnotapplytomandatoryalarmfornobreathmovementcondition.Referto
section4.2fordetails.




Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
8

Alarmvolume
Thereisa10‐stepintervalscrollbarforadjustingthe
alarmvolumeforthesmartphone.

Tap on “Alarm volume”
Adjust the volume on the scroll bar
Tap “OK” to set the alarm volume.




WARNING:
Settolowvolumeandadjustupslowlytoprotectyourears.
Settingforalarmvolumedoesnotapplytomandatoryalarmfornobreathmovementcondition.Refertosection
4.2fordetails.

Alertenable

Thealertenablefunctionisasinglecontrolfunction
whichactivatesBOTHthebabywakeupandabsence
detection.
Toenablethealertfunction,
Tap the checkbox for “Alert enable” as shown.

Todisablethealertfunction,
Tap the checkbox once till the check mark
symbol disappears.
It is disabled by default.

Whenenabled,thealertenableiconisindicatedonthe
topoftheLCDscreenasshown(highlightedinred).
Note:Pleaserefertosection4.3and4.4formore
detailsontheWakeupandAbsencealertnotification
functionsrespectively.


WARNING:
Alertwillbedisabledduringmusic/lullabystreamtopreventfalsealertduetosound.
ItisadvisableNOTtodisablealarmwhenyourbabyisunwellorneedextraattention.



Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
9

InfantSnoozevolume 

Thereare3volumelevelstoselectforthemusicstream
andtransmittingaudiosoundfromtheInfantSnooze
High
Mid
Low

Tapthepreferredvolumeleveltoactivateit.



WARNING:
VolumeisfixedforthemandatoryNobreathnovementalarmandcannotbeadjusted.Refertosection4.2for
details.

InfantSnoozesensitivity

Thereare3sensitivitylevels.
High(3,Default)
Mid(2)
Low(1)

Tapthepreferredsensitivityleveltoadjustit.

Thenumericalrepresentationforthesensitivitylevelis
indicatedonthetopoftheLCDscreenasshown
(highlightedinred).





HINT:
WhenbabyismovingextensivelyandthedisplaydoesNOTshowstrongmovement,sethighersensitivity.
Setlowersensitivitywhenbabyissleepingsoundlyandthedisplayshowsstrongmovement.






Copyright2012iBabyGuardInternational  www.iBabyGuard.com  
10

Feedingschedule

Toschedulefeedingreminder,
Tap the checkbox for “Feeding reminder” as
shown.
Select reminder tone
Select time interval
Thefeedingreminderactivationiconisindicatedonthe
topoftheLCDscreenasshown(highlightedinred).


Temperatureunit

Thereare2unitsforselectiontodisplayforthe
ambienttemperature,namelyCelsius(
o
C)orFahrenheit
(
o
F).

Tapthecommonlyusedunitforyourlocation.











