Ibabyguard Infant snooze baby sleep monitor User manual

iBabyGuard™

Infant Snooze Baby Sleep Monitor

User Manual

(Android Devices)

IMPORTANT INFORMATION –PLEASE READ FIRST BEFORE USE

The iBabyGuard™ Infant Snooze consists of a wireless Breath Movement monitoring mat (model IBG iSnooze 5M)

which works with an Android-powered Smartphone Apps for remote control.

The Android-based smart phone OS Version had to be minimum version 2.1 in order to be used with the Infant

Snooze Apps.

All the music file formats supported by Android OS are supported by the music stream function of the Infant

Snooze Apps. Some phone models may not support all the music files formats listed.

MP3

MIDI

PCM/WAVE

AAC LC/LTP

HE-AACv1 (AAC+)

AMR-NB

AMR-WB

FLAC

Vorbis

Only either the iBabyGuard™ Infant Snooze smartphone Apps or the Parent Unit can be used for communication

with the Infant Snooze at any one time, but NOT both can be used simultaneously.

Baby weight limit on the Infant Snooze for effective monitoring should fall within the range below:

Avoid placing any cloth material between the baby and the Infant Snooze. When cloth material is placed on the

mat, thickness of the material should be less than 3mm. Recommended materials are cotton bed sheet, cotton

bath towel or swaddling cloth. Other unknown materials may compromise the sensitivity.

Warning and disclaimer

The iBabyGuard™ Infant Snooze is NOT a medical device or a diagnostic device to prevent Sudden Infant

Death Syndrome (SIDS) or ‘cot death’. Babies with a known predisposition to any breathing abnormality

including apnea, obstructive sleep apnea should be monitored by a doctor. Please seek advice from

doctors or health care professional for medical diagnosis or when unsure of any symptoms.

iBabyGuard™ Infant Snooze is NOT a substitute for proper adult supervision. It is important that an adult

stays within range of the monitor at all times during use.

This Infant Snooze is constructed with highly sensitive fiber optics technology. To ensure accuracy and durability,

please observe the following care and maintenance instructions.

2kg / 4.4lb –10kg / 22lb

Care and maintenance of the mat

NO JUMPING/STAMPING/SITTING

NO SHARP HITS

NO HEAVY WEIGHT BEYOND LIMIT

NO BENDING

NO HOLDING OF THE

EDGE IN ONE HAND

NO IMMERSING IN WATER

It is advisable to use the Infant Snooze for sleeping purpose and should not be used as a play mat.

Avoid major movement activity around the Infant Snooze as it is highly sensitive and may pick up the

movement signal as part of the movement signal of the baby. Patting action, high vibration or motor-

running activities will affect the accuracy of the breath movement count.

DO NOT add thick and heavy items such as mattress between your baby and the Infant Snooze.

Any form of spillage or stain should be wiped off immediately with water on a damp cloth to prevent

permanent stain on the Infant Snooze. Avoid using strong detergent. Gentle wipe is sufficient to clean up

stains. Excessive scrubbing action may damage the water-resistance property of the Infant Snooze.

Observe polarity of the battery placement for proper functioning of the Infant Snooze.

DO NOT disassemble, crush, short-circuit or incinerate the battery as it may cause fire, injury, burns or

other hazards.

DO NOT put the Parent Unit near wireless devices or a microwave oven. Such devices can disrupt the

transmission of the alarm signal.

The operating temperature range for the iBabyGuard™ Infant Snooze is from 100C - 400C. DO NOT

operate beyond this range as it may not function according to defined specifications.

Disposal instructions

Do not dispose of the iBabyGuard™ Infant Snooze with unsorted waste. Improper disposal may be harmful to the

environment and human health. Please refer to your local waste authority for information on return and collection

systems in your area.

iBabyGuard™ Infant Snooze Smartphone Apps Status Indication Summary Sheet

Status indication

Event

Remarks

Calibration in progress

The display will indicate an hour glass

rotating in a circular motion

Sleeping

The display will be as shown when baby

is sleeping soundly.

Movement / Wake up alert

The display will be as shown whenever

the baby moves. After the baby falls

asleep, wake up alert is activated after

a baby’s sounds or cries with

continuous movement is detected from

the Infant Snooze

Absence from Infant Snooze

alert

The display will be as shown and alarm

will be activated whenever the baby is

out of the Infant Snooze

No breath movement

detected

The display will be as shown and alarm

will be activated when no breath

movement is detected

Error 1: Fiber sensor is broken

Please contact your service centre

Error 8: High pressure

exerted / Weight limit

exceeded

High pressure, such as heavy weight on

the mat or the baby sitting up. The

alarm will also be activated.

Error 9: Device

Malfunction

means any other number

than 1 and 8

Please contact your service centre

Table of Contents

1. GETTING STARTED................................................................................................................................. 1

1.1 Parts description for the Infant Snooze(Model IBG iSnooze 5M)................................................. 1

1.2 Setting up the Infant Snooze with the Smartphone Apps ............................................................ 2

1.3 Settings on the Smartphone Apps ................................................................................................ 4

2. KEY FEATURES OF SMARTPHONE APPS ................................................................................................ 9

2.1 Baby activity monitor.................................................................................................................... 9

2.2 Ambient temperature display..................................................................................................... 10

2.3 Streaming of music / lullaby ....................................................................................................... 10

2.4 Baby sleep log .............................................................................................................................11

2.5 Breath Scope............................................................................................................................... 11

3. BABY ACTIVITY STATUS INDICATION ON SMARTPHONE ....................................................................12

3.1 Sleeping....................................................................................................................................... 12

3.2 Baby movement..........................................................................................................................12

3.3 Baby absence ..............................................................................................................................13

4. ALARM CONDITIONS FOR THE SMARTPHONE APPS...........................................................................13

4.1 Clearing of alarms ....................................................................................................................... 13

4.2 No breath movement.................................................................................................................. 14

4.3 Wake up alert.............................................................................................................................. 14

4.4 Baby absence alert......................................................................................................................15

5. OTHER STATUS INDICATIONS ON THE SMARTPHONE APPS...............................................................16

5.1 Out of range / Link loss ...............................................................................................................16

5.2 Manual pairing of Infant Snooze and Smartphone..................................................................... 16

5.3 Low battery alert for Infant Snooze............................................................................................17

5.4 Error 1: Fiber sensor is broken.................................................................................................... 17

5.5 Error 8: Weight limit indication for the Infant Snooze ...............................................................18

5.6 Error 9: Device malfunction ........................................................................................................ 18

6. EXCEPTIONS MANAGEMENT FOR SMARTPHONE...............................................................................19

7. TROUBLESHOOTING AND FAQ............................................................................................................ 20

8. MAINTENANCE.................................................................................................................................... 21

9. TECHNICAL SUPPORT .......................................................................................................................... 21

10. LIMITED WARRANTY ....................................................................................................................... 22

1. GETTING STARTED

Package contents

Your iBabyGuard™ Infant Snooze package includes:

Infant Snooze

Quick Start Guide

Before you can use the mat, you need the following (not included in the product):

-4 X AA dry cell battery for the Infant Snooze

For best performance, Lithium dry cell battery is recommended.

1.1Parts description for the Infant Snooze(Model IBG iSnooze 5M)

1.2 Setting up the Infant Snooze with the Smartphone Apps

Insertion of battery to the Infant Snooze

Flip the Infant Snooze over to the bottom side.

Unscrew the battery cover and insert the 4 AA batteries

inside the battery compartment. Cover back the battery

cover as shown by the arrow.

** Batteries not included

Power on the Infant Snooze

Place the Infant Snooze on the cot, mattress or any flat

surface.

Put your baby on the Infant Snooze.

Press the power button at the tip of Infant Snooze

frame as shown. The LED indicator on the top of the

Infant Snooze will light up.

HINT:

Check the mat LED indicator. It will light up alternating between green and red colour during initial pairing mode,

will show green colour once connection is established with the smartphone Apps.

POWER button

Turn the Infant Snooze ON or OFF

LED indicator

Infant Snooze operation status indication

Microphone

Pick up audio sound from the Infant Snooze

Speaker

Output lullaby music stream from smart phone (Output parents / caregivers voice only

when Parent Unit is used)

Battery

compartment of

mat

Uses 4 x AA dry cell batteries for the Infant Snooze (Batteries not included)

Infant Snooze

For monitoring baby
