iBall Andi4.5M Enigma User manual

1
Legal Information
All rights are reserved. Reproduction, transfer, distribution of
the contents herein in any manner without the prior written
permission of Best IT World (India) Pvt. Ltd. is prohibited. Best
IT World (India) Pvt. Ltd. reserves the right to add, modify or
delete, any of the contents herein or withdraw this document at
any time without prior notice and without assigning any
reasons thereof. For detailed terms and conditions refer
www.iBallMobiles.co.in
Safety Precautions
Operate Safely
• Please do not use Mobile while charging. Disconnect Mobile
from charger before use.
• Make sure to charge the battery full for the first time usage.
• Keep the mobile phone at least an inch away from your body
while dialing / answering calls.
• Do not use the mobile phone if the screen is cracked or
broken. Cracked and / or broken screens could cause injury to
hands and / or face.
• To reduce the risk of motion injuries:
- While using your mobile phone, hold it with a relaxed grip and
press the keys lightly.
- Do not handle the mobile phone with wet hands.
- Use of special keys / features reduce the number of keys
presses
- Take regular breaks in between calls.
- Use hands-free accessories.
- Switch off the mobile phone before cleaning it.

2
- Switch off the Mobile Phone and external power sources
before any attempt to change batteries, SIM Cards or any
other accessories.
- Keep your mobile phone and all accessories out of reach of
small
Children and animals.
When using the device, mind the following
• Hold the device upright, as you would with a traditional phone.
• Speak directly into the microphone.
• Do not cover the antenna area with your hands or other
objects. This may cause connectivity problems or drain the
battery.
Careful handling
• Avoid potential damage to your mobile phones as under:
- Keep away from liquids.
- Avoid using and / or storing in dusty and / or dirty places /
environments.
- Do not drop, knock, throw or otherwise handle the mobile
phone roughly.
- Avoid exposing your mobile phone and / or batteries to
extreme temperatures. Extreme temperatures reduce the
charging capacity and life of batteries and mobile phone.
- Never use damaged chargers or batteries.
- Do not use chemicals or other cleaning solutions to clean the
mobile phone.
- Use moist or anti-static cloth.
- Avoid using mobile phone with camera flash or light close to
the eyes.

3
- Do not dismantle the mobile phone and / or accessories
without permission.
- Avoid handling by unauthorized personnel.
Do not use damaged power cords or plugs, or loose electrical
sockets
Do not use your device outdoor during a thunderstorm
Do not handle a damaged or leaking Lithium Ion (Li-Ion)
battery
Do not use your device near devices or apparatuses that emit
radio frequencies, such as sound systems or radio towers
If you notice strange smells or sounds coming from your
device or the battery, or if you see smoke or liquids leaking
from the device or battery, stop using the device immediately
and take it to a iBall Service Centre
Turn Off your Mobile Phone in Restricted Areas
Use of mobile phones in certain areas / places / conditions can
be hazardous.
• Switch off your mobile phone:
- Inside aircrafts;
- In Medical hospitals / clinics;
- Areas where chemicals are used and / or stored;
- Fuel and gas stations;
- In and around areas having electrical / electronic equipment;
- Areas where any kind of blasting activity is being carried out.
Turn off the device in potentially explosive environments
• Removing, installing or charging mobile phone batteries in
such areas is hazardous as potential sparks may result in
explosion and / or fire and may cause damage to property and
/ or life and can also prove fatal.

4
Keep your device dry
• Humidity and liquids may damage the parts or electronic
circuits in your device.
•Do not turn on your device if it is wet. If your device is already
on, turn it off and remove the battery immediately (if the device
will not turn off or you cannot remove the battery, leave it as-is).
Then, dry the device with a towel and take it to a service
center.
• Liquids will change the colour of the label that indicates water
damage inside the device. Water damage to your device can
void your manufacturer‟s warranty.
Drive Safety
Avoid using your mobile phone while driving and respect and
obey all regulations that restrict the use of mobile phones while
driving. Primary consideration while driving should be safety.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles such as
electronic fuel injection, electronic speed control, and air bag
systems. Only qualified personnel should service the device or
install the device in a vehicle. Faulty installation or service may
be dangerous and may invalidate your warranty. The use of
wireless tele devices in an aircraft may be dangerous to the
operation of the aircraft and may be illegal.
Interference with Electronic Devices
Mobile phones emit Radio Frequency (RF) signals that may
interfere with unshielded or improperly

5
Shielded electronic equipment, such as pace makers, hearing
aids, other medical devices and other electronic devices in
homes and / or vehicles and may prove to be hazardous.
Protect Your Hearing
Excessive exposure to high volumes may cause hearing
problems. Maintain proper volume levels for conversations and
/ or music.
Use & Dispose of Batteries & Chargers
• Use only iBall accessories and batteries. Using incompatible
batteries and / or accessories may damage your mobile phone
or cause injury.
• Never dispose the battery or mobile phone in fire.
• Never crush or puncture the battery.
• Avoid exposing the battery to high external pressure, which
can lead to an internal short circuit.
• Never place batteries or mobile phone in or on heating
devices, such as microwave ovens, stoves or radiators.
Battery may explode when overheated.
In order to use mobile phone correctly, please read the
following statement of the user manual carefully before using
the mobile phone.
Do not store your device with metal objects, such as coins,
keys, and necklaces
• Your device may be scratched or may malfunction.
• If the battery terminals come into contact with metal objects,
this may cause fire.
Do not store your device near magnetic fields
• Your device may malfunction or the battery may discharge
from exposure to magnetic fields.

6
• Magnetic stripe cards, including credit cards, phone cards,
passbooks, and boarding passes, may be damaged by
magnetic fields.
Do not use your device or applications for a while if the
device is overheated
Prolonged exposure of your skin to an overheated device may
cause low temperature burn symptoms, such as red spots and
pigmentation.
Do not use your device with the back cover removed
The battery may fall out of the device, which may result in
damage or malfunction.
If your device has a camera flash or light, do not use it
close to the eyes of people or pets
Using a flash close to the eyes may cause temporary loss of
vision or damage to the eyes.
Malware and viruses
To protect your device from malware and viruses, follow these
usage tips. Failure to do so may result in damages or loss of
data that may not be covered by the warranty service
• Do not download unknown applications.
• Do not visit untrusted websites.
• Delete suspicious messages or email from unknown senders.
• Set a password and change it regularly.
• Deactivate wireless features, such as Bluetooth, when not in
use.
• If the device behaves abnormally, run an antivirus program to
check for infection.
• Run an antivirus program on your device before you launch
newly downloaded applications and files.

7
• Install antivirus programs on your computer and run them
regularly to check for infection.
• Do not edit registry settings or modify the device‟s operating
system.
Using this Guide
This guide has been specially designed to guide you through
the basics of your device, such as getting started with the
device. Please read this guide carefully before using your
device to ensure safe and correct use.
The descriptions in this guide are based on the default settings
of your device.
Please keep this guide for future reference.
Installing the SIM card, Battery, and Storage card
You need to remove the back cover before you can install the
SIM card and battery. Also, make sure to always turn off the
power before installing or replacing the SIM card and battery.
To remove the back cover
1. Make sure your device is turned off.
2. Firmly hold the device with both hands and the front panel
facing down.
3. Pull battery cover from the right corner at bottom until it
disengages from the device and then pull it up to remove.
To install the SIM card
The SIM card contains your phone number, service details,
and phonebook/ message memory. Your device supports both
3G and 2G SIM cards.
1. Remove the battery if it is installed.

8
2. Locate the SIM card slot, and then insert the SIM card with
its gold contacts facing down and its cut-off corner facing out
the card slot.
3. Push the SIM card completely into the slot.
Note: The phone supports dual SIM cards, SIM slot 1 & SIM
slot 2 both supports 3G networks.
To install the battery
Your device comes with a rechargeable Lithium-ion battery
and is designed to use only manufacturer-specified original
batteries and accessories. Battery performance depends on
many factors, including network configuration, signal strength,
and usage patterns.
Warning: To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery
pack.
• Do not crush, puncture, short external contacts, or dispose of
in fire or water.
• Do not expose to temperatures above 60°C (140°F).
• Replace only with the battery pack designated for this
product.
• Recycle or dispose of used battery as stipulated by local
regulations.
1. Align the battery‟s exposed copper contacts with the battery
connectors in the battery compartment.
2. Insert the contacts side of the battery first and then gently
push the battery into place.
3. Replace the back cover.
To remove the battery

9
1. Make sure your device is turned off.
2. Remove the back cover.
3. The bottom of the phone has a notch. Lift the battery by the
notch to remove it.
To install the memory card
To have additional storage for your images, videos, music, and
files
You can purchase a memory card and install it into your device.
1. Make sure that your device is turned off, and then remove
the back cover.
2. Locate the memory card slot on the upper part of the
exposed right panel.
3. Insert the memory card into the slot with its gold contacts
facing down until it clicks into place.
Note: To remove the memory card, pull it to eject it from the
slot.
Charging the Battery
New batteries are shipped partially charged. Before you start
using your device, it is recommended that you install and
charge the battery. Some batteries perform best after several
full charge/discharge cycles.
The battery can be charged and discharged many times, but it
will eventually wear out. When the talk and standby times are
noticeably shorter than normal, replace the battery. Use only
iBall approved batteries, and recharge your battery only with
iBall approved chargers designated for this device. If a battery
is being used for the first time or if the battery has not been
used for a prolonged period, it may be necessary to connect
the charger, then disconnect and reconnect it to begin

10
charging the battery. If the battery is completely discharged, it
may take several minutes before the charging indicator
appears on the display or before any calls can be made.
Note: Only the AC adapter and USB sync cable provided with
your device must be used to charge the device.
Connect the USB connector of the AC adapter to the sync
connector on your device, and then plug in the AC adapter to
an electrical outlet to start charging the battery.
As the battery is being charged while the device is on, a
charging icon
Appears in the title bar of the Home screen. After the battery
has been fully charged, a full battery icon appears on the title
bar of the Home screen.
Warning: • Do not remove the battery from the device while
you are charging it using the AC or car adapter.
• As a safety precaution, the battery stops charging before it
overheats.
SAR
This mobile phone is SAR accredited adheres to international
quality benchmarks and safety measures concerning the
harmful impact of radiations. It complies with applicable safety
requirements for exposure to radio waves. The radio waves
exposure guidelines employ a unit of measurement called
Specific Absorption Rate (SAR). SAR is a measure of the rate
at which energy is absorbed by the body when exposed to a
radio frequency (RF). SAR is usually averaged either over the
whole body, or over a small sample volume (typically 1g or 10g
of tissue). The recommended SAR limit for a mobile handset is

11
1.6 W/Kg averaged over a volume containing a mass 1g of
human tissue.
SAR Value
• Your phone is designed not to exceed the limits of emission
of radio waves recommended by international guidelines.
• SAR (Specific Absorption Rate) is the measurement of body-
absorbed RF quantity when the phone is in use. SAR value is
ascertained according to the highest RF level generated during
laboratory tests.
• The SAR value of the phone may depend on factors such as
proximity to the network tower, use of accessories.
SAR Recommendations
• Use a wireless hands free system (headphone, headset) with
lower Bluetooth emitter.
• Make sure the cell phone has a low SAR.
• Please keep your calls short and use SMS whenever more
convenient. This advice applies especially to children and
pregnant women.
• Prefer to use your phone when the signal quality is good.
• People having active medical implants should preferably
keep the phone at least
SAR Value
Tested SAR Value of Andi4.5M Enigma is as follows:
(2G) GSM 900 MHz: 0.709 W/Kg (1g)
(2G) GSM 1800 MHz: 0.524 W/Kg (1g)
(3G) WCDMA 2100 MHz: 0.589 W/Kg (1g)
Maximum Permitted SAR value is: 1.6 W/Kg (1g)

12
Index
Legal Information......................................................1
Using this Guide........................................................7
SAR........................................................................10
Index.......................................................................12
1. Introduction.........................................................13
2. Starting up Device...............................................15
1. Settings...............................................................17
4. Phone.................................................................32
5. Messaging ..........................................................39
6. Internet ...............................................................45
7. Media..................................................................45
8 Others..................................................................49
9. Locate.................................................................52
10 Applications .......................................................53

13
1. Introduction
1.1 iBall Andi4.5M Enigma Technical Specifications
Details
Description
CPU
Powerful Quad Core 1.3GHz Cortex A7
Advanced Processor
Memory
1 GB RAM
Storage
8 GB internal storage (Approx. 2GB
memory used in software) 32 GB
external Micro SD card support
Display
11.43cm (4.5”) qHD IPS (960x540) High
Quality Display
Android
Android 4.4, Kitkat
SIM Card
Dual SIM Dual Standby (Both slot
support 3G network)
Sensor
Back Touch sensor G-sensor, Proximity
sensor & Light sensor
Network
GSM/GPRS/WCDMA
900MHz/1800MHz/1900MHz/850MHz,
/2100 MHz
Connectivity
3G HSPA+, 21Mbps Downlink &
5.6Mbps Uplink;EDGE / GPRS / GSM –
850/900/1800/1900MHz;Wi-Fi 802.11
b/g/n;Bluetooth 4.0, USB & NFC
Camera
Enhanced 13MP AF Rear Camera with
BSI Sensor,LED Flash & Enhanced 8MP
FF Front Camera with 88 degree wide
angle view to take clear selfie

14
Audio
Format
Support aac, amr, wav, mp2, mp3, ogg
Video
Format
Support 3gp, avi, flv, m4v, mkv,
mov,mp4
Format
Support bmp, gif, jpeg, jpg, png, wbmp
Battery
1500mAh with 3.7V
Power
Input:100-240V output:5V, 700mA
Dimension
133.77x 66.31x 8.77mm with 135 Gram
1.2 Know Your Device

15
2. Starting up Device
2.1 Quick setting panel
Quick setting panel is the option you will find in the notification
bar. This option provides the shortcut to the following functions:
Touch and drag the notification bar to access this shortcut.
Power on/off
To power off your phone, press & hold the POWER key. On
release, the
Phone options menu opens. Select „Power off‟ from the given
options and confirm. This will turn off the device.
Silent mode
The Menu screen, touch and select SettingsAudio profiles.
Select „Silent‟ check box. You can only activate silent profile
but cannot customize it. You can also long press the power
key and you will get the option to change user profile.
2.2 Home screen
The Home screen is your starting point for using all the
applications on your phone. You can customize your Home
screen to display applications, shortcuts, and widgets as you
like.
1. Touch the application tab with your fingertip to reveal the
application
2. The Home screen actually extends beyond the screen width.
On Home screen, swipe your fingertip left and right along the
screen to reveal the full width of the Home screen. This
additional space gives you more room to customize Home with
applications, shortcuts, and widgets.

16
2.3 Read your notifications
When you see a notification in the status bar, touch the bar
and swipe your finger down the screen to open the list of
notifications displayed in the sliding window.

17
3. Settings
Wireless & networks
3.1 SIM Management
You can select to activate or deactivate the SIM card you want
to keep in use. From here you can set the default SIM to use
3.2 Wi-Fi
Wi-Fi on/off: Select this option if you prefer to use Wi-Fi for
your data connection. You can activate Wi-Fi by toggling the
switch left/right to On/Off Wi-Fi connectivity.
Wi-Fi settings: Open the Wi-Fi settings screen. Select it from
the network list. Provide your username or password if
required
Scan: To scan the available Wi-Fi networks.
WPS Pin Entry: Any wireless computer or wireless adapter
that will connect to the modem router wirelessly is a client. The
client must support a WPS PIN, and must have a WPS
configuration utility.
Wi-Fi Direct: Using Wi-Fi direct feature, you can transfer data
from one device to another through Wi-Fi without the need of
an access point.
3.3 Bluetooth
Bluetooth on/off: Select this option if you prefer to use
Bluetooth for your data connection. You can activate Bluetooth
by toggling the switch left/right to On/Off Bluetooth connectivity.

18
Bluetooth settings: With Bluetooth services on, you can open
the Bluetooth settings screen to:
1. Rename Phone: Make sure you have turned Bluetooth on.
Select SettingsBluetooth Bluetooth settings Device
name.
Type the name for your device in the dialog box, and then
select „OK‟.
Your new device name appears on the Bluetooth settings
screen.
2. Visibility timeout: Set the visibility time or you can select
“never time out”.
3. Show received file: You can get a path where you have
received the file through Bluetooth.
3.4 Data Usage
It provides a graphical representation of the data usage for a
specified Data Usage cycle through Mobile Internet or Wi-Fi.
Data usage refers to the amount of data uploaded or
downloaded by your device during a given period .Depending
on the device and your wireless plan, you may be charged
additional fees when your data usage exceeds your plan's limit.
To monitor your data usage, adjust your data usage settings..
.
3.5 More Settings
Airplane mode on/off: When airplane mode is selected, all
wireless connectivity is off. This icon will display in the status
bar when airplane mode is selected.
Default SMS app: You can set text message by default
Hangouts or Messaging app.

19
NFC: It stand for Near Field Communication
It allow data exchange when the phone touches another
device
P2P: Send & receive App content
Android beam: Ready to transmit app content via NFC
Tag reading & Writing: Read from or write to tag
Card emulation: get the NFC card turn on & off.
Tethering & portable hotspot: The device is used as a wireless
modem for a PC, when it‟s connected to the PC using a USB
cable.
VPN: VPN stands for Virtual Private Mode. Using this feature,
you can connect to your private network through a public
network in a secured way. You can add a VPN connection,
customize it as per your requirement and then save the
settings. Once the network is created, select the network again
to connect to it.
Using hotspot, you can share your mobile network with other
Wi-Fi enabled devices. You can connect and block the User.
Wi-Fi hotspot: Select the Wi-Fi networks which are mobile
hotspots. Apps can be restricted from using these networks
when in the background. Apps may also warn before using
these networks for large downloads.
USB tethering: Tethering refers to connecting one device to
another. Tethering allows sharing the Internet connection of
the phone or tablet with other devices such as laptops. Sharing
internet connection using USB cable is called USB tethering.
