Ibanez AEQ-TTS Quick setup guide

Preamp Information
AEQ-TTS
ENGLISH

1
AEQ-TTS
Basic Controls
Tuner Functions
Displays the note that is closest to that of the sound that was input. Tighten or loosen the string until the desired
note is displayed. Pay attention not to overtighten a string, as it may break. When in tune, a display like (g.1) below
is shown. If the tuning is at, the meter moves toward the right as in (g.2), and if the tuning is sharp, the meter
moves toward the left as in (g.3). Check whether the desired note is displayed, and adjust the tuning so that the
meter comes to the center.
Adjusts the overall volume of the Pre-Amp.
VOLUME
AEQ-TTS
Pressing this button switches the tuner ON or OFF. The tuner will automatically switch OFF when 5 minutes have
passed after switching it ON.
※Sound will not output from the output jack while the tuner is ON.
TUNER ON/OFF SWITCH
NOTE INDICATOR & TUNING GUIDE METER
Turn to the right to increase the treble frequencies for a bright, shimmery sound, or turn to the left to increase the
bass frequencies to produce a thicker, more booming sound. In the center position, the EQ is not effected making
for a natural sound.
SHAPE
fig.1 fig.2 fig.3
ENGLISH

2
fig.4 fig.5
NOTE
The battery used with the Pre-Amp needs to be replaced regularly. The battery needs to be replaced in situations
such as the following:
※The included battery is for confirming proper operation of the Pre-Amp at the factory, and may have a short lifespan.
※Discard of used batteries in accordance with local laws and regulations.
※The specifications and appearance of this product are subject to change without notification for the purpose of
improvement.
Also, be sure to remove the plug from the output jack when not using a guitar in order to prevent unnecessary
damage to the battery.
• Deterioration in sound quality or reduction in volume
• No response to tuning even when the tuner is ON
• Display does not illuminate even when the tuner is ON
• A low battery warning is displayed
ENGLISH
When the battery charge starts running low, the battery charge display changes as shown, from (g.4) to (g.5). The
Pre-Amp may not work properly if the battery charge is low, so replace the battery as soon as you can.
BATTERY INDICATOR
