IBASE Technology FWA8506 User manual

FWA8506
1U Rackmount
Enterprise Network Appliance
User’s Manual
Version 1.0
(Dec. 2017)

ii
FWA8506 User Manual
Copyright
©2017 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

FWA8506 User Manual
iii
Compliance
The product described in this manual complies with all applicable European Union
(CE) directives if it has a CE marking. For systems to remain CE compliant, only CE-
compliant parts may be used. Maintaining CE compliance also requires proper cable
and cabling techniques.
This product has been tested and found to comply with the limits for a Class A
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product complies with the current RoHS directives restricting the
use of the following substances in concentrations not to exceed 0.1%
by weight (1000 ppm) except for cadmium, limited to 0.01% by weight
(100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
FWA8506 User Manual
Important Safety Information
Carefully read the following safety information before using the device.
Setting up your system:
•Put the device horizontally on a stable and solid surface.
•Do not use this product near water or any heated source.
•Leave plenty of space around the device and do not block the ventilation
openings. Never drop or insert any objects of any kind into the openings.
•Use this product in environments with ambient temperatures between 0˚C and
40˚C.
Care during use:
•Do not place heavy objects on the top of the device.
•Make sure to connect the correct voltage to the device. Failure to supply the
correct voltage could damage the unit.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure the total ampere rating of all devices
plugged into the extension cord does not cord’s ampere rating.
•Do not spill water or any other liquids on your device.
•Always unplug the power cord from the wall outlet before cleaning the device.
•Only use neutral cleaning agents to clean the device.
•Vacuum dust and particles from the vents by using a computer vacuum cleaner.
Product Disassembly
Do not try to repair, disassemble, or make modifications to the device. Doing so will
void the warranty and may result in damage to the product or personal injury.
CAUTION
There is a danger of explosion if the lithium-ion battery is replaced with an incorrect
battery. Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries by observing local regulations.

FWA8506 User Manual
v
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, HDD, power adapter, panel
and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you encounter any technical problems and require assistance from your
distributor or sales representative, please prepare and send the following
information:
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
FWA8506 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
CAUTION .......................................................................................................iv
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................3
1.3 Packing List ............................................................................................3
1.4 Optional Accessories ..............................................................................3
1.5 Specifications..........................................................................................4
1.6 Overview.................................................................................................6
1.7 Dimensions.............................................................................................8
Chapter 2 Hardware Configuration.........................................................9
2.1 Installations...........................................................................................10
2.1.1 Memory Installation / Replacement.........................................11
2.1.2 HDD Installation / Replacement..............................................12
2.1.3 CF Card Installation / Replacement........................................13
2.1.4 Fan Module Installation / Replacement...................................14
2.2 Setting the Jumpers..............................................................................15
2.2.1 How to Set Jumpers ...............................................................15
2.3 Jumper & Connector Locations on Motherboard...................................16
2.4 Jumpers Quick Reference.....................................................................17
2.4.1 CPU SV Mode Selection (JP2)...............................................17
2.4.2 Clear CMOS Data (JP3).........................................................18
2.4.3 Clear RTC Data (JP5).............................................................19
2.4.4 AT & ATX Mode Selection (JP6).............................................20
2.5 Connectors Quick Reference................................................................21
2.5.1 COM2 Port (CN3)...................................................................22
2.5.2 PM Bus Connector (J14) ........................................................22
2.5.3 SATA Power Connector (J7, J10)...........................................23
2.5.4 System Function Connector (JP8)..........................................23

FWA8506 User Manual
vii
2.5.5 Digital I/O Port (JP10).............................................................25
2.5.6 FanPowerConnector(CPU_FAN1, SYS_FAN1, SYS_FAN2) ..25
Chapter 3 BIOS Setup............................................................................26
3.1 Introduction...........................................................................................27
3.2 BIOS Setup...........................................................................................27
3.3 Main Settings........................................................................................28
3.4 Advanced Settings................................................................................29
3.4.1 Trusted Computing.................................................................30
3.4.2 PCIE Link Configuration .........................................................31
3.4.3 NCT5523D Super IO Configuration ........................................32
3.4.4 Hardware Monitor...................................................................35
3.4.5 LAN Bypass Configuration......................................................36
3.4.6 Serial Port Console Redirection..............................................37
3.4.7 Console Port Redirection Settings..........................................38
3.4.8 USB Configuration..................................................................39
3.4.9 CSM Configuration.................................................................40
3.5 Intel RC Setup.......................................................................................41
3.5.1 Processor Configuration.........................................................42
3.5.2 System Event Log ..................................................................43
3.5.3 South Bridge Chipset Configuration........................................47
3.6 Security Settings...................................................................................49
3.7 Boot Settings.........................................................................................50
3.8 Save & Exit Settings..............................................................................51
Appendix ......................................................................................................52
A. I/O Port Address Map............................................................................53
B. Interrupt Request Lines (IRQ)...............................................................56
C. Watchdog Timer Configuration..............................................................58

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Optional Accessories
•Specifications
•Overview
•Dimensions

2
FWA8506 User Manual
1.1 Introduction
FWA8506 series is specifically designed for the network security and
management market. There are plenty of applications adopting network
security or network management as listed below.
Network Security Applications:
•Firewall
•Unified Threat Management (UTM)
•Virtual Private Network (VPN)
•Proxy Server
•Caching Server
Network Management Applications:
•Load balancing
•Quality of Service
•Remote Access Service
Photo of FWA8506

General Information
FWA8506 User Manual
3
1
1.2 Features
•1U rackmount platform designed with Intel®Atom®C3000 processor
•2 x DDR4 DIMM 2400 MHz, expandable up to 32 GB for UDIMM (ECC /
non-ECC) and up to 64 GB for RDIMM
•6 x GbE LAN ports with 2 advanced LAN Bypass pairs
•4 x 10 GbE SFP+ ports
•CF slot and PCIe (x8) expansion slot(s)
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
•FWA8506 x 1
•Power Cord x 1
•Rackmount Bracket x 2
1.4 Optional Accessories
IBASE provide optional accessories as follows. Please contact us or your
dealer if you need any.
•Console Cable (160 cm, PK1-51)
•Riser Card (IPN104)

4
FWA8506 User Manual
1.5 Specifications
Product Name
FWA8506
System
Motherboard
MBN802-8C40G
Operating
System
•Windows 10 (64-bit)
•Linux Ubuntu 16.04.3
CPU
Intel®Atom®C3758
Chipset
Integrated
Memory
•2 x DDR4 UDIMM 400 MHz, expandable to 32 GB
(ECC / non-ECC)
•2 x DDR4 RDIMM 2400 MHz, expandable to 64 GB
Storage
•Max. 2 x 2.5” HDD or SSD internal drive bay
•On-board CF slot
Network
6 x Intel®I211AT GbE
Bypass
2 x segments (LAN3 / LAN4 & LAN5 / LAN6)
Super I/O
Nuvoton NCT5523D
IPMI
N/A
Power Supply
Full range 250W ATX power supply
BIOS
AMI BIOS
TPM
1.2
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
Chassis
Steel with textured black color paint
Dimensions
(W x H x D)
438 x 44 x 340 mm (17.24” x 1.73” x 13.38”)
Weight
8 kg (17.64 lb)
Certificate
CE / FCC Class A
Front I/O Ports
Console
1 x Console port
Traffic LAN
Port
6 x RJ45 GbE LAN ports
USB
2 x USB 3.0
Rear I/O Ports
Power Inlet
1 x AC inlet 100V ~ 240V, 47 ~ 63 Hz
CF
1 x CF slot
Fan
3 x system fan module

General Information
FWA8506 User Manual
5
1
Expansion
1 x PCIe (x8) slot (4-lane)
Environment
Temperature
•Operating: 0 ~ 40 °C (32 ~ 104 °F)
•Storage: -20~ 70 °C (-4 ~ 158 °F)
Relative
Humidity
5 ~ 90%
Vibration
Protection
•Operating: 0.25 Grms / 3 ~ 500 Hz (Z-axis)
•Non-operating: 1.0 Grms / 3 ~ 500Hz (Z-axis)
Shock
Protection
Half-sinewave 50G Z-axis
All specifications are subject to change without prior notice.

6
FWA8506 User Manual
1.6 Overview
Front View
No.
Name
No.
Name
1
LCM Display with 4 buttons
5
Reserved Area for HDD/SSD
or expansion card
2
LED Indicators(from top to
bottom: Status, HDD, Power)
6
USB 3.0 Ports
3
Console Port
7
User Self-defined Button
(with GPI Signal)
4
GbE LAN Ports
Oblique View

General Information
FWA8506 User Manual
7
1
Rear View
No.
Name
No.
Name
1
System Fans
3
AC Power Inlet
2
Power Switch

8
FWA8506 User Manual
1.7 Dimensions
Unit: mm

9
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
•installations
•Information and locations of connectors

10
FWA8506 User Manual
2.1 Installations
For installation or replacement of the memory modules, HDD/SSD, CF card
and fans, you need to disassemble the device cover first by loosening 9
screws as indicated below.
Configuration inside the device:
Area-A shown below can fit optional HDD/SSD and Area-B can fit one or two
optional HDD/SSD or an expansion card .

Hardware Configuration
FWA8506 User Manual
11
2
2.1.1 Memory Installation / Replacement
If you need to install or replace a memory module, follow the instructions
below after you have removed the device cover.
1. Locate the memory slots in the device.
2. Press the ejector tab of the memory slot down and outwards with your
fingertips.
3. Hold the memory module and align the key of the module with that on the
memory slot.
4. Gently push the module in an upright position until the ejector tabs of the
memory slot close to hold the module in place when the module touches
the bottom of the slot.
To remove the module, press the ejector tabs outwards with your fingertips to
eject the module.

12
FWA8506 User Manual
2.1.2 HDD Installation / Replacement
After removing the device cover, notice Optional Area-A for 2.5” HDD/SSD
and Optional Area-B for 2.5” HDD/SSD or expansion as shown below. If you
need to install or replace an HDD/SDD or an expansion card, follow the
instructions below.
1. Remove 4 screws as indicated below for each HDD/SSD (8 screws for two
HDD/SSD).
2. Install a new HDD/SDD onto the tray and fasten the 4 screws for each
HDD/SDD.

Hardware Configuration
FWA8506 User Manual
13
2
3. Secure the tray with HDD from the bottom of the device as ilustrated
below.
2.1.3 CF Card Installation / Replacement
If you need to replace a CF card, remove the device cover firstly, locate the
CF slot and Insert the CF card to the slot.
‘To remove the CF card, pull it out with your thumb and index finger directly.
