IBASE Technology IB112 User manual

IB112
Freescale I.MX536 ARM Cortex™-A8
Embedded BOARD
USER’S MANUAL
Version 1.0

ii IB112 User’s Manual
Acknowledgments
Freescale is a registered trademark of Freescale Semiconductor
Inc.
All other product names or trademarks are properties of their
respective owners.

IB112 User’s Manual iii
Table of Contents
Introduction.......................................................5
Product Description.............................................................5
Checklist..............................................................................7
Board Dimensions...............................................................8
Installations.....................................................10
Setting the Jumpers...........................................................11
Connectors on IB112.........................................................16

iv IB112 User’s Manual
This page is intentionally left blank.

INTRODUCTION
IB112 User’s Manual 5
Introduction
Product Description
The IB112 Embedded board is based on the Freescale I.MX536
Microprocessor. I.MX536 is a high-performanceARM Cortex-A8
microprocessor with speeds up to 800 MHz. The device offers 3D
graphics acceleration while also supporting numerous peripherals,
including DDR3 and USB OTG that are well suited for industrial
applications.
The following subsystems are part of the device:
• Microprocessor unit (MPU) subsystem based on the ARM Cortex-A8
Microprocessor
•OpenGL ES 2.0 3D accelerator
• OpenVG 1.1 graphics accelerator
•Multi-format HD1080 video decoder
•Multi-format HD720 video encoder

INTRODUCTION
6 IB112 User’s Manual
IB112 FEATURES:
Freescale I.MX536 800 MHz ARM Cortex-A8 Microprocessor
1G Byte DDR3 RAM
1 x 18 bit LVDS Connector
1 x 18 bit TTL LCD Connector
2 x COM Port Connector
1 x Mini-PCIe(x1) Slot (w/ USB support Only)
2 x 10/100 Based-T Ethernet (RJ-45) Connector
12V~ 30V DC-IN Power Connector
1 x SD Card Slot, 1x Micro SD
1 x emmc FLASH (Option)
1 x USB OTG
2 x USB Host(1 x USB A-Type, 1 x pin header)
1 x HDMI Port (Option)
1 x VGA Port (Option)
1 x SATA Port (Option)
8 Bits GPIO (Option)
Resistive Touch Connector
2 x CANBUS Connector
1 x Microphone / 1 x Speaker

INTRODUCTION
IB112 User’s Manual 7
Checklist
Your IB112 package should include the items listed below.
The IB112 Embedded board
This User’s Manual

INTRODUCTION
8 IB112 User’s Manual
[
Board Dimensions
Top Side
Units: mm

INSTALLATIONS
IB112 User’s Manual 9
Installations
This section provides information on how to use the jumpers and
connectors on the IB112 in order to set up a workable system. The topics
covered are:
Setting the Jumpers.............................................................................. 11
Connectors on IB112........................................................................... 16

INSTALLATIONS
10 IB112 User’s Manual
Setting the Jumpers
Jumpers are used on IB112 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB112 and their respective functions.
Jumper Locations on IB112 .................................................................11
S1 (sw1, sw2): System Boot Configuration .........................................12
S2: System Boot Configuration (factory use only)...............................12
JP9: COM2 RS232, RS422, RS485 Selection .....................................14
JP7: USB +3.3V/+5V Power Setting...................................................14
J14: LVDS +3.3V/+5V Power Setting.................................................15
JP10: LED Brightness +5V/+9.6V/+12V Power Setting.....................15
