IBASE Technology IB895 User manual

IB895
Intel ®Cedarview-D or
Cedarview-M / NM10
3.5” Disk Size SBC
USER’S MANUAL
Version 1.1A

ii IB895 User’s Manual
Acknowledgments
AMI is a registered trademark of American Megatrends Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Intel® Sandy Bridge DC/QC Processor are registered
trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.

IB895 User’s Manual iii
Table of Contents
Introduction .......................................................1
Product Description.............................................................1
Checklist..............................................................................2
IB895 Specifications...........................................................3
Board Dimensions...............................................................4
Installations .......................................................5
Installing the Memory.........................................................6
Setting the Jumpers .............................................................7
Connectors on IB895.........................................................11
BIOS Setup.......................................................19
Drivers Installation ......................................39
Intel Chipset Software Installation Utility.........................40
VGA Drivers Installation ..................................................41
Realtek HD Audio Driver Installation...............................42
LAN Drivers Installation...................................................43
Appendix ...........................................................44
A. I/O Port Address Map...................................................44
B. Interrupt Request Lines (IRQ)......................................46
C. Digital I/O Sample Code ..............................................47
D. Watchdog Timer Configuration ...................................52

iv IB895 User’s Manual
This page is intentionally left blank.

INTRODUCTION
IB895 User’s Manual 1
Introduction
Product Description
The IB895 is a 3.5-inch single board computer based on the Intel®Atom
Cedarview chipset. The Cedar Trail is a platform that uses the Intel
Cedarview-D or Cedarview -M Processor and Intel NM10 Express
Chipset family in the desktop platforms.
The role of the processor in the system is to manage the flow of
information between the following interfaces: DDR3 System Memory
interface, DVI display interface, VGAgraphics interface, Low Voltage
Differential Signaling (LVDS) and the Direct Media Interface (DMI).
The processor supports single channel, one DDR3 SODIMMs.
The Intel®processors provide advanced performance in both computing
and graphics quality. This meets the requirement of customers in the
gaming, POS, digital signage and server market segment.
The processor is built on 32-nanometer Hi-K process technology with
Micro-FCBGA11 packaging.
IB895 FEATURES:
 Supports Intel®Cedarview -D and Cedarview-M processors
 One DDR3 SO-DIMM, 800/1066 MHz, Max. 2GB/4GB
memory*
 Integrated Graphics for DVI-I, LVDS displays
 2 x SATA Connector
 4x COM Port Connector
 2 x Mini-PCIe(x1) slot (w/ USB support)
 2x GbE (RJ-45) Connector
 1x 24V to 12V DC-IN Power Connector
*Note: IB895 with Intel Atom D2550 supports up to 4GB memory
and IB895N with Intel Atom N2600 supports up to 2GB memory.

INTRODUCTION
2 IB895 User’s Manual
Checklist
Your IB895 package should include the items listed below.
 The IB895 Embedded Flex Motherboard
 This User’s Manual
 1 CD containing chipset drivers and flash memory utility

INTRODUCTION
IB895 User’s Manual 3
IB895 Specifications
Product Name IB895 [default silk screen model # on PCB]
IB895N(N2600 onboard)
Form Factor 3.5”
CPU
Type/Speed
Intel® AtomTM DC D2550 / 1MB cache / 1.86 GHz [TDP=10W] (IB895)
Intel® AtomTM DC N2600 / 1MB cache / 1.60 GHz [TDP=3.5W]
(IB895N)
Package = FCBGA437 [ 22 mm x 22 mm] ; Cores / Threads = 2 / 4
Chipset Intel®CG82NM10 PCH [TDP = 2.1W]
Package = BGA360, 17mm x 17 mm
BIOS AMI BIOS, support ACPI Function
Memory Intel®Atom TM on-die memory controller
1x DDR3-1066 SO-DIMM socket [Horizontal type]
Maximum memory: 4GB for D2550; 2GB for N2600
Non-ECC, Unbuffered, 1.5V
VGA Intel® GMA 3650 (Gfx freq @ 640MHz) for D2550
Intel® Graphics Media Acc GMA elerator 3600 (Gfx freq @ 400MHz)
for N2600
Supports DirectX 9 Graphics, OpenGL 3.0
DVI-I x 1 (Thru VGA + ASM1422 for DVI-D via D2550 or N2600)
LVDS 24-bit dual channel via CH7511thru eDP
LAN Intel 82583V PCIe Gigabit LAN x 2
USB NM10 built-in USB 2.0 host controller, support 6 ports
Serial ATA
Ports
NM10 built-in SATA II controller, supports 2 ports
Audio Intel®NM10 PCH built-in HD Audio controller + Realtek ALC269QHD
Codec w/class-D speaker amplifier(2.3W per channel @ 5V power
supply) [7mm x 7mm @ 48-QFN] ; support 2-channel audio out + amp
LPC I/O Nuvoton NCT6627UD [128-pin QFP, 14x14x1.4mm]
- COM #1 (RS232/422/485) support ring-in with power @500 mA
(selectable for 5V or 12V) [EXAR SP339EER1 232/422/485
transceiver x 1 for jumper-less]
- COM #2 (RS232 only)
- COM #3 / COM #4 (RS-232 only)
[Hardware Monitor]
2 x Thermal inputs; 2 x Voltage monitoring
1 x Fan Header(DC Fan type)
Digital IO 4 in & 4 out
Keyboard/
Mouse Connector Pin headers
Expansion
Slots
Mini PCI-e socket x 2 (1x Full-sized+1xHalf-sized)
**Full-sized MiniPCIe(1x) support mSATA**
Edge
Connector
DVI-I, 2x RJ45, 2x USB, COM1
Onboard
Header/Connector Keyboard/mouse, 4x USB 2.0, 2x DF13 for 24-bit dual channel LVDS,
Audio, speaker, COM2, COM3/4, LPC (80-port card debugging
purpose), 2x Mini PCI-e(1x), smart battery, backlight/brightness
control, 2x power connector SATA HDD [JST type]

INTRODUCTION
4 IB895 User’s Manual
[Watchdog
Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
Power
Connector
+12V ~ +24V DC-in
Others - i-Smart function (TI MSP430G2433 MCU)
- AT24C02C EEPROM [SO8 type] via SMbus (Optional)
OS Support - Windows 7 (32-bit only)
- Linux
RoHS Yes
Board Size 102mm x 147mm
Board Dimensions

INSTALLATIONS
IB895 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the IB895 in order to set up a workable system. The topics
covered are:
Installing the Memory ........................................................................... 6
Setting the Jumpers................................................................................ 7
Connectors on IB895........................................................................... 11

INSTALLATIONS
6 IB895 User’s Manual
Installing the Memory
The IB895 board supports one DDR3 memory socket for a maximum
total memory of 2GB or 4GB DDR3 memory type.
Note: IB895 with Intel Atom DC D2550 supports up to 4GB and
IB895N with Intel Atom DC N2600 supports up to 2GB.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and
perform the following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligned
with that on the memory slot.
2. Gently push the DDR3 module in an upright position until the clips
of the slot close to hold the DDR3 module in place when the DDR3
module touches the bottom of the slot.
3. To remove the DDR3 module, press the clips with both hands.

INSTALLATIONS
IB895 User’s Manual 7
Setting the Jumpers
Jumpers are used on IB895 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB895 and their respective functions.
Jumper Locations on IB895................................................................... 8
JP2: Clear CMOS Contents................................................................... 9
JP3: BL Voltage Setting ........................................................................ 9
JP5: COM1 RS232 RI/+5V/+12V Power Setting ................................. 9
JP6: LVDS Panel Power Selection........................................................ 9
JP7: BL_ADJ_LEVEL Setting............................................................ 10
JP8: Factory use only........................................................................... 10
SW1 : LVDS Panel Type setting......................................................... 10

INSTALLATIONS
8 IB895 User’s Manual
Jumper Locations on IB895
Jumpers on IB895............................................................................ Page
JP2: Clear CMOS Contents ...................................................................9
JP3: BL Voltage Setting ........................................................................9
JP5: COM1 RS232 RI/+5V/+12V Power Setting..................................9
JP6: LVDS Panel Power Selection........................................................9
JP7: BL_ADJ_LEVEL Setting............................................................10
JP8: Factory use only...........................................................................10
SW1 : LVDS Panel Type setting.........................................................10

INSTALLATIONS
IB895 User’s Manual 9
JP2: Clear CMOS Contents
JP2 Setting Function
Pin 1-2
Short/Closed Normal
Pin 2-3
Short/Closed Clear CMOS
JP3: BL Voltage Setting
JP3 Setting Function
Pin 1-2
Short/Closed +3.3V
Pin 3-4
Short/Closed +5V
Pin 5-6
Short/Closed +12V(Default)
JP5: COM1 RS232 RI/+5V/+12V Power Setting
JP5 Setting Function
Pin 1-2
Short/Closed +12V
Pin 3-4
Short/Closed RI
Pin 5-6
Short/Closed +5V
JP6: LVDS Panel Power Selection
JP6 Setting Panel Voltage
Pin 1-2
Short/Closed 3.3V (default)
Pin 2-3
Short/Closed 5V

INSTALLATIONS
10 IB895 User’s Manual
JP7: BL_ADJ_LEVEL Setting
JP7 Setting Voltage
Open 3.3V
Close 5V(default)
JP8: Factory use only
SW1: LVDS Panel Type Setting
SW1-4 SW1-3 SW1-2 SW1-1 Panel T
yp
e
ON ON ON ON 800*600 18bit 1ch
ON ON ON OFF 1024*768 18bit 1ch
ON ON OFF ON 1024*768 24bit 1ch
ON ON OFF OFF 1280*768 18bit 1ch
ON OFF ON ON 1280*800 18bit 1ch
ON OFF ON OFF 1280*960 18bit 1ch
ON OFF OFF ON 1280*1024 24bit 2ch
ON OFF OFF OFF 1366*768 18bit 1ch
OFF ON ON ON 1366*768 24bit 1ch
OFF ON ON OFF 1440*900 24bit 2ch
OFF ON OFF ON 1440*1050 24bit 2ch
OFF ON OFF OFF 1600*900 24bit 2ch
OFF OFF ON ON 1680*1050 24bit 2ch
OFF OFF ON OFF 1600*1200 24bit 2ch
OFF OFF OFF ON 1920*1080 24bit 2ch
OFF OFF OFF OFF 1920*1200 24bit 2ch

INSTALLATIONS
IB895 User’s Manual 11
Connectors on IB895
Connector Locations on IB895............................................................ 12
CN4, CN5: Gigabit LAN (Intel 82583V)............................................ 13
CN6: USB 1/2 Connector.................................................................... 13
CN7: VGA DVI-I Connector .............................................................. 13
CN8: DB9 Connector.......................................................................... 13
CN1, CN3: SATA Connector.............................................................. 14
CN2: LCD Backlight Connector ......................................................... 14
J1: Board Input Power Connector ....................................................... 14
J2, J3: SATA HDD Power Connector................................................. 14
J5: Digital I/O Connector .................................................................... 14
J6: SPI Flash Connector (factory use only)......................................... 14
J7: Keyboard & Mouse Connector (DF11 Connector)........................ 15
J11: Smart Battery Interface Connector .............................................. 15
J12, J13: USB3/4/5/6 Connector......................................................... 15
J15: COM3, COM4 Serial Port (DF11 Connector)............................. 16
J16: COM2/RS232 Serial Port ............................................................ 16
J18: Audio Connector (DF11 Connector) ........................................... 16
J22: Amplify Connector...................................................................... 17
J23: LVDS EEPROM Flash Connector (factory use only) ................. 17
CH1, CH2: LVDS Connectors ............................................................ 17
JP1: Front Panel Connector................................................................. 18

INSTALLATIONS
12 IB895 User’s Manual
Connector Locations on IB895

INSTALLATIONS
IB895 User’s Manual 13
CN4, CN5: Gigabit LAN (Intel 82583V)
This RJ45 LAN connector (CN4 only) features for EUP LAN wakeup.
CN6: USB 1/2 Connector
CN7: VGA DVI-I Connector
CN8: DB9 Connector
(COM1) is a DB-9 connector.
Signal Name Pin # Pin # Signal Name
DCD, Data carrier detect 1 6 DSR, Data set ready
RXD, Receive data 2 7 RTS, Request to send
TXD, Transmit data 3 8 CTS, Clear to send
DTR, Data terminal ready 4 9 RI, Ring indicator
GND, ground 5 10 Not Used
COM1 is jumper-less for RS-232, RS-422 and RS-485 and configured
with BIOS Selection.
[ Pin # Signal Name
RS-232 R2-422 RS-485
1 DCD RX+ DATA-
2 RX RX- DATA+
3 TX TX+ NC
4 DTR TX- NC
5 Ground Ground Ground
6 DSR NC NC
7 RTS NC NC
8 CTS NC NC
9 RI NC NC
10 NC NC NC

INSTALLATIONS
14 IB895 User’s Manual
CN1, CN3: SATA Connectors
CN2: LCD Backlight Connector
Pin # Signal Name
1 Backlight Power
2 Backlight Enable
3 Brightness Control
4 Ground
J1: Board Input Power Connector
Pin # Signal Name
1 +12V to +24V
1
2 GND
J2, J3: SATA HDD Power Connector
Pin # Signal Name
1 +5V
2 Ground
3 Ground
4 +12V
J4: Debug 80 Port Connector (factory use only)
J5: Digital I/O Connector
Signal Name Pin Pin Signal Name
GND 1 2 VCC
OUT3 3 4 OUT1
OUT2 5 6 OUT0
IN3 7 8 IN1
IN2 9 10 IN0
J6: SPI Flash Connector (factory use only)

INSTALLATIONS
IB895 User’s Manual 15
J7: Keyboard & Mouse Connector (DF11 Connector)
Signal Name Pin # Pin # Signal Name
VCC 2 1 VCC
KBDA 4 3 MDA
KBCL 6 5 MCL
Ground 8 7 Ground
J8: DDR3 SO-DIMM Socket
J9: Mini PCIE Connector(Support mSATA)
J9 also supports mSATA. However, when J9 is used for mSATA, then
CN3 SATA port cannot be used. Only one of them can be used at one
time to support SATA.
J11: Smart Battery Interface Connector
Pin # Signal Name
1 RST
2 EXTSMI
3 Ground
4 DATA
5 CLK
J12, J13: USB3/4/5/6 Connector
Signal Name Pin # Pin # Signal Name
Vcc 1 2 Ground
D- 3 4 D+
D+ 5 6 D-
Ground 7 8 Vcc
J14: MCU Flash Connector (factory use only)

INSTALLATIONS
16 IB895 User’s Manual
J15: COM3, COM4 Serial Port (DF11 Connector)
Signal Name Pin # Pin # Signal Name
DSR3 2 1 DCD3
RTS3 4 3 RXD3
CTS3 6 5 TXD3
RI3 8 7 DTR3
NC 10 9 Ground
DSR4 12 11 DCD4
RTS4 14 13 RXD4
CTS4 16 15 TXD4
RI4 18 17 DTR4
NC 20 19 Ground
J16: COM2/RS232 Serial Port
Signal Name Pin # Pin # Signal Name
DCD, Data carrier detect 1 2 RXD, Receive data
TXD, Transmit data 3 4 DTR, Data terminal ready
GND, ground 5 6 DSR, Data set ready
RTS, Request to send 7 8 CTS, Clear to send
RI, Ring indicator 9 10 Not Used
J17: Mini PCIE Connector
J18: Audio Connector (DF11 Connector)
Signal Name Pin # Pin # Signal Name
LINEOUT_R 2 1 LINEOUT_L
Ground 4 3 JD_FRONT
LINEIN_R 6 5 LINEIN_L
Ground 8 7 JD_LINEIN
MIC-R 10 9 MIC_L
Ground 12 11 JD_MIC1
