iBeam TE-MDC User manual

TE-MDC
Product Manual

1. Box Contents
a. Camera
b. Buzzer
c. Camera harness
d. Buzzer harness
2. Connections
a.
b.
c.
d.
(Orange) parking line wire
Remove orange wire from brown connection
to remove parking lines.

3. Mounting
Install the camera approximately in the center of the vehicle
4. Specifications
Camera Dimensions
39.5 X 28.5 X 32 mm
Field of view
170
Detection Range
180
Operating Voltage
8-24V DC
Operating Current
<200mA / 12V DC
Resolution
1280 X 960 (1.2m Pixel)
Dynamic range
More than 130 dB
AV output
RCA
Warning Method
Visual and Audio
IP rating
IP68

IMPORTANT
If you are having difficulties with the installation ofthis product, please call out
Tech Support line at386-257-2956.Before doing so, looks over the instructions a second
time, and make sure the installation wasperformed exactly asthe instructions are stated.
Please have the vehicle apart and ready toperform troubleshooting steps before calling.
REV 01/27/2020
386-257-1187
