IBM ThinkPad 510Cs Service manual

IBM PC Institute
Personal Systems Reference
IBM ThinkPad Notebooks
1992 to 2001 - withdrawn
Jan ary 2001 - Version 214
IBM

IntelMobile Celeron300, 366, or 400MHz1 / 66MHz system bus
No upgrade / processor on Ball Grid Array (H-PBGA)
128KB / onboard (full speed) / synchronous pipelined burst / ECC / write-back
External 3.5" 1.44MB / connects to left side with FDD port / includes case and cable
Option: External CD-ROM / via Portable Drive Bay and 24X-10X5CD-ROM UltraslimBay Drive
Option: External DVD-ROM / via Portable Drive Bay and DVD-ROM UltraslimBay Drive
✂2609-21U ✂2609-31U ✂2609-41U
Celeron 300MHz Celeron 366MHz Celeron 400MHz
6.4GB4/ 13ms read / Ultra DMA/33 or PIO Mode 4 12.0GB / 12ms read / ATA-66 or PIO4
Windows 987Windows 987 SE Windows 987 SE
June 1999 / February 2000 November 1999 / February 2000 February 2000 / February 2001
10.4" TFT color (264.16mm) / Active Matrix
SVGA / 800x600 / 15ms refresh (typical) / 50 to 110 nits
16.7 million simultaneous colors / 250 to 1 contrast (typical)
NeoMagicMagicMedia128XD(NM2160C) / 128-bit accelerator / DDC2B /
2MB / SGRAM (embedded) / color space conversion
Simultaneous LCD and CRT26 / 180 degree tilt / no multiple-monitor support / ext SVGA to 1024x768 with 65,536 colors
64MB / 192MB33
SDRAM / non-parity / 66MHz / 3.3 volt / 64-bit
1 available socket for JEDEC 144-pin SO DIMM / std memory soldered to
motherboard / socket accessed by removing three screws and keyboard
EIDE / PCI 2.1 / supports one internal disk / customer can remove
disk for upgrade (by removing three screws on base)
Keyboard palm rest / 95% size of current standard ThinkPad keyboards /
18mm key pitch
TrackPoint/ Press-to-Select / Release-to-Select / dragging / click pace /
sensitivity / spare caps
10.2 x 8.0 x 1.05" (86 cubic inches) / 260mm x 202mm x 26.6mm
Approximately 2.98 lbs (1.35 kg) with battery and disk
IBM ThinkPad UltraCarboncasing / Top: carbon-fiber reinforced plastic;
Bottom: glass-fiber reinforced plastic
Li-Ion (3 cell) / intelligent / left side
21U: 1.9 hrs 31U: 1.8 hrs 41U: 1.7 hrs
Optional 6 cell battery 3.8 hrs (21U) or 3.6 hrs (31U) or 3.4 hrs (41U)
3.5 hrs on / 3.0 hrs off
Intel 440DX PCIset / Intel 82371EB PIIX4M (EIDE, PCI to ISA bridge, USB)
Texas InstrumentsTI1211 PCMCIA controller / NS PC97338 (FDC, IR, I/O)
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, PCMCIA, USB, audio, modem)
ISA (diskette, serial, parallel, infrared)
None
None (all standard ports already on back of system)
1 Type I or 1 Type II / CardBus 32-bit / PCMCIA 2.1 / no Zoomed Video support
One USB / one 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Ultraslim AC adapter, barrel, 3-prong, 56 watts
None
None (software support for MPEG-1 in Windows 98)
56K37 V.90 / integrated in system / Mini PCI Type IIIb /
Lucent 1646 / not voice-capable
16-bit SoundBlaster Prosupport / ESS 1946 / PCI / full duplex
One internal speaker (.5 watt)
Internal microphone / Fn+Insert and Fn+Delete volume control with mute
Microphone jack (mono) / headphone jack (stereo) / line-in jack (stereo)
Infrared port on right side / IrDA 1.1 compatible / up to 4Mbps
Power-on password / setup password / disk password / security keyhole
1 year - carry-in or ThinkPad EasyServ31 (door-to-door depot repair service)
On-site32, M-F, 8-5, next bus day (72 cities) / serv up to 5 yrs from purchase date
Processor
Processor features
L2 cache
Diskette drive
CD-ROM
DVD-ROM
Type-model
Processor
Disk - size / ms
Preload (see side)
Avail / withdrawn date
Display - size and type
Display - technology
Graphics - controller
Graphics - features
Memory - std / max
Memory - features
Disk controller / disk
Keyboard
Pointing
Dimensions
Weight2
Case material
Battery - type
Battery - life10
Charge time10
Architecture
Docking station
Port replicator
PC Card Std slots
USB / serial / parallel
Other features
Video (TV) out
MPEG decoder
Data/fax modem
Audio
Speaker
Audio features
Audio in/out jacks
Infrared ports
Security
Limited warranty11
Service options15
IBM ThinkPad240 - withdrawn
IBMThinkPad
FEATURES
Wired for Management 1.1a compliant
DMI 2.0 compliant
PC 98 compliant
ACPI ready (APM enabled)
Setup Guide, User's Reference, Windows
OS manual, and Quick Reference Card
System Status Indicators
Reset switch on bottom
Plug and Play 1.0a
Standby, suspend, redisafe, and
hibernation modes
ENERGY STAR compliant
International Warranty Service14
IBM SystemXtra, 35
24 hour / 7 day30 telephone, bulletin
board, fax, electronic, and Internet
(www.ibm.com/pc/us) support
No warranties are expressed or implied in this summary
(240)  IBM Corp. January 2001
All trademarks are the property of their respective owners
✂= Withdrawn from marketing
OPTIONS
- 32MB SO DIMM 3.3v NP SDRAM 76H0294
- 64MB SO DIMM 3.3v NP SDRAM 20L0241
- 128MB SO DIMM 3.3v NP SDRAM 01K1150
- 12GB disk, 12ms read, ATA-66 05K9245
- High-capacity 6-cell Li-Ion Battery 02K6580
- Ultraslim 56 watt AC Adapter (3-prong) 02K6545
- V.90 PC Card Modem with XJACK24 10L7393
- V.90 56K PC Card Modem with 02K4196
Cellular Capability24
- 10/100 Ethernet CardBus PC Card 08L3147
- 10/100 EtherJet plus 56K modem37 08L3167
- Turbo 16/4 Token-Ring PC Card II 34L1401
- Smart Card Security Kit 33L5075
- IBM Portable Drive Bay (UltraslimBay) 37L1511
- Zip 100MB UltraslimBay Drive 37L1507
- SuperDisk LS-120 UltraslimBay Drive 20L1929
- DVD-ROM UltraslimBay Drive 05K8890
- 24X-10X CD-ROM UltraslimBay Drive 05K9122
- IBM MultiPort USB Hub 00N8215
- IBM ThinkPad Mobile Mouse 28L3670
WINDOWS 98 PRELOAD16
- MicrosoftWindows98 (Model 21U)
or MicrosoftWindows98 Second
Edition (Model 31U and 41U)
•Online User's Guide
•ThinkPad Configuration Program
•ThinkPad Utilities
•ThinkPad on the Net
•Access ThinkPad
•IBM Update Connector
•RingCentral Fax
•IBM Registration
•IBM Global Network Dialer
•Netscape Communicator
•PC-Doctor
•ConfigSafe
•Norton AntiVirus(OEM Version)
•Universal Management Services (web)
✧Software Selections CD
✧LotusSmartSuite Millennium CD
✧Recovery CD-ROM (Windows 98)
✧Recovery CD-ROM (Windows 95)7
All models:
- C: drive is FAT16 of 2GB
- D: drive is FAT32 of remaining space
Pressing F1 during startup brings up IBM
BIOS Setup Utility
Resolution TFT 60Hz 70Hz 75Hz 85Hz
640x480 16M 16M -- 16M 16M
800x600 16M 16M -- 16M 16M
1024x768* 64K 64K 64K 64K --
1280x1024 -- -- -- -- --
* Virtual screen mode on 10.4" LCD
LCD External Monitor Color depth
- ThinkPad Provensolutions12 (visit
www.ibm.com/pc/us/thinkpad/proven)
Disks are S.M.A.R.T.29 compliant

IntelMobile Celeron450MHz1 or Intel Mobile Pentium

III 500MHz / 100MHz system bus
Celeron: 128KB / onboard (at processor speed); Pentium III: 256KB / onboard (at processor speed)
External 3.5" 1.44MB / connects to left side with FDD port / includes case and cable
Option: External via USB port or via Portable Drive Bay 2000 and 24X-10X5CD-ROM Ultrabay 2000 Drive
Option: External via Portable Drive Bay 2000 and drive option / no support for DVD in the Portable Drive Bay
2609-51U 2609-52U 2609-61U 2609-62U
Celeron 450MHz Celeron 450MHz Pentium III 500MHz Pentium III 500MHz
6.0GB4/ 13ms read / Ultra DMA/33 or PIO Mode 4 12.0GB / 12ms read / ATA-66 or PIO4
Windows 987 SE Windows 2000 Windows 987 SE Windows 2000
June 2000 June 2000 June 2000 June 2000
10.4" TFT color (264.16mm) / Active Matrix
SVGA / 800x600 / 15ms refresh (typical) / 50 to 110 nits
16.7 million simultaneous colors / 150 to 1 contrast (typical)
Silicon MotionLynx EM+ SM712G/ DDC2B /
2MB / SGRAM (embedded) / color space conversion / multiple monitor support26 for Windows 98
Simultaneous LCD and CRT26 / 180 degree tilt / external SVGA to 1024x768 with 65,536 colors
64MB / 192MB33
SDRAM / non-parity / 100MHz / 3.3 volt / 64-bit
1 available socket for JEDEC 144-pin SO DIMM / std memory soldered to
motherboard / socket accessed by removing three screws and keyboard
EIDE / PCI 2.1 / supports one internal disk / customer can remove
disk for upgrade (by removing three screws on base)
Keyboard palm rest / 95% size of current standard ThinkPad keyboards /
18mm key pitch
TrackPoint/ Press-to-Select / Release-to-Select / dragging / click pace /
sensitivity / spare caps
10.2 x 8.0 x 1.05" (86 cubic inches) / 260mm x 202mm x 26.6mm
51U/52U: approximately 2.98 lbs (1.35 kg) with battery and disk
61U/62U: approximately 3.28 lbs (1.49 kg) with battery and disk
IBM ThinkPad UltraCarboncasing / Top: carbon-fiber reinforced plastic;
Bottom: glass-fiber reinforced plastic
51U/52U: Li-Ion (3 cell); 61U/62U: Li-Ion (6 cell); All: intelligent / left side
51U/52U: 2.1 hrs 61U/62U: 4.2 hrs
51U/52U: Optional 6 cell battery for 4.2 hrs
3.5 hrs on / 3.0 hrs off
Intel 440MX PCIset (82443MX) / combines Host Bridge and PIIX4 in single
chip / TI1211 PCMCIA controller / NS PC97338 (FDC, IR, I/O) /
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, PCMCIA, USB, audio, modem)
ISA (diskette, serial, parallel, infrared)
None
None (all standard ports already on back of system)
1 Type I or 1 Type II / CardBus 32-bit / PCMCIA 2.1 / no Zoomed Video support
One USB / one 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
72 watt AC adapter
None
56K37 V.90 / Mini PCI Type IIIb / Lucent 1646
16-bit SoundBlaster Prosupport / CS4281 PCI audio / CS4297A
AC97 codec
One internal speaker (.5 watt)
Internal microphone / Fn+Insert and Fn+Delete volume control with mute
Microphone jack (mono) / headphone jack (stereo) / line-in jack (stereo)
Infrared port on right side / IrDA 1.1 compatible / up to 4Mbps
Power-on password / setup password / disk password / security keyhole
1 year - carry-in or ThinkPad EasyServ31 (door-to-door depot repair service)
Service upgrades available based on specific ThinkPad purchased
Processor
L2 cache
Diskette drive
CD-ROM
LS-120 and CD-RW
Type-model
Processor
Disk - size / ms
Preload (see side)
Available date
Display - size and type
Display - technology
Graphics - controller
Graphics - features
Memory - std / max
Memory - features
Disk controller / disk
Keyboard
Pointing
Dimensions
Weight2
Case material
Battery - type
Battery - life10
Charge time10
Architecture
Docking station
Port replicator
PC Card Std slots
USB / serial / parallel
Other features
Video (TV) out
Data/fax modem
Audio
Speaker
Audio features
Audio in/out jacks
Infrared ports
Security
Limited warranty11
Service options15
IBM ThinkPad240X - withdrawn
IBMThinkPad
FEATURES
Toll-free hardware support during the
warranty period
Personalized web-based support
Wired for Management 1.1a compliant
DMI 2.0-compliant
PC 99-compliant
ACPI ready (APM enabled)
Setup Guide, User's Reference, Windows
OS manual, and Quick Reference Card
System Status Indicators
Reset switch on bottom
Plug and Play 1.0a
Standby, suspend, redisafe, and
hibernation modes
ENERGY STAR compliant
International Warranty Service14
IBM SystemXtra, 35
24 hour / 7 day30 telephone, fax,
electronic, and Internet
(www.ibm.com/pc/us) support
No warranties are expressed or implied in this summary
(240X)  IBM Corp. January 2001
All trademarks are the property of their respective owners
Withdrawn from marketing effective February 2001
OPTIONS
- 32MB SO DIMM 100MHz NP SDRAM 20L0253
- 64MB SO DIMM 100MHz NP SDRAM 20L0254
- 128M SO DIMM 100MHz NP SDRAM 20L0255
- 12GB disk, 12ms read, ATA-66 05K9245
- High capacity 6-cell Li-Ion Battery 02K6580
- Ultraslim 72 watt AC Adapter 02K6699
- DC Auto Adapter 02K3381
- V.90 56K Intern Modem with GSM 02K4280
- 10/100 EtherJetCardBus Adapter 34L5301
- IBM 16/4 Token-Ring CardBus Adap 34L4801
- Smart Card Security Kit 33L5075
- IBM Portable Drive Bay 2000 19K4480
- IBM MultiPort USB Hub 00N8215
- IBM 340MB microdrive 00N8073
- IBM USB Portable CD-ROM Drive 33L5151
- IBM USB Mobile Mouse 33L3243
- IBM USB Numeric Keypad 33L3225
WINDOWS 98 PRELOAD16
- MicrosoftWindows98 Second
Edition
•Online User's Guide
•ThinkPad Configuration Program
•ThinkPad Utilities
•Access ThinkPad
•IBM Update Connector
•PC-Doctor
•ConfigSafe
•Norton AntiVirus(OEM Version)
•Universal Manageability Services (web)
✧Software Selections CD
✧LotusSmartSuiteMillennium CD
✧Recovery CD-ROM (Windows 98)
✧Recovery CD-ROM (Windows 95)7
All models:
- C: drive is FAT16 of 2GB
- D: drive is FAT32 of remaining space
Pressing F1 during startup brings up IBM
BIOS Setup Utility
Resolution TFT 60Hz 70Hz 75Hz 85Hz
640x480 16M 16M -- 16M 16M
800x600 16M 16M -- 16M 16M
1024x768* 64K 64K 64K 64K --
1280x1024 -- -- -- -- --
* Virtual screen mode on 10.4" LCD
LCD External Monitor Color depth
- ThinkPad Provensolutions12 (visit
www.ibm.com/pc/us/thinkpad/proven)
Disks are S.M.A.R.T.29 compliant
WINDOWS 2000 PRELOAD16
- Windows 2000Professional
•ThinkPad Utilities
•Online User's Guide
•ThinkPad Configuration Program
•PC-Doctor
•ConfigSafe
•Norton AntiVirus(OEM Version)
•IBM Update Connector
•Universal Manageability Services (web)
✧Software Selections CD
✧LotusSmartSuiteMillennium CD
✧Recovery CD-ROM (Windows 2000)
✧Recovery CD-ROM (Windows NT)40

IBM ThinkPad 300, 500, 700, 700C - withdrawn
Processor type
Processor speed
Memory cache
Coprocessor socket
Diskette drive
Price (retail USD)
Type - model
Hard drive - size
Hard drive - speed
Available date
Withdrawal date
Display - type
Display - grey scales
Display - techology
Display - light source
Display - size (diag)
Display - contrast ratio
180 degree display tilt
Memory - std / max
Mem - sockets empty
SIMM/ICs available
Keyboard / # of keys
Fn key functions
Keyboard slope
Mouse/pointing
Ext keyboard support
Dimensions
Cubic inches
Carrying case
Color
Weight (with battery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Battery - options
Architecture
External AT/MCA port
Comm Crtrdge (1 card)
Docking Station
Port replicator
Modem/serial slot
PCMCIA 2.01 slots
Visible LEDs - closed
Serial / parallel ports
APM-aware BIOS
Other features
Preinstalled software
Warranty
IBMThinkPad:
80386 SL
25 MHz
64 KB external
Yes (for 387 SL)
3.5" 1.44 MB
$ 1,999 $ 2,199
2615-065 2615-067
80 MB ?120 MB
19 ms 17 ms
Oct 92 Oct 92
Oct 93 Oct 93
VGA mono ?
64 grey scales ?
STN ?
LCD - Side-lit ?
9.5 inch ?
13 to 1 ?
Yes
4 / 12 MB 80 ns
2 sockets (parity)
2, 8 MB SIMMs
Full size alp/num/ 82
Yes (back panel)
Miniature (option)
Yes
12 (in any appl)
12.1 x 8.5 x 1.7"
175 inches
Blk nylon (option)
Charcoal grey
5.9 pounds
Nickel hydride
3 to 10 hours
10 hrs / 2 hrs
None
AT bus
No
No (fast parallel)
No
Yes
None
Modem only
Yes - batt charge
Yes / Yes (EPP)
APM-aware BIOS
Hrdw security loop
None
1 year - carry in or
EasyServ (opt onsite)
✂300
monochrome 80486 SLC2
50/25 MHz
16 KB internal
No
External 3.5" 1.44 MB
$ 1,999 $ 2,499
2603-081 2603-171
85 MB 170 MB
15 ms 15 ms
June 93 Aug 93
Dec 93 Dec 93
VGA mono
64 grey scales
STN
LCD - backlit
7.4 inch
18 to 1
Yes (external SVGA)
4 / 12 MB 80 ns
1 socket (non-parity)
4, 8 MB ICs (3.3 volt)
90% size alp/num/ 81
11 (in any appl)
No
TrackPoint II
No
10.1 x 7.2 x 1.6"
116 inches
Blk nylon (option)
Black
3.8 pounds
Sealed lead acid
3 to 9 hours
2.5 hrs / 1.2 hrs
Nickel hydrid ($49)
AT bus
No
No
No
No
No
1 Type I or 1 Type II
Yes
Yes (cable) / Yes (EPP)
APM-aware BIOS
Hibernation mode
DOS 5.02, PRODIGY
1 year - carry in or
EasyServ (opt onsite)
✂500
sub-notebook 80486 SLC ?
25 MHz
16 KB internal
Yes (for 387 SL)
3.5" 1.44 MB
$ 4,350
9552-30B
120 MB?
17 ms ❍
Oct 92
Oct 93
VGA color
256 colors 640x480
Thin film transistor
Active matrix
10.4 inch
100 to 1
Yes
4 / 16 MB 80 ns
2 sockets (parity)
2, 4, 8 MB ICs
Full size alp/num/84
None
8 degrees (legs)
TrackPoint II
Yes (with opt cable)
11.7 x 8.3 x 2.2"
214 inches
Blk nylon (option)
Black
7.6 pounds
Nickel hydride
2 to 4 hours
1.5 hrs / 1.4 hrs
Yes - status indicator
Micro Channel
Yes
Yes (black)
Yes (3550-002) blk
Yes (black)
Yes
None
Yes
Yes / Yes (DMA)
APM-aware BIOS
Hrdw security loop
DOS 5.02, PRODIGY
3year - carry in or
EasyServ (opt onsite)
✂700C
color TFT
80486 SLC ?
25 MHz
16 KB internal
Yes (for 387 SL)
3.5" 1.44 MB
$ 2,750 $ 2,950
9552-300 9552-301
82 MB ?122 MB ?
17 ms ❍17 ms ❍
Oct 92 Oct 92
Oct 93 Oct 93
VGA mono ?
64 grey scales ?
STN ?
LCD - backlit ?
9.5 inch ?
18 to 1 ?
Yes
4 / 16 MB 80 ns
2 sockets (parity)
2, 4, 8 MB ICs
Full size alp/num/ 84
None
8 degrees (legs)
TrackPoint II
Yes (with opt cable)
11.7 x 8.3 x 1.9"
185 inches
Blk nylon (option)
Black
6.5 pounds
Nickel hydride
3.8 to 7.5 hours
3 hrs / 2 hrs
Yes - status indicator
Micro Channel
Yes
Yes (black)
Yes (3550-002) blk
Yes (black)
Yes
None
Yes
Yes / Yes (DMA)
APM-aware BIOS
Hrdw security loop
DOS 5.02, PRODIGY
3year - carry in or
EasyServ (opt onsite)
✂700
monochrome
ThinkPad EasyServ:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight).
STN = Super twisted nematic; = Upgradeable; ❍= Removable; ✂ = Withdrawn
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(1THINKW) Compiled by Roger Dodson, IBM. May 1994
?
FEATURES OF 700/700C and 720/720C
3 year international warranty
700/720 mono upgradeable to TFT color
700/700C upgradeable to 486SLC2 50/25
Upgradeable to 120, 160, 240, or 340 MB
Removable hard disk
Pressure activated TrackPoint II
Optional battery w/ power status indicators
Quick Charger holds 2 batt; discharge button
Coupon book with $4,000 in savings
FEATURES OF ALL PRODUCTS
IBM or dealer warranty/service
30 day money back guarantee
24 hour / 7 day fax support
24 hour / 7 day bulletin board support
24 hour / 7 day telephone support at
1-800-772-2227
Suspend/resume mode; battery life indicator
Non-disruptive battery exchange
Simultaneous LCD and external CRT
US EPA Energy Star compliant
International warranty
FEATURES OF 300
Upgradeable to TFT active color; 8.4"
Ethernet on planar for 10baseT,10base2
Upgradeable to 120 MB (80 MB version)
External VGA is SVGA (to 1024 x 768)
2 level password security
Hot key setup in any application
Standby mode and rest mode
Rest mode lasts up to 2 weeks
FEATURES OF 500
Most powerful sub-notebook with 486SLC2
Lightweight 3.8 pounds
Hibernation mode savesmemory tothe hard
drive and shuts system off
External VGA is SVGA (to 800 x 600)
Std external floppy (9 oz) plugs into back
Personalizednameplateinmoldedindentation
Coupon book with $4,000 in savings
Self charging battery with integrated wall
plug and no memory effect (081, 171)
ThinkPad 500 models 081 and 171 withdrawn
due to problems with the sealed lead acid
battery and replaced by models 08N and 17N
with a nickel hydride battery
The 700/720 family hard disks, batteries, and docking station are NOT compatible with 360, 750, 755. The 700/720 memory IS compatible with
360, 750, 755.

Pentium

133/66 MHz(P54CSLM) / 64 bit to transfers to L2 cache and memory
None
256 KB / write-back / direct mapped / 7 ns / sychronous pipelined burst
External FDD port (works with standard external diskette on CD-ROM-based model; or use if upgrade to CD-ROM)
Internal 3.5" 1.44 MB (on left side) External 3.5" 1.44 MB (connect to rear)
None(upgradeavailable) None (upgradeavailable) 10 x CD-ROM / bootable(left side) / CAV
LaCrosse LaCrosse LaCrosse
2600-100 2600-300 2600-200
Windows95OSR2
June1997/January 1998
1.08GB / 13ms read; 14ms write / PIO Mode 4
EIDE / busmaster / PCI 2.1 / supports one internal disk
11.3"DualScan SVGAcolor 11.3" TFT SVGA color 11.3" Dual Scan SVGA color
C&T65550 HiQV32/ 64 bit SVGA accelerator / 1 MB EDO DRAM/ 70 ns
PCI 2.1 / interpolation / color space conversion
Simultaneous LCD and CRT /180 degree tilt / Zoomed Video support
External SVGA to 1024x768 with 256 colors
16MB / 64MB / one 16MB SO-DIMM is installed in one of two sockets
60 ns / non-parity / 3.3 volt / EDO / memory installed from bottom of system
1 socket available for two JEDEC 144 pin EDO SO-DIMM of 8, 16, or 32MB
Full size alp/num / 85 keys (9 Fn key functions)
Large palm rest / keyboard remains flat (no sloop) / no liftup keyboard
TrackPoint III/ no drag lock keys
Integratedpalmrest/ external keyboard support (nooptionalcable)
11.7 x 8.9 x 1.9" (198 cubic inches)
6.6 pounds (3.0 kg) 6.6 pounds (3.0 kg) 7.0 lbs (3.2 kg)
NiMH / non-intelligent / battery unique to 310 / insert from right side
2.5hours
3.5 to 10 hrs / 2.8 hrs / no non-disruptive battery exchange
ISA(audio, diskette, serial, parallel) / ALI

AladdinIII M1521/M1523 chipset
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, PCMCIA)
NS PC87336VJG (diskette, serial, parallel) / TI PCI1131 CardBus (PCI)
None
None
2 Type I or 2 Type II or 1 Type III / PCMCIA 2.1 compatible / PC Card Standard 95
CardBus 32-bit PCI / Zoomed Video support in lower slot
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Universal AC Adapter 3 prong (45 watts) with barrel connector (slim) /
APM-aware BIOS / APM 1.2 / Selectable boot / Acer

BIOS
None
None
None
16-bit audio chip / 18 voice MIDI FM synthesis / Yamaha YMF715
Internal stereo speakers / .5 watt / Fn key volume control
Input jack (3.5 mm) / stereo output jack (3.5 mm) / stereo mic jack (3.5 mm)
None
None
Power-onpassword /Setup password(for NotebookManager andBIOS Utility)/
Diskette and disk write protect and disable /
Locking device keyhole on back (Kensingtoncable lock)
Windows95withapplications (listed on right)
1 year - carry-in
Processor type
Processorupgrade
L2cache
ExternalFDD port
Diskettedrive
CD-ROMdrive
Codename
Price
Type- model
Preload(seeside)
Avail/withdrawn date
Disk - size / ms
Diskcontroller
Display - size and type
Display- techology
Graphics- controller
Graph-arch/data path
Gaphics - features
Graphics - external
Memory - std / max
Memory-features
Memory-upgrade
Keyboard / # of keys
Keyboardslope
Pointingdevice
Palmrest
Dimensions
Weight
Battery - type
Battery - life
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIAslots
Serial/parallelports
Otherfeatures
Videoin/out
MPEGdecoder
Data/faxmodem
Audiosupport
Audiojacks
Telephone
Infraredports
Security
Preinstalledsoftware
Warranty
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(310) IBM Corp. December 1997
✂✂
✂✂
✂ 310
11.3" Dual Scan SVGA color
IBM
ThinkPad 310 (EMEA) - withdrawn
WINDOWS 95 PRELOAD
- MicrosoftWindows 95 OSR2 (FAT16)
- NotebookManager
- PhoenixCardManager
- (no diskette factory)
1. IBMAnti-Virus
2. IntelliQuestRegistrationMailer
3. ThinkPadCustomizationIcon
- LotusSmartSuiteCD-ROM
- Recovery CD-ROM with boot diskette
- Windows95CD-ROM(noinstallation)
11.3" SVGA color / 640x480 or 800x600
256 simultaneous colors / Dual Scan / 30 to 1 contrast ratio 11.3" SVGA color / 640x480 or 800x600 / 65,536 sim colors Black Matrix TFT - active matrix / 100 to 1 contrast ratio
FEATURES OF 310 MODELS
Plugand Play 1.0a
Standbyandhibernationmodes
ColorLEDindicator
US EPA Energy Star compliant
Personalizednameplateindention
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(http://www.pc.ibm.com)support
IBManddealerwarranty/service
✂✂
✂✂
✂ 310D
11.3" Dual Scan SVGA color / 10 x CD-ROM
✂✂
✂✂
✂ 310
11.3" TFT SVGA color
BIOS Utility is entered by holding F2 while the
ThinkPadlogo is displayed afterpower on.
Fn + F1 = Hot key help
Fn + F2 = Brightness/contrast
Fn + arrows = Adjust brightness/contrast
Fn + F3 = LCD/CRT/Simultaneous
Fn + F4 = Fuelgauge
Fn + F5 = Audiovolume
Fn + arrows = Adjust volume
Fn + F6 = Power mgmt and system info
Fn + F7 = Standby
Fn + F8 = Hibernation
Fn + Esc = Close Hot key icon
CompatibleinThinkPad310family:
- 2.1GBHDD13/14 ms (user upgradeable) 11J8643
- NiMHBattery 11J8639
- AC Adapter, 3 prong w/o power cord 11J8699
- AC Adapter, 3 prong with US power cord 11J8702
- 8MBSODIMM3.3vNPEDO64-bit,gold 11J8635
- 16MBSODIMM3.3vNPEDO64-bit, gold 11J8636
- 32MBSODIMM3.3vNPEDO64-bit, gold 11J8637
- 10 x CD-ROM w/ external FDD/cable 11J8676
(dealerinstallableonly)
- PCMCIA28.8KbpsInternational 42H4319
IBM

ThinkPad

:
Disk is not removable, but it can be
upgraded via a dealer or service center
(notcustomerinstallable).
Systemdoesnothave non-disruptive
battery exchange. Battery can be
changed while system is off, in
hibernation,orunder ACpower.

PentiumMMX133/66MHz1PentiumMMX150/60MHz PentiumMMX133/66MHz
None
MMX technology / P55CLM / 64-bit to transfers to L2 cache and memory
256KB / write-back / direct mapped / 7ns / sychronous pipelined burst
External FDD port (works with standard external diskette on CD-ROM-based model; or use if upgrade to CD-ROM)
Internal 3.5" 1.44MB (on left side) External 3.5" 1.44MB (connect to rear)
None(upgradeavailable) 10X5CD-ROM / bootable (left side) / CAV
LaCrosse-2 LaCrosse-2
2600-400 2600-600 2600-500
Windows95 OSR2
November1997 /July 1998
1.6GB4/ 13ms read; 14ms write / PIO Mode 4 / SMART
EIDE / busmaster / PCI 2.1 / supports one internal disk
12.1" Dual Scan SVGA color 11.3" TFT SVGA color 12.1" Dual Scan SVGA color
C&T65550 HiQV32/ 64-bit SVGA accelerator / 1MB EDO DRAM/ 70ns
PCI 2.1 / interpolation / color space conversion
Simultaneous LCD and CRT /180 degree tilt / Zoomed Video support
External SVGA to 1024x768 with 256 colors
16MB / 64MB / one 16MB SO-DIMM is installed in one of two sockets
60ns / non-parity / 3.3 volt / EDO / memory installed from bottom of system
1 socket available for two JEDEC 144 pin EDO SO-DIMM of 8, 16, or 32MB
Full size alp/num / 85 keys (9 Fn key functions)
Large palm rest / keyboard remains flat (no sloop) / no liftup keyboard
TrackPointIII / no drag lock keys
Integratedpalmrest/ external keyboard support (nooptionalcable)
11.7 x 8.9 x 2.0" (208 cubic inches) / 298 mm x 227 mm x 49 mm
6.6 pounds (3.0 kg) 6.6 pounds (3.0 kg) 7.1 lbs (3.2 kg)
3.0hours 3.5hours 3.0hours
3.5 to 10 hrs / 2.0 hrs / no non-disruptive battery exchange
NiMH / non-intelligent / battery unique to 310 / insert from right side
ISA(audio, diskette, serial, parallel) /ALIAladdinIIIM1521/M1523 chipset
PCI2.1/32-bit/33MHz(EIDE,graphics,PCMCIA)
NS PC87336VJG (diskette, serial, parallel) / TI PCI1131 CardBus (PCI)
None
None
2 Type I or 2 Type II or 1 Type III / PCMCIA 2.1 compatible / PC Card Standard 95
CardBus 32-bit PCI / Zoomed Video support in lower slot
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Universal AC Adapter 3 prong (45 watts) with barrel connector (slim) /
APM-aware BIOS / APM 1.2 / Selectable boot / AcerBIOS
None
None
None
16-bit audio chip / 18 voice MIDI FM synthesis / Yamaha YMF715
Internal stereo speakers / .5 watt / Fn key volume control
Input jack (3.5 mm) / stereo output jack (3.5 mm) / stereo mic jack (3.5 mm)
None
None
Power-onpassword /Setup password(for NotebookManager andBIOS Utility)/
diskette and disk write protect and disable / security keyhole /
electronicpersonalization
MicrosoftWindows95with applications (listed on right)
1 year - carry-in
Processor type
Processorupgrade
Processorfeatures
L2cache
ExternalFDD port
Diskettedrive
CD-ROMdrive
Codename
Price
Type- model
Preload(seeside)
Avail/withdrawn date
Disk - size / ms
Diskcontroller
Display - size and type
Display- techology
Graphics- controller
Graph-arch/data path
Gaphics - features
Graphics - external
Memory - std / max
Memory-features
Memory-upgrade
Keyboard / # of keys
Keyboardslope
Pointingdevice
Palmrest
Dimensions
Weight2
Battery - life
Charge time - on / off
Battery - type
Architecture
DockingStation
Portreplicator
PCMCIAslots
Serial/parallelports
Otherfeatures
Videoin/out
MPEGdecoder
Data/faxmodem
Audiosupport
Audiojacks
Telephone
Infraredports
Security
Preinstalledsoftware
Limitedwarranty11
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(310E)  IBM Corp. September 1998
310E
12.1" Dual Scan SVGA color
IBM
ThinkPad310E and 310ED (EMEA) - withdrawn
WINDOWS 95 PRELOAD16
- MicrosoftWindows 95 OSR2 (FAT16)
- NotebookManager
- (no diskette factory)
1. IBMAnti-Virus
2. IntelliQuestRegistrationMailer
3. ThinkPadCustomizationIcon
CD-ROMsincludedinshippingcarton:
- ApplicationCD-ROM(includes
W95/W31/DOSdevicedrivers,
preloadedapplications)
- Windows95CD-ROM(no installation;
includesSetupBootDiskette)
12.1" SVGA color / 640 x 480 or 800 x 600
256 simultaneous colors / Dual Scan / 30 to 1 contrast ratio 11.3" SVGA color / 640 x 480 or 800 x 600 / 65,536 sim colors Black Matrix TFT - active matrix / 100 to 1 contrast ratio
FEATURES
Plugand Play 1.0a
Standbyandhibernationmodes
ColorLEDindicator
ENERGY STAR compliant
Personalizednameplateindention
InternationalWarrantyService14
IBMSystemXtra
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(www.ibm.com/pc/us)support
IBManddealerwarranty/service
310ED
12.1" Dual Scan SVGA color / 10X CD-ROM
310E
11.3" TFT SVGA color
BIOS Utility is entered by holding F2 while the
ThinkPadlogo is displayed afterpower on.
Fn + F1 = Hot key help
Fn + F2 = Brightness/contrast
Fn + arrows = Adjust brightness/contrast
Fn + F3 = LCD/CRT/Simultaneous
Fn + F4 = Fuelgauge
Fn + F5 = Audiovolume
Fn + arrows = Adjust volume
Fn + F6 = Power mgmt and system info
Fn + F7 = Standby
Fn + F8 = Hibernation
Fn + Esc = Close Hot key icon
OPTIONS
- 2.1GB disk, 13/14ms (user upgradeable) 11J8643
- 3.2GB disk, 13/14ms (user upgradeable) 05K8864
- NiMHBattery 11J8639
- AC Adapter, 3 prong without power cord 11J8699
- 16MBSODIMM3.3vNPEDO64-bit, gold 11J8636
- 32MBSODIMM3.3vNPEDO64-bit, gold 11J8637
- 10X CD-ROM w/ external FDD/cable 11J8676
(dealerinstallableonly)
- 20X-8XPortableCD-ROM 1969010
- 20X-8XPortableStereoCD-ROM 1969011
- PCMCIA33.6KbpsInternationalData/Fax 42H4319
- PCMCIA 33.6Kbps Modem w/ XJACK 55H6759
IBMThinkPad:
Systemdoesnothave non-disruptive
battery exchange. Battery can be
changed while system is off, in
hibernation,orunder ACpower.
Nosuspend mode;has standbyand
hibernationmode

PentiumMMX 166/66MHz1
None
MMX technology / P55CLM / 64-bit to transfers to L2 cache and memory
256KB / write-back / direct mapped / 7ns / sychronous pipelined burst
External FDD port (works with standard external diskette on CD-ROM-based model; or use if upgrade to CD-ROM)
Internal 3.5" 1.44MB (on left side) External 3.5" 1.44MB (connect to rear)
None(dealerupgradeavailable) 20X-8X5x CD-ROM / bootable (left side) / CAV
2600-A00 2600-C00 2600-B00
Windows95 OSR2
March1998/September1998
2.1GB4/ 13ms read; 14ms write / PIO Mode 4 / SMART
EIDE / busmaster / PCI 2.1 / supports one internal disk
12.1" Dual Scan SVGA color 12.1" TFT SVGA color 12.1" Dual Scan SVGA color
C&T65550HiQV32/64-bit SVGA accelerator
1MB EDO DRAM / 70ns
PCI 2.1 / interpolation / color space conversion
Simultaneous LCD and CRT /180 degree tilt / Zoomed Video support
External SVGA to 1024 x 768 with 256 colors
16MB /64MB 32MB / 64MB
One 16MB SO-DIMM is installed in one of two sockets
60ns / non-parity / 3.3 volt / EDO / memory installed from bottom of system
1 socket available for two JEDEC 144 pin EDO SO-DIMM of 16 or 32MB
Full size alp/num / 85 keys (9 Fn key functions)
Large palm rest / keyboard remains flat (no sloop) / no liftup keyboard
TrackPointIII / no drag lock keys
Integratedpalmrest/ external keyboard support (nooptionalcable)
11.7 x 8.9 x 2.0" (208 cubic inches) / 298 mm x 227 mm x 50 mm
6.6 pounds (3.0 kg) 6.6 pounds (3.0 kg) 6.9 lbs (3.1 kg)
3.0hours 2.8hours 3.0hours
3.5 to 10 hrs / 2.0 hrs / no non-disruptive battery exchange
NiMH / non-intelligent / battery unique to 310 / insert from right side
ISA(audio, diskette, serial, parallel) /ALIAladdinIIIM1521/M1523 chipset
PCI 2.1 / 32-bit / 33 Mhz (EIDE, graphics, PCMCIA)
NS PC87336VJG (diskette, serial, parallel) / TI PCI1131CardBus (PCI)
None
None
2 Type I or 2 Type II or 1 Type III / PCMCIA 2.1 compatible / PC Card Standard 95
CardBus 32-bit PCI / Zoomed Video support in lower slot
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Universal AC Adapter 3 prong (45 watts) with barrel connector (slim) /
APM-aware BIOS / APM 1.2 / Selectable boot / Acer

BIOS
None
None
None
16-bit audio chip / 18 voice MIDI FM synthesis / Yamaha YMF715
Internal stereo speakers / .5 watt / Fn key volume control
Input jack (3.5 mm) / stereo output jack (3.5 mm) / stereo mic jack (3.5 mm)
None
None
Power-onpassword /Setup password(for NotebookManager andBIOS Utility)/
diskette and disk write protect and disable / security keyhole /
electronicpersonalization
MicrosoftWindows95with applications (listed on right)
1 year - carry-in
Processor type
Processorupgrade
Processorfeatures
L2cache
ExternalFDD port
Diskettedrive
CD-ROMdrive
Price
Type- model
Preload(seeside)
Avail/withdrawn date
Disk - size / ms
Diskcontroller
Display - size and type
Display- techology
Graphics- controller
Graphics - memory
Graph-arch/data path
Gaphics - features
Graphics - external
Memory - std / max
Memory-implement
Memory-features
Memory-upgrade
Keyboard / # of keys
Keyboardslope
Pointingdevice
Palmrest
Dimensions
Weight2
Battery - life
Charge time - on / off
Battery - type
Architecture
DockingStation
Portreplicator
PCMCIAslots
Serial/parallelports
Otherfeatures
Videoin/out
MPEGdecoder
Data/faxmodem
Audiosupport
Audiojacks
Telephone
Infraredports
Security
Preinstalledsoftware
Limitedwarranty11
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(310E98)  IBM Corp. September 1998
310E
12.1" Dual Scan SVGA color
IBM
ThinkPad310E and 310ED (EMEA) - Spring 1998 - withdrawn
WINDOWS 95 PRELOAD16
- MicrosoftWindows 95 OSR2 (FAT16)
- InternetExplorer4.0
- NotebookManager
- (no diskette factory)
1. IBMAnti-Virus
2. IntelliQuestRegistrationMailer
3. ThinkPadCustomizationIcon
CD-ROMsincludedinshippingcarton:
- ApplicationCD-ROM(includes
W95/W31/DOSdevicedrivers,
preloadedapplications)
- Windows95CD-ROM(no installation;
includesSetupBootDiskette)
12.1" SVGA color / 640 x 480 or 800 x 600
256 simultaneous colors / Dual Scan / 30 to 1 contrast ratio 12.1" SVGA color / 640 x 480 or 800 x 600 / 65,536 sim colors Black Matrix TFT - active matrix / 100 to 1 contrast ratio
FEATURES
Plugand Play 1.0a
Standbyandhibernationmodes
ColorLEDindicator
ENERGY STAR compliant
Personalizednameplateindention
InternationalWarrantyService14
IBMSystemXtra
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(www.ibm.com/pc/us)support
IBManddealerwarranty/service
310ED
12.1" Dual Scan SVGA color / CD-ROM
310E
12.1" TFT SVGA color
BIOS Utility is entered by holding F2 while the
ThinkPadlogo is displayed afterpower on.
Fn + F1 = Hot key help
Fn + F2 = Brightness/contrast
Fn + arrows = Adjust brightness/contrast
Fn + F3 = LCD/CRT/Simultaneous
Fn + F4 = Fuelgauge
Fn + F5 = Audiovolume
Fn + arrows = Adjust volume
Fn + F6 = Power mgmt and system info
Fn + F7 = Standby
Fn + F8 = Hibernation
Fn + Esc = Close Hot key icon
OPTIONS
- 2.1GBdisk13/14ms(userupgradeable) 11J8643
- 3.2GBdisk13/14ms(userupgradeable) 05K8864
- NiMHBattery 11J8639
- AC Adapter, 3 prong without power cord 11J8699
- 16MBSODIMM3.3vNPEDO64-bit, gold 11J8636
- 32MBSODIMM3.3vNPEDO64-bit, gold 11J8637
- 10X CD-ROM w/ external FDD/cable 11J8676
(dealer installable only)
- 20X-8X CD-ROM w/ external FDD/cable 05K8867
(dealer installable only)
- 20X-8XPortableCD-ROM 1969010
- 20X-8XPortableStereoCD-ROM 1969011
- PCMCIA33.6KbpsInternationalData/Fax 42H4319
- PCMCIA 33.6Kbps Modem w/ XJACK 55H6759
IBMThinkPad:
Systemdoesnothave non-disruptive
battery exchange. Battery can be
changed while system is off, in
hibernation,orunder ACpower.
Nosuspend mode;has standbyand
hibernationmode

PentiumMMX133/66MHz1Pentium MMX166/66MHz
None
MMX technology / P55CLM / 64-bit to transfers to L2 cache and memory
256KB / write-back / direct mapped / 7ns / sychronous pipelined burst
External FDD port (works with standard external diskette on CD-ROM-based model; or use if upgrade to CD-ROM)
External 3.5" 1.44MB (connect to rear)
10x5CD-ROM / bootable (left side) / CAV 20X-8X5CD-ROM / bootable (left side) / CAV
2600-50U 2600-B0U
087944375975 087944395997
Windows95 OSR2 Windows95OSR2.5
November1997 / May1998 March1998/September1998
1.6GB4/ 13ms/14ms / PIO 4 / SMART 2.1GB / 13ms read; 14ms write / PIO Mode 4 / SMART
EIDE / busmaster / PCI 2.1 / supports one internal disk
12.1" Dual Scan SVGA color
C&T65550 HiQV32/ 64-bit SVGA accelerator / 1MB EDO DRAM/ 70ns
PCI 2.1 / interpolation / color space conversion
Simultaneous LCD and CRT /180 degree tilt / Zoomed Video support
External SVGA to 1024 x 768 with 256 colors
16MB / 64MB / one SO-DIMM used 32MB / 64MB / one SO-DIMM used
60ns / non-parity / 3.3 volt / EDO / memory installed from bottom of system
1 socket available for JEDEC 144 pin EDO SO-DIMM of 8, 16, or 32MB
Full size alp/num / 85 keys (9 Fn key functions)
Large palm rest / keyboard remains flat (no sloop) / no liftup keyboard
TrackPoint

III / no drag lock keys
Integratedpalmrest/ external keyboard support (nooptionalcable)
11.7 x 8.9 x 2.0" (208 cubic inches) / 298 mm x 227 mm x 50 mm
7.1 lbs (3.2 kg) 6.9 lbs (3.1 kg)
3.0hours
3.5 to 10 hrs / 2.0 hrs / no non-disruptive battery exchange
NiMH / non-intelligent / battery unique to 310 / insert from right side
ISA(audio, diskette, serial, parallel) /ALIAladdinIIIM1521/M1523 chipset
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics, PCMCIA)
NS PC87336VJG (diskette, serial, parallel) / TI PCI1131 CardBus (PCI)
None
None
2 Type I or 2 Type II or 1 Type III / PCMCIA 2.1 compatible / PC Card Standard 95
CardBus 32-bit PCI / Zoomed Video support in lower slot
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
Universal AC Adapter 3 prong (45 watts) with barrel connector (slim) /
APM-aware BIOS / APM 1.2 / Selectable boot / AcerBIOS
None
None 56Kbps PC Card modem
ActionTecDataLink/K56flex
16-bit audio chip / 18 voice MIDI FM synthesis / Yamaha YMF715
Internal stereo speakers / .5 watt / Fn key volume control
Input jack (3.5 mm) / stereo output jack (3.5 mm) / stereo mic jack (3.5 mm)
None
None
Power-onpassword /Setup password(for NotebookManager andBIOS Utility)/
diskette and disk write protect and disable / security keyhole /
electronicpersonalization
MicrosoftWindows95with applications (listed on right)
1 year - carry-in
Processor type
Processorupgrade
Processorfeatures
L2cache
ExternalFDD port
Diskettedrive
CD-ROMdrive
Price
Type- model
UPCcode
Preload(seeside)
Avail/withdrawn date
Disk - size / ms
Diskcontroller
Display - size and type
Display- techology
Graphics- controller
Graph-arch/data path
Gaphics - features
Graphics - external
Memory - std / max
Memory-features
Memory-upgrade
Keyboard / # of keys
Keyboardslope
Pointingdevice
Palmrest
Dimensions
Weight2
Battery - life
Charge time - on / off
Battery - type
Architecture
DockingStation
Portreplicator
PCMCIAslots
Serial/parallelports
Otherfeatures
Videoin/out
Data/faxmodem
Audiosupport
Audiojacks
Telephone
Infraredports
Security
Preinstalledsoftware
Limitedwarranty11
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(310ED)  IBM Corp. August 1998
IBM
ThinkPad310ED (Retail models) - withdrawn
WINDOWS 95 PRELOAD16
- MicrosoftWindows 95 OSR2 (FAT16)
-Internet Explorer 4.0
-AOL, AT&T WorldNet, CompuServ
-Media Player
- ActiveMovie (MPEG-1, AVI)
- Video for Windows
- CD Audio Player
-MIDISequencer
1. LotusSmartSuite97
- WordPro Work Processor
-1-2-3Spreadsheet
-FreelanceGraphics
-ApproachDatabase
-OrganizerScheduler
-ScreenCam
2. IBMAnti-Virus
3. PointCast(withThinkPadChannel)
4. ThinkPadCustomizationIcon
5. NotebookManager
6. Ergonomics
7. IntelliQuestRegistrationMailer
8. PasswordProtectedMarketingDemo
9. PhoenixCardManager
- (no diskette factory)
CD-ROMsincludedinshippingcarton:
- ApplicationCD-ROM(includesLotus
SmartSuite97,W95/W31/DOSdevice
drivers,preloadedapplications)
- Windows95CD-ROM(no installation;
includesSetupBootDiskette)
12.1" SVGA color / 640 x 480 or 800 x 600
256 simultaneous colors / Dual Scan / 30 to 1 contrast ratio
FEATURES
Plugand Play 1.0a
Standbyandhibernationmodes
ColorLEDindicator
ENERGY STAR compliant
Personalizednameplateindention
Year2000ready
InternationalWarrantyService14
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(www.ibm.com/pc/us)support
IBManddealerwarranty/service
BIOS Utility is entered by holding F2 while the
ThinkPadlogo is displayed afterpower on.
Fn + F1 = Hot key help
Fn + F2 = Brightness/contrast
Fn + arrows = Adjust brightness/contrast
Fn + F3 = LCD/CRT/Simultaneous
Fn + F4 = Fuelgauge
Fn + F5 = Audiovolume
Fn + arrows = Adjust volume
Fn + F6 = Power mgmt and system info
Fn + F7 = Standby
Fn + F8 = Hibernation
Fn + Esc = Close Hot key icon
OPTIONS
- 2.1GBdisk13/14ms(userupgradeable) 11J8643
- 3.2GBdisk 12ms (user upgradeable) 05K8864
- NiMHBattery 11J8639
- AC Adapter, 3 prong, US pwr cord, 45 wa 11J8702
- 16MB SO DIMM 3.3v NP EDO 64-bit, gold 11J8636
- 32MB SO DIMM 3.3v NP EDO 64-bit, gold 11J8637
- PCMCIA33.6KbpsInternationalData/Fax 42H4319
- PCMCIA 33.6Kbps Modem w/ XJACK 55H6759
- 56K PC Card Modem Kit 04K0052
IBMThinkPad:
Systemdoesnothave non-disruptive
battery exchange. Battery can be
changed while system is off, in
hibernation,orunder ACpower.
Nosuspend mode;has standbyand
hibernationmode
✂ 310ED ✂ 310ED
✂ = Withdrawn from marketing

IntelDX4
75/25 MHz/ 3.3 volt
16 KB internal (no L2 cache)
IntegratedinDX4
None
3.5"1.44MB (not removable)
None
$$$$
2610-EYF 2610-EYG 2610-FYF 2610-FYG
360MB 540MB 360MB 540 MB
13 ms 13 ms 13 ms 13 ms
Sep 1995 / Jan 1996 Sep 1995 / Apr 1996
VGA color/ 640 x 480 VGA color / 640 x 480
256simultaneouscolors 256simultaneouscolors
Dual Scan - passive matrix BlackMatrix TFT - active matrix
10.4inch 10.4inch
20 to 1 100 to 1
Yes Yes
WD90C24A Rev C with 1 MB DRAM
Western Digital / External SVGA to 1024 x 768 with 256 colors (up to 60 Hz)
VL-Bus local bus / 32 bit / Simultaneous LCD and CRT
4 MB / 20 MB 70 ns / non-parity / 5 volt
1 socket
4, 8, 16 MB IC DRAM
Full size alp/num / 85 keys / quiet keyboard
7 (in any appl)
None
TrackPoint III(no drag lock)
Yes(withoptionalcable)
11.7x 8.3 x 1.9" 11.7 x8.3 x 2.0"
184inches 194inches
Black Black
5.2pounds 5.5pounds
Nickelhydride(NiMH)/non-intelligent
2.5 to 5 hours
2 hrs / 1.5 hr
AT bus (ISA)
None
None
1 Type I or 1 Type II or 1 Type III
Yes (one 9 pin) 16550A / Yes (EPP)
APM-awareBIOS/Selectable boot
ACadapter,35 watts, worldwide,3 pin, not wallmount
Audiobeeponly
Power-onpassword
Lockingdevicekeyhole(KensingtonMicroSavercablelock)
IBM DOS 7.0, Windows3.11, and all appls listed to right:
1 year - ThinkPad EasyServ only
None
TheThinkPad 345 family has the same
physicaldesign as the ThinkPad 340
PCCard Director(EasyPlaying) is preinstalled
and on the utility diskette for DOS, Windows and
OS/2. It provides:
①automaticconfig of many PCMCIA cards;
②visual/audibleconfirmationofinsertion/
removal of cards;
③abilitytoautomaticallylaunchanappl(e.g.
asyncemulation)whencardinserted;
④status and info on PCMCIA cards installed.
Easy-Setupis entered by holding F1 when
turningon. Easy-Setup, BIOS,and diagnostics
arelocated in flash memory.
Hard disk and diskette drive are not removable.
Keyboarddoes not lift up.
Processor type
Processorspeed
Memorycache
Coprocessorsocket
Processor/ L2 upgrade
Diskettedrive
RemovableCD-ROM
Price
Type- model
IDE disk - size
Hard drive - speed
Avail/withdrawn date
Display - type
Display - colors
Display- techology
Display- diagonal size
Display - contrast ratio
180degreedisplaytilt
Graphics- controller
Graphics - vendor
Graph-arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Fn key functions
Keyboardslope
Mouse/pointing
Extkeyboard support
Dimensions
Cubicinches
Color
Weight(withbattery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA2.1 slots
Serial/parallelports
Otherfeatures
Audiosupport
Security
Preinstalledsoftware
Warranty
Warrantyoptions
FEATURES OF 345 FAMILY
3 power saving modes: standby, suspend,
and hibernation
Personalizednameplateinmoldedindentation
Batterylifeindicator
Non-disruptivebatteryexchange
US EPA Energy Star compliant
IBM ThinkPad 345 (non-US) - withdrawn
IBM

ThinkPad

::
::
:✂345CS ✂345C
dual scan color TFT color
PREINSTALLEDAPPLICATIONS
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(345) Compiled by Roger Dodson, IBM. May 1996
ThinkPad EasyServ

:customer calls 1-800-565-3344 in Canada, courier service picks up
ThinkPad at any location, IBM repairs and mails back (no shipping charges, most shipping is
overnight, 3 business day average turnaround).
❏❏
❏❏
❏= Upgradeable; = Removable; ✂= Withdrawn from marketing
❍
ThinkPad 345 is a fast, lightweight, full function,
TFT or dual scan color notebook at a very
attractivepricepoint
➭➭
➭➭
➭EntrypricedThinkPad
➭➭
➭➭
➭Large color 10.4" dual scan or TFT display
➭➭
➭➭
➭FastIntelDX4 75/25 MHz
➭➭
➭➭
➭Lightweight (5.2 or 5.5 pounds)
➭➭
➭➭
➭TrackPointIII
HELPWARE
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBMor dealerwarranty/service
OnlineHousecall (remote diagnostics)
30daymoney back guarantee
- IBM PC DOS 7.0
- Windows3.11
- IBM PC Card Director for PCMCIA
- IBMThinkPadDemo
- ThinkPad features; Diskette Factory
1. Lotuscc:Mail, for the IBM Global
network,
2. LotusOrganizer1.12
3. LotusScreenCam1.0,
4. TritonCoSessionHost,
5. PRODIGY,
6. SofNetFaxWorks3.0
7. AlphaNetFollowFax
8. SedonaREPRINT
9. VideoforWindows1.1Runtime
Memoryupgradedvia
1 open socket for IC DRAM
memory card for 20 MB max
Optionsfor345:
- 4 MB IC DRAM 70 ns Parity 92G7232
- 8 MB IC DRAM 70 ns Parity 92G7233
-16 MB IC DRAM 70 ns Parity 92G7234
- 4 MB IC DRAM 70 ns non-Parity 92G7236
- 8 MB IC DRAM 70 ns non-Parity 92G7237
-16 MB IC DRAM 70 ns non-Parity 92G7424
- NiMHBattery Pack (Worldwide) 85G7637
- NiMH Battery Pack (Japan) 95G7638
- NiMH Battery Pack (EMEA) 85G7605
- 35 watt AC Adapter (Worldwide) 85G6680
- 35 watt AC Adapter (Japan) 85G6682
- 35 watt AC Adapter (EMEA) 85G6683
IC DRAM parity memory from the above
optionswill workbut withoutparity
Fn key functions:
- Fuelguage(battery)
- Standbymode
- Suspendmode
- Audiovolume
- LCD or CRT or both
- Powermanagementmode
- Hibernationmode

Processor type
Processorspeed
Memorycache
Coprocessorsocket
Diskettedrive
Price (retail USD)
Type- model
Hard drive - size
Hard drive - speed
Avail/withdrawaldate
Display - type
Display - grey scales
Display- techology
Display - light source
Display - size (diag)
Display - contrast ratio
180degreedisplaytilt
Graphics- controller
Graphics - vendor
Graphics- arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Fn key functions
Keyboardslope
Mouse/pointing
Extkeyboard support
Dimensions
Cubicinches
Carryingcase
Color
Weight(withbattery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
DockingStation
Portreplicator
Modem/serialslot
PCMCIA2.01 slots
Visible LEDs - closed
Serial/parallelports
APM-awareBIOS
Otherfeatures
Preinstalledsoftware
Warranty
SOFTWAREPREINSTALLED ON
500-17N (after July 1, 1994) and 510Cs
IBM DOS 6.3, Windows 3.1,
Demo,and8 appls:
①Lotus cc:Mail, ② Lotus Organizer 1.12,
③Lotus ScreenCam 1.0,④Official Airline
Guide Flight Disk 1.0, ⑤ Triton CoSession
Host,⑥PRODIGY,⑦America Online,
⑧SofNet FaxWorks 3.0
EasyPlaying (PC Card Director) is
preloadedand on the utility diskette for DOS,
Windows and OS/2; it provides status and info
on PCMCIA cards installed. In Windows and
OS/2, it can register an appl for PCMCIA
cardsand execute them automatically. Auto
ConfiguratorandMemoryDeviceDriver
enablessupported PCMCIA cardsby sensing
themautomatically (so do not needto install
theirdevice drivers).
All: 80486 SL (no math co)
All: 25 MHz
All: 8 KB internal (no L2)
All: No
All: 3.5"1.44 MB
$1,499 $1,899
2618-J0A 2618-L0A
125MB 250MB
15 ms 12 ms
June 93 / withd Sep 94
VGAmono
64 grey scales
STN
LCD - Backlit
9.5inch
18 to 1
Yes (external SVGA)
All: 65530 / External VGA is ISO capable (75Hz)
All: Chips& Tecnologies, Inc.
All: Local bus / 16 bit / Peripheral Interface
All: 4 / 20 MB 80 ns
All: 1 socket (non-parity)
All: 4, 8, 16 MB SIMMs
All: Fullsizealp/num/85
All: 2 (in any appl)
All: Yes (back panel)
All: TrackPointII


All: Yes (with opt cable)
11.7 x 8.3 x 1.9"
184inches
Manyoptions
Black
5.2pounds
Nickelhydride(NiMH)
2.7 to 9 hours
2 hrs / 1 hr
All: AT bus (ISA)
All: No
All: No
All: Modemonly
All: 1 Type I or 1 Type II
All: Yes
All: Yes / Yes
All: APM-awareBIOS
All: WallmountACadapter
All: Personalizednameplateinindentation
All: Couponbookwith $4,000 insavings
All: IBM DOS 5.02, PRODIGY
All: 1 year - carry in or EasyServ (opt onsite)
$ 1,599➷$ 1,999 ➷
2618-N0A 2618-P0A
125MB 250MB
15 ms 12 ms
June 93 / withd Sep 94
VGA color
256 colors 640 x 480
STN - passive matrix
LCD - Backlit
9.2inch
13 to 1; Single scan
Yes (external SVGA)
11.7 x 8.3 x 2.0"
194inches
Manyoptions
Black
5.8pounds
Nickelhydride(NiMH)
2 to 7.5 hours
2 hrs / 1 hr
BlueLightning486BL2-50
50/25MHz
16 KB internal (no L2 cache)
No
External 3.5" 1.44 MB (9 oz.)
$ 1,799➷
2604-C2U
200MB
17 ms
June 94 / w May 95
VGA color
256 colors 640 x 480
STN - passive matrix
LCD - backlit
7.7inch
14 to 1; Single scan
Yes (external SVGA)
WD90C24A2 / 1 MB video mem
WesternDigital
VL-Bus / VESA 32 bit local bus
4 / 20 MB 80 ns
1 socket (non-parity)
4, 8, 16 MB ICs (3.3 volt)
90%sizealp/num/81
15 (in any appl)
No
TrackPointII
Yes(onMultiPort)
10.1 x 7.2 x 1.7"
124inches
Manyoptions
Black
4.0pounds
Nickelhydride(NiMH)
2.5 to 8 hours
2.5 hrs / 1.5 hrs
AT bus (ISA)
No
Yes(MultiPortshipsstandard)
No
1 Type I or 1 Type II
Yes
Yes (MultiPort) / Yes (EPP)
APM-awareBIOS
Microsaversecurityconnector
Hibernationmode
Personalizednameplateinindentation
Personalgreetingscreenatstartup
IBM DOS 6.3, Windows 3.1,
Demo,and 8 appls listedbelow
1 year - carry in or
EasyServ (optional onsite for $40 a year)
IBM ThinkPad 350, 350C, 500, 510Cs - withdrawn
IBM

ThinkPad

::
::
:
80486SLC2
50/25MHz
16 KB internal (no L2)
No
External 3.5"1.44MB
$ 799➷$ 999➷
2603-08N 2603-17N
85 MB 170 MB
15 ms 15 ms
Dec 93 / withd Jan 95
VGAmono
64 grey scales
STN
LCD - backlit
7.24inch
18 to 1
Yes (external SVGA)
WD90C26
WesternDigital
ISA 16 bit
4 / 12 MB 80 ns
1 socket (non-parity)
4, 8 MB ICs (3.3 volt)
90%sizealp/num/81
11 (in any appl)
No
TrackPointII
No
10.1 x 7.2 x 1.6"
116inches
Manyoptions
Black
3.4pounds / 3.7 (170M)
Nickelhydride(NiMH)
3.5 to 9 hours
3 hrs / 1.5 hrs
AT bus (ISA)
No
No
No
1 Type I or 1 Type II
Yes
Yes (cable) / Yes (EPP)
APM-awareBIOS
Hibernationmode
Personalizednameplate
Coupon book w/ sav
IBM DOS 6.1,PRODIGY
After July 1 only on
17N: see below
1 year - carry in or
EasyServ (opt onsite)
✂350
monochrome
Suspend/resumebuttn
abovekeyboard
Fn+F1=Configuration
Utility
Fn+F2=Reversevideo
Fn+F3=Contrasttext
✂500
sub-notebook ✂510Cs colorsub-notebook
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business days average turnaround). Overnight repair option in US available for $99.
➷Price decrease effective July 13 (350C) and Aug 18 (510), 1994.
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(1THINK) Compiled by Roger Dodson, IBM. April 1995
✂350C
passivecolor
Fn+ Q =Incbrightness
Fn+A =Decbrightness
Fn+ W= Inc contrast
Fn+ S =Dec contrast
EnterSetup by
CTRL+ALT+F3
fromDOS prompt
(withdrawn500
hadsealedlead
acidbattery)
FEATURES OF 500 and 510Cs FEATURES OF ALL PRODUCTS
Suspend/resumemode;batterylifeindicator
Non-disruptivebatteryexchange
SimultaneousLCDandexternalCRT
US EPA Energy Star compliant
Internationaltravelerswarranty
IBMor dealerwarranty/service
30daymoney back guarantee
24 hour / 7 day fax support
24 hour / 7 day bulletin board support
24 hour / 7 day telephone support at
1-800-772-2227
ThinkPad 500 memory (4, 8 MB IC 3.3 volt) is
compatiblewithThinkPad510Cs.
ThinkPad510CsMultiPortisNOTcompatible
withThinkPad500.
500: External cable has 2 connectors for
serialport and external diskette drive
510: External cable has 1 connector for
externaldiskette drive (serial port on
MultiPort).
MultiPort: A port replicator with connectors for
diskettedrive,externaldisplay,mouse/
keyboard, and serial device (ships with 510Cs).
Plugs into 160 pin connector on back.
3power saving modes: doze,suspend,
hibernation.
Batteries in 500 and 510Cs are NOT
compatible
✂Withdrawnfrom marketing
Fn+F2 = Fuelguage
Fn+F3 = Setup
Fn+F4 = Suspend
Fn+F5 = Speaker
Fn+F6 = Sysrequest
Fn+F7 = CRT/LCD
Fn+F8 = Revvideo
Fn+ F9 = Num Lock
Fn+ F10= Scroll Lock
Fn+ F11= Print Scrn
Fn+F12= Hibernation

All: 80486 SX (no math coprocessor)
All: 33MHz 3.3 volt (SL Enhanced)
All: 8KB internal (no L2 cache)
All: No
All: 3.5" 1.44MB ❍
$1,899
2619-I15
125MB ??
??
?
15ms ❍
June94
VGAmono
64greyscales640x480
STN
LCD - Backlit
9.5inch
18 to 1
Yes
All: WD90C24A2 with 1MB DRAM / Graphics WinMarks 4.0 = 3.7
All: Western Digital / External SVGA to 1024x768 with 256 colors
All: VL-Bus / 32-bit VESA local bus / Simultaneous LCD and CRT
All: 4 / 20MB 70ns
All: 1 socket (non-parity)
All: 4, 8, 16MB ICs (5.0 volts)
All: Fullsizealp/num/85
All: 10 (in any appl)
All: Yes (legs pop out)
All: TrackPointII
All: Yes(withoptionalcable)
11.7 x 8.3 x 1.7"
165inches
Manyoptions
Black
5.6pounds
Nickelhydride
4.6 to 10 hours
2 hrs / 1.5 hr
All: AT bus (ISA)
All: No
All: No
All: 2400 data / 4800 receive fax / 9600 send fax
All: 1 Type I or 1 Type II or 1 Type III
All: Yes (one 9 pin) / Yes
All: APM-awareBIOS/Selectable boot
All: WallmountACadapterwithoutpowercordwithretractableprongs,30watts
All: Hibernation mode saves memory to disk and shuts off system
All: Power-on password / Hard disk password / Hardware security loop / PCMCIA card lock / Optional Security Base
All: MSDOS 6.21, Windows 3.1, Demo, and 8 applications:
① Works for Windows, ② ThinkPad Fitness,
③ ThinkPad Index, ④Official Airline Guide Flight Disk

1.0,
⑤ Triton CoSessionsHost, ⑥ PRODIGY,⑦ America OnlineSM, ⑧ SofNet FaxWorks3.0
All: 1 year - carry in to retailer or EasyServ(optional onsite for $40)
$3,399 $3,749
2619-L50 2619-L55
125MB ??
??
?250MB ??
??
?
15ms ❍14ms ❍
July 94 July 94
VGA color
256 colors 640 x 480
TFT - active matrix
LCD - Backlit
8.4inch
100 to 1
Yes
11.7 x 8.3 x 1.9"
185inches
Manyoptions
Black
6.1pounds
Nickelhydride
3.5 to 7 hours
2 hrs / 1.5 hr
$2,599 $2,849
2619-K20 2619-K25
170MB ??
??
?250MB ??
??
?
15ms ❍14ms ❍
June94 June94
VGA color
256 colors 640 x 480
STN - passive matrix
LCD - Backlit
9.5 inch Dual scan
20 to 1
Yes
11.7 x 8.3 x 2.0"
194inches
Manyoptions
Black
6.2pounds
Nickelhydride
3 to 7 hours
2 hrs / 1.5 hr
FEATURES
3 power saving modes: standby, suspend,
and hibernation
Personalizednameplateinmoldedindentation
External VGA is ISO capable (75Hz)
Upgradeabledisks:170MB,250MB,340MB,
540MB, 810MB (all 2.5 inch)
Batterylifeindicator
Non-disruptivebatteryexchange
US EPA Energy Star compliant
IBMor retailerwarranty/service
30daymoney back guarantee
24 hour / 7 day fax support
24 hour / 7 day bulletin board support
24 hour / 7 day telephone support at
1-800-772-2227
Processor type
Processorspeed
Memorycache
Coprocessorsocket
Removablediskette
Price (retail USD)
Type- model
Removable disk - size
Hard drive - speed
Availabledate
Display - type
Display - grey scales
Display- techology
Display - light source
Display - size (diag)
Display - contrast ratio
180degreedisplaytilt
Graphics- controller
Graphics - vendor
Graph-arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Fn key functions
Keyboardslope
Mouse/pointing
Extkeyboard support
Dimensions
Cubicinches
Carryingcase
Color
Weight(withbattery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
DockingStation
Portreplicator
Data/faxmodem
PCMCIA2.01 slots
Serial/parallelports
Otherfeatures
Security
Preinstalledsoftware
Warranty
IBM ThinkPad 355 - withdrawn
IBM
ThinkPad::
::
:355
monochrome
Compatibleinall355,360,750,and 755
family:
- Harddisks (170, 250, 340, 540, 810MB)
- 1.44MBdiskettedrive
- CDPDMobileCommunicationsModule
- Keyboard/mouseconnector
- 355 battery does not work in ThinkPad 750/
755,but 750/755 battery will work in 355
- QuickCharger
- ACAdapter
MemoryfromThinkPad 350, 500, and510Cs
is NOT compatible in 355 (or 360).
ICMemory from ThinkPad700, 720, 750,
and 755 will work but without parity.
ThinkPad750and 755options
compatibleONLYinThinkPad355C:
- TVtuner
TheThinkPad 355 family has the same
physicaldesign as the ThinkPad 360, 750, and
755.
EasyPlaying (PC Card Director) is
preinstalledand on the utility diskette for DOS,
Windows and OS/2; it provides status and info
on PCMCIA cards installed. In Windows and
OS/2, it can register an appl for PCMCIA cards
andexecutethemautomatically. Auto
ConfiguratorandMemoryDeviceDriver
enablessupported PCMCIA cardsby sensing
themautomatically (so do not needto install
their device drivers). This utility ships with
ThinkPads355,360,510Cs, and 755 family.
Easy-Setupis entered by holding F1 when
turningon. Easy-Setup, BIOS,and diagnostics
arelocated in Flashmemory.
??
??
?❍
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back within 2 business days (no shipping charges, most
shipping is overnight). STN = Super twisted nematic; = Upgradeable; = Removable
All models withdrawn effective May 1995
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(355) Compiled by Roger Dodson, IBM. August 1998
355Cs
dual scan color 355C TFTcolor
Liftable(pop-up)
keyboard
toaccess
andremove:
①diskettedrive
②disk
③battery
④memory
ALL 355 MODELS
Anintelligentbattery(standardinThinkPad750
and755) is optional. The ThinkPad 355 battery
is lower cost, easy to use because no storage-
switch control is required, and
shows % of
remaining power (compared to hours of remaining
power).
Fn + F7 = Extdisplay/LCD
Fn + F8 = Reversevideo(mono)
Fn + F9 = Hi-intensitytext(mono)
Fn + F11 = Powermgmt
Fn + F12 = Hibernationmode
Fn + F2 = Fuelguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F5 = Audiooff/down
Fn + F6 = Audioon/up
Diskette drive can be removed ① to
reduceweight,
② toinsert cellular modem
(CDPD),
③ (355C only) to insert TV Tuner
(on screen TV/VCR playback), or
④ to add
otherthirdpartyoptions.

All: 80486 SX (no math coprocessor)
All: 33 MHz 3.3 volt (SL Enhanced)
All: 8 KB internal (no L2 cache)
All: No
All: 3.5" 1.44 MB❍
$1,899 $2,299
2620-00D 2620-00F
170MB ❏❏
❏❏
❏340MB ❏❏
❏❏
❏
15 ms ❍14 ms ❍
May 94 / withd May 95
VGAmono
64greyscales640x480
STN
LCD - Backlit
9.5inch
18 to 1
Yes
All: WD90C24A2 with 1 MB DRAM / Graphics WinMarks 4.0 = 3.7
All: Western Digital / External SVGA to 1024 x 768 with 256 colors
All: VL-Bus / 32 bit VESA local bus / Simultaneous LCD and CRT
All: 4 / 20 MB 70 ns
All: 1 socket (non-parity)
All: 4, 8, 16 MB ICs (5.0 volts)
All: Fullsizealp/num/85
All: 10 (in any appl)
All: Yes (legs pop out)
All: TrackPointII
All: Yes(withoptionalcable)
11.7 x 8.3 x 1.7"
165inches
Manyoptions
Black
5.6pounds
Nickelhydride
4.6 to 10 hours
2 hrs / 1.5 hr
All: AT bus (ISA)
All: Yes(Dock I and II; same as 750/755)
All: Yes (Port Replicator I and II)
All: No
All: 2 Type I or 2 Type II or 1 Type III
All: Yes (one 9 pin) / Yes (EPP)
All: APM-awareBIOS/Selectable boot
All: WallmountACadapterwithoutpowercordwithretractableprongs,30watts
All: Hibernation mode saves memory to disk and shuts off system
All: Power-on password / Hard disk password / Hardware security loop / PCMCIA card lock / Optional Security Base
All: IBMDOS 6.3, Windows 3.1, Demo, and 8 applications:
①Lotus

cc:Mail, e-mail for Advantis

network,②Lotus Organizer 1.12,
③LotusScreenCam 1.0, ④Official Airline Guide Flight Disk

1.0,
⑤Triton CoSessionsHost,⑥PRODIGY, ⑦America OnlineSM,⑧SofNet FaxWorks3.0
All: 1 year - carry in or EasyServ (optional onsite for $40) / International travelers warranty
$2,349 $2,749
2620-20D 2620-20F
170MB ❏❏
❏❏
❏340MB ❏❏
❏❏
❏
15 ms ❍14 ms ❍
May 94 / withd Dec 95
VGA color
256 colors 640 x 480
STN - passive matrix
LCD - Backlit
9.5 inch Dual scan
20 to 1
Yes
11.7 x 8.3 x 2.0"
194inches
Manyoptions
Black
6.2pounds
Nickelhydride
3 to 7 hours
2 hrs / 1.5 hr
Processor type
Processorspeed
Memorycache
Coprocessorsocket
Removablediskette
Price (retail USD)
Type- model
Removable disk - size
Hard drive - speed
Availabledate
Display - type
Display - grey scales
Display- techology
Display - light source
Display - size (diag)
Display - contrast ratio
180degreedisplaytilt
Graphics- controller
Graphics - vendor
Graph-arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Fn key functions
Keyboardslope
Mouse/pointing
Extkeyboard support
Dimensions
Cubicinches
Carryingcase
Color
Weight(withbattery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
DockingStation
Portreplicator
Modem/serialslot
PCMCIA2.01 slots
Serial/parallelports
Otherfeatures
Security
Preinstalledsoftware
Warranty
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
STN = Super twisted nematic; ❏❏
❏❏
❏= Upgradeable; = Removable
➷Price decrease effective January 26, 1995; ✂Withdrawn from marketing
FEATURES OF 360 FAMILY
3 power saving modes: standby, suspend,
and hibernation
Personalizednameplateinmoldedindentation
External VGA is ISO capable (75 Hz)
Upgradeabledisks:170MB, 250 MB, 340MB,
540 MB, 810 MB (all 2.5 inch)
Batterylifeindicator
Non-disruptivebatteryexchange
US EPA Energy Star compliant
Internationaltravelerswarranty
IBMor dealerwarranty/service
30daymoney back guarantee
24 hour / 7 day fax support
24 hour / 7 day bulletin board support
24 hour / 7 day telephone support at
1-800-772-2227
Winstone 94 for 360C = 26.4
The360Psupports
penbasedapplications
$2,899 $3,399
2620-50D 2620-50F
170 MB ❏❏
❏❏
❏340 MB ❏❏
❏❏
❏
15 ms ❍14 ms ❍
June 94 / withd Dec 95
VGA color
256 colors 640 x 480
STN - passive matrix
LCD - Backlit
9.5 inch Dual scan
18 to 1
Yes
Incudesuntethered
stylus to write on
pen-enabledscreen
11.7 x 8.3 x 2.1"
204inches
Manyoptions
Black
6.8pounds
Nickelhydride
3.3 to 7 hours
2 hrs / 1.5 hr
$ 2,299➷$ 2,599 ➷
2620-30D 2620-30F
170MB ❏❏
❏❏
❏340MB ❏❏
❏❏
❏
15 ms ❍14 ms ❍
June 94 / withd Dec 95
VGA color
256 colors 640 x 480
TFT - active matrix
LCD - Backlit
8.4inch
100 to 1
Yes
11.7 x 8.3 x 1.9"
185inches
Manyoptions
Black
6.1pounds
Nickelhydride
3.5 to 7 hours
2 hrs / 1.5 hr
IBM ThinkPad 360 - withdrawn
IBM

ThinkPad

::
::
:✂360
monochrome ✂360Cs dual scan color ✂360C TFTcolor ✂360P colorpen
Fn + F7 = Extdisplay/LCD
Fn + F8 = Reversevideo(mono)
Fn + F9 = Hi-intensitytext(mono)
Fn + F11 = Powermgmt
Fn + F12 = Hibernationmode
Fn + F2 = Fuelguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F5 = Audiooff/down
Fn + F6 = Audioon/up
Apreconfigured,
multimedia360Cs;
AvailableJune94;
WithdrawnMay1995
Part#2337290
$5,299
IncludedwiththeIBM
TravelingMultimedia:
Hardware:
- 360Cs(allfeatures
listedon left)
- 16bit Mwaveaudio
chipon adapter card
- Stereoin/outjacks
- 340MBremovable
harddisk
- 8 MB memory (4 MB
std + 4 MB IC DRAM)
- 14.4Data/Fax
modem(PCMCIA)
- Dock I (Docking
Station)
- CD-ROM/XA-double
speedandKodak
PhotoCD
multisession
- Dock I Carrying Case
- InterlinkProPoint
Software:
- AsymetrixCOMPEL
(onscreenmultimedia
presentations)
- AsymetrixMediaBlitz!
(libraryof media clips)
- LapLinkV
- PictureFactory
- TalkWorks
- SoundEffectsLibrary
- ClickART2000
✂TravelingMultimedia
preconfiguredsystem
ALL 360 MODELS
Liftable(pop-up)
keyboard
toaccess
andremovediskette
drive,disk,battery,
andmemory
The removed diskette drive can be used externally via the
optional'FDDExternalKit'(includes cable and enclosure;
$135) to the Port Replicator Model I and II and Dock I.
Diskette drive can be removed
① to reduce weight, ② to insert
cellular modem (CDPD),
③ (360C only) to insert TV Tuner (on
screen TV/VCR playback), or
④ to add other third party options.
360P includessoftware to left and
①PenDOS

2.2,②IBM ThinkWrite,
③Windowsfor Pen Computing1.0
Compatibleinall360,750,and 755 family:
- Hard disks (170, 250, 340, 540, 810 MB)
- 1.44MB diskette drive
- Dock I and Dock II
- Port Replicator I and Port Replicator II
- CDPDMobileModule(notpen models)
- FDD(diskette) External Attachment kit
- Keyboard/mouseconnector
- 360 battery does not work in ThinkPad 750/
755,but 750/755 battery will work in 360
- QuickCharger
- ACAdapter
MemoryfromThinkPad 350, 500, and510Cs
is NOT compatible in 360. IC Memory from
ThinkPad700, 720, 750, and 755 will work but
withoutparity.
ThinkPad750and 755options
compatibleONLYinThinkPad360C:
- TV tuner and AD card
TheThinkPad 360 family has the same
physicaldesign asthe ThinkPad750 and755.
EasyPlaying (PC Card Director) is
preinstalledand on the utility diskette for DOS,
Windows and OS/2; it provides status and info
on PCMCIA cards installed. In Windows and
OS/2, it can register an appl for PCMCIA cards
andexecutethemautomatically. Auto
ConfiguratorandMemoryDeviceDriver
enablessupported PCMCIA cardsby sensing
themautomatically (so do not needto install
their device drivers). This utility ships with
ThinkPads360,510Cs,and755family.
Easy-Setupis entered by holding F1 when
turningon. Easy-Setup, BIOS,and diagnostics
arelocated in Flashmemory.
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(360THINK) Compiled by Roger Dodson, IBM. December 1995
❍
Anintelligentbattery(standardinThinkPad750
and755) is optional. The ThinkPad 360 battery
is lower cost, easy to use because no storage-
switch control is required, and
shows % of
remaining power (compared to hours of remaining
power).

80486DX2
50/25 MHz 3.3 volt (SL Enhanced)
8 KB internal (no L2 cache)
Integratedin486DX2
3.5" 1.44 MB❍/ supports internal 2.88 MB diskette
None
$ 2,399➷$ 2,699➷$ 3,049➷
2620-80D 2620-80F 2620-80G
170 MB ❏❏
❏❏
❏340 MB ❏❏
❏❏
❏540 MB ❏❏
❏❏
❏
14 ms ❍ 14 ms ❍ 14 ms ❍
Oct 94 / withdrawn Dec 95
VGA color/ 640 x 480
256simultaneouscolors
Dual scan- passive matrix
9.5inch
20 to 1
Yes
WD90C24A or A2 with 1 MB DRAM
Western Digital / External SVGA to 1024 x 768 with 256 colors (up to 75 Hz)
VL-Bus local bus / 32 bit / Simultaneous LCD and CRT
4 MB / 20 MB 70 ns / non-parity / 5.0 volt
1 socket
4, 8, 16 MB ICs
Full size alp/num / 85 keys
8 (in any appl)
Yes (legs pop out)
TrackPointII
Yes(withoptionalcable)
11.7 x 8.3 x 2.0"
194inches
Black
6.2pounds
Nickelhydride(NiMH)
2.9 to 7 hours
2 hrs / 1.5 hr
AT bus (ISA)
Dock I and II
Port Replicator I and II
No
2 Type I or 2 Type II or 1 Type III
Yes (one 9 pin) 16550B / Yes (EPP)
APM-awareBIOS/Selectable boot
SomemodelswillhaveWallmountACadapterwithoutpowercordwith
retractableprongs,30watts
Hibernation mode saves memory to disk and shuts off system
Power-on password / Hard disk password / Hardware security loop /
PCMCIA card lock / Optional Security Base
IBM DOS 6.3, Windows3.11, and all appls listed to right:
1 year - carry in or EasyServ (optional onsite for $40)
$2,799 $3,099 $3,449
2620-90D 2620-90F 2620-90G
170 MB ❏❏
❏❏
❏340 MB ❏❏
❏❏
❏540 MB ❏❏
❏❏
❏
14 ms ❍14 ms ❍14 ms ❍
Oct 94 / withdrawn Dec 95
VGA color / 640 x 480
256simultaneouscolors
TFT - active matrix
8.4inch
100 to 1
Yes
11.7 x 8.3 x 1.9"
185inches
Black
6.1pounds
Nickelhydride(NiMH)
3.2 to 7 hours
2 hrs / 1.5 hr
Processor type
Processorspeed
Memorycache
Coprocessorsocket
Removablediskette
RemovableCD-ROM
Price (retail USD)
Type- model
Removable disk - size
Hard drive - speed
Availabledate
Display - type
Display - colors
Display- techology
Display - size (diag)
Display - contrast ratio
180degreedisplaytilt
Graphics- controller
Graphics - vendor
Graph-arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Fn key functions
Keyboardslope
Mouse/pointing
Extkeyboard support
Dimensions
Cubicinches
Color
Weight(withbattery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
DockingStation
Portreplicator
Modem/serialslot
PCMCIA2.1 slots
Serial/parallelports
Otherfeatures
Security
Preinstalledsoftware
Warranty
IBM ThinkPad 360CSE / CE - withdrawn
IBM

ThinkPad

::
::
:✂360CSE
dual scan color ✂360CE TFTcolor The 360CSE / CE is the same as the 360(oldermodels)except:
360 360CSE / CE
Mono, Dual scan, TFT, Pen Dual scan, TFT
486SX - 33 MHz 486DX2 -50/25 MHz
Nomath cop possible Integratedmathcop
170, 340 MB std models 170, 340, 540 MB std
Morepreloadedappls
ALL 360 MODELS
Compatiblein all 360 family, 360CSE / CE,
750 family, 755 family, 755CSE / CE, 755CD:
- Disks: 170 MB IDE disk 66G2849
250 MB IDE disk 84G2391
340 MB IDE disk 66G2849
540 MB IDE disk 84G2150
810 MB IDE disk 84G8250
- Dock I (1 slot / 1 bay) 3450001
- Dock II (2 slot / 2 bay) 84G3587
- Port Replicator I (w/ PCMCIA) 66G3510
- PortReplicatorII 66G3520
- 1.44MBdiskette stdinnewer
- 2.88MBdiskette 66G0108
Options for 360 (not pen), 360CSE / CE,
750 (not pen), 755, 755CSE / CE:
- CDPDMobilemodule 71G2560
Memoryfrom ThinkPad 350, 500, and 510Cs is
NOT compatible in 360. IC Memory from
ThinkPad700, 720, 750, and 755 will work
butwithoutparity.
Options only for TFT models - 360C, 360CE,
750C,755C,755CE,755CD
- TV Tuner 66G3689
TheThinkPad 360 family has the same
physicaldesign as the ThinkPad 750 and 755
family.
FEATURES OF 360 FAMILY
3 power saving modes: standby, suspend,
and hibernation
Personalizednameplateinmoldedindentation
External VGA is ISO capable (75 Hz)
Upgradeabledisks:170MB, 250 MB, 340MB,
540 MB, 810 MB (all 2.5 inch)
Batterylifeindicator
Non-disruptivebatteryexchange
US EPA Energy Star compliant
Liftable(pop-up)keyboard to
accessandremovediskette
drive,disk,battery,and
memory
The removed diskette drive can be used
externallyviatheoptional'FDDExternal
Kit'(includescableandenclosure;$135)
to the Port Replicator Model I and II and
Dock I and II.
Diskette drive can be removed
①toreduceweight
②toinsert cellular modem(CDPD)
③to insert TV Tuner (for on screen TV
andVCR playback)
④to insert 2.88 MB diskette
➄toadd otherthird partyoptions
PREINSTALLEDAPPLICATIONS
- IBM PC DOS 6.3
- Windows3.11
- IBM PC Card Director for PCMCIA
- IBMThinkPadDemo
- OnlineUsers Guide
- ThinkPadfeatures
1. Lotus

cc:Mail, e-mail for Advantis


network,
2. LotusOrganizer1.12,
3. LotusScreenCam1.0,
4. Official Airline Guide Flight Disk

1.0,
5. TritonCoSessionHost,
6. PRODIGY,
7. AmericaOnlineSM,
8. SofNetFaxWorks3.0
9. Taxi
10. Second NatureScreenSaver
11. Farallon

Replica
12. AlphaNetFollowFax
13. SedonaREPRINT
14. COMPELPersonalEdition
15. ReutersSM Money

Network
PCCard Director(EasyPlaying) is preinstalled
and on the utility diskette for DOS, Windows and
OS/2. It provides:
①automaticconfig of many PCMCIA cards;
②visual/audibleconfirmationofinsertion/
removal of cards;
③abilitytoautomaticallylaunchanappl(e.g.
asyncemulation)whencardinserted;
④status and info on PCMCIA cards installed.
Easy-Setupis entered by holding F1 when
turningon. Easy-Setup, BIOS,and diagnostics
arelocated in flash memory.
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(360E) Compiled by Roger Dodson, IBM. December 1995
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❏❏
❏❏
❏= Upgradeable; = Removable; ➷Price decrease effective February 14, 1995.❍
1 year warranty
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBMor dealerwarranty/service
OnlineHousecall (remote diagnostics)
30daymoney back guarantee
HELPWARE
Batterycompatibility:
84G2392 360 NiMH battery Y N N N
66G2846 750 NiMH battery Y Y Y N
85G1513 NiMH Batt Pack II N N N Y
Y = battery supported; N = not supported
755
CE/
CSE/
CD
All
360 All 750
755
C/
CS

Processor type
Processorspeed
Memorycache
Coprocessorsocket
Removablediskette
RemovableCD-ROM
Price (retail USD)
Type- model
Removable disk - size
Hard drive - speed
Avail/withdrawn date
Display - type
Display - colors
Display- techology
Display - size (diag)
Display-penenabled
Graphics- controller
Graphics - vendor
Graph-arch/data path
Memory - std / max
Mem - sockets empty
Mem-options available
Keyboard / # of keys
Fn key functions
Keyboardslope
Mouse/pointing
Extkeyboard support
Dimensions
Cubicinches
Color
Weight(withbattery)
Battery - type
Batt - life (per battery)
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA2.1 slots
Serial/parallelports
Audiosupport
Audioin/outjack
Otherfeatures
Security
Preinstalledsoftware
Warranty
Warrantyoptions
80486DX2
50/25 MHz 3.3 volt (SL Enhanced)
8 KB internal (no L2 cache)
Integratedin486DX2
3.5" 1.44 MB❍/ supports internal 2.88 MB diskette
None
$3,699 $4,049
2620-BOF 2620-BOG
340 MB ❏❏
❏❏
❏❍ 540 MB ❏❏
❏❏
❏❍
14 ms 14 ms
April 1995 / June 96 July 1995 / June 1996
VGA color/ 640 x 480
256simultaneouscolors
Dual scan- passive matrix
9.5 inch / 20 to 1 contrast ratio
Penenabled screen / folds flat / includes untethered batteryless stylus
WD90C24A or A2 with 1 MB DRAM
Western Digital / External SVGA to 1024 x 768 with 256 colors (up to 75 Hz)
VL-Bus local bus / 32 bit / Simultaneous LCD and CRT
4 MB / 20 MB 70 ns / non-parity / 5.0 volt
1 socket
4, 8, 16 MB ICs
Full size alp/num / 85 keys
8 (in any appl)
Yes (legs pop out)
TrackPointII
Yes(withoptionalcable)
11.7 x 8.3 x 2.1"
204inches
Black
6.8pounds
Nickelhydride(NiMH)
3 to 7 hours
2 hrs / 1.5 hr
AT bus (ISA)
Dock I and II
Port Replicator I and II
2 Type I or 2 Type II or 1 Type III
Yes (one 9 pin) / Yes (EPP)
16 bit audio codec on planar / CrystalSemiconductorCS4248/ intspeaker
Input jack / output jack
APM-awareBIOS/Selectable boot
ACadapter, 35 watts,worlwide, not wallmount
Hibernation mode saves memory to disk and shuts off system
Power-on password / Hard disk password / Hardware security loop (secures
unit,prevents openingkeyboard) /PCMCIA cardlock /Optional SecurityBase
IBM DOS 6.3, Windows3.11, pen op systems, and all appls listed to right:
1 year - ThinkPad EasyServ only
Onsite via special bid only / ThinkPad EasyServ Overnight Repair Option
IBM ThinkPad 360PE - withdrawn
IBM

ThinkPad

::
::
:✂ 360PE
dual scan color - pen
Compatibleinall 360 family, all750 family, and
all755family:
- Disks: 170 MB IDE 66G2847
250 MB IDE 84G2391
340 MB IDE 66G2849
540 MB IDE 84G2150
810 MB IDE 84G8250
- Dock I (1 slot / 1 bay) 3545001
- Dock II (2 slot / 2 bay) 3546001
- Port Replicator I (w/ PCMCIA) 66G3510
- PortReplicatorII 66G3520
- 1.44MBdiskette stdinnewer
Optionsfor360PE:
- AC Adapter, 35 watts 85G6680
- AC Adapter, 40 watts 49G2165
- ACAdapter,40w, wallmount 84G2148
- CarBatteryAdapter 49G2167
MemoryfromThinkPad 350, 500, and510Cs
is NOT compatible in 360. IC DRAM memory
fromThinkPad700, 720, 750,and 755 will
workbut without parity.
TheThinkPad 360 family has the same
physicaldesign as the ThinkPad 750 and 755
family.
FEATURES OF 360 FAMILY
3 power saving modes: standby, suspend,
and hibernation
Personalizednameplateinmoldedindentation
External VGA is ISO capable (75 Hz)
Upgradeabledisks:170MB, 250 MB, 340MB,
540 MB, 810 MB (all 2.5 inch)
Batterylifeindicator
Non-disruptivebatteryexchange
US EPA Energy Star compliant
PCCard Director(EasyPlaying) is preinstalled
and on the utility diskette for DOS, Windows and
OS/2. It provides:
①automaticconfig of many PCMCIA cards;
②visual/audibleconfirmationofinsertion/
removal of cards;
③abilitytoautomaticallylaunchanappl(e.g.
asyncemulation)whencardinserted;
④status and info on PCMCIA cards installed.
Easy-Setupis entered by holding F1 when
turningon. Easy-Setup, BIOS,and diagnostics
arelocated in flash memory.
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(360PE) Compiled by Roger Dodson, IBM. June 1996
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❏❏
❏❏
❏ = Upgradeable; = Removable; ✂= Withdrawn from marketing
.❍
1 year warranty
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBMor dealerwarranty/service
OnlineHousecall (remote diagnostics)
30daymoney back guarantee
HELPWARE
ALL 360 MODELS
Liftable(pop-up)keyboard to
accessandremovediskette
drive,disk,battery,and
memory
The ThinkPad 360PE has the same features as 360CSE except:
➭➭
➭➭
➭Penenableddisplay
➭➭
➭➭
➭Untetheredbatterylessstylus(pen)
➭➭
➭➭
➭Display folds down to flat position to write on
➭➭
➭➭
➭16 bit audio codec(vs no audio)
➭➭
➭➭
➭Audio in and audio out jacks
➭➭
➭➭
➭PenDOS, PenWindows,andMonologue preinstalled
➭➭
➭➭
➭35 watt universal AC adapter(vs 30 watt)
PREINSTALLEDAPPLICATIONS
- IBM PC DOS 6.3
-PenDOS

2.2
- IBMThinkWrite1.21
- Windows3.11
-Windows for Pen computing

1.0
- IBM PC Card Director for PCMCIA
- OnlineUsers Guide
- ThinkPadfeatures
1. Lotus

cc:Mail, for the IBM Global


network
2. LotusOrganizer1.12
3. LotusScreenCam1.0
4. Official Airline Guide Flight Disk

1.0
5. TritonCoSessionHost
6. PRODIGY
7. AmericaOnlineSM
8. SofNetFaxWorks3.0
9. Taxi
10. Second NatureScreenSaver
11. Farallon

Replica
12. AlphaNetFollowFax
13. SedonaREPRINT
14. COMPELPersonalEdition
15. ReutersSM Money

Network
16. Monologue
The removed diskette drive can be used
externallyviatheoptional'FDDExternal
Kit'(includes cableand enclosure)to the
Port Replicator Model I and II and Dock I
andII.
Diskette drive can be removed
①toreduceweight
②toadd otherthird partyoptions
ThinkPad360PEsupportedbatteries:
- 360NiMHbattery 84G2392
- 750NiMHbattery 66G2846
- 750QuickCharger 66G2843
Memoryoptions:
4 MB IC DRAM 70 ns 5v parity 92G7232
8 MB IC DRAM 70 ns 5v parity 92G7233
16 MB IC DRAM 70 ns 5v parity 92G7234
4 MB IC DRAM 70 ns 5v non-parity 92G7236
8 MB IC DRAM 70 ns 5v non-parity 92G7237
16 MB IC DRAM 70 ns 5v non-parity 92G7424

Cyrix Cx486DX475/25 MHz /integratedmathcoprocessor
None
8 KB in DX4 (write back) / no L2 cache
Internal3.5"1.44MB(notremoveable)
None(cannotupgrade)
203 W11 205 W12 2625-305 2625-W13
38H5711 41H8660 38H5712 41H8661 38H5714 41H8662
SelSys Win95 SelSys Win 95 SelectaSystem Windows95
340MB 340MB 540MB 540MB 540 MB 540MB
13 ms / EIDE 13 ms / EIDE 13 ms / EIDE 13 ms / EIDE
Nov 1995 / Jun 96 Nov1995 / Jun 96 Nov 95 / Jun 96 Nov 1995 / Jun 96
10.4" Dualscan 10.4" Black Matrix TFT - active matrix
VGA color / 640 x 480 VGA color / 640 x 480
256simultaneouscolors 262,144simultaneouscolors
30 to 1 100 to 1
ChipsandTechnologies65545 ChipsandTechnologies65545
512 KB DRAM 1 MB DRAM
External SVGA to 1024 x 768 w/ 256 colors up to 70 Hz
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
8 MB / 24 MB 70 ns / non-parity / 3.3 volt / fast page
1 socket for one JEDEC 72 pin SO DIMM of 4or16 MB
Full size alp/num / 85 (8 Fn key functions)
Yes (legs pop out)
TrackPointIII
Yes (with option cable or Port Replicator)
11.7 x 8.3 x 2.0" (194 cubic inches)
5.9pounds 5.8pounds
NiMH/non-intelligent
3 to 9 hours
6 hrs / 2 hrs
ISA(audio,PCMCIA,diskette,serial,parallel,100pinexternalexpansion)
VL-Bus 2.0 / 32 bit / 25 MHz (graphics, disk)
None
PortReplicator and Charger(with built-in batterycharger and palmrest)
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter (35 watts) / PhoenixBIOS
None
None
None
None
Infrared port in back / IrDA 1.0 compatible / up to 115 Kbps
Power-on password / Supervisor password / Locking device keyhole
(KensingtonMicroSavercablelock) /keyboard lock(requires Kensington)
Choiceoftwopreloadedconfigurations(listedtoright)
1 year -ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
IBM ThinkPad 365 (non-CD-ROM models) - withdrawn
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365) Compiled by Roger Dodson, IBM. June 1996
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
✂= Withdrawn from marketing
IBM

ThinkPad

::
::
:✂365CS
10.4"dual scan ThinkPad365strengths:
➭➭
➭➭
➭Entry-pricednotebook
➭➭
➭➭
➭Extensivesoftwarepreload
➭➭
➭➭
➭Infraredport
➭➭
➭➭
➭Optional Port Replicator with battery
chargerand palm rest
Processor
Processorupgrade
Memorycache
Diskettedrive
CD-ROM
Price
Type - modelall 2625
Partnumber
Preload(seeside)
Disk - capacity
Disk - ms / interface
Avail/withdrawn date
Display- diagonal size
Display - type
Display - colors
Display - contrast
Graphics- controller
Graphics - memory
Graphics - external
Graph-arch/data path
Memory - std / max
Memory-upgrade
Keyboard / # of keys
Keyboardslope
Pointing
Extkeyboard support
Dimensions(cubicin)
Weight(withbattery)
Battery - type
Battery - life
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA2.1 slots
Serial/parallelports
Otherfeatures
MPEGdecoder
Data/faxmodem
Audiosupport
Audioin/outjacks
Infraredports
Security
Preinstalledsoftware
Warranty
✂365C
10.4"TFT
ThePort Replicator and Charger provide
cablemanagement,abattery charger for an
optionalsecond battery, apalm rest when
installedon the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator,it will attemptto recharge thebattery
in ThinkPad first (if there is one) before
chargingthe battery inthe Port Replicator.
PortReplicatorand Chargerconnectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
-Keyboard
-Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Spare battery connector(to charge 2nd battery)
FEATURES OF 365 MODELS
ProductMap
LEDindicatorpanel
Plugand Play 1.0a
Non-disruptivebatteryexchange
Doze,standby,suspend, safe suspend,
andhibernationmodes
US EPA Energy Star compliant
Personalizednameplateinindention
Personalizationscreenatstartup
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBMor dealerwarranty/service
OnlineHousecall (remote diagnostics)
30daymoney back guarantee
SELECTASYSTEMPRELOAD
- IBM DOS 7.0
- Windows3.11
- OS/2Warp 3.0 (dual boot) with
selectedBonusPakapplications
- IBM PC Card Director1.4
- IBMThinkPadDemo
- OnlineUsersGuide
- ThinkPadfeatures ; Diskette Factory
1. Lotuscc:Mail,e-mail forIBM Global
Network
2. LotusOrganizer
3. LotusScreenCam
4. TritonCoSessionHost
5. PRODIGY
6. SofNetFaxWorks
7. VideoForWindowsRuntime
8. PumaTranXit
9. CompuservforWindows
10. NetFinity for Windows and OS/2
WINDOWS 95 PRELOAD
- MicrosoftWindows95
- IBMThinkPadDemo
- OnlineUsersGuide
- ThinkPadfeatures;Diskette Factory
1. Lotus

cc:Mail, e-mailforIBM Global
network
2. LotusOrganizer
3. LotusScreenCam
4. TritonCoSessionHost
5. PRODIGY
6. SofNetFaxWorks
7. PumaTranXit
8. CompuserveforWindows
Diskis not removable (like 755/760
systems), but it can be upgraded via tools
Liftable(pop-up)keyboard to
accessandremovebattery
(andupgradememory and
disk); diskette drive is not
removable
OptionsforThinkPad365:
-4 MB SO DIMM3.3v non-parity 72 pin 92G7287
-16MBSODIMM3.3vnon-parity72pin 92G7293
- 720 MB EIDE HDD 13 ms PIO Mode 3 38H6306
- 810 MB EIDE HDD 13 ms PIO Mode 442H4012
- 1.08 GB EIDE HDD 13 ms Mode 4 69H7956
-PortReplicatorandCharger 38H6303
- NiMH Battery Pack 38H6304
Setup is entered by Ctrl + Alt + F11 from any
full-screenDOSprompt
Fn + F2 = Batteryguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 =LCD/CRT/Simultaneous
Fn + F8 = Reverse video
Fn +F11 = Powermgmt
Fn + F12 = Hibernation
PgUp=Speakerenable
PgDn=Speakerdisable
Systementershibernationmodewhenkeyboard
is lifted up.

Cyrix Cx 486DX475/25 MHz / integrated math coprocessor
None
8 KB in DX4 (write-back) / no L2 cache
External3.5"1.44MB(connectstoback of system) / use simultaneously w/CD-ROM
5.25" CD-ROM / double speed / multi-session / XA / front loaded / ATAPI
2625-A05 2625-W14 2625-B05 2625-W15
38H5724 41H8663 38H5726 41H8664
SelectaSystem Windows95 SelectaSystem Windows95
540MB 540MB 540 MB 540 MB
13 ms / EIDE 13 ms / EIDE 13 ms / EIDE 13 ms / EIDE
Nov 1995 / Jun96 Nov 95 / Jun 96 Nov 95 / Jun 96 Nov 95 / Jun 96
10.4" Dualscan 10.4" Black Matrix TFT- active matrix
VGA color / 640 x 480 VGA color / 640 x 480
256simultaneouscolors 262,144simultaneouscolors
30 to 1 100 to 1
Chipsand Technologies65545with1 MB DRAM
External SVGA to 1024 x 768 w/ 256 colors up to 70 Hz
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
8 MB / 24 MB 70 ns / non-parity / 3.3 volt / fast page
1 socket for one JEDEC 72 pin SO DIMM of 4or16 MB
Full size alp/num / 85 (8 Fn key functions)
Yes (legs pop out)
TrackPointIII
Yes (with option cable or Port Replicator)
11.7 x 8.3 x 2.0" (194 cubic inches)
6.4pounds 6.3pounds
NiMH/non-intelligent
2.5 to 9 hours
6 hrs / 2 hrs
ISA(audio,PCMCIA,diskette,serial,parallel,240pinexternalexpansion)
VL-Bus 2.0 / 32 bit / 25 MHz (graphics, disk)
None
PortReplicator and Charger(with built-in batterycharger and palmrest)
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter (35 watts) / PhoenixBIOS
None
None
16 bit audio chip / 18 voice MIDI FM Synthesis / ESS1688 with OPL3
Internal speaker / .5 watt / dial volume control / internal microphone
Input jack (stereo) / microphone jack / output jack (stereo)
Joystick/MIDI port (includes Joystick/MIDI cable)
Infrared port in back / IrDA 1.0 compatible / up to 115 Kbps
Power-on password / Supervisor password / Locking device keyhole
(KensingtonMicroSavercablelock) /keyboard lock (requiresKensington)
Choiceoftwopreloadedconfigurations(listedtoright)
1 year -ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
Processor
Processorupgrade
Memorycache
Diskette(notinternal)
CD-ROM(not remove)
Price
Type - modelall 2625
Partnumber
Preload(seeside)
Disk - capacity
Disk - ms / interface
Avail/withdrawn date
Display- diagonal size
Display - type
Display - color
Display - contrast
Graphics- controller
Graphics - external
Graph-arch/data path
Memory - std / max
Mem-upgrade
Keyboard / # of keys
Keyboardslope
Pointing
Extkeyboard support
Dimensions(cubicin)
Weight(withbattery)
Battery - type
Battery - life
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA2.1 slots
Serial/parallelports
Otherfeatures
MPEGdecoder
Data/faxmodem
Audiosupport
Audioin/outjacks
Infraredports
Security
Preinstalledsoftware
Warranty
IBM ThinkPad 365 (CD-ROM models) - withdrawn
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365CD) Compiled by Roger Dodson, IBM. June 1996
ThinkPad EasyServ

:customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
✂= Withdrawn from marketing
ThinkPad365(CD-ROMmodels)strengths:
➭➭
➭➭
➭Entry-pricedCD-ROMnotebook
➭➭
➭➭
➭Integratedaudio,microphone,speaker
➭➭
➭➭
➭Simultaneousexternaldiskette
➭➭
➭➭
➭Joystick/MIDIport
➭➭
➭➭
➭Infraredport
Liftable(pop-up)keyboard to
accessandremovebattery
(andupgradememory and
disk);
CD-ROM is not removable
IBM

ThinkPad

::
::
:✂365CSD
10.4" dual scan - CD-ROM ✂365CD 10.4"TFT - CD-ROM
OptionsforThinkPad365:
-4 MB SO DIMM3.3v non-parity 72 pin 92G7287
-16MBSODIMM3.3vnon-parity72pin 92G7293
- 720 MB EIDE HDD 13 ms PIO Mode 3 38H6306
- 810 MB EIDE HDD 13 ms PIO Mode 442H4012
- 1.08 GB EIDE HDD 13 ms Mode 4 69H7956
-PortReplicatorandCharger 38H6303
- NiMH Battery Pack 38H6304
Setup is entered by Ctrl + Alt + F11 from any
full-screenDOSprompt
Fn + F2 = Batteryguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 =LCD/CRT/Simultaneous
Fn + F8 = Reverse video
Fn +F11 = Powermgmt
Fn + F12 = Hibernation
PgUp=Speakerenable
PgDn=Speakerdisable
Systementershibernationmodewhenkeyboard
is lifted up.
SELECTASYSTEMPRELOAD
- IBM DOS 7.0
- Windows3.11
- OS/2Warp 3.0 (dual boot) with
selectedBonusPakapplications
- IBM PC Card Director1.4
- IBMThinkPadDemo
- OnlineUsersGuide
- ThinkPadfeatures ; Diskette Factory
1. Lotuscc:Mail,e-mailfor IBMGlobal
Network
2. LotusOrganizer
3. LotusScreenCam
4. TritonCoSessionHost
5. PRODIGY
6. SofNetFaxWorks
7. VideoForWindowsRuntime
8. PumaTranXit
9. CompuservforWindows
10. NetFinity for Windows and OS/2
WINDOWS 95 PRELOAD
- MicrosoftWindows95
- IBMThinkPadDemo
- OnlineUsersGuide
- ThinkPadfeatures;Diskette Factory
1. Lotus

cc:Mail,e-mail for IBM Global
Network
2. LotusOrganizer
3. LotusScreenCam
4. TritonCoSessionHost
5. PRODIGY
6. SofNetFaxWorks
7. PumaTranXit
8. CompuserveforWindows
Diskis not removable (like 755/760
systems), but it can be upgraded via tools
FEATURES OF 365 MODELS
ProductMap
LEDindicatorpanel
Plugand Play 1.0a
Non-disruptivebatteryexchange
Doze,standby,suspend, safe suspend,
andhibernationmodes
US EPA Energy Star compliant
Personalizednameplateinindention
Personalizationscreenatstartup
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board, fax, and electronic support
IBMor dealerwarranty/service
OnlineHousecall (remote diagnostics)
30daymoney back guarantee
ThePort Replicator and Chargerprovide
cablemanagement,abattery charger for an
optionalsecond battery, apalm rest when
installedon the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator,it will attemptto recharge thebattery
in ThinkPad first (if there is one) before
chargingthe battery inthe Port Replicator.
PortReplicatorand Chargerconnectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
-Keyboard
-Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Sparebattery connector (tocharge2ndbattery)

IBM 5x86c100/33 MHz(Cyrix) / integrated math coprocessor
None
16 KB in 5x86c (write back) / no L2 cache
Internal3.5"1.44MB(notremoveable)
None(cannotupgrade)
2625-W9A
Windows95
540MB
13 ms / EIDE / PIO Mode 3
May1996
October1996
10.4"Dualscan
VGA color / 640 x 480
256simultaneouscolors
30 to 1
ChipsandTechnologies65545
1 MB DRAM
External SVGA to 1024 x 768 w/ 256 colors up to 70 Hz
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
8 MB / 24 MB 70 ns / non-parity / 3.3 volt / fast page
1 socket for one JEDEC 72 pin SO DIMM of 4or16 MB
Full size alp/num / 85 (8 Fn key functions)
Yes (legs pop out)
TrackPointIII
Yes (with option cable or Port Replicator)
11.7 x 8.3 x 2.0" (194 cubic inches)
5.9pounds
NiMH/non-intelligent
2.5hours
6 hrs / 2 hrs
ISA(audio,PCMCIA,diskette,serial,parallel,100pinexternalexpansion)
VL-Bus 2.0 / 32 bit / 25 MHz (graphics, disk)
None
PortReplicator and Charger(with built-in batterycharger and palmrest)
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter (35 watts) / PhoenixBIOS
None
None
None
None
Infrared port in back / IrDA 1.0 compatible / up to 115 Kbps
Power-on password / Supervisor password / Locking device keyhole
(KensingtonMicroSavercable lock) / keyboard lock (requires Kensington)
Windows95with utilities and applications(listed to right)
1 year -ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
IBM ThinkPad 365E - withdrawn
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365E) Compiled by Roger Dodson, IBM. October 1996
IBM

ThinkPad

::
::
:✂365E
10.4"dual scan ThinkPad365strengths:
➭➭
➭➭
➭Entry-pricednotebook
➭➭
➭➭
➭Extensivesoftwarepreload
➭➭
➭➭
➭Infraredport
➭➭
➭➭
➭Optional Port Replicator with battery
chargerand palm rest
FEATURES OF 365 MODELS
ProductMap
LEDindicatorpanel
Plugand Play 1.0a
Non-disruptivebatteryexchange
Doze,standby,suspend, safe suspend,
andhibernationmodes
US EPA Energy Star compliant
Personalizednameplateinindention
Personalizationscreenatstartup
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(http://www.pc.ibm.com)support
IBManddealerwarranty/service
OnlineHousecall (remote diagnostics)
Liftable(pop-up)keyboard to
accessandremovebattery
(andupgradememory and
disk); diskette drive is not
removable
WINDOWS 95 PRELOAD
- MicrosoftWindows95
- OnlineUsers Guide
- DisketteFactory
- PC Card Director 1.4
1. TritonCoSessionHost
2. PumaTranXit
3. NetFinityforWindows
4. CompuServ forWindows
Processor
Processorupgrade
Memorycache
Diskettedrive
CD-ROM
Price
Type- model
Preload(seeside)
Disk - capacity
Disk - ms / interface
Availabledate
Withdrawndate
Display- diagonal size
Display - type
Display - colors
Display - contrast
Graphics- controller
Graphics - memory
Graphics - external
Graph-arch/data path
Memory - std / max
Memory-upgrade
Keyboard / # of keys
Keyboardslope
Pointing
Extkeyboard support
Dimensions(cubicin)
Weight(withbattery)
Battery - type
Battery - life
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA2.1 slots
Serial/parallelports
Otherfeatures
MPEGdecoder
Data/faxmodem
Audiosupport
Audioin/outjacks
Infraredports
Security
Preinstalledsoftware
Warranty
OptionsforThinkPad365:
-4 MB SO DIMM 3.3vnon-parity 72 pin 92G7287
-16MBSODIMM3.3vnon-parity72pin 92G7293
- 810 MB EIDE HDD 13 ms Mode 4 42H4012
- 1.08 GB EIDE HDD 13 ms Mode 4 69H7956
-Port Replicator andCharger (old) 38H6303
replaced by 75H7529
- NiMH Battery Pack 38H6304
- 35 watt AC Adapter - 2 pin 85G6719
Setup is entered by Ctrl + Alt + F11 from any
full-screenDOSprompt
Fn + F2 = Batteryguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 = LCD/CRT/Simultaneous
Fn + F8 = Reversevideo
Fn +F11 = Powermgmt
Fn +F12 = Hibernation
PgUp = Speakerenable
PgDn = Speakerdisable
Systementershibernationmodewhenkeyboard
is lifted up
Disk is not removable (like 755/760 systems), but
it can be upgraded via a screwdriver
ThePort Replicator and Charger provide
cablemanagement,abattery charger for an
optionalsecond battery, apalm rest when
installedon the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator,it will attemptto recharge thebattery
in ThinkPad first (if there is one) before
chargingthe battery inthe Port Replicator.
PortReplicatorand Chargerconnectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
-Keyboard
-Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Spare battery connector(to charge2nd battery)
ThinkPad EasyServ

:customer calls IBM HelpCenter, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround).

ThinkPad365(CD-ROMmodels)strengths:
➭➭
➭➭
➭Entry-pricedCD-ROMnotebook
➭➭
➭➭
➭Integratedaudio,microphone,speaker
➭➭
➭➭
➭Simultaneousexternaldiskette
➭➭
➭➭
➭Joystick/MIDIport
➭➭
➭➭
➭Infraredport
➭➭
➭➭
➭MPC2compliant
IBM 5x86c100/33 MHz(Cyrix) / integrated math coprocessor
None
16 KB in 5x86c (write-back) / no L2 cache
External3.5"1.44MB(connectstoback of system) / use simultaneously w/CD-ROM
5.25" CD-ROM / 4 x speed / multi-session / XA / front loaded / ATAPI
2625-W9G
Windows95
540MB
13 ms / EIDE / PIO Mode 3
May1996
October1996
10.4"Dualscan
VGA color / 640 x 480
256simultaneouscolors
30 to 1
Chipsand Technologies65545with1 MB DRAM
External SVGA to 1024 x 768 w/ 256 colors up to 70 Hz
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
8 MB / 24 MB 70 ns / non-parity / 3.3 volt / fast page
1 socket for one JEDEC 72 pin SO DIMM of 4or16 MB
Full size alp/num / 85 (8 Fn key functions)
Yes (legs pop out)
TrackPointIII
Yes (with option cable or Port Replicator)
11.7 x 8.3 x 2.0" (194 cubic inches)
6.4pounds
NiMH/non-intelligent
2.3hours
6 hrs / 2 hrs
ISA(audio,PCMCIA,diskette,serial,parallel,240pinexternalexpansion)
VL-Bus 2.0 / 32 bit / 25 MHz (graphics, disk)
None
PortReplicator and Charger(with built-in batterycharger and palmrest)
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter (35 watts) / PhoenixBIOS
None
None
16 bit audio chip / 18 voice MIDI FM Synthesis / ESS1688 with OPL3
Internal speaker / .5 watt / dial volume control / internal microphone
Input jack (stereo) / microphone jack / output jack (stereo)
Joystick/MIDI port (includes Joystick/MIDI cable)
Infrared port in back / IrDA 1.0 compatible / up to 115 Kbps
Power-on password / Supervisor password / Locking device keyhole
(KensingtonMicroSavercablelock) /keyboard lock (requiresKensington)
Windows95with utilities and applications(listed to right)
1 year -ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
Processor
Processorupgrade
Memorycache
Diskette(notinternal)
CD-ROM(not remove)
Price
Type- model
Preload(seeside)
Disk - capacity
Disk - ms / interface
Availabledate
Withdrawndate
Display- diagonal size
Display - type
Display - color
Display - contrast
Graphics- controller
Graphics - external
Graph-arch/data path
Memory - std / max
Mem-upgrade
Keyboard / # of keys
Keyboardslope
Pointing
Extkeyboard support
Dimensions(cubicin)
Weight(withbattery)
Battery - type
Battery - life
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA2.1 slots
Serial/parallelports
Otherfeatures
MPEGdecoder
Data/faxmodem
Audiosupport
Audioin/outjacks
Infraredports
Security
Preinstalledsoftware
Warranty
IBM ThinkPad 365ED - withdrawn
ThinkPad EasyServ

:customer calls IBM HelpCenter, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround).
Liftable(pop-up)keyboard to
accessandremovebattery
(andupgradememory and
disk);
CD-ROM is not removable
IBM

ThinkPad

::
::
:✂365ED
10.4" dual scan - CD-ROM
FEATURES OF 365 MODELS
ProductMap
LEDindicatorpanel
Plugand Play 1.0a
Non-disruptivebatteryexchange
Doze,standby,suspend, safe suspend,
andhibernationmodes
US EPA Energy Star compliant
Personalizednameplateinindention
Personalizationscreenatstartup
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(http://www.pc.ibm.com)support
IBManddealerwarranty/service
OnlineHousecall (remote diagnostics)
WINDOWS 95 PRELOAD
- MicrosoftWindows95
- OnlineUsers Guide
- DisketteFactory
- PC Card Director 1.4
1. TritonCoSessionHost
2. PumaTranXit
3. NetFinityforWindows
4. CompuServ forWindows
ThePort Replicator and Chargerprovide
cablemanagement,abattery charger for an
optionalsecond battery, apalm rest when
installedon the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator,it will attemptto recharge thebattery
in ThinkPad first (if there is one) before
chargingthe battery inthe Port Replicator.
PortReplicatorand Chargerconnectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
-Keyboard
-Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Sparebattery connector (tocharge2ndbattery)
OptionsforThinkPad365:
-4 MB SO DIMM 3.3vnon-parity 72 pin 92G7287
-16MBSODIMM3.3vnon-parity72pin 92G7293
- 810 MB EIDE HDD 13 ms Mode 4 42H4012
- 1.08 GB EIDE HDD 13 ms Mode 4 69H7956
-Port Replicator andCharger (old) 38H6303
replaced by 75H7529
- NiMH Battery Pack 38H6304
- 35 watt AC Adapter - 2 pin 85G6719
Setup is entered by Ctrl + Alt + F11 from any
full-screenDOSprompt
Fn + F2 = Batteryguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 = LCD/CRT/Simultaneous
Fn + F8 = Reversevideo
Fn +F11 = Powermgmt
Fn +F12 = Hibernation
PgUp = Speakerenable
PgDn = Speakerdisable
Systementershibernationmodewhenkeyboard
is lifted up
Disk is not removable (like 755/760 systems), but
it can be upgraded via a screwdriver
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365ED) Compiled by Roger Dodson, IBM. October 1996

Pentium
â
100/66 / 64-bit transfer to memory
None
None(notupgradeable)
Internal 3.5" 1.44MB ❍ (not removable)
External FDD port (used if purchase CD-ROM upgrade)
None standard / 4 x CD-ROM option available (not customer install)
2625-6E7 2625-7E7
Windows95 Windows95
May 1996 / January 1997 May 1996 / January 1997
810MB / 13ms m / PIO Mode 4
EIDE / busmaster / PCI 2.1 / supports one internal disk
10.4 inch DSTN color 10.4 inch TFT color
SVGA / 640x480 or 800x600 SVGA / 640x480 or 800x600
Dualscan Black Matrix TFT - active matrix
256 sim colors / 25 to 1 contrast ratio 65,536 simultaneous colors / 100 to 1 contrast ratio
Trident ä CYBER9320 / 32-bit SVGA accelerator / 1MB fast page DRAM / 70ns
PCI 2.1 / 32-bit / external SVGA to 1024x768 w/ 256 colors
SimultaneousLCD and CRT/ 180 degree tilt
8MB / 40MB
70ns / non-parity / 3.3 volt / EDO / 1 socket for one JEDEC 144 pin EDO SO DIMMs of 8, 16, or 32MB
Full size alp/num / 85 (6 Fn key functions)
Yes (legs pop out)
TrackPoint III ä / external keyboard support (w/ option cable or Port Replicator)
11.7 x 8.3 x 1.9" (185 cu in)
6.0 pounds (2.7 kg)
NiMH/non-intelligent
2.5hours
1.5 hrs / 1.2 hrs
ISA(audio,PCMCIA,diskette, serial, parallel, infrared)
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics)
None
PortReplicator and Charger(with built-in batterycharger and palmrest)
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter 3 prong (35 watts) / Selectable boot
None
None
None
16-bit audio chip / 18 voice MIDI FM Synthesis / ESS1688
One internal speaker / .5 watt / dial volume control / internal microphone
Input jack (stereo) / microphone jack / output jack (stereo) / no joystick port
Infrared port in back / IrDA 1.0 compatible / up to 115Kbps
Power-on pwd / Hard disk pwd / Supervisor pwd / Locking device keyhole
(Kensington ä MicroSaver ä cablelock)/ keyboard lock (requires Kensington)
MicrosoftWindows 95 wth applications(listed on right)
1 year - ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
WINDOWS 95 PRELOAD
- MicrosoftWindows95
- OnlineUser'sGuide
- ThinkPadFeatures
- PC Card Director 4.0
- DisketteFactory
1. TritonCoSession ä Host
2. CompuservforWindows
3. NetFinityfor Windows 95
4. PumaTranXit ä
- LotusSmartSuite96CD-ROM
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365X) Compiled by Roger Dodson, IBM. May 1999
ThinkPad EasyServ ä :customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❍= Removable
IBM
â
ThinkPad
â
:
Processor type
Processorupgrade
L2cache
Diskettedrive
ExternalFDD port
InternalCD-ROM
Price
Type- model
Preload(seeside)
Avail/withdrawn date
Disk - size / ms
Diskcontroller
Display - size and type
Display- techology
Graphics- controller
Graph-arch/data path
Gaphics - features
Memory - std / max
Memory-features
Keyboard / # of keys
Keyboardslope
Pointing/ palm rest
Dimensions
Weight
Battery - type
Battery - life (1 batt)
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA ä 2.1 slots
Serial/parallelports
Otherfeatures
Videoin/out
MPEGdecoder
Data/faxmodem
Audiosupport
Audioin/outjacks
Infraredports
Security
Preinstalledsoftware
Warranty
" 365X
10.4" SVGA TFT or DSTN color
IBM ThinkPad 365X - withdrawn
Easy-Setupis entered by holding F1
whenturningon.
810MB = DMA Mode 2 or PIO Mode 4
1.08GB = DMA Mode 2 or PIO Mode 4
Keydifferencesbetween365Eand365X:
365E 365X
5x86c 100/33MHz Pentium 100, 120, 133
8MB fast page (to 24MB) 8MB EDO (to 40MB)
VL-Bus graphics and disk PCI graphics and disk
10.4" VGA 640x480 LCD SVGA 800x600
540MB disk standard 810MB or 1.08GB disk
No integrated audio 16-bit audio
PhoenixBIOS IBM BIOS with
EasySetup and
ThinkPadFeatures
FEATURES OF 365 MODELS
QuickSetup Guide
LEDindicatorpanel
Plugand Play 1.0a
Doze,standby,suspend, safe suspend,
andhibernationmodes
US EPA Energy Star compliant
Personalizednameplateinindention
Personalizationscreenatstartup
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(http://www.pc.ibm.com)support
IBManddealerwarranty/service
OnlineHousecall (remote diagnostics)
OptionsforThinkPad365X:
- 8MB SO DIMM 3.3v NP EDO 64-bit 92G7340
- 16MB SO DIMM 3.3v NP EDO 64-bit 92G7341
- 32MB SO DIMM 3.3v NP EDO 64-bit 92G7342
- 810MB EIDE HDD 13ms 42H4012
- 1.08GB EIDE HDD 13ms 69H7956
- 1.4GB EIDE HDD 3L 12.5 mm 82H8161
-Port Replicator andCharger 75H7529
- NiMH Battery Pack 38H6304
- 365X 4 x CD-ROM Drive 73H7225
- 35 watt AC Adapter (2 pin barrel) 85G6719
- 35 watt AC Adapter (slim, 2 pin) 76H0139
Fn + F2 = Batteryguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 = LCD/CRT/Simultaneous
Fn + F11 = Powermgmt
Fn + F12 = Hibernation
Disk is not removable (like 755/760 systems), but
it can be upgraded via a screwdriver
The Port Replicator and Charger provide
cablemanagement,abattery charger for an
optionalsecond battery, apalm rest when
installedon the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator,it will attemptto recharge thebattery
in ThinkPad first (if there is one) before
chargingthe battery inthe Port Replicator.
PortReplicatorand Chargerconnectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
-Keyboard
-Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Sparebattery connector(to charge2ndbattery)
-
-
-
-
-
1.
2.
3.
4.
Liftable(pop-up)keyboard toaccess and
removebattery(and upgrade memory and
disk); diskette drive is not removable

Pentium
â
120/60 or 133/66MHz / 64-bit transfer to memory
None
None(notupgradeable)
Internal 3.5" 1.44MB m (not removable)
External FDD port (used if purchase CD-ROM upgrade)
None standard / 4 x or 8 x CD-ROM option available which includes an external diskette drive (not customer install)
2625-3E9 2625-2E9
Windows95 Windows95
October 1996 / July 1997 October 1996 / October1997
120/60MHz 133/66MHz
810MB / 13ms ❍ / PIO Mode 4 1.08GB / 13ms ❍ / PIO Mode 4
EIDE / busmaster / PCI 2.1 / supports one internal disk
10.4 inch TFT color 11.3 inch DSTN color
SVGA / 640x480 or 800x600 SVGA / 640x480 or 800x600
Black Matrix TFT - active matrix Dualscan
65,536 simultaneous colors /100 to 1 256 simultaneous colors / 30 to 1 contrast ratio
Trident ä CYBER9320 / 32-bit SVGA accelerator / 1 MB fast page DRAM / 70ns
PCI 2.1 / 32-bit / external SVGA to 1024x768 w/ 256 colors
SimultaneousLCD and CRT/ 180 degree tilt
8MB / 40MB
70ns / non-parity / 3.3 volt / EDO / 1 socket for one JEDEC 144 pin EDO SO DIMMs of 8, 16, or 32MB
Full size alp/num / 85 (6 Fn key functions)
Yes (legs pop out)
TrackPoint III ä / external keyboard support (w/ option cable or Port Replicator)
11.7 x 8.3 x 1.9" (185 cu in)
6.1pounds (2.76 kg) 5.9 pounds (2.67kg)
NiMH/non-intelligent
2.5hours
1.5 hrs / 1.2 hrs
ISA(audio,PCMCIA,diskette, serial, parallel, infrared)
PCI 2.1 / 32-bit / 33MHz (EIDE, graphics)
None
PortReplicator and Charger(with built-in batterycharger and palmrest)
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter 3 prong (35 watts) / Selectable boot
None
None
None
16-bit audio chip / 18 voice MIDI FM Synthesis / ESS1688
One internal speaker / .5 watt / dial volume control / internal microphone
Input jack (stereo) / microphone jack / output jack (stereo) / no joystick port
Infrared port in back / IrDA 1.0 compatible / up to 115Kbps
Power-on pwd / Hard disk pwd / Supervisor pwd / Security keyhole
(requires cable) / keyboard lock (requires cable)
MicrosoftWindows 95 wth applications(listed on right)
1 year - ThinkPad EasyServ (optional Overnight Repair Option) or carry-in
WINDOWS 95 PRELOAD
- MicrosoftWindows95
- OnlineUser'sGuide
- ThinkPadFeatures
- PC Card Director 4.0
- DisketteFactory
1. TritonCoSession ä Host
2. CompuservforWindows
3. NetFinityfor Windows 95
4. PumaTranXit ä
- LotusSmartSuite96CD-ROM
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(365X96) Compiled by Roger Dodson, IBM. May 1999
ThinkPad EasyServ ä :customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❍= Removable
IBM
â
ThinkPad
â
:
Processor type
Processorupgrade
L2cache
Diskettedrive
ExternalFDD port
InternalCD-ROM
Price
Type- model
Preload(seeside)
Avail/withdrawn date
Pentiumspeed
Disk - size / ms
Diskcontroller
Display - size and type
Display- techology
Graphics- controller
Graph-arch/data path
Graphics - features
Memory - std / max
Memory-features
Keyboard / # of keys
Keyboardslope
Pointing/ palm rest
Dimensions
Weight
Battery - type
Battery - life
Charge time - on / off
Architecture
DockingStation
Portreplicator
PCMCIA ä 2.1 slots
Serial/parallelports
Otherfeatures
Videoin/out
MPEGdecoder
Data/faxmodem
Audiosupport
Audioin/outjacks
Infraredports
Security
Preinstalledsoftware
Warranty
✂ 365X
10.4" SVGA TFT or 11.3" SVGA DSTN color
IBM ThinkPad 365X (Fall 1996 models) - withdrawn
Easy-Setupis entered by holding F1
whenturningon.
810MB = DMA Mode 2 or PIO Mode 4
1.08GB = DMA Mode 2 or PIO Mode 4
FEATURES OF 365 MODELS
QuickSetup Guide
LEDindicatorpanel
Plugand Play 1.0a
Doze,standby,suspend, safe suspend,
andhibernationmodes
US EPA Energy Star compliant
Personalizednameplateinindention
Personalizationscreenatstartup
InternationalWarrantyService
24 hour / 7 day telephone, bulletin
board,fax,electronic, and Internet
(http://www.pc.ibm.com)support
IBManddealerwarranty/service
OnlineHousecall (remote diagnostics)
OptionsforThinkPad365X:
- 8MB SO DIMM 3.3v NP EDO 64-bit 92G7340
- 16MB SO DIMM 3.3v NP EDO 64-bit 92G7341
- 32MB SO DIMM 3.3v NP EDO 64-bit 92G7342
- 810MB EIDE HDD 13ms 42H4012
- 1.08GB EIDE HDD 13ms 69H7956
- 1.4GB EIDE HDD 3L 12.5 mm 82H8161
- 2.1GB HDD 13ms 82H8175
-Port Replicator andCharger 75H7529
- NiMH Battery Pack 38H6304
- 35 watt AC Adapter (2 pin barrel) 85G6719
- 35 watt AC Adapter (slim, 2 pin) 76H0139
- 365X 4 x CD-ROM Drive 73H7225
- 8 x CD-ROM 83H6726
Fn + F2 = Batteryguage
Fn + F3 = Standby
Fn + F4 = Suspend
Fn + F7 = LCD/CRT/Simultaneous
Fn + F11 = Powermgmt
Fn + F12 = Hibernation
Disk is not removable (like 755/760 systems), but
it can be upgraded via a screwdriver
The Port Replicator and Charger provide
cablemanagement,abattery charger for an
optionalsecond battery, apalm rest when
installedon the system, and has complete port
replication.
The Port Replicator can charge a battery
whether or not a ThinkPad is connected to it.
When the ThinkPad is attached to the Port
Replicator,it will attemptto recharge thebattery
in ThinkPad first (if there is one) before
chargingthe battery inthe Port Replicator.
PortReplicatorand Chargerconnectors:
- Serial (RS-232, 9 pin)
- Parallel (EPP, ECP, 25 pin)
- External display (15 pin)
-Keyboard
-Mouse
- Diskette drive (26 pin)
- Game with MIDI support (15 pin)
- Audio in (3.5 mm)
- Audio out (3.5 mm)
- DC input connector
- Sparebattery connector(to charge2ndbattery)
Liftable(pop-up)keyboard toaccess and
removebattery(and upgrade memory and
disk); diskette drive is not removable
