IBM 56K Modem User manual

`
56K Modem
Internet Kit
Modem Installation Guide
OPTIONS
by IBM

Note Before using this information and the product it supports, be sure to read the
general information in Product Warranty and Notices.
Second Edition (December 1998)
The following paragraph does not apply to the United Kingdom or any
country where such provisions are inconsistent with local law:
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES
THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of
express or implied warranties in certain transactions, therefore, this statement
may not apply to you.
This publication could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will
be incorporated in new editions of the publication. IBM may make
improvements and/or changes in the product(s) and/or the program(s)
described in this publication at any time.
It is possible that this publication may contain reference to, or information
about, IBM products (machines and programs), programming, or services
that are not announced in your country. Such references or information must
not be construed to mean that IBM intends to announce such IBM products,
programming, or services in your country.
Requests for technical information about IBM products should be made to
your IBM reseller or IBM marketing representative.
© Copyright International Business Machines Corporation 1998. All
rights reserved.
Note to U.S. Government Users — Documentation related to restricted rights
— Use, duplication or disclosure is subject to restrictions set forth in GSA
ADP Schedule Contract with IBM Corp.

56K Modem Internet Kit
iii
Part 1 : Safety......................................................................................1-1
Part 2 : Introduction............................................................................2-1
Package contents..................................................................................2-1
About V.90 56Kbps Connections.........................................................2-2
Part 3 : Installation .............................................................................3-1
Overview..............................................................................................3-1
Installing the Modem...........................................................................3-1
Installing Drivers for Windows 3.1/3.11 .............................................3-2
Installing Drivers for Windows 95......................................................3-5
Installing Drivers for Windows 98......................................................3-8
Uninstalling Drivers for Windows 3.1/3.11.......................................3-13
Uninstalling Drivers for Windows 95/98...........................................3-14
Installation du modem.......................................................................3-19
Installation du pilote sous Windows 3.1/3.11 ....................................3-20
Installation du pilote sous Windows 95/98 ........................................3-20
Cómo Instalar el Módem...................................................................3-21
Cómo Instalar los Drivers en Windows 3.1/3.11................................3-22
Cómo Instalar los Drivers para windows 95/98.................................3-22
Part 4 : Testing Your Modem.............................................................4-1
Part 5 : Typical Applications..............................................................5-1
Internet Access ....................................................................................5-1

56K Modem Internet Kit iv
Speakerphone / Phone Answering Functions......................................5-1
Faxing..................................................................................................5-2
Part 6 : Troubleshooting.....................................................................6-1
Additional Information about IRQ and COM port conflicts.............6-7
AT Commands.....................................................................................6-9
Part 7 : Help and Service Information...............................................7-1
Step 1: Try to solve the problem.........................................................7-1
Step 2: Preparing for the Call.............................................................7-1
Step 3: Placing the Call to IBM..........................................................7-2
Part 8 : Product Warranty .................................................................8-1
Part 9 : Notices....................................................................................9-1
Electronic Emission Notices................................................................9-1
Telecommunication Notices.................................................................9-2
Notices..................................................................................................9-5
Trademarks.........................................................................................9-5

56K Modem Internet Kit
1-1
Part 1 : Safety
This modem card is for use only in Personal Computers that have
installation instructions detailing user installation of adapter cards.

56K Modem Internet Kit 1-2
Safety Information

56K Modem Internet Kit
1-3
Safety Information

56K Modem Internet Kit 1-4

56K Modem Internet Kit
1-5
Safety Information
To avoid a shock hazard, do not connect or disconnect any cables or perform
installation, maintenance, or reconfiguration of this product during an
electrical storm.
To avoid shock hazard:
•The power cord must be connected to a properly wired and earthed
receptacle.
•Any equipment to which this product will be attached must also be
connected to properly wired receptacles.
Pour éviter tout risque de choc électrique, ne manipulez aucun câble et
n'effectuez aucune opération d'installation, d'entretien ou de reconfiguration
de ce produit au cours d'un orage.
Pour éviter tout risque de choc électrique :
•Le cordon d'alimentation doit être branché sur une prise d'alimentation
correctement câblée et mise à la terre.
•D'autre part, tout le matériel connecté à ce produit doit également être
branché sur des prises d'alimentation correctement câblées et mises à la
terre.
Para evitar peligo de descargas, no contecte o desconecte ningún
cable, ni realice ninguna instalación, mantenimiento o reconfiguración
de este producto durante una tormenta eléctrica.
Para evitar peligro de descargas:
•El cale de alimentación debe estar conectado a una toma de
alimentación adecuadamente cableada y con toma de tierra.
•Cualquier equipo al cual se conecte este producto debe estar
tamblén conectado a tomas de alimentación adecuadamente
cableadas.
Cuando sea posible, utilice una mano para conectar o desconectar los
cables de señal para impedir que se produzcan posible descargas eléctricas al
tocar dos superficies con potencial eléctrico distinto.

56K Modem Internet Kit 1-6
DANGER
When using your telephone equipment basic safety precautions should
always be followed to reduce the risk of fire, electrical shock, and injury to
persons, including the following:
•Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
•Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electrical shock from lightning.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
Thank you for purchasing an IBM 56K Modem Internet Kit.
Note:
Do NOT connect your modem to a digital PBX (switchboard) system, because
you may damage the modem. Modems are designed to function with analog
telephone lines, such as most residential lines.
Do NOT connect your modem to an ISDN line. In some areas, ISDN (digital)
lines are being provided for residences and businesses. These lines may
damage the modem.
Please note that this modem is fully compatible with analog telephone lines
that are connected to a Digital Exchange. The Digital Exchange supplies
analog lines to homes and businesses.

56K Modem Internet Kit
2-1
Part 2 : Introduction
Important!
This modem will not function in DOS Real Mode, OS/2, or Windows NT.
This modem will only work with a Windows 3.1x or Windows 95 or 98
operating systems.
Package contents
Before getting started, make sure that you have the following items that were
included with your package.
•An internal IBM 56K Modem
•Communications Software on CD-ROM disc
•RJ11 Phone Cord
•Support diskette containing drivers
•A microphone.
•Program License Agreement
Important!
Refer to the readme file that is included with your software drivers diskette.
This file contains additional information that is not in the modem installation
guide. You can also visit the IBM website for the latest information:
http://www.pc.ibm.com/options/modems/56kmodem.html
As you examine these items, look for any physical damage.
Retain the shipping container in the event that you need to ship your IBM
56K Modem Internet Kit.
Important: Be sure to retain your proof of purchase because it might be required to receive
warranty service. You can find information on how to get help, technical support, and
warranty service in Help and Service Information.

56K Modem Internet Kit 2-2
About V.90 56Kbps Connections
Initially when 56K technology was introduced, there was no industry
standard. Lucent Technologies, Rockwell International, and U.S. Robotics
each proposed their own protocols. Then, Rockwell and Lucent joined forces
to promote their K56Flex protocol, and U.S. Robotics released its own
protocol known as x2. In February 1998, the International
Telecommunications Union (ITU) released V.90 as a draft standard, with
approval expected in Fall 1998. The IBM 56K Modem supports both the x2
protocol and the draft V.90 standard.
56K modems take advantage of the fact that Internet Service Providers (ISPs)
and corporate networks typically connect digitally to the public telephone
system, enabling higher download speeds. Years ago, downloaded data was
converted from analog form to digital form then back to analog form again.
Today, it is now typically converted only once. That is, it travels digitally
from ISP to the telephone company, digitally between two phone company
offices, and finally analog to your modem. 56Kbps/V.90 modems use this fact
to treat the downstream communication path as entirely digital, allowing
faster download speeds. But that ability is only realized if your modem and
phone connection meet all the requirements as described in the following
paragraphs, and it only improves the downstream path. Data uploads to your
ISP will be 33.6bps or less.
There are several variables that will effect your Internet connection and your
ability to benefit from 56K technology. First your local phone system must not
make more than one analog to digital transition. Also modem speeds will be
affected by line noise, or interference, which is dependent on the quality of a
particular phone line. The maximum data rate available over regular phone
lines under the United States Federal Communications Commission’s voltage
regulations for central office telephone equipment is 53Kbps. While 56K
protocol modems are capable of reaching download speeds near 56Kbps
under ideal conditions, speeds typically range from 40 to 50Kbps.
This modem includes both V.90 and x2 56K technology. To make 56K
connections, the modem requires that you connect to a V.90 or x2 compatible
Internet Service Provider. The modem will first attempt to make a V.90
connection. If this connection attempt fails, the modem will attempt to make
an x2 connection. If this attempt fails, the modem will attempt to make a
V.34 connection at the highest speed possible (up to 33.6Kbps speed).

56K Modem Internet Kit
3-1
Part 3 : Installation
Overview
The installation has three elements:
•Installing the modem card (hardware installation).
•Installing the modem drivers. The instructions vary by operating system.
•Installing application software, such as fax or internet dialers. This
process is not discussed in this manual.
Installing the Modem
1. Turn off and unplug your computer and any peripheral devices, such as a
printer.
2. Remove the computer’s cover. Refer to the computer manual, if
necessary, to see which rear panel screws to remove before sliding the
cover off.
3. Unscrew and remove the solid bracket at the back of any available ISA
expansion slot.
4. Insert the modem board into the slot you have chosen, with the gold leads
on the modem’s edge firmly in the slot’s groove.
5. Once the modem is in place, screw the bracket at the back of the modem
firmly to the computer’s rear panel. This ensures that the modem board is
firmly in place.
6. Replace the computer cover and all its screws. Reattach all cables and
power cords.
7. If you currently have a phone plugged into the wall jack, disconnect it.
Plug one end of the phone cable that came with the modem into the
TELCO jack at the rear of the modem. Plug the other end of the cable
into the wall jack.
8. This completes the modem hardware installation.

56K Modem Internet Kit 3-2
Installing Drivers for Windows 3.1/3.11
The following steps should be performed in order to install the driver
software for the modem:
1. Insert the installation diskette.
2. Select the File pulldown menu located at the top of the Program
Manager.
3. Select Run…
4. Type a:\install (if a: is your 3.5” diskette drive). Click OK

56K Modem Internet Kit
3-3
5. Follow the prompts from the installation program.
Click YES to create a new directory if needed.
6. One of the prompts will ask you to select an available COM port. Select
one that is free (Available COM port will be highlighted) and press OK.

56K Modem Internet Kit 3-4
Restart Windows if directed at the end of the installation.
7. At the conclusion of the installation, you will find an ISA Modem for
Windows group in the Windows Program Manager window.
Important!
If you decide to upgrade to or install Windows 95 or 98, you must first
uninstall your Windows 3.1 drivers and remove the modem from your PC. If
you do not uninstall these drivers, your modem will not be recognized and
will not configure for use in Windows 95/98. Windows 3.1 drivers are not
compatible with Windows 95/98. Do not attempt to install these drivers in
place of the Windows 95/98 drivers. Refer to uninstall instructions that are
provided on page 3-8.

56K Modem Internet Kit
3-5
Installing Drivers for Windows 95
There are two major versions of Windows 95. The following steps describe
the OEM (B) version most widely used. Installation steps for the retail
version of Windows 95 are included at the end of this section as well.
Once the system is turned on, the following steps should be performed to
install the driver software for the modem:
1. Once the modem has been physically installed in the system, Windows
95 should come up with the New Hardware Found screen. Otherwise
refer to the Troubleshooting section.
2. Select the Driver from disk provided by hardware manufacturer if
prompted and direct the Copy files from: box to the location of the
drivers (A: if the installation diskette is in your A-drive ).

56K Modem Internet Kit 3-6
3. Insert the ISA Modem for Windows diskette into your diskette drive and
click the OK button.
NOTE:
a. It will be necessary to change to A: drive before continuing
installation of the modem driver. Type A: and click OK.
b. If installing drivers from another directory or drive source,
use the Browse button to select the source. Click OK.
4. The next screen will confirm that you are installing initialization
software for the ISA Modem for Windows. Click OK.

56K Modem Internet Kit
3-7
5. An installation screen will appear telling you that the system is installing
drivers for the ISA Modem for Windows.
6. Wait for the installation of the driver software to complete. Windows will
continue loading after completing installation of the modem drivers.
Important!
When performing a completely new installation of Windows 95 it will be
necessary to physically remove the 56K DSVD Modem. Windows 95 will not
recognize the modem during installation of the operating system. After
completing installation of Windows 95, install the modem as outlined in
instructions given above. Remember to follow all cautions or warnings given
for installing this modem.
Note:
This message does not apply to Windows 95 upgrades to Windows 98. The
modem drivers will be carried over to Windows 98.
Windows 95 retail version which also shipped on earlier IBM PCs installs
differently:
1. After you power up your computer, a window will appear that says “New
Hardware Found”. Select the option “Driver from disk provided by
Hardware Manufacturer”, and then click the OK button.
2. Insert the ISA Modem for Windows diskette into your diskette drive and
click the OK button.
3. The next screen will confirm that you are installing initialization
software for the ISA Modem for Windows. Click the OK button.
4. An installation screen will pop up telling you that the system is installing
drivers for the ISA Modem for Windows.
5. Wait for the installation of the driver software to complete. Restart the
computer if prompted to.
