Huawei 51071SMK User manual

Quick Start
Démarrage rapide
Schnellanleitung
Avvio rapido
Snelstartgids
Início rápido
Inicio rápido
31500DRM_01

Contents
English.......................................................................................................................................................1
Français................................................................................................................................................... 11
Deutsch....................................................................................................................................................23
Italiano..................................................................................................................................................... 35
Nederlands.............................................................................................................................................. 46
Português................................................................................................................................................ 57
Español....................................................................................................................................................68
i

Getting to Know Your USB Stick
The following figure shows the appearance of the USB Stick. It is provided only for your reference. The
actual product may be different.
1
2
3
USB Connector
It connects the USB Stick to a PC.
Indicator
It indicates the status of the USB Stick.
•Green, blinking twice every 2s: No service/The network is not registered.
•Green, blinking once every 0.2s: The software of the USB Stick is being upgraded.
English
1

•Green, blinking once every 2s: The 2G network has already been registered.
•Blue, blinking once every 2s: The 3G /3G+ network has already been registered.
•Cyan, blinking once every 2s: The LTE network has already been registered.
•Green, solid: The USB Stick is connected to a 2G network.
•Blue, solid: The USB Stick is connected to a 3G network.
•Cyan, solid: The USB Stick is connected to an LTE network.
•Off: The USB Stick is removed.
After the device is inserted into the USB port, the indicator will turn solid green, indicating that
the software startup process has initiated. After the startup is complete, the indicator works as
detailed above.
SIM Card Slot
It holds a Subscriber Identity Module (SIM) card.
Getting Your USB Stick Ready
1Slide the cover to remove it from the USB Stick.
2Insert the SIM card into the corresponding card slots, as shown in the following figure.
3Replace the cover and slide it into place.
2

•Ensure that the beveled edge of the SIM card is properly aligned with that of the SIM card
slot.
•Do not remove the SIM card when the card is in use. Otherwise, the card as well as your USB
Stick may get damaged and the data stored on the card may be corrupted.
3

Safety information
Copyright © Huawei 2020. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE ANY
KIND OF WARRANTIES.
LTE is a trademark of ETSI.
Privacy Policy
To better understand how we use and protect your personal information, please read the Privacy Policy
at http://consumer.huawei.com/privacy-policy.
To understand how we use and protect your personal information on this device, open the web-based
management page, access Statement about Huawei Mobile Broadband Devices and Privacy, and read
our privacy policy.
Software Update
By continuing to use this device, you indicate that you have read and agree to the following content:
In order to provide better service, this device will automatically obtain software update information from
Huawei or your carrier after connecting to the Internet. This process will use mobile data, and requires
access to your device's unique identifier (IMEI/SN) and the service provider network ID (PLMN) to check
whether your device needs to be updated.
4

This device supports the automatic update feature. Once enabled, the device will automatically
download and install critical updates from Huawei or your carrier. The function is enabled by default, and
can be disabled from the settings menu on the web-based management page.
Safety information
•Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your
service provider for more information.
•Pacemaker manufacturers recommend that a minimum distance of 20 cm be maintained between a
device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker,
hold the device on the side opposite the pacemaker and do not carry the device in your front pocket.
•Ideal operating temperatures are -10 °C to +40 °C. Ideal storage temperatures are -20 °C to +70 °C.
Extreme heat or cold may damage your device or accessories.
•Keep the device and accessories in a well-ventilated and cool area away from direct sunlight. Do not
enclose or cover your device with towels or other objects. Do not place the device in a container with
poor heat dissipation, such as a box or bag.
•Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water
heater, radiator, or candle.
•Using an unapproved or incompatible power adapter, charger or battery may cause fire, explosion or
other hazards.
•Choose only accessories approved for use with this model by the device manufacturer. The use of
any other types of accessories may void the warranty, may violate local regulations and laws, and
5

may be dangerous. Please contact your retailer for information about the availability of approved
accessories in your area.
•For pluggable devices, the socket-outlet shall be installed near the devices and shall be easily
accessible.
•Ensure that the charger meets the requirements of Clause 2.5 in IEC60950-1/EN60950-1/UL60950-1
and has been tested and approved according to national or local standards.
•Keep the battery away from excessive heat and direct sunlight. Do not place it on or in heating
devices, such as microwave ovens, stoves, or radiators. Batteries may explode if overheated.
•Do not attempt to modify or remanufacture the battery, insert foreign objects into it, or immerse or
expose it to water or other liquids. Doing so may lead to fire, explosion, or other hazards.
•Dispose of used batteries in accordance with local regulations. Improper battery use may lead to fire,
explosion, or other hazards.
•Areas with flammables and explosives: Do not use the device where flammables or explosives are
stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these
environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text
or symbols. Do not store or transport the device in containers with flammable liquids, gases, or
explosives.
•Blasting Caps and Areas: Turn off your device or wireless device when in a blasting area or in areas
posted turn off “two-way radios” or “electronic devices” to avoid interfering with blasting operations.
6

•Medical devices: Please consult your doctor and the device manufacturer to determine if operation of
your device may interfere with the operation of your medical device.
•Hospitals: Switch off your wireless device when requested to do so in hospitals, clinics or health care
facilities. These requests are designed to prevent possible interference with sensitive medical
equipment.
•Aircraft: Switch off your wireless device whenever you are instructed to do so by airport or airline staff.
Consult the airline staff about the use of wireless devices on board the aircraft, if your device offers a
‘flight mode’ this must be enabled prior to boarding an aircraft.
Disposal and recycling information
The crossed-out wheeled-bin symbol on your product, battery, literature or packaging reminds you that
all electronic products and batteries must be taken to separate waste collection points at the end of their
working lives; they must not be disposed of in the normal waste stream with household garbage. It is the
responsibility of the user to dispose of the equipment using a designated collection point or service for
separate recycling of waste electrical and electronic equipment (WEEE) and batteries according to local
laws.
7

Proper collection and recycling of your equipment helps ensure electrical and electronic equipment
(EEE) waste is recycled in a manner that conserves valuable materials and protects human health and
the environment, improper handling, accidental breakage, damage, and/or improper recycling at the end
of its life may be harmful for health and environment. For more information about where and how to drop
off your EEE waste, please contact your local authorities, retailer or household waste disposal service or
visit the website http://consumer.huawei.com/en/.
Reduction of hazardous substances
This device and its electrical accessories are compliant with local applicable rules on the restriction of
the use of certain hazardous substances in electrical and electronic equipment, such as EU REACH,
RoHS and Batteries (where included) regulations. For declarations of conformity about REACH and
RoHS, please visit our web site http://consumer.huawei.com/certification.
EU regulatory conformance
RF exposure requirements
Important safety information regarding radio frequency (RF) radiation exposure:
RF exposure guidelines require that the device be used at a minimum of 0.5 cm from the human body.
Failure to observe this guideline may result in RF exposure exceeding limits.
Certification information (SAR)
This device meets guidelines for exposure to radio waves.
8

Your device is a low-power radio transmitter and receiver. As recommended by international guidelines,
the device is designed not to exceed the limits for exposure to radio waves. These guidelines were
developed by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), an
independent scientific organization, and include safety measures designed to ensure the safety of all
users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for the amount of radio frequency
energy absorbed by the body when using a device. The SAR value is determined at the highest certified
power level in laboratory conditions, but the actual SAR level during operation can be well below the
value. This is because the device is designed to use the minimum power required to reach the network.
The SAR limit adopted by Europe is 2.0 W/kg averaged over 10 grams of tissue, and the highest SAR
value for this device complies with this limit.
Frequency Bands and Power
Statement
Hereby, Huawei Technologies Co., Ltd. declares that this device E3372h-320 is in compliance with the
essential requirements and other relevant provisions of Directive 2014/53/EU.
The most recent and valid version of the DoC (Declaration of Conformity) can be viewed at
http://consumer.huawei.com/certification.
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is used.
This device may be restricted for use, depending on the local network.
9

(a) Frequency bands in which the radio equipment operates: Some bands may not be available in all
countries or all areas. Please contact the local carrier for more details.
(b) Maximum radio-frequency power transmitted in the frequency bands in which the radio equipment
operates: The maximum power for all bands is less than the highest limit value specified in the related
Harmonized Standard.
The frequency bands and transmitting power (radiated and/or conducted) nominal limits applicable to
this radio equipment are as follows: GSM 900: 37 dBm, GSM 1800: 34 dBm, WCDMA 900/2100: 25.7
dBm,LTE Band 1/3/7/8/20/28: 25.7 dBm.
Accessories and Software Information
The product software version is 10.0.3.1(H192SP11C00). Software updates will be released by the
manufacturer to fix bugs or enhance functions after the product has been released. All software versions
released by the manufacturer have been verified and are still compliant with the related rules.
All RF parameters (for example, frequency range and output power) are not accessible to the user, and
cannot be changed by the user.
For the most recent information about accessories and software, please see the DoC (Declaration of
Conformity) at http://consumer.huawei.com/certification.
Please visit http://consumer.huawei.com/en/support/hotline for recently updated hotline and email
address in your country or region.
10

Découvrez votre clé USB
La gure suivante montre les caractéristiques de la clé USB. Elle sert de référence uniquement. Le
produit réel peut diérer de la gure.
1
2
3
Connecteur USB
Il permet de connecter la clé USB à un PC.
Indicateur
Il indique le statut de la clé USB.
•Vert, deux clignotements toutes les 2 secondes : aucun service/le réseau n'est pas enregistré.
•Clignotement vert une fois toutes les 0,2 seconde : le logiciel de la clé USB est en cours de mise à
niveau.
Français
11

•Vert, un clignotement toutes les 2 secondes : le réseau 2G a déjà été enregistré.
•Bleu, un clignotement toutes les 2 secondes : le réseau 3G/3G+ a déjà été enregistré.
•Cyan, un clignotement toutes les 2 secondes : le réseau LTE a déjà été enregistré.
•Vert, xe : la clé USB est connectée à un réseau 2G.
•Bleu, xe : la clé USB est connectée à un réseau 3G.
•Cyan, xe : la clé USB est connectée à un réseau LTE.
•Éteint : la clé USB est retirée.
une fois l'appareil inséré dans le port USB, le voyant devient vert xe, indiquant que le
processus de démarrage du logiciel a été lancé. Une fois le démarrage terminé, l'indicateur
fonctionne comme indiqué ci-dessus.
Connecteur de carte SIM support
Il supporte une carte SIM (module d’identication du titulaire).
Préparer votre clé USB
1Faites glisser le couvercle pour le retirer de la clé USB.
2Insérez la carte SIM dans le logement de carte correspondant comme l'illustre la gure suivante.
3Replacez le couvercle et faites-le glisser en place.
12

•Assurez-vous que le bord biseauté de la carte SIM est correctement aligné avec celui du
logement de carte SIM.
•Ne retirez pas la carte SIM lorsque celle-ci est en cours d'utilisation. Autrement, la carte et
votre clé USB pourraient s'endommager et entraîner la perte des données contenues sur la
carte.
13

Informations relatives à la sécurité
Copyright © Huawei 2020. Tous droits réservés.
CE DOCUMENT EST FOURNI À TITRE INFORMATIF UNIQUEMENT. IL NE CONSTITUE EN AUCUN CAS
UNE FORME DE GARANTIE.
LTE est une marque de commerce de ETSI.
Politique de condentialité
Pour mieux comprendre comment nous utilisons et protégeons vos informations personnelles,
veuillez lire notre politique de condentialité sur http://consumer.huawei.com/privacy-policy.
Mise à jour du logiciel
En continuant à utiliser cet appareil, vous reconnaissez avoir lu, compris et accepté le contenu
suivant :
An de fournir un meilleur service, cet appareil obtiendra automatiquement les informations de mise
à jour du logiciel provenant de Huawei ou de votre opérateur après sa connexion à Internet. Ce
processus utilisera les données mobiles et nécessite un accès à l'identiant unique (IMEI/numéro de
série) de votre appareil, ainsi qu'à l'identiant réseau du fournisseur du service (PLMN) pour vérier
si votre appareil a besoin d'être mis à jour.
Cet appareil prend en charge la fonctionnalité de mise à jour automatique. Une fois activée,
l'appareil téléchargera et installera automatiquement les mises à jour critiques de Huawei ou de
14

votre opérateur. Cette fonctionnalité est activée par défaut et peut être désactivée depuis le menu
des paramètres sur la page de gestion web.
Informations relatives à la sécurité
•Certains appareils sans l peuvent aecter les performances des appareils auditifs ou des
stimulateurs cardiaques. Consultez votre fournisseur de services pour de plus amples informations.
•Les fabricants de stimulateurs cardiaques recommandent de laisser un écart minimum de 20 cm
entre un appareil et un stimulateur cardiaque an d'empêcher des interférences potentielles avec
le stimulateur. Si vous utilisez un stimulateur cardiaque, tenez l'appareil du côté opposé au
stimulateur cardiaque et ne portez pas l'appareil dans votre poche avant.
•Les températures d'utilisation idéales sont entre -10°C et +40°C. Les températures de stockage
idéales sont entre -20°C et +70°C. Des températures extrêmement froides ou chaudes peuvent
endommager votre appareil ou les accessoires.
•Conservez l'appareil et les accessoires dans un endroit bien aéré et frais, à l'écart des rayons
directs du soleil. N'enveloppez pas et ne recouvrez pas votre appareil de serviettes ou d'autres
objets. Ne placez pas l'appareil dans un récipient ayant une faible capacité de dissipation
thermique, comme par exemple une boîte ou un sac.
•Conservez l'appareil à l'écart des sources de chaleur et de ammes, telles qu'un radiateur, un four
à micro-ondes, une cuisinière, une bouilloire ou une bougie.
•L'utilisation d'un adaptateur d'alimentation, d'un chargeur ou d'une batterie non approuvé(e) ou
incompatible peut entraîner un incendie, une explosion ou d'autres dangers.
15

•Seuls les accessoires approuvés par le fabricant de l'appareil pour une utilisation avec ce modèle
peuvent être utilisés. L'utilisation de tout autre type d'accessoires peut entraîner la nullité de la
garantie, enfreindre les règlementations et lois locales et être dangereuse. Veuillez contacter votre
détaillant pour obtenir plus d'informations sur la disponibilité, près de chez vous, d'accessoires
agréés.
•Pour les appareils enchables, la prise de courant doit être installée près des appareils et être
facile d'accès.
•Assurez-vous que le chargeur respecte les exigences de l'article 2.5 de la norme IEC60950-1/
EN60950-1/UL60950-1 et qu'il a été testé et approuvé conformément aux normes nationales ou
locales.
•Tenez la batterie à distance des sources de chaleur excessive et des rayons directs du soleil. Ne la
placez pas sur ou dans des appareils de chauage, tels que des fours à micro-ondes, des
cuisinières ou des radiateurs. Les batteries pourraient exploser en cas de surchaue.
•N'essayez pas de modier ou réusiner la batterie, d'y insérer des corps étrangers, de l'immerger ou
de l'exposer à de l'eau ou à d'autres liquides. Cela pourrait entraîner des incendies, des explosions
ou d'autres dangers.
•Mettez au rebut les batteries usagées conformément aux règlementations locales en vigueur. Une
mauvaise utilisation de la batterie pourrait entraîner un incendie, une explosion ou d'autres
dangers.
16
