Hardware Announcement
April 4, 2006
IBM xSeries 336 servers feature processors up to
3.8 GHz with Intel EM64T —Rack-optimized
servers for outstanding computing power

Overview
The xSeries336 server is designed
to handle compute-intensive,
Web-based, or enterprise network
applications. Optimized for EM64T,
the xSeries 336 server helps you
migrate to 64-bit computing.
This highly manageable, ultrathin,
1 U high rack-optimized server
features two-way SMP-capable
processors, high availability, and
scalability.
Power and scalability for On Demand
Business
Apply powerful processors, large
amounts of high-performing memory,
and high-bandwidth PCI buses to
datacenter applications:
•Wide range of processor options:
−Single-core IntelXeon
processors from 2.8 to 3.8 GHz
enhanced with 2 MB advanced
transfer L2 cache
−Dual-core Intel Xeon
processors at 2.8 GHz
enhanced with 4 MB advanced
transfer L2 cache
•800 MHz front-side bus (FSB)
•1, 2, or 4 GB of two-way
interleaved, high-speed PC2-3200
ECC DDR2 SDRAM RDIMM
memory, supporting up to 16 GB
memory
•Integrated Ultra320 SCSI with
RAID-1 or -1E
•Support for hot-swap Ultra320
SCSI (up to 600 GB3) and
simple-swap SATA HDDs (up to
500 GB) depending on model
•Dual Gigabit Ethernet controllers
for high I/O capacity, plus failover
capability
High availability for around-the-clock
business
High availability, manageability, and
serviceability features help diagnose
problems quickly, even from remote
locations:
•Hot swap/redundant cooling fans,
optional hot-swap/redundant
power supplies
•Memory mirroring and hot spare
memory configurable using BIOS
setup
•Integrated systems management
processor
•Monitoring and control of
operating status and key server
components
•Predictive Failure Analysis
(PFA) on selected components
that warns of problems before
they occur
•Fast and easy servicing:
Innovative Light Path Diagnostics,
improved on-board diagnostics,
and LED diagnostic panel
•Optional Remote Supervisor
Adapter II SlimLine card for full
out-of-band systems management
Service and support perfected for On
Demand Business
ServerGuide, IBM Director, Web
support, and three-year on-site
limited warranty4
Key prerequisites
Monitor, keyboard, mouse, and
EIA-310D compatible rack
Planned availability date
April 28, 2006
At a glance
Power, scalability, control, and
serviceability for dynamic
Web-serving and on demand
business applications:
•Ultrathin, high-availability,
rack-optimized, 1 U servers
•Single core Intel Xeon
processors from 2.8 to 3.8 GHz
with 2 MB L2 cache, or dual
core 2.8 GHz Intel Xeon
processors with 4 MB L2 cache
•800 MHz1FSB and Intel
Extended Memory 64
Technology (EM64T)
•1 to 4 GB of two-way
interleaved PC2-3200 ECC
double data rate (DDR2)
SDRAM RDIMM memory
•Eight DIMM slots supporting up
to 16 GB memory
•Support for Ultra320 SCSI or
Serial-ATA (SATA) (depends on
model)
•Choice of open bay HDD
configurations
•Single-channel Ultra320 SCSI
controller for high-speed,
internal disk storage solutions
up to 600 GB2
•Two PCI-X slots, one 64-bit/133
MHz (full height, full length) one
64-bit/100 MHz (low profile, half
length)
•Optional support for
PCI-Express Adapters
•585-watt, auto-ranging power
supply
•Integrated systems
management processor
•Integrated dual Gigabit Ethernet
•One serial port
(16550A-compatible), three USB
ports, and a mouse, keyboard,
and video port
For ordering, contact:
Your IBM representative, an IBM Business
Partner, or the Americas Call Centers at
800-IBM-CALL Reference: SE001
This announcement is provided for your information only. For additional information, contact your IBM representative,
call 800-IBM-4YOU, or visit the IBM home page at: http://www.ibm.com.
IBM United States IBM is a registered trademark of International Business Machines Corporation. 106-239

Description
xSeries 336 related options
The xSeries 336 server features an Intel Xeon processor
system that supports single-core internal processing
speeds up to 3.8 GHz, or dual-core internal processing
speeds up to 2.8 GHz. Processing operations to memory
and the PCI bus occur at 133 MHz. It contains an
integrated, full-speed 2 MB ECC L2 cache per core. This
system supports up to two-socket (four-core) SMP
applications through installation in the second processor
slot of xSeries 336 models with like processors.
High-performance server subsystems: These servers are
high-throughput, SMP-capable network servers with
excellent scalability when you add memory and a second
processor. They incorporate powerful 800 MHz Intel Xeon
processors with 2 MB advanced transfer L2 cache per
core. Data transfer across the system bus is at a 4X rate
(four data transfers per clock) for an effective data
transfer rate of 800 MHz (5.3 GB/s). Address transfers
across the system bus is at a 2x rate (two addresses per
clock) for an effective transfer rate of 400 MHz.
Two Intel Xeon connectors are standard on the system
board to support installation of a second processor.
High-speed 400 MHz PC2-3200 ECC DDR2 SDRAM RDIMM
memory is optimized for 800 MHz processor-to-memory
subsystem performance.
Additional features
•System board contains eight DIMM connectors
supporting 256, 512 MB, 1 GB, or 2 GB PC2-3200 ECC
DDR2 SDRAM RDIMM memory:
−Support for up to 16 GB of system memory
−Interleaved memory populated with two DIMM at a
time with the same size DIMM
−Support for mixed memory sizes in pairs
−Support for Chipkillmemory
•Single-channel, 64-bit, Ultra320 SCSI PCI controller
supports high-speed (up to 320 MB/s) data transfer,
and Low-Voltage Differential SCSI (LVDS) internal
storage solutions.
•IDE controller supports DVD-ROM.
•Support for SATA drive employs high-speed (up to 1.5
Gbps) dual differential pairs to communicate with
simple-swap SATA HDDs.
•Two full-duplex Broadcom 5721 Gigabit Ethernet PCI
controllers speed network communications to LAN
clients.
The xSeries 336 subsystems are tuned to provide solid
system throughput from processor, to memory, to bus, to
disk-intensive I/O. These features combined with SMP
capability make this server an excellent choice for:
•Web caching
•Dynamic Web serving
•Firewall
•Telecommunications
•Active directory services
•Scientific and technical computing
•Linuxclustering
High-availability and serviceability features: The xSeries
336 server subsystem delivers excellent reliability and
serviceability features:
•Two 3.5-in or four 2.5-in hot-swap Ultra320 HDD bays
(hot-swap models) with SCA-2 connectors supporting
LVD HDDs
•Hot swap/redundant cooling fans
•Optional hot swap/redundant power supplies
•ECC DIMMs combined with an integrated ECC memory
controller correcting many soft and hard single-bit
memory errors, while minimizing disruption of service
to LAN clients
•Chipkill memory for the detection and correction of
many multibit memory errors, helping keep the server
up and running while taking the inoperative memory
offline
•ECC L2 cache processors to improve data integrity and
help reduce downtime
•PFA on HDD options, memory, processors, VRMs, and
fans to help alert the system administrator of an
imminent component failure
•Dual Broadcom 5721 Gigabit Ethernet controllers that
support:
−Failover, Adapter Fault Tolerance (AFT)
−PXE 2.0 Boot Agent
−ASF 2.0 support
−Wake on LAN
−Load balancing or teaming
•Worldwide, voltage-sensing 585-watt power supply
with auto restart
•Up to 10 cooling fans for excellent cooling with added
reliability:
−One fan in each power supply
−Seven system fans for processors, memory, and
HDD bays
−Fan speed controls incorporated to reduce noise
while reducing system temperatures
•Integrated systems management processor for
diagnostic, reset, POST, and auto recovery functions;
monitoring temperature, voltage, and fan speed; alerts
generated when thresholds are exceeded (refer to the
Limitations section for restrictions)
•Information LED panel giving visual indications of
system well-being
• Light Path Diagnostics and on-board diagnostics
providing an error log to help find a failing component,
helping reduce downtime and service costs
•Easy access to system board, adapter cards,
processor, and memory
•CPU failure recovery in SMP configurations:
−Forces failed processor offline
−Automatically reboots server
−Generates alerts
−Continues operations with the working processor
Expandability and growth: The xSeries 336 server
contains high levels of function and storage capacity for
a 1 U, 19-inch rack-drawer package. It supports customer
installation of adapters, processors, memory, and HDD
options. Functions (such as SVGA video, Ultra320 SCSI,
SATA, and two Gigabit Ethernet controllers) are
integrated on the system board. Features include:
•Rack-optimized design for 19-inch wide,
industry-standard rack cabinets supported in the
NetBAY42 and NetBAY25
106-239 -2-

•Eight DIMM connectors capable of support for up to 16
GB of system memory
•Two available PCI-X adapter card slots
−One full-length —64-bit/133 MHz (or PCI Express x8
slot)
−One half-length —64-bit/100 MHz
•Choice of:
−Two 3.5-in slim-high, hot-swap Ultra320 HDD bays
(up to 600 GB)
−Four 2.5-in slim-high, hot-swap Ultra320 HDD bays
(up to 292 GB)
−Two simple-swap SATA HDD bays (up to 500 GB)5
•DVD-ROM on some models
•ATI 7000M controller with 16 MB of video memory
Systems management: Integrated Baseboard
Management Controller (BMC):
The xSeries 336 server includes an integrated BMC that
provides industry-standard Intelligent Platform
Management Interface (IPMI) 1.5-compliant systems
management. The BMC comes standard, and shares one
of the two onboard Ethernet ports for access. The BMC
can be accessed via software that is compatible with IPMI
1.5 (xCAT, for example). The BMC is implemented using
industry-leading OSA firmware and applications.
Features and benefits:
•Monitoring of system and battery voltage and system
temperature
•Fan speed control
•Fan tachometer monitor
•System ID and planar version detection
•System power and reset control
•NMI and SMI detection and generation (system
interrupts)
•Serial port text console redirection
•System LED control (power, HDD, activity, alerts,
heartbeat)
You can also purchase the optional Remote Supervisor
Adapter (RSA) II SlimLine for additional systems
management function.
RSA II SlimLine adds accelerated graphics and delivers
advanced control and monitoring features to manage your
xSeries server (selected models) at virtually any time,
from virtually any place. This daughter card can be added
to the server through a connector that connects to the
planar or through a riser for select models. This adapter
enables easy console redirection with text and graphics,
keyboard, and mouse (operating system must support
USB) support over the system management LAN
connections.
With video compression now built into the adapter
hardware, the adapter enables the greater screen sizes
and refresh rates standard in the marketplace. You can
display server activities from power-on to full operation
with remote user interaction at virtually any time.
The embedded Web server provides remote control from
any standard Web browser. No additional software is
required on the remote administrator′s workstation. For
users who are accustomed to a command-line interface
(CLI), the administrator can also use the provided CLI
from a Telnet session to perform some of the functions
that they can perform from the Web server. The RSA II
SlimLine provides remote management and control of the
system independent of the server status, in many cases
even if the server is powered off or otherwise disabled.
Features and benefits:
•Continuously monitors system environmentals
(temperatures and voltages), operating system status,
critical system components such as processors, VRMs,
memory, fans, power supplies, and power backplanes
(where supported by the system).
•Video compression hardware is built in, eliminating
drivers.
•Faster graphics support makes monitoring and control
more efficient.
•Virtual CD and diskette drives enable you to configure
and diagnose a server remotely without a visit from
your IT staff.
•RSA II SlimLine supports Secure Socket Layer (SSL)
and Lightweight Directory Access Protocol (LDAP).
•The adapter is integrated with IBM Director and
Director Agent.
•Built-in LAN and serial connectivity support virtually
any network infrastructure.
•Multiple alerting functions warn systems
administrators of potential problems, over e-mail,
pager support, LAN, or SNMP.
•It can be installed on the system planar using a
dedicated connector, eliminating the need for an
empty PCI-X slot.
The RSA II SlimLine features are similar to the RSA II
except for the following:
•Reset button is not accessible from the back of the
system.
•Mini-USB cable is no longer required; the adapter uses
the internal USB bus. The system has a designated
systems management Ethernet port, activated only
when RSA II SlimLine is installed.
•External ac adapter is not required; the adapter uses
standby power from system power supplies.
•Status LEDs are not viewable externally.
•The RSA II SlimLine no longer supports the previous
RSA II interconnect function.
IBM Director: The xSeries 336 server also features IBM
Director, a powerful, highly integrated,
systems-management software solution built on industry
standards and designed for ease of use. Exploit your
existing enterprise or workgroup-management
environments and use rich security to access and manage
physically dispersed IT assets more efficiently over the
internet. It can help reduce costs through:
•Reduced downtime
•Increased productivity of IT personnel and end users
•Potentially reduced service and support costs
IT administrators can view the hardware configuration of
remote systems in detail and monitor the usage and
performance of critical components such as processors,
HDDs, and memory.
IBM Director includes a portfolio of integrated server
tools that work with the RSAs or other
-3- 106-239

systems-management monitoring functions. Typical
functions and monitoring capabilities can include:
•PFA-enabled critical hardware components
•Temperature
•Voltage
•Fan speed
•Light Path Diagnostics
IT administrators have comprehensive, virtual on-site
control of xSeries servers with the ability to remotely:
•Access the server often regardless of its status
•Inventory and display detailed system and component
information
•View server bootup during POST
•Browse and delete logs of events and errors
•Reset or power cycle the server
•Monitor and set thresholds on server health including:
−Operating system load
−POST time-out
−Voltage
−Temperature
•Set proactive alerts for critical server events including
PFA on:
−Processors
−VRMs
−Memory
−Fans
−Power supplies
−HDDs
•Define automated actions such as:
−Send e-mail or page to an administrator
−Execute a command or program
−Pop up an error message to the IBM Director
console
•Flash BIOS
•Monitor and graph the use of server resources such
as:
−Memory
−Processor
−HDDs
•Identify potential performance bottlenecks and react
to prevent downtime
IBM Director Agent integrates into leading workgroup and
enterprise systems management environments via
Upward Integration Modules (available from IBM and
third parties). Advanced management capabilities built
into xSeries servers are available through:
•TivoliEnterprise and Tivoli NetView
•Computer Associates Unicenter TNG
•HP OpenView
•MicrosoftSMS
•BMC Patrol
•NetIQ
World-class support tools and programs: The xSeries 336
server includes a number of tools and programs designed
to make ownership a positive experience. From the start,
IBM programs help you purchase servers, get them
running, and keep them running over the long haul. IBM
can help your company maintain ownership of technology
leadership network servers.
•IBM on-site three-year limited warranty with
next-business-day service (same-business-day service
optionally available) helps protect your investment if
a problem occurs. This service also includes
replacement of parts identified through PFA.
• The ServerProven6program lets you confidently
configure your server with various devices and
operating systems. This program provides
compatibility information from actual testing of the
xSeries 336 server with various adapters and devices.
•The ServerGuide CD library includes online
publications, in addition to utilities and drivers that
enable assisted loading of popular network operating
systems.
•Electronic support on the Web provides additional
support in an easy-to-use format.
Standard xSeries 336 configurations
Express HDD CD-
Model Processor Memory Interface ROM HDD Other
8837-1RU 3.0 GHz 1 GB SCSI 3.5-in DVD Open bay, hot-swap
L2 Cache: 2 MB per core (all models)
Product positioning
The xSeries 336 server is an ultrathin rack platform. The
most powerful 1 U server of the xSeries rack-optimized
offerings, it is positioned between the xSeries 306 and the
xSeries 346 server. The xSeries 306 server also has a
1 U form factor, but supports uniprocessor operations
and only fixed Ultra320 SCSI or SATA HDDs. The xSeries
346 server includes more slots and drive bays; however,
it requires a 2 U rack space.
High-density, two-way, Xeon-based xSeries 336 and
xSeries 346 servers enable customer installation of
features. You can prepare for future expansion to meet
changing reliability needs. At the same time, the server
can handle emerging applications requiring maximum
computing power and function in a small amount of rack
space. These applications include:
•Web caching
•Dynamic Web serving
•Firewall
•Telecommunications
•Active directory services
•Scientific and technical computing
•Linux clustering
These powerful servers also meet traditional enterprise
network server requirements, but with an added benefit
of requiring less space.
Reference information
1GHz and MHz denote the internal and/or external clock
speed of the microprocessor only, not application
performance. Many factors affect application performance.
2A single physical processor′s resources look like two logical
processors to the operating system and other applications
allowing different tasks to execute simultaneously. This
provides a performance boost on multitasking operations.
3When referring to HDD or tape backup capacity, GB stands
for 1,000,000,000 bytes. Total user capacity may vary
depending on operating environments.
4For information on the IBM Statement of Limited Warranty,
call 800-IBM-SERV (426-7378) or contact your IBM
representative or reseller. Copies are available upon
request.
5Not available on models with dual-core processors.
6IBM makes no warranties, expressed or implied, regarding
non-IBM products and services that are ServerProven,
including but not limited to implied warranties of
106-239 -4-

merchantability and fitness for a particular purpose. These
products are offered and warranted solely by third parties.
Business Partner information
If you are a Direct Reseller - System Reseller acquiring
products from IBM, you may link directly to Business
Partner information for this announcement. A
PartnerWorld ID and password are required (use IBM ID).
BP Attachment for Announcement Letter 106-239
https://www.ibm.com/partnerworld/
mem/sla.jsp?num=106-239
Trademarks
ServerGuide and Chipkill are trademarks of International
Business Machines Corporation in the United States or other
countries or both.
xSeries, Predictive Failure Analysis, Wake on LAN, Tivoli,
NetView, ServerProven, and xSeries are registered
trademarks of International Business Machines Corporation
in the United States or other countries or both.
Intel is a registered trademark of Intel Corporation.
Microsoft is a trademark of Microsoft Corporation.
Linux is a trademark of Linus Torvalds in the United States,
other countries or both.
Other company, product, and service names may be
trademarks or service marks of others.
-5- 106-239

IBM United States
Announcement
Supplemental Information
April 4, 2006
Publications
The following publications and CD-ROMs are shipped with
the xSeries336 server.
•
xSeries 336 Installation Guide contains an introduction
to the computer, installation and setup, installing
options, reference information, and problem
determination. The installation guide has easy-to-use
text and illustrations to enable you to quickly set up
your xSeries 336 server.
•
Documentation/User ′ s Guide CD contains translated
versions of the product user′s guide.
•
ServerGuide contains online publications and
drivers to support the xSeries 336 server. In addition,
it includes a set of easy-to-use utilities to help you
install the system using CDs of several popular
network operating systems.
•IBM Director systems management software is
included.
Note: Software versions, features, and functions shipped
with these systems may change as new releases become
available or may be discontinued at any time.
The
xSeries 336 Installation Guide and Hardware
Maintenance Manual,
in U.S. English versions, are
available from
http://www.ibm.com/pc/support
Click servers, then the server family, and then Online
Publications.
Services
IBM Integrated Technology Services
IBM services include business consulting, outsourcing,
hosting services, applications, and other technology
management.
These services help you learn about, plan, install,
manage, or optimize your IT infrastructure to be an On
Demand Business. They can help you integrate your
high-speed networks, storage systems, application
servers, wireless protocols, and an array of platforms,
middleware, and communications software for IBM and
many non-IBM offerings. IBM is your one-stop shop for
IT support needs.
For details on available services, contact your IBM
representative or visit
http://www.ibm.com/services/
For details on available IBM Business Continuity and
Recovery Services, contact your IBM representative or
visit
http://www.ibm.com/services/continuity
For details on education offerings related to specific
products, visit
http://www.ibm.com/services/learning/index.html
Select your country, and then select the product as the
category.
Technical information
Physical specifications
8837-1Rx
Processor Xeon
Internal speed 3.0 GHz
External speed 200/800 MHz
Number standard 1
Maximum 2
L2 cache (full speed) 2 MB
Memory (400 MHz SDRAM) 1 GB ECC
RDIMMs 2 x 512 MB
DIMM sockets 8
Address capability 16 GB
Video SVGA
Memory 16 MB
HDD controller Ultra320
Channels 1
Connector internal 1
Connector external 0
IDE controller IDE ATA-100
Channels 2
Connector internal 2
Connector external 0
HDD Open bay 3.5-in
Total bays 3
5.25/3.5-in slim 1
3.5-in slim 2
2.5-in slim 0
Hot-swap 2
Internal capacity 600 GB(7)
Bays available 2
5.25/3.5-in slim 0
3.5-in slim 2
2.5-in slim 0
Hot-swap 2
Total slots 2(8)
PCI 2
64-bit/133 MHz 1
64-bit/100 MHz 1
Slots available 2
Management processor Standard
Ethernet controllers 2
Rate 10/100/1k Mbps
DVD-ROM (IDE) 1
Diskette drive 0
Power supply 585 W
Number standard 1
Hot-swap Optional
Redundant power Optional
Auto restart Yes
7Capacities are based on installation of two 3.5-in 300 GB
Ultra320 HDDs.
For the latest information on supported HDD options, visit
http://www.ibm.com/servers/eserver/
serverproven/compat/us/
This announcement is provided for your information only. For additional information, contact your IBM representative,
call 800-IBM-4YOU, or visit the IBM home page at: http://www.ibm.com.
IBM United States IBM is a registered trademark of International Business Machines Corporation. 106-239

8One adapter slot is full-length. The other slot is half-length
supporting cards not exceeding 180 mm in length.
DVD-ROM drive characteristics
•Speed: 8X
•Sustained data transfer rate: 3.6 MB/s max
•Average access time: 130 ms
•Buffer size: 256 KB
•Interface: Ultra DMA Mode 2 33.3 MBs max
•Compatibility: DVD-R/RW
SCSI HDD characteristics
36.4 GB HDD —2.5-in
Formatted capacity 36,400 million bytes
Average read seek time 4.5 ms
Burst transfer rate (maximum) 320.0 MB/s
Average latency 3.0 ms
Drive rotation speed (rpm) 10,000 rpm
Sustained data transfer rate 63 to 94 MB/s
PFA/S.M.A.R.T enabled Yes
Interface Ultra320 SCSI
73.4 GB HDD —2.5-in
Formatted capacity 73,400 million bytes
Average read seek time 4.5 ms
Burst transfer rate (maximum) 320.0 MB/s
Average latency 3.0 ms
Drive rotation speed (rpm) 10,000 rpm
Sustained data transfer rate 63 to 94 MB/s
PFA/S.M.A.R.T enabled Yes
Interface Ultra320 SCSI
Video subsystem
•ATI 7000M Graphics Controller chip
•Integrated on planar and connected to the PCI bus
•16 MB SDRAM standard/maximum video memory
•128-bit graphics engine with 8, 16, and 32 bpp mode
acceleration
•32 bpp (4G colors/True Color) support
•Integrated 300 MHz RAMDAC
•DDC2B monitor communications support
Supported video mode capabilities for the SVGA PCI
controller:
MicrosoftWindows2000 and Linux
Refresh
Resolution Colors rate (Hz)
640 x 480 x 8 256 60, 72, 75, 85, 90, 100, 120,
160, 200
640 x 480 x 16 64K 60, 72, 75, 85, 90, 100, 120,
160, 200
640 x 480 x 24 16M 60, 72, 75, 85, 90, 100, 120,
160, 200
640 x 480 x 32 16M 60, 72, 75, 85, 90, 100, 120,
160, 200
800 x 600 x 8 256 60, 70, 72, 75, 85, 90, 100, 120,
160, 200
800 x 600 x 16 64K 60, 70, 72, 75, 85, 90, 100, 120,
160, 200
800 x 600 x 24 16M 60, 70, 72, 75, 85, 90, 100, 120,
160, 200
800 x 600 x 32 16M 60, 70, 72, 75, 85, 90, 100, 120,
160, 200
1024 x 768 x 8 256 60, 70, 72, 75, 85, 90, 100, 120,
140, 150, 160, 200
1024 x 768 x 16 64K 60, 70, 72, 75, 85, 90, 100, 120,
140, 150, 160, 200
1024 x 768 x 24 16M 60, 70, 72, 75, 85, 90, 100, 120,
140, 150, 160, 200
1024 x 768 x 32 16M 60, 70, 72, 75, 85, 90, 100, 120,
140, 150, 160, 200
1280 x 1024 x 8 256 60, 70, 74, 75, 85, 90, 100, 120
1280 x 1024 x 16 64K 60, 70, 74, 75, 85, 90, 100, 120
1280 x 1024 x 24 16M 60, 70, 74, 75, 85, 90, 100, 120
1280 x 1024 x 32 16M 60, 70, 74, 75, 85, 90, 100, 120
1600 x 1200 x 8 256 52, 58, 60, 66, 75, 76, 85, 92, 100
1600 x 1200 x 16 64K 52, 58, 60, 66, 75, 76, 85, 92, 100
1600 x 1200 x 24 16M 52, 58, 60, 66, 75, 76, 85, 92, 100
1600 x 1200 x 32 16M 52, 58, 60, 66, 75, 76, 85, 92, 100
Note: Some modes are not supported by all monitors.
Dimensions
•Width: 440 mm (17.3 in)
•Depth: 686 mm (27.0 in)
•Height: 43 mm (1.7 in)
•Weight:
−Minimum configuration 12.7 kg (28 lb)
−Maximum configuration 15.6 kg (35.5 lb)
Electrical
•100 to 127 (nominal) V ac; 50 Hz or 60 Hz; 5.5 A
•200 to 240 (nominal) V ac; 50 Hz or 60 Hz; 2.75 A
•Input kilovolt-amperes (kVA) (approximately):
−Minimum configuration: 0.172 kVA
−Maximum configuration: 0.550 kVA
•Btu output:
−Minimum configuration: 587 Btu/hr (172 watts)
−Maximum configuration: 1878 Btu/hr (550 watts)
•Acoustical noise level emission level: Sound power
levels
−6.9 bels (idling)
−6.9 bels (operating)
Note: The noise emission level stated is the declared
(upper limit) sound power level, in bels, for a random
sample of machines. All measurements made in
accordance with ISO 7779 and reported in conformance
with ISO 9296.
xSeries 336 servers are intended for use as rack-drawer
servers and are tested and designed to operate in a
horizontal position.
106-239 -2-

Standards: These systems support or comply with the
following standards:
•Multi Processor Specification (MPS) 1.4
•Peripheral Component Interconnect (PCI) specification
2.2
•Hardware-enabled to meet the International
Organization for Standardization (ISO) 9241, Part 3
Equipment approvals and safety
•FCC —Verified to comply with Part 15 of the FCC
Rules, Class A
•Canada ICES-003, issue 3, Class A
•UL 19509
•CSA C22.2 No. 950
•NOM-0189
9These servers are certified by the respective UL and NOM
agencies.
Operating environment
•Temperature:
−10.0° to 35.0°C (50° to 95°F) (Server on)
−0.0° to 60.0°C (-32° to 140°F) (Server off)
•Relative humidity: 8% to 80%
•Maximum altitude: 2,133 m (7,000 ft)
Hardware requirements: For attended installation of an
operating system, this server requires a compatible:
•Keyboard
•Mouse
•HDD
•Display
Unattended or remote installation may be performed
without requiring some or all of these components.
Review your unattended software installation program
information for specific hardware configuration
requirements.
For service, the server requires a compatible:
•Keyboard
•Mouse
•HDD
•Display
When having the unit serviced, plan to have these
components attached to your server either directly or
indirectly via a console.
Software requirements: The following software products
have been tested by IBM and software publishers in the
latest available versions, and where appropriate, are or
will soon be certified by the publisher to be compatible
with the xSeries 336 server.
Operating systems
Software
Publisher Description
Microsoft Windows 2000 Advanced Server
Windows 2000 Server
Windows Server 2003, Web Edition
Windows Server 2003, Standard Edition
Windows Server 2003, Enterprise Edition
Linux Red Hat Enterprise Linux 3 AS for x86(10)
Red Hat Enterprise Linux 3 ES for x86(10)
Red Hat Enterprise Linux 3 for AMD64 and
Intel(R) EM64T(10)
Novell SUSE Linux Enterprise Server 8(10)
VMware VMware ESX Server V2.1
10 Support and certification is planned for these operating
systems.
The following software is supported as preloads:
Linux Red Hat Enterprise Linux ES 3 Standard
Red Hat Enterprise Linux WS 3 Standard
Microsoft Windows Server 2003 Standard Edition
Windows Server 2003 Enterprise Edition
Note: Additional support, certification, and version
information on network operating systems can be
accessed at
http://www.ibm.com/servers/eserver/
serverproven/compat/us/
Compatibility: The xSeries 336 server contains licensed
system programs that include set configuration, set
features, and test programs. System SurePathBIOS is
loaded from a “flash” EEPROM into system memory. This
BIOS provides instructions and interfaces designed to
support the standard features of the xSeries 336 server
and to maintain compatibility with many current software
programs.
For detailed information about IBM and non-IBM devices,
adapters, software, and network operating systems
supported with xSeries servers, visit
http://www.ibm.com/pc/support
Contact your IBM representative, IBM Business Partner,
or refer to the IBM Sales Manual for information on the
compatibility of hardware and software for xSeries
servers. The Sales Manual is updated periodically as new
features and options are announced that support these
servers.
Limitations
•The xSeries 336 server contains a single, configurable
serial port. It can be configured to be
operating-system-controlled,
service-processor-controlled, or shared between the
two. You can set the configuration by changing the
header location to which the internal serial cable is
plugged. The default location from the factory is in the
shared position. In the shared position, the service
processor controls the port until the operating system
is running, then the operating system takes control.
The service processor can regain control of the port
for user-configured dial-out situations or if the
operating system is not available, but operating
system control cannot be reestablished without
resetting the server.
•xSeries 336 servers can address a maximum of 16 GB
of system memory by adding a 2 GB PC2-3200 ECC
-3- 106-239

DDR2 SDRAM RDIMM in each of the eight DIMM slots.
All supported system memory is addressable through
direct memory access. The xSeries 336 server
supports 256 MB, 512 MB, 1 GB, and 2 GB PC2-3200
ECC DDR2 SDRAM RDIMM memory. All supported
DIMMs can coexist in the same system. Memory must
be populated in pairs. Refer to the Planning
information section for supported memory options.
•To ensure proper air flow for cooling, the xSeries 336
server requires a rack with a perforated door, such as
the NetBAY42 SR or NetBAY25 SR. An alternative is
to remove the front door of rack cabinets where the
door panel is of solid construction.
•Microprocessor SMP upgrades must be of the same
type and clock speed. Mixing microprocessors of
different speeds or cache size is not supported.
•Use the version of ServerGuide that is shipped with
the system, or a later version, to load software and
drivers. Earlier versions of ServerGuide may not be
compatible with the server.
Planning information
Customer responsibilities
xSeries 336 and related options:
The xSeries 336 server
and related options are designated as customer setup.
Customer setup instructions are shipped with system and
options.
Configuration information
Bay configuration
This xSeries 336 server supports two 3.5-in Ultra320 SCSI
HDDs, comes with a DVD-ROM, and is an open bay model.
Models using the DVD-ROM are cabled directly to the IDE
port.
Cabling
—
Standard Non-RAID configurations: xSeries
336 hot-swap models contain a DASD backplane
supporting up to four hot-swap, SCA-2-compliant drive
bays. The backplane is connected to the internal
connector of the integrated Ultra320 SCSI controller
through a 16-bit LVD SCSI cable.
Additional cabling alternatives: xSeries 336 non-hot-swap
models support two simple-swap SATA HDDs directly to
a SATA controller through a two-drop cable.
Rack installations: xSeries 336 1 U rack-drawer models
are designed to be installed in a 19-inch rack cabinet
designed for 711.1 mm (28 in) deep devices, such as the
NetBAY42U ER and NetBAY42U SR. Installation into
some of the older Netfinityracks (9306900, 9306910,
9306200) requires a rack extension kit for proper cable
bend radius and cooling.
If an xSeries 336 server is mounted in a non-IBM rack, the
rack must satisfy the following specifications:
•The rack must meet EIA-310-D standards for mounting
flanges and hole locations.
•The front to rear distance of the mounting flanges must
be between 457.2 and 762 mm (24 and 30 in).
•The thickness of the mounting flanges must be
between 1.9 and 3.3 mm (0.08 and 0.13 in).
• The mounting flanges must have either 7.1-mm
(0.28-in) diameter holes or 9.6-mm (0.38-in) square
holes on the standard EIA hole spacing.
•The rack must have a minimum depth of 50 mm (1.97
in) between the front mounting flange and inside of the
front door for appropriate cooling.
•The rack must have a minimum depth of 166 mm (6.53
in) between the rear mounting flange and inside of the
rear door to install the server and provide cable
management space.
•The minimum side-to-side clearance in the rack
between the front and rear mounting flanges must be
467 mm (18.2 in) to accommodate the width of the
server and the slide mounting brackets.
•The minimum side-to-side clearance in the rack
between each door and the mounting flanges must be
484 mm (19.1 in) to accommodate the slide mounting
brackets.
•The rack must include perforated front and rear doors
and must not prevent the flow of cool air into or out
of the rack.
•The weight-handling capacity of the rack must be able
to support the maximum rack configuration, including
all servers, external cables, power distribution units,
and so on.
•The rack must provide proper stabilization so that the
rack does not become unstable when servers are
pulled out for service.
Processor options: The xSeries 336 server is an Intel
Xeon processor system that supports internal processing
speeds of up to 3.6 GHz and processing operations to
memory and the PCI bus at 133 MHz. It contains an
integrated, full-speed 1 MB ECC L2 cache. This system
supports SMP applications through installation in the
second processor slot of xSeries 336 models with like
processors.
Supported processor options: The following processor
options are supported:
•2.8 GHz 800 MHz 2MB L2 Cache Xeon Processor
(40K2509)
•3.0 GHz 800 MHz 2MB L2 Cache Xeon Processor
(40K2510)
•3.2 GHz 800 MHz 2MB L2 Cache Xeon Processor
(40K2511)
•3.4 GHz 800 MHz 2MB L2 Cache Xeon Processor
(40K2512)
•3.6 GHz 800 MHz 2MB L2 Cache Xeon Processor
(40K2513)
•3.8 GHz 800 MHz 2MB L2 Cache Xeon Processor
(40K2514)
•Dual Core Intel Xeon Processor 2.8 GHz (40K2501)
Supported memory options: The following memory
options are supported:
•512 MB (1 x 512 MB) PC2-3200 CL3 ECC DDR2 SDRAM
RDIMM Non-Chipkill(39M5858)
•1 GB (2 x 512 MB Kit) PC2-3200 CL3 ECC DDR2 SDRAM
RDIMM Non-Chipkill (39M5818)
•1 GB (2 x 512 MB Kit) PC2-3200 CL3 ECC DDR2 SDRAM
RDIMM (39M5821)
106-239 -4-

•2 GB (2 x 1 GB Kit) PC2-3200 CL3 ECC DDR2 SDRAM
RDIMM (39M5809)
•4 GB (2 x 2 GB Kit) Dual Rank PC2-3200 CL3 ECC DDR2
SDRAM RDIMM (39M5812)
•4 GB (2 x 2 GB Kit) Single Rank PC2-3200 CL3 ECC
DDR2 SDRAM RDIMM (39M5815)
•8 GB (2 x 4 GB Kit) PC2-3200 CL3 ECC DDR2 SDRAM
RDIMM (30R5145)
Power considerations: The xSeries 336 sever includes a
standard 585-watt power supply. This power supply is
capable of providing sufficient power to run the server
fully configured with supported devices.
Cable orders: The dual 10/100/1000 Mbps, full-duplex,
Ethernet PCI controllers, standard with the xSeries 336
server, are connected directly to independent RJ-45
connectors. The RJ-45 connectors provides a 10/100/1000
Base-T interface (either at half- or full-duplex) for
connecting twisted-pair cable to the Ethernet network.
Cabling is not included with the server. To connect the
Ethernet controller to a repeater or switch, use a UTP
cable with RJ-45 connectors at both ends. For 100 Mbps,
or higher, Category 5e, or better, cabling must be used.
There are no additional cabling requirements, other than
for system power, keyboard, mouse, and monitor
connections.
Installability: The xSeries 336 server requires about 20
minutes for installation. Installation includes unpacking,
setting up, and powering on the system. Additional time
is required to install an operating system, additional
adapters, or features.
Packaging
One box
•System unit carton: System unit
•Country kit carton
−Power cord
−xSeries 336 Installation Guide
−Rack Installation Guide
−ServeRAIDSupport Package
−Velcro/cable tie package
−CD-ROM packages11
−Cable Management Arm
11 Documentation, ServerGuide, IBM Director, Broadcom
The xSeries 336 server is shipped in a single package.
The country kit carton is contained inside the top portion
of the system unit carton.
Processor upgrade options
•Intel Xeon processor
•Safety instructions/warranty
Security, auditability, and control
Security and auditability features include:
•Power-on and privileged-access password functions
provide controls of who has access to the data and
server setup program on the server.
•A set unattended boot mode allows the system
keyboard to be locked to all entries except the
password and at the same time allows other
computers on the network to access the system disk
drive.
•A selectable boot sequence can be used to prevent
unauthorized installation of software or removal of
data from the diskette drive.
These servers are intended to be installed and secured
in a rack. It is a customer′s responsibility to ensure that
the server and rack installation are secure to prevent
sensitive data from being removed.
The customer is responsible for evaluation, selection, and
implementation of security features, administrative
procedures, and appropriate controls in application
systems and communications facilities.
Terms and conditions
IBM Global Financing: Yes
To obtain copies of the IBM Statement of Limited
Warranty, contact your reseller or IBM.
In the United States, call 800-IBM-SERV (426-7378) or
write to:
Warranty Information
P.O. Box 12195
Research Triangle Park, NC 27709
Attn: Dept JDJA/B203
Warranty period
•System hardware —Three years
•Optional features —One year
Optional IBM features initially installed in an IBM system
carry the same warranty period as the system. If installed
after the initial system installation, they carry the balance
of the system warranty or the optional feature warranty,
whichever is greater.
Warranty service: If required, IBM provides repair or
exchange service depending on the type of warranty
service specified for the machine. IBM will attempt to
resolve your problem over the telephone or electronically
by access to an IBM Web site. You must follow the
problem determination and resolution procedures that
IBM specifies. Scheduling of service will depend upon the
time of your call and is subject to parts availability.
Service levels are response time objectives and are not
guaranteed. The specified level of warranty service may
not be available in all worldwide locations. Additional
charges may apply outside IBM′s normal service area.
Contact your local IBM representative or your reseller for
country- and location-specific information.
Customer replaceable unit (CRU) (for example, keyboard,
mouse, speaker, memory, or HDD) service and on-site
service for other selected parts.
CRU service: IBM provides replacement CRUs to you for
you to install. CRU information and replacement
instructions are shipped with your machine and are
available from IBM at any time on your request. CRUs
are designated as being either a Tier 1 or a Tier 2 CRU.
Installation of Tier 1 CRUs is your responsibility. If IBM
installs a Tier 1 CRU, at your request, you will be charged
for the installation. You may install a Tier 2 CRU yourself
or request IBM to install it, at no additional charge under
the type of warranty service specified, on-site service.
Based upon availability, CRUs will be shipped for
next-business-day (NBD) delivery. IBM specifies in the
materials shipped with a replacement CRU whether a
defective CRU must be returned to IBM. When return is
required, return instructions and a container are shipped
-5- 106-239

with the replacement CRU, and you may be charged for
the replacement CRU if IBM does not receive the
defective CRU within 30 days of your receipt of the
replacement.
The following parts are designated as Tier 1 CRUs:
•Fan
•Memory
•Memory Expansion Card, 4 slot
•Power Supply
•Line Cord
•HDD
•PCI Spacer
•Lift Handle Kit
•HDD Blank Filler
•Chassis Top Cover Assembly
•System Bezel
•System Labels
On-site service: IBM on-site repair (IOR), 9 hours per day,
Monday through Friday excluding holidays, NBD
response. IBM will repair the failing machine at your
location and verify its operation. You must provide a
suitable working area to allow disassembly and
reassembly of the IBM machine. The area must be clean,
well-lit, and suitable for the purpose. On-site service is
not available in all countries, and some countries have
kilometer or mileage limitations from an IBM service
center. In those locations where on-site service is not
available, the normal in-country service delivery is used.
Call IBM at 800-IBM-SERV (426-7378) to assist with
problem isolation for hardware to determine if warranty
service is required. Telephone support may be subject to
additional charges, even during the limited warranty
period.
International Warranty Service (IWS): IWS is available
during the warranty period to customers who travel or
relocate to countries where their computer is sold and
serviced by IBM or IBM resellers authorized to perform
warranty service. Eligible IBM computers are identified
by their four-digit machine type.
You can obtain IWS through the method of service, such
as CRU, depot, carry-in, or on-site, provided in the
servicing country. Service methods and procedures vary
by country, and some service or parts may not be
available in all countries. Service centers in certain
countries may not be able to service all models of a
particular machine type. In addition, some countries may
have fees and restrictions that apply at the time of
service.
To determine the eligibility of your computer and to view
a list of countries where service is available, visit
http://www-3.ibm.com/pc/support/site.wss/
warranty/warranty.vm
For more information on IWS, refer to Services
Announcement 601-034, dated September 25, 2001.
Note: Due to the earth′s magnetic field, CRT monitors are
manufactured to work in northern, southern, and
equatorial regions of the earth and may not produce a
satisfactory image when moved between them. Any
required adjustment (if possible) is not covered under
IWS and may be subject to a chargeable action. The
magnetic field does not affect flat-panel LCD monitors and
ThinkPadLCD displays.
Licensing: Programs included with this product are
licensed under the terms and conditions of the License
Agreements that are shipped with the system.
Maintenance services
—
ServicePac  ,
ServiceSuite
 , and ServiceElect
ServicePac, ServiceSuite and ServiceElect provide
hardware warranty service upgrades, maintenance, and
selected support services in one agreement.
Warranty service upgrade: During the warranty period,
warranty service upgrade provides an enhanced level of
on-site service for an additional charge. A warranty
service upgrade must be purchased during the warranty
period and is for a fixed term (duration). It is not
refundable or transferable and may not be prorated. If
required, IBM will provide the warranty service upgrade
enhanced level of on-site service acquired by the
customer. Service levels are response time objectives
and are not guaranteed.
IBM will attempt to resolve your problem over the
telephone or electronically by access to an IBM Web site.
You must follow the problem determination and resolution
procedures that IBM specifies. Scheduling of service will
depend upon the time of your call and is subject to parts
availability.
CRUs will be provided as part of the machine′s standard
warranty CRU service except that you may install a Tier
1 CRU yourself or request IBM installation, at no
additional charge, under one of the on-site service levels
specified.
IBM will repair the failing machine at your location and
verify its operation. You must provide a suitable working
area to allow disassembly and reassembly of the IBM
machine. The area must be clean, well-lit, and suitable
for the purpose.
The following warranty service upgrade options are
available:
•IOR, 9 hours per day, Monday through Friday excluding
holidays, 4-hour average response.
•IOR, 24 hours per day, 7 days a week, 4-hour average
response
•IOR, 24 hours per day, 7 days a week, 2-hour average
response
Maintenance service: If required, IBM provides repair or
exchange service depending on the type of maintenance
service specified for the machine. IBM will attempt to
resolve your problem over the telephone or electronically
by access to an IBM Web site. You must follow the
problem determination and resolution procedures that
IBM specifies. Scheduling of service will depend upon the
time of your call and is subject to parts availability.
Service levels are response time objectives and are not
guaranteed.
CRU service: If your problem can be resolved with a CRU
(for example, keyboard, mouse, speaker, memory, or
HDD), IBM will ship the CRU to you for you to install. CRU
information and replacement instructions are shipped
with your machine and are available from IBM at any time
on your request.
IBM specifies in the materials shipped with a replacement
CRU whether a defective CRU must be returned to IBM.
When return is required, return instructions and a
container are shipped with the replacement CRU, and you
may be charged for the replacement CRU if IBM does not
receive the defective CRU within 30 days of your receipt
of the replacement.
106-239 -6-

On-site service: IOR. IBM will repair the failing machine
at your location and verify its operation. You must
provide a suitable working area to allow disassembly and
reassembly of the IBM machine. The area must be clean,
well-lit, and suitable for the purpose.
The following on-site service options are available:
•IOR, 9 hours per day, Monday through Friday excluding
holidays, NBD response
•IOR, 9 hours per day, Monday through Friday excluding
holidays, 4-hour average response
•IOR, 24 hours per day, 7 days a week, 4-hour average
response
•IOR, 24 hours per day, 7 days a week, 2-hour average
response
Maintenance service (ICA)
Maintenance services are available for ICA legacy
contracts. The preferred go-to-market offerings are
ServiceElect. However, ICA legacy contracts will still be
available for current customers until they are withdrawn.
Alternative service (warranty service upgrades): During
the warranty period, warranty service upgrade provides
an enhanced level of on-site service for an additional
charge. A warranty service upgrade must be purchased
during the warranty period and is for a fixed term
(duration). It is not refundable or transferable and may
not be prorated. If required, IBM will provide the
warranty service upgrade enhanced level of on-site
service acquired by the customer. Service levels are
response time objectives and are not guaranteed.
IBM will attempt to resolve your problem over the
telephone or electronically by access to an IBM Web site.
You must follow the problem determination and resolution
procedures that IBM specifies. Scheduling of service will
depend upon the time of your call and is subject to parts
availability.
CRUs will be provided as part of the machine′s standard
warranty CRU service except that you may install a Tier
1 CRU yourself or request IBM to install it at no additional
charge under the type of warranty service specified,
on-site service.
IBM will repair the failing machine at your location and
verify its operation. You must provide a suitable working
area to allow disassembly and reassembly of the IBM
machine. The area must be clean, well-lit, and suitable
for the purpose.
The following warranty service upgrade option is
available:
IOR, 24 hours per day, 7 days a week, 4-hour average
response
Maintenance service: If required, IBM provides repair or
exchange service depending on the type of maintenance
service specified for the machine. IBM will attempt to
resolve your problem over the telephone or electronically
by access to an IBM Web site. You must follow the
problem determination and resolution procedures that
IBM specifies. Scheduling of service will depend upon the
time of your call and is subject to parts availability.
Service levels are response time objectives and are not
guaranteed.
CRU service: If your problem can be resolved with a CRU
(for example, keyboard, mouse, speaker, memory, or
HDD), IBM will ship the CRU to you for you to install. CRU
information and replacement instructions are shipped
with your machine and are available from IBM at any time
on your request.
IBM specifies in the materials shipped with a replacement
CRU whether a defective CRU must be returned to IBM.
When return is required, return instructions and a
container are shipped with the replacement CRU, and you
may be charged for the replacement CRU if IBM does not
receive the defective CRU within 30 days of your receipt
of the replacement.
On-site service: IOR. IBM will repair the failing machine
at your location and verify its operation. You must
provide a suitable working area to allow disassembly and
reassembly of the IBM machine. The area must be clean,
well-lit, and suitable for the purpose.
The following on-site service options are available:
•IOR, 9 hours per day, Monday through Friday excluding
holidays, NBD response
•IOR, 24 hours per day, 7 days a week, 4-hour average
response
Non-IBM parts support
Warranty service: IBM is now shipping machines with
selected non-IBM parts that contain an IBM field
replaceable unit (FRU) part number label. These parts
are to be serviced during the IBM machine warranty
period. IBM is covering the service on these selected
non-IBM parts as an accommodation to their customers,
and normal warranty service procedures for the IBM
machine apply.
Warranty service upgrades and maintenance services:
Under certain conditions, IBM Integrated Technology
Services repairs selected non-IBM parts at no additional
charge for machines that are covered under a warranty
service upgrade or maintenance services.
IBM service provides hardware problem determination
on non-IBM parts (adapter cards, PCMCIA cards, disk
drives, memory, and so forth) installed within IBM
systems covered under warranty service upgrade or
maintenance services and provides the labor to replace
the failing parts at no additional charge. If IBM has
Technical Service Agreements with the manufacturers of
the failing part, or if the failing part is an accommodations
part (a part with an IBM FRU label), IBM may also source
and replace the failing parts at no additional charge. For
all other non-IBM parts, customers are responsible for
sourcing the parts. Installation labor is provided at no
additional charge, if the machine is covered under a
warranty service upgrade or maintenance services.
IBM hourly service rate classification: One
Field-installable features: Yes
Model conversions: No
Machine installation: Customer setup. Customers are
responsible for installation according to the instructions
IBM provides with the machine.
Graduated Program License Charges apply: No. This
product does not contain licensed internal code or
licensed machine code.
Educational allowance: None
-7- 106-239

Prices
Express Model
Machine IBM
Part type list
number model price(12)
xSeries 336 -- 3.0 GHz/2MB, 88371RU 8837-1RU $2,059
1 GB, DVD, SCSI hot-swap
open bay
2.8 GHz 800 MHz 2 MB L2 Cache 40K2509 299
Xeon Processor
3.0 GHz 800 MHz 2 MB L2 Cache 40K2510 449
Xeon Processor
3.2 GHz 800 MHz 2 MB L2 Cache 40K2511 649
Xeon Processor
3.4 GHz 800 MHz 2 MB L2 Cache 40K2512 749
Xeon Processor
3.6 GHz 800 MHz 2 MB L2 Cache 40K2513 899
Xeon Processor
3.8 GHz 800 MHz 2 MB L2 Cache 40K2514 1,199
Xeon Processor
Dual Core Intel Xeon 40K2501 1,399
Processor 2.8 GHz
12 IBM list price does not include tax or shipping and is subject
to change without notice. Reseller prices may vary.
ServicePac for warranty and maintenance charges
Part
Description number
1-year MA IOR 24 x 7 69P9401
2-hour average response
2-year MA IOR 24 x 7 96P2120
2-hour average response
3-year IOR 24 x 7 21P2074
2-hour average response
4-year IOR 24 x 7 69P9245
2-hour average response
5-year IOR 24 x 7 69P9249
2-hour average response
1-year MA IOR 24 x 7 69P9400
4-hour average response
2-year MA IOR 24 x 7 96P2119
4-hour average response
3-year IOR 24 x 7 21P2073
4-hour average response
4-year IOR 24 x 7 69P9244
4-hour average response
5-year IOR 24 x 7 69P9248
4-hour average response
1-year MA IOR 9 x 5 69P9399
4-hour average response
2-year MA IOR 9 x 5 96P2118
4-hour average response
3-year IOR 9 x 5 21P2072
4-hour average response
4-year IOR 9 x 5 69P9243
4-hour average response
5-year IOR 9 x 5 69P9247
4-hour average response
1-year MA IOR 9 x 5 69P9398
NBD response
2-year MA IOR 9 x 5 96P2117
NBD response
4-year IOR 9 x 5 69P9242
NBD response
5-year IOR 9 x 5 69P9246
NBD response
xSeries 336
Maintenance service charges (Legacy)
Alternative service (warranty service upgrades)
IOR
24 x 7
$450
Maintenance service
IOR IOR
9 x 5 24 x 7
$380 $570
For ServiceElect (ESA) Maintenance Service Charges,
contact IBM Global Services at 888-IBM-4343 (426-4343).
IBM Global Financing: IBM Global Financing offers
competitive financing to credit-qualified customers to
assist them in acquiring IT solutions. Our offerings
include financing for IT acquisition, including hardware,
software, and services, both from IBM and other
manufacturers or vendors. Offerings (for all customer
segments: small, medium, and large enterprise), rates,
terms, and availability can vary by country. Contact your
local IBM Global Financing organization or visit
http://www.ibm.com/financing
IBM Global Financing offerings are provided through IBM
Credit LLC in the United States and other IBM
subsidiaries and divisions worldwide to qualified
commercial and government customers. Rates are based
on a customer′s credit rating, financing terms, offering
type, equipment type, and options, and may vary by
country. Other restrictions may apply. Rates and
offerings are subject to change, extension, or withdrawal
without notice.
Order now
To order, contact the Americas Call Centers, your local
IBM representative, or your IBM Business Partner.
To identify your local IBM representative or IBM Business
Partner, call 800-IBM-4YOU (426-4968).
Phone: 800-IBM-CALL (426-2255)
Fax: 800-2IBM-FAX [phone])
Internet: [email protected]
Mail: IBM Americas Call Centers
Dept. Teleweb Customer Support, 9th floor
105 Moatfield Drive
North York, Ontario
Canada M3B 3R1
Reference: SE001
The Americas Call Centers, our national direct marketing
organization, can add your name to the mailing list for
catalogs of IBM products.
Note: Shipments will begin after the planned availability
date.
Trademarks
ServerGuide, Chipkill, ServeRAID, and ServiceSuite are
trademarks of International Business Machines Corporation
in the United States or other countries or both.
106-239 -8-

eServer, ServerProven, BladeCenter, SurePath, Netfinity,
and ServicePac are registered trademarks of International
Business Machines Corporation in the United States or other
countries or both.
Intel is a registered trademark of Intel Corporation.
Microsoft and Windows are trademarks of Microsoft
Corporation.
Linux is a trademark of Linus Torvalds in the United States,
other countries or both.
ThinkPad is a registered trademark of Lenovo in the United
States, other countries, or both
Other company, product, and service names may be
trademarks or service marks of others.
-9- 106-239
