iSeries 270 and 8xx
Upgrading the System Unit from
Operations Console to Twinaxial
Console (5540)
Version 5
ERserver


iSeries 270 and 8xx
Upgrading the System Unit from
Operations Console to Twinaxial
Console (5540)
Version 5
ER s e r v e r


© Copyright International Business Machines Corporation 2000, 2003. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Upgrade Operations Console to twinaxial console
Before you begin
This feature is customer installable. You can elect not to do this installation
yourself. You may contact IBM
®
or an authorized dealer to make arrangements for
them to perform the feature installation for a fee.
You need to allow additional time to complete your jobs, back up your system,
perform an initial program load (IPL) of your system, and verify your hardware
configuration.
When you use these instructions, you may do some of the following:
vRemove the system unit covers.
vInstall your new hardware.
vInstall covers.
vPerfrom an IPL of your operating system.
vVerify your new hardware configuration.
Some of the figures in these instructions may not look exactly like the system unit
that you have. However, the steps to perform the task are the same.
__ 1. Ensure that you have a current backup of your system (including operating
systems, licensed programs, and data).
__ 2. Ensure that you take a few minutes to become familiar with these
instructions.
__ 3. If there are incorrect, missing, or visibly damaged parts, contact one of the
following:
vYour authorized dealer
vIBM Rochester Manufacturing Automated Information Line (R-MAIL)
–1-800-300-8751 (United States)
–1-507-253-5242 (worldwide)
__ 4. If you encounter difficulties during the installation, contact your authorized
service provider or your authorized dealer.
__ 5. Determine if there are any existing PTF prerequisites before you install your
new feature. Go to the following Web site:
http://www-912.ibm.com/supporthome.nsf/document/10000051
a. Select All Documents.
b. Select Collapse.
c. Select General Information.
d. Select Offerings.
e. Select Feature Prerequisites.
f. Select Customer Install Features Prerequisites.
g. Locate your feature number and OS/400
®
release, and check the
prerequisites.
Power off the system unit
__ 1. Ensure that all jobs are complete.
© Copyright IBM Corp. 2000, 2003 1

__ 2. When all jobs are complete, type pwrdwnsys *immed on a command line and
press Enter.
Note: Should you encounter difficulties during the installation, contact your
authorized dealer or service provider.
__ 3. When the unit is completely powered down, disconnect all PCs from the
system unit. Power off all devices, such as printers and displays, that are
connected to the system unit.
__ 4. Unplug any power cords, such as printers and displays, from electrical
outlets.
__ 5. Unplug the system-unit power cord and any attached expansion-unit power
cords from the electrical outlet.
__ 6. Refer to “Removing the covers” on page 9 to remove the system unit
covers.
__ 7. Attach the disposable wrist strap to prevent electrostatic discharge from
damaging a device. Attach the adhesive part of the foil to an unpainted
surface on the frame of the unit.
Notes:
a. Follow the same precautions you would use without the wrist strap. The
2209 Disposable Wrist Strap is for static control. It will not increase or
decrease your risk of receiving electric shock when using or working on
electrical equipment.
b. Remove the liner from the copper foil at the end, when you unroll the
strap.
c. Attach the copper foil to an exposed, unpainted metal surface on the
frame of the unit (electrical ground).
Installing the 2746 workstation adapter card
__ 1. DANGER
To prevent a possible electrical shock from touching two surfaces with
different electrical grounds, use one hand, when possible, to connect
or disconnect signal cables. (RSFTD004)
__ 2. If you are using local console on a network (LAN console), remove the
console network cable.
__ 3. If you are using local console directly attached, disconnect the Operations
Console cable connected to the card in one of the following positions:
v270 or 810 system unit, position C07. See “Configuration tables”on
page 15 for more information.
v820 system unit, position C06. See “Configuration tables”on page 15 for
more information.
v825 system unit, position C07. See “Configuration tables”on page 15 for
more information.
v830, 840, SB2, SB3 system unit, position C02. See “Configuration tables”
on page 15 for more information.
v870 or 890 system unit, position C02. See “Configuration tables”on
page 15 for more information.
__ 4. Is there a 2746 card installed in one of the following positions?
v270 or 810 system unit: C06
v820 system unit: C04 or C11
2Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

v825 system unit: C07
v830, 840, SB2, SB3 system unit: C04, C06, C07, C09, or C10
v870 or 890 system unit: C04, C06, C07, C08, or C09
__ No: Continue with the next step.
__ Yes:Goto“Connecting the Twinaxial cable attachment and Twinaxial
console cable”on page 5.
__ 5. Before you remove the card from the system unit, you need to see if you
have an open position to install the card you removed in a different
position.
Look at the PCI card area. Are there any open positions?
__ Yes: Go to the Install PCI Card topic in the Information Center for
instructions on Moving a card in your iSeries.
__ No: Use the following to help determine card placement.
–Go to the Install PCI Card topic in the Information Center
–Contact your authorized service provider or your authorized
dealer
__ 6. Attention: Adapter cards are fragile. Use static strap when handling,
handle only by the edges, and keep fingers off printed circuit area.
__ 7. Install the new 2746 adapter card in one of the following positions:
v270 system unit: C06
v810 system unit: C07
v820 system unit: C04 or C11
v825 system unit: C06
v830, 840, SB2, SB3 system unit: C04, C06, C07, C09, or C10
v870 or 890 system unit: C04, C06, C07, C08, or C09
__ 8. Does your unit have screws to secure the cards?
__ No: Continue with the next step.
__ Yes: Remove the screw from the card position where you plan to
install the card.
Upgrade Operations Console to twinaxial console 3

__ Go to step 11 on page 5.
__ 9. Your unit has card latches to secure the cards.
__ 10. Open the latch at the card position where you plan to install the card.
Move the latch counterclockwise and then swing the black latch out.
Figure 1. Example of 270, 810, 820, 825, 5075 Card Latch
4Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

__ 11. Remove the card filler plate.
__ 12. Attention: Adapter cards are fragile:
vHandle only by the edges
vKeep fingers off printed circuit area
vUse static strap when handling
vLeave in protective packaging until ready to install
__ 13. Align the new adapter card with the card holders inside the system unit
and push until it is connected securely.
__ 14. Swing the black latch in and move the other latch clockwise, or install the
screw to secure the card.
__ 15. Go to “Connecting the Twinaxial cable attachment and Twinaxial console
cable”.
Connecting the Twinaxial cable attachment and Twinaxial console
cable
__ 1. Find the 8-port Twinaxial cable attachment (part number 21F5093) and label
the cable, for example, C06.
__ 2. Connect the 8-port Twinaxial cable attachment to the connector on the 2746
card.
Note: Each port on the 8-port attachment cable supports seven devices that
allow for 56 attached devices, of which only 40 can be active.
Figure 2. Example of 830, 840, 870, 890, SB2, SB3, 5079 Card Latches
Upgrade Operations Console to twinaxial console 5

__ 3. Set up the workstation or personal computer (PC) that will be connected to
the system unit and used as the console.
Notes:
a. Place the workstation or PC that will be used as the system unit console
not more than 6 meters (20 feet) from the system unit.
b. Follow the instructions that came with the workstation or PC to set it up.
__ 4. Find a Twinaxial cable and label it console cable.
__ 5. Align the key B in port 0 on the 8-port Twinaxial cable connector with the
slot A on the Twinaxial cable ( Figure 3) attachment.
Push in, hold, and turn the outer ring until it is tight.
__ 6. Connect the other end of the Twinaxial console cable to the PC or
workstation that is the system unit console.
Note: The workstation address of your console must be set to 0. To set the
address, refer to the book that was shipped with your device.
__ 7. Install the side and back covers.
__ 8. DANGER
An electrical outlet that is not correctly wired could place hazardous
voltage on metal parts of the system or the products that attach to the
system. It is the customer’s responsibility to ensure that the outlet is
correctly wired and grounded to prevent an electrical shock.
(RSFTD201)
Plug the following power cords into an electrical outlet.
vSystem unit
Note: Do not power on your system unit at this time.
vSystem unit console
Figure 3. Where to Connect the System Unit Console Cable
6Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

Completing the Installation
__ 1. Power on the PC or workstation that is your system unit console.
__ 2. Is your system unit a 270/810 or 820/825?
__ 270 or 810: Continue with the next step.
__ 820, 825, 830, 840, SB2, SB3, 870 or 890: Go to step 5.
__ 3. Look at the Function/Data display on the control panel.
__ 4. Does 01 B M V=S appear in the Function/Data display?
__ Yes: Go to step 7 on page 8.
__ No: Do the following:
__ a. Press the Increment/Decrement push button until 02 appears
in the Function/Data display.
__ b. Press the Enter push button on the control panel.
__ c. Press the Increment/Decrement push button until Bappears in
the Function/Data display.
__ d. Press the Enter push button on the control panel.
__ e. Press the Increment/Decrement push button until Mappears in
the Function/Data display.
__ f. Press the Enter push button on the control panel.
__ g. Press the Increment/Decrement push button until Sappears in
the Function/Data display.
__ h. Press the Enter push button on the control panel.
__ i. Press the Increment/Decrement push button until 01 appears
in the Function/Data display.
__ j. Press the Enter push button on the control panel.
01BMSshould appear in the Function/Data display. If it does
not, repeat steps 4a through 4i.
__ k. Go to step 7 on page 8.
__ 5. Look at the Function/Data display on the control panel.
__ 6. Does 01 B V=S appear in the Function/Data display and is the manual
mode indicator (a small hand) illuminated?
__ Yes: Continue with the next step.
__ No: Do the following:
__ a. Press the Mode Select button until the Manual mode indicator
(a small hand) is illuminated.
__ b. Press the Increment/Decrement push button until 02 appears
in the Function/Data display.
__ c. Press the Enter push button on the control panel.
__ d. Press the Increment/Decrement push button until Bappears in
the Function/Data display.
__ e. Press the Enter push button on the control panel.
__ f. Press the Increment/Decrement push button until Sappears in
the Function/Data display
__ g. Press the Enter push button on the control panel.
__ h. Press the Increment/Decrement push button until 01 appears
in the Function/Data display.
__ i. Press the Enter push button on the control panel.
Upgrade Operations Console to twinaxial console 7

01BSshould appear in the Function/Display panel and the
manual mode indicator (a small hand) is illuminated. If it does
not appear, repeat steps 6a on page 7 through 6h on page 7.
__ j. Go to step 7.
__ 7. Press the system unit power-on button. The power-on light will appear.
Note: When the power on and IPL is complete, the IPL or Install the System
display should appear on your system unit console.
__ 8. Select Use Dedicated Service Tools (DST) from the IPL or Install the System
display.
Press Enter.
__ 9. Type your service tools user ID and service tools password on the
Dedicated Service Tools (DST) Sign On display.
Press Enter.
__ 10. Select Work with DST Environment from the Use Dedicated Service Tools
(DST) display.
Press Enter.
__ 11. Select System devices from the Work with DST Environment display.
Press Enter.
__ 12. Select Console mode from the Work with System Devices display.
Press Enter.
__ 13. Select Twinaxial from the Select Console Type display.
Press Enter.
__ 14. Press F3 (Exit) once.
__ 15. Select Perform an IPL from the Use Dedicated Service Tools (DST) display.
Press Enter.
__ 16. Sign on the system unit. Ensure you have service tools authority.
__ 17. Type strsst on the command line of the Main Menu.
Press Enter.
__ 18. Select Start a service tool from the System Service Tools (SST) display.
Press Enter.
__ 19. Select Hardware service manager from the Start a Service Tool display. Press
Enter.
__ 20. Select Packaging hardware resources (system, frames, cards...) from the
Hardware Service Manager display. Press Enter.
__ 21. Type 9on the System Unit line.
__ 22. Press Page Down if needed and look at the Card Pos column.
__ 23. Verify that the cards you installed or moved appears in the position you
installed them.
__ 24. Your feature upgrade is complete.
__ 25. Press F3 three times and press Enter to get back to the Main Menu.
8Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

Removing the covers
Locate the diagram of the unit you are working on:
__ “270, 810 or 820 system units”
__ “830, 840, 870, 890, SB2, SB3, 5074, 5079, and 5094 units”on page 10
__ “Accessing units in a rack”on page 11
270, 810 or 820 system units
To access the PCI card location, you need to remove the back cover, if you have
one, and the side cover:
__ 1. Place your hand near the bottom of the back cover and lift up and out.
__ 2. Attention: If you are removing the side cover while the server is powered
on, errors may occur due to electromagnetic interference.
Remove the right side cover (view from back) by loosening the thumbscrews
and sliding the cover from front to back until it stops.
__ 3. Pull the cover out.
© Copyright IBM Corp. 2000, 2003 9

825 system unit
To access the PCI card location, you need to remove the back cover and the side
cover:
__ 1. Place your hand near the bottom of the back cover and lift up and out.
__ 2. Remove the right side cover (view from back) by loosening the thumbscrews
and sliding the cover from front to back until it stops.
__ 3. Pull the cover out.
830, 840, 870, 890, SB2, SB3, 5074, 5079, and 5094 units
To access the PCI card location, you need to open the back cover:
vA Open the back cover.
vB Remove the back cover.
vRemove the PCI card access plate.
10 Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

Accessing units in a rack
1. Move to the back of the rack, press latch A, and open the back door of the
rack.
Removing the covers 11

2. Press latches B and pull the server out using the handle C.
3. Refer to previous unit diagrams to remove the side cover.
12 Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

4. If you are cabling the server, feed the excess cabling along the cable
management arm D and secure the cables with the fasteners.
Removing the covers 13

14 Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2

Configuration tables
Go to your system unit:
v“270 and 810 system unit”
v“820 system unit”on page 16
v“825 system unit”on page 17
v“830, 840, SB2, and SB3 system unit”on page 17
v“870 and 890 system unit”on page 18
270 and 810 system unit
vThe Imbed IOP controls positions C07, C01, and possibly C06 and C05.
vIOPs control the IOAs in the positions below the IOP. For example, an IOP in
C04 would control IOAs in C03 and C02.
vSCSI in the diagram indicates the first internal disk unit controller position
(cards 2757, 2763, 2782, 4748, 4778, 5705, or 9767). (9767 is only in 270 units.) The
first disk unit controller card must be in C01 and connect the load source disk
unit internal tape and CD–ROM or DVD device.
vA second 2757, 2763, 2782, 4748, or 4778 is allowed in a 270 and 810 system unit
with an attached 7104 or 7116 expansion unit.
© Copyright IBM Corp. 2000, 2003 15

820 system unit
vThe Imbed IOP controls C06, C05, and possibly C04 and C03.
vIOPs control IOAs in the direction of the arrows in the PCI bridge set.
vSCSI in the diagram indicates the first internal disk unit controller position.
Place IOA 2757, 2763, 2782, 4748, 4778 or 9767 in position C05. The first disk unit
controller card must be in C05 and connect the load source disk unit internal
tape and CD–ROM or DVD device.
vTwo internal disk unit controllers are allowed per 820 system unit.
vA second internal disk unit controller in the system unit is only allowed when
removable cable retention mechanisms are installed.
vThe second internal disk unit controller cannot be in card position C07 or C08.
16 Upgrading the System Unit from Operations Console to Twinaxial Console (5540) V5R2
