IBM System x3550 M4 1
I B M ®
IBM System x3550 M4
IBM Redbooks Product Guide
The IBM® System x3550 M4 server provides outstanding performance for your business-critical
applications. Its energy-efficient design supports more cores, memory, and data capacity in a compact 1U
package that is easy to service and manage. With more computing power per watt and the latest Intel
Xeon processors, you can reduce costs while maintaining speed and availability.
Suggested use: database, virtualization, enterprise applications, collaboration/email, streaming media,
web, HPC, and cloud applications.
Figure 1 shows the IBM System x3550 M4.
Figure 1. The IBM System x3550 M4
Did you know?
The x3550 M4 offers a flexible, scalable design and a simple upgrade path to eight HDDs plus an optical
drive at the same time, and up to 768 GB of memory. The flexible onboard Ethernet solution provides four
standard integrated Gigabit Ethernet ports and two optional embedded 10 Gb Ethernet ports without
occupying PCIe slots. Comprehensive systems management tools with the next-generation Integrated
Management Module II (IMM2) make it easy to deploy, integrate, service, and manage.

IBM System x3550 M4 2
Key features
The x3550 M4 is a cost- and density-balanced 1U, 2-socket business-critical server, offering improved
performance and pay-as-you grow flexibility along with new features that improve server management
capability. The powerful system is designed for your most important business applications and cloud
deployments.
Combining balanced performance and flexibility, the x3550 M4 is a great choice for small and medium
businesses and up to the large enterprise. It can provide outstanding uptime to keep business-critical
applications and cloud deployments running safely. Ease-of-use and comprehensive systems
management tools make it easy to deploy. Outstanding RAS and high-efficiency design improves your
business environment and helps save operational costs.
Scalability and performance
The x3550 M4 offers numerous features to boost performance, improve scalability, and reduce costs:
Intel Xeon processor E5-2600 v2 product family

Improves productivity by offering superior system performance with up to 12-core processors, up

to 30 MB of L3 cache, and up to two 8 GT/s QPI interconnect links.
Supports up to two processors, 24 cores, and 48 threads maximize the concurrent execution of

multi-threaded applications.
Supports up to 1866 MHz memory speeds.

Supports up to 768 GB memory with 32 GB LRDIMMs.

Intel Xeon processor E5-2600 product family

Improves productivity by offering superior system performance with up to 8-core processors, up

to 20 MB of L3 cache, and up to two 8 GT/s QPI interconnect links.
Supports up to two processors, 16 cores, and 32 threads maximize the concurrent execution of

multi-threaded applications.
Supports up to 1600 MHz memory speeds.

Supports up to 768 GB memory with 32 GB LRDIMMs.

Intelligent and adaptive system performance with Intel Turbo Boost Technology 2.0 allows CPU cores

to run at maximum speeds during peak workloads by temporarily going beyond processor TDP.
Intel Hyper-Threading Technology boosts performance for multithreaded applications by enabling

simultaneous multithreading within each processor core, up to two threads per core.
Intel Virtualization Technology integrates hardware-level virtualization hooks that allow operating

system vendors to better utilize the hardware for virtualization workloads.
Intel Advanced Vector Extensions (AVX) significantly improve floating point performance for

compute-intensive technical and scientific applications compared to Intel Xeon 5600 series
processors.
12 Gbps SAS internal storage connectivity doubles the data transfer rate compared to 6 Gb SAS

solutions to maximize performance of storage I/O-intensive applications.
The use of solid-state drives (SSDs) instead of or along with traditional spinning drives (HDDs) can

significantly improve I/O performance. An SSD can support up to 100 times more I/O operations per
second (IOPS) than a typical HDD.
The server has four integrated Gigabit Ethernet ports and two optional 10 Gb Ethernet ports with

mezzanine cards that do not consume a PCIe slot.

IBM System x3550 M4 3
The server offers PCI Express (PCIe) 3.0 I/O expansion capabilities that improve the theoretical

maximum bandwidth by almost 100% (8 GTps per link using 128b/130b encoding) compared to the
previous generation of PCI Express 2.0 (5 GTps per link using 8b/10b encoding).
With Intel Integrated I/O Technology, the PCI Express 3.0 controller is integrated into the Intel Xeon

processor E5 family. This helps to dramatically reduce I/O latency and increase overall system
performance.
Support for NVIDIA Quadro graphics processing units (GPUs) to maximize computing power.

Availability and serviceability
The x3550 M4 provides many features to simplify serviceability and increase system uptime:
The server offers memory mirroring and memory rank sparing for redundancy in the event of a

non-correctable memory failure.
Tool-less cover removal provides easy access to upgrades and serviceable parts, such as CPU,

memory, and adapter cards.
The server offers hot-swap drives supporting RAID redundancy for data protection and greater

system uptime.
The server has two redundant hot-swap power supplies and six dual-motor hot-swap redundant fans

(two fan zones with N+1 fan design) to provide availability for business-critical applications.
The power source-independent light path diagnostics panel and individual light path LEDs quickly

lead the technician to failed (or failing) components. This simplifies servicing, speeds up problem
resolution, and helps improve system availability.
Predictive Failure Analysis (PFA) detects when system components (processors, VRMs, memory,

hard disk drives, fans, and power supplies) operate outside of standard thresholds and generates
proactive alerts in advance of possible failure, therefore increasing uptime.
Solid-state drivers (SSDs) offer significantly better reliability than traditional mechanical HDDs for

greater uptime.
Built-in Integrated Management Module II (IMM2) continuously monitors system parameters, triggers

alerts, and performs recovery actions in case of failure, to minimize downtime.
Built-in diagnostics using Dynamic Systems Analysis (DSA) Preboot speeds up troubleshooting tasks

to reduce service time.
Three-year customer replaceable unit and onsite limited warranty, next business day 9x5. Optional

service upgrades available.
Manageability and security
Powerful systems management features simplify local and remote management of the x3550 M4:
The server includes an Integrated Management Module II (IMM2) to monitor server availability and

perform remote management.
An integrated industry-standard Unified Extensible Firmware Interface (UEFI) enables improved

setup, configuration, and updates, and simplifies error handling.
An integrated Trusted Platform Module (TPM) 1.2 support enables advanced cryptographic

functionality such as digital signatures and remote attestation.
There is industry-standard AES NI support for faster, stronger encryption.

IBM Systems Director offers comprehensive systems management tools that help to increase uptime,

reduce costs and improve productivity through advanced server management capabilities.
Intel Execute Disable Bit functionality can help prevent certain classes of malicious buffer overflow


IBM System x3550 M4 4
attacks when combined with a supporting operating system
.
Intel Trusted Execution Technology provides enhanced security through hardware-based resistance

to malicious software attacks, allowing an application to run in its own isolated space protected from
all other software running on a system.
Energy efficiency
The x3550 M4 offers the following energy-efficiency features to save energy, reduce operational costs,
increase energy availability, and contribute to a green environment:
Energy-efficient planar components help lower operational costs.

The x3550 M4 is Energy Star 2.0 compliant. Energy Star is the trusted, US government-backed

symbol for energy efficiency, with the goal of helping customers save money and protect the
environment through energy efficient products and practices. For the Power and Performance Data
Sheet, see http://ibm.com/systems/x/hardware/energy-star
High-efficiency 550 W and 750 W power supplies with 80 PLUS Platinum certification. Available 750

W dc power supply option.
The Intel Xeon processor E5-2600 and E5-2600 v2 product families offer significantly better

performance over the previous generation, while fitting into the same thermal design power (TDP)
limits.
Intel Intelligent Power Capability powers individual processor elements on and off as needed, to

reduce power draw.
Low-voltage Intel Xeon processors draw less energy to satisfy the demands of power and thermally

constrained data centers and telecommunication environments.
Low-voltage 1.35 V DDR3 memory RDIMMs consume 15% less energy compared to 1.5 V DDR3

RDIMMs.
Solid-state drives (SSDs) consume as much as 80% less power than traditional spinning 2.5-inch

HDDs.
The server uses hexagonal ventilation holes, a part of IBM Calibrated Vectored Cooling™ technology.

Hexagonal holes can be grouped more densely than round holes, providing more efficient airflow
through the system.
IBM Systems Director Active Energy Manager™ provides advanced data center power notification and

management to help achieve lower heat output and reduced cooling needs.

IBM System x3550 M4 5
Locations of key components and connectors
Figure 2 shows the front of the server.
Figure 2. Front view of the IBM System x3550 M4
Figure 3 shows the rear of the server.
Figure 3. Rear view of the IBM System x3550 M4

IBM System x3550 M4 6
Figure 4 shows the locations of key components inside the server.
Figure 4. Inside view of the IBM System x3550 M4

IBM System x3550 M4 7
Standard specifications
The following table lists the standard specifications.
Table 1. Standard specifications (part 1)
Components Specification
Form factor 1U Rack.
Processor E5-2600 v2: Up to two Intel Xeon processor E5-2600 v2 product family CPUs with 12 cores
(up to 2.7 GHz) or ten cores (up to 3.0 GHz) or eight cores (up to 3.3 GHz) or six cores (up to
3.5 GHz) or four cores (up to 3.5 GHz). Two QPI links up to 8.0 GT/s each. Up to 1866 MHz
memory speed. Up to 30 MB L3 cache.
E5-2600: Up to two Intel Xeon processor E5-2600 product family CPUs with eight cores (up to
2.9 GHz) or six cores (up to 2.9 GHz) or quad-cores (up to 3.3 GHz). Two QPI links up to 8.0
GT/s each. Up to 1600 MHz memory speed. Up to 20 MB L3 cache.
Chipset Intel C604
Memory Up to 24 DIMM sockets (12 DIMMs per processor).
E5-2600 v2: RDIMMs and LRDIMMs (Load Reduced DIMMs) are supported but memory
types cannot be intermixed. Memory speed up to 1866 MHz.
E5-2600: RDIMMs, UDIMMs and LR-DIMMs (Load Reduced DIMMs) are supported but
memory types cannot be intermixed. Memory DIMM speeds up to 1600 MHz.
Memory
maximums
E5-2600 v2:
With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors

With LRDIMMs: Up to 768 GB with 24x 32 GB LRDIMMs and two processors

E5-2600:
With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors

With UDIMMs: Up to 64 GB with 16x 4 GB UDIMMs and two processors

With LRDIMMs: Up to 768 GB with 24x 32 GB LRDIMMs and two processors

Memory
protection
ECC, Chipkill (for x4-based memory DIMMs), memory mirroring, and memory rank sparing.
Disk drive bays Up to eight 2.5" hot-swap SAS/SATA HDDs, or up to three 3.5" hot-swap SAS/SATA HDDs, or
up to three 3.5" Simple Swap SATA HDDs.
Maximum internal
storage
Up to 7.2 TB with 900 GB 2.5" SAS HDDs (E5-2600 v2), or up to 9.6 TB with 1.2 TB 2.5" SAS
HDDs (E5-2600), or up to 8 TB with 1 TB 2.5" NL SAS/SATA HDDs, or up to 12.8 TB with 1.6
TB 2.5" SAS SSDs, or up to 12 TB with 4 TB 3.5" NL SAS/SATA HDDs. Intermix of SAS/SATA
is supported.
RAID support 6 Gb SAS/SATA: RAID 0, 1, 10 with H1110, M1115 or M5110. Optional upgrades to RAID 5,
50 available for M1115. Optional upgrades to RAID 5, 50 are available for M5110
(zero-cache; 512 MB battery-backed cache; 512 MB or 1 GB flash-backed cache). Optional
upgrade to RAID 6, 60 are available for M5110 with 512 MB or 1 GB cache upgrades.
12 Gb SAS/SATA: RAID 0, 1, 10 with optional M5210. Optional upgrades to RAID 5, 50 are
available for M5210 (zero-cache; 1 GB non-backed cache; 1 GB or 2 GB flash-backed cache).
Optional upgrade to RAID 6, 60 are available for M5210 with 1 GB or 2 GB cache upgrades.
Optical drive bays One, optional, for models with 2.5" drives. Support for DVD-ROM or Multiburner.
Tape drive bays None.
Network
interfaces
Four integrated Gigabit Ethernet 1000BASE-T ports (RJ-45); two integrated 10 Gb Ethernet
ports (10GBASE-T RJ-45 or 10GBASE-SR SFP+ based) on optional 10 Gb Ethernet
mezzanine card (does not consume a PCIe slot).

IBM System x3550 M4 8
Table 1. Standard specifications (part 2)
Components Specification
PCI Expansion
slots
Two slots, depending on the riser cards installed. The slots are as follows (all PCIe slots are
PCIe 3.0, all PCI-X slots are 64 bit/133 MHz):
Slot 1: PCIe x16; low profile, half-length

Slot 2: PCIe x8, opt. PCI-X or PCIe x16; full-height/half-length (PCIe x16 req. 2nd CPU)

Additional dedicated slot for ServeRAID adapter.
Ports Two USB 2.0 (three USB 2.0 for 3.5" HDD models) and one DB-15 video on front. Four USB
2.0, one DB-15 video, one DB-9 serial, one RJ-45 systems management, four RJ-45 GbE
network ports, two optional RJ-45 or SFP+ 10 GbE network ports on rear. One internal USB
ports (for embedded hypervisor).
Cooling IBM Calibrated Vectored Cooling™ with up to six N+1 redundant hot-swap fans (four standard,
additional two with second processor or with the x3550 M4 Thermal Solution Kit); two fan
zones with N+1 fan design; each fan has two motors.
Power supply Up to two redundant hot-swap 550 W AC or 750 W AC power supplies (80+ Platinum
certification), or 750 W DC power supply options.
Hot-swap parts Hard drives, power supplies, fans.
Systems
management
UEFI, IBM Integrated Management Module 2 (IMM2), Predictive Failure Analysis, Light Path
Diagnostics, Automatic Server Restart, IBM Systems Director and IBM Systems Director
Active Energy Manager™, IBM ServerGuide. Optional IBM Advanced Management Module
Advanced Upgrade (FoD) for remote presence (graphics, keyboard and mouse, virtual
media).
Security features Power-on password, administrator's password, Trusted Platform Module (TPM).
Video Matrox G200eR2 with 16 MB memory integrated into the IMM2. Maximum resolution is
1600x1200 at 75 Hz with 16 M colors.
Operating
systems
supported
Microsoft Windows Server 2012 R2, 2012, 2008 R2 and 2008, Red Hat Enterprise Linux 5 and
6, SUSE Linux Enterprise Server 10 and 11, VMware ESX 4.1 and VMware ESXi 4.1
embedded hypervisor (E5-2600 only), VMware vSphere (ESXi) 5.0 and 5.1.
Limited warranty Three-year customer-replaceable unit and onsite limited warranty with 9x5/NBD.
Service and
support
Optional service upgrades are available through IBM ServicePacs®: 4-hour or 2-hour
response time, 8 hours fix time, one-year or two-year warranty extension, remote technical
support for IBM hardware and selected IBM and third-party (Microsoft, Linux, VMware)
software.
Dimensions Height: 43 mm (1.7 in), width: 429 mm (16.9 in), depth: 734 mm (28.9 in)
Weight Minimum configuration: 12.7 kg (28 lb), maximum: 15.9 kg (35.1 lb)
The x3550 M4 servers are shipped with the following items:
Statement of Limited Warranty

Important Notices

Rack Installation Instructions

Documentation CD containing Installation and User's Guide

IBM Systems Director Flyer

IBM System x Gen-III Slides Kit

IBM System x Gen-III Cable Management Arm (CMA)

2.8 m C13-C14 power cord (one for models with one power supply and two for models with two power

supplies)

IBM System x3550 M4 9
Standard models
The following table lists the standard models.
Table 2. Standard models (Part 1: Intel Xeon processor E5-2600 v2 product family)
MTM* Intel Xeon processors†
(two maximum) Memory RAID Drive
bays
(std /
max)
Drives GbE I/O
slots
(std /
max)
Optical Power
supply
(std /
max)
Models announced September 2013
7914-23x 1x E5-2637 v2 4C 3.5GHz
15MB 1866MHz 130W
1x 8GB
1866MHz
M5110 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
7914-33x 1x E5-2643 v2 6C 3.5GHz
25MB 1866MHz 130W
1x 8GB
1866MHz
M5110 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
7914-43x 1x E5-2667 v2 8C 3.3GHz
25MB 1866MHz 130W
1x 8GB
1866MHz
M5110 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
7914-53x 1x E5-2650L v2 10C 1.7GHz
25MB 1600MHz 70W
1x 8GB
1600MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-73x 1x E5-2695 v2 12C 2.4GHz
30MB 1866MHz 115W
1x 8GB
1866MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
7914-83x 1x E5-2697 v2 12C 2.7GHz
30MB 1866MHz 130W
1x 8GB
1866MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
7914-A3x 1x E5-2603 v2 4C 1.8GHz
10MB 1333MHz 80W
1x 4GB
1600MHz§
H1110 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-B3x 1x E5-2609 v2 4C 2.5GHz
10MB 1333MHz 80W
1x 4GB
1600MHz§
M1115 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-C3x 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M1115 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-C5x 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
H1110 3x 3.5"
HS / 3
Open
bay
4 2 / 2 None 1x 550W
HS / 2
7914-D3x 1x E5-2630 v2 6C 2.6GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110
512MB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-F3x 1x E5-2640 v2 8C 2.0GHz
20MB 1600MHz 95W
1x 8GB
1600MHz
M5110
512MB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-G3x 1x E5-2650 v2 8C 2.6GHz
20MB 1866MHz 95W
1x 8GB
1866MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-H3x 1x E5-2660 v2 10C 2.2GHz
25MB 1866MHz 95W
1x 8GB
1866MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-J3x 1x E5-2670 v2 10C 2.5GHz
25MB 1866MHz 115W
1x 8GB
1866MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 550W
HS / 2
7914-L3x 1x E5-2680 v2 10C 2.8GHz
25MB 1866MHz 115W
1x 8GB
1866MHz
M5110
1GB Flash
4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
7914-M3x 1x E5-2690 v2 10C 3.0GHz
25MB 1866MHz 130W
1x 8GB
1866MHz
M5110 4x 2.5"
HS / 8
Open
bay
4 2 / 2 Optional 1x 750W
HS / 2
* x in the Machine Type Model (MTM) represents a country-specific letter (for example, the EMEA MTM is
7914-A3G, and the US MTM is 7914-A3U). Ask an IBM representative for specifics.
† Processor detail: Processor quantity and model, cores, core speed, L3 cache, memory speed, TDP.
§ For models A3x and B3x, the standard DIMM is rated at 1600 MHz, but operates at up to 1333 MHz to match the
processor memory speed. Actual memory speed maximums depend on several factors, as described in "Memory
options".

IBM System x3550 M4 10
Table 2. Standard models (Part 2: Intel Xeon processor E5-2600 product family)
Model Intel Xeon Processors†
(2 maximum) Memory RAID Disk bays Disks GbE Optical Power
Models announced August 2012
7914-32x 1x E5-2643 4C 3.3GHz
10MB 1600MHz 130W
1x 4 GB M5110 4x 2.5" HS/8 Open 4 Open 1x 750W
7914-DDx* 2x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
8x 4 GB M5110 512MB
with Battery
4x 2.5" HS/8 2x 600 GB
SAS
6* Multi-
burner
2x 550W
7914-M2x 1x E5-2690 8C 2.9GHz
20MB 1600MHz 135W
1x 4 GB M5110 4x 2.5" HS/8 Open 4 Open 1x 750W
Models announced March 2012
7914-A2x 1x E5-2603 4C 1.8GHz
10MB 1066MHz 80W
1x 4 GB H1110 4x 2.5" HS/8 Open 4 Open 1x 550W
7914-B2x 1x E5-2609 4C 2.4GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS/8 Open 4 Open 1x 550W
7914-C2x 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M1115 4x 2.5" HS/8 Open 4 Open 1x 550W
7914-C4x 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB H1110 3x 3.5" HS/6 Open 4 None 1x 550W
7914-D2x 1x E5-2630 6C 2.3GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-F2x 1x E5-2640 6C 2.5GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-G2x 1x E5-2650 8C 2.0GHz
20MB 1600MHz 95W
1x 8 GB M5110
1GB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-52x 1x E5-2650L 8C 1.8GHz
20MB 1600MHz 70W
1x 8 GB M5110
1GB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-H2x 1x E5-2660 8C 2.2GHz
20MB 1600MHz 95W
1x 8 GB M5110
1GB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-62x 1x E5-2665 8C 2.4GHz
20MB 1600MHz 115W
1x 8 GB M5110
1GB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-J2x 1x E5-2670 8C 2.6GHz
20MB 1600MHz 115W
1x 8 GB M5110
1GB+Flash
4x 2.5" HS/8 Open 4 Open 1x 550W
7914-L2x 1x E5-2680 8C 2.7GHz
20MB 1600MHz 130W
1x 8 GB M5110
1GB+Flash
4x 2.5" HS/8 Open 4 Open 1x 750W
† Processor detail: Processor quantity and model, core speed, number of cores, L3 cache, memory speed.
* Model DDx is a management server for offerings such as cloud. See below
Refer to the Specifications section for information about standard features of the server.
Management node
Model 7914-DDx is a model optimized as a management node and is preloaded with Windows Server
2008 R2 Standard and IBM Systems Director.
The model also includes these components as standard:
Intel Ethernet Dual Port Server Adapter I340-T2 (49Y4230)

IBM Integrated Management Module Advanced Upgrade (90Y3901)

Two PCIe x16 slots


IBM System x3550 M4 11
Express models
The following table lists the express models.
Table 3. Express models (Part 1: Intel Xeon processor E5-2600 v2 product family)
MTM** Intel Xeon processors†
(two maximum) Memory RAID Drive
bays
(std /
max)
Drives GbE I/O
slots
(std /
max)
Optical Power
supply
(std /
max)
United States, Canada, Latin America
7914-EGU 1x E5-2609 v2 4C 2.5GHz
10MB 1333MHz 80W
1x 8GB
1600MHz§
M1115 4x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-EHU 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110 4x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-EJU 1x E5-2640 v2 8C 2.0GHz
20MB 1600MHz 95W
1x 8GB
1600MHz
M5110 4x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-EKU 1x E5-2660 v2 10C 2.2GHz
25MB 1866MHz 95W
1x 16GB
1866MHz
M5110 4x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
2x 550W
HS / 2
Latin America (Brazil only)
7914-EPU 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M1115 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Multi-
burner
2x 550W
HS / 2
7914-EQU 1x E5-2640 v2 8C 2.0GHz
20MB 1600MHz 95W
2x 8GB
1600MHz
M1115 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Multi-
burner
2x 550W
HS / 2
Asia Pacific (China only)
7914-ELC 1x E5-2603 v2 4C 1.8GHz
10MB 1333MHz 80W
1x 8GB
1600MHz§
M1115 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Optional 1x 550W
HS / 2
7914-EOC 1x E5-2603 v2 4C 1.8GHz
10MB 1333MHz 80W
1x 8GB
1600MHz§
M5110 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Optional 1x 550W
HS / 2
7914-ESC 1x E5-2609 v2 4C 2.5GHz
10MB 1333MHz 80W
1x 8GB
1600MHz§
M1115 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Optional 1x 550W
HS / 2
7914-ETC 1x E5-2609 v2 4C 2.5GHz
10MB 1333MHz 80W
1x 8GB
1600MHz§
M5110 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Optional 1x 550W
HS / 2
7914-EVC 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M1115 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Optional 1x 550W
HS / 2
7914-EWC 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110 4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Optional 1x 550W
HS / 2

IBM System x3550 M4 12
Table 3. Express models (Part 1: Intel Xeon processor E5-2600 v2 product family) (continued)
MTM** Intel Xeon processors†
(two maximum) Memory RAID Drive
bays
(std /
max)
Drives GbE I/O
slots
(std /
max)
Optical Power
supply
(std /
max)
Europe
7914-E6G 1x E5-2603 v2 4C 1.8GHz
10MB 1333MHz 80W
1x 4GB
1600MHz§
M1115 4x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-E7G 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110
512MB (c)
8x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-E8G 1x E5-2630 v2 6C 2.6GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110
512MB (f)
4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Multi-
burner
2x 550W
HS / 2
Central and Eastern Europe (CEE) and Middle East and Africa (MEA)
7914-E7G 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110
512MB (c)
8x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-E8G 1x E5-2630 v2 6C 2.6GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110
512MB (f)
4x 2.5"
HS / 8
2x 300GB
10K
4 2 / 2 Multi-
burner
2x 550W
HS / 2
Russia/Commonwealth of Independent States (CIS)
7914-E9G 1x E5-2620 v2 6C 2.1GHz
15MB 1600MHz 80W
1x 8GB
1600MHz
M5110
512MB (f)
8x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
7914-EFG 1x E5-2630 v2 6C 2.6GHz
15MB 1600MHz 80W
1x 16GB
1866MHz§
M5110
512MB (f)
8x 2.5"
HS / 8
Open bay 4 2 / 2 Multi-
burner
1x 550W
HS / 2
** MTM = Machine Type Model
† Processor detail: Processor quantity and model, number of cores, core speed, L3 cache, memory speed, TDP.
‡ Not available in Russia/CIS.
(c) The ServeRAID M5110 RAID controller in this model includes cache memory with optional battery backup.
(f) The ServeRAID M5110 RAID controller in this model includes flash-backed cache memory.
§ For models E6G, EGU, ELC, EOC, ESC, and ETC, the standard DIMM is rated at 1600 MHz, but operates at up to
1333 MHz to match the processor memory speed. For model EFG, the standard DIMM is rated at 1866 MHz, but
operates at up to 1600 MHz to match the processor memory speed. Actual memory speed maximums depend on
several factors, as described in "Memory options".

IBM System x3550 M4 13
Table 3. Express models (Part 2: Intel Xeon processor E5-2600 product family)
Model Intel Xeon Processors†
(2 maximum) Memory RAID Disk bays Disks GbE DVD Power
United States, Canada, and Latin America
7914-EAU 1x E5-2609 4C 2.4GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-EBU 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8GB M5110
512MB Flash
4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-ECU 1x E5-2630 6C 2.3GHz
15MB 1333MHz 95W
1x 8GB M5110
512MB Flash
4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-EDU 1x E5-2650 8C 2.0GHz
20MB 1600MHz 95W
1x 8GB M5110
1GB Flash
4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
Europe
7914-E1G 1x E5-2603 4C 1.8GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-E2G 1x E5-2603 4C 1.8GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS / 8 2 x 500GB
HS SATA
4 Multi-
burner
1x 550W
7914-E3G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Cache
8x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-E4G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M1115 3x 3.5" HS/ 3 Optional 4 None 1x 550W
7914-E5G 1x E5-2630 6C 2.3GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Flash
4x 2.5" HS / 8 2 x 300GB
10K HS SAS
4 Multi-
burner
2x 550W

IBM System x3550 M4 14
Table 3. Express models (Part 2: Intel Xeon processor E5-2600 product family) (continued)
Model Intel Xeon Processors†
(2 maximum) Memory RAID Disk bays Disks GbE DVD Power
Central and Eastern Europe and Middle East & Africa
7914-E1G 1x E5-2603 4C 1.8GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-E2G 1x E5-2603 4C 1.8GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS / 8 2 x 500GB
HS SATA
4 Multi-
burner
1x 550W
7914-E3G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Cache
8x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-E4G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M1115 3x 3.5" HS/ 3 Optional 4 None 1x 550W
7914-E5G 1x E5-2630 6C 2.3GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Flash
4x 2.5" HS / 8 2 x 300GB
10K HS SAS
4 Multi-
burner
2x 550W
7914-K2G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Flash
3x 3.5" HS/ 3 Optional 4 None 1x 550W
7914-K3G 1x E5-2630 6C 2.3GHz
15MB 1333MHz 95W
2x 8 GB M5110
512MB Flash
8x 2.5" HS / 8 Optional 4 Multi-
burner
2x 550W
Russia/Commonwealth of Independent States (CIS)
7914-E1G 1x E5-2603 4C 1.8GHz
10MB 1066MHz 80W
1x 4 GB M1115 4x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-K1G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Flash
8x 2.5" HS / 8 Optional 4 Multi-
burner
1x 550W
7914-K2G 1x E5-2620 6C 2.0GHz
15MB 1333MHz 95W
1x 8 GB M5110
512MB Flash
3x 3.5" HS/ 3 Optional 4 None 1x 550W
7914-K3G 1x E5-2630 6C 2.3GHz
15MB 1333MHz 95W
2x 8 GB M5110
512MB Flash
8x 2.5" HS / 8 Optional 4 Multi-
burner
2x 550W
† Processor detail: Processor quantity and model, core speed, number of cores, L3 cache, memory speed.
Refer to the Specifications section for information about standard features of the server.

IBM System x3550 M4 15
Processor options
The x3550 M4 supports the processor options listed in the following table. The server supports up to two
processors. This table shows which server models have each processor standard. If there is no
corresponding where used model for a particular processor, then this processor is only available through
CTO. The part numbers include two system fans.
Table 4. Processor options (Part 1: Intel Xeon processor E5-2600 v2 product family)
Part
number Feature codes* Description
Standard
models
where
used
46W2835 A3X3 / A3WK Intel Xeon Processor E5-2603 v2 4C 1.8GHz 10MB Cache 1333MHz 80W A3x
46W2836 A3X4 / A3WL Intel Xeon Processor E5-2609 v2 4C 2.5GHz 10MB Cache 1333MHz 80W B3x
46W2837 A3X5 / A3WM Intel Xeon Processor E5-2620 v2 6C 2.1GHz 15MB Cache 1600MHz 80W C3x
00Y7257 A469 / A467 Intel Xeon Processor E5-2628L v2 8C 1.9GHz 20MB Cache 1600MHz 70W -
46W2838 A3X6 / A3WN Intel Xeon Processor E5-2630 v2 6C 2.6GHz 15MB Cache 1600MHz 80W D3x
46W2849 A3X7 / A3WP Intel Xeon Processor E5-2630L v2 6C 2.4GHz 15MB Cache 1600MHz 60W -
46W2846 A3XG / A3WY Intel Xeon Processor E5-2637 v2 4C 3.5GHz 15MB Cache 1866MHz 130W 23x
46W2839 A3X8 / A3WQ Intel Xeon Processor E5-2640 v2 8C 2.0GHz 20MB Cache 1600MHz 95W F3x
46W2847 A3XH / A3WZ Intel Xeon Processor E5-2643 v2 6C 3.5GHz 25MB Cache 1866MHz 130W 33x
00Y7259 A468 / A466 Intel Xeon Processor E5-2648L v2 10C 1.9GHz 25MB Cache 1866MHz
70W
-
46W2840 A3X9 / A3WR Intel Xeon Processor E5-2650 v2 8C 2.6GHz 20MB Cache 1866MHz 95W G3x
46W2850 A3XF / A3WX Intel Xeon Processor E5-2650L v2 10C 1.7GHz 25MB Cache 1600MHz
70W
53x
46W2841 A3XA / A3WS Intel Xeon Processor E5-2660 v2 10C 2.2GHz 25MB Cache 1866MHz 95W H3x
46W2848 A3XJ / A3X0 Intel Xeon Processor E5-2667 v2 8C 3.3GHz 25MB Cache 1866MHz 130W 43x
46W2842 A3XC / A3WU Intel Xeon Processor E5-2670 v2 10C 2.5GHz 25MB Cache 1866MHz
115W
J3x
46W2843 A3XD / A3WV Intel Xeon Processor E5-2680 v2 10C 2.8GHz 25MB Cache 1866MHz
115W
L3x
46W2844 A3XE /
A3WW
Intel Xeon Processor E5-2690 v2 10C 3.0GHz 25MB Cache 1866MHz
130W
M3x
46W2833 A3XK / A3X1 Intel Xeon Processor E5-2695 v2 12C 2.4GHz 30MB Cache 1866MHz
115W
73x
46W2834 A3XL / A3X2 Intel Xeon Processor E5-2697 v2 12C 2.7GHz 30MB Cache 1866MHz
130W
83x
* The first feature code is for the first processor; the second feature code is for the second processor

IBM System x3550 M4 16
Table 4. Processor options (Part 2: Intel Xeon processor E5-2600 product family)
Part number* Feature
codes** Description Standard models where used
Intel Xeon processor E5-2600 product family
69Y5672 A1LG / A1LT Intel Xeon E5-2603 4C 1.8GHz 10MB 1066MHz 80W A2x
69Y5674 A1LJ / A1LV Intel Xeon E5-2609 4C 2.4GHz 10MB 1066MHz 80W B2x
69Y5675 A1LK / A1LW Intel Xeon E5-2620 6C 2.0GHz 15MB 1333MHz 95W C2x, C4x, DDx
69Y5676 A1LL / A1LX Intel Xeon E5-2630 6C 2.3GHz 15MB 1333MHz 95W D2x
94Y7464 A2B3 / A2B6 Intel Xeon E5-2630L 6C 2.0GHz 15MB 1333MHz 60W -
94Y7546 A2VR / A2QK Intel Xeon E5-2637 2C 3.0GHz 5MB 1600MHz 80W -
69Y5677 A1LM / A1LY Intel Xeon E5-2640 6C 2.5GHz 15MB 1333MHz 95W F2x
94Y7465 A2B4 / A2B7 Intel Xeon E5-2643 4C 3.3GHz 10MB 1600MHz 130W 32x
00D9441 A39A / A39D Intel Xeon E5-2648L 8C 1.8GHz 20MB 1600MHz 70W
69Y5678 A1LN / A1LZ Intel Xeon E5-2650 8C 2.0GHz 20MB 1600MHz 95W G2x
69Y5685 A1LS / A1M3 Intel Xeon E5-2650L 8C 1.8GHz 20MB 1600MHz 70W 52x
00D9440 A399 / A39C Intel Xeon E5-2658 8C 2.1GHz 20MB 1600MHz 95W
69Y5679 A1LP / A1M0 Intel Xeon E5-2660 8C 2.2GHz 20MB 1600MHz 95W H2x
94Y7547 A2GN / A2GP Intel Xeon E5-2665 8C 2.4GHz 20MB 1600MHz 115W 62x
69Y5682 A1LR / A1M2 Intel Xeon E5-2667 6C 2.9GHz 15MB 1600MHz 130W -
94Y7463 A2B2 / A2B5 Intel Xeon E5-2670 8C 2.6GHz 20MB 1600MHz 115W J2x
69Y5680 A1LQ / A1M1 Intel Xeon E5-2680 8C 2.7GHz 20MB 1600MHz 130W L2x
94Y7545 A2VQ / A2QJ Intel Xeon E5-2690 8C 2.9GHz 20MB 1600MHz 135W M2x
* The option for the second processor includes two additional system fans.
** The first feature code is for the first processor; the second feature code is for the second processor
Memory options
IBM DDR3 memory is compatibility tested and tuned for optimal IBM System x® performance and
throughput. IBM memory specifications are integrated into the light path diagnostics for immediate system
performance feedback and optimum system uptime. From a service and support standpoint, IBM memory
automatically assumes the IBM system warranty, and IBM provides service and support worldwide.
The IBM System x3550 M4 supports DDR3 memory. The server supports up to 12 DIMMs when one
processor is installed, and up to 24 DIMMs when two processors are installed. Each processor has four
memory channels, and there are three DIMMs per channel.
The following rules apply when selecting the memory configuration:
Server supports UDIMMs (E5-2600 only), RDIMMs, and LRDIMMs.

Mixing different types of memory (UDIMMs, RDIMMs, and LRDIMMs) is not supported.


IBM System x3550 M4 17
Mixing 1.5 V and 1.35 V DIMMs in the same server is supported; in such cases, all DIMMs operate at

1.5 V.
The maximum number of ranks supported per one channel is eight (with the exception of Load

Reduced DIMMs, where more than eight ranks are supported because one quad-rank LRDIMM
provides the same electrical load on a memory bus as a single-rank RDIMM).
The maximum quantity of DIMMs that can be installed in server depends on number of CPUs, DIMM

type, rank, and operating voltage as shown in the "Maximum quantity" row in the following table.
All DIMMs in all CPU memory channels operate at the same speed, which is determined as the

lowest value of:
The memory speed supported by the specific CPU.

The lowest of maximum operating speeds for the selected memory configuration that depends on

rated speed, operating voltage, and quantity of DIMMs per channel, as shown under "Maximum
operating speed" section in the following table.
The following table (Parts 1, 2, and 3) shows the characteristics of the supported DIMMs. Tables cells
highlighted with a gray background indicate when the combination of DIMM voltage and the number of
DIMMs per channel still allows the DIMMs to operate at a rated speed.
Table 5. Maximum memory speeds (Part 1: Intel Xeon processor E5-2600 v2 product family - RDIMMs
and LRDIMMs)
DIMM
specification RDIMM LRDIMM
Rank Single rank Dual rank Dual rank Quad rank
Part numbers 00D5024 (4 GB)
00D5036 (8 GB)
00D5020 (4 GB)
00D5032 (8 GB)
00D5040 (8 GB) 00D5048 (16 GB) 46W0761 (32 GB)
Rated speed 1600 MHz 1866 MHz 1866 MHz 1866 MHz 1866 MHz
Rated voltage 1.35 V 1.5 V 1.5 V 1.5 V 1.5 V
Operating voltage 1.35 V 1.5 V 1.5 V 1.5 V 1.5 V 1.5 V
Max qty supported* 24 24 24 24 24 24
Max DIMM capacity 8 GB 8 GB 8 GB 8 GB 16 GB 32 GB
Max memory capacity 192 GB 192 GB 192 GB 384 GB 384 GB 768 GB
Max. memory at rated speed None 128 GB 64 GB 64 GB 256 GB 512 GB
Maximum operating speed
1 DIMM per channel 1333 MHz 1600 MHz 1866 MHz 1866 MHz 1866 MHz 1866 MHz
2 DIMMs per channel 1333 MHz 1600 MHz 1600 MHz 1600 MHz 1866 MHz 1866 MHz
3 DIMMs per channel 800 MHz 1066 MHz 1066 MHz 1066 MHz 1066 MHz 1066 MHz
* The maximum quantity that is supported is shown for two processors installed.

IBM System x3550 M4 18
Table 5. Maximum memory speeds (Part 2: Intel Xeon processor E5-2600 product family - RDIMMs)
Specification RDIMMs
Rank Single rank Dual rank Quad rank
Part numbers 49Y1405 (2 GB)
49Y1406 (4 GB)
49Y1559 (4 GB) 49Y1407 (4 GB)
49Y1397 (8 GB)
49Y1563 (16 GB)
90Y3178 (4 GB)
90Y3109 (8 GB)
00D4968 (16 GB)
49Y1399 (8 GB)
Rated speed 1333 MHz 1600 MHz 1333 MHz 1600 MHz 1066 MHz
Rated voltage 1.35 V 1.5 V 1.35 V 1.5 V 1.35 V
Operating voltage 1.35 V 1.5 V 1.5 V 1.35 V 1.5 V 1.5 V 1.35 V 1.5 V
Maximum quantity* 16 24 24 16 24 24 16 16
Largest DIMM 4 GB 4 GB 4 GB 16 GB 16 GB 16 GB 8 GB 8 GB
Maximum memory
capacity
64 GB 96 GB 96 GB 256 GB 384 GB 384 GB 128 GB 128 GB
Maximum memory
at rated speed
64 GB 64 GB 64 GB 256 GB 256 GB 256 GB 128 GB 64 GB
Maximum operating speed (MHz)
1 DIMM per channel 1333 MHz 1333 MHz 1600 MHz 1333 MHz 1333 MHz 1600 MHz 800 MHz 1066 MHz
2 DIMMs per channel 1333 MHz 1333 MHz 1600 MHz 1333 MHz 1333 MHz 1600 MHz 800 MHz 800 MHz
3 DIMMs per channel NS** 1066 MHz 1066 MHz NS** 1066 MHz 1066 MHz NS** NS**
* Maximum quantity supported is shown for two processors installed. When one processor installed the maximum
quantity supported is a half of shown.
** NS = Not Supported

IBM System x3550 M4 19
Table 5. Maximum memory speeds (Part 3: Intel Xeon processor E5-2600 product family - UDIMMs and
LRDIMMs)
Specification UDIMMs LRDIMMs
Rank Dual rank Quad rank
Part numbers 49Y1404 (4 GB) 90Y3105 (32 GB)
Rated speed 1333 MHz 1333 MHz
Rated voltage 1.35 V 1.35 V
Operating voltage 1.35 V 1.5 V 1.35 V 1.5 V
Maximum quantity* 16 16 24 24
Largest DIMM 4 GB 4 GB 32 GB 32 GB
Maximum memory
capacity
64 GB 64 GB 768 GB 768 GB
Maximum memory
at rated speed
32 GB 64 GB 256 GB 512 GB
Maximum operating speed (MHz)
1 DIMM per channel 1333 MHz 1333 MHz 1333 MHz 1333 MHz
2 DIMMs per channel 1066 MHz 1333 MHz 1066 MHz 1333 MHz
3 DIMMs per channel Not supported Not supported 1066 MHz 1066 MHz
* Maximum quantity supported is shown for two processors installed. When one processor installed the maximum
quantity supported is a half of shown.
The following memory protection technologies are supported:
ECC

Chipkill (for x4-based memory DIMMs)

Memory mirroring

Memory rank sparing

If memory mirroring is used, then DIMMs must be installed in pairs (a minimum of one pair per each
CPU), and both DIMMs in a pair must be identical in type and size.
If memory rank sparing is used, then a minimum of one quad-rank DIMM or two single-rank or dual-rank
DIMMs must be installed per populated channel (the DIMMs do not need being identical). In rank sparing
mode, one rank of a DIMM in each populated channel is reserved as spare memory. The size of a rank
varies depending on the DIMMs installed.

IBM System x3550 M4 20
The following table (Parts 1 and 2) lists memory options available for the x3550 M4 server.
Table 6. Memory options (Part 1: Intel Xeon processor E5-2600 v2 product family)
Part
number Feature code Description Maximum
supported
Standard
models
where used
RDIMMs - 1600 MHz
00D5024 A3QE 4GB (1x4GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC
DDR3 1600MHz LP RDIMM
24 (12 per CPU) A3x, B3x
00D5036 A3QH 8GB (1x8GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC
DDR3 1600MHz LP RDIMM
24 (12 per CPU) 53x, C3x, C5x,
D3x, F3x
RDIMMs - 1866 MHz
00D5020 A3QD 4GB (1x4GB, 1Rx4, 1.5V) PC3-14900 CL13 ECC
DDR3 1866MHz LP RDIMM
24 (12 per CPU) -
00D5032 A3QG 8GB (1x8GB, 1Rx4, 1.5V) PC3-14900 CL13 ECC
DDR3 1866MHz LP RDIMM
24 (12 per CPU) 23x, 33x, 43x,
73x, 83x, G3x,
H3x, J3x, L3x,
M3x
00D5040 A3QJ 8GB (1x8GB, 2Rx8, 1.5V) PC3-14900 CL13 ECC
DDR3 1866MHz LP RDIMM
24 (12 per CPU) -
00D5048 A3QL 16GB (1x16GB, 2Rx4, 1.5V) PC3-14900 CL13 ECC
DDR3 1866MHz LP RDIMM
24 (12 per CPU) -
LRDIMMs (support is planned for later in 2013)
46W0761 A47K 32GB (1x32GB, 4Rx4, 1.5V) PC3-14900 CL13 ECC
DDR3 1866MHz LP LRDIMM
24 (12 per CPU) -
