Expandable Storage Plus
2104 Models DU3 and TU3
Operator’s Guide
SA33-3310-03

Expandable Storage Plus
2104 Models DU3 and TU3
Operator’s Guide
SA33-3310-03

Fourth Edition (June 2003)
This revision supersedes SA33-3310-02. Technical changes are shown by a vertical line to the left of each change.
The following paragraph does not apply to any country where such provisions are inconsistent with local law:
THIS PUBLICATION IS PRINTED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in
certain transactions; therefore, this statement may not apply to you.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in new editions of the publication.
It is possible that this publication may contain reference to, or information about, products (machines and
programs), programming, or services that are not announced in your country. Such references or information must
not be construed to mean that such products, programming, or services will be offered in your country. Any
reference to a licensed program in this publication is not intended to state or imply that you can use only the
licensed program indicated. You can use any functionally equivalent program instead.
© Copyright International Business Machines Corporation 2000, 2003. All rights reserved.
Note to U.S. Government Users – Documentation related to restricted rights – Use, duplication, or disclosure is
subject to restrictions set forth in the GSA ADP Schedule Contract.

Contents
Communications Statements......v
Federal Communications Commission (FCC)
Statement...............v
Japanese Voluntary Control Council for Interference
(VCCI) Statement.............v
Korean Government Ministry of Communication
(MOC)Statement.............v
NewZealandComplianceStatement......v
International Electrotechnical Commission (IEC)
Statement...............v
Avis de conformitéàla réglementation d’Industrie
Canada ................vi
Industry Canada Compliance Statement .....vi
United Kingdom Telecommunications Requirements vi
EuropeanUnion(EU)Statement.......vi
Radio Protection for Germany ........vi
TaiwanClassAComplianceStatement.....vii
Safety Notices............ix
Definitions of Safety Notices .........ix
Acoustic Noise Declaration .........ix
Electrostatic Discharge (ESD) .....xi
About This Book ..........xiii
IfYouNeedMoreInformation........xiii
Trademarks..............xiii
Numbering Convention ..........xiv
Chapter 1. Using the 2104 Model DU3 or
TU3 ................1
2104 Model DU3 .............2
2104 Model TU3 .............4
Controls and Lights ............6
Disk Drive Module Lights .........7
Fan-and-Power-Supply Assembly and Fan
Assembly Lights and Switch ........9
SCSI Interface Card Lights ........12
Switch Card .............14
Identifying 2104 Disk Enclosures .......18
Identifying Disk Drive Modules .......19
Security ...............20
Ordering Cover Lock Keys ........20
Chapter 2. Adding Disk Drive Modules 23
Before Adding a Disk Drive Module ......24
To Add a Disk Drive Module ........26
Chapter 3. Exchanging FRUs .....31
Exchanging Disk Drive Modules .......32
Before Exchanging a Disk Drive Module....33
To Exchange a Disk Drive Module......34
Exchanging a Fan-and-Power-Supply Assembly . . 41
Before Exchanging a Fan-and-Power-Supply
Assembly ..............41
To Exchange a Fan-and-Power-Supply Assembly 42
Exchanging a Fan Assembly .........51
Before Exchanging a Fan Assembly .....51
To Exchange a Fan Assembly .......52
Exchanging a SCSI Interface Card Assembly . . . 58
Before Exchanging the SCSI Interface Card
Assembly ..............59
To Exchange a SCSI Interface Card Assembly . . 60
Exchanging the Switch Card Assembly .....69
Before Exchanging the Switch Card Assembly . . 69
To Exchange the Switch Card Assembly ....70
Reporting Problems ...........76
Appendix A. Operating with RISC
Systems ..............77
SCSI Adapters and Cables .........77
SCSI Service Aids ............77
Identifying a 2104 and its Disk Drive Modules . . 78
Problem Determination ..........78
Checking the SCSI Error Log ........78
Configuring a 2104 to the Using System - AIX
Systems Only..............78
Unconfiguring a 2104 from the Using System - AIX
Systems Only..............78
Configuring a 2104 in a SuSE Linux Enterprise
Server for pSeries Environment........78
Web Support Page ............78
Related Publications ...........79
Appendix B. Translated Safety Notices 81
Index ...............115
iii
|
|||
|||
||

iv 2104 Models DU3 and TU3 Operator’s Guide

Communications Statements
The following statements apply to this product. The statements for other products
intended for use with this product appear in their accompanying manuals.
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to
meet FCC emission limits. Neither the provider nor the manufacturer is
responsible for any radio or television interference caused by using other than
recommended cables and connectors or by unauthorized changes or modifications
to this equipment. Unauthorized changes or modifications could void the user’s
authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Japanese Voluntary Control Council for Interference (VCCI) Statement
This product is a Class A Information Technology Equipment and conforms to the
standards set by the Voluntary Control Council for Interference by Information
Technology Equipment (VCCI). In a domestic environment, this product might
cause radio interference, in which event the user might be required to take
adequate measures.
Korean Government Ministry of Communication (MOC) Statement
Please note that this device has been approved for business purposes with regard
to electromagnetic interference. If you find that this device is not suitable for your
use, you can exchange it for one that is approved for non-business purposes.
New Zealand Compliance Statement
This is a Class A product. In a domestic environment this product might cause
radio interference, in which event the user might be required to take adequate
measures
International Electrotechnical Commission (IEC) Statement
This product has been designed and built to comply with (IEC) Standard 60950.
v

Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe A est conforme àla norme NMB-003 du
Canada.
Industry Canada Compliance Statement
This Class A digital apparatus complies with IECS-003.
United Kingdom Telecommunications Requirements
This apparatus is manufactured to the International Safety Standard EN60950 and
as such is approved in the U.K. under approval number NS/G/1234/J/100003 for
indirect connection to public telecommunications systems in the United Kingdom.
European Union (EU) Statement
This product is in conformity with the protection requirements of EU council
directive 89/336/EEC on the approximation of the laws of the Member States
relating to electromagnetic compatibility. Neither the provider nor the
manufacturer can accept responsibility for any failure to satisfy the protection
requirements resulting from a non-recommended modification of the product,
including the fitting of option cards not supplied by the manufacturer.
This product is in conformity with the EU council directive 73/23/EEC on the
approximation of the laws of the Member States relating to electrical equipment
designed for use within certain voltage limits. This conformity is based on
compliance with the following harmonized standard: EN60950.
Radio Protection for Germany
Zulassungsbescheinigung laut dem Deutschen Gesetz über die
elektromagnetische Verträglichkeit von Geräten (EMVG) vom 30. August 1995
(bzw. der EMC EG Richtlinie 89/336):
Dieses Gerät ist berechtigt in Übereinstimmung mit dem Deutschen EMVG das
EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die
Konformitätserklärung nach Paragraph 5 des EMVG ist die:
IBM Deutschland Informationssysteme GmbH, 70548 Stuttgart.
Informationen in Hinsicht EMVG Paragraph 3 Abs. (2) :
Das Gerät erfüllt die Schutzanforderungen nach EN 50082-1 und EN 55022 Klasse A.
EN 55022 Klasse A Geräte müssen mit folgendem Warnhinweis versehen werden:
″Warnung: dies ist eine Einrichtung der Klasse A. Diese Einrichtung kann im
Wohnbereich Funkstörungen verursachen; in diesem Fall kann vom Betreiber
verlangt werden, angemessene Massnahmen durchzuführen und dafür
aufzukommen.″
EN 50082-1 Hinweis:
″Wird dieses Gerät in einer industriellen Umgebung betrieben (wie in EN 50082-2
festgelegt), dann kann es dabei eventuell gestört werden. In solch einem Fall ist
der Abstand bzw. die Abschirmung zu der industriellen Störquelle zu vergrössern.″
vi 2104 Models DU3 and TU3 Operator’s Guide

Anmerkung:
Um die Einhaltung des EMVG sicherzustellen sind die Geräte, wie in den
Handbüchern angegeben, zu installieren und zu betreiben.
Taiwan Class A Compliance Statement
Communications Statements vii

viii 2104 Models DU3 and TU3 Operator’s Guide

Safety Notices
For a translation of the danger and caution notices contained in this book, see
Appendix B, “Translated Safety Notices”, on page 81.
Definitions of Safety Notices
Adanger notice indicates the presence of a hazard that has the potential of causing
death or serious injury.
Adanger notice appears on page 46.
Acaution notice indicates the presence of a hazard that has the potential of causing
moderate or minor personal injury.
Caution notices appear on pages 43, 45, 54, 63, 65, and 72.
An attention notice indicates an action that could cause damage to a program,
device, system, or data.
Acoustic Noise Declaration
The equivalent continuous A-weighted sound pressure level at the bystander’s
position measured for a 2104 Model DU3 or TU3 does not exceed 68 dB(A). This
level has been measured under the following conditions:
vRack-mounted unit:
–The 2104 Model DU3 had fourteen disk drive modules installed.
–The 2104 Model DU3 was installed in a 7202 Rack with the bottom of the
2104 Model DU3 system at EIA position 17.
–The remainder of the rack was filled with units to which power was not
connected.
vDeskside unit:
–The 2104 Model TU3 had fourteen disk drive modules installed.
These levels were measured using a procedure in accordance with ISO standard
DIS7779, Measurement of Airborne Noise Emitted by Computer and Business Equipment.
The equipment was installed and operated as described in Appendix C.8 of that
standard.
ix

x2104 Models DU3 and TU3 Operator’s Guide

Electrostatic Discharge (ESD)
Attention:
When you handle field-replaceable units (FRUs) and other computer parts, take
these precautions to avoid static damage:
vLimit your movement. Movement can cause static electricity to build up
around you.
vAlways touch computer parts carefully. Hold adapters and memory-modules
by their edges. Never touch any exposed circuits.
vPrevent people who are not correctly grounded from touching computer parts.
vBefore you install a new part, touch the static-protective package that contains
the part against an unpainted metal part of the 2104 or using system for at
least two seconds. This action reduces static electricity in the package and in
your body.
vRemove the part from its package and, if possible, install it directly into the
2104 without putting the part down. If you need to put the part down, first
place the static-protective package that contained the part onto a smooth, level
surface, then place the part onto the package. Do not place the part onto any
metal surface.
xi

xii 2104 Models DU3 and TU3 Operator’s Guide

About This Book
This book is for people who operate a system that has one or more 2104 Model
DU3 or TU3 connected to it.
Throughout this book, service representative means a person who has been
authorized by your organization to maintain your 2104 Model DU3 or TU3.
Chapter 1 describes the 2104 Models DU3 and TU3, their controls, and how to use
them.
Chapter 2 describes how to add disk drive modules to a 2104 Model DU3 or TU3
that is already installed as part of your system.
Chapter 3 describes what to do if you have a problem with your 2104 Model DU3
or TU3. It tells you how to replace particular failed components, such as disk drive
modules, and what to report if you need to call your service representative for
assistance.
Appendix A gives additional information about using a 2104 Model DU3 or TU3
that is attached to a RISC system.
Appendix B gives a translation of all danger and caution notices contained in this
book.
An index is provided at the back of this book.
If You Need More Information
Other books that you might need are:
vExpandable Storage Plus : 2104 Model DU3 Installation Guide, GA33-3311
vExpandable Storage Plus : 2104 Model TU3 Installation Guide, GA33-3312
vExpandable Storage Plus : 2104 Models DU3 and TU3 Service Guide, GY33-0198
vThe Operator Guide for your system
vThe User’s Guide for your using-system SCSI attachment (for example, your SCSI
adapter)
vThe Site and Hardware Planning Information for your system
vThe Problem Solving Guide and Reference for your system.
Trademarks
The following items are trademarks of International Business Machines
Corporation in the United States, or other countries, or both:
vAIX
vIBM
vRS/6000
vEserver
xiii

Numbering Convention
In this book:
KB means 1 000 bytes.
MB means 1 000 000 bytes.
GB means 1 000 000 000 bytes.
xiv 2104 Models DU3 and TU3 Operator’s Guide

Chapter 1. Using the 2104 Model DU3 or TU3
Important: The installation of this product is a customer responsibility.
Attention: Before continuing with any of the actions described in this book,
please refer to “Safety Notices”on page ix.
This section describes the Expandable Storage Plus: 2104 Models DU3 and TU3,
their controls, and how to use them. A 2104 Model DU3 or TU3 can be attached to
any supported RS/6000
™
or IBM ER s e r v e r pSeries computer that provides support
for any of the Small Computer System Interface (SCSI) adapters listed in “SCSI
Adapters and Cables”on page 77.
The 2104 Models DU3 and TU3 look like this:
Figure 1. 2104 Model TU3 (Left) and 2104 Model DU3 (Right)
1

2104 Model DU3
The 2104 Model DU3 is a rack-mounted SCSI disk enclosure that can be installed
into a standard Electrical Industries Association (EIA) 19-inch rack.
A fully configured 2104 Model DU3 looks like this:
Figure 2. 2104 Model DU3 from the Front (Top) and Back (Bottom)
22104 Models DU3 and TU3 Operator’s Guide

At the front of a 2104 Model DU3 there are 14 device slots 1. Each slot must
contain either a SCSI disk drive module, or a dummy disk module. Each disk
drive module connects to a backplane which is mounted vertically about halfway
between the front and back of the 2104 Model DU3.
Note: To run I/O at least one SCSI disk drive module must be present in each
2104 Model DU3.
The 14 device slots are divided into two groups of seven slots. Between the two
groups of seven slots there is a SCSI bridge card2. The SCSI bridge card assigns
the disk drive modules to a SCSI bus, in accordance with the setting of the SCSI
bus split switch on the switch card 5.
On the back of the backplane are connectors for two fan-and-power-supply
assemblies3, two SCSI interface cards4, and a switch card5.
The 2104 Model DU3 has either two fan-and-power-supply assemblies or one
fan-and-power-supply assembly and one fan assembly. Either option provides all
the necessary power and cooling for the 2104 Model DU3.
It is better, however, to have two fan-and-power-supply assemblies, rather than
one fan-and-power-supply assembly and one fan assembly, because then the
amount of power required from each power supply is reduced, and, if one power
supply fails, power for the 2104 disk enclosure continues to be supplied by the
other power supply.
The SCSI interface cards4 are used to connect host machines to the 2104 Model
DU3. These cards contain logic that provides information about what is happening
in the 2104 Model DU3 and the status of components within it.
The switch card5 contains switches that control which SCSI bus mode is selected,
how the 2104 Model DU3 is supplied with power, and what enclosure services are
enabled. It also contains a rotary switch that sets the ID of the 2104 Model DU3.
Options for configuring a 2104 Model DU3 are described in the Expandable Storage
Plus: 2104 Model DU3 Installation Guide.
Chapter 1. Using the 2104 Model DU3 or TU3 3

2104 Model TU3
The 2104 Model TU3 is a deskside SCSI disk enclosure.
A fully configured 2104 Model TU3 looks like this:
Figure 3. 2104 Model TU3 from the Front (Left) and Back (Right)
42104 Models DU3 and TU3 Operator’s Guide
