Document information
Intended purpose and audience
This manual contains the instructions for installing and maintaining this appliance. The audience for this
guide consists of those individuals responsible for installing IBM Cloud Object Storage System™
appliances.
Note:
• The equipment and device described for installation herein are sophisticated and relatively complex to
install. The party or parties installing the equipment must be familiar with installations of computer
hardware and disk drives prior to attempting this installation. Only personnel procient in working with
computer hardware and disk drives should attempt to install this appliance.
• After all appliances have been installed in the rack, refer to the Appliance Conguration Guide to
congure the appliance settings required prior to setting up the system.
• After these appliances are congured, refer to the System Manager Administration Guide for information
about how to congure, operate, and maintain your system.
• Both the Appliance Conguration Guide and the System Manager Administration Guide assume that all
necessary appliances for the system are installed in the rack.
© Copyright IBM Corp. 2016, 2020 v

vi IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Safety and environmental notices
Review the safety notices, environmental notices, and electronic emission notices for IBM® Cloud Object
Storage System before you install and use the product.
Suitability for telecommunication environment - This product is not intended to connect directly or
indirectly by any means whatsoever to interfaces of public telecommunications networks.
Examples of a caution and a danger notice. Numbers in parentheses refer to message numbers in the IBM
Safety Notices publication G229-9054, which is included with your product.
CAUTION: A caution notice indicates the presence of a hazard that has the potential of causing
moderate or minor personal injury. (C001)
DANGER: A danger notice indicates the presence of a hazard that has the potential of causing
death or serious personal injury. (D002)
Safety notices
Safety notices for this product.
Familiarize yourself with the IBM Safety Notices publication G229-9054, which is included with your
product.
© Copyright IBM Corp. 2016, 2020 vii

viii IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Safety and environmental notices ix

Environmental notices
This information contains all of the environmental notices for IBM Systems products in English and other
languages.
The IBM Systems Environmental Notices information includes statements on limitations, product
information, product recycling and disposal, battery information, flat panel display, refrigeration and
water-cooling systems, external power supplies, and safety data sheets.
Declared noise emissions
Declared noise emissions in accordance with ISO 9296(1, 2, 3)
Table 1. Declared noise emissions in accordance with ISO 9296(1,2,3)
Product description Declared A-Weighted
Sound Power Level,
LWAd (B)
Declared A-Weighted
Sound Pressure Level,
LpAm (dB)
Operating Idling Operating Idling
Models: A00, A01, A02, M01
@ 25 deg. C room ambient
7.2(4) 6.8 56 52
Models: A00, A01, A02, M01
@ 35 deg. C room ambient
7.2(4) 7.2(4) 56 56
Models: A00, A01, A02, M01
@ 25 deg. C room ambient
Acoustical Doors Feature codes
FC EC07 = back FC EC08 = front
6.6 6.2 49 45
Models: A00, A01, A02, M01
@ 35 deg. C room ambient
Acoustical Doors Feature codes
FC EC07 = back FC EC08 = front
6.6 6.6 49 49
x IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Table 1. Declared noise emissions in accordance with ISO 9296(1,2,3) (continued)
Product description Declared A-Weighted
Sound Power Level,
LWAd (B)
Declared A-Weighted
Sound Pressure Level,
LpAm (dB)
Operating Idling Operating Idling
Notes:
1. Declared level LWAd is the upper-limit A-weighted sound power level; Declared level LpAm is the mean
A-weighted sound pressure level measured at the 1-meter bystander positions.
2. All measurements made in conformance with ISO 7779 and declared in conformance with ISO 9296.
3. B, dB, abbreviations for bels and decibels, respectively. 1 B = 10 dB.
4. Notice: Government regulations (such as those prescribed by OSHA or European Community
Directives) may govern noise level exposure in the workplace and may apply to you and your server
installation. This IBM system is available with an optional acoustical door feature that can help
reduce the noise emitted from this system. The actual sound pressure levels in your installation
depend upon a variety of factors, including the number of racks in the installation; the size, materials,
and conguration of the room where you designate the racks to be installed; the noise levels from
other equipment; the room ambient temperature, and employees' location in relation to the
equipment. Further, compliance with such government regulations also depends upon a variety of
additional factors, including the duration of employees' exposure and whether employees wear
hearing protection. IBM recommends that you consult with qualied experts in this eld to
determine whether you are in compliance with the applicable regulations.
Safety and environmental notices xi

xii IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Support information
Technical support contacts.
For more information on the product or help with troubleshooting, contact IBM Support at ibm.com/
mysupport or visit the Directory of worldwide contacts.
© Copyright IBM Corp. 2016, 2020 xiii

xiv IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Chapter 1. Manager 3105 Appliance Manual
This information contains the instructions for installing and maintaining the Manager 3105 appliance.
© Copyright IBM Corp. 2016, 2020 1

2 IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Chapter 2. Appliance safety precautions
Observe physical, electrical, and electronic component safety precautions.
Physical
Ensure that your equipment rack is placed in a dust-free, well-ventilated area close to an uninterruptible
power supply (UPS). Leave enough room behind and around the rack for services and sufcient airflow.
• Keep the area around the appliance clean and free of clutter.
• Place the appliance top cover and any appliance components that were removed away from the
appliance or on a table so that they do not accidentally get damaged.
• While you are working on the appliance, do not wear loose clothing such as neckties and unbuttoned
shirt sleeves. They can retain a charge even if you are wearing a wrist strap, or could be pulled into a
fan.
• After you access the inside of the appliance, close the appliance and secure it to the rack unit with the
retention screws after you ensure that all connections are made.
• Close the rack’s front door and all panels and components on the appliances when not servicing to
maintain proper cooling.
Electrical
Basic electrical safety precautions must be followed to protect yourself and the appliance:
• Do not work alone with high-voltage components.
• Be aware of the locations of the power switch on the appliance and the room’s emergency power-off
switch, disconnection switch, or electrical outlet. If an electrical accident occurs, quickly remove power
from the system.
DANGER: A danger of explosion exists if the Onboard battery is installed upside down, which
reverses its polarities. This battery must be replaced only with the same or an equivalent type that
is recommended by the manufacturer. Dispose of used batteries according to the battery
manufacturer’s instructions.
Electronic components
Electrostatic discharge (ESD) is generated by two objects with different electrical charges when they
come into contact with each other. An ESD neutralizes this difference, which can damage electronic
components and printed circuit boards (PCBs). In general, the following measures are sufcient to
neutralize this difference before contact is made to protect equipment from ESD:
• Use a grounded wrist strap that is designed to prevent ESDs.
• Keep all components in their antistatic containers until ready for installation.
© Copyright IBM Corp. 2016, 2020 3

• Touch a grounded metal object before you remove any board from its antistatic container.
• Remove any jewelry or metal objects from your body. They are excellent metal conductors that can
create short circuits and harm you if they come into contact with printed circuit boards or areas where
power is present.
4 IBM Cloud Object Storage System: Manager 3105 Appliance Manual

Chapter 3. Specications and requirements
See the appendix for additional specications.
Appliance specications
• CPU is Intel Xeon E5-2690v3 processor
• 8 x 16 GB PC4-17000 2133 MHz ECC Registered RAM modules
• 1U server with 8 front-accessible 2.5" drive bays
• Four 4-cm internal fans
• 2 hot-swappable 750 W PSUs in 1+1 conguration
• 3 OS/data drives - Seagate ST1200MM0118 in a RAID 5 conguration
• Onboard IPMI
• 2 Onboard 1 Gbps network ports
• 1 Onboard 1 Gbps dedicated IPMI network port
Note: Extra Networking Option
The appliance can support another networking card to provide extra Ethernet ports. This port is found to
the right of center on the rear of the appliance, as shown in the following gure.
Figure 1. Rear of the appliance with the card slot highlighted
Requirements
Cabling
Table 2. Cabling requirements for the appliance
Cable Type and Usage
Power Cords Use only the power cords that are supplied with the appliance. Do not use
another type of cord. Do not use extension cords. If more power cords are
needed, contact IBM Support.
1000BASE-T Copper
Cables
Use high-quality Category 5e or 5 (CAT5e, CAT5) copper cables.
Optical Fiber Cables Use Intel based enhanced small form-factor pluggable (SFP+) transceivers only.
Both short reach (SFP+ SR) and long reach (SFP+ LR) optics are supported.
Optical ber cable specications depend on the SFP+ module used. For more
detail, refer to Intel documentation on Modules and Cables.
Direct Attach Copper
Cables
Any SFP+ passive or active direct attach copper cable compliant with the
SFF-8431 v4.1 and SFF-8472 v10.4 specications is supported. For more
information, see Intel documentation on Modules and Cables.
© Copyright IBM Corp. 2016, 2020 5

6 IBM Cloud Object Storage System: Manager 3105 Appliance Manual
