IC ELECTRIC SCL 33 DA 4015BP User manual
www.ic-electronic.com
So starter with integrated Motor Protection, Current and Voltage control
3 phases controlled with internal by-pass
Rated operational Voltage 400VAC
Frequency 45 ... 65Hz self detecting and corrective
Initial torque 20 ... 50%
Electronic motor protection Trip class 10
Adjustable I2t setting for optimal motor protection
Phase sequence protection
Temperature protection internal
Ramping sequence with current limiting
Automatic reduction to optimum start current
Relay for fault signal
Relay for operating signal
LED- indications “ON”: Power, ramping, bypassing, ser-
vice, pause and stop.
LED- indications “FAULT”: Over-/undercurrent, Stall,
Voltage control, Frequency control, Motor connections,
Main supply connections, Motor protection, Temperature
control.
Spring clamp terminals for montage.
Automatic reset aer failure.
Selection and technical specications.
Product type Rated operational EAN Nr. Rated operational Control
voltage Ue current Ie voltage Uc
SCL 33 DA 4015BP 400VAC 5705609002893 15A AC 58b 230VAC
SCL 33 DA 4025BP 400VAC 5705609002909 25A AC 58b 230VAC
SCL 33 DA 4035BP 400VAC 5705609002916 35A AC 58b 230VAC
Product description:
e So starter is 3 phase controlled and designed for
starting and running compressor motors. e so
starter has current controlled ramping up and by-pass
function.
e voltage control compensate for missing start
torque at starting up ramping. e current measure-
ment is also for I2t calculation for protection of the
motor. e motor protection has to be adjusted before
starting up.
e so starter has internal by-pass relays for bypass-
ing the semiconductors when the motor is in full
speed.
Any kind of failure cause stop and the so starter will
go into service mode until the failure is reset. e so
starter has also pause mode for protecting the
semiconductors against overheating.
Alarm indication is provided through a red LED which
signals the type of fault via a user-friendly ashing
sequence.
2
Costumer Advantage:
Current reduction up to 65% peak, extend mechanical lifetime of the compressor.
Current reduction eliminates the voltage clips and light ickering.
Real RMS current measurement, for exact control of the current.
Mounting from the top and down.
Spring clamps for fast and easy mounting.
Internal motor protection (I2t- metering, using class 10 trip curve) gives reduction in cost for external motor protec-
tion and wiring.
Individual adaptation.
Fault detections:
Over/under current : If the current cross the upper limit the so starter will go into service mode to protect
relays and motor. e failure is automatically reset.
: If the current is too low, the so starter will go into service mode and stay until the
failure is automatically reset.
Motor protection : e protection of the motor is continuously monitored and will trip according to trip
class 10. e failure is automatically reset.
(Other trip classes can be integrated).
Stall : If the motor is stalling the current will raise and the motor protection will close
down.
e failure is automatically reset.
Temperature control : If the temperature in the so starter is detected to be under or over allowed
temperature the so starter will be in service mode and not be able to start until the
temperature is in between the limits.
Frequency sequence : If the frequency is outside the area (45 … 65 Hz) it will not be able to start.
e so starter will be in service mode until the failure is corrected and reset.
Hardware failure : If a hardware failure occur inside the so starter. e so starter will stop and go into
pause mode. e failure can be reset manually but it will continue in the pause mode
until the time is running out.
Reset (push button) : e reset will reset all failure. e pause will continue until end of time.
e motor will start if the start signal is activated, if not it will go into service mode.
e so starter is active (motor not running) :
If the voltage drop below lower level the “Fault” alarm will occur and the so starter
will go into “Service” mode and wait until the voltage is over lower level.
If the voltage is above upper level the “Fault” alarm will occur and the so starter will
go into “Service” mode and wait until the voltage is below upper level.
Motor Protection Adjustment :
Adjust the motor current to In + 10% as maximum.
20A
32A
29A
35A
26A
23A
22A
19A 16A
10A
25A 13A
12,6
10,2A
15A 3A
7,8A
5,4A
3
Technical specications:
Supply voltage specications:
Rated operational voltage Ue (L1-L2-L3) : 400VAC +15/- 15%
Rated AC frequency (self detecting and corrective) : 45 …65Hz
Rated insulation voltage : 660Vrms
Undervoltage alarm : 300VAC
Overvoltage alarm : 480 VAC
Control voltage specications:
Control voltage Uc : 230VAC +/- 15%
Control current : 5mA
Max. control current for no operation : 1,5W max
Drop-out voltage less than : 90 VAC
Response time max. : Start 2000 msec
: Stop 200 msec
Insulation specications:
Rated insulation voltage : Ui 660Volt
Rated impulse withstand voltage : Uimp. 4 kVolt
Installation category : III
Output specications:
Utilization category : AC 58b with integrated by-pass contactor
Overload current prole 15/25/35A: : 15A X-Tx: 6-1:300
: 25A X-Tx: 6-1:300
: 35A X-Tx: 6-1:300
General specications
Initial torque : 20 … 50%
Motor current nominal : 3 … 15A; 10 … 25A; 20 … 35A;
Start current limit : 35 …45% of LRA
LRA max. : 66/100/140 A;
automatic adjusted @ motor.
Semiconductor data
Product type Rated operational current I2t Short circuit protection
SCL 33 DA 4015BP 15A 610 A2s max.: 35A gl/gG
SCL 33 DA 4025BP 25A 1800 A2s max.: 63A gl/gG
SCL 33 DA 4035BP 35A 1800 A2s max.: 63A gl/gG
Indications (LED):
Ready mode : e yellow LED is blinking steady slowly.
Run mode : e yellow LED is light steady.
Pause mode : e yellow LED is blinking steady fast.
Fault : e yellow LED is ashing 10 times sequence and the red LED is ashing with
a fault-code sequence.
Hardware failure : e red LED is blinking with a fault-code sequence. 4
Fault:
LED red (alarm signals via user friendly ashing sequence)
- High voltage / low voltage / Voltage (2)
- High current / low current (3)
- Current not symmetrical (3)
- Motor protection (I2t) (3)
- Stall (4)
- By-pass relay failure (5)
- High temperature / low temperature (6)
- Connection failure (7)
- Wrong phase sequence (7)
- Wrong frequency (8)
- Failure in so starter (9)
4/T2 6/T32/T1
3/L21/L1 5/L3
34 14 C A NL
Housing material:
Self- extinguishing ABS/PC UL94V0 Halogen
free
Colour: black
Integrated DIN-Rail connection
Terminal blocks:
Spring clamps main-/motor connection 6 mm2
Spring clamps control 2,5 mm2
L1; L2; L3: Main supply
T1; T2; T3: Motor connection
A : Control voltage 230VAC -
C – 14 : For control of start/stop function
C – 34 : Fault signal relay
N (A2) : Neutral -
L : Phase 230VAC -
Wiring specications
Mounting instructions
5
Environent:
Degree of protection : IP 20
Pollution degree : 3
Operating temperature : -20 to 65C
Storage temperature : -20 to 80C
Terminals : Spring clamps
75
150
80
80 mm min.
30 mm min.
30 mm min.
Dimensions
Motor Protection:
The internal electronic motorprotection is
automatically temperature compensated.
The motor protections acts exactly as an
external motor protection circuit breaker.
Figure: Electronic Motorprotection Class 10.
Mode of Operation:
Motor
Signal Out
Main Voltage
Yellow LED
Ctrl. Volt
Normal Conditions
Ready 5 min. < 5 min. 5 min.
R
6
5 min.
Red LED error code
Yellow LED ready
Yellow LED break
Running
Error 10 ashing
Cold
Hot
<
<
Locked Rotor/Fault (4)
Main Voltage
Yellow LED
Ctrl. Volt
Motor
Signal
Alarm Out
Alarm
High Temperature/Fault (6)
Break/Normal
Main Voltage
Yellow LED
Ctrl. Volt
Motor
Signal
Alarm
Alarm Out
Main Voltage
Power S
Yellow LED
Ctrl. Volt
Motor
Pause
< 3 min. >
<5 min. Break >
7
< Condition fultilled >
tamb < tspec.
Alarm timed out.
1 2 3
5 min.1 + 2 = 5 min.
< 5min. < 5 min.
Standards
Restrictions of hazardous substances RoHs Compliant
CE Marking LVD EN 60947-4-2
EMC: Immunity EN 61000-6-4
Emission EN 61000-6-2
Electrostatic Dicharge ESD
Immunity EN 61000-4-2
8kV, Air discharge
4kV, Contact
Electrical fast transient/
Burst Immunity EN 61000-4-4
Output 4kV
Input 4kV
Electrical Surge Immunity EN 61000-4-5
Output, line to line 1kV
Output, line to earth 2kV
Input, line to line 1kV
Input, line to earth 2kV
Radiated Radio Frequency EN 61000-4-3
Immunity 3V/m, 80-1000MHz
Conducted Radio Frequency EN 61000-4-6
Immunity 3V/m, 0,15-80MHz
Voltage dips & interference IEC/EN 61000-4-11
Radio interference eld
emissions (radiated) CISPR 11
IEC/EN 55011, ClassB
Radio interference voltage
emissions (conducted) CISPR 11
IEC/EN 55011,ClassB
Harmonics IEC 61000-3-2
8
Specications are subject to change without notice (2014.07.30).
Eksportvej 7-9 · Laurbjerg
DK-8870 Langaa · Denmark
Phone: +45 70 23 49 44
Fax: +45 70 23 49 24
E-mail: info@ic-electronic.com
www.ic-electronic.com
