Ice-O-Matic ICE2106 Series User manual

11100 E. 45th Avenue
Denver, CO 80239
Phone: 1. 866. PURE. ICE
Fax: [phone]
www.iceomatic.com
Rev: A-01/09
®
Part: 1016
ICE2106/2107Cube Ice Machine
ICE2106/2107Cube Ice Machine
ICE2106 on B100
Features
•Space saving 26" (660 mm) tall design.
•Produces up to 1,998 lbs (908 kg) of ice perday.
•HarvestAssist provides consistent ice production for the life of the ice
maker while reducing energy consumption and increasing capacity.
•PureIce® exclusively by Ice-O-Matic. Built-in antimicrobial protection for the life of the
ice maker inhibits bacteria growth on ice maker surfaces. Ice-O-Matic's optional water
filtration system provides protection against unpleasant tastes, odors and scale formation.
•Durable, electroless nickel plating on all evaporator plates ensures reliability.
•Longestwarrantyintheindustry. Purchase an Ice-O-Matic water filter with your
cube ice maker, replace the filter every six months, and the evaporator warranty
is extended to 7 years parts and labor (availableintheU.S.andCanadaonly).
•Constructed from corrosion-resistant stainless steel and fingerprint-proof plastic.
Options & Accessories
Water Filters
Ice Machine
Model
Manifold Inline
System Replacement System
ICE2106 IFQ2 IOMQ (2) N/A
ICE2107 IFQ2 IOMQ (2) N/A
Ice Maker Warranty
Every Ice-O-Matic ice maker is backed by a warranty that
provides both parts and laborcoverage.
•Three years Parts and Labor.
•Five years Parts coverage on the evaporator and compressor.
•Seven years Parts and Labor on the evaporator when you
purchase an Ice-O-Matic water filter with your cube ice maker
and replace the filter every six months (availableintheU.S.
andCanadaonly).
Ice Form
CUBED ICE
Full Cube
W x D x H (in) ⁄x ⁄ x ⁄
W x D x H (mm) 22 x 22 x 22
Half Cube
W x D x H (in) ⁄x ⁄x ⁄
W x D x H (mm) 22 x 22 x 10
Bin Chart
KitsforCombiningWiderBinswithSmallerModels
Ice Storage Bins
ModelNo.
Capacity
Width
B25
255lbs(116kg)
30in(762mm).
B40
365lbs(165kg)
30in(762mm)
B42
374lbs(170kg)
22in(559mm)
B55
556lbs(252kg)
30in(762mm)
B100
927lbs(420kg)
48in(1219mm)
B120
1193lbs(541kg)
48in(1219mm)
B150
1499lbs(679kg)
60in(1524mm)
B170
1866lbs(846kg)
60in(1524mm)
Kits
ICE2106 N/A N/A N/A N/A KIT NOT
REQUIRED
KIT NOT
REQUIRED
KIT NOT
REQUIRED
KIT NOT
REQUIRED
ICE2107 N/A N/A N/A N/A KIT NOT
REQUIRED
KIT NOT
REQUIRED
KIT NOT
REQUIRED
KIT NOT
REQUIRED
*SeeIce-O-MaticPriceListforAdapterKitstocombineicemakerswithmostavailableice/beveragedispensers.
ISO 9001 Certied
ICE2106/2107 - Cube Ice Maker

11100 E. 45th Avenue
Denver, CO 80239
Phone: 1. 866. PURE. ICE
Fax: [phone]
www.iceomatic.com
Rev: A-01/09
®
Part: 1016
Water Cooled/Remote
A. Ice maker potable water in, ⁄"FPT.
B. Ice maker water out, ⁄"FPT.
C. Hole for electricalconnections, ⁄".
D. Electrical Junction Box.
E. Condenser water in, ⁄"FPT.
F. Condenser water out, ⁄"FPT.
G. Liquid line, ⁄" male quick connect
coupling for precharged line set
(remoteonly).
H. Discharge line, ⁄" male
quickconnect coupling for
precharged line set (remoteonly).
I. Hole for remote electrical
connections, ⁄" (remoteonly).
1.75" (45 mm)
2.9"
(74 mm)
3.2"
(81 mm)
.75" (19 mm)
8.9"
(229 mm)
18"
(460 mm)
18"
(460 mm)
19.1"
(485 mm)
19.1"
(485 mm)
21.2"
(536 mm)
21.2"
(536 mm)
15"
(381 mm)
15"
(381 mm)
6.7" (170 mm)6.7" (170 mm)
3.4"
(86 mm)
3.4"
(86 mm)
8.9"
(229 mm)
8.9"
(229 mm)
17.2" (565 mm)17.2" (565 mm)
23.3" (565 mm)23.3" (565 mm)
C.
F.
E.
G.
I.
H. A.
B.
3.6" (92 mm)
D.
Bin Strap Bin Strap
WaterCooled&Remote
Operating Requirements
Minimum Maximum
AmbientTemp. Range Air 50˚F (10˚C) 100˚F (38˚C)
WaterTemp. 40˚F (4.4˚C) 100˚F (38˚C)
Water Pressure 20 PSIG (1.4 BAR) 60 PSIG (4.1 BAR)
Dimensions
All Models
W x D x H (inches) 48 x 26 x 24
W x D x H (mm) 1,219 x 660 x 610
Specifications
Model Number Cond. Unit
Ice Production
per 24hrs
Water Usage
gallons per 100 lbs of Ice
90°F air/70°F water kWH Used
per 100 lbs
of ice @
90°F air/
70°F water
Voltage
Characteristics
Min.
Circuit
Ampacity
Fuse
Size
Approx.
BTUs
per hour
70°F air/
50°F water
lbs (kg)
90°F air/
70°F water
lbs (kg)
Potable Condenser
ICE2106R Remote* 1,737 (790) 1,561 (710) 21.8 - 5.0 208-230/60/1 26.9 30 30,034
ICE2106W Water 1,856 (844) 1,692 (769) 23.6 156 3.9 208-230/60/1 22.3 30 29,091
ICE2107R Remote* 1,636 (744) 1,525 (693) 21.8 - 5.0 208-230/60/3 21.2 25 29,342
ICE2107W Water 1,814 (825) 1,650 (750) 24.2 154 3.9 208-230/60/3 13.5 30 28,369
*RequiresRemoteVRC5061Condenserandprechargelineset.
NOTES:
NumberofWires: ICE2106:3(includingground) • ICE2107:4(includingground)
Approx.ShippingWeightlbs(kg): ICE2106R340(155) • ICE2106W310(141) • ICE2107R340(155) • ICE2107W340(155)
Refrigerant Type: R404A
