Ice-Tech EUROC 4 User manual

EUROC 4 INSTALLATION
STEPS TO START UP THE EUROC 4 WATER SOFTENER
1. WATER CONNECTION
Connect water to the unit, inlet and outlet. Connect also the drain line.
Rear view

EUROC 4 INSTALLATION
Top view
2. FILLING THE BRINE DEPOSIT WITH SALT
The brine deposit should be fill up with salt.
3. START UP
Fill with water half the bin. Wait around 15 minutes. If posible, wait 3 to 4
hours before starting the unit the first time.
Connect to power and program as folllows:
Time of day: press until desired hour
appears. Release.
Range: 0 through 23 hours
Note: The elapsed minutes will reset to
zero when the hours are changed.
Regenerant dosage: Press until
desired regenerant dosage appears.
Release.
Range: 0,20 kg to 6,0 kg
0,20 kg to 1,0 kg by increments of 0,05 kg
1,0 kg to 3,0 kg by increments of 0,1 kg
3,0 kg to 6,0 kg by increments of 0,5 kg
Default: 0,6 kg
Capacity Cubic Meters: Press until
desired interval appears.
Release.
Range: 0,40 to 9,cubic meters
0,40 m3 t 1,0 m3 by increments of 0,05 m3
(12 increments)
1,0 m3 to 3,0 m3 by increments of 0,1 m3
(20 increments)
3,0 m3 to 5,0 m3 by increments of 0,2 m3
(10 increments)
5,0 m3 to 9,5 m3 by increments of 0,05 m3
(10 increments)

EUROC 4 INSTALLATION
Press during 3 seconds to start a manual regeneration.
Open the water supply very slow to approximately the ¼ open position. Let it
flow until the air inside is purged from the tank. Allow the water to run to
drain until the water runs clear from the drain line.
Open the water supply all the way.
Regeneration schelude
The programmer needs a method to set days between regeneration for regulary requirements
and for cases when the flow sensor has failed.
Enter by holding and for 3 seconds. Press to increase the value.
0 = no calendar override
0,3 = Regeneration every 8 hours.
0,5 = Regeneration every 12 hours.
1-30 days between regeneration
Default: 0
