iCeeO2 C30 User manual
www.iCeeO2.com 1 iCeeO2-C30_US_009.UserMan.docx
Product may vary from picture.
To ensure safety, please read this manual carefully before installation and
follow the instructions herein.
Store this manual in a secure place for future reference.
WARNING: CHOKING HAZARD - Accessories contain small parts.
This manual is printed by color ink; water will smudge.
Getting Started ...................................2
Package Contents ...............................2
Features at a Glance...........................2
Operating Instructions........................2
LCD Display .........................................3
Trend Chart Zoom ..............................4
Max/Min.............................................4
Outo Detect Day/Night ......................4
Output Control ...................................4
LED Display .........................................5
Main Menu Functions ........................5
Specifications .....................................6
Instruction manual
CO2 Controller
models –C30
www.iCeeO2.com 2 iCeeO2-C30_US_009.UserMan.docx
Getting Started
Hello there! Congratulations on your new iCeeO2product! Our products are
packaged and shipped with the utmost care. In the unlikely event that your item is
incorrect, incomplete, or unsatisfactory, please contact us and we will see to fix it
.
Package Contents
CO2Controller Unit
CO2Monitor Unit
User Manual
Screws
Features at a Glance
CO2controller; Tracer
Built-in Day/Night detect sensor
Chart with variable time Zoom Levels
2-Channel Low Drift NDIR Sensor
Foolproof “Hold Home”function
Operating Instructions
Initial Setup: When first unboxing, plug the piggyback into the power socket. If
successfully connected, 3 things will happen while booting up:
Buzzer beep one time
Chart display shows the current software version & “Warm Up”
Main display shows a countdown from 10
Once the countdown is complete, your product is ready to use. No initial setup or
calibration is needed.
1. Controller working graphic
www.iCeeO2.com 3 iCeeO2-C30_US_009.UserMan.docx
LCD Display
1. CO2Chart
2. Max Reading of Chart
3. Min Reading of Chart
4. Audible Alarm On/Off
5. CO2Zone value
6. CO2Center value
7. CO2Reading
8. Zoom Level of Time –indicates
the chart’s span of time
9. Target Zone Indicator
CO2 , Set center, Set zone Readings
The device has three built-in main parameters: ambient carbon dioxide(7), Set
Center value (6), and Set Zone value(5). They are constantly displayed on screen.
www.iCeeO2.com 4 iCeeO2-C30_US_009.UserMan.docx
Trend Chart Zoom
Below is a table that show the available Zoom Levels for all parameters CO2, as well
as the duration of each division for corresponding Zoom Levels:
Using DOWN will toggle the available Zoom Levels for each parameters. Note that in
addition to the Zoom Levels for each parameter, there is an option that will
automatically cycle between the Zoom Levels. This can be achieved just by pressing
DOWN until icon(8) appears at the bottom left of the chart.
Max/Min
At the top right corner of the display, there are two numerical indicators: Max (2)and
Min (3). As the Zoom Level is changed, the Max and Min values will reflect the
maximum and minimum values on the chart of the selected parameter. At startup,
the unit will automatically display values for 1d (day) value.
Auto Detect Day/Night
The built-in Photo-Cell sensor can automatically detect whether it is Day or Night. It
can override the CO2control and shut off the CO2generator by turning off the
output power during the night. Conversely, if the Photo-Cell detects light and the
CO2level is low, the device will start the CO2generator by turning on output power.
Output Control
Output power is on when CO2 concentration is over Set Center+(1/2) Set zone, and off
when CO2concentration is below Set Center-(1/2) Set zone. For example, if the Set
Center is 1200ppm, and the Set zone is 400ppm, the output power will shut off when
CO2over 1200+(1/2)*(400)=1400ppm, and power on when CO2below 1200-
(1/2)*(400)=1000ppm.
Zoom Level
(Time Span) (8)
Time Per
Division
1m (minute)
5sec /div
1h (hour)
5m/div
1d (day)
2h/div
1w (week)
0.5d/div
Auto Cycle Zoom
Cycle
www.iCeeO2.com 5 iCeeO2-C30_US_009.UserMan.docx
LED Display
Main Menu Functions
The Main Menu functions can be toggled through by using MENU. If the main menu
is not selected, the menu LED will remain off, leaving the UP buttons to toggle
Zoom Levels, respectively.
Pressing MENU once will bring up the menu LED, with flashing before the current
choice.
To select the function, press ENTER when menu selection LED flashing. Note that
after 1 minute if nothing is pressed, the Main Menu LED will off and the device will
revert to the normal state.
HOLD HOME
To revert to start up settings at any point, hold ENTER for 3 sec until an audible
beep. The device will revert to Home Setting, as if the power was reset, displaying
“Back Home done.” Note that this is not the same as Restore to factory settings.
Below is a table showing what main menu selection is made by pressing MENU
multiple times as well as their functions. Note that the device will display “Done,”
followed by the confirmed selection if selected correctly.
Function
Directions
S1 Set Center
By default , the Set Center value is 1200ppm for general plant,
Once Set Center is selected (by pressing ENTER), use either UP or
DOWN to toggle the center value. Press ENTER one more time to
confirm.
S2 Set
Zone(Deadband)
This function allows the user to setting Zone(Deadband). Once
selected, Use UP and DOWN to toggle to the set zone value. Press
ENTER to confirm. Note that the default value of set zone is
400ppm.
S3 Home(For
This function for Home plant(General plant), Once selected, the Set
Center value is fixed 1200ppm, and Set Zone value is fixed 400ppm.
www.iCeeO2.com 6 iCeeO2-C30_US_009.UserMan.docx
General Plant)
S4 Re-Calibrate
Use this function to calibrate your device with outside atmospheric
CO2level ~ 400ppm. Select this mode, hold ENTER for 3 seconds
until a beep and the chart will read “Calibrating”, then place the
device outside for 20min. To escape, press MENU. Make sure the
device is far from a source of CO2, not in direct sunlight, and not
exposed to water.
S5 Advance
Setting
This function toggles between 3 things when selected: changing the
alarm function for buzzer beep or Altitude setting or Restore factory
setting.
Restore factory setting will reset the device to factory settings and
erase all stored data in the chart. To use Restore mode, hold ENTER
for 3 seconds until an audible beep.
Specifications
Typical test conditions, unless otherwise specified: Ambient Temp =23+/-3°C,
RH=50%-70%, Altitude=0~100 meter
Measurement
Spec
Operating Temperature
32°F to 122°F (0°C to 50°C)
Storage Temperature
-4°F to 140°F (-20°C to 60°C)
Operating & Storage RH
0-95%, non-condensing
CO2Measurement
Accuracy at 0~3000ppm
±50ppm or ±5% of reading, whichever is greater
Accuracy over 3000ppm
±7%
Repeatability
20ppm at 400ppm (standard dev. of 10 readings in 1 minute)
Measurement Range
0-5000ppm
Display Resolution
1ppm (0-1000); 5ppm (1000-2000); 10ppm (>2000)
Temp Dependence
±0.2% of reading per °C or ±2ppm per °C,
whichever is greater, referenced to 25°C
Pressure Dependence
0.13% of reading per mmHg (corrected by user’s
altitude input)
Response Time
<2min for 63% of step change or <4.6min for 90%
step change
Warm-up Time
<30 sec
Power input
AC 100 ~ 240 VAC
Dimension
Sensor Unit: 153*33*27mm (6.0*1.3*1.1inch)
Control Unit: 195*145*44mm195 (7.7*5.7*1.7inch)
Weight
700g ( 24.7oz)
www.iCeeO2.com 7 iCeeO2-C30_US_009.UserMan.docx
Rear View:
Disclaimers:
This device is not intended for workplace hazard CO2monitoring, nor intended as a definitive monitor for
human or animal health institutions, life sustenance, or any medical-related situation.
iCeeO2and the manufacturer assumes no responsibility for any damage or loss suffered by the user or any
third party arising through the use of this product or its malfunction.
iCeeO2reserve the right to change the specifications without notice.
*** *
