ICM Controls SimpleComfort PRO SC5812 User manual

3-STAGE HEAT/2-STAGE COOL OR HEAT PUMP 7-Day, 5-2-Day & 5-1-1-Day
Programmable
R C W1/O/B Y1 W3GY2W2 S1 S2
• 3-stage heat/2-stage cool
• Single or dual compressor heat pump
• New ICM patented Thermal Intrusion
Barrier
• New ICM patent-pending SimpleSet™
Target Programming technology
• Large display with backlight
• Permanent memory
• Accuracy: ±1°F, ±0.5°C
• Programmable fan mode
• Manual or auto changeover
• Field adjustable calibration
• Hardwired
• Dual fuel compatible
• Extra comfort and energy savings
modes between stages
• Adjustable maximum heat/minimum
cool setpoints
• Adjustable temperature differentials
• Configurable remote sensor compatible
• Selectable °F or °C
• Keypad lockout
• Soft touch controls
• Status LEDs
Simplicity is in its name. ICM’s SimpleComfort®PRO series thermostats feature innovation and
technology that provides programming simplicity with precise control for year-round comfort and energy
savings. Our patented Thermal Intrusion Barrier and patent-pending SimpleSet™ Target Programming set
new industry standards in thermostat technology and are exclusive to each PRO series model.

Specifications subject to change without notice.
1-800-365-5525
www.icmcontrols.com
Specications
Electrical Rating:
• 24 VAC (18-30 VAC)
• 1 amp maximum per terminal
• 3 amp maximum total load
• Easy access terminal block
Temperature Control Ranges:
• 45°F to 90°F, Accuracy: ±1°F
• 7°C to 32°C, Accuracy: ±.5°C
System Configurations:
• 3-stage heat/ 2-stage cool
• Single or dual compressor heat
pump
Terminations:
• SC5812: R, C, W1/O/B, Y1, W2,
Y2, G, W3, S1, S2
• 3-stage heat/ 2-stage cool
• Single or dual compressor heat
pump
• Large display with backlight
• Field temperature calibration
• Dual fuel compatible
Dimensions
Thermal
Intrusion
Barrier
Patent No. Design: 424,953
Patent No. Thermal Intrusion Barrier: 6,597,275
Patent Pending SimpleSetTM Target Programming
Need to monitor the temperature
away from the thermostat?
Choose an ICM remote sensor.
The fast, easy solution
for temperature
sensing problems.
• For tamper prone areas
• Poor airflow areas
• Troubled applications
• Foam gasket prevents
drafts through
wall opening
• Mounts to standard
2” x 4” outlet box
• ACC-RT103 — 2 3/4” x 4 1/2”
Exclusive,
patented insulation
technology
eliminates thermal
drift caused by
wall effect.
NEW
Thermal
Intrusion
Barrier
Patent-pending technology lets you transfer
the program and configuration from one
thermostat to another in seconds.
NEW SimpleSetTM Target
Programming
1.12 " 5.50 "
3.25 "
1.68 "
3.75 "
LIS176
Programmable 7-Day, 5-2-Day & 5-1-1-Day
3-Stage Heat/2-Stage Cool or Heat Pump
Hardwired
