ICON Cube6nano-VST User manual

User manual
4-In / 4-Out with +48V Phantom Power Recording USB Interface

Important Safety Instructions
1. Read this manual thoroughly before using this unit.
2. Keep this manual for future reference.
3. Take notice of and comply with all warnings included in the user's manual or indicated on the
appliance.
4. Follow all instructions included in this manual.
5. Do not expose this unit to rain or moisture. Avoid having water or other liquids spilled on this
unit.
6. When cleaning the cabinet or other parts of this appliance, use only a dry or slightly damp soft
cloth.
7. Do not block any ventilation openings or interfere with the proper ventilation of this unit. Install
in accordance with the manufacturer's instructions.
8. Do not use or store near any heat sources such as radiators, heat registers, stoves, or other heat-
producing appliances.
9. Do not interfere with the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding-type plug has two blades and a third
grounding prong. These are designated for your safety. If the provided plug does not fit into your
outlet, consult an electrician.
10. Protect the power cord from being walked on or otherwise damaged by items placed on or
against them. Particular attention should be given to the plugs, receptacles, and the point where
the cord exits the appliance.
11. To avoid the risk of electrical shock, do not touch any exposed wiring while the unit is in
operation.
12. Only use attachments/accessories specified by the manufacturer.
13. Unplug this unit and all connected electrical equipment during lightning storms or when left
unused a long period of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the appliance has
been damaged in any way or fails to operate normally.
WARNING: To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture

Introduction...............................................................................................4
What’s in the package? ............................................................................4
Features ...................................................................................................5
Front Panel ..............................................................................................6
Rear Panel................................................................................................7
Mac driver installation...............................................................................8
Mixer control panel .................................................................................10
Windows driver installation..................................................................... 11
ProDriver VST ........................................................................................14
Mixer control panel .................................................................................15
Settings (Sample rate and latency settings)...........................................17
ProDriver VST hosting rack....................................................................21
Hardware Connections...........................................................................22
Specications .........................................................................................23
Services..................................................................................................24
Contents

4
Introduction
What’s in the package?
Thank you for purchasing the ICON Cube6Nano-VST digital audio Interface. We
sincerely trust this product will provide years of satisfactory service, but if anything is
not to your complete satisfaction, we will endeavor to make things right.
In these pages, you'll nd a detailed description of the features of the Cube6Nano-
VST digital audio interface, as well as a guided tour through its front and rear panels,
step-by-step instructions for its setup and use, and full specications.
You'll also nd a warranty card enclosed---please don't forget to ll it out and mail
it in, or register your product online at: www.iconproaudio.com, for the most
effective technical support, and so we can send you updated information about this
and other ICON products in the future. As with most electronic devices, we strongly
recommend you retain the original packaging. In the unlikely event the product
must be returned for servicing, the original packaging (or reasonable equivalent) is
required.
With proper care and adequate air circulation, your Cube6Nano-VST digital audio
interface will operate without any trouble for many years. We recommend that you
record your serial number in the space provided below for future reference.
Please write your serial number here for future reference:
Purchased at:
Date of purchase:
●Cube6Nano-VST USB Recording Interface
●Quick Start Guide x 1
●Driver Software CD with Electronic user manual & quick start guide (pdf)
●DAW software – Reaper & KiloHearts VST
●USB 2.0 cable x 1

5
Features
The ICON Cube6Nano-VST USB recording interface provides an audio input and
output module with USB connectivity. Main features include:
●24-Bit 192KHz 4-In/4-Out USB Recording Interface
●High dynamic range:
DAC: Dynamic Range: 114dB
ADC: Dynamic Range: 114dB
●4x4 analog I/O full duplex recording and playback
●Dual Mic/Instrument preamps with individual gain control and phantom power switch
●2 analog inputs on 1/4” TRS jacks
●4 analog outputs on 1/4” TRS jacks
●S/PDIF I/O on RCA coaxial connectors
●1 x 1 – 16 channel MIDI I/O
●Master volume control on the front panel
●Direct monitor knob control on the top panel
●1 headphone output with assignable source and individual volume control
●Flexible channel routing via the software control panel
●ICON's innovative ProDriverVST™ VST plug-ins hosting rack is provided
●Kilohearts VST plug-ins are provided
●USB2.0 High Speed equipped and USB bus-powered
●Supports DirectSound, WDM and ASIO2.0
●Compatible with Mac OS (Intel-Mac) 10.11 and later, iOS 9 or above and Windows 7,
8 & 10 (32-bit/64-bit)
●Full duplex, simultaneous record/playback
●+12VDC power supply connector is equipped for external power supply when using
with iOS
●Rugged aluminum construction

6
Front Panel
31
24 8 7
56
1. “Mic/Inst” inputs 1/2
Unbalanced instrument and mic level inputs. These hybrid connectors will accept
a standard 3-pin XLR plug or a 1/4” TS connector.
2. 48V phantom power switch
Press to supply +48V phantom power to the associated XLR input. This phantom
power circuit is suitable for most condenser microphones.
3. Input gain level controls 1/2
These potentiometers control the input level of their associated analog Mic/Inst/
Line input.
4. Direct monitoring control knob
This potentiometer controls the audio signal ow of the PC output and the actual
analog inputs.
Comp (Anticlockwise) Only PC audio signal will be monitored
Direct Out (Clockwise) Only analog inputs (Mic/Inst 1&2) will be
monitored
Mix (Centre) Both PC & analog inputs audio signal will be
monitored
5. HP Monitor 1 output
This output jack accepts a standard 1/4" stereo TRS headphone connector.
6. HP Monitor 1 volume control
This potentiometer controls the output level of HP Monitor 1.
7. HP Monitor 2 output
This output jack accepts a standard 1/4" stereo TRS headphone connector.
8. HP Monitor 2 volume control
This potentiometer controls the output level of HP Monitor 2.

7
Rear Panel
3
2
3146
5
1. USB 2.0 Connector
Connect it with the provided USB cable to your Mac/PC’s USB connector.
Your Mac/PC must have a USB2.0 connector in order to run the full speed of
Cube6Nano-VST.
2. Line inputs 3/4
These are unbalanced analog inputs on standard 1/4″ TS connectors at
–10dB line level.
3. Line outputs 1-4
These are unbalanced analog outputs on standard 1/4″ TS connectors at
+6dBU line level.
4. S/PDIF coaxial I/O connectors
S/PDIF digital input and output on coaxial RCA connectors. The digital input
is selected via the Cube6Nano-VST's software control panel, while the digital
output will be sent to the coaxial.
5. MIDI I/O connectors
MIDI input and output on standard 5-pin DIN connectors
6. 12V/1A power adaptor
Connect the provided power adaptor here.
Note: Cube6Nano-VST is not able to work without the provided power
adaptor connected. The USB bus power is not able to provide sufcient power
supply for Cube6Nano-VST.

8
Mac driver installation
Cube6Nano-VST is a class compliant device. Thus there is no driver installation
needed for Mac. Also, it fully supports iOS devices by connecting the unit to a
camera kit.
Please follow the step-by-step procedures below to install your Cube6Nano-VST
USB recording interface.
1. Turn on your Mac
(Note: Do not connect the Cube6Nano-VST digital audio interface to your Mac
yet.)
2. Class compliant device
Cube6Nano-VST is class compliant on macOS, so no driver installation is
needed.
3. Copy the software control panel shortcut logo to your
desktop
Open the previous “Mac” folder. Copy the “ProDriver VST” software panel
shortcut logo and paste it to your desktop.
4. Launch the software control
panel
Click the Cube6Nano-VST’s software
control panel shortcut logo you have
just copied to your desktop to launch
the software control panel.
Diagram 1
Mac
Diagram 2

9
5. Connect your Cube6Nano-
VST digital audio interface
Now connect the Cube6Nano-VST
digital audio interface to your Mac's
USB port.
Note: Cube6Nano-VST audio interface
only support USB2.0. Your Mac must
have a USB2.0 port.
Diagram 4
Cube6 Nano VST (Core Audio) Cube6 Nano VST: Output
Cube6 Nano VST (Core Audio)
Cube4 Nano VST (Bit Accurate)
6. Audio MIDI setup
Open the “Audio MIDI setup”
window and conrm that the
Cube6Nano-VST device has
been setup properly as shown in
diagram 4.
Diagram 3
Cube6 Nano VST
13
13
14 15
USB
Esc
F1 F2 F3 F4
F5
F6
F7 F8 F9 F10 F11 F12
Prtsc
sysrq
pause
Break
Lns
Del
Home
Pgup
PgDN
End
$
~
`
!
1
··
23456778 90
)
)
*—
-
+
=
#¥%
*
##
QWERTYUIOP{}|
ASDFGHJKL:
;
ZXCVBNM<>?
Tab
CapsLook
Shift
Ctrl Alt AltGr Ctrl
Backspace
[
]
|
Enter
Shift
intel
USB
Mac

10
Diagram 5
1. HW Input 1/2 level metering
Shows the hardware 1/2 input level. (HW In 1/2).
2. HW Output 1/2 level metering
Shows the hardware 1/2 output level.(HW Out 1/2).
3. HW Input 3/4 level metering
Shows the hardware 3/4 input level. (HW In 3/4).
4. HW Output 3/4 level metering
Shows the hardware 3/4 output level.(HW Out 3/4).
5. S/PDIF In 1/2
Shows the S/PDIF 3/4 input level (S/PDIF In 3/4).
6. S/PDIF Out 1/2
Shows the S/PDIF 3/4 output level (S/PDIF Out 3/4).
7. Link switch
Switch to adjust both channels' levels simultaneously.
8. Mute switch
Switch to mute the corresponding channel.
9. “0dB” switch
Switch to instantly adjust the corresponding channel to “0dB” level.
10. Gain control fader
Slide to adjust the gain level for the corresponding channel.
11. Inputs & Outputs Matrix switches
Switch to turn On/Off the corresponding input channel route to the corresponding
output channel. Remember you may route any input(s) to any output(s)
.
Mixer control panel
The mixers work like a matrix mixer. Activate and adjust the corresponding input or output
channel level. They are very useful and make your inputs and outputs very exible. You may
route any of your input(s) to any output(s).
6
7
8
9
2
1
10
11
3
5
4
Cube6Nano VST

11
Diagram 6
Diagram 8
Diagram 7
Windows driver installation
Please follow the step-by-step procedures below to install your Cube6Nano-VST
USB recording interface and its driver.
1. Turn on your computer
Note: Do not connect the Cube6Nano-VST digital audio interface to your
computer yet.
2. Insert the Driver CD into your CD-Rom.
After you have inserted the provided Driver CD into your CD-Rom, an Installation
screen should appear as shown in Diagram 6, then click "Windows” for the driver
installation".
Note: If the Installation screen does not appear automatically. Go to the CD
folder and double click "Setup" .
3. Installation Wizard appears
Choose "Next" when you see the Welcome
Screen shown in Diagram 7.
4. License Agreement
Click “I Agree” to proceed.

12
Cube6Nano VST Device Drivers
Icon_Cube6NanoVST_2.9.86.50.exe
Diagram 9
Diagram 10
5. Select components for installation
Check mark the components that you would
like to install. We strongly recommend that
you select all components.
6. Preparing installation les
Once the installation process has started,
the process may take some time depending
on your computer performance. Please be
patient and wait for the process to nish.
7. Click “Install” to proceed.
Note: The same message will appear three
times as there are three different driver
installations.
Diagram 11
Diagram 12
Diagram 13

13
8. Setup completed
A window as shown in Diagram 14
should appear. Choose "Finish”.
Diagram 14
9. Launch the software
control panel
You may click the ICON ProAudio
logo on the system tray to launch
the software control panel (Page
15).
10. Connect your
Cube6Nano-VST digital
audio interface
Now connect the Cube6Nano-
VST digital audio interface to
your computer's USB port.
Cube6 Nano VST
13
13
14 15
USB
Esc
F1 F2 F3 F4
F5
F6
F7 F8 F9 F10 F11 F12
Prtsc
sysrq
pause
Break
Lns
Del
Home
Pgup
PgDN
End
$
~
`
!
1
··
23456778 90
)
)
*—
-
+
=
#¥%
*
##
QWERTYUIOP{}|
ASDFGHJKL:
;
ZXCVBNM<>?
Tab
CapsLook
Shift
Ctrl Alt AltGr Ctrl
Backspace
[
]
|
Enter
Shift
intel
USB
Mac
Diagram 16
16
14
Mac
Diagram 15

14
Diagram 17
Diagram 18
ProDriver VST
The Cube6Nano-VST comes equipped with ProDriver VST - our innovative VST
rack, plug-in host, and virtual signal router. ProDriver VST runs either in standalone
mode or with your favorite digital audio workstation (DAW). Pull up your guitar
modeling VST and play, or plug in your midi controller and control your favorite virtual
instruments without running through your digital audio workstation.

15
1. Cube6Nano-VST Hardware channels (HW In 1/2, 3/4 & HW Out
1/2, 3/4)
These are the hardware input and output channels on Cube6Nano-VST.
2. Cube6Nano-VST S/PDIF channels (S/PDIF In 1/2 & S/PDIF Out 1/2)
These are the S/PDIF input and output channels on Cube6Nano-VST.
3. Cube6Nano-VST Virtual channels (VC In 1/2, 3/4 and 5/6), (VC
Out 1/2, 3/4 and 5/6)
These are the input and output virtual channels that related to the WDM.
For example: WDM Out 1/2 linked to VC In1/2
VC Out1/2 linked to WDM In1/2
4. Cube6Nano-VST Loopback channels (LB 1/2, 3/4 and 5/6)
These are the ASIO loop-back channels.
Mixer control panel
On the mixer control panel, there are four different main types of ASIO channels that
you can manipulate.
Diagram 19
20
18
2
144 131211106
19
17
16
15
7
8
5
13
9
14
15
3
1
1. HW Input 1/2 level metering
Shows the hardware 1/2 input level (HW In 1/2).
2. HW Output 1/2 level metering
Shows the hardware 1/2 output level (HW Out 1/2).
By activating different cross points, you may route the corresponding signal to your
desired channels.

16
3. HW Input 3/4 level metering
Shows the hardware 3/4 input level (HW In 3/4).
4. HW Output 3/4 level metering
Shows the hardware 3/4 output level (HW Out 3/4).
5. S/PDIF Input 1/2 level metering
Shows the S/PDIF 1/2 input level. (S/PDIF In 1/2).
6. S/PDIF Output 1/2 level metering
Shows the S/PDIF 1/2 output level. (S/PDIF Out 1/2)
7. VC In 1/2 (Virtual) input level metering
Shows the WDM 1/2 output level (VC In 1/2).
8. VC In 3/4 (Virtual) input level metering
Shows the WDM 3/4 output level (VC In 3/4).
9. VC In 5/6 (Virtual) input level metering
Shows the WDM 5/6 output level (VC In 5/6).
10. VC Out 1/2 (Virtual) output level metering
Shows the ASIO 1/2 VC output level (VC Out 1/2).
11. VC Out 3/4 (Virtual) output level metering
Shows the ASIO 3/4 VC output level (VC Out 3/4).
12. VC Out 5/6 (Virtual) output level metering
Shows the ASIO 5/6 VC output level (VC Out 5/6).
13. Loopback 1/2
Shows the ASIO loop-back 1/2 channel’s level metering.
14. Loopback 3/4
Shows the ASIO loop-back 3/4 channel’s level metering.
15. Loopback 5/6
Shows the ASIO loop-back 5/6 channel’s level metering.
16. Link switch
Switch to adjust both channels level simultaneously.
17. Mute switch
Switch to mute the corresponding channel.
18. “0dB” switch
Switch to instantly adjust the corresponding channel to “0dB” level.
19. Gain control fader
Slide to adjust the gain level for the corresponding channel.
20. Inputs & Outputs Matrix switches
Switch to turn On/Off the corresponding input channel route to the corresponding
output channel. The matrix is very useful and makes your inputs and outputs
very exible. You may route any of your input(s) to any output(s).

17
Click the “Setting” button to launch the settings window.
Sample rate setting
Select your desired sampling rate from 44.1KHz to 192KHz on the pull down
window shown in Diagram 21.
Settings (Sample rate and latency settings)
Diagram 20
Diagram 21

18
Latency settings
Diagram 22
●Safe (maximum latency)
●Extra Large
●Normal
●Small
●Very Small
●Minimum (minimum latency)
●Custom
There are six standard latency settings to select. If you would like to customize
your own latency value, select custom.

19
Diagram 23
Diagram 24
There are three different settings you can adjust to customize your own latency
settings: These values include:
1. ASIO buffer Size
You may adjust the value ranging from 32/64/128/256/512/1024/2048 and 4096.
2. Streaming buffer Size
Adjustable settings: Minimum/Low/Normal/High and Maximum.

20
Diagram 25
Diagram 26
3. Streaming buffer volume
Adjustable values: 2/3 and 4.
(Note: If a warning message appears on the “Latency Status” windows, please
select a larger latency setting.)
(Note: If a clicking sound occurs, you should change to a larger buffer size
for the settings. If the largest buffer size has been selected and there is still a
clicking sound. It means your computer performance is not able to handle the
task. (It is not caused by Cube6Nano-VST digital audio interface.)
Table of contents
Other ICON USB Interface manuals
