ICP DAS USA FSM-510G series User manual

FSM-510G Series
10-Port Managed Industrial Ethernet Switch
Web Configuration ool Guide
Version Number:
Issue: 1.1R01, December 2014

2
[CONTENTS]
1. Introductions..............................................................................................................9
1.1 System Description ..................................................................................................9
1.2 Using the Web Interface ..........................................................................................9
1.2.1 Web Browser Support..............................................................................................9
1.2.2 Na igation ..............................................................................................................10
1.2.3 Title Bar Icons ........................................................................................................10
1.2.4 Ending a Session ....................................................................................................11
1.3 Using the Online Help............................................................................................11
2. Using the Web..........................................................................................................12
2.1 Login.......................................................................................................................12
2.2 Tree View ...............................................................................................................13
2.2.1 Configuration Menu...............................................................................................13
2.2.2 Monitor Menu .......................................................................................................14
2.2.3 Diagnostics Menu ..................................................................................................15
2.2.4 Maintenance Menu ...............................................................................................15
2.3 Configuration .........................................................................................................16
2.3.1 System....................................................................................................................16
2.3.2 System Information................................................................................................16
2.3.3 System IP................................................................................................................17
2.3.4 System NTP ............................................................................................................20
2.3.5 System Time...........................................................................................................21
2.3.6 System Log .............................................................................................................23
2.3.7 Green Ethernet ......................................................................................................24
2.3.8 Port Power Sa ings ................................................................................................24
2.3.9 Port ........................................................................................................................26
2.3.10 DHCP ......................................................................................................................28
2.3.11 DHCP Ser er...........................................................................................................28
2.3.12 DHCP Ser er Mode ................................................................................................28
2.3.13 DHCP Ser er Excluded IP .......................................................................................30
2.3.14 DHCP Ser er Pool...................................................................................................31
2.3.15 DHCP Snooping ......................................................................................................32
2.3.16 DHCP Relay.............................................................................................................33
2.3.17 Security ..................................................................................................................35
2.3.18 Switch.....................................................................................................................35
2.3.19 Users ......................................................................................................................35

Contents
3
2.3.20 Pri ilege Le el ........................................................................................................37
2.3.21 Auth Method .........................................................................................................39
2.3.22 SSH .........................................................................................................................40
2.3.23 HTTPS.....................................................................................................................41
2.3.24 Access Management..............................................................................................42
2.3.25 SNMP .....................................................................................................................43
2.3.26 SNMP System Configuration..................................................................................43
2.3.27 SNMP Trap Configuration ......................................................................................45
2.3.28 SNMP Communities...............................................................................................49
2.3.29 SNMP Users ...........................................................................................................50
2.3.30 SNMP Groups.........................................................................................................52
2.3.31 SNMP Views...........................................................................................................53
2.3.32 Access Views..........................................................................................................54
2.3.33 RMON ....................................................................................................................56
2.3.34 RMON Statistics .....................................................................................................56
2.3.35 RMON History........................................................................................................57
2.3.36 RMON Alarm..........................................................................................................58
2.3.37 RMON E ent...........................................................................................................60
2.3.38 Network .................................................................................................................61
2.3.39 Limit Control ..........................................................................................................61
2.3.40 NAS.........................................................................................................................64
Force Authorized ..........................................................................................................................67
Force Unauthorized......................................................................................................................67
Port-based 802.1X ........................................................................................................................67
Single 802.1X 68
Multi 802.1X 68
MAC-based Auth. .........................................................................................................................69
2.3.41 ACL .........................................................................................................................73
2.3.42 ACL Port .................................................................................................................73
2.3.43 ACL Rate Limiters ...................................................................................................75
2.3.44 Access Control List .................................................................................................77
2.3.45 IP Source Guard .....................................................................................................88
2.3.46 IP Source Guard Configuration ..............................................................................88
2.3.47 IP Source Guard Static Table ..................................................................................90
2.3.48 ARP Inspection.......................................................................................................91
2.3.49 Port Configuration .................................................................................................91
2.3.50 VLAN Configuration ...............................................................................................93
2.3.51 Static Table.............................................................................................................94

4
2.3.52 Dynamic Table........................................................................................................95
2.3.53 AAA ........................................................................................................................97
2.3.54 RADIUS ...................................................................................................................97
2.3.55 TACACS+ .................................................................................................................99
2.3.56 Aggregation..........................................................................................................101
2.3.57 Static Aggregation................................................................................................101
2.3.58 LACP Aggregation ................................................................................................103
2.3.59 Loop Protection ...................................................................................................105
2.3.60 Spanning Tree ......................................................................................................107
2.3.61 Bridge Settings .....................................................................................................107
2.3.62 MSTI Mapping......................................................................................................109
2.3.63 MSTI Priorities......................................................................................................111
2.3.64 CIST Ports .............................................................................................................112
2.3.65 MSTI Ports............................................................................................................114
2.3.66 IPMC Profile .........................................................................................................116
2.3.67 Profile Table .........................................................................................................116
2.3.68 Address Entry.......................................................................................................118
2.3.69 MVR .....................................................................................................................119
2.3.70 IPMC.....................................................................................................................122
2.3.71 IGMP Snooping ....................................................................................................122
2.3.72 Basic Configuration ..............................................................................................122
2.3.73 VLAN Configuration .............................................................................................124
2.3.74 Port Filtering Profile.............................................................................................126
2.3.75 MLD Snooping......................................................................................................127
2.3.76 Basic Configuration ..............................................................................................127
2.3.77 VLAN Configuration .............................................................................................129
2.3.78 Port Filtering Profile.............................................................................................131
2.3.79 LLDP .....................................................................................................................132
2.3.80 LLDP .....................................................................................................................132
2.3.81 LLDP-MED ............................................................................................................135
2.3.82 MAC Table ............................................................................................................141
2.3.83 VLANs...................................................................................................................143
2.3.84 Pri ate VLANs.......................................................................................................147
2.3.85 Membership.........................................................................................................147
2.3.86 Port Isolation........................................................................................................149
2.3.87 VCL .......................................................................................................................150
2.3.88 MAC-based VLAN.................................................................................................150
2.3.89 Protocol-based VLAN ...........................................................................................152

Contents
5
2.3.90 Protocol to Group ................................................................................................152
2.3.91 Group to VLAN .....................................................................................................154
2.3.92 IP Subnet-based VLAN .........................................................................................156
2.3.93 Voice VLAN...........................................................................................................157
2.3.94 Voice VLAN Configuration....................................................................................157
2.3.95 Voice VLAN OUI ...................................................................................................159
2.3.96 QoS.......................................................................................................................160
2.3.97 Port Classification ................................................................................................160
2.3.98 Port Policing .........................................................................................................163
2.3.99 Port Scheduler .....................................................................................................165
2.3.100 Port Shaping.........................................................................................................166
2.3.101 Port Tag Remarking..............................................................................................167
2.3.102 Port DSCP .............................................................................................................168
2.3.103 DSCP-Based QoS ..................................................................................................170
2.3.104 DSCP Translation ..................................................................................................172
2.3.105 DSCP Classification...............................................................................................174
2.3.106 QoS Control List ...................................................................................................175
2.3.107 Storm Control.......................................................................................................179
2.3.108 Mirror...................................................................................................................180
2.3.109 GVRP ....................................................................................................................182
2.3.110 Global Config........................................................................................................182
2.3.111 Global Config........................................................................................................183
2.3.112 sFlow ....................................................................................................................184
2.3.113 RingV2..................................................................................................................187
2.4 Monitor................................................................................................................190
2.4.1 System..................................................................................................................190
2.4.2 System Information..............................................................................................190
2.4.3 CPU Load..............................................................................................................191
2.4.4 IP Status ...............................................................................................................192
2.4.5 System Log ...........................................................................................................193
2.4.6 System Detailed Log.............................................................................................195
2.4.7 Green Ethernet ....................................................................................................196
2.4.8 Port Power Sa ing ................................................................................................196
2.4.9 Ports.....................................................................................................................197
2.4.10 Ports State............................................................................................................197
2.4.11 Trafice O er iew ..................................................................................................198
2.4.12 QoS Statistics .......................................................................................................199
2.4.13 QCL Status............................................................................................................200

6
2.4.14 Detailed Statistics.................................................................................................202
2.4.15 DHCP ....................................................................................................................205
2.4.16 DHCP Ser er.........................................................................................................205
2.4.17 Statistics ...............................................................................................................205
2.4.18 Binding .................................................................................................................207
2.4.19 Declined IP ...........................................................................................................208
2.4.20 DHCP Snooping Table...........................................................................................209
2.4.21 DHCP Relay Statistics ...........................................................................................211
2.4.22 DHCP Detailed Statistics ......................................................................................213
2.4.23 Security ................................................................................................................215
2.4.24 Accessment Management Statistics ....................................................................215
2.4.25 Network ...............................................................................................................216
2.4.26 Port Security ........................................................................................................216
2.4.27 Switch...................................................................................................................216
2.4.28 Port ......................................................................................................................218
2.4.29 NAS.......................................................................................................................219
2.4.30 Switch...................................................................................................................219
2.4.31 Port ......................................................................................................................221
2.4.32 ACL Status ............................................................................................................224
2.4.33 ARP Inspection.....................................................................................................226
2.4.34 IP Source Guard ...................................................................................................228
2.4.35 AAA ......................................................................................................................230
2.4.36 RADIUS O er iew.................................................................................................230
2.4.37 RADIUS Details.....................................................................................................232
2.4.38 Switch...................................................................................................................233
2.4.39 RMON ..................................................................................................................233
2.4.40 Statistics ...............................................................................................................233
2.4.41 History..................................................................................................................235
2.4.42 Alarm....................................................................................................................237
2.4.43 E ent ....................................................................................................................238
2.4.44 LACP .....................................................................................................................239
2.4.45 System Status.......................................................................................................239
2.4.46 Port Status............................................................................................................240
2.4.47 Port Statistics .......................................................................................................241
2.4.48 Loop Protection ...................................................................................................242
2.4.49 Spanning Tree ......................................................................................................243
2.4.50 Bridge Status........................................................................................................243
2.4.51 Port Status............................................................................................................244

Contents
7
2.4.52 Port Statistics .......................................................................................................245
2.4.53 MVR .....................................................................................................................246
2.4.54 MVR Statistics ......................................................................................................246
2.4.55 MVR Channel Groups...........................................................................................247
2.4.56 MVR SFM Information .........................................................................................249
2.4.57 IPMC.....................................................................................................................251
2.4.58 IGMP Snooping ....................................................................................................251
2.4.59 IGMP Snooping Status .........................................................................................251
2.4.60 Groups Information .............................................................................................253
2.4.61 IP 4 SFM Information ..........................................................................................255
2.4.62 MLD Snooping......................................................................................................257
2.4.63 MLD Snooping Status...........................................................................................257
2.4.64 Groups Information .............................................................................................259
2.4.65 IP 6 SFM Information ..........................................................................................261
2.4.66 LLDP .....................................................................................................................263
2.4.67 Neighbors.............................................................................................................263
2.4.68 LLDP-MED Neighbors...........................................................................................265
2.4.69 EEE .......................................................................................................................270
2.4.70 Port Statistics .......................................................................................................272
2.4.71 MAC Table ............................................................................................................274
2.4.72 VLANs...................................................................................................................276
2.4.73 VLANs Membership .............................................................................................276
2.4.74 VLANs Ports .........................................................................................................278
2.4.75 VCL .......................................................................................................................280
2.4.76 MAC-Based VLAN.................................................................................................280
2.4.77 sFlow ....................................................................................................................281
2.4.78 RingV2..................................................................................................................282
2.5 Diagnostics...........................................................................................................284
2.5.1 Ping ......................................................................................................................284
2.5.2 Ping6 ....................................................................................................................286
2.5.3 VeriPHY ................................................................................................................288
2.6 Maintenance........................................................................................................290
2.6.1 Restart De ice ......................................................................................................290
2.6.2 Factory Default.....................................................................................................291
2.6.3 Software...............................................................................................................292
2.6.3.1 Software Upload ..................................................................................................292
2.6.3.2 Image select.........................................................................................................293
2.6.4 Configuration .......................................................................................................294

8
2.6.4.1 Sa e startup-config ..............................................................................................294
2.6.4.2 Download.............................................................................................................295
2.6.4.3 Upload..................................................................................................................296
2.6.4.4 Acti ate ................................................................................................................297
2.6.4.5 Delete...................................................................................................................298

Command Descriptions
9
1.1 System Description
FSM-510G industrial Ethernet switch series delivers high quality, wide operating temperature range,
extended power input range, IP-30 design, and advanced VLAN & QoS features. It’s ideal for harsh
environments and mission critical applications.
Managed QoS FSM-510G provides enterprise-class networking features to fulfill the needs of large
network infrastructure and extreme environments.
FSM-510G eases the effort to build a network infrastructure which offers a reliable, well managed
and good QoS networking for any business requiring continuous and well-protected services in
management environments. With the features such as Fast Failover ring protection and QoS,
customers can ensure their network is qualified to deliver any real-time and high quality
applications.
1.2 Using the Web Interface
The object of this document “FSM-510G Web Configuration Tool Guide” is to address the web
feature, design layout and descript how to use the web interface.
1.2.1 Web Browser Support
IE 7 (or newer version) with the following default settings is recommended:
Language script Latin based
Web page font Times New Roman
Plain text font Courier New
Encoding Unicode (UTF-8)
Text size Medium
Firefox with the following default settings is recommended:
Web page font Times New Roman
Encoding Unicode (UTF-8)
Text size 16
Google Chrome with the following default settings is recommended:
1. Introductions

10
Web page font Times New Roman
Encoding Unicode (UTF-8)
Text size Medium
1.2.2 Navigation
All main screens of the web interface can be reached by clicking on hyperlinks in the four menu
boxes on the left side of the screen:
Status - Display statistics, status, and contents of memory.
Configuration - Configure the system, interfaces, and filters.
System - Display system information, download firmware, back up configurations, and modify
users.
You can find the detailed information in section 2.2 Tree View.
1.2.3 Title Bar Icons
Help Button
For more information about any screen, click on the Help button on the screen.
Help information is displayed in the same window.
Save Button

Command Descriptions
11
If any unsaved change has been made to the configuration (by you during this or a prior session, or
by any other administrator using the web interface or the Command Line Interface), a Save icon
appears in the title line. To save the running configuration to the startup configuration:
1. Click on the Save icon. The System/Save and Restore screen appears.
2. Click on Submit next to Data Control Action drop-down list on top of System/Save and
Restore screen.
1.2.4 Ending a Session
To end a session, close your web browser. This prevents an unauthorized user from accessing the
system using your user name and password.
1.3 Using the Online Help
Each screen has a Help button that invokes a page of information relevant to the particular
screen. The Help is displayed in a new window.
Each web page of Configuration/Status/System functions has a corresponding help page.

12
2.1 Login
2. Using the Web
Operation 1. Fill Username and Password
2. Click “Sign in”
Field Description
Username Login user name. The maximum length is 32.
Default: admin
Password Login user password. The maximum length is 32.
Default: none

Command Descriptions
13
2.2 Tree View
The tree view is a menu of the web. It offers user quickly to get the page for expected data or
configuration.
2.2.1 Configuration Menu

14
2.2.2 Monitor Menu

Command Descriptions
15
2.2.3 Diagnostics Menu
2.2.4 Maintenance Menu

16
2.3 Configuration
2.3.1 System
2.3.2 System Information
Object Description
System Contact The textual identification of the contact person for this managed node, together with
information on how to contact this person. The allowed string length is 0 to 255, and
the allowed content is the ASCII characters from 32 to 126.
System Name An administratively assigned name for this managed node. By convention, this is the
node's fully-qualified domain name. A domain name is a text string drawn from the
alphabet (A-Za-z), digits (0-9), minus sign (-). No space characters are permitted as
part of a name. The first character must be an alpha character. And the first or last
character must not be a minus sign. The allowed string length is 0 to 255.
System Location The physical location of this node(e.g., telephone closet, 3rd floor). The allowed string
length is 0 to 255, and the allowed content is the ASCII characters from 32 to 126.
Buttons
Click to save changes.
Click to revert to previously saved values.

Command Descriptions
17
2.3.3 System IP
Object Description
IP Configuration
Mode Configure whether the IP stack should act as a Host or a Router. In Host mode,
IP traffic between interfaces will not be routed. In Router mode traffic is routed
between all interfaces.
DNS Server This setting controls the DNS name resolution done by the switch. The
following modes are supported:
• From any DHCP interfaces
The first DNS server offered from a DHCP lease to a
DHCP-enabled interface will be used.
• No DNS server
No DNS server will be used.
• Configured
Explicitly provide the IP address of the DNS Server in dotted
decimal notation.
• From this DHCP interface
Specify from which DHCP-enabled interface a provided DNS
server should be preferred.

18
DNS Proxy When DNS proxy is enabled, system will relay DNS requests to the currently
configured DNS server, and reply as a DNS resolver to the client devices on the
network.
IP Interfaces
De ete Select this option to delete an existing IP interface.
VLAN The VLAN associated with the IP interface. Only ports in this VLAN will be able to
access the IP interface. This field is only available for input when creating an new
interface.
IPv4 DHCP Enab ed Enable the DHCP client by checking this box. If this option is enabled, the system
will configure the IPv4 address and mask of the interface using the DHCP protocol.
The DHCP client will announce the configured System Name as hostname to
provide DNS lookup.
IPv4 DHCP Fa back Timeout The number of seconds for trying to obtain a DHCP lease. After this period expires,
a configured IPv4 address will be used as IPv4 interface address. A value of zero
disables the fallback mechanism, such that DHCP will keep retrying until a valid
lease is obtained. Legal values are 0 to 4294967295 seconds.
IPv4 DHCP Current Lease For DHCP interfaces with an active lease, this column show the current interface
address, as provided by the DHCP server.
IPv4 Address The IPv4 address of the interface in dotted decimal notation.
If DHCP is enabled, this field configures the fallback address. The field may be left
blank if IPv4 operation on the interface is not desired - or no DHCP fallback address
is desired.
IPv4 Mask The IPv4 network mask, in number of bits (prefix length). Valid values are between 0
and 30 bits for a IPv4 address.
If DHCP is enabled, this field configures the fallback address network mask. The field
may be left blank if IPv4 operation on the interface is not desired - or no DHCP
fallback address is desired.
IPv6 Address The IPv6 address of the interface.A IPv6 address is in 128-bit records represented
as eight fields of up to four hexadecimal digits with a colon separating each field (:).
For example, fe80::215:c5ff:fe03:4dc7. The symbol :: is a special syntax
that can be used as a shorthand way of representing multiple 16-bit groups of
contiguous zeros; but it can appear only once. It can also represent a legally valid
IPv4 address. For example, ::192.1.2.34.
The field may be left blank if IPv6 operation on the interface is not desired.
IPv6 Mask The IPv6 network mask, in number of bits (prefix length). Valid values are between 1
and 128 bits for a IPv6 address.
The field may be left blank if IPv6 operation on the interface is not desired.

Command Descriptions
19
IP Routes
De ete Select this option to delete an existing IP route.
Network The destination IP network or host address of this route. Valid format is dotted
decimal notationor a valid IPv6 notation. A default route can use the value
0.0.0.0or IPv6 :: notation.
Mask Length The destination IP network or host mask, in number of bits (prefix length). It defines
how much of a network address that must match, in order to qualify for this route.
Valid values are between 0 and 32 bits respectively 128 for IPv6 routes. Only a
default route will have a mask length of 0(as it will match anything).
Gateway The IP address of the IP gateway. Valid format is dotted decimal notationor a valid
IPv6 notation. Gateway and Network must be of the same type.
Next Hop VLAN(On y for IPv6) The VLAN ID (VID) of the specific IPv6 interface associated with the gateway.
The given VID ranges from 1 to 4094 and will be effective only when the
corresponding IPv6 interface is valid.
If the IPv6 gateway address is link-local, it must specify the next hop VLAN for the
gateway.
If the IPv6 gateway address is not link-local, system ignores the next hop VLAN for
the gateway.
Buttons
Click to add a new IP interface. A maximum of 8 interfaces is supported.
Click to add a new IP route. A maximum of 32 routes is supported.
Click to save changes.
Click to revert to previously saved values.

20
2.3.4 System NTP
Object Description
Mode Indicates the NTP mode operation. Possible modes are:
Enabled: Enable NTP client mode operation.
Disabled: Disable NTP client mode operation.
Server # Provide the IPv4 or IPv6 address of a NTP server. IPv6 address is in 128-bit records
represented as eight fields of up to four hexadecimal digits with a colon separating
each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The symbol '::' is a special
syntax that can be used as a shorthand way of representing multiple 16-bit groups of
contiguous zeros; but it can appear only once. It can also represent a legally valid
IPv4 address. For example, '::192.1.2.34'.
Buttons
Click to save changes.
Click to undo any changes made locally and revert to previously saved values.
