ICP ICARUS blue User manual
USER MANUAL
The ICP Group (manufacturer of this product) updates the user manual from time to time.
When purchasing the product, the customer / user undertakes to request the latest documentation
from the ICP Group.
© ICP Group | All rights reserved. V.2.12.EN
BASIC
Page 1© ICP Group | All rights reserved.
BASIC
ABOUT THIS USER MANUAL
This manual is intended for installers and users of the ICARUS blue BASIC receiver (called „the receiver“ in the following).
This manual provides installers and users with all the necessary information to to ensure a correct, ecient and safe ins-
tallation and use of the receiver (during its lifetime), even in the event of foreseeable misuse.
This manual must be read carefully by installers and users and must be fully understood without leaving uncertainty prior
to installation and use of the receiver.
INTRODUCTION AND PURPOSE OF THE PRODUCT
The ICARUS blue BASIC receiver is a Bluetooth® receiver with four outputs. Via these four outputs electrial loads can be
switched on and/or o.
The receiver is operated via a corresponding ICARUS blue BASIC app for smartphones and/or tablets (called „the app“ in
the following). The app establishes a wireless connection via Bluetooth technology between the receiver and the smart-
phone / tablet.
The user interface of the app visualizes the respective outputs as well as their status (on / o) and allows the user to
configure, activate and deactivate the outputs accordingly.
The receiver can only be used in systems with a voltage range of 9 - 36 volts. The load of the entire system must never
exceed a maximum total current of 10 amperes.
The receiver also has an internal memory to store the configured settings. When another user connects his device to the
receiver, the stored settings are automatically loaded and displayed.
CONTENTS OF THE PACKAGE
Please check the completeness of the box‘s contents:
ICARUS blue BASIC receiver
Connection cable
Short User Manual
Page 2© ICP Group | All rights reserved.
BASIC
TABLE OF CONTENTS
ABOUT THIS MANUAL .............................................................................................................. 1
INTRODUCTION AND PURPOSE OF THE PRODUCT ..................................................................... 1
CONTENTS OF THE PACKAGE ................................................................................................... 1
SAFETY INSTRUCTIONS ........................................................................................................... 3
1. ICARUS BLUE BASIC RECEIVER ............................................................................................. 5
1.1 TECHNICAL SPECIFICATIONS ....................................................................................................... 6
1.2 PRODUCT TYPE IDENTIFICATION ................................................................................................. 6
1.3 INSTALLATION REQUIREMENTS ................................................................................................. 7
1.4 CONNECTING THE CABLES ........................................................................................................... 8
1.5 ACTIVATING THE PAIRING MODE .................................................................................................. 9
1.6 STATUS LED ................................................................................................................................... 9
2. ICARUS BLUE BASIC APP ...................................................................................................... 10
2.1 DOWNLOAD AND FIRST START .................................................................................................... 10
2.2 BUTTON LAYOUTS AND DESCRIPTIONS ..................................................................................... 11
2.3 ADDING A NEW RECEIVER .......................................................................................................... 11
2.4 BUTTON AND OUTPUT SETTINGS ................................................................................................ 12
2.5 GENERAL APP SETTINGS ............................................................................................................. 13
2.6 CONTROL BUTTON ICONS ............................................................................................................ 13
3. USING THE RECEIVER .......................................................................................................... 14
4. MAINTENANCE AND CLEANING ........................................................................................... 14
5. SOLVING OF DTCS ................................................................................................................ 14
6. DISPOSAL ........................................................................................................................... 15
7. WARRANTY ........................................................................................................................ 15
8. SIMPLIFIED DECLARATION OF CONFORMITY ........................................................................ 15
Page 3© ICP Group | All rights reserved.
BASIC
SAFETY INSTRUCTIONS
Before installing or using the receiver, you must read carefully through the „Short User Manual“ as well as this manual, to
ensure that you install and use the receiver correctly.
To ensure safety you must have fully understood the manuals without leaving uncertainty prior to installation and use of
the receiver. If there still are questions and / or uncertainties after reading the manual, contact your supplier
for clarification before installing or using the receiver! The „Short User Manual“ must also be included when this device is
used by any third party. Improper operation, by NOT having read the manual and having full understanding of it as well as
how to use the receiver, can bring the operator, bystanders and other matters in danger, depending on its application, and
may cause personal injury and / or damage to personal possessions as well as to the device.
ABOUT THE SYMBOLS
Various symbols are used in this manual, the „Short User Manual“ and on the receiver itself to ensure correct installation
and usage, to prevent danger to the user and others, and to prevent property damage. The meanings of these symbols are
described below. It is important that you read these descriptions carefully and fully understand the contents.
Indicates a hazardous situation which, if not avoided, could result in property damage.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
SAFETY PRECAUTIONS
• DO NOT leave packaging material lying around. This can be hazardous material for children.
• DO NOT open and / or disassemble and / or alter the receiver to avoid electric shock, malfunction or fire. This will
also expire the warranty.
• DO NOT put the receiver under mechanical pressure to avoid electric shock, malfunction or fire.
• DO NOT operate the receiver in an environment with flammable gases, vapours or solvents, as this may increase the
risk of fire and explosions.
• DO NOT use the receiver or/and any of its components (cable, plug, button ...) and/or the parts of the application the
receiver is used in, if it/they is/are damaged. In this case, discard the receiver in an environmental friendly manner.
• DO NOT use the receiver
• if it begins to malfunction or is not functioning at all.
• if it is producing smoke or burnt smell / odor.
• if it is discoloured or has other sustainable visible damage.
• DO NOT cover the receiver with a cloth (or similar) to avoid fire or injury by overheating.
• Make sure that the power supply is interrupted and that the cables are not crushed, kinked or damaged in any way,
for instance by sharp edges, when installing the receiver.
• Make sure the receiver is neither mechanically nor electrically overloaded. This may damage the receiver and cause
fire or electric shock.
• Only use the receiver within a range of 9 to 36 Volt dc. The load of the entire system must never exceed a maximum
total current of 10 amperes.
Page 4© ICP Group | All rights reserved.
BASIC
SAFETY INSTRUCTIONS (CONTINUED)
NOTES ON USE
• Loss and damage incurred due to non-observance of the safety requirements are not covered by the warranty. The
manufacturer is not liable for subsequent damage.
• The receiver may not be used to operate systems/applications in which the user is not protected by system-mounted
safety functions.
• The manufacturer will not be liable for damage or injuries caused by improper use or non-compliance of safety
provisions. In these cases, the warranty will become null and void.
• The receiver is not a toy and is not suitable for children.
• Contact an expert if you have any questions about the use/operation, safety or connection of the receiver.
• Observe the safety regulations, the valid laws and warnings of the respective application/machine manufacturers
(dealer, supplier) in which the receiver is used.
• The installer and user must always comply with the safety and operating instructions. This also applies to all other
devices and / or applications associated with the receiver.
Page 5© ICP Group | All rights reserved.
BASIC
1. ICARUS BLUE BASIC RECEIVER
Figure 1: ICARUS blue BASIC receiver.
STATUS
LED
CONNECTION
PLUG
ASSEMBLY HOLE
(M5)
PAIRING
BUTTON
Pin Wire-colour Function
4Black 0Vdc
1Red 9-36V
2Green Output 1
5Yellow Output 2
3Purple Output 3
6Grey Output 4
Figure 2: Pin and wire assignment
Page 6© ICP Group | All rights reserved.
BASIC
1.1 TECHNICAL SPECIFICATIONS
Frequency 2,4 GHz
Transmission power 7,5 dBm
Operating range approximately 100 ft
Power consumption ~4mA on 12V
Supply voltage 9-36 Vdc
Outputs 4 outputs with a rated current of 3.7A
Total current max. 10A
Dimensions 3,11“ x 3,42“ x 1,02“ (L x W x H)
Weight 138g
Casing moulded casing (IP66)
Temperature range -40°F to +131°F
Optical feedback Dual colour LED (red / green)
Platform Android and iOS
Max. number of paired devices 24
For min. system requirements see https://www.icarus-blue.com
1.2 PRODUCT TYPE IDENTIFICATION
Each ICARUS blue BASIC receiver is marked on the back with a corresponding product sticker, which enables a clear
identification of the product.
Page 7© ICP Group | All rights reserved.
BASIC
1.3 INSTALLATION REQUIREMENTS
• Only qualified personnel may install / mount the receiver.
• Incorect installation can endanger the user, bystanders or others (depending on
the application) causing injuries or damage to personal property and the receiver
itself.
• When installing / mounting the receiver, ensure that the work / assembly
environment is clean, tidy and dry.
• Unplug the receiver from a connected power source before installation
and assembly.
• Install the receiver in sight of the user, if possible.
• DO NOT install the receiver in the immediate vicinity of motors, relays or power cables.
• DO NOT install the receiver on the inside of a metal casing (this limits the connection range).
• Always observe a supplied wiring diagram before use.
• Always use adequately thick and correctly insulated cables that are suitable for the application.
• Connect the wires to the correct cable connectors and do not use any insulation tape. Improper connections can
cause fire and / or electric shock and lead to personal injuries and may damage the product.
• The receiver must be attached / mounted with two screws (M5) through the corresponding assembly holes (see chapter
1, fig. 1).
• Always observe the valid safety instructions.
• Install the receiver with the connector facing down for maximum water resistance!
It is strictly forbidden to install
and/or operate the receiver if
you are tired or under the
influence of drugs (including
alcohol) or medication.
Follow the safety instructions!
Page 8© ICP Group | All rights reserved.
BASIC
1.4 CONNECTING THE CABLES
1. The following tasks may only be carried out by qualified electricians or by other persons supervised by qualified
electricians.
2. Connect the supplied cable to the receiver by inserting the cable plug to the receiver (see chapter 1, fig. 2).
Note: Only use the supplied cable and plug!
3. Connect the loose end of the black wire (of the supplied cable) to the earth (0 Vdc) of the connected unit/part.
4. Connect the loose ends of the green, yellow, grey and/or purple wires (of the supplied cable) to the respective unit /
part that you want to control.
5. Connect the loose end of the red wire (of the supplied cable) to the power supply. Note: The voltage range is 9 - 36
Vdc.
6. Check that all cables have been connected correctly.
7. Switch the power supply back on. Information: The LED on the receiver starts to flash green during the start process.
As soon as the start process has been completed successfully, the LED flashes green every two seconds.
You can now start to activate the pairing mode (see 1.5) and pair the receiver with your smartphone (see 2.3).
TURN OFF POWER SUPPLY
BEFORE CONNECTING THE
CABLES, TO AVOID
ELECTRIC SHOCK,
MALFUNCTION OR FIRE!
READ AND FOLLOW THE
CORRESPONDING MANUAL AND
SAFETY INSTRUCTIONS
OF THE DEVICES YOU CONNECT
TO THE RECEIVER!
Page 9© ICP Group | All rights reserved.
BASIC
1.6 STATUS LED
START UP ERROR CODE
LED flashing green rapidly. Example: Flashing 3x red with short pause inbetween.
Green Green
Red Red
NO SMARTPHONE/TABLET CONNECTED
LED flashing green 1x with a 2 second pause inbetween.
Green
Red
SMARTPHONE/TABLET CONNECTED
LED lighting up green (permanently).
Green SEE CHAPTER 5. TO SOLVE THE ERRORS!
Red
PAIRING MODE ACTIVE
LED flashing alternately red and green.
Green
Red
Flashing Description
3x (red) Undervoltage (<6,5V for 1,5s)
4x (red) Overvoltage (>36V for 60ms)
5x (red) Sum of separate currents > 10A
6x (red) Overcurrent output 1
7x (red) Overcurrent output 2
8x (red) Overcurrent output 3
9x (red) Overcurrent output 4
1.5 ACTIVATING THE PAIRING MODE
The „pairing button“ of the receiver (see chapter 1, fig. 1) is used to activate the pairing mode (pairing smartphones / tab-
lets with the receiver).
STEP 1 Make sure that the receiver is correctly wired, supplied with power and started up (see 1.4).
STEP 2 Press the pairing button on the receiver three times within 4 seconds. Information: The LED on the receiver
starts flashing green rapidly.
STEP 3 Wait until the LED alternates between red and green.
The pairing-mode of the receiver is now activated. Continue by pairing the receiver with your smartphone / tablet
(see 2.2) or deactivate the pairing-mode, by pressing the pairing button once more.
Page 10© ICP Group | All rights reserved.
BASIC
2. ICARUS BLUE BASIC APP
The receiver can only be controlled and configured via the corresponding free ICARUS blue BASIC app.
Once you have downloaded and installed the app (see 2.1) you will be able to:
• add and manage multiple ICARUS blue BASIC receivers to the app,
• control the separate outputs of the receiver,
• configure the behaviour and function of the control buttons,
• configure individual options per control button and output,
• change the icons of the control buttons,
• activate or deactivate live monitoring of the battery voltage,
• set a password to protect the configuration from unauthorized changes by third parties.
Since most of the settings and options are self-explanatory and / or are explained within the app (see 2.2), this
manual is limited to explaining the essential processes and options.
2.1 DOWNLOAD AND FIRST START
STEP 1 Open the „Play Store“ (only for Android devices) or the
„App Store“ (only for iOS devices) on your device.
STEP 2 Search for „ICARUS blue BASIC“ (by ICP Group).
STEP 3 Download and install the free ICARUS blue BASIC app.
STEP 4 Start the app.
STEP 5 Activate the Bluetooth function of your device if the app
prompts you to do so.
STEP 6 Read the displayed general terms of usage / disclaimer
carefully. Note: To continue using the app, you must accept
those terms.
STEP 7 Follow the short instructions shown in the „Welcome to the first installation“-screen. Note: If this screen
is not showing (for example because it is not the first time that you are using the app), follow the
instructions in 2.3.
Make sure that your device
meets the min. requirements
(www.icarus-blue.com).
Otherwise you will not be able
to download the app and / or
the app will not work properly.
Page 11© ICP Group | All rights reserved.
BASIC
2.2 BUTTON LAYOUTS AND DESCRIPTIONS
2.3 ADDING A NEW RECEIVER
Note: To add a new receiver, the corresponding receiver must be in „pairing- mode“ (see chapter 1.5). Make sure that there
is only one receiver in „pairing-mode“ at a time. Otherwise you will not be able to identify the respective receiver correctly.
STEP 1 Open the main menu via the main menu button.
STEP 2 Select the menu item „New receiver“. Note: The app will automatically begin to search for receivers within your
range, that are currently in pairing mode.
STEP 3 Select the receiver you want to connect.
STEP 4 Enter a description / name for the receiver.
STEP 5 Press „Pair“ to confirm the entered description / name.
Your smartphone now connects to the selected receiver and synchronises the settings.
After the connection-process has been successfully completed, you will get redirected to the „Home“ screen of the
smartphone app.
BUTTON LAYOUT BUTTON NAME AND DESCRIPTION
MAIN MENU BUTTON
· Located at the top left corner of the app screen.
· Opens the main menu when pressed.
INFORMATION BUTTON
· Located on the right side of several setting options.
· Shows additional / corresponding information and / or instructions when pressed.
CONTROL BUTTON
· Located on the „Home“ screen.
· Activates the assigned output(s) and functions when pressed.
· Icon can be changed (Main menu →Settings →Icon)
· Control button can have several states (from top to bottom, as shown on the left):
1) Control button is not pressed and output is not active
2) Control button is pressed, but output is not active
3) Control button is not pressed but output is active
4) Control button is pressed and output is active
Page 12© ICP Group | All rights reserved.
BASIC
2.4 BUTTON AND OUTPUT SETTINGS
Once you have paired and connected the receiver with your smartphone, you can control and configure the „control
buttons“ and outputs of the receiver within the smartphone app.
STEP 1 Open the main menu.
STEP 2 Select the „settings“ menu item.
STEP 3 Press the gearwheel-icon of the „control button“ whose options you want to change.
You will get the following four basic setting options:
OPTION DESCRIPTION
NO FUNCTION When this option is selected, the corresponding „control button“ is disabled and does
not appear on the home screen of the smartphone app.
BUTTON When this option is selected, the corresponding „control button“ functions like a push
button. This means that the corresponding output of the receiver remains active only
as long as the „control button“ is pressed continuously. When the „control button“ is
released, the output switched o.
SWITCH When this option is selected, the corresponding „control button“ functions like a switch.
This means that when the button is pressed, the corresponding output of the receiver is
activated and remains active until the button is pressed again.
SAFETY FUNCTION When this option is active, the corresponding
output of the receiver will be turned o after:
· the smartphone app lost focus,
· the Bluetooth connection has been interrupted,
· or the receiver can not be reached.
If you deactivate the safety function option, the
corresponding output of the receiver remains
active under all circumstances.
THIS FUNCTION MAY ONLY
BE DEACTIVATED AS LONG
AS THE CORRESPONDING
OUTPUT DOES NOT
CONTROL ANY SAFETY-
RELEVANT FUNCTIONS!
STEP 4 If you want to configure more advanced settings, press the „Advanced“ button at the bottom of the pop-up.
Note: The advanced settings include timer functions, button interlock, output selection and button visibility
All advanced settings are self-explanatory. However, additional explanatory information is stored in the
app, which you can call up by pressing the respective information buttons.
STEP 5 Press „Save“ at the bottom of the pop-up to save all settings made and return to the settings screen.
Otherwise, press „Cancel“ to return to the settings screen without saving the settings you made.
Page 13© ICP Group | All rights reserved.
BASIC
2.5 GENERAL APP SETTINGS
In addition to the buttons and output settings (see 2.4), you can also change the general app settings.
STEP 1 Open the main menu.
STEP 2 Select the „settings“ menu item.
STEP 3 Press „App Settings“ at the bottom of the screen.
You will get the following app setting options:
2.6 CONTROL BUTTON ICONS
The app contains a large selection of dierent icons, which you can assign to the respective control buttons individually.
STEP 1 Open the main menu.
STEP 2 Select the „settings“ menu item.
STEP 3 Press the „Icon“ button of the control button whose icon you want to change.
STEP 4 Select the desired icon by pressing on it. A pop-up will appear with the message „Settings are stored“.
STEP 5 Confirm the pop-up message by pressing „OK“. The icon has now been assigned to the selected button.
OPTION DESCRIPTION
RESTORE FACTORY
SETTINGS
Here you have the possibility to reset all button and output settings of the receiver to
the factory state.
SET PASSWORD Here you can set a password to prevent the receiver settings from being changed by
unauthorized persons. Once a password is set, the receiver settings can only be changed
after entering the correct password.
BATTERY STATUS Enabling the battery status will show the actual system voltage in the home screen.
It could also help to prevent the system against undervoltage. The detailed setting
options of the battery status function are explained via the respective information
buttons in the app.
Page 14© ICP Group | All rights reserved.
BASIC
3. USING THE RECEIVER
Improper operation, by NOT having read the user manual and having full understanding of it as well as how to use the
device, can bring the operator, bystanders and other matters in danger, depending on its application, and may cause
personal injury and / or damage to personal possessions as well as to the receiver.
4. MAINTENANCE AND CLEANING
The receiver is maintenance-free for the user. Maintenance and repairs must be done by a specialist.
The receiver should be cleaned only with a damp cloth and without chemicals. Doing otherwise may damage the receiver.
5. SOLVING OF DTCs (DIAGNOSTIC TROUBLE CODES)
FOR A DETAILED ILLUSTRATION OF THE DTCS, PLEASE SEE 1.6!
FLASHING 3X: UNDERVOLTAGE
This error appears if the supply voltage of the receiver drops under 6,5V for at least 1,5sec. A pop-up will be shown in the
smartphone app. To reset the error raise up the supply voltage over 6,5V again and click on „reset error“ in the smartphone
app.
Note: Undervoltage can be triggered by heavy loads (large powerful motors).
FLASHING 4X: OVERVOLTAGE
This error appears if the supply voltage of the receiver raises over 36V for at least 60ms. A pop-up will be shown in the
smartphone app. To reset the error lower the supply voltage under 32V again and click on „reset error“ in the smartphone
app.
Note: Overvoltage can be a result of defect components in the system or external voltage sources which are
connected to the system (e.g. battery charger). Make sure that those sources are removed before resetting the error.
FLASHING 5X: OVERCURRENT OF ALL OUTPUTS COMBINED
This error appears if the total current of the receiver is too high. To reset the error, a smartphone needs to be connected.
After connecting, a pop-up will be shown in the smartphone app and the error can be resetted by clicking on „reset error“.
The error won‘t be resetted by a current drop.
Note: Overcurrent can be a result of connecting to many loads to the receiver. Make sure those loads won‘t exeed a total
maximum current of 10A.
FLASHING 6X - 9X: OVERCURRENT OF A SINGLE OUTPUT
This error appears if the current of one of the outputs is too high. To reset the error, a smartphone needs to be connected.
After connecting, a pop-up will be shown in the smartphone app and the error can be resetted by clicking on „reset error“.
The error won‘t be resetted if the current will drop down again.
Note: Overcurrent of an output can be a result of connecting the output to a component which needs to much
current. Make sure the current won‘t exeed the maximum current of 3,7A per output.
Overcurrent of an output can also be a result of a short circuit in the wiring. Make sure that all short circuits are removed
before resetting the error.
Page 15© ICP Group | All rights reserved.
BASIC
6. DISPOSAL
Electronic devices are recyclable waste and DO NOT belong in the garbage. If the receiver does not work anymore, dispose
it in accordance with applicable legal regulations.
By following the above recommendation you comply with your legal obligations and contribute to the protection of the
environment.
7. WARRANTY
The ICARUS blue BASIC receiver was tested in a controlled environment and has proven resistant to moisture and dust
under certain circumstances (corresponds to the requirements of the classification IP66 pursuant to the international
norm IEC 60529).
The supplier / manufacturer is not able to ensure that the content of these operating instructions and the use of the
receiver have been understood and observed by the user. Incorrect and/or faulty installation and/or assembly as well as
incorrect / faulty operation can lead to injuries and damage of materials.
The manufacturer will not accept liability for injuries and damage to materials and/or personal property or any other costs
incurred due to incorrect and/or faulty assembly, incorrect use and/or application for which the product was not designed
and produced, or non-observance of maintenance or incorrect servicing and/or anything else connected to this.
The manufacturer is relieved of any responsibility in case of unauthorized dismantling and/or modification. All necessary
and used parts must be approved by the manufacturer so that the receiver maintains its guaranteed safety and operation
throughout its service life.
8. SIMPLIFIED DECLARATION OF CONFORMITY
ICP Systems b.v. (Handelsweg 48, 7451 PJ Holten, The Netherlands) herewith declares that the radio system ICARUS blue
BASIC complies with the Directive 2014/53/EU. The complete text of the EU Declaration of Confirmity is available at the
following address: https://www.icarus-blue.com
Other manuals for ICARUS blue
1
Table of contents
Other ICP Receiver manuals
