ICRealtime ICIP-P2300Y-IR User manual

HD IR Speed Dome User’s Manual
Version 1.0.0

i
Table of Contents
1FEATURES AND FUNCTIONS...........................................................................................1
1.1 General Introduction...................................................................................................................................................1
1.2 Features .......................................................................................................................................................................1
1.2.1 On-Screen Menu....................................................................................................................................................1
1.2.2 Zoom Speed Limit..................................................................................................................................................1
1.2.3 OSD.........................................................................................................................................................................1
1.2.4 Preset Setup and Call ...........................................................................................................................................1
1.2.5 Auto Scan................................................................................................................................................................1
1.2.6 Auto Touring...........................................................................................................................................................1
1.2.7 Auto Pattern............................................................................................................................................................1
1.2.8 Privacy Masking.....................................................................................................................................................1
1.2.9 Auto Flip..................................................................................................................................................................1
1.2.10 Self-diagnosis....................................................................................................................................................1
1.2.11Day/Night Mode (B/W & Color Mode)............................................................................................................2
1.2.12 Auto Focus.........................................................................................................................................................2
1.2.13 Backlight Compensation ..................................................................................................................................2
1.2.14 Pan Tilt and Zoom.............................................................................................................................................2
1.2.15 3D Intelligent Positioning .................................................................................................................................2
1.2.16 Idle Status ..........................................................................................................................................................2
1.2.17 Image Stabilizer/Flip.........................................................................................................................................2
2QUICK CONFIGURATION TOOL .......................................................................................3
2.1 Overview ......................................................................................................................................................................3
2.2 Operation .....................................................................................................................................................................3
3WEB OPERATION..............................................................................................................6
3.1 Network Connection ...................................................................................................................................................6
3.2 Login and Logout ........................................................................................................................................................6

ii
4MENU .................................................................................................................................9
4.1 Screen Menu Index ..................................................................................................................................................9
4.2 Self-diagnosis System Information ........................................................................................................................10
4.3 Main Menu .................................................................................................................................................................10
4.4 Menu Operation ......................................................................................................................................................11
4.4.1 System Information..............................................................................................................................................11
4.4.2 Display Setting .....................................................................................................................................................12
4.4.3 Camera Setting ....................................................................................................................................................12
4.4.4 Function Setting...................................................................................................................................................18
4.4.5 IR Light Setting.....................................................................................................................................................26
4.5 Abnormity Handling...............................................................................................................................................26
5CABLE CONNECTION .....................................................................................................27
5.1 Combination Cable Connection............................................................................................................................27
5.2 System Layout ........................................................................................................................................................28
5.2.1 System Connection .............................................................................................................................................28
5.2.2 Alarm Connection ................................................................................................................................................28
6FAQ...................................................................................................................................29
6.1 Daily Maintenance..................................................................................................................................................29
6.2 Problems and Solutions .......................................................................................................................................29
7APPENDIX ⅠLIGHTNING PROOF AND SURGE PROTECTION .....................................30
8APPENDIX 2 TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS ...........................31

iii
Welcome
Thank you for purchasing our product!
This user’s manual is designed to be a reference tool for the operation of your system.
Here you can find information about this speed dome features and functions, as well as a detailed menu tree.
Please keep it well for future reference!
Before installation and operation, please read the following safeguards and warnings carefully!

iv
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation Security
No heavy stress, violent vibration or water splash are allowed during transportation, storage and
installation.
Please use the original packing material (or the material of the same quality) when you ship it back to
the manufacturer.
3．Installation
Do not apply power to the product before completing installation.
Do not put object on the product.
4. Qualification Requirement
The device has to be installed and repaired by professional licensed technician and installation
personnel.
5. Dismantling
Don’t remove screws or protection cover; there are no parts inside the SD for users to repair by
themselves.
6．Environment
This series product should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the device. This series product complies with the IP66
standard specified in the Degrees of Protection Provided by Enclosure.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Usually we recommend thunder-proof device to prevent thunder strike.
The GND port of the product shall be grounded to further enhance the reliability of the device.
7. Daily Maintenance
Current series product has no power button. Please unplug all corresponding power cables before your
begin installation or daily maintenance work.
Please keep the dustproof cap back to protect the CCD or CMOS part if the device does not work for a
long time.

v
Do not touch CCD (CMOS) component. You can use the blower to clean the dust on the surface of the
device. You can use the dry cloth with some alcohol or mild detergent to clear if necessary.
Do not use the volatility solvent such as the benzene or thinner, or detergent with strong abradibility. It
may result in lens damage or it may adversely affect the device performance.
If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device.
8. About Accessories
Always use all the accessories recommended by manufacturer.
Before installation, please open the package and check that all the components are included in the package:
Contact your local retailer ASAP if something is missing in your package.

1
1Features and Functions
1.1 General Introduction
This series HD IR speed dome product is an integrated high intelligent speed dome. It adopts new
configuration design and is easy for the project construction. This is a digital and intelligent product of vivid
video. The installation is convenient.
Comparing with the previous series product, this series HD IR speed dome has added some new features. It
supports intelligent analysis function, and the PTZ rotation speed can automatically adjust according to the
zoom rate of the lens. It supports various languages, real-time clock function and protocol auto recognition.
It supports 360°continuously pan, 110°tilt(-20°-90°) and 180°auto flip. It can realize no blind spot monitor.
1.2 Features
This series speed dome has the following features:
1.2.1 On-Screen Menu
This series product menu supports multiple languages.
It is easy for you to view dome information and configure dome, camera parameters.
1.2.2 Zoom Speed Limit
The laser HD intelligent speed Dome adopts auto match technology between focal length and rotation speed.
The pan and tilt speed of the speed dome change according to the zoom rate of the device. The movement
speed becomes slower when the zoom speed increases, and the movement speed becomes higher when
the zoom speed decreases.
1.2.3 OSD
It can display the called preset and preset ID, speed dome title, speed dome system temperature, speed
dome location coordinates when touring via menu setting.
1.2.4 Preset Setup and Call
Preset function is to save the address information (such as PTZ pan/tilt, focus and etc) to the memory so
that you can quickly adjust the dome and PTZ to the correct position.
1.2.5 Auto Scan
Camera scans back and forth regularly in a horizontal field. Here you need to set left and right limit and scan
speed.
1.2.6 Auto Touring
Add addresses into a routine in a desired order and then set time and stop duration for each address. The
dome will begin an auto touring between these addresses.
1.2.7 Auto Pattern
Memorize dome operation such as pan, tilt, and zoom to repeat. You can call it to repeat the previous
operation.
1.2.8 Privacy Masking
Privacy masking is a user-defined, four-sided area that cannot be viewed by you. The masking area will
move with pan and tilt functions and automatically adjust in size as the lens zooms.
1.2.9 Auto Flip
As long as you continue to hold the keyboard joystick in the down position, the dome rotates 180 degrees
and repositions itself for uninterrupted viewing of any subjects that passes directly beneath the dome.
1.2.10 Self-diagnosis

2
There is a self diagnosis procedure when dome boots up.
Tilt and vertical engine check
Camera diagnostics (mainly zoom function diagnosis)
Display dome information.
1.2.11 Day/Night Mode (B/W & Color Mode)
Auto/manual switches in low illumination. There are several modes such as photoresistor, auto, manual and
etc. This function needs the speed dome driver (camera) supported.
1.2.12 Auto Focus
Support camera auto focus function.
1.2.13 Backlight Compensation
Balance the brightest and darkest sections of a scene to produce a more vivid picture.
1.2.14 Pan Tilt and Zoom
Supports zoom in and zoom out during tilt and pan movement.
You can still get vivid image even you set auto focus and auto iris during this period.
1.2.15 3D Intelligent Positioning
Support 3D intelligent positioning function. The speed dome can auto track to the specified zone.
1.2.16 Idle Status
When there is no available order for specified duration, you can use menu to set dome idle status.
1.2.17 Image Stabilizer/Flip
You can enable image stabilizer function and flip in the menu.
When there is vibration, this IS function can guarantee video stability and when flip, you can view video
more clearly.
This function needs speed dome driver (camera) supported.

3
2Quick Configuration Tool
2.1 Overview
Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it
to upgrade the device.
Please note the tool only applies to the IP addresses in the same segment.
2.2 Operation
Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 2-1.
In the device list interface, you can view device IP address, port number, subnet mask, default gateway,
MAC address and etc.
Figure 2-1
Select one IP address and then right click mouse, you can see an interface is shown as in Figure 2-2.
Note:
You can set the IP address, subnet mask and gateway for the network camera and PC. Please note network
camera IP address and PC IP address shall be in the same network segment if there is no router. Network
camera default IP address is 192.168.1.108. If there is a router, please set the corresponding gateway and
subnet mask.
The factory default user name is admin and password is admin. For security reasons, please modify your
password after you first login.
For detailed WEB operation, please refer to the Web Operation Manual in the resource CD.

4
Figure 2-2
Select the “Open Device Web”item; you can go to the corresponding web login interface. See Figure 2-3.
Figure 2-3
If you want to modify the device IP address without logging in the device web interface, you can go to the
configuration tool main interface to set.
In the configuration tool search interface (Figure 2-1), please select a device IP address and then double
click it to open the login interface. Or you can select an IP address and then click the Login button to go to
the login interface. See Figure 2-4.
In Figure 2-4, you can view device IP address, user name, password and port. Please modify the
corresponding information to login.
Please note the port information here shall be identical with the port value you set in TCP port in Web
Network interface. Otherwise, you can not login the device.
If you are using device background upgrade port 3800 to login, other setups are all invalid.

5
Figure 2-4
After you logged in, the configuration tool main interface is shown as below. See Figure 2-5.
Figure 2-5
For detailed information and operation instruction of the quick configuration tool, please refer to the
Quick Configuration Tool User’s Manual included in the resources CD.

6
3Web Operation
This series speed dome product supports the Web access and management via PC.
Web includes several modules: live view, PTZ, setup, alarm, logout and etc.
Speed dome factory default setup:
IP address: 192.168.1.108.
User name: admin
Password: admin
3.1 Network Connection
Please follow the steps listed below for network connection.
Make sure the speed dome has connected to the network properly.
Speed dome IP address and PC IP address shall be in the same network segment. Speed dome default
IP address is 192.168.1.108. If there is router, please set the corresponding gateway and subnet mask.
Use order ping ***. ***. ***. *** (* speed dome address) to check connection is OK or not.
3.2 Login and Logout
Open IE and input speed dome address in the address bar.
For example, if your speed dome IP is 192.168.1.108, then please input http:// 192.168.1.108 in IE address
bar. See Figure 3-1.
Figure 3-1
System pops up warning information to ask you whether install control webrec.cab or not. Please click OK
button, system can automatically install the control. When system is upgrading, it can overwrite the previous
Web too.
If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the
control download. Or you can lower the IE security level. See Figure 3-2.
Input your IP
address here

7
Figure 3-2
After installation, the interface is shown as below. See Figure 3-3.
Please input your user name and password.
Default factory name is admin and password is admin.
Select the network connection type.
Note: For security reasons, please modify your password after you first login.
Figure 3-3
After you logged in, you can see the main window. See Figure 3-4.

8
Figure 3-4
Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction.

9
4Menu
4.1 Screen Menu Index
Note:
ERR means current setup is invalid; you need to restores speed dome factory default setup.
Slight difference may be found due to different series.
PRESET TITLE
AZIMUTH DISP
POSITION
ZOOM DISP
INSIDE TEMP
PATTERN DISPLAY
RS485 DETECT
BACK EXIT
DISPLAY SETTING
SYSTEM
INFORMATION
CAMERA SETTING
FUNCTION SETTING
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETTING
IMAGE ADJUST
DEFOG SETTING
ZOOM SPEED
NEXT PAGE
BACK EXIT
PRESET
PAN
AUTO SCAN
AUTO TOUR
AUTO PATTERN
IDLE MOTION
TIME TASK
NEXT PAGE
BACK EXIT
IR LIGHT SETTING
IR SENSITIVITY
IR CONTROL RULE
NEAR LIGHT
FAR LIGHT
IR LIGHT COMPENSATION
BACK EXIT
SYSTEM INFORMATION…
ADDR INFORMATION…
SET NORTH
LANGUAGE
FACTORY DEFAULT
RESTART
BACK EXIT
EXIT

10
SYSTEM SETTING
DISPLAY SETTING
CAMERA SETTING
FUNCTION SETTING
IR LIGHT SETTING
EXIT
The above diagram illustrates the overall structure of the speed dome setup menu.
Note:
ERR means current setup is invalid.
Please make sure all the cable connections are right.
4.2 Self-diagnosis System Information
After installation, please connect speed dome to power. The system goes on a self-diagnosis, and then it
pops up the above interface to show the system information.
The above interface disappears after speed dome received the first command (or the display time lasts for
20 seconds.)
ADDR: Here you can view dome address information. For example, 1-S, 1 is the address number, –S is
software address mode.
Baud rate: Dome communication baud rate.
Parity: Communication parity bit format.
Model: Speed dome model.
Software: Dome PTZ software version.
When you are using the control keyboard or the matrix host to control the device, please make sure
the control parameter of the keyboard or the matrix host is the same with the speed dome OSD
(including address, baud rate, parity). Please make sure the cable connection is OK.
4.3 Main Menu
You can open the IP dome menu via control keyboard, matrix, or speed dome control terminal.
Control the speed dome via control keyboard, matrix host, speed dome control terminal and etc, and then
open the main menu.
SYSTEM SETTING：Display speed dome system information, address information. Here you can set
north direction, language, factory default setup, reboot and so on.
DISPLAY SETTING: Display dome preset title, azimuth display, time, direction, dome internal
temperature, title information, zoom information and etc.
CAMERA SETTINGS：Set dome white balance, camera parameter, day/night setup and etc.
FUNCTION SETTING: Set preset, pan, auto scan, auto tour, pattern, idle function, time task and
privacy mask function.
Address ：1-S
Baud rate ：9600
Parity ：None
MODEL :SD6A8
Software Version ：2.02.63. R
BACK EXIT

11
SYSTEM INFORMATION
ADDR INFORMATION
SET NORTH
LANGUAGE : ENGLISH
FACTORY DEFAULT
RESTART
BACK EXIT
ADDR ：1-S
BAUD RATE ：9600
PARITY ：NONE
MODEL : SD6A8
SOFTWARE ：2.02.63. RHISFG
BACK EXIT
IR LIGHT SETTING: Set IR sensitivity, IR control rule, near light brightness, far light brightness, IR light
compensation and etc.
EXIT: Log out the system menu.
4.4 Menu Operation
In the speed dome main menu, you can use the left/right button on the keyboard or in the speed dome
terminal menu to configure the system menu. Before setup, please move the cursor to the current item you
want to configure.
In main menu, please click confirm button to go to the sub menu or use left/right key to configure setup.
Use up/down button to select back option and then click confirm button to go back to the previous menu.
Use up/down button to select exit option and then click confirm button to log out system menu.
All setup here will not lose when encounter power failure.
4.4.1 System Information
Move the cursor to SYSTEM SETTING and then click confirm button, you can go to the third submenu.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set. After completed
setup, please click save button to save current setup.
SYSTEM INFORMATION: Move the cursor to SYSTEM INFORMATION and then click confirm button
to go to the third submenu.
ADDR INFORMATION: Move the cursor to SITE INFORMATION and then click confirm button to go to
the third submenu.
SYSTEM TIME SETTING: Move the cursor to SYSTEM TIME SETTING and then click confirm button
to go to the third submenu.
SET NORTH DIRECTION: Set dome benchmark direction so that you can know the angel between the
benchmark and then current location. Please move the cursor to the option and then click confirm
button until you see O.K. Now you have set north direction.
LANGUAGE: The dome menu language. There are several languages for you to select. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
FACTORY DEFAULT: Restore dome factory default setup. Please move the cursor to the option and
then click confirm button until you see O.K. Now you can see the IP dome begin rebooting to restore
factory default setup.
RESTART: Reboot the speed dome.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
4.4.1.1 System information

12
Move the cursor to SYSTEM INFORMATION and then click confirm button, you can see the above interface.
Here you can view dome basic information.
4.4.1.2 Address Information
Move the cursor to SITE INFORMATION and then click confirm button.
ADDR TYPE: System supports software address only.
ADDR-SOFT: It is to display speed dome software address. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set. The value ranges from 1 to 255.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
4.4.2 Display Setting
Before the operation, please make sure you purchased camera supports zoom function.
Move the cursor to DISPLAY SETTING and then click confirm button, you can go to the third submenu.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set. After completed
setup, please click save button to save current setup.
PRESET TITLE: Display dome preset title or not. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.
AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set
TIME DISP: Display dome system time or not. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
POSITION: Display the angel between the benchmark and then current location. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
ZOOM DISP: Display speed dome optical zoom speed or not.
INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options: ℃/F/Off.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
RS485 DETECT: It will display wrong messy code when users control the speed dome in a situation
where RS485 connection is wrong. The function can be used to set if it will display the wrong code.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
4.4.3 Camera Setting
Before the operation, please make sure your camera supports the corresponding function.
ADDR TYPE ：SOFT
ADDR-SOFT ：1
BACK EXIT
PRESET TITLE ：ON
AZIMUTH DISP ：OFF
TIME DISP ：OFF
POSITION ：OFF
ZOOM DISP ：OFF
INSIDE TEMP ：ON
RS485 DETECT ：ON
BACK EXIT

13
Move the cursor to CAMERA SETTING and then click confirm button, you can go to the submenu.
WHITE BALANCE SETUP: Move the cursor to current option and then click confirm button, you can go
to the third menu.
EXPOSURE SETTING: Move the cursor to current option and then click confirm button, you can go to
the third menu.
DAY/NIGHT: Set day/night mode. Move the cursor to current option and then click confirm button, you
can go to the third menu. There are three options: auto/manual/off. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set. Please make sure your product supports this
function.
FOCUS SETUP: It is to set the camera focus mode, focus limit and etc. Please move the light to
highlight current item and then click the OK button to go to the next level menu.
IMAGE ADJUSTMENT: It is to set the camera hue, saturation, color control, gamma and etc. There is
the third menu. Please move the light to highlight current item and then click the OK button to go to the
next level menu.
DEFOG: It is to set camera defog mode and intensity. It can enhance the camera video quality under
the fog environment. There is the third menu. Please move the light to highlight current item and then
click the OK button to go to the next level menu.
ZOOM SPEED: The bigger the value, the faster the speed. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
NEXT PAGE: It includes the following options: DIGITAL ZOOM, PICTURE FLIP, FREEZE FUNCTION,
STABLE, CAMERA FACTORY DEFAULT SETUP, and CAMERA RESTART. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
APERTURE SETTING: It is to adjust the lens to achieve clear video. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
APERTURE RESTRAIN LEVEL: System can auto reduce the aperture to lower the video noise when it
is in low illumination environment. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
DIGITAL ZOOM: Click “left”, “right”button to set “on/off”.
PICTURE FLIP: Click “left”, “right”button to set “on/off”.
FREEZE FUNC: Click “left”, “right”button to set “on/off”.
STABLE: Click “left”, “right”button to set “on/off”.
CAMERA FACTORY DEFAULT: move the cursor to the item, click “OK”button to restore camera
factory default.
CAMERA RESTART: move the cursor to the item, click “OK”button to restart the camera.
BACK: Go back to previous menu.
EXIT: Log out system menu.
4.4.3.1 White Balance Setup
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETING
IMAGE ADJUST
DEFOG SETTING
ZOOM SPEED
NEXT PAGE
BACK EXIT
WB MODE ：AUTO
R GAIN ：80
B GAIN ：80
BACK EXIT
APERTURE SETTING
APERTURE RESTRAIN LEVEL
DIGITAL ZOOM
PICTURE FLIP
FREEZE FUNC
STABLE
CAMERA FACTORY DEFAULT
CAMERA RESTART
BACK EXIT

14
Move the cursor to WHITE BALANCE MODE and then click confirm button, you can go to the submenu.
WHITE BALANCE MODE: Set white balance adjustment mode. There are several modes such as auto,
auto trace white balance, indoor, outdoor, and manual and etc. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
R GAIN: Before you set R GAIN option, please note the mode shall not be auto. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
B GAIN: Before you set B GAIN option, please note the mode shall not be auto. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
BACK: Go back to previous menu.
EXIT: Log out system menu.
4.4.3.2 Exposure Setting
AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/iris priority/shutter
priority.
oAuto: The gain, iris and shutter is under auto setup mode
oManual: You need to set gain, iris and shutter manually.
oIris priority: You can set iris manually. Gain and shutter is under auto setup mode.
oShutter priority: You can set shutter manually. Gain and iris is under auto setup mode.
oClick “left”, “right”button to set.
GAIN SETTING: It is to set camera gain. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
SHUTTER: It is to set camera shutter speed. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
IRIS SETTING: It is to set camera iris value. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
EXPOSURE COM: It is to set camera exposure compensation. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
SLOW AE: In the strong light environment, you can lower the camera exposure speed to capture the
image and enhance the definition. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
BLC: It is adjust the camera brightness, the camera makes brightness compensation automatically to
darker target when it is exposed to strong light background, and adjust the background with strong light,
click “left”, “right”button to set.
NEXT PAGE: It includes SLOW SHUTTER, AUTO SLOW SHUTTER LIMIT, AUTO GAIN LIMIT, 2DNR,
CAMERA 3DNR, EXPOSURE RESTRAIN, AUTO EXPOSURE RECOVERY, WDR SETTING.
AE MODE ：AUTO
GAIN SETTING ：2
SHUTTER SETTING ：1/50
IRIS SETTING ：11
EXPOSURE COMP ：08
SLOW AE ：1
BLC ：OFF
NEXT PAGE
BACK EXIT
SLOW SHUTTER : ON
AUTO SLOW SHUTTER LIMIT ：1/25
AUTO GAIN LIMIT ：3
NOISE REDUCTION ：2
3D NOISE REDUCTION : OFF
EXPOSURE RESTRAIN : OFF
AE RECOVERY : 15Min
WDR SETTING
BACK EXIT
