Ganz ZC-YX270P User manual

EG-2
Thank you for your purchase of this product.
 Before operating this product, please read this instruction manual carefully.
 After you have read this manual, store it in a safe place for future reference.
CONTENTS
PRODUCT FEATURES --------------------------------------------------------------------------------------------------------- EG-2
SAFETY PRECAUTIONS ------------------------------------------------------------------------------------------------------ EG-3
PART NAMES AND FUNCTIONS ------------------------------------------------------------------------------------------- EG-4
CAMERA MOUNTING ---------------------------------------------------------------------------------------------------------- EG-8
EXTERNAL DIMENSIONS----------------------------------------------------------------------------------------------------- EG-8
MODEL DESCRIPTION -------------------------------------------------------------------------------------------------------- EG-9
SPECIFICATIONS --------------------------------------------------------------------------------------------------------------EG-10
PRODUCT FEATURES
• High-resolution surveillance camera with a new built-in 1/3-type CCD. It delivers clear images at
a horizontal resolution of 700 TVL by using a new high-resolution CCD and image processing
technology.
• 12 V DC/24 V AC auto switching power supply.
(ZC-YX270P, ZC-NX270P, ZC-YXW270P, ZC-NXW270P)
• The new Wide Dynamic Range (WDR) processing technology offers the high dynamic range of
approximately 82dB, ensuring sharp images even if the pictures are shot in mixed indoor/outdoor
scenes with backlight.
• New Easy Focus function helps adjust the lens focus by edge enhancement focus level bar, and
screen view zoom-up / down.
• The Color Bar Output function enables the checking and adjustment of cable signal levels and
monitoring of the image quality.
• The Defog function provides high-quality images with automatically enhanced contrast in an
environment with poor visibility, such as fog, mist, rain, and snow.
• The 3D-Digital Noise Reduction (3D-DNR) function realizes low noise and high sensitivity.
• The OSD settings can be dynamically switched using the Profile Switching function. With these
functions, two preset profiles can be switched with each other when a Mode Selection terminal has
been controlled or Day/Night switching has been made. A combination of profiles can be selected
according to surveillance conditions.
• Day/Night function provides a high-sensitivity black and white image in low light conditions (e.g., night
time) by automatically switching the camera to black and white mode. The camera is automatically
switched to color mode in brighter light conditions (e.g., day time).
• This product offers additional functions such as Stabilizer, Privacy Mask, and Motion Detection
functions.
• Long-distance transmission is possible using UTP (Unshielded Twisted Pair) cable.
(Use a receiver produced by NVT) (ZC-YX270PU, ZC-YXW270PU)

EG-3
SAFETY PRECAUTIONS
The installation should be made by a qualified service person and should conform to all local
codes.
For this device provided no power switch, the installation shall be carried out in accordance
with the rules of the country or the region in which the equipment is to be installed.
This symbol indicates that there is a possibility of death or damage to operator or others.
(1) Use only 24V AC power supply marked class 2 or +12V DC regulated power supply marked class 2.
(ZC-YX270P, ZC-NX270P, ZC-YXW270P, ZC-NXW270P)
(2) Use only with a 230 V AC power supply.
(ZC-YX270PE, ZC-NX270PE, ZC-YXW270PE, ZC-NXW270PE)
(3) Be sure to connect each lead to the appropriate terminal. Wrong connection may cause malfunction and/or
damage to the video camera.
(4) Never attempt to disassemble or modify the camera.
(5) If an abnormality should occur, immediately turn off the power and consult your dealer.
(6) To prevent fire or electric shock, do not expose this product to rain or moisture.
(7) Never remove the cover. This may cause fire or electric shock.
This symbol indicates that there is a possibility of injury or damage to equipment.
(1) Do not attempt to aim the camera at the sun or other extremely bright objects that cause smear to appear
irrespective of whether the camera is operating or not. This can damage the CCD (Charge Coupled
Device).
(2) Do not place the camera in the following locations.
1 Locations subject to extremely high or low temperatures.
(Operating temperature range: -10°C to +50°C {14°F to 122°F})
(Storage temperature range: -20°C to +60°C {-4°F to 140°F})
2 Locations subject to high levels of humidity and dust.
(Operating humidity range: max 85% {No condensation})
(Storage humidity range: max 95% {No condensation})
3 Locations where there are large amounts of water vapor and steam.
(3) Ensure the location selected is sufficiently strong enough to support the weight of the camera and is free
from vibration.
(4) When this camera is installed near equipment that emits a strong electromagnetic field, some irregularity
such as noise on the monitor screen may happen.
(5) Do not allow the camera to be subjected to strong impacts or shocks. The camera could be damaged by
improper handling or storage.
(6) When plugging the power cord into an electric outlet, be sure to leave enough space around the outlet so
that it will easy to unplug the power cord.
(ZC-YX270PE, ZC-NX270PE, ZC-YXW270PE, ZC-NXW270PE)
The CE Marking is a Directive Conformity mark of the European Union (EU).
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste
stream via designated collection facilities appointed by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences for
the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city
office, waste disposal service or the shop where you purchased the product.

EG-4
PART NAMES AND FUNCTIONS
12 V DC/24 V AC / Model with communication function
LOCK
IRIS
UP
LEFT RIGHT
DOWN
MENU
GND
RS485
TERM
MODE-SEL
B/W-FIX
VIDEO
ON OFF A+ A- B+ B-
DC VIDEO
IRIS
RS485
MODE-SEL
B/W-FIX
GND
A+ A- B+ B-
RS485
MODE-SEL
B/W-FIX
GND
A+ A- B+ B-
GND+12VDC
AC24V
1
2
3
4
56 7
8
9
bk
AC230V / Model with communication function
UP
LEFT RIGHT
DOWN
MENU
VIDEO
GND+12VDC
AC24V
DC VIDEO
IRIS
UTP BNC
UTP
+-
RS485
TERM
MODE-SEL
B/W-FIX
VIDEO
ON OFF A+ A- B+ B-
DC VIDEO
IRIS
UP
LEFT RIGHT
DOWN
MENU
AC230V
GND
6
6
b
b
NVT Model
Power plug

EG-5
1 Flange back adjustment wheel
If the focus needs to be adjusted after the
lens has been mounted, loosen the flange
back locking screw (2) and rotate the
adjustment wheel to adjust.
2 Flange back lock screw
Loosen this screw for flange back
adjustment. Be sure to retighten the screw
after adjustment.
3 Auto-Iris mode switch
For switching the output from the auto-iris
connector (7).
:
When connecting the auto-iris lens, turn off
the camera power. Also, if the Auto-Iris mode
switch is set to a mode other than “DC” or
“VIDEO” that is set for the connecting lens,
the lens may be damaged.
DC : To be set when using a non-amp
auto-iris lens.
VIDEO : To be set when using an auto-iris
lens a built-in amp.
4 Menu Operation Switch
To adjust settings in the OSD menu, press
and hold down the Menu Operation Switch.
The OSD menu appears, and here you can
adjust various settings using this switch.
UP
LEFT RIGHT
DOWN
MENU
Menu Operation Switch
• Pressing the switch in the UP/DOWN/
LEFT/RIGHT direction moves the cursor
and allows you to select an item.
• Press the Menu Operation Switch to
confirm the item you have selected.
* For details, please see the separate “OSD
Operation Manual.”
Video iris lens adjustment
While using a video iris lens, make sure
to make this adjustment. Activate the
adjustment screen of the video iris lens by
selecting “Setup”  “Lens” in the OSD menu.
To adjust the brightness, turn the “LEVEL”
volume control to “L” or “H” until “LEVEL VR
Position: OK” appears on the OSD screen.
When the adjustment is completed, close the
OSD menu.
* For details, please see “Video-Iris LEVEL
VR Setup” of the separate “OSD Operation
Manual.”
:
• Make sure to adjust the lens in a bright
light environment.
• Make sure to set the ALC adjustment
volume of the lens to the Average (AV)
end.
Easy focus adjustment
Make sure to adjust focus in a bright light
environment. With the OSD screen not
displayed, activate the focus adjustment
screen by pressing and holding down the
Menu Operation Switch in the UP direction
(Jump function). You can also activate the
focus adjustment screen by selecting “Setup”
 “EZ Focus” in the OSD menu. The lens iris
is forcibly kept open while this screen is being
displayed. The focus can be easily adjusted
by using focus adjustment assisting functions
such as edge enhancement, focus level bar
indication, and screen view zoom-up/down
enabled by pressing the Menu Operation
Switch in the left/right direction. When the
adjustment is completed, close the OSD
menu.
* For details, please see “EZ Focus Menu”
of the separate “OSD Operation Manual.”

EG-6
5 Video output connector
Connected to the TV monitor with a coaxial
cable.
6 Power input terminal
(when using 12 V DC/24 V AC)
This model can use 24 V AC and 12 V DC.
:
Use only with a 24 V AC power supply
marked class 2 or +12 V DC power supply.
12V DC connection
24V AC connection
When connecting to a terminal
When connecting a cable to a power cable
terminal (AWG16-24), peel off the cable by
11 mm from the end.
11 mm
Power cable (when using 230V AC)
AC Power Cord : Use AC230 V, 50Hz.
(ZC-YX270PE, ZC-NX270PE,
ZC-YXW270PE, ZC-NXW270PE)
TERM
B/W-FIX
GND
VIDEO
ON OFF
A+ A- B+ B-
AC230V
Power plug
AC230V cable
:
Use only with a 230V AC.
7 Auto-iris output connector
For connecting the cable of an auto-iris lens,
the pin assignment is as shown below. (While
using the auto-iris lens, set the Auto-iris
Mode switch (3) to “DC” or “VIDEO”
depending on the type of lens used.)
No. DC VIDEO
1 CONTROL- +9.4V (max. 50 mA)
2 CONTROL+ N. C.
3 DRIVE+ VIDEO
4 DRIVE- GND
8 B/W Fix terminal/Mode Selection terminal
This terminal can be used as a B/W Fix
terminal and also as a Mode Selection
terminal that enables the dynamic switching
of OSD settings. The mode selection setting
needs to be adjusted beforehand on the
OSD setting screen. The picture mode can
be fixed at B/W by shorting the two contacts
on the B/W Fix terminal. (See the back side
of the camera on page 3.) Fixing the picture
mode at B/W can prevent the picture from
having a phenomenon in which continuous
switching occurs between the color mode
and B/W mode under infrared illumination.
The Mode Selection terminal allows switching
between Profile 1/Profile 2 selected on the
OSD screen.
When using infrared illumination, make sure
to adjust the focal point of the lens in color
mode.
If excessive infrared illumination causes the
phenomenon above, set the picture mode at
B/W using the BW Fix terminal.

EG-7
9 RS485 communication terminal
(with communication function)
The RS485 communication function enables
remote operation of the OSD function.
* For initial settings of the camera for RS485
communication, please see “RS485 Menu”
of the separate “OSD Operation Manual.”
When connecting to a terminal
While connecting a shielded twisted pair
cable to a terminal [B/W Fix terminal,
Communication terminal (AWG22-26)], peel
off the cable by 9 mm from the end.
9 mm
bk Termination resistance switch
(with communication function)
TERM
AC24V
ON OFF A+
Termination
resistance switch
During the RS485 communication
connection, turn on the termination resistance
switch of the camera connected at the end
of the cable, and turn off all other switches.
Adjust the characteristic impedance of the
cable used to the same level as that of the
termination resistance (120 Ω).
b
Video output terminal
(ZC-NX270PU, ZC-NXW270PU)
Connected to the NVT Receiver using a UTP
cable (AWG 22 to 24).
b
UTP/BNC video output select switch
(ZC-NX270PU, ZC-NXW270PU)
For switching the video output.
• When I use video output connector (5),
please set it in BNC.
• When I use video-out (b), please set it in
UTP.
VIDEO
DC VIDEO
IRIS
ＵＴＰ
UTP BNC
＋
－
UTP/BNC video
output select switch

EG-8
CAMERA MOUNTING
The camera can be attached to a tripod, fixer or other mounting device from either the top or
bottom side by using the mounting screw holes (1/4-inch, 20 UNC) of the tripod set base plate.
The tripod set base plate can be moved by first removing the two screws and then attaching
the base plate to the top or bottom.
Top attachmentBottom attachmentMoving the tripod set
base plate
:
Use of longer screws can damage the camera and use of shorter screws can result in falling.
EXTERNAL DIMENSIONS
LOCK
IRIS
LOCK
IRIS
119.4
108.4
60
46 54
UP
LEFT RIGHT
DOWN
MENU
RS485 DC VIDEO
IRIS
TERM
MODE-SEL
B/W-FIX
GND
VIDEO
GND+12VDC
AC24V
ON OFF A+ A- B+ B-
RS485
TERM
MODE-SEL
B/W-FIX
VIDEO
ON OFF A+ A- B+ B-
DC VIDEO
IRIS
UP
LEFT RIGHT
DOWN
MENU
AC230V
GND
UP
LEFT RIGHT
DOWN
MENU
VIDEO
GND+12VDC
DC VIDEO
IRIS
UTP BNC
UTP
+-
AC24V
DC12V/AC24V/Model
with communication
function
True Day & Night model
Digital Day & Night model
NVT Model AC230V / Model
with communication
function

EG-9
MODEL DESCRIPTION
R; RS-485 Communication (Manufacturer’s Option)
E; AC230V, U; UTP (Un-shield Twisted Pair cable) or None; DC12V / AC24V
W; WDR (Wide Dynamic Range) or None; EDR (Extended Dynamic Range)
N; True Day/Night or Y; Digital Day/Night
ZC-YX270P ; EDR, Digital Day/Night
ZC-YXW270P ; WDR, Digital Day/Night
ZC-NX270P ; EDR, True Day/Night
ZC-NXW270PER

EG-10
SPECIFICATIONS
EDR Type
Digital Day/Night model True Day/Night model
Model No. ZC-YX270P ZC-YX270PE ZC-YX270PU ZC-NX270P ZC-NX270PE
TV system PAL
Scanning system 2:1 Interlace
Image sensor 1/3-type Interline transfer CCD
Effective pixels 976 (H) × 582 (V)
Scanning frequency 15.625kHz (H) / 50.0Hz (V)
Video output 1.0V (p-p) / 75ΩBNC 1.0V(p-p)/
75 Ω/UTP
1.0V (p-p) / 75Ω
Horizontal resolution 700 TVL
Min. Illuminance
F1.2
Night mode
AGC Extreme
50IRE SENS UP: OFF
0.3 lx (Color) / 0.03 lx (B/W) 0.07 lx (Color) / 0.007 lx (B/W)
SENS UP: ON (x512) 0.0006 lx (Color) / 0.00006 lx (B/W) 0.00014 lx (Color) / 0.000015 lx (B/W)
30IRE SENS UP: OFF 0.15 lx (Color) / 0.015 lx (B/W) 0.035 lx (Color) / 0.0035 lx (B/W)
SENS UP: ON (x512) 0.0003 lx (Color) / 0.00003 lx (B/W) 0.00007 lx (Color) / 0.000007 lx (B/W)
S/N ratio More than 50dB (At AGC Off)
Gamma characteristic 0.45
Sync. System Internal synchronization (INT.) / Line Lock (L.L.)
Electronic shutter Electronic shutter ON: 1/50 s to 1/100,000 s.
* The shutter speed ranging from 1/1,000 s to 1/5,000 s can be set by 1/500 s.
1/50 sec. fixed (Flickerless: OFF), 1/120 sec. fixed (Flickerless: ON)
Iris control DC IRIS DC-drive auto-iris lens
AES Fixed iris lens (1/50-1/100,000 sec. automatic electronic shutter)
AIC Control of electronic shutter and iris (1/50-1/100,000 sec.)
VIDEO IRIS Video-drive auto-iris lens
Vcc = 9.4 V DC, 50mA max, video signal: 0.7V (p-p) (high impedance)
Extended Dynamic Range (EDR) ON / OFF
Backlight Compensation (BLC) ON / OFF
White balance ATW (Normal / Wide) / AWB / Manual
SENS UP ON: Auto (x2 to x512) / OFF
Day/Night setting Auto / Color Fix / B/W Fix
Noise Reduction (2D/3D-DNR) Extreme / High / Middle / Low
Electronic zoom ON (16 times max.) / OFF
Defog Image correction ON / OFF
Profile setting standard / high sensitivity / casino / sodium vapor lamp / profile
AGC ON (Extreme / High / Middle / Low) / OFF
ALC -20 to +20
HLC Detection level: 1-3 steps
Easy focus Enabled
Privacy Mask ON (16 spots max., 10 colors, mosaic) / OFF
Motion detection Detects all areas. 6 (horizontal) × 4 (vertical),
24 pixels in total (minimum block), sensitivity (1–10)
Stabilizer ON / OFF
Monitor output mode CRT / LCD
Communication function
RS485 communication, half duplex (models
with communication function only)
- RS485 communication, half duplex (models
with communication function only)
Power source 24 V AC ± 10%
(50/60 Hz ± 1 Hz)
or 12 V DC ± 10%
230 V AC ±10%
(50Hz ± 1Hz)
24 V AC ± 10%
(50/60 Hz ± 1 Hz)
or 12 V DC ± 10%
24 V AC ± 10%
(50/60 Hz ± 1 Hz)
or 12 V DC ± 10%
230 V AC ±10%
(50Hz ± 1Hz)
Power consumption 12 V DC 260mA - 260mA 260mA -
24 V AC 220mA, 3.1W - 220mA, 3.1W 220mA, 3.1W -
230 V AC - 25mA, 3.6W - - 25mA, 3.6W
Operating temperature/humidity -10°C to +50°C, 85% or lower humidity (no condensing)
Storage temperature/humidity -20°C to +60°C, 95% or lower humidity (no condensing)
External dimensions 60 (W) x 54 (H) x 119.4 (D) mm
Weight 320g 600g 330g 320g 600g
Input/Output
terminals
Video output BNC BNC / 2p terminal BNC
Auto-iris terminal 4P connector (D4-157J-250/equivalent)
Power supply terminal 2P screwless
terminal block
AWG16-24
2-core 2.0m cord 2P screwless
terminal block
AWG16-24
2P screwless
terminal block
AWG16-24
2-core 2.0m cord
B/W Mode-Fix terminal
2P screwless terminal block AWG22-26 - 2P screwless terminal block AWG22-26
RS485 communication terminal 4P screwless terminal block AWG22-
26 (models with communication
function only)
- 4P screwless terminal block AWG22-
26 (models with communication
function only)
UTP terminal - 2P screwless
terminal block
AWG22-26
-
Adjustment switch OSD switch Push-button switch with 5 contact points (in 4 directions and at a central point)
Iris mode switching switch Slide switch
Termination resistance switch Slide switch (models with
communication function only)
- Slide switch (models with
communication function only)
UTP/BNC switching switch - Slide switch -
Accessories OSD Operation Manual, Instruction manual (this document)
* The specifications and/or appearance of the product may change without a prior notice.

EG-11
WDR type
Digital Day/Night model True Day/Night model
Model No. ZC-YXW270P ZC-YXW270PE ZC-YXW270PU ZC-NXW270P ZC-NXW270PE
TV system PAL
Scanning system 2:1 Interlace
Image sensor 1/3-type Interline transfer CCD
Effective pixels 976 (H) × 582 (V)
Scanning frequency 15.625kHz (H) / 50.0Hz (V)
Video output 1.0V (p-p)/75ΩBNC 1.0V(p-p)/
75 Ω/UTP
1.0V (p-p)/75Ω
Horizontal resolution 700 TVL
Min. Illuminance
F1.2
Night mode
AGC Extreme
50IRE SENS UP: OFF
0.3 lx (Color) / 0.03 lx (B/W) 0.07 lx (Color) / 0.007 lx (B/W)
SENS UP: ON (x512) 0.0006 lx (Color) / 0.00006 lx (B/W) 0.00014 lx (Color) / 0.000015 lx (B/W)
30IRE SENS UP: OFF 0.15 lx (Color) / 0.015 lx (B/W) 0.035 lx (Color) / 0.0035 lx (B/W)
SENS UP: ON (x512) 0.0003 lx (Color) / 0.00003 lx (B/W) 0.00007 lx (Color) / 0.000007 lx (B/W)
S/N ratio More than 50dB (At AGC Off)
Gamma characteristic 0.45
Sync. System Internal synchronization (INT.) / Line Lock (L.L.)
Electronic shutter Electronic shutter ON: 1/50 s to 1/100,000 s.
* The shutter speed ranging from 1/1,000 s to 1/5,000 s can be set by 1/500 s.
1/50 sec. fixed (Flickerless: OFF), 1/120 sec. fixed (Flickerless: ON)
Iris control DC IRIS DC-drive auto-iris lens
AES Fixed iris lens (1/50-1/100,000 sec. automatic electronic shutter)
AIC Control of electronic shutter and iris (1/50-1/100,000 sec.)
*The WDR mode is 1/50-1/500 sec.
VIDEO IRIS Video-drive auto-iris lens
Vcc = 9.4 V DC, 50mA max, video signal: 0.7V (p-p) (high impedance)
Wide Dynamic Range (WDR) Max 82dB
Backlight Compensation (BLC) ON / OFF
White balance ATW (Normal / Wide) / AWB / Manual
SENS UP ON: Auto (x2 to x512) / OFF
Day/Night setting Auto / Color Fix / B/W Fix
Noise Reduction (2D/3D-DNR) Extreme / High / Middle / Low
Electronic zoom ON (16 times max.) / OFF
Defog Image correction ON / OFF
Profile setting standard / high sensitivity / casino / sodium vapor lamp / profile
AGC ON (Extreme / High / Middle / Low) OFF
ALC -20 to +20
HLC Detection level: 1-3 steps
Easy focus Enabled
Privacy Mask ON (16 spots max., 10 colors, mosaic) / OFF
Motion detection Detects all areas. 6 (horizontal) × 4 (vertical),
24 pixels in total (minimum block), sensitivity (1–10)
Stabilizer ON / OFF
Monitor output mode CRT / LCD
Communication function
RS485 communication, half duplex (models
with communication function only)
- RS485 communication, half duplex
(models with communication function only)
Power source 24 V AC ± 10%
(50/60 Hz ± 1 Hz)
or 12 V DC ± 10%
230 V AC ±10%
(50Hz ± 1Hz)
24 V AC ± 10%
(50/60 Hz ± 1 Hz)
or 12 V DC ± 10%
24 V AC ± 10%
(50/60 Hz ± 1 Hz)
or 12 V DC ± 10%
230 V AC ±10%
(50Hz ± 1Hz)
Power consumption 12 V DC 310mA - 310mA 310mA -
24 V AC 250mA, 3.7W - 250mA, 3.7W 250mA, 3.7W -
230 V AC - 30mA, 5.1W - - 30mA, 5.1W
Operating temperature/humidity -10°C to +50°C, 85% or lower humidity (no condensing)
Storage temperature/humidity -20°C to +60°C, 95% or lower humidity (no condensing)
External dimensions 60 (W) x 54 (H) x 119.4 (D) mm
Weight 320g 600g 330g 320g 600g
Input/Output
terminals
Video output BNC BNC / 2p terminal BNC
Auto-iris terminal 4P connector (D4-157J-250/equivalent)
Power supply terminal 2P screwless
terminal block
AWG16-24
2-core 2.0m cord 2P screwless
terminal block
AWG16-24
2P screwless
terminal block
AWG16-24
2-core 2.0m cord
B/W Mode-Fix terminal
2P screwless terminal block AWG22-26 - 2P screwless terminal block AWG22-26
RS485 communication terminal 4P screwless terminal block AWG22-
26 (models with communication
function only)
- 4P screwless terminal block AWG22-
26 (models with communication
function only)
UTP terminal - 2P screwless
terminal block
AWG22-26
-
Adjustment switch OSD switch Push-button switch with 5 contact points (in 4 directions and at a central point)
Iris mode switching switch Slide switch
Termination resistance switch Slide switch (models with
communication function only)
- Slide switch (models with
communication function only)
UTP/BNC switching switch - Slide switch -
Accessories OSD Operation Manual, Instruction manual (this document)
* The specifications and/or appearance of the product may change without a prior notice.

176-1.0
