ICT MP306 User manual

DocRef: Ver1.3
MP306 Moisture Probe
Operation Manual
ICT International Pty Ltd
PO Box 503
Armidale NSW 2350
AUSTRALIA
Phone: [61] 2-6772-6770
Fax: [61] 2-6772-7616
Email: [email protected]
Web: www.ictinternational.com

MP306 Moisture Probe Operation Manual
TABLE OF CONTENTS PAGE
1. Introduction......................................................3
2. Operation .......................................................3
2.1 HandHeldMoistureProbeMeter.................................3
2.2 Data Logging or Irrigation Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.2.1General.................................................3
2.2.2Installation ..............................................3
2.2.3CableLength.............................................4
2.2.4Power ..................................................4
2.3 TheoryofOperation ...........................................4
2.3.1Theory..................................................4
2.3.2Results..................................................5
 2.3.3Denitions...............................................6
2.4 Calibration...................................................7
2.4.1General.................................................7
2.4.2LinearCalibration.........................................7
2.4.3PolynomialCalibration.....................................7
2.4.4PolynomialLookupTable...................................8
2.5 Wiring......................................................8
2.6 TechnicalSpecications ........................................9
2.6.1MechanicalDiagram.......................................9
 2.6.2ElectricalandMechanicalSpecications .......................9
LIST OF FIGURES PAGE
1. MP306 Measurement of Absolute Volumetric Soil Water Percent. . . . . . . . . . . . 5
2. MP306 in comparison to TDR Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3. Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

MP306 Moisture Probe Operation Manual
1. Introduction
The MP306 Moisture Probe can be used to measure the moisture content in many materials such as soil,
food and materials used in roadway and building construction.
The MP306 can be used to measure the soil moisture for scientific research or irrigation management. In
either situation the MP306 can:
-rapidly measure the soil moisture by pushing the needles of the sensor into the soil surface or soil profile;
-make measurements over time by permanently burying the MP306 and connecting it to a data logger;
-control irrigation by permanently burying the MP306 and connecting it into an irrigation controller.
2. Operation
2.1 Hand Held Moisture Probe Meter
The MP306 has a connector which plugs directly into the MPM-160 hand held meter for direct readout.
The meter provides the power to the MP306 for the reading, display and storage of measurements. The
returned mV signal is displayed directly as mV and is also converted and displayed as Volumetric Water
Content (VSW%). Refer to section 2.4.4 for the conversion table.
When being used with a hand held meter the MP306 is usually connected to a set of chrome extension rods
which have a T handle on the end.
The extension rods enable the operator to insert the needles of the MP306 into the soil surface without
bending over, and then more conveniently read the MPM-160 meter.
2.2 Data Logging or Irrigation Control
2.2.1 General
The MP306 exterior is made from extremely durable ABS plastic formed into a custom designed tube. The
electronics is totally sealed within this tube. The needles are made from high quality stainless steel. Then the
MP306 can be buried permanently at a location as part of either an input to a data logging system or for an
input to an irrigation controller or environmental monitoring system.
2.2.2 Installation
The MP306 can be installed by drilling a close fitting hole into the soil profile, either at an angle or
vertically or it can be installed horizontally from a larger augered hole or soil pit. In all situations care must
be taken to ensure the needles are in contact with soil profile after installation. It is usual practice to install
the MP306 with the 3 needles in a horizontal plane in order to maximise the measurement of soil spatial
variability. The MPM-160 meter should be used during the installation process to ensure good contact of the
needles and the soil is maintained during back filling of the hole.

MP306 Moisture Probe Operation Manual
2.2.3 Cable Length
The standard cable length is 4.5 m. This may be extended by using suitable cable.
Multi Core Polypropylene Insulated Irrigation Control Cable, specifications 9 core (9 x 7/0.30) has been
tested successfully over 500 m. Two wires were connected for power supply positive from the data logger to
the MP306.
2.2.4 Power
The MP306 is normally powered by a voltage in the range 7.0 to 18.0 volts using 18 mA of power. It can
function satisfactorily within the voltage limits of 7.0 to 18.0 volts provided 18 mA is maintained.
1 x MP306 = 32 mA (maximum power use)
5 seconds of warmup/hour = 5/3600 x 32 = 0.04 mAh
Total of 16 x MP306 = 16 x 0.04 mAh = 0.64 mAh
Logging for 24 hours on an hourly frequency = 0.64 x 24 = 15.36 mAh/day
Gel Cell Battery 7 Ah capacity. Then = 7/0.01536 = 455 days
In other words a Gel Cell battery is capable of supplying enough power for about 455 days. The battery
would need to be recharged within about 30 days as it will self discharge in this time.
2.3 Theory of Operation
2.3.1 Theory
The MP306 has a high frequency moisture detector which uses the standing wave principle to indicate
the ratio of two or more substances forming a body of material, each substance having a different electric
constant (Ka).
The moisture measurement of the material is based upon the fact that in a water: soil: air matrix, the
dielectric constant is dominated by the amount of water present. The dielectric constant of water is
approximately equal to 80 whereas the dielectric constant of soil is approximately equal to 3 or 4 and air is
equal to 1. Therefore any changes in the volume matrix ratio of water will result in a substantial change in
the dielectric constant of the matrix. Then the soil water content can be measured exactly because changes in
water content of the soil result in changes in the dielectric constant of the soil.
The material that can be measured by the MP306 is often soil but can be any composition of non-metallic
powdered, liquid or solid phase substance into which the needles are inserted.

MP306 Moisture Probe Operation Manual
2.3.2 Results
The results from measurement of absolute volumetric soil water percent (VSW%) from prepared soil
samples using the MP306 are given in Figure 1. This result is typical of the results obtained from
comparative testing of the MP306 in prepared soil samples, for a wide range of agricultural soils.
MP306
OVEN
0 5 10 15 20 25 30 35 40
Soil Sample Volumetric
Soil Water (%)
MP306 = 1.0136x + 0.4298
R2=0.9931
Figure 1. MP306 Measurement of Absolute Volumetric Soil Water Percent from Prepared
Soil Samples as a Standard.
Volumetric Soil Water (%)
MP306 Measurement of VSW%
Using Soil Samples as a Standard
40
35
30
25
20
15
10
5
0

MP306 Moisture Probe Operation Manual
The results from measurement of the absolute volumetric soil water percent (VSW%) using the MP306
when compared with TDR technology are given in Figure 2. This result is typical of the results obtained
from comparative testing of the MP306 compared to TDR technology for a wide range of agricultural soils.
MP306
TDR
0 5 10 15 20 25 30 35 40
TDR Volumetric Soil Water (%)
Figure 2. The MP306 in comparison to TDR Measurement of Absolute Volumetric Soil Water Percent as
a Standard.
2.3.3 Definitions
Gravimetric Soil Water Content is defined as
θG = Mw Where Mw is the mass of water in the soil sample
Ms and Ms is the total mass of the dry soil sample.
VolumetricSoilMoistureContentisdenedas
θV = θG * Ps Where Ps is the bulk density of the soil sample ( = Ms )
( Vs )
Where Ms is the total mass of the dry sample and
Vs is the total volume of the dry soil sample.
Volumetric Soil Water Percent (VSW%)
VSW% = θv * 100
The VSW%typicallyvariesintheeldfrom2–5%forsandysoilsatpermanentwilting
pointto45–55%forclaysoilsatsaturation.
Volumetric Soil Water (%)
A Comparison of the MP306 and TDR
as a Standard
40
35
30
25
20
15
10
5
0

MP306 Moisture Probe Operation Manual
2.4 Calibration
2.4.1 General
The results obtained from measurement of the absolute volumetric soil water content (VSW%) using the
MP306 are expected to be within ± 2–5% of the actual soil moisture as determined in the laboratory by
gravimetric and volumetric methods of determination. Recalibration is not expected to be necessary for most
applications in most commonly occurring agricultural soils. This is especially so when it is considered that
for practical end uses such as irrigation scheduling and irrigation control the change in VSW% is the most
important variable to be determined for management decision making. The change measured will be correct
in absolute VSW% units or mm of water applied as the relationship of voltage output to water content,
hence calibration slope remains constant, across all soil types.
Scientists or regulatory authorities may wish to calibrate the MP306 to verify the data measured. In these
cases it is simply necessary to compare the MP306 output in mV (0–1 mV) to the VSW% from the soil
samples, either prepared in the laboratory or obtained in the field. The resultant regression of these variables
will provide the new calibration of the MP306. As all MP306 respond to changes in water content of the soil
and the resultant changes in the dielectric constant in the same way the calibration would apply to all
MP306.
Data Loggers variously are able to store linear, polynomial or polynomial lookup tables depending on their
specifications. Then various forms of the MP306 soil calibration are supplied for these data loggers.
2.4.2 Linear Calibration
VSW% = a + b χ
= INTERCEPT + SLOPE (χ)
= -0.1552 + 0.80829 (χ)
Where χ = MP306 output in volts
{Output Range of MP306
{Limits of VSW
0≤MP306≤1.20V
0≤VSW<1.00
2.4.3 Polynomial Calibration
VSW% = ao+ a1χ+ a2χ2+ a3χ3
= -0.05334 + 1.19650χ– 2.5356χ2+ 1.9961χ3
Where χ = MP306 output in volts
{Output Range of MP306
{Limits of VSW
0≤MP306≤1.20V
0≤VSW<1.00

MP306 Moisture Probe Operation Manual
2.4.4 Polynomial Lookup Table
Linearisation tables can be added to Data Loggers using the following data:
A: Conversion Table for MP-306 - From VSW% to mV & mA in mineral soil.
2.5 Wiring
The MP306 is supplied with 4.5 m of four core shielded wire.
Wiring
Red = 7-16V DC
Blue and shield = Analogue Ground
(Signal Return)
Yellow = signal +
Black = DC Ground
VSW% mV MP-306 mA MP-306 VSW% mV MP-306 mA MP-306
0.0 4.00 55.00 1015 18.50
120 5.71 60.00 1025 18.64
--5.0
2.00
5.00 210 6.99 65.00 1035 18.785
10.00 310 8.43 70.00 1045 18.93
15.00 415 9.93 75.00 1055 19.07
20.00 510 11.285 80.00 1065 19.21
25.00 610 12.71 85.00 1070 19.28
30.00 720 14.285 90.00 1080 19.43
35.00 825 15.785 95.00 1095 19.64
40.00 895 16.785 100.00 1120 20.00
45.00 955 17.64 105.00 2090
50.00 1005 18.35
B: Polynomial Lookup Table for Organic and Mineral Soil
Soil moisture
3

v, m3.m-
mV,
organic
soil
mV,
mineral
soil
soil moisture
3

v, m3.m-
mV,
organic soil
mV,
mineral soil
--0.0 --209 --209 0.55 985 1015
0 50 120 0.6 1010 1025
0.05 140 210 0.65 1020 1035
0.1 230 310 0.7 1030 1045
0.15 320 415 0.75 1045 1055
0.2 415 510 0.8 1055 1065
0.25 500 610 0.85 1070 1070
0.3 600 720 0.9 1080 1080
0.35 700 825 0.95 1095 1095
0.4 800 895 1.0 1106 1106
0.45 875 955 1.05 2090 2090
0.5 940 1005

MP306 Moisture Probe Operation Manual
2.6 Technical Specifications
2.6.1 Mechanical Diagram
130 mm 60 mm
Figure 3. Mechanical Dimensions
2.6.2 Electrical and Mechanical Specifications
MeasurementRange 0–100VSW%
Accuracy 2VSW%aftercalibrationtoaspecicsoiltype,
or 5 VSW% using the supplied soil calibration
Interface Inputrequirements:7–18VDCunregulated
Power consumption: 32 mA typical
Outputsignal:0–1Vfor0–50VSW%
Response Time Less than 0.5 seconds
Stabilisation Time
5 seconds approximately from power-up
Mechanical Total length 215 mm. Diameter 40 mm
Needle length 60 mm, needle separation 14 mm
Exterior ABS Plastic
Needles Stainless Steel
Cable 4.5 m Standard
Environment Designed for permanent burial
ICT International Pty Ltd
PO Box 503, Armidale NSW 2350, Australia
Tel [61] 2-6772-6770 Fax [61] 2-6772-7616
Email: [email protected]
Email: www.ictinternational.com
14 mm
14 mm
