Icy Box IB-MP3010HW Instruction manual

IB-MP3010HW
HDD and Network-Recorder and
Multimedia-Player
Key Features
• Multimedia-Player with recording function
• HDD support: 3.5" SATA
• 5 adjustable recording quality level: HQ/SP/LP/EP/SLP
• Time shift function with Video in
• File System: FAT32, NTFS (read only)
• Network streaming by LAN 10/100 Mbps, RJ-45 or
WLAN 54 Mbps by delivered ICY BOX USB dongle (Samba protocol)
• Supports subtitle formats like SRT, SSA, SMI, SMI, IDX/SUB, SUB
• Audio Output: Stereo L/R, SPDIF (coaxial/optical)
• Video Output: Composite, Component, HDMI
• TV system: NTSC/PAL
• USB 2.0 up to 480 Mbit/s
• Supports Windows 98/XP/Vista, MAC OS
• Remote control
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: [phone] – 468 900 (Vertrieb) • Fax: [phone] – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Technical Data
Model IB-MP3010HW
Article No. 25311
EAN Code 4250078184133
Colour black
Brand name ICY BOX
Article text HDD and Network-Recorder and Multimedia-Player
Processor Realtek 1262
Video formats MPEG-1, MPEG-2, MPEG-4: AVI, MPG, VOB, IFO,
DAT, MPEG2 TS, XviD
Recording formats MPEG2 up to 720x576@25 fps (PAL),
720x480@30 fps (NTSC)
Subtitle formats SRT, SSA, SMI, IDX/SUB, SUB
Audio formats MP3: up to 320Kbps, WMA: up to 192Kbps, OGG
Picture formats JPG/JPEG, BMP
Network support LAN 10/100 Mbps, RJ-45, LAN 10/100 Mbps, RJ-45,
WLAN 54 Mbps (only by delivered ICY BOX USB dongle)
Network protokol SAMBA (SMB)
Dateisystem FAT32, NTFS (read only)
HDD interface 3.5" SATA
External data interface 2x USB 2.0 Host, 1x USB 2.0 to PC
External video
interface output Composite, Component, HDMI
External video interface
input (recording) Composite
External audio interface
output Stereo L/R, SPDIF (coaxial/optical)
External audio interface
input (recording) Stereo L/R
Power supply AC 100~240 V, 50~60 Hz, 35 W, DC 12 V, 3 A
Record your favourite
TV program or movies
from TV, Video-DVD player
and set top box!
(only by composite)

RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: [phone] – 468 900 (Vertrieb) • Fax: [phone] – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Logistical Data
Packing unit: 4 pcs./carton Dimension/carton: 520x325x233 mm Import tax: 84717030
Total weight: 11kg/carton Dimension of packing box: 250x155x210 mm
Gross weight (incl. packing): 2.5 kg/pcs. Dimension of article: 164x52x205 mm
Net weight: 1.08 kg/pcs. Country of origin: China
NEW: ICY BOX IB-MP3010HW
HDD and Network-Recorder and Multimedia-Player
A Good Deal of Recorder plus Player.
The Mix is Right. The Price is Right.
For many customers the ICY BOX IB-MP3010HW is finally the
appropriate network media-player. For a price typical for ICY BOX
they get what's good and useful.
You can record, playback or stream from the inputs of terrestrial
antenna, cable, set-top box, DVD-player and the good old VCR.
With the IB-MP3010HW you will enjoy videos, music and photos
on the main stage. This might be the home entertainment center,
the TV-set or the stereo.
The ICY BOX IB-MP3010HW works in a network environment,
with a 3.5" SATA HDD as the sole source of good entertainment,
or you combine the two – HDD and LAN.
In a network you access the shared multimedia files and drives
via Samba. With a disk drive the IB-MP3010HW becomes a digital
video recorder with time-shift function.
The ICY BOX IB-MP3010HW offers a reasonably composed bundle
of features. You won't miss anything that's indispensable in its
class. And you don't have to pay for features, you don't need.
Packing content
IB-MP3010HW
A/V cable
Y/Pb/Pr cable
SCART adaptor
USB cable
Remote Control
Remote Control Battery
AC adaptor
AC adaptor cable
Wireless LAN USB Adapter
Driver CD
User Manual
Hard Disk Installation Guide
1. STANDBY indicator 4. REC indicator
2. ON indicator 5. Infrared Receiver window
3. MUSIC indicator 6. POWER/STANDBY button
1. DC IN jack 6. A/V OUT jack
2. S/PDIF Optical jack 7. Y/Pb/Pr OUT jack (Components Video)
3. 2x USB HOST port 8. USB Device port
4. HDMI jack 9. RJ45 LAN socket
5. A/V IN jack 10. S/PDIF Coaxial jack
1 2 3 4 5 6
10 9
1 2 3 458
Frontside
Rearside
67
WLAN via
USB Dongle
Illustration similar
