iDataLink COM-AL(RS)-TL2-EN User manual

NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
reviewtheInstallation Guide carefullybefore beginning any work.
!
VERSION FRANÇAISE DISPONIBLE EN LIGNE AU www.idatalink.com
PLEASE VISIT www.idatalink.com/support FOR COMPLETE PRODUCT DETAILS
Automotive Data Solutions Inc.
INSTALL GUIDE
com-al(rs)-tl2-En
availablE for: ads-al ca
TL2
The brand names and logos found in this guide are property of their respective owners. Automotive Data Solutions Inc. © 2013
Rev. Date: February 13, 2013
Doc. No.: ##10870##
20130211

INSTALL TYPE SELECTION
ADS-AL(DL)-TL2 PAGE X-X
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS PUSH TO START CTRL ARM OEM ALARM DISARM OEM ALARM DOOR LOCK DOOR UNLOCK POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) TRUNK/HATCH RELEASE POWER LIFTGATE TACHOMETER OUTPUT BRAKE PEDAL STAT OUTPUT E-BRAKE OUTPUT DOOR STAT OUTPUT TRUNK STAT OUTPUT HOOD STAT OUTPUT*
LEXUS
CT200h PTS 11-13 3 • • • • • • • • • • • • •
GX460 PTS 10-13 2 • • • • • • • • • • • • •
HS250h PTS 10-12 3 • • • • • • • • • • • • •
RX350 PTS 10-13 2 • • • • • • • • • • • • •
RX450h PTS 10-13 2 • • • • • • • • • • • • •
TOYOTA
4Runner PTS 10-13 2 • • • • • • • • • • • • •
Prius PTS 10-13 3 • • • • • • • • • • • • •
Prius V PTS 12-13 3 • • • • • • • • • • • • •
Sienna PTS 11-13 2 • • • • • • • • • • • • • • •
Venza PTS 09-13 1 • • • • • • • • • • • • •
* Available only if vehicle is equipped with factory hood switch.
NOTE
I Keyless and smart-
key systems will
remain functional
during remote start.
Page 2 of 16 COM-AL(RS)-TL2-EN 20130211
INSTALL GUIDE ALL IN ONE
ToyoTa/Lexus
Guides Français disponibles au www.idatalink.com
WWW.IDATALINK.COM/SUPPORT Automotive Data Solutions Inc. © 2013
Doc. No.: ##10870##

COMPONENT LOCATOR
XX-XX PAGE X-XADS-AL(DL)-TL2 PAGE X-X
AB
D
C
Page 3 of 16 COM-AL(RS)-TL2-EN 20130211
INSTALL GUIDE ALL IN ONE
ToyoTa/Lexus
Guides Français disponibles au www.idatalink.com
WWW.IDATALINK.COM/SUPPORT Automotive Data Solutions Inc. © 2013
Doc. No.: ##10870##

XX-XX PAGE X-X
WIRE CROSS REFERENCE CHART
XX-XX PAGE X-X
TYPE 1 - WIRE CROSS REFERENCE CHART
ADS-AL(DL)-TL2 T1 PAGE X-X
MAKE MODEL YEAR WIRE DESCRIPTION
CONNECTOR
POSITION WIRE COLOR POLARITY LOCATION COMPONENT LOCATOR NAME COLOR TYPE
TOYOTA
Venza
PTS 09-13
CanH D1 ~ 16 pin 06 Yellow (DATA) OBDII D
CanL D1 ~ 16 pin 14 White (DATA) OBDII D
12V D17 ~ 07 pin 07 Pink (+) Black connector at steering lock B
Ignition D17 ~ 07 pin 06 LtGreen (+) Black connector at steering lock B
SLP D17 ~ 07 pin 04 Violet (-) Black connector at steering lock B
TX D49 ~ 28 pin 22 Blue (DATA) Main body ECU, back side A
RX D49 ~ 28 pin 23 Black (DATA) Main body ECU, back side A
Parking D50 ~ 26 pin 23 Red (-) Main body ECU, back side A
Push D13 ~ 14 pin 07 Blue (-) Push to start button C
Page 4 of 16 COM-AL(RS)-TL2-EN 20130211
INSTALL GUIDE ALL IN ONE
ToyoTa/Lexus
Guides Français disponibles au www.idatalink.com
WWW.IDATALINK.COM/SUPPORT Automotive Data Solutions Inc. © 2013
Doc. No.: ##10870##

TYPE 1 - WIRING DIAGRAM
Page 5 of 16 COM-AL(RS)-TL2-EN 20130211
INSTALL GUIDE ALL IN ONE
ToyoTa/Lexus
Guides Français disponibles au www.idatalink.com
WWW.IDATALINK.COM/SUPPORT Automotive Data Solutions Inc. © 2013
7 8 9 10 11
18 19 20 21
12 13 14 15
22 23 24
16
25
17
26
123456
11 12 13 14 15
21 22 23 24
16 17 18 19
25 26 27
20
28
12345678910
7654321
6
74
23
22
23
10 11 12 13 14 15 16
12345678
9
6
14
1234567
8 9 10 11 12 13 14
ENGINE
START
STOP
7
7.5 AMPS
RF KIT
BROWN/RED - CANHBROWN/RED - CANH
BROWN/YELLOW - CANL
BROWN/YELLOW - CANL
ORANGE/BLACK - GROUND (-) INPUT
ORANGE/BLACK - GROUND (-) INPUT
ORANGE/WHITE - TX
ORANGE/WHITE - TX
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK - SLP (-) OUTPUT
WHITE/BLACK - SLP (-) OUTPUT
WHITE/RED (NC)
WHITE/RED (NC)
WHITE - GROUND (-) INPUT
WHITE - GROUND (-) INPUT
MAIN BODY ECU
BACK SIDE
D50
D49
INPUTBLUE/RED - GROUND (-) INPUT
BLUE/YELLOW - PTS (-) OUTPUT
BLUE/YELLOW - PTS (-) OUTPUT
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED (NC)
GRAY/RED (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
STEERING LOCK
D17 CONNECTOR
BLACK
IMPORTANT:
1- NO TAKEOVER AVAILABLE.
UPON OPENING VEHICLE DOOR ENGINE WILL SHUTDOWN.
2- ALL DOORS MUST BE CLOSED TO REMOTE START VEHICLE.
HOOD STATUS (-) INPUT - GREEN/BLACK
(NC) RED/WHITE
(NC) BROWN
(NC) BROWN
(NC) PURPLE/YELLOW
(NC) PURPLE/YELLOW
RX -
RX - PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
PARKING LIGHT (-) OUTPUT -
PARKING LIGHT (-) OUTPUT - GREEN
(NC) PURPLE/WHITE
HOOD STATUS (-)
RX
TX
12V (+)
SLP (-)
IGNITION (+)
PARKING LIGHT (-)
YELLOW/BLACK (NC)
YELLOW/RED (NC)
YELLOW (NC)
ORANGE (NC)
WITHOUT
OEM HOOD
STATUS ONLY
CONNECT WITH
BLUE HARNESS ONLY
12V (+) INPUT - RED
12V (+) INPUT - RED
GROUND (-) INPUT - BLACK
GROUND (-) INPUT - BLACK
FLASH RF DECODER
BEFORE INSTALLATION
RF DECODER
WITHOUT
OEM HOOD
STATUS
ONLY
CANL
CANH
CONNECTIONS ARE REQUIRED
ONLY IF IDLE MODE IS DESIRED
PTS (-)
(NC) BLUE/BLACK
