iDataLink BLADE Series User manual

NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
reviewtheInstallation Guide carefullybefore beginning any work.
!
The brand names and logos found in this guide are property of their respective owners. Automotive Data Solutions Inc. © 2016
U.S. PATENT NO. 8,856,780
Automotive Data Solutions Inc.
INSTALL GUIDE
BLADE-AL(DL)-VO2-EN
AVAILABLE FOR: ADS-BLADE AL
VO2
PLEASE VISIT WWW.IDATALINK.COM FOR COMPLETE PRODUCT DETAILS
Rev. Date: March 02, 2016
Doc. No.: ##27127##
20160302

U.S. Patent No. 8,856,780
INSTALL TYPE SELECTION
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS DISARM OEM ALARM DOOR LOCK DOOR UNLOCK TRUNK/HATCH RELEASE POWER LIFTGATE RETRACTABLE MIRROR CTRL SECURE TAKE OVER DOOR STATUS OUTPUT TRUNK STATUS OUTPUT HOOD STATUS OUTPUT* BRAKE PEDAL STATUS OUTPUT E-BRAKE OUTPUT TACHOMETER OUTPUT
LAND ROVER
LR2 PTS 07-12 2 • • • • • • • • • • • •
VOLVO
S80 PTS 07-11 1 • • • • • • • • • • • • •
V70 PTS 08-11 1 • • • • • • • • • • • • •
XC60 PTS Motorized keyport 10-11 1 • • • • • • • • • • • • •
XC70 PTS 08-11 1 • • • • • • • • • • • • •
*Available only if vehicle is equipped with factory hood switch.
Page 2 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
COMPONENT LOCATOR
ADS-AL(DL)-VO2 PAGE X-X
A
B
C
Page 3 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CROSS REFERENCE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
VOLVO
XC70 PTS 08-11
12V ~ Gray 6 pin 1 Red (+) Immobiliser A
Ground ~ Gray 6 pin 2 Black (-) Immobiliser A
PTS ~ Gray 6 pin 5 Blue/White (+) Immobiliser A
Immobiliser LIN ~ Gray 6 pin 3 Gray (DATA) Immobiliser A
Brake ~ ~ ~ ~ Purple/White (+) Driver kick panel C
CanH ~ ~ ~ ~ Gray/Orange (DATA) Driver kick panel C
CanL ~ ~ ~ ~ Purple/Orange (DATA) Driver kick panel C
Ignition ~ ~ ~ ~ Blue/Red (+) Driver kick panel C
Trunk LIN ~ Black 6 pin 6 Green/Purple (DATA) Behind parking light switch assembly B
V70 PTS 08-11
12V ~ Gray 6 pin 1 Red (+) Immobiliser A
Ground ~ Gray 6 pin 2 Black (-) Immobiliser A
PTS ~ Gray 6 pin 5 Blue/White (+) Immobiliser A
Immobiliser LIN ~ Gray 6 pin 3 Gray (DATA) Immobiliser A
Brake ~ ~ ~ ~ Purple/White (+) Driver kick panel C
CanH ~ ~ ~ ~ Gray/Orange (DATA) Driver kick panel C
CanL ~ ~ ~ ~ Purple/Orange (DATA) Driver kick panel C
Ignition ~ ~ ~ ~ Blue/Red (+) Driver kick panel C
Trunk LIN ~ Black 6 pin 6 Green/Purple (DATA) Behind parking light switch assembly B
XC60 PTS 10-11
12V ~ Gray 6 pin 1 Red (+) Immobiliser A
Ground ~ Gray 6 pin 2 Black (-) Immobiliser A
PTS ~ Gray 6 pin 5 Blue/White (+) Immobiliser A
Immobiliser LIN ~ Gray 6 pin 3 Gray (DATA) Immobiliser A
Brake ~ ~ ~ ~ Purple/White (+) Driver kick panel C
CanH ~ ~ ~ ~ Gray/Orange (DATA) Driver kick panel C
CanL ~ ~ ~ ~ Purple/Orange (DATA) Driver kick panel C
Ignition ~ ~ ~ ~ Blue/Red (+) Driver kick panel C
Trunk LIN ~ Black 6 pin 6 Green/Purple (DATA) Behind parking light switch assembly B
S80 PTS 07-11
12V ~ Gray 6 pin 1 Red (+) Immobiliser A
Ground ~ Gray 6 pin 2 Black (-) Immobiliser A
PTS ~ Gray 6 pin 5 Blue/White (+) Immobiliser A
Immobiliser LIN ~ Gray 6 pin 3 Gray (DATA) Immobiliser A
Brake ~ ~ ~ ~ Purple/White (+) Driver kick panel C
CanH ~ ~ ~ ~ Gray/Orange (DATA) Driver kick panel C
CanL ~ ~ ~ ~ Purple/Orange (DATA) Driver kick panel C
Ignition ~ ~ ~ ~ Blue/Red (+) Driver kick panel C
Trunk LIN ~ Black 6 pin 6 Green/Purple (DATA) Behind parking light switch assembly B
Page 4 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
TYPE 1 - WIRING DIAGRAM
123
456
321
654
63
2
1
5
86
30
87
87A
85
1N4001
DIODE
BROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW - PUSH BUTTON (+) OUTPUT
YELLOW - PUSH BUTTON (+) OUTPUT
BROWN/YELLOW - CANL
ORANGE/BLACK - TRUNK LIN (DATA) OUTPUT
ORANGE/WHITE (NC)
ORANGE - BRAKE POWER (+) OUTPUT
ORANGE - BRAKE POWER (+) OUTPUT
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED - IMMO. LIN VEHICLE SIDE
BLACK (NC)
BLACK (NC)
GRAY/RED - IMMO. LIN CONNECTOR SIDE
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK - IMMO. LIN VEHICLE SIDE
WHITE/RED
WHITE/RED - IMMO. LIN CONNECTOR SIDE
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
IMMO. LIN (DATA)
IGNITION (+)
CANL
BRAKE POWER (+)
GROUND (-)
12V (+)
PTS (+)
TRUNK (-) OUTPUTTRUNK (-) OUTPUT
HARNESS IN DRIVER KICK PANEL
GROUND (-)GROUND (-)
12V (+)
12V (+)
IGNITION (+) INPUTIGNITION (+) INPUT
12V (+)
DRIVER KICK PANEL
IMMOBILIZER LIN
CONNECTOR
GRAY
TRUNK LIN (DATA)
BEHIND PARKING LIGHT
SWITCH ASSEMBLY
BLACK
CANH
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
Page 5 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
TYPE 2 - WIRE CROSS REFERENCE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
LAND ROVER
LR2 PTS 07-12
12V ~ Gray 6 pin 1 Blue/Red (+) Immobiliser A
Ground ~ Gray 6 pin 2 Black/Purple (-) Immobiliser A
PTS ~ Gray 6 pin 5 Blue/Gray (+) Immobiliser A
Immobiliser LIN ~ Gray 6 pin 3 White/Green (DATA) Immobiliser A
Brake ~ ~ ~ ~ Purple/Brown (+) Driver kick panel C
CanH ~ ~ ~ ~ Gray/Orange (DATA) Driver kick panel C
CanL ~ ~ ~ ~ Purple/Orange (DATA) Driver kick panel C
Ignition ~ ~ ~ ~ Purple (+) Driver kick panel C
Page 6 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
TYPE 2 - WIRING DIAGRAM
123
456
3
2
1
5
1N4001
DIODE
BROWN/RED - CANH
BLUE/RED (NC)
BLUE/RED (NC)
YELLOW - PUSH BUTTON (+) OUTPUT
YELLOW - PUSH BUTTON (+) OUTPUT
BROWN/YELLOW - CANL
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE - BRAKE POWER (+) OUTPUT
ORANGE - BRAKE POWER (+) OUTPUT
PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED - IMMO. LIN VEHICLE SIDE
BLACK (NC)
BLACK (NC)
GRAY/RED - IMMO. LIN CONNECTOR SIDE
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK
WHITE/BLACK - IMMO. LIN VEHICLE SIDE
WHITE/RED
WHITE/RED - IMMO. LIN CONNECTOR SIDE
WHITE (NC)
WHITE (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
REMOTE STARTER
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
GRAY/RED GRAY/YELLOW
BLUE/YELLOW
YELLOWGREEN/RED
BLUE/RED
NO WIREORANGE
ORANGE/WHITEORANGE/BLACK
BROWN/YELLOWBROWN/RED
BLACKNO WIRE
PINKPINK/BLACK
NO WIREWHITE
WHITE/BLACKWHITE/RED
*BLADE CONNECTOR
EXACT PIN-OUT
IMMO. LIN (DATA)
IGNITION (+)
CANL
BRAKE POWER (+)
GROUND (-)
12V (+)
PTS (+)
HARNESS IN DRIVER KICK PANEL
GROUND (-)GROUND (-)
12V (+)
12V (+)
IGNITION (+) INPUTIGNITION (+) INPUT
DRIVER KICK PANEL
IMMOBILIZER LIN
CONNECTOR
GRAY
CANH
Page 7 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
CARTRIDGE INSTALLATION
1Slide cartridge into unit. Notice
button under LED. 2Ready for Module Programming Procedure.
MODULE PROGRAMMING PROCEDURE - WITH KLON - 1 OF 2
4Wait, LED will turn solid BLUE.
(This may take up to 10 seconds)
1Open driver door.
3Press and hold start button to
ON position.
Æ
5Push start button once [1x] to
OFF position.
x1
Æ
2Insert keyfob 1 in keyport.
Æ
7Insert keyfob 1 in keyport.
Æ
6Remove keyfob 1 from keyport.
Æ
8Wait, LED will turn solid BLUE.
10 Insert keyfob 1 in keyport.
Æ
9Remove keyfob 1 from keyport.
Æ
12 Remove keyfob 1 from keyport.
Æ
11 Wait, LED will turn solid RED
then will fl ash BLUE rapidly.
ÈIMPORTANT: READ NEXT PAGE !
Page 8 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
MODULE PROGRAMMING PROCEDURE - WITH KLON - 2 OF 2
22 Module Programming
Procedure completed.
17 Proceed with extended
programming.
19 Insert keyfob 1 in keyport.
Æ
21 Remove keyfob 1 from keyport.
Æ
20 Wait, LED will turn solid RED
then will turn solid BLUE for 2
seconds.
16 Connect remote starter to
computer.
Æ
15 Remove remote starter from
vehicle.
Æ
13 Disconnect all connectors from
remote starter except the power
connector.
   
   
14 Disconnect the power
connector.
18 Connect remote starter to
vehicle.
Æ
Page 9 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
BLADE-AL PAGE 1-1
LED STATUS
DIAGNOSTICS
DURING PROGRAMMING DURING REMOTE START WITH IGNITION OFF
Flashing RED Missing/wrong information from
fi rmware or vehicle Incorrectly programmed Incorrectly programmed or connected
Solid RED Waiting for more vehicle information Incorrectly programmed Not programmed waiting for more
vehicle information
Flashing BLUE Additional steps required to complete
programming
Correctly programmed and
operational
False ground when running status
from remote starter
Solid BLUE then OFF Correctly programmed Reset in progress Reset in progress
OFF No activity or already programmed Invalid ground when running status
from remote starter
At rest and ready for a remote start
sequence
MODULE DIAGNOSTICS
FACTORY RESET PROCEDURE
5RECONNECT all connectors.
Repeat programming procedure.
!Failure to follow procedure may result with a DTC or a
CHECK ENGINE error message.
1DISCONNECT cartridge from
remote starter.
2PRESS AND HOLD programming
button while re-connecting
cartridge to remote starter.
3LED will fl ash red. Immediately
RELEASE programming button.
4LED will turn solid red for 2
seconds.
RESET COMPLETED.
IDENTIFY VEHICLE YEAR
1 Locate the Vehicle Identifi cation Number (VIN), identify the 10th
character then match it to its corresponding year.
4 Y 1 N53 A 5 T A L 8 D 5 R 0 X
Æ
A1980 L1990 Y2000 A2010
B1981 M1991 12001 B2011
C1982 N1992 22002 C2012
D1983 P1993 32003 D2013
E1984 R1994 42004 E2014
F1985 S1995 52005 F2015
G1986 T1996 62006 G2016
H1987 V1997 72007 H2017
J1988 W1998 82008 J2018
K1989 X1999 92009 K2019
Æ
Page 10 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##

U.S. Patent No. 8,856,780
ADS-AL(DL)-VO2 PAGE X-X
TAKE OVER PROCEDURE - TO THE VEHICLE OWNER
5Take over procedure completed.
4Press and release BRAKE pedal.
!Failure to follow procedure within time restriction will
result in vehicle engine shutdown.
2TIME RESTRICTI
º N
Within 45 SECONDS from
previous step:
Open vehicle door.
Enter vehicle.
NOTE
I All vehicle doors must be closed and locked prior to remote
start sequence.
1Press UNLOCK on after-market
remote.
ÈTIME RESTRICTI
º N COMING UP !
3Insert keyfob in keyport.
Æ
Page 11 of 11 BLADE-AL(DL)-VO2-EN 20160302
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2016
DOORLOCK INTERFACE
VolVo
Doc. No.: ##27127##
