Idea LUA8C User manual
1
QS_LUA8C_EN_v3.3
LUA8C
Install Column Loudspeaker Quick Start Guide
LUA8C is a versatile, powerful, Mid/High Frequency loudspeaker featuring
eight 3” wide-band high power transducers. This column loudspeaker features
all the expected benets of this kind of driver arrangement: very focused and
controlled directivity, extremely natural and dened midrange reproduction
and surprising “throw” of acoustic energy for such contained dimensions.
For installations requiring very rened audio reproduction and superior
directivity control, it features a 4/16 Ohm selectable impedance switch, that
makes the LUA8C ideal for distributed audio solutions in highly reverberant
spaces or in locations where speech intelligibility is paramount.
IDEA provides for LUA8C recommended DSP settings for different processing
platforms, and with many different IDEA subwoofers, particularly with
BASSO12, BASSO12i, BASSO12t and BASSO24t.
LUA8C is available in all RAL colours as well as in weatherized versions (with
optional micro-perforated protection grill), and offers both adjustable angle
wall-mount and pole-mount accessories.
OPTIONAL INSTALLATION ACCESSORIES
LUA8C feature optional wall-mount dedicated accessort for ease of
installation in distributed audio environments in order to easily integrate with
the venue, as well as a pole-mount accessory for easy setup in mobile sound
applications.
The U-Bracket WM-L48C (shown in the image above) uses the cabinet’s four
M8 insert to attach the bracket and M6 bolts to to lock the desired angulation
points with 7 horizontal positions and 4 vertical tilt angles
Screw the back plate to the wall, t the anglulation parts to the cabinet
and slide down the LUA8C with the accesory into the back plate brackets to
assemble both parts. This easy, convenient installation process saves time
at the setup operation while allowing for precise vertical and horizontal
positioning of the loudspeaker.
The WM-LUA48 optional accessory couples to the bottom side of the cabintet
with 4 M6 insterts and features a 36-mm pole mount cup to use with any
standard 35-mm distance rod.
2
QS_LUA8C_EN_v3.3
TECHNICAL DATA
IEC ltered pink noise with a 6dB crest factor, 2 hours.
*
Frequency range values for recommended factory presets.
**
TECHNICAL DRAWINGS
Enclosure Design Sealed
Transducers 8 x 3”
RMS Power Handling * 240 W
Nominal Impedance 4 / 16 Ohm selectable
SPL (Continuous/Peak) 116/122 dB SPL
Frequency Range (-10 dB) 120 - 18000 Hz
Frequency Range (-3 dB) 180 - 18000 Hz
Coverage 80˚ x 30˚
Dimensions (W x H x D) 105 x 650 x 115 mm
(4,1 x 25,6 x 4,5 inch)
Weight 7,4 kg (16,3 lbs)
Connectors 2 x Neutrik®SpeakON NL-4 in parallel
Cabinet Construction 12 mm Birch Plywood
Grille 1.5 mm perforated weatherised steel with protective foam
Finish Durable IDEA proprietary Aquaforce high-resistance paint coating process
Installation Dedicated install and pole-mount accessories
Accessories Pole Mount Accessory (PM-L48)
Wall Mount Accessory (WM-L48)
7,4kg
240W
RMS
INPUT
IMPEDANCE
16 Ω
LINK
LUA8C
Designed,engineered and
manufacturedby IDEA
inCedeira (Galicia)
PRODUCTOFEUROPE
MadeinSpain
Butt24
90Hz
4 Ω
115 mm 105 mm
650 mm
3
QS_LUA8C_EN_v3.3
I MAS D ELECTROACÚSTICA SL
POL. A TRABE 19-20 15350 CEDEIRA (GALICIA - SPAIN)
DECLARES THAT: LUA8C
COMPLIES WITH THE FOLLOWING EU DIRECTIVES:
ROHS (2002/95/CE) RESTRICTION OF HAZARDOUS SUBSTANCES
LVD (2006/95/CE) LOW VOLTAGE DIRECTIVE
EMC (2004/108/CE) ELECTRO-MAGNETIC COMPATIBILITY
WEEE (2002/96/CE) WASTE OF ELECTRIC AND ELECTRONIC EQUIPMENT
EN 60065: 2002 AUDIO, VIDEO AND SIMILAR ELECTRONIC APPARATUS. SAFETY REQUIRE-
MENTS.
EN 55103-1: 1996 ELECTROMAGNETIC COMPATIBILITY: EMISSION
EN 55103-2: 1996 ELECTROMAGNETIC COMPATIBILITY: IMMUNITY
DECLARATION OF CONFORMITY
WARNINGS AND SAFETY GUIDELINES
WARRANTY
!
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical parts
and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in order
to claim guarantee service or replacement.
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by quali-
ed and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or recom-
mended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers to
any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recycling of
electronic devices.
• IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment.
4
QS_LUA8C_EN_v3.3
For further information scan the QR Code
or refer to the following web address: www.ideaproaudio.com/lua8c
www.ideaproaudio.com
IDEA is always in pursuit of better performance, greater reliability and design features.
Technical specications and minor nish details may vary without notice in order to improve our products.
©2019 - I MAS D Electroacústica SL
Pol. A Trabe 19-20 15350 Cedeira (Galicia – Spain)
