Idea EXO12 User manual

1
QS_EXO12_EN_v3.4
EXO12
2-Way Multipurpose Monitor Quick Start Guide
EXO12 is a versatile, high-performance full range 2-way passive
wedged monitor conceived for professional environments where
portable sound reinforcement is required, delivering a superior audio
reproduction in a very compact, multipurpose format.
EXO12 HF assembly couples a 3˝ compression driver into common
EXO Series birch plywood axisymmetric horn with IDEA’s proprietary
design and a premium European, dedicated-design passive crossover
lter provides a smooth, natural transition intro the MLF 12˝ woofer and
summing up into a full-range superior audio playback along the whole
usable frequency range from 18 kHz down to 55 Hz.
Like all IDEA models, EXO12 is built with 15 and 18 mm birch plywood,
IDEA’s Aquaforce waterproof paint coating and a high quality steel
grille, creating a rugged, durable and stylish loudspeaker.
The 60° wedged cabinet allows not only to be used as FOH main
system in small venues, bars and AV applications and as a stage
monitor but to seamlessly t into any wall mount xed installation.
EXO12 integrates a bottom Pole Mount 35 mm socket to be congured
on BASSO Series subwoofers for portable sound reinforcement and
medium performance venues and clubs. The dedicated U-bracket and
ten threaded M8 inserts allow for all vertical and horizontal U-bracket
positions both for wall and ceiling xed installations as well as to be
precisely oriented in pole mounted congurations.
INSTALLATION ACCESSORIES
EXO12 is tted with 10 threaded M8 inserts for hung permanent
installations as well as bottom 36 mm pole-mount socket that serves
for both pole mount congurations onto a BASSO Series subwoofer.
UB-E12-V
Optional Wall-Mount Accessory
The optional U-Bracket accessory
for EXO12 wall-mount installations
allows for dierent vertical
angulations. FIt the M8 bolts,
choose the proper vertical angle
and lock the position with a M6 bolt
per side.
Examples showing
EXO12 in dierent setups
and congurations

2
QS_EXO12_EN_v3.4
TECHNICAL DATA
TECHNICAL DRAWINGS
Enclosure design Wedged
LF Transducers 1 x 12’’ High performance woofer
HF Transducers 3’’ Voice coil Compression Driver
Power Handling (RMS) 500 W
Nominal Impedance 8 Ohm
SPL (Continuous/Peak) 122/128 dB SPL
Frequency Range (-10 dB) 55 - 23000 Hz
Frequency Range (-3 dB) 69 - 21000 Hz
Coverage 80° Axisymmetric
Dimensions (WxHxD) 336 x 681 x 366 mm (13.2 x 26.8 x 14.4 in)
Weight 23.7 kg (52.2 lb)
Connectors
+/-1
+/-2
2 x Neutrik speakOn NL-4 in parallel
Input
Link
Cabinet Construction 15 + 18 mm Birch Plywood
Grille 1.5 mm perforated weatherised steel with protective foam
Finish Durable IDEA proprietary Aquaforce High Resistance paint coating process
Handles 2 integrated handles
Feet/Skates 4+3 Rubber feet
Installation 10 threaded M8 inserts. Bottom 36 mm pole mount socket
Accessories U-Bracket vertical (UB-E12-V)
U-Bracket horizontal (UB-E12-H)
Pole (K&M-21336)
336 mm366 mm
681 mm
EXO12
NominalImpedance: 8 Ohm
This product must be installed
and/or operated by qualified
professionals following safe
practicesand local regulations.
Refer to the owner’s manual
for instructions and optional
accessories.
Recommendedamp power:
300/900Watt
PARALLELI/O A
B
PARALLELI/O
FullRange Signal
ParallelSignal
NL-4PINOUT
PRODUCTOF EUROPE
Madein Spain
Designed, engineered
and manufactured by
IDEAin Cedeira (Galicia)

3
QS_EXO12_EN_v3.4
I MAS D ELECTROACÚSTICA SL
POL. A TRABE 19-20 15350 CEDEIRA (GALICIA - SPAIN)
DECLARES THAT: EXO12
COMPLIES WITH THE FOLLOWING EU DIRECTIVES:
ROHS (2002/95/CE) RESTRICTION OF HAZARDOUS SUBSTANCES
LVD (2006/95/CE) LOW VOLTAGE DIRECTIVE
EMC (2004/108/CE) ELECTRO-MAGNETIC COMPATIBILITY
WEEE (2002/96/CE) WASTE OF ELECTRIC AND ELECTRONIC EQUIPMENT
EN 60065: 2002 AUDIO, VIDEO AND SIMILAR ELECTRONIC APPARATUS. SAFETY RE-
QUIREMENTS.
EN 55103-1: 1996 ELECTROMAGNETIC COMPATIBILITY: EMISSION
EN 55103-2: 1996 ELECTROMAGNETIC COMPATIBILITY: IMMUNITY
DECLARATION OF CONFORMITY
WARNINGS AND SAFETY GUIDELINES
WARRANTY
!
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical
parts and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in
order to claim guarantee service or replacement.
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by
qualied and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or rec-
ommended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers
to any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recy-
cling of electronic devices.
• IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment.

4
QS_EXO12_EN_v3.4
For further information scan the QR Code
or refer to the following web address: www.ideaproaudio.com/product-detail/exo12
www.ideaproaudio.com
IDEA is always in pursuit of better performance, greater reliability and design features.
Technical specications and minor nish details may vary without notice in order to improve our products.
