Ideal Heating LOGIC COMBI2 C24 User guide

When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com
where you can download the relevant information in PDF format.
October 2022
UIN 228296 A06
INSTALLATION
& SERVICING
LOGIC COMBI2
C24 C30 C35

2
Installation and Servicing
ERP DATA
The code of practice for the installation,
commissioning & servicing of central
heating systems
WEEE DIRECTIVE 2012/19/EU
Waste Electrical and Electronic Equipment Directive
• At the end of the product life, dispose of the
packaging
and product in a corresponding recycle centre.
• Do not dispose of the unit with the usual domestic refuse.
• Do not burn the product.
• Remove the batteries.
• Dispose of the batteries according to the local statutory
requirements and not with the usual domestic refuse.
 
MODEL
SYMBOL UNITS 24 kW 30 kW 35 kW
Condensing Boiler n/a n/a yes yes yes
Low Temperature Boiler n/a n/a no no no
B1 Boiler n/a n/a no no no
Cogeneration Space Heater n/a n/a no no no
Equipped with a Supplementary Heater n/a n/a no no no
Combination Heater n/a n/a yes yes yes
Nominal Heat Output for Space Heating
Full Load P4 kW 24.3 24.3 24.3
Part Load P1 kW 8 8 8
Auxiliary Electricity Consumption
Full Load elmax kW 0.046 0.027 0.026
Part Load elmin kW 0.013 0.01 0.012
Standby PSB kW 0.002 0.003 0.002
Seasonal Space Heating Energy E󰀩ciency
Full Load ƞ4 % 90 90 90
Part Load ƞ1 % 98.7 98.7 98.7
Standby Loss Pstby kW 0.05 0.05 0.05
Ignition Pign kW 0 0 0
Emissions NOx (Gross) NOx, pond Hs mg/kWh 28 25 30
Annual Energy Consumption QHE GJ 75 75 75
Sound Power Level, Indoors LWA dB 50 46 46
Domestic Hot Water
Domestic Hot Water Qelec kWh 0.157 0.157 0.158
Water heating energy e󰀩ciency (Eco) Tapping Prole L ƞWH % 81 81 79
Daily fuel consumption 24hr (GCV) Actual measured Qfuel kWh 14.76 14.631 15.14
Annual electricity consumption AEC kWh 34 34 34
Annual fuel consumption AFC GJ 11 11 11

3Installation and Servicing
LOGIC COMBI2C BOILER
Ideal Heating ERP DATA
Seasonal Space Heating Energy E󰀩ciency of the Boiler *%
Temperature control (from che of temperature control) %
Class I Class II Class III Class IV Class V Class VI Class VII Class VIII
1% 2% 1.5% 2% 3% 4% 3.5% 5%
PRODUCT FICHE
 
The energy e󰀩ciency of the package of products provided for in this document may not correspond to its actual energy e󰀩ciency once
installed in a building, as the e󰀩ciency is inuenced by further factors such as heat loss in the products in relation to the building size and its
characteristics.
Collector Size
(in m2)Tank Volume (in m3)Collector E󰀩ciency
(in %)
Tank rating
A* = 0.95
A = 0.91
B = 0.86
C = 0.83
D-G = 0.81
Solar Contribution (from che of solar device)
Seasonal Space Heating Energy E󰀩ciency of Package TOTAL: A+B+C=
Seasonal Space Heating Energy E󰀩ciency Class of Package
= (‘III ’x + ‘IV ’ x ) x 0.9 x ( / 100 x ) = %
%
GG F E D C B A A+ A++ A+++
< 30% ≥ 30% ≥ 34% ≥ 36% ≥ 75% ≥ 82% ≥ 90% ≥ 98% ≥ 125% ≥ 150%
A
B
C
SYMBOL UNITS MODEL
24 kW 30 kW 35 kW
Condensing boiler Yes
Seasonal space heating e󰀩ciency class A
Rated heat output kW 24
Seasonal space heating energy e󰀩ciency ƞs % 94*
Annual energy consumption QHE GJ 75
Sound power level, indoors LWA dB 50 46 46
Water heating energy e󰀩ciency class A
94%

4
Installation and Servicing
DEFINITIONS
IMPORTANT: Important information
For any technical queries please ring the Ideal installer helpline : 01482 498663
BOILER RESTART PROCEDURE -
Press the RESTART button. The boiler will repeat the ignition sequence if a heat demand is present.
NOTES FOR THE INSTALLER
WARNING: Risk of injury or death
CAUTION: Risk of damage to objects
Table of Acronyms
CH - Central Heating
DHW - Domestic Hot Water
TRV - Thermostatic Radiator Valve
PRV - Pressure Relief Valve
IE - Ireland
ETCI - Electro-Technical Council of Ireland
BS - British Standard
WRAS - Water Regulations Advisory Scheme
SAP - Standard Assessment Procedure
IEE - Institution of Electrical Engineers
UKCA - UK Conformity Assessed
RHS - Right Hand Side
LHS - Left Hand Side
PCB - Printed Circuit Board

5Installation and Servicing
Section 1 - General.................................................................................6
1.1 Introduction...............................................................................8
1.2 Operation..................................................................................8
1.3 Safe Handling...........................................................................8
1.4 OptionalAccessories................................................................8
1.5 Safety........................................................................................9
1.6 Safe Handling of Substances...................................................9
1.7 Location of Boiler .....................................................................9
1.8 Air Supply...............................................................................10
1.9 Gas Supply.............................................................................10
1.10 Water Circulation System.......................................................10
1.11 Boiler Controls........................................................................10
1.12 Electrical Supply.....................................................................10
1.13 Condensate Drain...................................................................10
1.14 Boiler Dimensions, Services & Clearances............................11
1.15 System Requirements - Central Heating................................12
1.16 System Requirements - DHW.................................................13
1.18 Water Treatment.....................................................................13
1.17 System Balancing...................................................................13
Section 2 - Installation..........................................................................14
2.1 BoilerAssembly - Exploded View...........................................14
2.2 Unpacking...............................................................................15
2.3 Wall Mounting Template..........................................................16
2.4 Preparing the Wall..................................................................16
2.5 Fitting the Wall Mounting Plate...............................................16
2.6 Mounting the Boiler.................................................................16
2.7 Flues and Locations................................................................17
2.8 Flues and Locations - Cont.....................................................18
2.9 Horizontal Flue Positions .......................................................19
2.10 Vertical Flue Positions ...........................................................19
2.11 Flue System Dimensions .......................................................20
2.12 Fitting the Turret......................................................................20
2.13 Cutting the Flue......................................................................21
2.14 Assembling the Vertical Flue..................................................22
2.15 Condensate Drain...................................................................23
2.16 Condensate Drain - Cont’d.....................................................24
2.17 Connections & Filling..............................................................25
2.18 Connections & Filling Continued.............................................26
2.19 Electrical Connections............................................................27
2.20 Installer Wiring........................................................................27
2.21 External Wiring.......................................................................28
2.22 Wiring Diagram.......................................................................29
2.23 Replacing Pre-Fitted Mains Cable..........................................30
2.24 Commissioning and Testing....................................................30
2.25 Initial Lighting..........................................................................31
2.26 The Display.............................................................................32
2.27 General Checks......................................................................32
2.28 General Checks - Water Circulation.......................................33
2.29 Restart Procedure...................................................................33
2.30 Accessing the Installer Mode..................................................34
2.31 Handing Over..........................................................................34
Section 3 - Servicing.............................................................................35
3.1 Servicing Schedule.................................................................35
3.2 Removal / Replacement of Components................................36
3.3 Draining the Boiler..................................................................36
3.4 Boiler Front Panel Removal / Replacement............................37
3.5 Flue Manifold Removal/Replacement.....................................37
3.6 Fan and VenturiAssembly Removal and Cleaning.................38
3.7 Burner Removal and Cleaning................................................39
3.8 Cleaning the Heat Exchanger.................................................39
3.9 Ignition / Detection Electrode Replacement / Inspection........40
3.10 Cleaning the Condensate Trap...............................................40
3.11 DHW Filter & DHW Flow Regulator Cleaning/Replacement...41
3.12 Burner Injector Replacement..................................................41
3.13 Burner Replacement...............................................................41
3.14 Return Thermistor Replacement............................................42
3.15 Spark Generator Replacement...............................................42
3.16 Gas Control Valve Replacement.............................................43
3.17 Diverter Valve Actuator Replacement.....................................43
3.19 Condensate Trap Replacement / Cleaning.............................44
3.18 Primary PCB Replacement.....................................................44
3.20 DHW Flow Turbine Sensor Replacement...............................45
3.21 Pressure Gauge Replacement...............................................45
3.22 PRV Replacement..................................................................46
3.23 PumpAutomaticAir Vent Replacement..................................46
3.24 Replacement of DHW Thermistor...........................................47
3.25 DHW Plate Heat Exchanger Replacement.............................47
3.26 Diverter Valve Body Assembly Replacement..........................48
3.27 Pump Head Replacement.......................................................49
3.28 CH Water Pressure Switch Replacement...............................49
3.29 Flow Thermistor Replacement................................................50
3.30 Heat Engine Replacement......................................................51
3.31 Expansion Vessel Recharging & Replacement......................52
Section 4 - Fault Finding.......................................................................53
4.1 Fault Finding Main Menu........................................................53
4.2 ‘L01’ - Overheat Lockout........................................................54
4.3 ‘L02’ - Ignition Lockout...........................................................54
4.4 ‘L06’ - Flame On Before Gas Valve On..................................55
4.5 ‘F 01’- Low Water Pressure...................................................55
4.6 ‘F 02 - Flame Loss.................................................................55
4.7 ‘F 03’- Fan Fault.....................................................................56
4.8 F 04 or L04’ - FlowThermistor Fault .....................................56
4.9 ‘F 05 or L05’ - ReturnThermistor Fault .................................57
4.10 ‘F 06’- Outside Sensor Fault..................................................57
4.11 No CH Operation but DHW Works OK...................................58
4.12 No DHW but CH Works OK....................................................59
4.13 No Display..............................................................................60
4.14 ‘F0U’Flow/Return Differential Greater than 50°C ..................60
4.15 F 0C’DHW Thermistor Fault...................................................60
Section 5 - Spare Parts........................................................................61
Section 6 - Benchmark to Commissioning............................................62
CONTENTS

6
Installation and Servicing
Section 1 - General
Table 2 Performance Data - Central Heating Table 3 Performance Data - Domestic Hot Water
Note. Gas consumption is calculated using a caloric value of 38.7
MJ/m3(1038 Btu/ft3) gross or 34.9 MJ/m3 (935 Btu/ft3) nett
To obtain the gas consumption at a di󰀨erent caloric value:
a. For l/s - divide the gross heat input (kW) by the gross C.V. of the
gas (MJ/m3)
b. For Btu/h - multiply the gross heat input (kW) by 26.8
c. For ft3/h - divide the gross heat input (Btu/h) by the gross C.V. of
the gas (Btu/ft3)
d. For m3/h - multiply l/s by 3.6
C13 C33 C53 = A room sealed appliance designed for connection via
ducts to a horizontal or vertical terminal, which admits
fresh air to the burner and discharges the products of
combustion to the outside through orices which, in
this case, are concentric. The fan is up stream of the
combustion chamber.
I2H = An appliance designed for use on 2nd family gas, Group H
only .
II2H/3P = An appliance designed for use on 2nd or 3rd family gases,
Group H or P .
* The value is used in the UK Government’s Standard Assessment
Procedure (SAP) for energy rating of dwellings. The test data from
which it has been calculated, has been certied by a notied body.
*Required for maximum ow rate. Boiler operates down to 2 L/min DHW delivery
** In areas of low water pressure the DHW restrictor can be removed
Table 1 General Data
24 kW 30 kW 35 kW
Gas Supply 2H - G20 - 20 mbar
Gas Supply Connection 15 mm copper compression
Injector Size mm 4.15 4.65 4.9
Inlet Connection Cold Water 15 mm copper compression
Outlet Connection Cold Hot Water 15 mm copper compression
Flow Connection Central Heating 22 mm copper compression
Return Connection Central Heating 22 mm copper compression
Flue Terminal Diameter mm 100
Average Flue Temp-Mass Flow Rate DHW 63ºC - 11g/s 68ºC - 13g/s 73ºC - 15g/s
CO2Content (± 0.7) Max. DHW 9.2% 9.3% 9.7%
Min. CH 8.5% 8.5% 8.8%
Maximum Working Pressure (Sealed Systems) bar (psi) 2.5 (36.3)
Maximum Domestic Hot Water Inlet Pressure bar (psi) [kPa] 10.0 (145) [1000]
Minimum Domestic Hot Water Inlet Pressure* bar (psi) [kPa] 0.8(11.6)(80) 1.3(18.9) (130) 1.3(18.9)**(130)
Minimum DHW Inlet Pressure to Operate at 0.6 bar System Pressure All Model Sizes 0.5 bar
Electrical Supply 230 V ~ 50 Hz
Power Consumption W 96 91 110
Fuse Rating External : 3 A Internal : T4A HRC L250 V
Water Content Central Heating litre (gal) 1.2 (0.26)
Domestic Hot Water litre (gal) 1.0 (0.22)
Packaged Weight kg 32.8 33 33
Lift Weight kg 28.5 28.6 28.6
Boiler Casing Size Height mm 700
Width mm 395
Depth mm 278
Boiler Input: Max Min
24 kW 30 kW 35 kW
Net CV kW 24.3 4.9 6.1 7.1
Gross CV kW 27 5.4 6.7 7.9
Gas Consumption m3/h 2.512 0.5 0.627 0.734
(ft3/h) (89) (17.8) (22) (25.9)
Boiler Output :
Non Condensing
70ºC Mean Water Temp. kW 24.2 4.8 6.1 7.1
Condensing
40ºC Mean Water Temp. kW 25.6 5.1 6.4 7.5
Seasonal E󰀩ciency* SEDBUK 2005 91.10% 91.10% 91.10%
Seasonal E󰀩ciency* SEDBUK 2009/2012 89.60% 89.60% 89.60%
NOx Classication CLASS 6
Maximum DHW Input: 24 kW 30 kW 35 kW
Nett CV kW 24.3 30.4 35.4
Gross CV kW 27 33.7 39.3
Gas Consumption m3/h 2.512 3.135 3.657
ft3/h 89 111 129
Maximum DHW Output kW 24.2 30.3 35.3
DHW Flow Rate l/min 9.9 12.4 14.5
At 35ºC Temp. Rise gpm 2.2 2.8 3.2
DHW Specic Rate l/min 11.5 14.5 16.9
gpm 2.5 3.2 3.7

7Installation and Servicing
Section 1 - General
24 kW 30 kW 35 kW
Gas Supply 2H - G20 - 20 mbar
Gas Supply Connection 15 mm copper compression
Injector Size mm 4.15 4.65 4.9
Inlet Connection Cold Water 15 mm copper compression
Outlet Connection Cold Hot Water 15 mm copper compression
Flow Connection Central Heating 22 mm copper compression
Return Connection Central Heating 22 mm copper compression
Flue Terminal Diameter mm 100
Average Flue Temp-Mass Flow Rate DHW 63ºC - 11g/s 68ºC - 13g/s 73ºC - 15g/s
CO2Content (± 0.7) Max. DHW 9.2% 9.3% 9.7%
Min. CH 8.5% 8.5% 8.8%
Maximum Working Pressure (Sealed Systems) bar (psi) 2.5 (36.3)
Maximum Domestic Hot Water Inlet Pressure bar (psi) [kPa] 10.0 (145) [1000]
Minimum Domestic Hot Water Inlet Pressure* bar (psi) [kPa] 0.8(11.6)(80) 1.3(18.9) (130) 1.3(18.9)**(130)
Minimum DHW Inlet Pressure to Operate at 0.6 bar System Pressure All Model Sizes 0.5 bar
Electrical Supply 230 V ~ 50 Hz
Power Consumption W 96 91 110
Fuse Rating External : 3 A Internal : T4A HRC L250 V
Water Content Central Heating litre (gal) 1.2 (0.26)
Domestic Hot Water litre (gal) 1.0 (0.22)
Packaged Weight kg 32.8 33 33
Lift Weight kg 28.5 28.6 28.6
Boiler Casing Size Height mm 700
Width mm 395
Depth mm 278
Maximum DHW Input: 24 kW 30 kW 35 kW
Nett CV kW 24.3 30.4 35.4
Gross CV kW 27 33.7 39.3
Gas Consumption m3/h 2.512 3.135 3.657
ft3/h 89 111 129
Maximum DHW Output kW 24.2 30.3 35.3
DHW Flow Rate l/min 9.9 12.4 14.5
At 35ºC Temp. Rise gpm 2.2 2.8 3.2
DHW Specic Rate l/min 11.5 14.5 16.9
gpm 2.5 3.2 3.7
Boiler Page
Make and model.........................................................9
Appliance serial no. on data badge .................Front Cover
SEDBUK No. %..........................................................8
Controls
Time and temperature control to heating .................29
Time and temperature control to hot water .............29
Heating zone valves................................................n/a
TRV’s........................................................................12
Auto bypass....................................................................12
Boiler interlock..........................................................12
For all boilers
Flushing to BS.7593.................................................15
Inhibitor...........................................................................15
Central heating mode
Heat input...................................................to be calculated
For assistance call Technical Helpline
01482 498663
Page
Burner operating pressure ......................................n/a
Central heating ow temp. ...........measure and record
Central heating return temp. ........measure and record
For combination boilers only
Scale reducer...........................................................15
Hot water mode
Heat input............................................to be calculated
Max. operating burner pressure..............................n/a
Max. operating water pressure........ measure & record
Cold water inlet temp ...................... measure & record
Hot water outlet temp...................... measure & record
Water ow rate at max. setting........ measure & record
For condensing boilers only
Condensate drain................................................25-26
For all boilers: Complete, sign & hand over to customer
For UK, to comply with Building Regulations Part L1 (Part 6 in Scotland) the boiler should be tted in accordance with the
manufacturer’s instructions. Self-certication that the boiler has been installed to comply with Building Regulations can be
demonstrated by completing and signing the Benchmark Commissioning Checklist.
Before installing this boiler, read the Code of Practice sheet at the rear of this book.
BENCHMARK COMMISSIONING CHECKLIST DETAILS
NOTE TO THE INSTALLER: COMPLETE THE BENCHMARK
COMMISSIONING CHECKLISTAND LEAVE THESE
INSTRUCTIONS WITHAPPLIANCE
Natural Gas Only
Destination Country: GB
LOGIC COMBI2 C
BOILER SIZE
kW G.C. Applicance No (Benchmark No.)
24 47-349-93
30 47-349-94
35 47-349-95

8
Installation and Servicing
Section 1 - General
1.1 INTRODUCTION
The Logic Combi2range of boilers are wall mounted,
condensing, combination gas boilers.
Features:
• High e󰀩ciency
• Full sequence
• Automatic spark ignition
• Low water content
• Fanned ue
The boiler is supplied fully assembled with DHW plate heat
exchanger, diverter valve, circulating pump, pressure gauge,
PRV and CH expansion vessel.
Variable CH and DHW temperature controls are tted on the
user control and the boiler features a DHW preheat facility.
The boiler includes as standard:
- Automatic bypass
- Boiler frost protection
- Daily pump and diverter valve exercise.
The boiler casing is of white painted mild steel with a white
polymer front panel.
The boiler temperature controls are visibly located in the
control panel on the front of the boiler.
The heat exchanger is manufactured from cast aluminium.
The boiler is suitable for connection to fully pumped,
sealed heating systems ONLY. Adequate arrangements for
completely draining the system by provision of drain cocks
MUST be provided in the installation pipework.
Pipework from the boiler is routed downwards.
A PRV grommet is tted to the boiler which requires the
correct tting and securing of a clip (supplied) to ensure safe
discharge of the PRV should this occur.
Data Plate
The boiler model and serial number can be located on the
bottom of the boiler casing, shown in Section 1.13 - Water &
Gas Connection Diagram.
Refer to Section
1.13
1.2 OPERATION
With no demand for CH, the boiler res only when DHW is
drawn o󰀨, or periodically for a few seconds without any DHW
draw-o󰀨, in order to maintain the DHW plate heat exchanger
in a heated condition. This only occurs if the “PREHEAT”
button is pressed and the display reads “PREHEAT ON or
PREHEAT TIMED”.
When there is a demand for CH, the heating system is
supplied at the selected temperature of between 30oC and
80oC, until DHW is drawn o󰀨. The full output from the boiler is
then directed via the diverter valve to the plate heat exchanger
to supply a nominal DHW draw-o󰀨 of
24 9.9 l/min at 35ºC temperature rise.
30 12.4 l/min at 35ºC temperature rise.
35 14.5 l/min at 35ºC temperature rise.
The DHW draw o󰀨 rate specied above is the nominal that
the boiler ow regulator will give. Due to system variations
and seasonal temperature uctuations DHW ow rates/
temperature rise will vary, requiring adjustment at the draw o󰀨
tap.
At low DHW draw-o󰀨 rates the maximum temperature may
exceed 65ºC.
The boiler features a comprehensive diagnostic system which
gives detailed information on the boiler status when operating,
and performance of key components to aid commissioning
and fault nding.
1.3 SAFE HANDLING
This boiler may require 2 or more operatives to move it to its
installation site, remove it from its packaging base and during
movement into its installation location. Manoeuvring the boiler
may include the use of a sack truck and involve lifting, pushing
and pulling.
Caution should be exercised during these operations.
Operatives should be knowledgeable in handling techniques
when performing these tasks and the following precautions
should be considered:
• Grip the boiler at the base.
• Be physically capable.
• Use personal protective equipment as appropriate, e.g.
gloves, safety footwear.
During all manoeuvres and handling actions, every attempt
should be made to ensure the following unless unavoidable
and/or the weight is light.
• Keep back straight.
• Avoid twisting at the waist.
• Avoid upper body/top heavy bending.
• Always grip with the palm of the hand.
• Use designated hand holds.
• Keep load as close to the body as possible.
• Always use assistance if required.
1.4 OPTIONALACCESSORIES
Please visit idealheating.com to access the
optional accessories for this boiler.
SCAN
for link

9Installation and Servicing
Section 1 - General
1.5 SAFETY
Current Gas Safety (installation and use) regulations or
rules in force:
The appliance is suitable only for installation in GB and should
be installed in accordance with the rules in force.
In GB, the installation must be carried out by a Gas Safe
Registered Engineer. It must be carried out in accordance with
the relevant requirements of the:
• Gas Safety (Installation and Use) Regulations
• Appropriate Building Regulations, either The Building
Regulations, The Building Regulations (Scotland), Building
Regulations (Northern Ireland).
• Water Fittings Regulations or Water byelaws in Scotland.
• Current I.E.E. Wiring Regulations.
Where no specic instructions are given, reference should be
made to the relevant British Standard Code of Practice.
The Boiler has been tested and certied to;
BSEN 15502-1, BSEN 15502-2, BSEN 15502-2-1, BSEN
60335-1, BSEN 60335-2-102, BSEN 55014-1 and BSEN
55014-2 for use with Natural Gas & Propane.
Detailed recommendations are contained in the following
British Standard Codes of Practice:
BS5440:1 Flues (for gas appliances of rated input not
exceeding 70 kW).
BS5440:2 Ventilation (for gas appliances of rated input
not exceeding 70 kW).
BSEN12828 Heating Systems in buildings: Design for water
based heating systems.
BSEN12831 Heating Systems in buildings: Method for
calculation of the design heat load.
BSEN14336 Heating Systems in buildings: Installation
and commissioning of water based heating
systems.
BS5546 Installation of gas hot water supplies for
domestic purposes (2nd Family Gases)
BS6798 Installation of gas red hot water boilers of
rated
input not exceeding 70 kW.
BS6891 Installation and maintenance of low pressure
gas installation pipework.
BS 7593:2019 Code of practice for the preparation,
commissioning and maintenance of domestic
central heating and cooling water systems.
Health & Safety Document No. 635.
The Electricity at Work Regulations, 1989.
The manufacturer’s notes must NOT be taken, in any way, as
overriding statutory obligations.
IMPORTANT: This appliance is UKCA/CE certicated for
safety and performance. Do not connect external control devices
directly to this appliance unless recommended in this manual or
by Ideal Heating in writing. If in doubt, please enquire.
Unapproved control devices could invalidate the warranty of this
appliance and infringe the Gas Safety Regulations.
1.6 SAFE HANDLING OF SUBSTANCES
No asbestos, mercury or CFCs are included in any part of the
boiler or its manufacture.
1.7 LOCATION OF BOILER
The boiler must be installed on a at and vertical internal wall,
capable of adequately supporting the weight of the boiler and
any ancillary equipment.
The boiler may be tted on a combustible wall and insulation
between the wall and the boiler is not necessary, unless
required by the local authority.
WARNING: Rear access to the boiler is not permitted.
CAUTION: Do not t the boiler outside.
Timber Framed Buildings
Boilers installed in a timber-framed building must comply with
IGE/UP7 +A 2008.
Bathroom Installations
CAUTION: This appliance is IP20 rated, do not clean
with jets of water.
You may install the boiler in any internal space. The installation
must comply with the current IEE (BS 7671) Wiring Regulations
and the electrical regulations applicable in Scotland.
If the appliance is to be installed in a room containing a bath or
shower then the appliance must be installed beyond Zone 2,
as detailed in BS7671.
Bathroom Installations
[0] Zone 0
[1] Zone 1
[2] Zone 2
[2*] Without the end wall, zone 2 must extend 600 mm from the bath
[A] 600 mm radius from the bath or shower
0010017086-002
2
12
12
2
1
600 mm
600 mm
600 mm
2250 mm
2250 mm
2*
A
A
A
600
m
m

10
Installation and Servicing
Section 1 - General
The complete installation MUST be tested for gas tightness
and purged as described, for the majority of installations the
appropriate standard is IGEM/UP/1B [23], but alternatively
IGEM/UP/1 [21] or IGEM/UP/1A [22], as appropriate, can be
utilized.
1.10 WATER CIRCULATION SYSTEM
IMPORTANT: A minimum length of 1 metre of copper
pipe MUST be tted to both ow and return connections from
the boiler before connection to any plastic piping.
The central heating system should be in accordance with
BS6798 and, in addition, for smallbore and microbore systems,
BS EN 12828:2012+A1:2014.
Water treatment is covered later in these instructions.
Refer to Section
1.18
1.11 BOILER CONTROLS
Install CH controls to ensure the boiler has no demand when
there is no requirement from the system.
Heating systems with TRVs in individual rooms must include a
thermostat to control the temperature in rooms without TRVs.
At least 10% of the minimum boiler heat output should be
achieved using a room thermostat. A bypass circuit with an
automatic bypass valve must be tted to systems with TRVs or
two-port valves on all the radiators to ensure water ow.
1.12 ELECTRICALSUPPLY
WARNING: This appliance must be earthed
Wiring external to the appliance MUST be in accordance with
the current I.E.E. (BS7671) Wiring Regulations and any local
regulations which apply.
The mains supply to the boiler and system wiring centre
shall be through one common fused double pole isolator and
for new heating systems, and where practical replacement
installations, the isolator shall be situated adjacent to the
appliance.
1.13 CONDENSATE DRAIN
The condensate drain provided must be connected to the
drainage point on site. All condensate drainage pipework and
ttings must be made of plastic.
IMPORTANT: The condensate drain pipework should
be installed in accordance with BS6798.
The drain outlet on the boiler is sized for standard 21.5 mm
overow pipe. It is a universal tting to allow use of di󰀨erent
brands of pipework.
Refer to Section
2.15
Compartment Installations
A boiler installed in a compartment does not require ventilation.
However, A boiler installed in a compartment must provide
adequate clearances for servicing. The compartment should
also be tted with a suitable label in accordance with current
standards.
Refer to Section
1.14
1.8 AIR SUPPLY
t is not necessary to have an air vent in the room or internal
space where the boiler is installed.
1.9 GAS SUPPLY
Consult the local gas supplier to establish an adequate supply
of gas. Do not use existing service pipes without consulting the
local gas supplier.
The gas supply must be governed with a meter.
A gas meter can only be connected by the local gas supplier or
by a Gas Safe Registered Engineer.
An existing meter should be checked, preferably by the gas
supplier, to ensure that the meter is adequate to deal with the
required gas supply rate.
It is the responsibility of the Gas Installer to size the gas
installation pipework in accordance with BS6891.
Whilst the principle of the 1:1 gas valve ensures the Logic
range is able to deliver it is full output at inlet pressures as low
as 14 mb, other gas appliances in the property may not be as
tolerant. When operating pressures are found to be below the
minimum meter outlet of 19 mb these should be checked to
ensure this is adequate for correct and safe operation.
Allowing for the acceptable pressure loss of 1mb across the
installation pipework, it can be assumed that a minimum
permitted operating pressure of 18mb will be delivered to the
inlet of the appliance.
(Reference BS6400-1 Clause 6.2 Pressure Absorption).
The external gas cock could further reduce the operating
pressure when measured at its test point. The pressure drop is
relative to the heat input to the boiler (kW), refer to graph below.
Gas Cock Pressure Drop
Heat Input to Boiler (kW)
Pressure Drop (mbar)
0 5 10 15 20 25 30 35 40
1.4
1.2
1
0.8
0.6
0.4
0.2
0
IMPORTANT: Ensure all gas valve connections are gas
tight with a gas soundness check up to the gas control valve.
Installation pipes must be tted in accordance with BS6891.

11Installation and Servicing
Section 1 - General
1.14 BOILER DIMENSIONS, SERVICES & CLEARANCES
The boiler connections are made on the boiler connection
tails.
The following minimum clearances must be maintained
for operation and servicing.
Additional space will be required for installation, depending
upon site conditions.
Side and Rear Flue
a. Provided that the ue hole is cut accurately, e.g. with a core
drill, the ue can be installed from inside the building where
wall thicknesses do not exceed 600 mm.
Front Clearance
The minimum front clearance when built in to a cupboard is
5 mm from the cupboard door but 450 mm overall clearance
is still required, with the cupboard door open, to allow for
servicing.
* Bottom Clearance
Bottom clearance after installation can be reduced to 5 mm.
This must be obtained with an easily removable panel to
provide the 100 mm clearance required for servicing.
395
75
61
36
21
33
32
43.5 94
Refer to Section
2.17
278
700
100*
Flue
terminal
2.52.5 from case
Underside View - Dimension to Wall
CH
Flow DHW Outlet Gas DHW Inlet CH Return CH Circuit Drain
Cond.
Drain
98
200
152
PRV Grommet
Refer to Section
2.17
IMPORTANT: Please ensure there is su󰀩cient
clearance either side and below the boiler, particularly from
door hinges and the base of a cupboard.
Measurements in mm
PRV
Grommet
75
61
36
21
33
32
43.5 94
Water and Gas Connections
Data
Plate
CH
Flow DHW Outlet
PRV
Grommet
CH
Return
DHW
Inlet
Gas
Inlet
Cond.
Drain Measurements in mm

12
Installation and Servicing
Section 1 - General
a. The method of lling, relling, topping up or
ushing sealed primary hot water circuits from the
mains via a temporary hose connection is only
allowed if acceptable to the local water authority.
b. Antifreeze uid, corrosion and scale inhibitor uids
suitable for use with boilers having aluminium heat
exchangers may be used in the central heating
system.
General
1. The installation must comply with national and local
regulations.
2. Design the system for ow temperatures up to 80oC.
3. Thesystem componentsmustbesuitable foranoperating
pressure of 3 bar and a maximum temperature of 110°C.
The following components are incorporated within the
appliance:
a. Circulating pump.
b. PRV, with a non-adjustable preset lift pressure of
3 bar.
c. Pressure gauge, covering a range of 0 to 4 bar.
d. An 8 litre expansion vessel, with an initial charge
pressure of 0.75 bar.
4. Makeup Water. One of the following provisions must be
made for replacing system water loss:
a. Manually lled vessel
The vessel must:
Have a visible water level
Be mounted at least 150 mm above the system’s
highest point
Connect through a non-return valve to the system
Be at least 150 mm below the makeup vessel on
the return side of the radiators
b. System prepressurisation.
The e󰀩ciency of the expansion vessel will be
reduced in a pressurised system; a larger vessel
or smaller system volume may be necessary. If
the vessel’s capacity is not su󰀩cient, an additional
vessel must be installed on the return to the boiler.
If the system is not pressurised, the cold water
capacity must not exceed 143 litres.
Guidance on vessel sizing is given in table above.
1.15 SYSTEM REQUIREMENTS - CENTRALHEATING
Water Flow Rate and Pressure Loss
Max CH Output kW 24.2
Water Flow Rate l/min 17.3
(gal/min) (3.8)
Temperature Di󰀨erential oC 20
Head available for System m.w.g. 3.4
(ft.w.g.) (11.1)
PRV setting bar 3.0
Vessel charge pressure bar 0.5 to 0.75
System pre-charge pressure bar None 1.0
System volume Expansion vessel
(litres) volume (litres)
25 1.6 1.8
50 3.1 3.7
75 4.7 5.5
100 6.3 7.4
125 7.8 9.2
150 9.4 11.0
175 10.9 12.9
190 11.9 14.0
200 12.5 14.7
250 15.6 18.4
300 18.8 22.1
For other system volumes
multiply by the factor across 0.063 0.074
5. Filling
The system may be lled by the following method:
Where the mains pressure is excessive a pressure
reducing valve must be used to facilitate lling.
a. Thoroughly ush out the whole system with cold water.
b. Fill and vent the system until the pressure gauge
registers 1 bar and examine for leaks.
Refer to Section
2.17
c. Check that a 15 mm diameter pipe is correctly located
and secured (using the clip supplied)
d. Check the operation of the PRV by raising the water
pressure until the valve lifts. This should occur within
0.3 bar of the preset lift pressure.
e. Check no escape of water occurs except at the
discharge point
f. Release water from the system until the
minimum system design pressure is reached;
1.0 bar if the system is to be pre-pressurised.
DOMESTIC HOT WATER
1. The DHW service must be in accordance with BS5546 &
BS6700.
2. Refer to Table 1 for minimum and maximum working
pressures. In areas of low mains water pressures the
domestic hot water regulator may be removed from the DHW
ow turbine cartridge. The boiler will require the ow rate to be
set to obtain a temperature rise of 35oC at the tap furthest from
the boiler.
Refer to Section
1.2
3. The boilers are suitable for connection to most types of
washing machine and dishwasher appliances.
Table 4 Vessel Sizing

13Installation and Servicing
Section 1 - General
The boiler does not normally need a bypass but at least
some radiators on the heating circuit, of load of at least
10% of the minimum boiler output, must be provided with
twin lockshield valves so that this minimum heating load is
always available. See note regarding thermostatic radiator
valves on page 10.
Note. Systems incorporating zone valves which could
completely cut o󰀨 the ow through the system must also
include a bypass.
Balancing
1. Set the programmer to ON.
Close the manual or thermostatic valves on all
radiators, leaving the twin lockshield valves (on the
radiators referred to above) in the OPEN position.
Turn up the room thermostat and adjust the lockshield
valve to give an uninterrupted ow through the radiator.
These valves should now be left as set.
2. Open all manual or thermostatic radiator valves and
adjust the lockshield valves on the remaining radiators,
to give around 20oC temperature drop at each radiator.
3. Adjust the room thermostat and programmer to
NORMAL settings.
1.18 WATER TREATMENT
1.17 SYSTEM BALANCING
Central Heating
The Logic range of boilers have an ALUMINIUM alloy heat
exchanger.
IMPORTANT The application of any other treatment to
this product may render the guarantee of Ideal Heating
invalid.
Ideal Heating recommend Water Treatment in accordance
with the Benchmark Guidance Notes on Water Treatment in
Central Heating Systems.
If water treatment is used Ideal Heating recommend only the
use of SCALEMASTER SM-1 PRO, FERNOX, MBI,ADEY MC1,
SENTINEL X100 or CALMAG CM100 inhibitors and associated
water treatment products, which must be used in accordance
with the manufacturers’ instructions.
This boiler can be used with a water softener. However, the
heating system should not be lled with softened water as
any softening chemicals could enhance corrosion of certain
materials in the heating system, including aluminium and
steel. The heating system should always be lled from the
bypass on the water softener installation.
1. It is most important that the correct concentration of the
water treatment products is maintained in accordance
with the manufacturers’ instructions.
2. If the boiler is installed in an existing system any
unsuitable additives MUST be removed by thorough
cleansing. BS7593:2019 details the steps necessary to
clean a domestic heating system.
1.16 SYSTEM REQUIREMENTS - DHW
4. If the shower/mixer valve does not incorporate non-
return valves the following must be followed:
a. The cold inlet to the boiler is tted with an approved
anti-vacuum or syphon non-return valve.
b. Hot and cold water supplies to the shower are of
equal pressure.
5. Hard Water Areas Where the water hardness exceeds
200 mg/ litre (200 ppm), it is recommended that a
proprietary scale reducing device is tted into the boiler
cold supply within the requirements of the local water
company.
IMPORTANT Provision must be made to
accommodate the expansion of DHW contained within the
appliance. If the DHW inlet contains a back ow prevention
device or non-return valve, e.g. a water meter, then a mini
expansion vessel should be tted between the device and
the boiler in the cold inlet pipe.
Cold water, rising main and pipework in exposed areas
need to be suitably lagged to prevent freezing.
Note DHW Expansion Vessel kit available from Ideal.
3. In hard water areas, treatment to prevent lime scale
may be necessary.
4. Under no circumstances should the boiler be red
before the system has been thoroughly ushed.
Domestic Hot water
In hard water areas where mains water can exceed
200ppm Total Hardness (as dened by BS 7593 Table 2) a
scale reducing device should be tted into the boiler cold
supply within the requirements of the local water company.
The mains cold water feed can come from a water softener
as the materials used in the domestic hot water circuit are
fully resistant to any chemicals in softened water.
Ideal Heating recommend the use of Fernox Quantomat,
Sentinel Combiguard,Calmag CalPhos I scale reducing
devices or Scalemaster In-line Scale Inhibitor branded Ideal,
which must be used in accordance with the manufacturers’
instructions.
For further information contact:
Fernox - www.fernox.com. Tel: [phone]
Sentinel Performance Solutions
www.sentinelprotects.com. Tel: [phone]
Scalemaster Water Treatment Products
www.scalemaster.co.uk. Tel: [phone]
Calmag Ltd. - www.calmag Ltd.com.
Tel: [phone]
Adey - www.adey.com. Tel: [phone]

14
Installation and Servicing
Section 2 - Installation
INSTALLATION
2.1 BOILERASSEMBLY - EXPLODED VIEW
Note that item numbers are linked to the spares list
104 CH Return Valve
105 CH Flow Valve
106 DHW Inlet & Outlet
107 Filling Loop Pipe
108 Pump Head
110 Auto Air Vent
111 Diverter Valve Motor
112 Diverter Valve Body & Paddle
113 Pressure Relief Valve
114 Pipe - PRV Outlet
115 Pipe - Flow
116 Pipe - Return
117 Pipe - Expansion Vessel
118 Expansion Vessel
119 Return Group Manifold
120 Flow Group Manifold
121 Plate Heat Exchanger
124 Flow Regulator
127 Flow Sensor/Turbine
131 Water Pressure Switch
135 Pressure Gauge
203 Gas Cock
205 Gas Valve
206 Pipe - Gas Injector
211 Injector Assy
214 Venturi
215 Fan
217 Burner
218 Gasket - Burner
219 Sump Clean Out Cover
223 Flue Manifold
224 Flue Manifold Top
227 Clamp Retaining Flue Turret
228 Hose Condensate Internal
229 Condensate Trap
231 Condensate Outlet Connection
239 Condensate Drain Tube
302 PCB
306 Ignition/Detection Electrode
308 Ignitor Unit
309 Thermistor
313 Ignition Lead
324 Control Box Lid
325 Control Box Front
326 Blank Insert
401 Heat Engine
503 Wall Mounting Bracket
504 Front Panel
505 Fascia
506 Bracket - Spark Generator
507 Bracket - Expansion Vessel
504
505
215
227
224 503
223
214
217
118
507
313
229
326 325
302
324
135
108 117
119
114
121
111
112
219
110
113
218
401
506
306
308
211
205
124
131
116
107
105 106
106
203
104
115
309
228
206
231
127
120
239
309
1
0
2
3
4
bar

15Installation and Servicing
Section 2 - Installation
INSTALLATION
2.2 UNPACKING
The boiler is supplied fully assembled in Pack A.
Pack A Contents
1. Boiler
2. Hardware Pack Box
3. Wall Mounting Plate
4. These Installation/Users Instructions
5. Boiler Warranty
6. Wall Mounting Template
Hardware Pack
Box Contents
7. 1x HP Box Dividers - 289 x 111 x 57.5 mm
8. 1x Plug Male and Clip
9. 1x Pipe DHW Outlet
10. 1x Pipe Filling Loop
11. 1x Valve DHW Inlet
12. 2x Pipe CH Flow/Return
13. 1x Valve Filling Loop
14. 1x Valve CH G3/4x 22 mm Filling Loop
15. 1x Cap Female
16. 1x Valve CH G3/4x 22 mm
17. 1x Pipe DHW Inlet
18. 1x Nut G1/216 Brass (Flat)
19. 1x Gas Cock
20. 1x PRV Clip
Accessory Bag Contents
21. 9x Washers*
22. 2x Wall Plugs
23. 2x Screws
24. 1x Flue Clamp Screw
22 23
21
1
2
3
46
5
Unpack and check the contents
8
11
19
18
16
12
13
14
17
15
10
9
7
24
*Refer to Valve Washer Template inside box lid.
Refer to Section
2.17
IMPORTANT This clip needs to be tted
to ensure correct operation of the boiler.
20

16
Installation and Servicing
Section 2 - Installation
INSTALLATION
The wall mounting template is located on the internal
protective packaging. The template shows the position
of the xing and rear ue centre holes for a standard
installation
Care MUST be taken to ensure the correct holes are drilled.
1. Secure the template into the required position. Ensure it
is square by hanging a plumbline.
2. If tting a side ue, extend the ue centreline onto the
side by 155 mm on a standard wall x or 200 mm if
using a stand-o󰀨 bracket.
3. Mark the following on to the wall:
a The selected group of wall mounting screw holes.
b. The centre position of the ue duct. Marking both the
centre and the circumference of the ue duct.
4. Remove the template plate from the wall.
2.3 WALL MOUNTING TEMPLATE
2.4 PREPARING THE WALL
“A”
Extended centre line
155
(200)
X
Section
through wall
Side flue only
127 mm diameter hole
Rear flue only
127 mm diameter hole
Refer to Section
2.8
1. Check all of the hole positions before drilling.
2. Cut the ue hole with a 127 mm core boring tool, ensure
the hole is square to the wall.
3. Drill the 2 mounting holes with a 7.5 mm / 8 mm masonry
drill and insert the plastic plugs provided.
4.
Locate 2 No.14 x 50 mm screws in the wall mounting plate
(one at each side, in any of the 3 holes provided at each
side) and screw home. Ensure mounting bracket is level.
2.5 FITTING THE WALLMOUNTING PLATE
1. Lift the boiler onto the wall mounting plate and locate
it over the 2 tabs.
2.6 MOUNTING THE BOILER
1. Screw the wall mounting plate to the wall using 2 wall
plugs tted previously with the 2 screws provided.
2. Choose one of the 2 sets of slots in left and right bank.
Ensure that at least one of the screws is tted into a top
slot and the mounting bracket is level.
esp9496
Example of fixing
WARNING: Ensure that, during the cutting
operation, masonry falling outside of the building
does not cause damage or personal injury.

17
Installation and Servicing
FLUE OUTLET
Section 2 - Installation
2.7 FLUESAND LOCATIONS
This installation & servicing manual must be read in conjunction with ue kit and tting guide.
Flue deflector
Ideal part no.
208176
Flue extension
0.5 m, 1 m or 2 m
Weather collar
flat roof
Ideal part no.
152259
Ideal part no.
203130
Flue elbow 90°
Ideal part no.
203131
Flue elbow 45°
Horizontal flue
0.6 or 0.8 m
Ideal part no.
0.5 m 208169
0.7 m 208174
Telescopic
horizontal flue
0.5 or 0.7 m
Ideal part no.
211039
Vertical flue
terminal and
connector
Weather collar
Ideal part no.
152258
Ideal part no.
0.5 m 211037
1 m 203129
2 m 211038
Balcony flue kit
Ideal part no. 208177
Soffit kit
Ideal part no. 211302
Raised horizontal flue kit
Ideal part no. 208290
pitched roof
0.6 m 208171
0.8 m 217442
Ideal part no.
WARNING:
• It is critical that products of combustion cannot re-enter
the building
• The ue terminal must always have a free passage of
air.
CAUTION:
• White sections of the ue must not be visable outside.
• Install a ue terminal guard where the ue terminal is less
than 2 metres above a platform where persons can walk
or come into contact with the terminal.
• Water is the only permitted lubricant for ue assembly.
Rubber
Terminal
Wall Seal
Terminal
MUST be
fitted as
shown

18
Installation and Servicing
FLUE OUTLET
Section 2 - Installation
1 m
2 m
3 m
4 m
26 mm
52 mm
78 mm
104 mm
L
2.8 FLUESAND LOCATIONS - CONTINUED
B = Top Clearance
Top Clearance is measure from the top of the turret to the top
of the hole where the ue terminates.
L = E󰀨ective ue length.
The e󰀨ective length of the ue is measured from the edge of
the turret to the ue terminal lip.
Flue systems that require extension kits must be installed
with a 1.5° decline from the ue terminal back to the boiler.
A 1.5° decline can be achieved by designing the ue with a
26 mm rise per meter length of ue.
Flue Terminal Positions Min. Spacing*
1. Directly below, above or alongside an opening. 300 mm
2. Below guttering, drain pipes or soil pipes. 75 mm
25 mm*
3. Below eaves. 200 mm
25 mm*
4. Below balconies or a car port roof. 200 mm
25 mm*
5. From vertical drain pipes or soil pipes. 150 mm
25 mm*
6. From an internal or external corner or a 300 mm
boundary alongside the terminal. 25 mm*
7. Above adjacent ground, roof or balcony level. 300 mm
8.
From a surface or a boundary facing the terminal. 600 mm
9. From a terminal facing a terminal. 1200 mm
10. From an opening in a car port into dwelling. 1200 mm
11. Vertically from a terminal on the same wall. 1500 mm
12. Horizontally from a terminal wall. 300 mm
13. Horizontally from an adjacent window 600 mm
14. Facing an opening into an adjacent building 2000 mm
15. At an angle to the boundary 90° 300 mm
45° 600 mm
16. Parallel to a boundary 300 mm
17. Below ground level – open light well
a) Below ground <1,000 mm
b) Above oor level 300 mm
c) From side 300 mm
d) From facing surface 600 mm
*Only one reduction down to 25mm is allowed per installation.
Table 5 - Flue Terminal Position
IMPORTANT INFORMATION
Install the ue in accordance to BS 5440:1 2008
Position the terminal, so the products of combustion do not
cause a nuisance.
The terminal outlet duct must not be closer than 25 mm to
combustible material.
The ue is secured in the wall using either sand and cement
or heatproof silicone.
The ue must be supported by a bracket every metre of ue
length and at every change of direction. Concealed ues
must have inspection hatches no more than 1.5 metres from
joints.
Where possible inspection hatches should be located at
change of directions. Where this is not possible then bends
must be viewable from both sides.
Inspection hatches must be at least 300 mm
2
.
B
Horizontal Maximum E󰀨ective Flue Length
24 kW 9.0 metres
30 kW 8.0 metres
35 kW 6.0 metres
Vertical
24/30/35 kW 7.5 metres
Elbows increase resistance and have an e󰀨ective ue
length equivalence. The following table is an example.
Part Resistance
45oelbow 0.6 metres
90oelbow 1.0 metres

19
Installation and Servicing
FLUE OUTLET
Section 2 - Installation
2.9 HORIZONTALFLUE POSITIONS
2.10 VERTICALFLUE POSITIONS
16
17
6
7
8
9
10 11
12
13
14
15
1
2
3
4
5
1
1
6
6
7
Boundary
Boundary
600
300
300 c.
300 b.
600 d.
300
a. < 1000
3
2
1
600
345
1
2
2000
Opening in adjacent
building
14
3
1
2
300
At an angle to the
boundary
15
2
Parallel to the
boundary
16
Facing the
boundary
8
600
1
300
3
All measurements : mm
Boundary
Boundary
600
Height Difference ‘A’
Less than 300 B= 300
Greater than 300 B = 1500
300
625
fixed
2000
600
2000
690
Fixed
Separation
Distance
‘B’
Height
Difference
‘A’
300
600 600
2000
All measurements : mm
Refer to Table 5
Refer to Table 5

20
Installation and Servicing
FLUE OUTLET
Section 2 - Installation
2.11 FLUE SYSTEM DIMENSIONS 2.12 FITTING THE TURRET
Flue Design
IMPORTANT:
1. Flue lengths may vary, always measure ue lengths
before cutting.
2. E󰀨ective ue length and actual ue length are di󰀨erent
measurements.
3. E󰀨ective ue length is made up of the ue length
equivalence and the ue sections between the turret,
elbows and terminal.
4. Actual ue length is the amount of ue needed to achieve
the e󰀨ective ue length, this includes insertions.
Retaining
screw Clamp Lugs
Sample points
Flue Outlet
C
A
A - Duct Assembly
B - Flue Turret
C - Turret Clamp
D - Seal
Flue Outlet
D
B
1. Ensure the condensate trap in lled with water
2. Ensure the rubber seal is not damaged and tted
correctly on the appliance manifold.
3. Firmly hold the ue and push the turret on until it has
travelled 30 mm ensuring the ue has not rotated or
moved forward.
4. Push the turret into the manifold ensuring the upper
plastic lip is ush with the top of the manifold.
5. Fully engage the clamp location section into the manifold
location hole and rotate down onto the ange.
6. Use the securing screws to secure the clamp to the
appliance.
7. Ensure all sample points are accessible and all sample
plugs and caps are tted.
30
30
Elbow insertion (mm)Turret insertion (mm)
100mm
Edge of turret
to outside face of wall plus
44mm = ue length
A
WALL
Part Actual
Length
Insertion E󰀨ective
Length
1 m ue length 1000 mm 30 mm 970 mm
90° elbow n/a 1000 mm
1 m ue length 1000 mm 30 mm 970 mm
90° elbow n/a 1000 mm
0.6 m ue terminal 600 mm 30 mm 570 mm
Total 4.510 mm
