INSTALLATION AND
SERVICING
ECOMOD AHP60
26 and 32 kW
Air/water monobloc heat pump
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal.
For the very latest copy of literature for specification and maintenance practices visit our website www.idealcommercialboilers.com
where you can download the relevant information in PDF format.
September 2022
UIN 00U07352250-A

01-07-2022 3 / 74
AHP60 26/32 kW - Installation, Use and Maintenance
CONTENTS
1. REGULATIONS, RECOMMENDATIONS AND WARNINGS..............................................................5
1.1. Applicable regulations and standards ........................................................................................................... 5
1.2. Recommendations and warnings................................................................................................................. 5
2. DESCRIPTION OF THE EQUIPMENT ..............................................................................15
2.1. Designations and scope.............................................................................................................................. 15
2.2. Packaging ................................................................................................................................................... 15
 ................................................................................................................................................... 15
2.4. Technical data ............................................................................................................................................. 16
2.5. Description .................................................................................................................................................. 20
2.6. Operating principle ...................................................................................................................................... 22
3. INSTALLATION ...................................................................................................................24
3.1. Lifting and handling ..................................................................................................................................... 24
3.2. Location....................................................................................................................................................... 25
3.3. Installing the outdoor unit ............................................................................................................................ 25
3.4. Control unit installation................................................................................................................................ 32
3.5. Hydraulic connections ................................................................................................................................. 33
3.6. Electrical connections ................................................................................................................................. 39
4. PRE-REQUISITES BEFORE COMMISSIONING .............................................................44
................................................................................................................... 44
4.2. Switching On ............................................................................................................................................... 45
4.3. Commissioning ........................................................................................................................................... 45
 ............................................................................................... 45
4.5. Operating diagram .......................................................................................................................................46
4.6. HMI navigation ............................................................................................................................................ 48
5. CONTROL INTERFACE .....................................................................................................49
5.1. User interface.............................................................................................................................................. 49
5.2. “Set” setpoint menu (For manual operation only) .................................................................50
5.3. Sensor menu [TP] ....................................................................................................................................... 51
5.4. Error menu [Err] .......................................................................................................................................... 51
5.5. Operating hours menu [OHR] ..................................................................................................................... 51
5.6. Parameter menu [Par]................................................................................................................................. 51
6. TROUBLESHOOTING ........................................................................................................52
6.1. Troubleshooting of failures without error code ........................................................................................... 52
6.2. Error codes and diagnostic assistance ....................................................................................................... 52
6.3. Inverter board errors ................................................................................................................................... 56
󰀨........................................................................................................ 58
7. OUTDOOR UNIT MAINTENANCE ....................................................................................59
7.1. Draining water from the outdoor unit........................................................................................................... 59
7.2. Filling the outdoor unit with water................................................................................................................ 59
7.3. Prolonged shutdown ................................................................................................................................... 59

4 / 74 00U07352250-A_EN 01.07.2022 5 / 74
7.4. Periodic checks ........................................................................................................................................... 60
7.5. Cleaning the external surfaces.................................................................................................................... 62
7.6. Maintenance of the outdoor unit.................................................................................................................. 62
7.7. Residual safety risks ................................................................................................................................... 63
7.8. Heavy maintenance .................................................................................................................................... 64
7.9. “Maintenance” check list ............................................................................................................................. 65
8. END OF PRODUCT LIFE- ..................................................................................................71
■Symbols used in this document
INFORMATION: This symbol draws attention to comments.
CAUTION: Failure to comply with these instructions may cause damage to the
installation or to other objects.
DANGER: Failure to comply with these instructions may cause electrocution.
DANGER: Failure to comply with these instructions may cause injury and serious
material damage.

4 / 74 00U07352250-A_EN 01.07.2022 5 / 74
1. REGULATIONS, RECOMMENDATIONS AND WARNINGS
1.1. Applicable regulations and standards
This outdoor heat pump has been designed in accordance with current regulations and
must be used accordingly. See the list of standards on the back cover.
This device must be transported in compliance with the Local Laws.
This device and its refrigerant R32 must be handled in compliance with the application

  
517/2014.
It must be installed in compliance with local or national regulations such as the RSD (Local
sanitary Regulations), and in accordance with standard EN 378-3: 2016 concerning the
installation of heat pumps.
The electrical connection must be made in compliance with the Current I.E.E. (BS7671)
Wiring Regulations standard.
The hydraulic connection must be made in compliance with the Local Laws
Regulations covering Maintenance
The appliance must be installed and maintained by an approved professional in
accordance with the prevailing regulations and code of practice, in particular:
- The legislation on the handling of refrigerants
- Current I.E.E. (BS7671) Wiring Regulations
CAUTION:
This device must be maintained by qualied personnel with a certicate of capacity
for the handling of refrigerants.
1.2. Recommendations and warnings
1.2.1. Transport and storage
The outdoor appliance and the hydraulic station:
- must be stored in a place where the temperature is between 
a relative humidity between 5 and 95%.
- must not be stacked,
- must be protected from humidity.
Transport and storage must comply with the national standards in force. In particular,
according to the provisions (see below), the maximum total quantity per transport unit

Handling
The outdoor unit must not be in a horizontal position during transport.
Transport in a horizontal position may damage the appliance by moving the refrigerant
and damaging the compressor's suspensions.
Damage caused by transportation in a horizontal position is not covered by the warranty.
If necessary, the outdoor unit may be tilted during manual handling (to go through a door
or use a staircase). This operation must be conducted very carefully and the appliance
must be immediately restored to the upright position.

6 / 74 00U07352250-A_EN 01.07.2022 7 / 74
1.2.2. Unpacking the unit
Acceptance
With the carrier present, carefully check the general appearance of the packaging and the
appliances. Check that the outdoor appliance has not been placed in a horizontal position.
In the event of disagreement, write to the carrier within 48 hours mentioning all reserves and
send a copy of this letter to the After Sales Department.
Before unpacking the appliance, check that there are no refrigerant leaks using a suitable
detector. Check that there are no ignition sources near the unit.
Smoking is forbidden near to the unit.
1.2.3. Safety recommendations related to the presence of the R32 refrigerant
The handling and installation of this outdoor appliance must only be performed by personnel

laws, directives and standards applicable in each country.

potential risk at each stage of the machine's life cycle. This standard was also used to design
this machine.
In the absence of local building codes or safety standards, the installation and maintenance of
the machine may follow the elements outlined in this standard; in particular, it is the responsibility
of the installer and personnel performing operations on this machine to perform a risk analysis
prior to any installation and work on the machine.
The elements indicated below are not exhaustive given the diversity of the possible
installations and interventions; they cannot be considered as an undertaking as to the
responsibility of Ideal Heating. These elements cannot replace a risk analysis, which
remains the responsibility of the installer and the personnel working on the machines.
Designation R32.
INDICATION OF DANGERS
Main dangers: Asphyxia.
 The rapidity of evaporation can cause burns.
EMERGENCY MEASURES
General information Do not give anything to persons who have fainted.
Inhalation:
Take the person to fresh air.

Do not administer adrenaline or similar substances.
Contact with the eyes: Rinse thoroughly with water for at least 15 minutes and seek
medical attention.
Contact with the skin:
Rinse thoroughly with water for at least 15 minutes. Apply a sterile
gauze.
Remove contaminated clothing immediately.
FIRE PREVENTION MEASURES
Extinguishers: Water spray, dry powder.
 Rupture or explosion of the recipient.

Cool down the recipients by spraying with water from a safe
position. If possible, stop the product from leaking. If possible, use
a water spray to hose down the smoke. Move the recipients well


6 / 74 00U07352250-A_EN 01.07.2022 7 / 74
MEASURES IN THE EVENT OF AN ACCIDENTAL LEAK
Individual precautions:
Use personal protection equipment.
Evacuate the personnel to safe areas.
Eliminate ignition sources.
Ensure there is adequate ventilation.
Environmental precautions: Try to stop the leak.
Cleaning methods: Ventilate the area.
HANDLING AND STORAGE
Handling:
Technical measures/precautions: Ensure that the premises have adequate air renewal/extraction .
Recommendations for safe use: Do not breathe in the vapours or use aerosols.
Storage
Close tightly and store in a cool, dry, well-ventilated place.
Keep in original recipients. Incompatible products: explosives,

CONTROLLED EXPOSURE/INDIVIDUAL PROTECTION
Control parameters:
󰀨
󰀨
󰀨



Respiratory protection:
Protection of the eyes:
Not necessary.
Safety glasses.
Protection of the hands: Rubber gloves.
Hygiene measures: Do not smoke!
PHYSICAL AND CHEMICAL PROPERTIES
Colour Colourless.
Smell: Ethereal. Hardly perceptible in low concentrations.
Boiling point: 
Flash point: 
 13%
 32%
 1.8
 1.1
Solubility in water: 280000 mg/l.
STABILITY AND REACTIVITY
Stability: Stable in normal conditions.
Materials to be avoided:
Hazardous decomposition products
Hazardous:
Air, oxidising agents, humidity.
In normal conditions of storage and use, no hazardous
decomposition product should be generated.

8 / 74 00U07352250-A_EN 01.07.2022 9 / 74
TOXICOLOGICAL INFORMATION
High toxicity:
󰀨
Long term toxicity:

󰀨
󰀨
ENVIRONMENTAL INFORMATION
Global warming potential
 675
Ozone damage potential ODP


0
Disposal Considerations: Comply with the supplier’s gas collection programme. Avoid direct
emission into the atmosphere.
■ Specic warnings on the R32 refrigerant
The R32 refrigerant:
- is odourless;



It is essential to follow the following guidelines:
- do not smoke near to the appliance ;
- put up no smoking signs near to the appliance ;
- make sure that the installation location is well ventilated
- do not pierce or burn the appliance ;

etc.;
- any special work or repairs to the appliance must be carried out by specialised technicians

■ R32 refrigerant load
The procedures described below must only be performed by specialised technicians or
qualied personnel:
- ensure that other types de refrigerant do not contaminate the R32;
- keep the gas bottle in a vertical position when loading it;
- put a suitable label on the unit after loading it;
- do not load more refrigerant gas than needed;
- before loading, search for leaks before carrying out an operating test. This operation has two
purposes, to control the quantity of refrigerant loaded and to check the circuit for leaks,
- after the operating test, we recommend carrying out another leak test,
■ Eliminating the R32 refrigerant
Follow the standardised procedures for collecting refrigerants, which may only be carried
out by specialised technicians or qualied personnel, and return it to the supplier.
■ Installation precaution related to the refrigerant
If local construction codes or safety standards don’t exist, the information shown below are
taken from the standard EN378: 2016 may be used for information; they may be used as a
guide for the safe use of machines that use R32 as a refrigerant.
This outdoor unit must not be installed in a place that can the general public or untrained,

It is designed to be installed outdoors, in open air. A shelter or alcove in which at least one of
the longest walls is open to the outside air by louvers having a free area of 75% and covering

8 / 74 00U07352250-A_EN 01.07.2022 9 / 74
at least 80% of the wall (or the equivalent if more than one wall is open to the outside air), is
considered to be open to the outside air.
It must be located so that no refrigerant leaks can enter the building and/or endanger people and
property. Therefore:
It must not be possible for the refrigerant to spill into a ventilation duct, under a door,
hatch or similar opening in case of a leak. For this reason, the installer must ensure that
there is a distance of at least 1m between the unit and any such opening. When a shelter
is provided for the refrigerant appliance in the open air, this shelter must be equipped with
a natural or forced ventilation device.
For refrigerant appliances which are installed outdoors at a location where a refrigerant
release may stagnate, for example, below ground level, the installation must meet the
requirements relative to gas detection and machine room ventilation.
1.2.4. Recommendations for hydraulic and electrical circuits
■Hydraulic connections
The connection must comply with good engineering practices according to the regulations in
force.
Reminder: Make the assembly seals according to good engineering practices in force for plumbing
work:
- 
- 
- Use sealant (synthetic as required).
■ Characteristics of the water for the appliance
     
indications at the beginning of this section) and the quantity of dissolved must be minimised.
Refer to chapter 3.6.4. For further recommendations.
The maximum authorised values are as follows:
Use glycol water if the room where the primary/secondary storage tank(s) is/are installed is
not frost-free; we recommend that this situation be temporary so as not to alter the system's
MAXIMUM AUTHORISED PHYSICAL-CHEMICAL CHARACTERISTICS AUTHORISED FOR THE INSTALLATION
WATER
PH 7.5 - 9
Electrical conductivity 
Total hardness 
Temperature 
Oxygen content 
Max. quantity of glycol 40%
Iron (Fe) < 0.3 ppm
Chlorine ions (Cl-) < 50 ppm

10 / 74 00U07352250-A_EN 01.07.2022 11 / 74

If glycol water is used, plan an annual control of the glycol quality. Use monopropylene
type glycol only. The recommended concentration should not exceed 40%.
If glycol is not used, trace the pipes electrically outside.
• In certain installations, the presence of di󰀨erent metals can cause corrosion
problems; in this case, the formation of metal particles and sludge in the
hydraulic circuit is seen.
- Please refer to the chapter "Treatment of domestic and heating water" in our price
catalogue
• It is also necessary to ensure that the treated water does not become aggressive
for the circuit.
■Electrical connections
          󰀨   
repair work.
Characteristics of the electrical power supply
󰀨
and in particular to current I.E.E. (BS7671) Wiring Regulations
󰀨

For installations without neutral, a galvanic isolating transformer must be used that is
earthed on the secondary side.
The electrical connections will only be made when all of the other assembly operations
(attachment, assembly,...) have been carried out.
Never use a socket for the power supply.
CAUTION:
The contract with the energy supplier must cover the maximum electrical requirement of
the installation.
The outdoor unit must be supplied directly (without external switch) by a dedicated line
protected at the start by a dedicated isolator switch. (Seer “Current source” paragraph).
Percentage of
glycol Freezing point [°C] Eciency cor- recon factor
Absorbed power
correcon factor
Water ow rate
correcon factor
Loss of head cor-
recon factor
10% -3.2 0.985 1 1.02 1.08
20% -7.8 0.98 0.99 1.05 1.12
30% -14.1 0.97 0.98 1.10 1.22
40% -22.3 0.965 0.97 1.14 1.25

10 / 74 00U07352250-A_EN 01.07.2022 11 / 74
Example of recommended connection diagram (non exhaustive)
TO THE EXPANSION
SYSTEM
COMMAND TO ELECT. CABINET

12 / 74 00U07352250-A_EN 01.07.2022 13 / 74
1.2.5. General safety rules
Before starting any operation on the units, each operator must be fully familiar with
the operation of the machine and its controls and have read and understood all the
information contained in this manual.
The removal and/or handling of any safety device is strictly prohibited.
Children and unaccompanied disabled people are not allowed to use the device.
It is forbidden to touch the device barefoot and with wet or wet parts of the body.
Any cleaning operation is prohibited when the main switch is in position « ON ».
It is forbidden to pull, unplug or twist the electrical cables coming out of the device, even if it is
disconnected from the power supply.
It is forbidden to stand on the device, to sit on it and/or to put objects of any kind on it.
It is forbidden to splash the device or project water on it.
It is forbidden to disperse, deposit or leave within the reach of children the packaging material
(cardboard, staples, plastic bags ... etc.) because it can be a potential source of danger.
Any ordinary or extraordinary maintenance operation must be carried out at a standstill, without
power supply.
Do not put your hands or introduce screwdrivers, wrenches or other tools into moving parts.
The machine manager and the maintenance technician must receive the appropriate training
and instruction for their tasks in safe conditions.
Operators should be familiar with personal protective equipment and accident prevention rules
prescribed by national and international laws and standards.
1.2.6. Worker safety
Anywhere the unit is installed, the applicable local laws regarding worker safety and
health must be accurately respected and enforced by each employer. We therefore
recall that:
It is forbidden to handle or replace parts of the machine without the express permission of the
manufacturer. These interventions release the manufacturer from any civil or criminal liability..
The use of components, consumables or spare parts other than those recommended by the
manufacturer and/or mentioned in this manual may constitute a danger to operators and/or
damage the machine.
The operator’s workstation must be kept clean, tidy and free of objects which may restrict his
󰀩
󰀩
Ensure the appropriate ventilation of the work zone is always guaranteed. Ensure the air suction
systems are operating correctly, in optimal conditions, and comply with the legal measures..
During the design phase, the indications contained in UNI EN ISO 14738 were followed with
regard to workstations on machines and the lifting limits imposed by UNI ISO 11228-1 were
evaluated.

12 / 74 00U07352250-A_EN 01.07.2022 13 / 74
Be sure to maintain a posture that does not cause fatigue when installing and maintaining the
unit. Also check the weight of any component before handling it.
The unit works with the refrigerant R32, included in the list of greenhouse gases (GWP
675) that meet the requirements of EU Regulation No. 517/2014 known as “F-GAS”
(mandatory in the European area). One of the provisions of this Regulation requires

recognised by the competent authority attesting that they have passed an examination
authorising them to carry out such work. In detail :


Refrigerant R32 in gaseous form is heavier than air, if it is dispersed in the environment,
it tends to concentrate strongly in poorly ventilated areas. Inhalation can cause dizziness
󰀨
be emitted (see Refrigerant Material Safety Data Sheet).
You should know that refrigerants may not develop an odor.
For any intervention on the heat pump system:
Wear appropriate PPE (especially gloves and goggles).
Ensure that the workplace is well ventilated. Do not work in closed rooms or ditches with low
air recirculation.

Avoid any dispersion of the refrigerant in the environment and pay particular attention to


1.2.7. Personal protective equipment
When using and maintaining units, it is necessary to provide for the use of personal
protective equipment such as:
Clothing: People who perform maintenance or work on the system must wear clothing that
does not leave parts of the body uncovered, because during maintenance it is possible to come
into contact with hot or sharp surfaces. Avoid clothing that can cling to or be sucked in by the


Gloves: Protective gloves must be worn during cleaning and maintenance interventions.
Mask and goggles: Goggles and a respiratory protective mask should be used during cleaning
operations.

14 / 74 00U07352250-A_ EN
AHP60 26/32 kW - Installation, Use and Maintenance
?

01-07-2022 15 / 74
AHP60 26/32 kW - Installation, Use and Maintenance
2. DESCRIPTION OF THE EQUIPMENT
2.1. Designations and scope
Ecomod hot water production system for heating networks or thermodynamic domestic hot
water production system.
2.2. Packaging
Outdoor unit
Model Code
ECOMOD 26 AH090915
ECOMOD 32 AH090918
ECOMOD 26 AC AH090916
ECOMOD 32 AC AH090919
Other accessories according to connection - see Ecomod Heat Pump Control manual, heating appli-
cation or DHW application.
The evaporator for the AC version is treated against corrosion. The heat pump's performance may be
󰀨2.4.1
2.3. Denitions
Change to monobloc heat pump : to be installed outdoors only for heating and/or domestic hot
water application .
air/water : The outdoor air is the energysource. This energy is transmitted to the primary water
circuit by the heat pump.
inverter : The fan and compressor speeds are modulated to suit the heat requirements which
allows the noise level to be reduced. This technology makes it possible to save energy by avoiding
high starting currents and by adjusting the power to the load.
󰀩 : instantaneously, this is the ratio between the energy transmitted
to the heating circuit and the electrical energy consumed.
DHW : Domestic hot water
CAUTION: The minimum admissible temperature for the storage of the units is 5°C.

16 / 74 00U07352250-A_ EN
AHP60 26/32 kW - Installation, Use and Maintenance
TECHNICAL CHARACTERISTICS Measurement
units
AHP 60
26 kW 32 kW
Heating
Heat output (1)
min/nom/max kW 9.5 / 26.0 /
27.3*
11.9 / 32.1 /
33.9*
Absorbed power (1) kW 6.44 7.84
C.O.P. (1) W/W 4.04 4.09
Nom thermal power (2) kW 25.1* 31.8*
Absorbed power (2) kW 9.51 12.10
C.O.P. (2) W/W 2.64 2.64
SCOP (3) W/W 4.55 4.81
 m3/h 4.5 5.5
Useful head (1) kPa 55 48
󰀩
 Class  
Compressor
Type Twin Rotary DC Inverter
Oil (type) FW65S or equivalent
Number of compressors 1 1
Quantity of oil L 1.5 1.5
Refrigerating circuits 1 1
Refrigerant
Type R32 R32
Refrigerant load (4) kg 4.3 5.1
Quantity of refrigerant in equivalent of CO(4) t 2.90 3.44
Operating pressure (high/low) in heat pump mode bar 42.8/1.3 42.8/1.3
Internal
exchanger
Water content L 1.7 2.1
Internal exchanger type Plates
2.4. Technical data
2.4.1. Data sheet for standard units
This product is designed to be installed at a maximum altitude of 2000m
(*) with the Hz maximum function activated

01-07-2022 17 / 74
AHP60 26/32 kW - Installation, Use and Maintenance
TECHNICAL CHARACTERISTICS Measurement
units
AHP 60
26 kW 32 kW
Hydraulic
circuit
Hydraulic circuit water capacity L 2.4 3.4
Maximum service pressure bar 6 6
Hydraulic connections Ø 1"M 1" 1/4M
Minimum volume of water for bottle L 110 110
Nominal power of the circulator kW 0.31 0.31
Maximum power of circulator kW 0.31 0.31
Max absorbed current of the circulator A 1.37 1.37
󰀩  
Acoustic level
Noise level Lw (5) dB (A) 74 76
Noise level Lw (6) 65 67
Acoustic pressure at a distance of 1 m Lp1 (7) dB (A) 58.1 60.1
Acoustic pressure at a distance of 10 m Lp1 (7) dB (A) 42.5 44.5
Electrical data
Power supply 
Maximum absorbed power kW 12.5 14.8
Maximum current absorbed A 23.3 27.1
Fan
Type Brushless DC motor
Maximum power of fan kW 0.83 0.83
Maximum current absorbed A 1.45 1.45
 m³/h 10812 11741
Dimensions
and weight
A - Length mm 1600 1600
B - Width mm 680 680
C - Height mm 1315 1315
A - Length packed mm 1660 1660
B - Width packed mm 700 700
C - Height packed mm 1412 1412
Weight for shipping kg 250 265
Weight in service kg 240 255
The above performances are given for the following operating conditions, as per the standard 14511:2018:
               



(4) Indicative data and subject to variation. For the correct data, always refer to the data label on the unit.
(5) Sound power: heating mode condition (1) according to EN 12102-1:2013; value calculated on the basis of
measurements made in accordance with UNI EN ISO 9614-1.
(6) Sound power: partial load heating mode according to Annex A of EN 12102:2017; value determined on the basis
of measurements carried out in accordance with UNI EN ISO 9614-1, in accordance with the requirements of HP

(7) Sound pressure: value calculated from the sound power level (5) according to ISO 3744:2010
N.B. : the performance date is indicative data and subject to variation. In addition, the outputs declared in (1),
(2), (3) and (4) are in relation to the instant power according to standard EN 14511. The gure indicated in points
(5) and (6) is determined based on standard EN 14825.

18 / 74 00U07352250-A_ EN
AHP60 26/32 kW - Installation, Use and Maintenance
2.4.2. Electrical data for the unit and auxiliaries

REMARK: The electrical data may be modied. You must consequently refer to the data label on the RH side
panel of the appliance.
2.4.3. Sound emissions
The acoustic pressure datas are calculated from the acoustic power level in compliance with

2.4.3.1. Full load
The noise levels are for the units under full load in normal test conditions in heating mode
in compliance with the provisions of the regulation UE 813/2013 (dry temperature (humid

on the value of the total acoustic power level is 2 dB (A). The value is determined in compliance
with EN 12102-1: 2017, used together with EN ISO 9614-2 which describes the test methods
with the intensimetric method.
Unit power supply V/~/Hz 3N~400V-50Hz* Ecomod Heat Pump Control command
circuit V/~/Hz 12/01/1950
Integrated command
circuit V/~/Hz 12/01/1950 Power supper to fans V/~/Hz 3N~400V-50Hz
Models
in kW Acoustic power level per octave band dB(A) Acoustic
power level
[LW(A)]
dB(A)
Acoustic
power
level at 1m
dB(A)
Acoustic
power level
at 10m
dB(A)
63 Hz 125 Hz 250Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz
26 47.5 57.2 64.8 62.1 66.0 61.4 55.1 70 54.1 38.5
32 48.8 58.0 65.6 62.9 68.1 63.7 57.4 72 56.1 40.5

01-07-2022 19 / 74
AHP60 26/32 kW - Installation, Use and Maintenance
2.4.3.2. Partial load
Sound levels refer to units at full load and in conditions guaranteeing a thermal capacity equal

14825, in accordance with the provisions of EU regulation 813/2013(dry bulb temperature (wet

tolerance on the value of the total sound power level is of 2dB(A). Value is determined according
to EN 12102-1:2017, used in conjunction with EN ISO 9614-1 which describes the test methods
with the intensimetric method
Models
in kW Acoustic power level per octave band dB(A) Acoustic
power
level
[LW(A)]
dB(A)
Acoustic
power level
at 1m dB(A)
Acoustic
power level
at 10m
dB(A)
63 Hz 125 Hz 250Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz
26 47,5 57,2 64,8 62,1 66,0 61,4 55,1 70 54,1 38,5
32 48,8 58,0 65,6 62,9 68,1 63,7 57,42 72 56,1 40,5

20 / 74 00U07352250-A_ EN
AHP60 26/32 kW - Installation, Use and Maintenance
2.5. Description
2.5.1. Models AHP60 26 - 32 kW
Figure 1 - Frame sizes (in mm) for both 26kW and 32kW
Front viewRight hand side view
Rear view
Top view
*IN/OUT: 1”M G
**IN/OUT: 1”1/4 M G
E: electricity supply input
Dimensions and weight
Models 26 kW* 32 kW**
A - Length mm 1600 1600
B - Width mm 680 680
C - Height mm 1315 1315
Weight for shipping kg 250 265
Weight in service kg 240 255
