Idealight HT-LM-200SW User manual

USER MANUAL
200W LED Moving Spot + 16*10W LED Moving Wash
HT-LM-200SW
This manual contains important information.
Please read before operating fixture.

2
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
Non-professionals are not to disassemble the moving head LED
unit and lighting accessories inside.
Rated voltage range: AC110V-120V/60Hz or AC200V-240V /
50HZ (to be selected).
The unit should not be placed near flammable materials and should
maintain at least 1M distances from its projection area.
The moving head should only be used in ambient temperature: -15c
> 40c, the highest temperature of the surface of the lamp: 60c.
To keep away from the liquid substance and humid environment.
Before using the moving head please ensure a good earth is fitted.
The installation of the moving heads, you must check fixing screw
fasteners with additional security cable and a regular inspection
done.
LED consecutive working hours is not recommended for more than
10 hours per time.
Moving head should not be used in time when unusual conditions
are in play.
Moving head should be regular inspected of the rotation, external
accessories and paste parts, in a timely manner to prevent accident
or damage to the unit or persons.
Moving head fans should be checked weekly as it is easy to
accumulate the dust, so weekly cleaning of especially the cooling
air opening and fans, otherwise unit my over heat and cause
damage.

3
2 TECHNOLOGY REFERENCE
1. Voltage：AC110V-240V/50Hz-60Hz
2. Power consumptions：400W
3. Profile LED Source: Ultra bright 200W LED
4. Wash LED Source: 16x10w fourcolor LED
5. Product size: 45x33.5x68cm；Package size: 46x45x72.5cm
6. N.W:21.00Kg; G.W: 23.5Kg
3 FUNCTIONS INTRODUCTION
1. International universal control signal: DMX512
2. 39/32/20 DMX channels
3. Digital display
4. DMX, Sound, Auto, Slave/Master
5. 2 Gobos wheels: Fixed gobo wheel & Rotating gobo wheel
6. 7 gobos+White with Bi-directional rotate effect
7. Color wheel: 7 main colors+open with the rainbow
8. One rotating 3-facet prism
9. Gobo indexing, Focus, Zoom function
10. Program inside ,Adjustable flash frequency

4
4 DISPLAYCODE SETTING METHOS
LED 200W Spot and Wash Mixing Moving head button
MENU
【DMX】
System Mode DMX Mode Adder Setup Adder Setup
DMX Mode Adder Setup Adder Setup
【Sound】[So P1] [So P8] Sound-control mode
[Reverse] [Pan] enter [Yes] [No] Pan
[Reset] [Yes] [No] Reset
DMX Mode
Adder Setup Adder Setup
[20CH]
[001] [512]
[32CH] [001] [512]
[001] [512]
Enter
Enter
Enter
[39CH]
[Tilt] [Yes]
【
Auto
】
[Au P1] [Au P8]
Self
-
control mode
[No]
Tilt
Enter

5
5 DMX CHANNEL SHEET
Channel Mode
20CH 32CH 39CH Function Channel
Value
Function
CH1 CH1 CH1 Pan 0-255 0-540°
CH2 CH2 CH2 Tilt 0-255 0-270°
CH15 CH3 Pan Fine Tilt 0-255 Pan Fine
CH16 CH4 Tilt Fine 0-255 Tilt Fine
CH3 CH3 CH5 X, Y speed
Adjustment 0-255 From fast to slow
CH4 CH4 CH6 200W Dimmer 0-255 From dark to bright
CH5 CH5 CH7 200W Strobe
0-7
8-250
251-255
Turn on
Strobe from fast to slow
Turn off
CH6 CH6 CH8 Color: 7 colors+
White
0-15
16-31
32-47
48-63
64-79
80-95
96-111
112-127
128-255
White
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color from fast to slow
0-7
8-15
16-23
24-31
32-39
40-47
48-55
56-63
64-71
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 7 shake speed
from slow to fast

6
CH7 CH7 CH9
7 Static Gobos +
Open
72-79
80-87
88-95
96-103
104-111
112-119
120-127
192-255
Gobo 6 shake speed
from slow to fast
Gobo 5 shake speed
from slow to fast
Gobo 4 shake speed
from slow to fast
Gobo 3 shake speed
from slow to fast
Gobo 2 shake speed
from slow to fast
Gobo 1 shake speed
from slow to fast
Open
Gobo positive and
negative running from
slow to fast
CH8 CH8 CH10 7 Rotating
Gobos + Open
0-15
16-31
32-47
48-63
64-79
80-95
96-111
112-127
128-191
192-255
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo CW Fast > slow
Gobo CCW Fast >slow
CH9 CH9 CH11
Gobo Indexing
Rotation
0-15
16-95
96-115
116-135
136-155
156-175
176-215
216-255
Stop
Gobo Fine 0-360
Gobo Rotating 0-90
Gobo Rotating 0-180
Gobo Rotating 0-360
Gobo Rotating 0-720
Gobo self-rotating CW
from slow to fast
Gobo self-rotating
CCW rotating from

7
slow to fast
CH10 CH10 CH12 Focus 1 0-255 Focus from near to far
CH11 CH11 CH13 Focus 2 0-255 Focus from near to far
CH12 CH12 CH14 Double Zoom 0-255 Gobo from small to big
CH13 CH13 CH15 Prism
0-63(0-50)
64-255(51-
100)
Open
Prism In
CH14 CH14 CH16 Prism Rotation
0-15
16-136(101
-176)
137-255(17
7-255)
Stop
Rotate CW slow > fast
Rotate CCW slow > fast
CH15 CH17 Global Red 0-255
From dark to bright
8xleds
CH16 CH18 Global Green 0-255
From dark to bright
8xleds
CH17 CH19 Global Blue 0-255
CH18 CH20 Global White 0-255 From dark to bright
8xleds
CH19 CH31 CH21 LED Strobe 0-255 From dark to bright
CH20 CH32 CH22
Preset RGBW
color
0-7
8-15
16-23
24-31
32-39
40-47
48-55
56-63
64-71
72-79
80-87
88-95
96-103
104-111
112-119
120-127
No action
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color 8
Color 9
Color 10
Color 11
Color 12
Color 13
Color 14
Color 15

8
128-135
136-195
196-255
Color 16
Color gradually change
from slow to fast
Color suddenly change
from slow to fast
CH15 CH23 Red Zone 1 0-255 From dark to bright
CH16 CH24 Green Zone 1 0-255 From dark to bright
CH17 CH25 Blue Zone 1 0-255 From dark to bright
CH18 CH 26 White Zone 1 0-255 From dark to bright
CH19 CH27 Red Zone 2 0-255 From dark to bright
CH20 CH28 Green Zone 2 0-255 From dark to bright
CH21 CH29 Blue Zone 2 0-255 From dark to bright
CH22 CH30 White Zone 2 0-255 From dark to bright
CH23 CH31 Red Zone 3 0-255 From dark to bright
CH24 CH32 Green Zone 3 0-255 From dark to bright
CH25 CH33 Blue Zone 3 0-255 From dark to bright
CH26 CH34 White Zone 3 0-255 From dark to bright
CH27 CH35 Red Zone 4 0-255 From dark to bright
CH28 CH36 Green Zone 4 0-255 From dark to bright
CH29 CH37 Blue Zone 4 0-255 From dark to bright
CH30 CH38 White Zone 4 0-255 From dark to bright
CH39 Reset 250-253 Reset

9
6 DIFFICULTY RESOLUTION
The following is a list of problems and resolutions, should only be
preformed by professionally qualified staff.
1. LED not working
a) Check whether approaching the service life of LED, then
change it
b) Check whether LED circuitry is not loss or connect poorly
2. Beam appears flash or is patchy
a) The LED maybe approach the service life, then change it, or
the optical components are unclean.
b) LED has an accumulation of dust, so the LED and other parts
inside the lamp should be cleaned and maintained in regular
period.
3. LCD Display works intermittently
a) Check whether the fan running
b) Check inner temperature-response control plug is off
c) Check whether the circuitry is good and contacted properly
4. The computer lamp not controlled by controller during lighting
a) Check numeral starting address and the connection of
communication control circuit
b) The corresponding channel button of controller is open or not
c) Check whether the fuse on power supply input jack is broken
off

10
7 CLEANING
To make sure the stable run of the moving head, you should keep it clean.
All fans, lens and color filters, do not use any soluble detergent when
cleaning the color filter avoiding the damage to LED..
8 AFTER SERVICE
1. BIG company offer technical consultation to customers.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to stage light, also matching accessories are as follows：
accessories：1x Power cable
1x Signal cable
1x Users manual
2x Hanging Bracket


11
Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product in
normal state, you can made under the provisions of the warranty, show the warranty card and
purchase bills(copy), and enjoy free maintenance service in a specific service center or the
manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by something can not resistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
End User
Company Name:
Add:
Sale Sto
re
Link man:
Tel: Stamp
