Idem SCR-73-i User manual

SCR
-
Viper Safety Relays
SCR
-
73
-
i
The new generation of safety relays from IDEM
Single or Dual channel operation
The Viper Safety Relays range from
IDEM are designed to meet the latest safety standards and
offer enhanced LED diagnostics and simplified wiring. Applications include safety interloc
switches, emergency e-stop devices, door guard monitoring.
The Viper Safety Relays range includes output expansion units that can be directly wired to
SCR-73-i safety relay to increase the number of safety output contacts. The expansion modules
are available with either immediate or time-delayed output contacts.
The SCR-73-i internal logic uses force guided relays to achieve cross monitoring, this ensures
that a single fault does not lead to the loss of the safety function and that all faults are detected
at or before the next safety demand.
Monitored Manual or Auto Start/Reset
7 NC safety output contacts
3 NO Auxiliary output contacts
Contactor feedbac chec
Easy diagnosis of status via 6 LEDs
24Vac/dc operation
Up to PLe, SILCL 3, Category 4
45mm DIN rail mounting
Emergency stop and guard interloc
monitoring
Output expansion units available to
increase number of outputs.
Fun tional Des ription
When the control line inputs are closed and the start/reset condition
has been met the safety output contacts close.
The safety relay outputs open when the inputs are de-activated or if
there is a power failure. When dual channel inputs are used it is not
necessary to synchronise switching of the input channels.
When operating in the monitored manual reset configuration the
reset button must perform a ma e-then-brea action before the
safety relay will activate.
External device feedbac contacts can be monitored via the reset
loop.
Blo k Diagram and Conne tions
A1
Power Supply
S21
Auto Reset
53
-
54
Safety Output Contact 5
A2
Power Supply
S22
Manual Reset
63
-
64
Safety Output Contact 6
S11
24Vd.c. Control Voltage
13
-
14
Safety Output Contact 1
73
-
74
Safety Output Contact 7
S12
Control Line
23
-
24
Safety
Output Contact 2
81
-
82
Auxiliary Output Contact 1
S13
Control Line
33
-
34
Safety Output Contact 3
91
-
92
Auxiliary Output Contact 2
S10
Control Line
43
-
44
Safety Output Contact 4
101
-
102
Auxiliary Output Contact 3

To request this datasheet in other languages please contact [e-mail]
Um dieses Datenblatt in Deutscher Sprache wenden Sie sich bitte anfordem [e-mail]
Variants
Part No.
Des ription
280005 SCR-73-i, AC/DC 24 V, (50-60Hz), Fixed screw terminals
280005-P SCR-73-i, AC/DC 24 V, (50-60Hz), Pluggable Terminals
Appli ation Cir uits
Fig.1
SCR
-
73
-
i,
Daul
Channel, E
-
Stop,
Manual Reset
Fig.2
SCR
-
73
-
i, Dual Channel, Non
-
Conta t Swit h, Auto Reset
Fig.3
Auto Reset
Fig.4
Manual Reset
Fig.5
Conta tor Feedba k Che k (
Auto or
Manual Reset)
Ele tri al Conne tion
• A power supply unit with electrical isolation from the mains supply must be connected.
• External fusing of each safety output contact is necessary, a 4A slow-blow or 6A quic action must be provided.
• The maximum cabling and connecting resistance of control lines must not be exceed 300 ohms.

Pour obtenir cette fiche en Francais, euillez contacter [e-mail]
Para solicitor esta hoja de datos en Espanol, por fa our contacto con [email protected]om
IDEM Safety Swit hes
Viper Safety Relays
SCR
-
73
-
i
Dimensions Diagnosti LEDs
POWER Power to the safety relay.
RESET Reset loop S11-S21 or S11-S22 is
closed.
CH1 Channel 1 control loop S11-S12 is
closed.
CH2 Channel 2 control loop S13-S10 is
closed.
K1 Power to Internal relay K1.
K2 Power to Internal relay K2.
Safety Chara teristi s
Characteristic Data according to
IEC
62061
Safety Integrity Level
SIL3
PFH
8.4 E
-
10 (
1/h
) (0.8% of SIL3
(1 E
-
07 (1/h))
PFD
av
7.2 E
-
05 (
1/h
) (7.2% of SIL3 (1 E
-
03)
Characteristic Data according to
EN ISO
13849
-
1
Performance Level
e
Category
4
MTTF
d
71
a
(High)
Diagnostic Coverage
99%
(High)
Spe ifi ation
Standards
EN/ISO13849
-
1; EN
/SO13849
-
2; EN62061; EN60204
-
1; EN/ISO12100;UL508
Power supply Cir uit
Operating
v
oltage
24V AC/DC
Operating voltage tolerance
-
15%
-
+10%
Rated
s
upply
f
requency
50Hz
–
60Hz
Rated supply current
130mA
Power consumption
24V
4W
Control Cir uits
Rated output voltage
S11
24V DC
Input current
S11..S14
100mA
Response time
30ms
Release t
ime
25ms
Recovery time
Approx. 1s
Output Cir uits
Rated
o
utput
v
oltage
250VAC
Max.
c
urrent per output
6A
Max. t
otal current all outputs
8A
Safety contact brea ing
c
apacity
AC
250V, 1500V, 6A, Ohmic
230V, 4A for AC
-
15
DC
24V, 30W, 1.25A, Ohmic
24V, 30W, 2A, DC
-
13
Minimum contact load
10V 10mA
Min.
c
ontact fuses
4A Slow blow, 6A Fast blow
Contact material
AgSnO
2
Contact service
life
10 x 10
6
General Data
Rated impulse withstand voltage
4 V
Rated insulation voltage
250V
Degree of protection
IP
Temperature range
-
20C + 55C
Degree of contamination
2
Overvoltage
c
ategory
III
Weight
0.3 g
Mounting
Any position

IDEM SAFETY SWITCHES Ltd, 2 Ormside
Close, Hindley Industrial Estate, Hindley Green, Wigan, WN2 4HR UK. Tel: [phone] Fax.: [phone]
IDEM (USA
)
-
4416 Te hnology Way
, Fremont, CA 94538
Tel: [phone]
Email:
sales@idemsafety. om
Web:
www.idemsafety
. om
Do
.
10258
1
Feb
16
SAFETY WARNINGS
• Installation should only be arried out by
ompetent and authorised personnel and in
a ordan e with the instru tions in this manual.
• Only make ele tri al onne tions when the devi e
is isolated from the main supply.
• If “Automati Start” is sele ted be aware that
safety output onta ts will swit h immediately
after the power supply is onne ted.
• Opening the devi e will void the warranty. Never
attempt to repair any devi e.
• Adhere to Safety Che ks.
• DO NOT DEFEAT, TAMPER, OR BYPASS THE
SAFETY FUNCTION. FAILURE TO DO SO CAN
RESULT IN DEATH OR SERIOUS INJURY.
• L'installation doit être effe tuée par un personnel
ompétent et autorisé et en onformité ave les
instru tions de e manuel.
• faites uniquement des onnexions éle triques lorsque
l'appareil est isolé de l'alimentation prin ipale.
• Si "Démarrage automatique" est séle tionné être ons ient
que les onta ts de sortie de sé urité passeront
immédiatement après l'alimentation est onne tée.
• Ouverture de l'appareil annule la garantie. Ne jamais tenter
de réparer tout appareil.
• Adhérer à des ontrôles de sé urité.
NE DÉFAITE PAS, SABOTAGE, OU DE CONTOURNER LA
FONCTION DE SÉCURITÉ. MANQUEMENT À S'Y PEUT
ENTRAÎNER LA MORT OU DES BLESSURES GRAVES
Installation and Maintenan e Information Regarding UL 508
Installation should as per EN 60204-1 in addition to any local
regulations. The safety relay should be mounted inside a
cabinet enclosure and on a 35mm DIN rail according to DIN
EN 60715. No maintenance is required, there are no
serviceable parts. (Refer to Safety Chec s). The product is
designed to be a component of a customised safety
orientated control system. It is the responsibility of the user
to ensure the correct overall functionality of its systems and
machines. IDEM, its subsidiaries and affiliates, are not in a
position to guarantee all of the characteristics of a given
system or product not designed by IDEM.
Pilot Duty R300, B300
Single contact must be used
250V AC/DC / 6,0A
Resistive
Single contact must be used
250V AC/DC 6,0A
General Purpose
All contact at once can be used
USE COPPER OR COPPER-CLAD ALUMINUM CONDUCTORS
Maximum surround air temperature 40°C
Safety Che ks:
1. Ensure the appropriate safety level is achieved for the application function.
2. The safety functions must be tested regularly. For applications were infrequent use is foreseeable, the system must have a manual function
test. At least once per month for PLe Cat3/4 or once per year for PLd Cat3 (ISO13849-1 / ISO14119).
De laration of Conformity
Manufacturer: IDEM SAFETY SWITCHES Ltd.
2 Ormside Close, Hindley Industrial Estate, Hindley Green, Wigan, WN2 4HR, UK
Product: Safety Emergency Stop De ices
Model types: SCR-73-i
The abo e products conform to the safety requirements of the following directi es and standards:
Machinery Directi e 2006/42/EC
EMC Directi e 2004/108/EC
Low Voltage Directi e 2006/95/EC
EN 13849-1:2008+AC:2009
EN 13849-2:2012
EN 62061:2005+AC:2010+A1:2013
EN 61508 (Parts 1-7): 2011-02
EN 60204-1:2006+A1:2009+AC:2010
EN 50178:1997
Third Party Certification: NB 0035 TUV Rheinland Industrie Ser ice GmbH
M. Mohtasham
Managing Director
