Idex GAST M Series Manual

70-6410 F2-226 (Rev. D)
KEEP THIS DOCUMENT FOR FUTURE REFERENCE
CONTENTS:
General Information and Installation ........................................................................................................2
Operation and Maintenance ......................................................................................................................3
Troubleshooting and Accessories..............................................................................................................4
Exploded View and Parts Ordering Information.......................................................................................5
Warranty and Authorized Service Facilities..............................................................................................6
Visit us at our website
www.gastmfg.com
REGENAIR TYPE M & H SERIES
BLOWERS OPERATION &
MAINTENANCE MANUAL

2
This is the hazard alert symbol: . When you see this
symbol, be aware that personal injury or property dam-
age is possible. The hazard is explained in text follow-
ing the symbol.
Read this information carefully before proceeding.
The following is an explanation of the three different
types of hazards:
DANGER Severe personal injury or death will
occur if hazard is ignored.
WARNING Severe personal injury or death
can occur if hazard is ignored.
CAUTION Minor injury or property damage
can occur if hazard is ignored.
GENERAL INFORMATION
 CAUTION Operation of M & H Series blowers
without required ltration, or in excess
of rated maximum pressure or vacuum
limits can damage blower.
This blower is only to be used for purpose of pumping
air and under no circumstances be used with any other
gases. The blower must not be used for pumping uids,
particles, solids, or any substance likely to cause re or
explosion.
 WARNING Do not pump ammable or toxic gas-
ses or operate pump in an atmosphere
containing them. Severe personal
injury can occur if hazard is ignored.
 WARNING Keep hands or other body parts away
from blower suction. Failure to do so
could result in personal injury.
 WARNING Required ambient temperature for nor-
mal operation should not exceed 40˚C
(105˚F). For higher ambient operation,
consult the factory. Failure to do so
could result in re or property damage.
 WARNING Blower surfaces can become very hot
during operation. Do not touch these
surfaces until unit has been shut off
and allowed to cool.
Blower performance is reduced by lower atmospheric
pressure found at high altitudes, consult the factory or a
Gast distributor for details.
INSTALLATION
 CAUTION Remove any plastic caps before starting
blower. Failure to do so could result in
cap being blown out of port and minor
injury could result.
 CAUTION Clean out new plumbing before attach-
ing to blower inlet. Any foreign material
(burrs, chips, welding drops, slag, pipe
cuttings, excess sealants, sand, lime,
etc.) must be removed, or ltered out.
Any such material, no matter how small,
that enters blower can damage it.
Wiring
 WARNING Wiring must conform to all required
safety codes and be installed by a
qualied person. Grounding is required.
Electrical shock or re hazard can re-
sult from incorrect wiring.
Fuses protect wiring against short circuits. Thermal or
magnetic over-current cut-outs are absolutely neces-
sary to prevent motor overloading, due to lack of one
phase in a three phase electric system, high starting
frequency, or jammed blower. Required power will rise
as differential pressure increases. For motor wiring
diagram, see motor label. Be sure that all dual-voltage
motors are wired for your power source.
Mounting
WARNING Air temperature increases when pass-
ing through the blower. This may cause
outlet piping to reach high temperatures
and can cause burns. Access to these
areas should be guarded, limited, or
marked "WARNING HOT".
 CAUTION The exhaust air of this blower can
become very hot. Do not direct exhaust
air towards property that is temperature
sensitive.
 CAUTION Attach blower to solid surface before
starting, to prevent injury or damage
from unit movement.
The blower may be installed in any orientation as long
as the ow of cool, ambient air over the blower and mo-
tor must not be blocked. It is very important to install
blower in a well-ventilated area where temperature does
not exceed 40ыC. Check this temperature after blower
has been running for an hour.

3
Strong forced ventilation is often needed for larger
blowers. In vacuum service, hot discharge air of larger
blowers must be plumbed away to avoid overheating the
room or enclosure where blower is located. Discharge
excess hot air into atmosphere through a relief valve.
Plumbing
Connect motor and check direction of rotation before
connecting plumbing. The threaded pipe ports are
designed as connection ports only and will not support
heavy plumbing. Be sure to use the same or larger size
pipe and ttings to prevent air ow restriction and over-
heating of the blower.
When installing plumbing, be sure to use a small
amount of pipe thread lubricant. This protects the
threads in the blower ange. Dirt and chips, often found
in new plumbing, should not be allowed to enter the
blower. To minimize friction loss due to pipe ttings,
use one pipe size larger than that of the blower ports.
When installing two blowers in parallel, use plumbing
two whole pipe sizes larger in diameter than that of the
blower.
Accessories
CAUTION Blower must be installed with a proper
sized inlet lter, gauge, and relief valve.
Failure to do so may damage blower.
Consult the factory or see a Gast
distributor for recommendations.
Keep in mind lters progressively increase losses, due
to clogging. Install a vacuum gauge to monitor lter
restriction. Install a relief valve to avoid overloading of
large blowers, caused by changes in pressure or vacuum.
Do not install check valves that close with a strong
spring due to their large pressure loss. We recommend
the check valves listed in the accesssory section.
These have minimal pressure drop, are positive sealing,
and resistant to the high discharge temperatures of large
blowers.
OPERATION
 WARNING Do not run blowers with no air ow
through them. Protect with Gast
recommended pressure or vacuum re-
lief valves. Failure to do so will damage
blower.
 WARNING Solid or liquid material exiting blower or
piping can cause eye or skin damage.
Keep away from air stream.
 WARNING Some of these models may exceed
85 dB(A). When in close proximity
to these models hearing protection is
required.
Do not exceed maximum pressure or vacuum
capabilities marked on data label of unit. High alti-
tudes will reduce maximum pressure or vacuum duties,
consult the factory or a Gast distributor for details.
Fit correct sized pipes and choose accessories that
reduce to a minimum air friction load loss. Do not
throttle discharge or suction pipe to reduce capac-
ity. Throttling increases differential pressure, which
consequently increases power absorption and working
temperature. When the blower is ran at duties above
200mbar (80" H2O) metal pipe may be required for the
hot exhaust air.
Once blower is in operation, check the following:
• Working pressure or vacuum values.
• Relief valve pressure or vacuum setting, adjust if
needed.
• Measure motor current and compare with motor
nameplate data.
• Rated electrical overload cut-out.
• Check ambient and discharge air temperatures to be
sure they do not exceed allowed values one hour after
starting.
MAINTENANCE
 WARNING Power must be de-energized and dis-
connected before servicing. Be sure all
rotating parts have stopped. Electric
shock or severe cuts can result if
hazard is ignored.
The electric motor and blower need periodic cleaning
to remove accumulated dust and dirt. If they are not
cleaned, this can result in an increase in temperature, or
can reduce blowerservice life. It is not recommended
to attempt to repair a “M” or “H” series blower since
clearances and tolerances are very close.

4
 CAUTION Blower must be installed with a proper sized inlet
lter, gauge, and relief valve. Failure to do so may
damage blower. Consult the factory or see a Gast
distributor for recommendations.
An increase in differential pressure across an inlet lter
indicates its getting clogged. Clean inlet air lter as
often as needed, blowing down against the current to
clean it. Change cartridge when cleaning no longer gets
cartridge clean. A dirty lter cartridge causes a high
intake resistance resulting in an increase of differential
pressure, absorbed power, and working temperature.
Gast will not guarantee a eld rebuilt pump. If repairs
are needed contact factory or send blower to a Gast
Authorized Service Facility.
EDIUGGNITOOHSELBUORT
motpmySsisongaiDelbissoPydemeRelbissoP
rognitaehrevO
toHyllausunU
ahgihoottagninnuR
,ytudmuucavroerusserp
htobfonoitanibmocaro
roerusserP,evlaVfeileRallatsnI
ytudecuderro,eguaGmuucaV
dnuoSlamronbA tsniagagnibburrellepmI
gnisuoHrorevoC
ecivreSotnruterro,ytudecudeR
ytilicaF
niesaercnI
leveLdnuoS
taocnaclairetamngieroF
maoFrelffuMyortsedro
relffuM,maoFecalperronaelC
ngierofretlifro,parT,stnemelE
tuola
iretam
esuFnwolBmelborpgniriwlacirtcelE kcehcnosrepdeifilauQevaH
gniriwdnayticapacesuf
SEIROSSECCADEDNEMMOCER
B0603H4R,1-A0603H4R,A0603H4RsledoM A0903M4R
sretlifmuucavenilnI E151JA G151JA
sretliferusserptelnI F621JA F621JA
eguaGerusserP F331EA 331EA
eguaGmuucaV F431EA F431EAro431EA
evlaVkcehC F623HA F623HA
evlaVfeileRerusserP 480VP/zH05
190VP/zH06852GA
evlaVfeileRmuucaV 852GA 852GA

5
NOITAMROFNIGNIREDROSTRAP
feR
oN noitpircseDytQA0603H4R1-A0603H4RB0603H4RA0903H4R
1drauGnaF1A/ND11JBA/NA/N
2naF1A/N811JBA/NA/N
3swercSrevoC7629BB629BB629BB629BB
4revoC1D101JBVD101JBD101JBMD101JB
*
5tloBrotfahSdutS1817BB501JB817BB817BB
*
6rehsaWrellepmI1712JA712JA712JA712JA
7rellepmI1D201JBD201JBD201JBD201JB
8etalPgnitfiL1812JA812JA812JA812JA
9gnisuoH1D301JBVD301JBD301JBMD301JB
01smaoF8K211JAK211JAK211JAK211JA
11gnirpSrelffuM 2QF311JAQF311JAQF311JAQF311JA
21xoBrelffuM 1K401JAK401
JAK401JAK401JA
*
smihS
*
seireS011JAseireS011JAseireS011JAseireS011JA
tiKgnisuoH/rotoM 11-A0111HJ2-A0111HJA2111HJ1-0121HJ
.yrotcafehttlusnocsledomMEOcificepsroF.stinuledomkcotsroferadetsilstraP
.srebmunlairesdnaledometelpmocevigesaelp,strapgniredrorognidnopserrocnehW
*
.tiKgnisuoH/rotoMehtnidedulcnismetisetacidnI

AUTHORIZED SERVICE FACILITIES
Gast Manufacturing Corp
9970 Red Arrow Hwy.
Bridgman, MI 49106
TEL: [phone]
FAX: [phone]
www.gastmfg.com
Wainbee Limited
215 Brunswick Blvd.
Pointe Claire, Quebec
Canada H9R 4R7
TEL: [phone]
FAX: [phone]
Gast Manufacturing Corp
505 Washington Avenue
Carlstadt, NJ 07072
TEL: [phone]
FAX: [phone]
Wainbee Limited
5789 Coopers Avenue
Mississauga, Ontario
Canada L4Z 3S6
TEL: [phone]
FAX: [phone]
Brenner Fiedler & Assoc
13824 Bentley Place
Cerritos, CA 90701
TEL: [phone]
TEL: [phone]
FAX: [phone]
Japan Machinery Co., Ltd
Central PO Box 1451
Tokyo, 100-91 Japan
TEL: [phone]
FAX: [phone]
or: 81-3-3571-7896
Gast Manufacturing Co., Ltd.
Beech House, Knaves Beech
Business Centre, Loudwater
High Wycombe, Bucks HP 10 9SD
England
TEL: [phone]
FAX: [phone]
NOTE: General correspondence should be
sent to—
Gast Mfg. Inc./A Unit of IDEX Corporation
P O Box 97
Benton Harbor, MI 49023-0097
6
YOUR WARRANTY
Gast nished products, when properly installed and operated under normal conditions of use, are warranted by Gast to be free
from defects in material and workmanship for a period of twelve (12) months from the date of purchase from Gast or an autho-
rized Gast Representative or Distributor. In order to obtain performance under this warranty, the buyer must promptly (in no event
later than thirty (30) days after discovery of the defect) give written notice of the defect to Gast Manufacturing Incorporated, PO
Box 97, Benton Harbor Michigan USA 49023-0097 or an authorized Service Center (unless specically agreed upon in writing
signed by both parties or specied in writing as part of a Gast OEM Quotation). Buyer is responsible for freight charges both to
and from Gast in all cases.
This warranty does not apply to electric motors, electrical controls, and gasoline engines not supplied by Gast. Gastʼs warranties
also do not extend to any goods or parts which have been subjected to misuse, lack of maintenance, neglect, damage by accident
or transit damage.
THIS EXPRESS WARRANTY EXCLUDES ALL OTHER WARRANTIES OR REPRESENTATIONS EXPRESSED OR
IMPLIED BY ANY LITERATURE, DATA, OR PERSON. GASTʼS MAXIMUM LIABILITY UNDER THIS EXCLUSIVE
REMEDY SHALL NEVER EXCEED THE COST OF THE SUBJECT PRODUCT AND GAST RESERVES THE RIGHT, AT
ITS SOLE DISCRETION, TO REFUND THE PURCHASE PRICE IN LIEU OF REPAIR OR REPLACEMENT.
GAST WILL NOT BE RESPONSIBLE OR LIABLE FOR INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND,
however arising, including but not limited to those for use of any products, loss of time, inconvenience, lost prot, labor charges,
or other incidental or consequential damages with respect to persons, business, or property, whether as a result of breach of war-
ranty, negligence or otherwise. Notwithstanding any other provision of this
warranty, BUYERʼS REMEDY AGAINST GAST FOR GOODS SUPPLIED OR FOR NON-DELIVERED GOODS OR FAIL-
URE TO FURNISH GOODS, WHETHER OR NOT BASED ON NEGLIGENCE, STRICT LIABILITY OR BREACH OF
EXPRESS OR IMPLIED WARRANTY IS LIMITED SOLELY, AT GASTʼS OPTION, TO REPLACEMENT OF OR CURE
OF SUCH NONCONFORMING OR NON-DELIVERED GOODS OR RETURN OF THE PURCHASE PRICE FOR SUCH
GOODS AND IN NO EVENT SHALL EXCEED THE PRICE OR CHARGE FOR SUCH GOODS. GAST EXPRESSLY DIS-
CLAIMS ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE OR PURPOSE WITH RE-
SPECT TO THE GOODS SOLD. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTIONS SET
FORTH IN THIS WARRANTY, notwithstanding any knowledge of Gast regarding the use or uses intended to be made of goods,
proposed changes or additions to goods, or any assistance or suggestions that may have been made by Gast personnel.
Unauthorized extensions of warranties by the customer shall remain the customerʼs responsibility.
CUSTOMER IS RESPONSIBLE FOR DETERMINING THE SUITABILITY OF GAST PRODUCTS FOR CUSTOMERʼS USE
OR RESALE, OR FOR INCORPORATING THEM INTO OBJECTS OR APPLICATIONS WHICH CUSTOMER DESIGNS,
ASSEMBLES, CONSTRUCTS OR MANUFACTURES.
This warranty can be modied only by authorized Gast personnel by signing a specic, written description of any modications.
